Rasonic RLF-20KP User manual

1
LIVING FAN 優美扇
OPERATION MANUAL 使用說明書
RLF-20KP / RLF-20KV / RLF-20KI
僅適用於家庭使用 For Household Use Only
使用前請先詳細閱讀本說明書，並保存以便日後參考。
Please read this user manual before using the product and retain it for your
future reference.

2
安全注意事項 (請務必詳細閱讀及遵守安全指導)
-請務必嚴格遵守以下說明之注意事項以防止對使用者或其他人造成傷害或財物損失。
-用戶必須使用有安全認證的合格插座，否則，可能會引起火災的危險。
-此設備可供 8歲以上兒童，肢體、感官、心智殘缺或缺乏經驗和知識的人使用，但他們必須已獲得監
督和安全使用該設備的指導，並且了解其中的危害。兒童不應將本產品用於玩耍。清潔和保養，不得
讓兒童在沒有監督的情況下實施。本設備是不打算供與(包括兒童)身體，感官或智力有障礙，或缺乏
經驗和知識人士使用，除非他們是在負責他們安全的人員監督或有關使用該設備的指示下使用。兒童
應當受到監督以確保他們不會玩耍器具, 請勿讓兒童爬上直立扇。
-拔掉電源線插頭時須緊握，切勿拉扯電線。
-確保電源插頭完全插入插座，否則會引致觸電或插頭過熱而造成火災。
-要定期清除電源插頭及插座上之灰塵，否則引致絕緣不良而導致火災。
-若電源線有裸露或有損壞時，切勿使用本機。避免危險，必須交由信興電器服務中心有限公司維修。
如果電源線損壞或產品出現故障，必須交由信興電器服務中心有限公司維修，以避免危險。請勿私自
拆卸、檢修，或更換非生產商提供的配件。
-切勿過度擰捏，彎曲或扭轉電源線，否則線芯可能會曝露在外或折斷。
-嚴禁讓機體沾水，否則會導致漏電、短路、產品損壞及導致火災的可能。
-為避免過熱，禁止覆蓋機體。
-切勿將物品放置在機體上。
-手濕時切勿接觸電源插頭, 否則有觸電的危險。
-請勿讓手指或其他異物插入機體任何通風或排氣口, 這可能會導致觸電、身體損傷、火災或損壞機體。
-本機在使用時不可用力敲擊或震動機身.
-請勿在陽光直射下使用產品。
-電源線要擺放好，防止行走時拌倒。
-機器要放在平坦堅實的地面上工作。
-嚴禁在以下場所使用風扇: 接近氣體爐具/有易燃氣體的地方/有雨淋或容易被滴水的地方/接近殺蟲劑
的地方/油性的腐蝕性溶劑附近/高溫的地方/潮濕的地方/在化學物品、油、多塵的地方
-機體上方不可掛滴水的衣物或受到雨淋，避免進水發生漏電危險.嚴禁將可燃物及未乾的衣物覆蓋在機
器出風口上，避免發生火災或觸電危險。
-請勿在產品周圍噴灑殺蟲劑及可燃性噴霧劑, 否則可能使產品受損。
-為了安全起見，當人離開產品時，必須關機，以免發生意外事件。
-避免將產品出風口長時間、直接向幼兒吹風。
-產品清洗，檢修或移除面蓋前必須先切斷電源並拔掉電源線插頭。
-產品外殼清潔時，應用濕布(或加點洗潔精)抹擦，不要用有腐蝕性的洗滌劑或溶劑之類清潔，嚴禁用
水沖(淋)洗。
-不可將本機進、出風口貼近牆壁、窗簾等物品,否則會阻塞氣流,影響使用效果。
-本機在使用一段時間後,若出現異聲或風速不均勻的現象,可能是後殼進風口處的灰塵太多阻塞了氣流,
此時用毛刷清潔一下後即可恢復正常。
-產品長期不使用時，應拔下電源插頭，包好本機防止灰塵進入機內，並放置乾燥通風處存放。

3
部件名稱
操作面板
夏日模式 左右搖擺 逆向送風 冬日模式
開關 調低風量 調高風量 定時
遙控器操作面板
開關 →←逆向送風
調低風量 →←調高風量
左右搖擺 →←定時
夏日模式 →←冬日模式
前網/前罩
扇葉
操作面板
底座
手挽
後網/後罩
手動調節高度按鍵

4
使用方法
請把風扇放在一個稳定的平面上使用，把電源插頭連接到一個合適的電源插座上(220V-240V~
50Hz)。輕觸操作面板按鍵或搖控器按鍵，則可觸發相應的功能及會響“BI, BI”兩聲。
開關 : 接通電源後，會響“BI, BI”兩聲。按下開關鍵啟動風扇，預設風速為 1
段。
風速調校 : 按下“+”及 “-”鍵選擇 1至8段風速，相應風速指示燈將亮起。
開機預設風速為 1段。
定時設定 : 選擇所需的定時開關時間 (1 - 7 小時)，相應時間指示燈將亮起。
左右搖擺 : 啟動或關閉左右搖擺送風功能。
逆向送風 : 啟動或關閉逆向送風功能。
夏日模式 : 按下此功能鍵啟動夏日模式，則向前送風 2分鐘後，自動轉為逆向送
風1分鐘，如此循環。
冬日模式 : 按下此功能鍵啟動冬日模式，則逆向送風 2分鐘後，自動轉為向前送
風1分鐘，如此循環。
清潔保養
1. 清潔、保養或移動產品前，必須先關閉產品，然後拔除電源插頭。必須待風扇完全停止轉動後
才可清潔，以免受傷。
2. 先取下位於前網/前罩下方的一顆螺絲，將前網向左旋轉即可取下前網/前罩。
3. 向右旋轉將扇葉圓蓋取下，然後拆下扇葉清洗。
前網/前罩 →
扇葉圓蓋
螺絲

5
其他注意事項 :
-切勿將電源線、插頭或主機浸在水中清潔或在水龍頭下沖洗，風扇内部零件不可沾水。
-切勿使用鋼絲刷、汽油、火酒、醋或其他揮發、有毒或含腐蝕性液體清潔產品，以免損壞產
品。
-用微濕的布清潔風扇表面即可。
-可拆開後蓋取出濾網，把濾網於流水下清洗。
-清潔完畢，必須待產品完全乾燥，才可連接電源使用。
-儲存時，切勿將電源線纏繞在產品四周或壓住電源線，以免造成電源線損壞。
-建議最少每個月清潔產品一次。
-如長時間不使用產品，請將產品收藏回包裝盒内並放置在乾燥陰涼且安全的地方。
規格
產品型號
RLF-20KP / RLF-20KV / RLF-20KI
顏色
粉紅色 / 粉紫色 / 白色
額定電壓
220-240V 伏特～
額定頻率
50 赫茲
額定功率
25 瓦
外型尺寸 (寬×深×高）
260 x 250 x 510-630 毫米
淨重
2.18 公斤
特別聲明
1. 本資料上所有內容經過認真核對，如有任何印刷及內容上的誤解，本公司將保留解釋權。
2. 本產品若有技術改進，會編進新版說明書中，恕不另行通知；產品外觀及顏色如有改動，則以
實物為準。
3. 用戶如需要電子版使用說明書，請致電信興電工工程有限公司熱線查詢：2861 2767。
售後服務
由購買日期起之一年保修期內，經信興電器服務中心有限公司之服務人員證實乃在正常使用之情
況下發生者，本公司將提供免費修理及更換零件。經更換之任何損壞零件，將歸屬本公司。保修
範圍不包括修理或更換產品之附件、外接線及機殼等，如有需要服務時，用戶須另付費用。
用戶請於維修時出示購買收據 / 換購收據及保修證，如有任何疑問，請致電信興電器服務中心有
限公司熱線查詢：2406 5666。
如在保修證內所列之電器：1.) 曾經被非本公司技術人員明顯地或非明顯地進行改裝、更改或修
理；或 2)曾經被錯誤或不適當或疏忽使用、或因液體浸蝕、水濺、不正常供電、天災、意外或外
來因素造成損壞；或 3)並非安裝在陸上固定地點；或 4)不當安裝位置影響正常操作；或 5)非工
商業用型號產品，被用作工商業用途；或 6)用戶搬遷地址或更換物主而未能及時通知信興電器服
務中心有限公司者，保修證將自動失效。

6
SAFETY PRECAUTIONS (Be sure to read carefully and follow these safety directions)
-Be sure to observe the following safety precautions in order to avoid possible injury to
yourself or others and damage to your belongings.
-The user must use qualified socket with safety certification, or it may cause fire.
-This appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge
if they have been given supervision or instruction concerning use of the appliance in a
safe way and understand the hazards involved.
-Children shall not play with the appliance. Cleaning and user maintenance shall not be
made by children without supervision. Do not allow children to climb on the tower fan.
-Hold the main plug when disconnect from the power supply, never pull the supply
cord.
-Make sure main plug is fully inserted into socket. Loose engagement of main plug and
socket may cause electric shock or fire due to overheating of the main plug.
-Wipe off dust on the main plug and socket periodically. Accumulation of dust on main
plug may cause poor insulation and may result in fire.
-Do not use the fan when the power cord or main plug is damaged。If the supply cord is
damaged, it must be replaced by the Shun Hing Electric Service Centre Limited in
order to avoid the hazard. If the power cord was damaged or the fan was malfunction,
please take the fan to Shun Hing Electric Service Centre Limited for repairing, please
do not dismount, repair or replace with parts and accessories without authorities.
-Do not pinch, bend, or twist the power cord excessively. The core conductors may be
exposed or broken which may cause electric shock, short circuit, fire and product
damage.
-Do not contact with water. It may cause fire and electric shock.
-Do not cover the fan in order to avoid overheating.
-Please do not put any object on the fan body.
-Never touch the fan with wet hands to avoid electric shock.
-Do not insert fingers or conductive object into the front and back air outlets of the
machine to avoid the risk of human injury or electric shock.
-Avoid any shocks, frictions or concussions to the fan.
-Do not put the fan under the power socket when using the fan.
-Do not use the fan in the sunshine.
-Put the power line correctly in case trip over by the cord.
-Put the fan on the flat and stable ground when using the fan

7
-Do not use the fan under the following situation: Near gaseous fuel cooker/ Place full
of inflammable gas/ Place expose to rain or water pour/ Near insecticide/ Oil corrosive
solvent/ High temperature/ High humidity/ Near chemistry, oil, dust area
-Please do not pour water into the machine or hang wet clothes over the machine so as
to avoid current leakage and electric shock; Please do not put flammable materials
and wet clothes covered on the air outlet so as to avoid risk of fire or electric shock.
-Please do not spray solvent or flammable liquid to the fan as it may cause damage to
the fan.
-Please shut down the machine before the user leave the machine so as to avoid
accidents.
-Avoid continuously exposure of direct wind from the fan especially to infant and
children.
-The power must be cut off and unplugged before cleaning or maintenance. Ensure
that the fan is switched off from the supply main before removing guard/ cover.
-Please clean the machine by using a damp cloth or a damp cloth with some mild
detergent, do not use corrosive detergent or solvent and such similar cleaning
products, do not pour water into the machine.
-Please do not put the air intake and outlet of the fan close to the wall or curtain,
otherwise the air flow will be blocked and affect the fan performance.
-If it occurs problems of abnormal sound or uneven wind speed after using for some
time, perhaps there is too much dust in the air intake grid and make the air flow
blocked, the fan could get right by cleaning the fan with a plastic brush.
-Cut off the power if the unit is not used for a long period of time. Pull out the plug,
pack the fan well to protect it away from dust and keep it in the dry, well-ventilated
and clean place.

8
PART NAME
CONTROL PANEL
Summer mode Left/Right Reverse Winter mode
On/Off Speed (Minus) Speed (Plus) Timer
REMOTE CONTROL
On/Off →←Reverse
Speed (Minus) →←Speed (Plus)
Left/Right →←Timer
Summer mode →←Winter mode
Front cover/ Guard
Fan blade
Control panel
Base
Back cover/ Guard
Height adjustment button
Handle

9
HOW TO USE
Place the fan on a stable flat surface. Insert the plug into a 220V-240V~50Hz electrical
power supply outlet. Press the buttons on the control panel or the remote control to
select functions. You can hear “Bi, Bi” after selection.
On/Off : Insert the plug, you can hear “Bi, Bi”. Press the button to turn
the unit on or off. Default fan speed is 1.
Speed : Set your desirable fan speed (1 –8 speed) by pressing “+”or
“-”buttons. Corresponding speed indicator light turn on. Default fan
speed is 1.
Timer : Activate the timer, 1 - 7 hours. Corresponding time indicator light
turn on.
Left/ Right Oscillation : Activate or deactivate horizontal oscillation of the
fan.
Reverse : Activate or deactivate reverse wind direction of the fan.
Summer Mode : Press the button to turn on Summer mode. Wind blows
forwards for 2 minutes and then blows backward for 1 minute, the wind
direction keeps switching continuously.
Winer Mode : Press the button to turn on Summer mode. Wind blows
backwards for 2 minutes and then blows forward for 1 minute, the wind
direction keeps switching continuously.

10
CLEANING AND MAINTENANCE
1. Always unplug the unit before moving or servicing. Unplug the unit and wait until the
fan stop running before cleaning.
2. Unscrew (in the bottom of the front cover) and turn the front cover anti-clockwise
carefully
3. Turn fan blade cover to the right and take fan blade out for washing.
Front cover →
Fan blade cover
screw
Additional Advices
- Do not immerse the power cord, plug and the whole unit into water or rinse under the
tap.
- Do not use gasoline, benzene, thinner, poisonous or corrosive detergent to clean the
unit to avoid damage of the appliance.
- Use a damp cloth to clean the surface of the fan.
- Filter and rear cover must be install before use.
- When store, never wrap the power cord tightly around the appliance or put any
pressure to the power cord so as to avoid power cord damage.
- Clean the fan every month.
- If the fan will not be used for a long time, store it in the cool, dry and safety place.
SPECIFICATION
Model
RLF-20KP / RLF-20KV / RLF-20KI
Colour
Pink / Velvet / White
Rated voltage
220-240V～
Rated frequency
50Hz
Rated power
25W
Dimension (W x D x H)
260 x 250 x 510-630mm
Net weight
2.18kg

11
SPECIAL AVOWAL
1. The information above has been checked. Our company reserves the hermeneutic
power to any printing errors or misunderstanding on the content.
2. If there are technical improvements on the appliance, the operation manual will be
updated without any prior notice. The product appearance and color are subject to the
actual appliance.
3. The e-copy of user manual can be sent by e-mail on requested, please call Shun Hing
Electric Works & Engineering Co. Ltd. hotline at 2861 2767.
AFTER SALES SERVICES
For any defect, in the judgment of technician from Shun Hing Electric Service Centre
Limited, caused under normal use, we are responsible for repairing or replacing parts of
the said electrical appliance free of charge within one year guarantee period commencing
from the date of purchase. Any defective part which has been replaced shall become our
property. Guarantee service does not cover the repair or replacement of accessories,
external cables or cabinet, etc. Additional charges shall be levied if services are required.
Please present the official invoice and the guarantee certificate with the sales point‘s chop
or the redemption center‘s chop for free maintenance. For enquiries, please call Shun
Hing Electric Service Centre Limited hotline at 2406 5666.
Free guarantee service will not be provided to the fan if: 1) it has been explicitly or
implicitly modified, tampered with, altered or repaired in any way by persons other than
technicians of the Company. Or 2) it has been damaged through misuse, negligence,
liquid ingress or corrosion, power interruption, natural calamities or accident or external
factors. Or 3) it is not a fixed installation on land. Or 4) the normal operation of the fan is
affected by improper installation. Or 5) the domestic model of fan is used for industrial or
commercial purpose. Or 6) the change of location or ownership of the fan and did not
inform Shun Hing Electric Service Centre Limited.

12
信興電工工程有限公司
SHUN HING ELECTRIC WORKS & ENGINEERING CO., LTD
辦公室: 香港九龍尖沙咀東部麼地道 67 號半島中心 9樓909-912 室
OFFICE: ROOM 909-912, 9/F, PENINSULA CENTRE, 67 MODY ROAD, TSIM SHATSUI EAST,
KOWLOON, HONG KONG
電話 Tel: [phone] 傳真 Fax : [phone]
網址 WEBSITE: www.rasonic.com 電郵 EMAIL: [e-mail]
保養及維修 Maintenance and Repair Service:
信興電器服務中心有限公司
SHUN HING ELECTRIC SERVICE CENTRE LTD.
辦公室: 香港新界葵涌勝耀街8號信興中心18樓
OFFICE: 18/F SHUN HING CENTRE, 8 SHING YIU STREET, KWAI CHUNG, N.T., HONG KONG
電話 Tel: [phone] 傳真 Fax: [phone]
網址 Website: www.shunhing-service.com
消耗品/附件銷售熱線 Consumable/Accessories Sales Hotline:
電話 Tel: [phone]
客戶服務中心 Customer Service Centres:
香港新界葵涌勝耀街 8 號信興中心19樓
19/F, Shun Hing Centre, 8 Shing Yiu Street, Kwai Chung, N.T
電話 Tel: [phone] 傳真 Fax: [phone]
澳門慕拉士大馬路193~199號南嶺工業大廈5樓I座
Avenida de Venceslau de Morais, No. 193~199, 5 andar - I, Edf. Industrial Nam Leng, Macau
電話 Tel: [phone] 傳真 Fax: [phone]
有關最新之客戶服務中心資訊, 請參閱信興服務中心網址: www.shunhing-service.com或致電維修服務熱線
查詢。
For the latest information of customer service centres, please visit www.shunhing-service.com or call us at our
hotline.
Y18M03
