RatPac Ultrabait VR User manual

UltrabaitVR
Vandalresistantsteelbaitstation

FixingInstruction
Caution:Sharpedges,exercisecarewhilstfittingorservicingsteelbaitstations.

LightwallfixingbracketProductCodeVRA‐02
Masonrywalls–Useplasticplugsandheavygaugescrews

InserttwoM5boltsthroughshortflangeofbracketandfixtoboxbaseplateusingnutssupplied.
Mustbeassembledwithnutsontop(Pleasenotecentreholedoesnotalign)
Positionboxagainstwallwithbracketfitted,drilloneholeonlyandlooselyfitfirstplugandscrewto
preventtheboxmovingasthesecondholeisdrilled.Fitsecondscrew.


HeavyWallfixingbracketProductCodeVRA‐03(Vandalresistantbracket)
Masonrywalls–Use8mmmasonrydrill(200‐300mmlong)

Note:Pleaseensurebracketisheldfirmlybackwhendrillingmasonryortheholesmaybedrilledtoo
lowcausingfixingproblems.

Positionbracketanddrill8mmdiaholethroughoneelongatedholeintothemasonryandpushthe
firstsleeveboltsuppliedlooselyintotheholetopreventtheboxmovingsidewaysasthesecond
holeisdrilled
Fitsecondboltandtightenbothwitha10mmnutspinner.Caution,overtighteningmaydamage
brickwork.
Nowlowerboxontobracketandfixwithfournutssupplied,tightenwith10mmnutspinner.
Theboxmaynowbeadditionallyfoxedtofloorusing2frontholesifrequired.


FloorFixing(Nobracketrequired)
Recommendedfixings–Plasticrawlplugsand50mmheavygaugescrewsarenormallysufficientbut
inextremecircumstancesuse8mmsteelsleeveanchors,thoughthesemaybehardertoremoveif
theboxistoberelocated.

Positionbox,drill,plug,andscrew1sthole,nowcheckboxisparalleltowallanddrill,plugandscrew
2ndholethendrillandfitremainingscrews.


GroundStakeProductCodeVRA‐04
Removeboltandfixintogroundusing7lbhammer.Openboxandinsertboltthroughcentreholein
baseplateandscrewintothreadedholeintopofstake,tightenwithnutspinner.Donotover
tighten.
Onlyuseingroundwhichwillsufficientlyretainstakeasstakescouldcauseorbeusedtocause
injury.Ifindoubtconcreteinposition.


IMPORTANT‐Finalcheckforallfixingmethodsorfreestanding
Onceinstalledandtheboxlocked,rattlethelidupanddownatthelockendandcheckthatthereis
someverticalfreeplayapprox2mm.FreeplayisagoodindicatoronallUltrabaitthattheboxis
lockedproperly.

UltrabaitVR
Vandalresistantsteelbaitstation

Troubleshooting

Nofreeplayfollowinginstallation
Removebaittrayandretest,ifthefreeplayreturnspleasecheckthefollowing.
Thatthereisnotexcessivedirtunderthebaittray.
Thatbaitblocksarenotstackedabovethetopofthebaittray
Thatthereinforcingbars(iffitted)arepushedinproperly.
Thatthebaitspikesarenotfittedinthewrongholes,boxesfittedwith4spikeshave2longspikes
fitted
nearesttothecutoutinthebaittrayand2shorterspikesfittedawayfromthecutout.
Ifproblemspersist,removespikesandreinforcingbarstofindwhichiscausingtheproblem.

Nofreeplaywithoutbaittrayinplace–slackenfloorfixingstofindifdistortioninbaseplatecaused
byanunevenflooristheproblem.

Thekeywillnotturn
Tryadifferentkey
Liftthekeyoffthebottomslightlyandtryandturnagain
Checkthatdebrisinthekeyholeisnotstoppingthekeyfrombottoming

Thekeyturnsbutthelidwillnotlift
Rattlethelidupanddownatthelockendandcheckthatthereissomeverticalfreeplay,ifnot,turn
thekeywhilstpushingtheliddownfirmlyatthelockendthisshouldreleasethelock.
























