Raycus RFL-P20Q Installation instructions

版本号
密级
内部
A0
会签
阶段
标记
C
RFL-P20Q
20Q 激光器英文说明书
RFL-P20Q·JS02
部门脉冲激光器技术研究部
编写颜鹏晖 20210303
校对刘红20210305
审核李科20210305
标审李其军 20210305
批准黄保20210308
武汉锐科光纤激光技术股份有限公司
谢良
夏巨江
旧底图登记
号
/
底图登记号
/

User
Instruction
RFL-P20Q
Wuhan Raycus Fiber Laser Technologies CO., Ltd.
2021

Wuhan Raycus Fiber Laser Technologies CO., Ltd.
Pulsed Fiber Laser User’s Guide V2.1
Safety Information
Please read this instruction carefully and familiarize yourself with the information we have
provided before you use the product. In this brochure, important operation procedures, safety and
other information are provided for you and all future users. In order to ensure operating safely
and optimal performance of the product, please do according to following warnings, cautions and
other information.
a) Raycus pulsed fiber laser is classified as a high power Class IV laser device. Before
supplying the power to the device, please make sure that the correct voltage of 24V
DC power source is connected and the anode and cathode are right. Failure to connect
power source correctly will cause damage to the device.
b) The device emits invisible 1060~1085nm wavelength light with average power 20W.
Do not expose your eyes or skin to the radiation of the laser.
c) Do not take apart the device, because there are no replaceable accessories available for
users to use. Any maintenance can only be proceeded in Raycus.
d) Do not look into the light output end directly. Use appropriate laser safety eyewear
when operating the device.
Safety labels and locations
The two labels above is located on the top of the cover of the device, representing laser
radicalization.

Wuhan Raycus Fiber Laser Technologies CO., Ltd.
Pulsed Fiber Laser User’s Guide V2.1
Content
1. Description..............................................................................................1
1.1. Product description ........................................................................................................1
1.2. Actual configuration list ................................................................................................1
1.3. Environmental requirements and cautions.....................................................................1
1.4. Specifications·.............................................................................................................2
2. Mounting.................................................................................................3
2.1 Mounting dimensions ....................................................................................................3
2.2 Method of installation....................................................................................................3
3. Control Interface....................................................................................4
4. Operation Regulations...........................................................................7
4.1 Pre-inspection ................................................................................................................7
4.2 Operation procedures.....................................................................................................7
4.3 Cautions.........................................................................................................................7
5. Instructions for warranty, return and maintenance..........................8
5.1 General warranty ...........................................................................................................8
5.2 Limitations of warranty .................................................................................................8
5.3 Service and repairs.........................................................................................................8

Wuhan Raycus Fiber Laser Technologies CO., Ltd.
Pulsed Fiber Laser User’s Guide V2.1
1
1.Description
1.1. Product description
Raycus pulsed laser is an ideal high power laser source with high speed and high efficiency.
It is specially designed for industrial laser making system and other applications.
Compared with traditional lasers, pulsed laser has some unique advantages in increasing the
conversion efficiency of the pump light 10 times higher.Its low power consumption and
automotive design make it appropriate for operating both in and outside the lab. Besides, it is
exquisite and convenient for its independence in placement, free time in using and facility in
connecting to equipment directly.
The device can emit 1060~1085nm wavelength pulsed light under the control of industrial
laser’s standard interface driven by 24V DC power source.
1.2. Actual configuration list
Table 1. Configuration list
Items
Quantity
Remark
Fiber Laser module
1
User Guide
2
1.3. Environmental requirements and cautions
Pulsed laser should be driven by 24V DC±1V power source.
a) Caution: Make sure the corresponding wires of the device are properly grounded.
b) All the maintenance to the device should only be done by Raycus, because there is no
replacement or accessory provided with the device. Please do not try to damage the
labels or open the cover in order to prevent against electric shock, or the warranty will
be invalid.
c) The output head of the product is connected with an optical cable. Please be careful
handling the output head. Avoid dirt and any other contaminations. Please use the
specialized lens paper when cleaning the lens. Please lid the laser with protective cover
of the light isolator to be against dirt only when the laser is not installed in the device
or not in working.
d) If the operating the device fails to follow this instruction, the protective function will
be weakened. Therefore, it should be used under normal conditions.

Wuhan Raycus Fiber Laser Technologies CO., Ltd.
Pulsed Fiber Laser User’s Guide V2.1
2
e) Do not install the collimating device into the output head when the laser device is in
working.
f) The device has three cooling fans at the rear panel to dissipate heat. In order to
guarantee enough airflow to help giving heat off, there must be a space of at least
10cm’s width for airflow in front and rear side of the device. As the cooling fans are
working at blow condition, if laser is mounted in a cabinet with fans, the direction
should be same as laser’s fans.
g) Do not look into the output head of the device directly. Please do wear appropriate
laser safety eyewear during the time when operating the device.
h) Make sure the pulse repetition rate higher than 20kHz.
i) For the longest time without pulse is only 50 x 10-6s. If there is no pulse output, please
stopmarking at once, to avoid further damage of the device.
j) Power source sudden interruption will do great harm to the laser device. Please make
sure the power supply works continuously.
1.4. Specifications
Table 2.pulsed fiber laser specifications
Pulsed fiber laser
20
Wavelength（nm）
1064±5
Polarization
Random
Optical isolator
Yes
Nominal average output power (W)
≥20
Single pulse energy (mJ)
1@20kHz
Beam quality（M2）
<1.5
Beam Diameter（mm）
6～8
Pulse duration（ns）
90-110@20kHz
Pulse repetition rate（kHz）
20-60
Output Power Tunability（%）
10-100
Output Fiber Cable length（m）
3
Working voltage（VDC）
24±1
Power consumption（20℃）（W）
170
Cooling
Forced Air Cooled
Dimension W×D×H（mm）
260×391×120
Operating temperature（℃）
0℃～40℃
Store temperature（℃）
-20℃～60℃
humidity（%）
≤80

Wuhan Raycus Fiber Laser Technologies CO., Ltd.
Pulsed Fiber Laser User’s Guide V2.1
3
2.Mounting
2.1 Mounting dimensions
a) Fiber Laser module dimensions (As shown in Fig. 1).
Figure 1. Dimension drawing of laser module(Unit: mm).
b) Isolated output head dimensions (As shown in Fig. 2).
Figure 2. Dimension drawing of output isolator (Unit: mm).
2.2 Method of installation
a) Fix the module stable to the bracket and keep the laser in good ventilation.
b) Connect the power line to 24V DC power and ensure enough DC output power.Keep it
clear to the polarity of the electric current: anode-brown; cathode-blue; PE-yellow and

Wuhan Raycus Fiber Laser Technologies CO., Ltd.
Pulsed Fiber Laser User’s Guide V2.1
4
green. The definition figure is shown in Fig. 3.
Figure 3. Definition of power line wires
c) Make sure that the interface of the external controllermatches the laser and the control
cable is well connected to the laser’s interface. The recommended electrical connection
is shown in Fig. 4.
User’s
controller
DB25
Controller
interface
Power
supply
wire
Laser
Module
24V+(Brown)
L
N
GND
External GND
24V
power
supply 24V-(Blue)
Figure 4. Schematic of recommended electrical connection
d) The bending radius of the delivery fiber should not exceed 15cm.
3.Control Interface
There are DB9 and DB25 interfaces at the rear of the laser. The DB9 is a RS232 interface
only used for debugging, no needs to connect. And DB25 is the joint interface connecting control
system with laser system, please make sure the connection is reliable before operation. Feet of
the DB25 are defined as follows in Fig. 5.
24V+
GND
24V-

Wuhan Raycus Fiber Laser Technologies CO., Ltd.
Pulsed Fiber Laser User’s Guide V2.1
5
Figure 5. Connect port of controller
Table 3Definition of connect ports of controller
PIN No.
Name
Description
1-8 (D0-D7)
Power Setting
8 bit Parallel port;
D0 is minimum bit and D7 is maximum bit;
Range: 0-255 (hexadecimal: 0X00-0XFF); 0 is
minimum power and 255 is maximum power.
10,13-15,24-25
Ground
Digital GND
11,12,16,21
Laser alarms status
see alarm codes in the table below
17
VCC
+5V DC power supply input,
providing power for inside chips of DB25 to ensure
that the input and output signals are valid.
18
EE
Emission Enable (EE) signal.
HIGH: Emission Enable
LOW or disconnected: Emission Disable
19
EM
Emission Modulation (EM) input.
HIGH (>3V): Emission ON
LOW or disconnected (<1V): Emission OFF
20
Sync
Pulse Repetition Rate (Synchronization) input,
square wave.
22
Guide Laser signal
Guide Laser (red diode) ON/OFF input.
9,23
Obligate PIN
Reserved for Raycus only
a) The pump current of diode laser and the laser output power are controlled by setting
the value of PIN1-PIN8 (TTL level). PIN1-PIN8 can be set from 0～255，
corresponding to the laser output power from 0～100％(the actual laser power may
not be strictly linear with the setting value). The relationship between PIN value and
output power is shown in Table 4:
b) PIN 10,13,14,15,24,25 are all digital GND.
c) PIN 17 is the external 5V DC input, providing power for inside chips of alarm signal to
ensure that alarm signals are valid.
d) PIN 18 is the start signal of the MO. PIN19 is the input for the optical output signal.
The electrical level for both PIN18 and PIN19 are 5V. Before turning on PIN 19, MO
signal must be switched ON, in other word, the signal of PIN 18 must be ahead of PIN

Wuhan Raycus Fiber Laser Technologies CO., Ltd.
Pulsed Fiber Laser User’s Guide V2.1
6
19 at least 5 ms, and otherwise the laser machine may be damaged.
Table 4 Definition of power control PIN value
Setting 1
Setting 2
Setting 3
Setting 4
Setting 5
PIN 1
0
0
0
0
1
PIN 2
0
0
0
0
1
PIN 3
0
0
0
0
1
PIN 4
0
0
0
0
1
PIN 5
0
0
0
1
1
PIN 6
0
0
1
1
1
PIN 7
0
1
1
1
1
PIN 8
1
1
1
1
1
Current
~50 %
~75 %
~87.5 %
~93.75 %
100%
e) PIN 20 provides control of the frequency. The frequency range should be 20kHz~60
kHz, depends on the varying power levels of different laser machines.
ATTENTION: The frequency signal must be ahead of the EM signal at least 5 ms,
otherwise the laser machine may be damaged.
f) Definition of alarm signal
Table 5 Definition of warning signal
PIN 12
PIN 11
PIN 16
PIN 21
Alarm item
×
Low
Low
Low
Temperature alarm
×
Low
Low
High
Normal
×
Low
High
High
System alarm
×
High
Low
Low
Supply voltage
g) Internal circuit of input/output signal
Internal circuit of input signal：(current of input signal must be greater than 7mA)
Figure 6. Internal circuit of input signal

Wuhan Raycus Fiber Laser Technologies CO., Ltd.
Pulsed Fiber Laser User’s Guide V2.1
7
Internal circuit of output signal：
Figure 7. Internal circuit of output signal
4.Operation Regulations
4.1 Pre-inspection
a) Make sure the device appearance is in good condition and the output fiber is
neitherexcessively bended nor broken.
b) Make sure signal line of laser and marking system are properly connected.
4.2 Operation procedures
a) Starting procedures
Please make sure the control system is on before you turn on the fiber laser. Only after
at least 1 minute since the power turned on, the subsequent operations can be preceded.
b) Frequency set introductions
For modelP20Q, the frequency setting range is from 20kHz to 60kHz.
c) Laser marking checking
d) For the device initial testing, firstturn the power down to zero without turning on the
marking system after the device is successfully started. Then draw a quadrate, marking
continuously whileslowly increasing the power from zero to 100% at the same time.
Meanwhile, use a ceramic material to observe the laser and the laser should become
stronger, otherwise shut down the device and check. If operating normally, the
marking system can be used in common order afterwards.
4.3 Cautions
a) Marking frequency must be in the range of20~60 kHz.

Wuhan Raycus Fiber Laser Technologies CO., Ltd.
Pulsed Fiber Laser User’s Guide V2.1
8
b) It should not modulate the frequency while marking.
c) Stop marking first before shutting down the device, then turn the power down to zero
and cut the power off.
5.Instructions for warranty, return and maintenance
5.1 General warranty
All products are warranted by Raycus against defects and problems in materials and
workmanship during the warranty period according to the purchase order or specifications and
we guarantee the product will accord with the specification under normal use.
Raycus has the right to choose to repair or replace any product that proves to be defective in
materials and workmanship selectively during the warranty period. Only products with particular
defects are under warranty. Raycus reserves the right to issue a credit note for any defective
products produced in normal conditions.
5.2 Limitations of warranty
The warranty does not cover the maintenance or reimbursement of our product of which the
problem results from tampering, disassembling, misuse, accident, modification, unsuitable
physical or operating environment, improper maintenance, damages due to excessive use or not
following the instructions caused by those who are not from Raycus. Customer has the
responsibility to understand and follow this instruction to use the device. Any damage caused by
fault operating is not warranted. Accessories and fiber connectors are excluded in this warranty.
According to the warranty, client should write to us within 31days since the defect is
discovered. This warranty does not involve any other party, including specified buyer, end-user
or customer and any parts, equipment or other products produced by other companies.
5.3 Service and repairs
Raycus is responsible for all the maintenance, for there is no accessory available inside for
users to use. Please contact Raycus as soon as possible when problems under warranty about
maintenance happen to the product. The product returned with permission should be placed in a
suitable container. If any damage happens to the product, please notify the carrier in document
immediately.

Wuhan Raycus Fiber Laser Technologies CO., Ltd.
Pulsed Fiber Laser User’s Guide V2.1
9
All the items about warranty and service above provided by Raycus are only
for reference; formal contents about warranty and service are subject to the
contract.
© 2021Wuhan Raycus Fiber Laser Technologies Co. Ltd.
All Rights Recerved.
