Raven 90C User manual

RAVEN® LITTER SERIES
STEP 1:
While standing
upright, release
buckles from litter.
Relaxed
Position
Figure 1
STEP 2:
Place litter on the ground
and completely extend with
the fabric side up.
NOTE:
When litter
is in the relaxed
position,
the hinges
closest to
you (when
holding the
handles)
will look like
Figure 1.
2.
1.
Raven®II Model 90C Litter
PN:60-0001 • NSN: 6530-01-432-5114
INSTRUCTIONS FOR USE
35 Tedwall Court • Greer SC 29650 • USA

STEP 4:
While maintaining hinges in the locked position,
apply firm, steady pressure on the spreader
bar with foot. Increase pressure with foot until
spreader bar locks
into place. 4.
NOTE:
To close and store
litter, repeat the
directions in
reverse order.
STEP 5:
Place patient on litter, securing
the straps around the patient, buckle
and pull straps tight to avoid patient
movement during transport. 5.
STEP 3:
Keeping the litter
straight as possible,
grab handles and
rotate inward until
all hinges rotate &
lock (see Figure 2).
NOTE:
This action
is best executed simultaneously using
2 individuals on each end of the litter.
Figure 2
3.
(OPENING INSTRUCTIONS CONTINUED)
RAVEN® LITTER SERIES
Raven®II Model 90C Litter
PN:60-0001 • NSN: 6530-01-432-5114
35 Tedwall Court • Greer SC 29650 • USA
REV.042319PN:ZZ-0227
