Rasonic RLF-9KIT User manual

1
僅適用於家庭使用。
For Household Use Only .
Living Fan
優美扇
RLF-9KIT
USER MANUAL
使用說明書
•使用前請詳細閱讀本說明書，並保存以便日後參考。
•本說明書中所有的圖片僅供解釋用途。
•Please read this user manual before using the product and retain it for future reference.
•All the pictures in this manual are for reference only.

2
一、安全注意事項 (請務必詳細閱讀及遵守安全指導)
-使用本產品時，請嚴格遵守以下注意事項。
不遵循或忽視這些安全注意事項會導致火災、觸電或個人傷害。
-請確保電力規格，必須符合本產品的電源要求。(220-240V~50-60Hz)
-切勿將本產品放在電源插座下。
-為減少觸電的潛在危險，請將插頭插在正確的電源插座上。
-本產品只適合在家居室內使用。
-此設備可供 8歲以上兒童，肢體、感官、心智殘缺或缺乏經驗和知識的人使用，但他們
必須已獲得監督和安全使用該設備的指導，並且了解其中的危害。兒童不應將本產品用
於玩耍。清潔和保養，不得讓兒童在沒有監督的情況下實施。
-本設備是不打算供與(包括兒童)身體，感官或智力有障礙，或缺乏經驗和知識人士使用，
除非他們是在負責他們安全的人員監督或有關使用該設備的指示下使用。兒童應當受到
監督以確保他們不會玩耍本產品， 請勿讓兒童爬上風扇。
-切勿過度擰捏，彎曲或扭轉電源線，否則線芯可能會曝露在外或折斷。拔掉電源線插頭
時須緊握，切勿拉扯電線，否則會導致電源線受損、漏電等危險。若電源線有損壞時，
為避免發生危險，必須交由信興電器服務中心有限公司進行更換。
-請找出電源線，避免把本產品或將其他物件壓在電源線上面。切勿將地毯、衣物或類似
物件覆蓋在電源線上面。請把電源線遠離容易被絆倒的地方。
-請定期清除電源插頭上之灰塵及確保電源插頭完全插入插座，否則可能會導致漏電的危
險。
-手濕時切勿接觸電源插頭， 否則可能引起觸電和短路。
-切勿在本產品操作時，干擾其運作。切勿將手指或其它物件，插入進風口或出風口，這
樣可能引發觸電、短路或火災等危險，或對本產品造成損壞。
-不可將本機進、出風口貼近牆壁、窗簾等物品，否則會阻塞氣流，影響使用效果。
-使用本產品時，請把本產品放在穩固、平坦和水平的表面，以免產品翻倒。
-嚴禁在以下場所使用風扇: 接近氣體爐具/有易燃氣體的地方/有雨淋或容易被滴水的地
方/接近殺蟲劑的地方/油性的腐蝕性溶劑附近/高溫的地方/潮濕的地方/在化學物品、
油、多塵的地方
-為避免過熱，禁止覆蓋機體。
-如果電源線損壞或產品出現故障，必須交由信興電器服務中心有限公司維修，以避免危
險。請勿私自拆卸、檢修，或更換非生產商提供的配件。
-嚴禁讓機體沾水，否則會導致漏電、短路、產品損壞及導致火災的可能。
-切勿將物品放置在機體上。
-本機在使用時不可用力敲擊或震動機身。
-請勿在陽光直射下使用產品。
-機體上方不可掛滴水的衣物或受到雨淋，避免進水發生漏電危險。嚴禁將可燃物及未乾
的衣物覆蓋在機器出風口上，避免發生火災或觸電危險。
-請勿在產品周圍噴灑殺蟲劑及可燃性噴霧劑， 否則可能使產品受損。
-為了安全起見，當無人看管產品時，必須關機，以免發生意外事件。
-避免將產品出風口長時間、直接向老年人，小孩或病人吹風。
-產品清洗，檢修或移除面蓋前必須先切斷電源並拔掉電源線插頭。
-產品外殼清潔時，應用微濕布(或加點洗潔精)抹擦，不要用有腐蝕性的洗滌劑或溶劑等
清潔用品，嚴禁用水直接沖(淋)洗。
-本機在使用一段時間後，若出現異聲或風速不均勻的現象，可能是後殼進風口處的灰塵
太多，阻塞了氣流，此時使用毛刷清潔後，即可恢復正常。
-產品長期不使用時，應拔下電源插頭，包好本機防止灰塵進入機內，並放置乾燥通風處
存放。

3
二、產品介紹
部件名稱
操作及顯示面板

4
遙控器
三、清潔保養
清潔、保養或移動產品前，必須先關閉產品，然後拔除電源插頭。必須待風扇完全停止轉動後才可清潔，
以免受傷。
其他注意事項 :
建議最少每月清潔產品一次。
切勿將電源線、插頭或主機浸在水中清潔或在水龍頭下沖洗，風扇内部零件不可沾水。
切勿使用鋼絲刷、汽油、火酒、醋或其他揮發性、有毒或腐蝕性液體清潔產品，以免損壞產品。
可使用管狀的清潔器、除塵棒或吸塵機等去清除後網蓋塵埃。
可用微濕抹布清潔風扇表面。
清潔完畢後，必須待產品完全乾燥，才可連接電源使用。
如長時間不使用產品，請將產品收藏回包裝盒内並放置在乾燥
陰涼且安全的地方。儲存時，切勿將電源線纏繞在產品四周或
壓住電源線，以免造成電源線損壞。
如何卸下扇葉和前網罩 :
1. 先用螺絲刀鬆開及取出後網右側一粒螺絲。
2. 按住後護板並將左護板向左(逆時針)並將其拉出以將其取出。
3. 按住扇葉，然後順時針旋轉扇葉安裝蓋。
4. 將扇葉拉向自己以將其卸下。
如果卸下前網罩和扇葉，則可以從內部對其進行清潔。
前網罩(香氛墊片等需要拆除)和扇葉可以清洗。
洗滌後，徹底乾燥。

5
四、安裝步驟
1. 主體底座和中柱
可以在已安裝或不使用中柱的兩個階段下設
置主機高度。
2. 安裝中柱
1. 將主機底座放置在平穩的地方。
2. 將中柱安裝到主體底座上。
3. 將主機風扇安裝地中柱上。
* 安裝時，請注意○
1○ 2○ 3時中柱和主機風扇
安裝方向。
* 拆卸主機風扇和中柱時，按下背面的鎖定
按鈕(如下所示)將其卸下。
3. 不使用中柱
1. 將主機底座放置在平穩的地方。
2. 將主機風扇安裝到主機基座上。
* 注意風扇單元方向。
* 降低高度時，請勿使用中柱。請小心存放
中柱。
* 拆卸主機風扇和中柱時，按下背面的鎖定
按鈕(如右圖所示)將其卸下。
五、使用方法
使用前準備
將電池插入搖控器
○
1搖控器背面有一個電池盒。請在壓下標籤的同時將其拉出
○
2正面朝上插入硬幣形鋰電池(CR2032)
○
3插入電池後，滑動電池盒，然後插入並固定電池盒。
功能說明
請將主機放置在平穩的地方上使用。把電源插頭連接到一個合適的電源插座上 (220V-240V~
50-60Hz)。輕觸操作面板按鍵或遙控器按鍵，則可觸發相應的功能。

6
【開/關機鍵】
接通電源後，會響“BI, BI”兩聲。
按下開關機鍵後初次啟動風扇，預設風速為 1開始並且沒有擺動。
【上下擺頭鍵】
啟動或關閉上下擺頭功能。
*本機無法手動調節送風角度。開啟電源並使用擺動操作功能調整上下左右角度，
以調整送風方向。
【自然/睡眠模
式鍵】
在操作過程中，按主機或搖控器上的自然/睡眠風按鈕可切換功能。
自然風功能
調節風量並模擬重現自然風。
通過切換主機或搖控器上的風量按
鈕來改變風量。
自然風模式改變如下 :
-超強 (風量 7, 8) - 超強自然風-強自然風-中自然風-弱自然風并隨時間變化。
-強(風量 5. 6) - 強自然風-中自然風-弱自然風并隨時間變化。
-中(風量 3. 4）- 中自然風-弱自然風并隨時間變化。
-弱(風量 1. 2) - 與弱自然風相同。
睡眠風功能
按下此功能鍵進入相對的自然風檔位，每 30 分鐘降低 1個自然風檔位，最後停留
在最低檔位自然風段速。
關燈模式
按住主機或搖控器上的自然/睡眠按鈕(3 秒鐘或更長時間)，以設置熄燈模式並關閉
點亮/閃爍的顯示燈。再次按主機或搖控器上的按鈕以輸入操作，解除熄燈模式，
並且指示燈以正常亮度點亮和閃爍。
【風速鍵】
風量可以設置為 1至8級。可使用主機或搖控器上風量按鈕進行風量調整。每按一
次風量按鈕，風量將增加一級。風量為 8之後，風量恢復為 1。
【預約/定時鍵】
選擇所需的定時開關時間 (1 / 2 / 4 /8 小時)，相應時間指示燈將亮起。
【左右擺頭鍵】
啟動或關閉左右擺頭功能，搖擺操作可選擇左右 30°/60°/90°擺動。每次按下左右
搖擺按鈕，左右搖擺角度按下圖序列改變，並且對應的顯示燈會切換。
*本機無法手動調節送風角度。開啟電源並使用擺動操作功能調整左右角度，以調
整送風方向。

7
額外功能
1. 顯示燈減光功能 : 以最後一次主機或遙控器操作 60 秒後，所有指示燈將自動切換至減光模式。再次
按主機或遙控器上的按鈕輸入操作，解除減光模式，並且顯示燈亮度恢復正常。
2. 自動關機的功能 : 在沒有輸入操作，連續運行 12 小時後，主機將自動停止操作，及進入待機狀態。
六、注意事項
本機有不斷電記憶功能，未斷電情況下，再次開機時會以關機前狀態啟動。
禁止手動上下左右調節風扇頭部，否則可能造成產品自動擺頭不暢順或損壞。
七、產品規格
八、特別聲明
1. 本資料上所有內容經過認真核對，如有任何印刷及內容上的誤解，本公司將保留解釋權。
2. 本產品若有技術改進，會編進新版說明書中，恕不另行通知；產品外觀及顏色如有改動，則
以實物為準。
3. 用戶如需要電子版使用說明書，請致電信興電工工程有限公司熱線查詢：2861 2767。
九、售後服務
由購買日期起之一年保修期內，經信興電器服務中心有限公司之服務人員證實乃在正常使用之情況下發
生者，本公司將提供免費修理及更換零件。經更換之任何損壞零件，將歸屬本公司。保修範圍不包括修
理或更換產品之附件、外接線及機殼等，如有需要服務時，用戶須另付費用。
用戶請於維修時出示購買收據 / 換購收據及保修證，如有任何疑問，請致電信興電器服務中心有限公司
熱線查詢：2406 5666。
如在保修證內所列之電器：1.) 曾經被非本公司技術人員明顯地或非明顯地進行改裝、更改或修理；或 2)
曾經被錯誤或不適當或疏忽使用、或因液體浸蝕、水濺、不正常供電、天災、意外或外來因素造成損壞；
或3)並非安裝在陸上固定地點；或 4)不當安裝位置影響正常操作；或 5)非工商業用型號產品，被用作
工商業用途；或 6)用戶搬遷地址或更換物主而未能及時通知信興電器服務中心有限公司者，保修證將自
動失效。
產品型號
RLF-9KIT
顏色
白色
額定電壓
220-240 伏特~50-60 赫茲
額定功率
25 瓦
產品尺寸 (寬×深×高）
300 ×300 ×600 / 900 毫米
淨重
4.7 公斤

8
1. Safety Precautions (Please read carefully and follow these safety
precaution)
Please observe the following safety precautions when using this appliance:
Failure or negligence in observing these safety precautions could cause fire, electric
shock or personal injury.
Make certain that the power source conforms to the electrical requirements of the fan.
(220-240V~50-60Hz)
Do not put the fan under the power socket when using the fan.
To reduce the risk of electric shock, this plug is intended to fit in a correct outlet.
This appliance is intended for household indoor use only.
This appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning use of the appliance in a safe
way and understand the hazards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children without supervision.
The appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless they
have been given supervision or instruction concerning use of the appliance by a person
responsible for their safety. Children should be under supervision to ensure they do not
play with or climb on this appliance.
Do not pinch, bend, or twist the power cord excessively, otherwise, the core conductors
may be exposed or broken. If the supply cord is damaged, it must be replaced by the Shun
Hing Electric Service Centre Limited in order to avoid the hazard. Do not pull the cord
when removing the power plug. It may cause power cord damage, electric leakage and
other hazards.
Locate the power cord so the appliance or other objects are not resting on it. Do not cover
power cord with carpeting, clothes or other similar objects. Arrange power cord away from
room traffic and where it will not be tripped over.
Wipe off dust on the plug periodically and make sure the plug is fully inserted in the socket,
otherwise, these may lead to the risk of electric leakage.
Never touch the fan with wet hands to avoid electric shock.
Do not block or tamper with the appliance in any manner while it is in operation. Do not
insert fingers or allow other objects to enter any ventilation or exhaust opening as it may
cause an electric shock, short circuit, fire or damage to the appliance.
Please do not put the air intake and outlet of the fan close to the wall or curtain, otherwise
the air flow will be blocked and affect the fan performance.
Always place this appliance on a stable, flat, level surface when operating, to avoid the
chance of the appliance overturning.
Do not use the fan under the following situation: Near gaseous fuel cooker/ Place full of
inflammable gas/ Place expose to rain or water pour/ Near insecticide/ Oil corrosive
solvent/ High temperature/ High humidity/ Near chemistry, oil, dust area
Do not cover the fan in order to avoid overheating.
If the supply cord is damaged or there is product malfunction, please contact Shun Hing
Electric Service Centre Ltd. for check and repair to avoid a hazard. Do not arbitrarily
disassemble or replace the parts. Disassembly or modification without permission will
affect the safety of the product.

9
This appliance cannot contact with water. It may cause fire and electric shock.
Please do not put any object on the fan body.
Avoid any shocks, frictions or concussions to the fan.
Do not use the fan in the sunshine.
Please do not pour water into the machine or hang wet clothes over the machine so as to
avoid current leakage and electric shock; Please do not put flammable materials and wet
clothes covered on the air outlet so as to avoid risk of fire or electric shock.
Please do not spray solvent or flammable liquid to the fan as it may cause damage to the
fan.
Please shut down the machine before the user leave the machine so as to avoid accidents.
Avoid continuously exposure of direct wind from the fan especially to the elderly, infant
and patients.
The power must be cut off and unplugged before cleaning or maintenance. Ensure that the
fan is switched off from the supply main before removing guard/ cover.
Please clean the machine by using a damp cloth or a damp cloth with some mild detergent,
do not use corrosive detergent or solvent and such similar cleaning products, do not pour
water into the machine.
If it occurs problems of abnormal sound or uneven wind speed after using for some time,
perhaps there is too much dust in the air intake grid and make the air flow blocked, the fan
could get right by cleaning the fan with a plastic brush.
Cut off the power if the unit is not used for a long period of time. Pull out the plug, pack
the fan well to protect it away from dust and keep it in the dry, well-ventilated and clean
place.

10
2. Product Description
Parts Name
Control and Display Panel

11
Remote Control
3. Cleaning and Maintenance
Always unplug the unit before moving or servicing. Unplug the unit and wait until the fan stop running
before cleaning.
Additional Advices
Clean the fan every month.
Do not immerse the power cord, plug and the whole unit into water or rinse under the tap.
Do not use gasoline, benzene, thinner, poisonous or corrosive detergent to clean the unit to avoid
damage of the appliance.
Please use a tubular cleaner, dust remover or vacuum cleaner to remove dust from the rear cover.
Use a damp cloth to gently clean the outer surface of the fan.
After cleaning, the product must be completely dry before connecting to the power supply.
If the fan will not be used for a long time, store it in the cool, dry and safety place. During storage,
never wrap the power cord tightly around the appliance or put any pressure to the power cord so as to
avoid power cord damage.
Disassembly of the blades & front guard
1. Use a screwdriver to loosen and then take out a screw on the
right side of the back guard.
2. Hold the rear guard and turn the front guard
anti-clockwise to the left and remove it.
3. Hold the blade and rotate the knob clockwise direction.
4. You can clean inside after removing the blade and front guard.
The front guard (inner lids of aroma box must be removed)
and blade can be cleaned. Please be sure to store in a dry
environment after cleaning.

12
4. Installation Instruction
1. Assembly of base, middle tube and unit top
The middle tube can be removed or installed,
and the height can be adjusted freely.
2. Installed middle tube
When the product height needs to be increased
1. Put the base on a stabe position.
2. Insert the middle tube into the base.
3. Insert the unit top into the middle tube.
* In steps○
1○ 2○ 3,please be ware of the
mounting direction of middle tube and unit top.
*Press the lock button to remove the unit top
and middle tube
3. Removed middle tube
When the product height needs to be decreased
1. Put the base on a stable position
2. Insert the unit top into the base
*Please be ware of the mounting direction of
the base and unit top.
*Please store the middle tube properly when it
is not in use
*Press the lock button to remove the unit top
and middle tube.
5. How To Use
Preparation before use
Installation of Battery
○
1Pull out the battery case from the main body of the remote
control and pull out the battery holder from the gap.
○
2Insert into the coin lithium battery; keep the positive pole
upwards (CR2032).
○
3After inserting the battery, slide the battery box, then insert and
fix the battery box.

13
Function
Place the fan on a stable flat surface. Insert the plug into a 220V-240V~50-60Hz electrical power supply
outlet. Press the buttons on the control panel or the remote control to select functions.
[ON/OFF]
Insert the plug, you can hear “Bi, Bi” alarm sound.
Press the On/Off button to start running. The default fan speed is 1, oscillation
function is disable.
[Up & Down
Oscillation]
Press the button to activate or deactivate up & down oscillation during operation.
*This unit is not allowed for manual adjustment of air flow direction. After connected
to power, make use of up & down oscillation function to adjust air flow direction.
[Natural/Sleep
wind Mode]
Press the button on the unit or remote control during operation to select natural wind
mode or sleep mode.
Natural wind mode
Adjust air volume and imitate
natural wind.
Change air volume by switching
the speed button on the main unit or remote control.
The natural wind mode operates as follows:
-Super strong (Volume 7, 8) - Super
strongStrongModerateWeakChange with time
-Strong (Volume 5, 6) - StrongModerateWeakChange with time
-Moderate (Volume 3, 4) - ModerateWeakChange with time
-Weak (Volume 1, 2) - Feeble, same with natural wind
Sleep mode
Press this function key to enter the relative natural wind gear, reduce 1 natural wind
gear every 30 minutes, and finally stay at the lowest natural wind speed.

Light off mode
Press and hold the natural/sleep button (3 seconds or more) on the control panel or
remote control to set the light off mode and turn off the indicator lights. Press the
button on the control panel or remote control again to release the light off mode, and
the indicator lights will light up and flash with normal brightness.
[Speed]
The fan volume has 8 levels. The fan speed button on the main unit or on the remote
control can be used to adjust. Press the fan speed button each time, the fan volume
will increase by one level. After the fan volume is 8, the fan volume is restored to 1.
[Timer]
Activate the timer ( 1 / 2 / 4 / 8 hours), the corresponding time indicators light up.

14
[Left & Right
Oscillation]
If you press the left/right oscillation button during operation, the unit will swing left
and right (around 30°/60°/90°). Each time you press the left/right oscillation button,
the swing angle will change, and the indicator light will change accordingly.
*This unit is not allowed for manual adjustment of air flow direction. After connected
to power, make use of left & right oscillation function to adjust air flow direction.
Additional Function :
1. Indicator Light Dimming Function : After 60 seconds no operation change on control panel or remote
control, all indicator lights dim automatically. Press any button on control panel or remote control again,
deactivate indicator light dimming setting, the indicator lights will light up and flash with normal
brightness.
2. Auto Power Off Function : After 12 hours of continuous operation without pressing any button on control
panel or remote control, the fan will turn off automatically.
6. Precaution
The machine has memory function in uninterruptible power on state. Without power off, when you
turn on the unit again, it will operate at the last setting before turn off.
It is forbidden to manually adjust the fan head direction, otherwise the automatic head swing of the
product may not move smooth or may be damaged.
7. Specification
Model
RLF-9KIT
Colour
White
Rated Voltage
220-240V~50-60 Hz
Rated Power
25W
Product Dimension (W x D x H)
300 × 300 × 600 / 900 mm
Net Weight
4.7 kg

15
8. Special Avowal
1. The information above has been checked. Our company reserves the hermeneutic power to any
printing errors or misunderstanding on the content.
2. If there are technical improvements on the appliance, the operation manual will be updated without
any prior notice. The product appearance and color are subject to the actual appliance.
3. The e-copy of user manual can be sent by e-mail on requested, please call Shun Hing Electric Works
& Engineering Co. Ltd. hotline at 2861 2767.
9. After Sales Services
For any defect, in the judgment of technician from Shun Hing Electric Service Centre Limited, caused
under normal use, we are responsible for repairing or replacing parts of the said electrical appliance free of
charge within one year guarantee period commencing from the date of purchase. Any defective part which
has been replaced shall become our property. Guarantee service does not cover the repair or replacement of
accessories, external cables or cabinet, etc. Additional charges shall be levied if services are required.
Please present the official invoice and the guarantee certificate with the sales point’s chop or the redemption
center’s chop for free maintenance. For enquiries, please call Shun Hing Electric Service Centre Limited
hotline at 2406 5666.
Free guarantee service will not be provided to the fan if: 1) it has been explicitly or implicitly modified,
tampered with, altered or repaired in any way by persons other than technicians of the Company. Or 2) it
has been damaged through misuse, negligence, liquid ingress or corrosion, power interruption, natural
calamities or accident or external factors. Or 3) it is not a fixed installation on land. Or 4) the normal
operation of the fan is affected by improper installation. Or 5) the domestic model of fan is used for
industrial or commercial purpose. Or 6) the change of location or ownership of the fan and did not inform
Shun Hing Electric Service Centre Limited.

16
信興電工工程有限公司
SHUN HING ELECTRIC WORKS & ENGINEERING CO., LTD
辦公室: 香港九龍尖沙咀東部麼地道 67 號半島中心 9樓909-912 室
OFFICE: ROOM 909-912, 9/F, PENINSULA CENTRE, 67 MODY ROAD, TSIM SHATSUI EAST,
KOWLOON, HONG KONG
電話 Tel: [phone] 傳真 Fax : [phone]
網址 Website: www.rasonic.com 電郵 Email: [e-mail]
保養及維修 Maintenance and Repair Service:
信興電器服務中心有限公司
SHUN HING ELECTRIC SERVICE CENTRE LTD.
辦公室: 香港新界葵涌勝耀街2號信興中心11樓
OFFICE: 11/F SHUN HING CENTRE, 2 SHING YIU STREET, KWAI CHUNG, N.T., HONG KONG
電話 Tel: [phone] 傳真 Fax: [phone]
網址 Website: www.shesc.com
消耗品/附件銷售熱線 Consumable/Accessories Sales Hotline:
電話 Tel: [phone]
客戶服務中心 Customer Service Centres:
香港新界葵涌勝耀街2號信興中心1樓
1/F, Shun Hing Centre, 2 Shing Yiu Street, Kwai Chung, N.T
電話 Tel: [phone] 傳真 Fax: [phone]
澳門慕拉士大馬路193~199號南嶺工業大廈5樓I座
Avenida de Venceslau de Morais, No. 193~199, 5 andar - I, Edf. Industrial Nam Leng, Macau
電話 Tel: [phone] 傳真 Fax: [phone]
有關最新之客戶服務中心資訊, 請參閱信興服務中心網址: www.shesc.com或致電維修服務熱線查詢。
For the latest information of customer service centres, please visit www.shesc.com or call us at our hotline.
RLF/K/2108
