Raytec XR8 Guide

Raytec Americas: [phone] • [email protected]
Raytec Ltd reserve the right to change specifications without prior notification or public announcement.
Version 1
www.raytecled.com
1277-D-0008
XR Bay luminaires are designed for use indoors, outdoors, wet locations, areas containing moisture, dirt, corrosion,
vibration and rough usage. The XR Bay luminaire has been certied for use on marine vessels inside, outside, and
in other severely wet saltwater environments.
UL 844, UL 1598, UL 1598A, and UL 8750;
CSA C22.2 No. 137, CSA C22.2 No. 250.0 and CSA C22.2 No. 250.13
Hazardous Location Certication:
Class I, Division 2, Groups ABCD;
Class II, Division 2, Groups FG;
Class III;
Class I, Zone 2, Group IIC;
Zone 22
3 x 3/4” NPT Conduit | Black: Line | White: Neutral | Green: Ground
Optional: Violet: 0-10V Dimming (+) | Grey: 0-10V Dimming (-)
For connections use wire rated to a minimum of 90°C. Class 1 Wiring only.
Dimming control wires must be rated 300V minimum for luminaires with sufx AC,
600V minimum for luminaires with sufx HV.
Certied to:
Connections:
Housing:
Ingress Protection:
Ambient
Temperature
Range:
Input Voltage:
Electrical Ratings:
Copper-free Cast Aluminium with Polycarbonate lens
IP66/67 | Suitable For Wet Locations. Marine Outside Type (Salt Water)
Based on luminaire sufx in table below: Sufx - AC: 120-277 VAC | Sufx - HV: 347-480 VAC
Class I Division 2 | Class I Zone 2 Class II Division 2 | Zone 22
XR8: -50°C to +75°C T3C All models -50°C to +50°C T3C
XR10: -50°C to +74°C T3C
XR15: -50°C to +74°C T3C
XR20: -50°C to +67°C T3
Application
Model Input Voltage Rated Wattage [Watts] Rated Voltage
[Volts]
Freqeuncy
[Hz]
XR8 AC Flood: 47 Optic: 60 120-277 50/60
HV Flood: 49 Optic: 64 347-480 50/60
XR10 AC Flood: 55 Optic: 75 120-277 50/60
HV Flood: 58 Optic: 77 347-480 50/60
XR15 AC Flood: 84 Optic: 103 120-277 50/60
HV Flood: 91 Optic: 107 347-480 50/60
XR20 AC Flood: 141 Optic: 156 120-277 50/60
HV Flood: 148 Optic: 160 347-480 50/60
Surface/Ceiling Mounting Installation
SPZ-XR
E477827

Raytec Americas: [phone] • [email protected]
Raytec Ltd reserve the right to change specifications without prior notification or public announcement.
Version 1
www.raytecled.com
1277-D-0008

5.0in
126mm 
5.2in
132mm 

16.0in
405mm 

17.3in
441mm 
0.5in
12.7mm
0.3in
6.8mm

0.5in
12.7mm
0.5in
12.7mm
0.5in
12.7mm
0.5in
12.7mm
Surface/Ceiling Mount Installation (Ordered Separately)
Step 1.
Step 2.
Step 3.
Warning! !
!
Warning
Warning
(Brackets are ordered separately)
Refer to alternate instructions if using Conduit, Hook, Wall, Pole or Yoke Mount
Inspect shipping package and contents to ensure no
damage has occurred during shipping.
Install Surface/Suspension Mount Brackets using the 8x
M6 hex cap bracket mounting screws. See diagram for
orientation of brackets. Torque M6 bolts to 5 Nm (45 in-
lbs).
A) For surface mounting conguration, mount luminaire
in desired locations using 4x 1/4-20 OR 4x M6 fasteners
and washers (Not provided). One mounting hole on each
bracket is keyed to allow partial pre-installation of two
fasteners for ease of install.
B) For ceiling mounting congurations, connect 4x
anchors to the 12.7mm (0.5”) holes. Suspension hardware
(Not provided) must be rated for a minimum of 180 lbs.
Step 2
Step 3A
Step 3B
To avoid the risk of re, explosion, or electric shock, this
product should be installed, inspected, and maintained by
a qualied electrician only, in accordance with all applicable
electrical codes.
To reduce the risk of electric shock, disconnect the luminaire
from the supply circuit before opening for installation and
servicing. Keep tightly closed when in operation.
Attention:
Le luminaire XR ne doit pas être orienté vers le haut à un degré
quelconque audelà de la position horizontale pour les installations
en zones dangereuses de classe II, division 2, zone 22 et classe III.
Warning:
The XR head must not face upwards any degree beyond the
horizontal position for Class II, Division 2, Zone 22 and Class III
hazardous location installations.
SPZ-XR
Warning POTENTIAL ELECTROSTATIC
CHARGING HAZARD
Avoid electrostatic discharge :
• Clean exterior lens surface with damp cloth only
LIGHT
BEAM
HORIZON

Raytec Americas: [phone] • [email protected]
Raytec Ltd reserve the right to change specifications without prior notification or public announcement.
Version 1
www.raytecled.com
1277-D-0008
Step 5.
Step 4.
Step 6.
Make wiring connections from branch circuit conductors
to factory provided lead wires using one of the 3/4” NPT
threaded entries. Follow wiring method requirements of
the Canadian Electrical Code or National Electrical Code
for the specic hazardous location of the installation.
For 0-10V Analog Dimming Control. Ensure dimming
control is certied and suitable for the classication of the
area of installation. Connect Violet (+) and Gray (-), driver
lead wires, to 0-10VDC control wiring.
• LED Drivers will source a combined maximum of
200µA for control needs
• 0-10V Controller must sink current from LED driver
10V control connections
Open XR Wiring Cover and allow cover to hang via
retention strap.
NOTE: Screws are captive fasteners and will remain
attached to the cover for ease of reinstall and to prevent
loss of fasteners.
NOTE: To aid in assembly and provide protection against
ingress, use of a petrolatum or soap thickened mineral oil
based thread lubricant/sealant is necessary.
Un-used conduit opening must be plugged to maintain
the integrity of the enclosure.
Close XR cover. Ensure the retention cable is not pinched
between XR Head and the XR cover. Tighten cover bolts
to 1.7 N-m (15 in-lbs).
Step 5
SPZ-XR

Raytec Americas: [phone] • [email protected]
Raytec Ltd reserve the right to change specifications without prior notification or public announcement.
Version 1
www.raytecled.com
1277-D-0008
PS 1
GROUND
(Factory)
BLACK
WHITE
GREEN
VIOLET
GREY
Wiring Diagram
Black - Line
White - Neutral
Green - Ground
Purple - DIM (+)
Grey - DIM (-)
*Any additional wiring not shown has been capped by the factory and is not to be used.
SPZ-XR

Raytec Americas: [phone] • [email protected]
Raytec Ltd reserve the right to change specifications without prior notification or public announcement.
Version 1
www.raytecled.com
1277-D-0008
Installation Steps
Pole Mount Installation
Step 1.
Step 2.
Step 5.
Step 6.
Step 3.
Step 4.
This SPX-BKT-XR-PM kit is intended for use with UL Listed XR luminaire as marked on the luminaire nameplate.
Accessory Package Contents
Refer to alternate instructions if using Conduit, Hook, Wall or Yoke Mount
Inspect shipping package and contents to ensure no
damage has occurred during shipping.
Install the provided plastic 3/4” bushing into side 3/4” NPT entry.
Insert and tension M6 set screw to pole to lock rotation.
Resume installation instructions provided with luminaire. (STEP
4 in XR Installation Instructions from the Surface/Ceiling Mount
installation provided with Luminaire).
Install Pole Mount and gasket with adhesive side applied
to mount using included M6 bolts and washers.
Torque to 5 Nm (45 in-lbs)
Thread luminaire assembly onto 1.5” NPT pole
NOTE: To aid in assembly and provide protection against
ingress, use of a petrolatum or soap thickened mineral oil
based thread lubricant/sealant is necessary.
Un-used conduit opening must be plugged to maintain
the integrity of the enclosure.
Step 3
Step 5
SPX-BKT-XR-PM QTY PART NAME
1POLE MOUNT
1POLE MOUNT GASKET
4M6 X 25mm HEX HEAD CAP SCREW
4M6 FLAT WASHER
1M6 X 16mm HEX HEAD CAP SCREW
13/4 NPT THREADED SMOOTH BORE BUSHING
SET SCREW
SPZ-XR
!Warning
Attention:
Le luminaire XR ne doit pas être orienté vers le haut à un degré
quelconque audelà de la position horizontale pour les installations
en zones dangereuses de classe II, division 2, zone 22 et classe III.
Warning:
The XR head must not face upwards any degree beyond the
horizontal position for Class II, Division 2, Zone 22 and Class III
hazardous location installations.
LIGHT
BEAM
HORIZON

Raytec Americas: [phone] • [email protected]
Raytec Ltd reserve the right to change specifications without prior notification or public announcement.
Version 1
www.raytecled.com
1277-D-0008
Installation Steps
Wall Mount Installation
Step 1.
Step 2.
Step 5.
Step 6.
Step 7.
Step 3.
Step 4.
This XR-WM kit is intended for use with UL Listed XR luminaire as marked on the luminaire nameplate.
Accessory Package Contents
Refer to alternate instructions if using Conduit, Hook, Pole or Yoke Mount
Inspect shipping package and contents to ensure no damage has occurred during
shipping.
Install provided 3/4 NPT conduit plugs in desired locations on wall mount. To maintain
ingress rating all NPT entries not used for wiring connections are required to be
plugged. Torque to 10 Nm (88 in-lbs)
NOTE: To aid in assembly and protection against ingress use of a petrolatum or soap
thickened mineral oil based thread lubricant/sealant is necessary.
Un-used conduit opening must be plugged to maintain the integrity of the enclosure.
Install Back Cover Plate with 4x M4 Flat head screws and adhesive backed gasket.
Apply gasket with adhesive side applied to mount main body. Torque to 1.7 N-m (15
in-lbs).
Mount luminaire assembly to desired location using 4x 1/4-20 OR M6 Screws or Bolts
(Not Provided).
Resume installation instructions provided with luminaire. (STEP 4 in XR Installation
Instructions from the Surface/Ceiling Mount installation provided with Luminaire).
Install provided 3/4” NPT plastic bushing onto side NPT entry on XR head, rotate
so that ats are parallel to lens surface to avoid interference with mount hardware.
Install Wall Mount main body with included M6 bolts and washers and adhesive backed
gasket. Apply gasket to mount with adhesive backed side. Torque to 5 Nm (45 in-lbs).
SPX-BKT-XR-WM QTY PART NAME
1WALL MOUNT
1WALL MOUNT PLATE
1WALL MOUNT PLATE SIDE GASKET
1WALL MOUNT GASKET
46 x 25mm SOCKET HEAD CAP SCREW
4M4x 10mm FLAT HEAD SOCKET CAP SCREW
4M6 FLAT WASHER
33/4 NPT HEX CAP PLUG
13/4 NPT THREADED SMOOTH BORE BUSHING
Steps 2 through 5
Step 6
[5.7in]
145mm
4x
6.8mmTHRUALL
[5.7in]
145mm
SPZ-XR
!Warning
Attention:
Le luminaire XR ne doit pas être orienté vers le haut à un degré
quelconque audelà de la position horizontale pour les installations
en zones dangereuses de classe II, division 2, zone 22 et classe III.
Warning:
The XR head must not face upwards any degree beyond the
horizontal position for Class II, Division 2, Zone 22 and Class III
hazardous location installations.
LIGHT
BEAM
HORIZON

Raytec Americas: [phone] • [email protected]
Raytec Ltd reserve the right to change specifications without prior notification or public announcement.
Version 1
www.raytecled.com
1277-D-0008
Installation Steps
High Vibration Yoke Installation (Ordered Separately)
Step 1.
Step 2.
Step 5.
Step 6.
Step 3.
Step 4.
This SPX-BKT-XR-YK kit is intended for use with UL Listed XR luminaire as marked on the luminaire nameplate.
Accessory Package Contents
Refer to alternate instructions if using Conduit, Hook, Pole, Wall Mount, or Yoke Mount
Inspect shipping package and contents to ensure no damage has occurred during
shipping.
Mount XR high vibration yoke to mounting surface using a minimum of 4x ¼-20 or M6
fasteners (not provided).
Thread installed wiring through opening in XR high vibration yoke mount and install XR
luminaire into yoke. The raised circular bosses on the XR cheek plates should register
inside of the large circular holes on the XR high vibration yoke mount arms. Rotate
luminaire to aim in the desired direction and fasten in place using 2x M6 socket head
cap screws and at washers per side. Torque fasteners to 5 Nm (45 in-lbs).
Resume installation instructions provided with luminaire. (STEP 4 in XR Installation
Instructions from the Surface/Ceiling Mount installation provided with Luminaire).
Make wiring connections from branch circuit conductors to factory provided
lead wires using one of the 3/4” NPT threaded entries. Follow wiring method
requirements of the Canadian Electrical Code or National Electrical Code for
the installation.
NOTE: Depending on which mounting hole is used in the curved slot, the
luminaire may be congured for an upward or downward adjustable swing.
Mount XR Cheek Plates to sides of XR luminaire using 4x M6 at head cap screws
per side. Thread one cheek plate over installed wiring during assembly. Torque
fasteners to 5 Nm (45 in-lbs).
SPX-BKT-XR-YK QTY PART NAME
1XR HIGH VIBRATION YOKE
2CHEEK PLATE
8M6 x 1 x 25mm SOCKET FLAT HEAD CAP SCREW
4M6 FLAT WASHER
4M6 x 1 x 16mm SOCKET HEAD CAP SCREW
Step 2
Step 4
8.0in
4.3in

203mm


108mm

3.8in

95mm

2.3in

59mm

10x
7mm
0.3in
THRUALL
SPZ-XR
!Warning
Attention:
Le luminaire XR ne doit pas être orienté vers le haut à un degré
quelconque audelà de la position horizontale pour les installations
en zones dangereuses de classe II, division 2, zone 22 et classe III.
Warning:
The XR head must not face upwards any degree beyond the
horizontal position for Class II, Division 2, Zone 22 and Class III
hazardous location installations.
LIGHT
BEAM
HORIZON

Raytec Americas: [phone] • [email protected]
Raytec Ltd reserve the right to change specifications without prior notification or public announcement.
Version 1
www.raytecled.com
1277-D-0008

4.3in
108.15mm


2.3in
59mm

0.27in
6.76mm
0.27in
6.8mm
1.7in
44mm
2.8in
70mm
Installation Steps
Yoke Mount Installation (Ordered Separately)
Step 1.
Step 2.
Step 5.
Step 6.
Step 7.
Step 3.
Step 4.
This SPX-BKT-XR-YM kit is intended for use with UL Listed XR luminaire as marked on the luminaire nameplate.
Accessory Package Contents
Refer to alternate instructions if using Conduit, Hook, Pole or Wall Mount
Inspect shipping package and contents to ensure no damage has occurred during
shipping.
Make wiring connections from branch circuit conductors to factory provided lead
wires using one of the 3/4” NPT threaded entries. Follow wiring method requirements
of the Canadian Electrical Code or National Electrical Code for the location of the
installation.
NOTE: To aid in assembly and provide protection against ingress, use of a petrolatum
or soap thickened mineral oil based thread lubricant/sealant is necessary.
Un-used conduit opening must be plugged to maintain the integrity of the enclosure.
Mount luminaire assembly to desired location using 4x 1/4-20 OR M6 Screws or Bolts
(Not Provided).
Adjust and aim luminaire to desired position. Torque hardware nuts to 9 N-m (80 in-lbs).
Resume installation instructions provided with luminaire. (STEP 4 in XR Installation
Instructions from the Surface/Ceiling Mount installation provided with Luminaire).
Loosely assemble Yoke mount with carriage bolts on inside and washers and nuts
on the outside.
NOTE: Depending on which mounting hole is used in the curved slot, the luminaire
may be congured for an upward or downward adjustable swing.
Thread installed wiring through openings in yoke mount cheek plate and yoke
mount bracket. Mount yoke assembly to luminaire using 4x M6 Socket Head Cap
Screws and Washers (Provided). Torque fasteners to 5 Nm (45 in-lbs).
Step 3
Step 5
SPX-BKT-XR-YM QTY PART NAME
1YOKE MOUNT A
1YOKE MOUNT B
1CHEEK PLATE
41/4-20 HEX NUT
41/4" FLAT WASHER
41/4-20 x 0.5in CARRIAGE BOLT
4M6 x 25mm HEX HEAD CAP SCREW
SPZ-XR
!Warning
Attention:
Le luminaire XR ne doit pas être orienté vers le haut à un degré
quelconque audelà de la position horizontale pour les installations
en zones dangereuses de classe II, division 2, zone 22 et classe III.
Warning:
The XR head must not face upwards any degree beyond the
horizontal position for Class II, Division 2, Zone 22 and Class III
hazardous location installations.
LIGHT
BEAM
HORIZON

Raytec Americas: [phone] • [email protected]
Raytec Ltd reserve the right to change specifications without prior notification or public announcement.
Version 1
www.raytecled.com
1277-D-0008
Installation Steps
Hook Pendant Installation (Ordered Separately)
Step 1.
Step 2.
Step 3.
Step 4.
Step 5.
Step 6.
This SPX-BKT-XR-HK kit is intended for use with UL Listed XR luminaire as marked on the luminaire nameplate.
Accessory Package Contents
Refer to alternate instructions if using Wall, Hook, Pole or Yoke Mount
Inspect shipping package and contents to ensure no damage has occurred during
shipping. Discard surface/ceiling mounting bracket provided with AR luminaire.
It is recommended to install Secondary Safety Cable by looping appropriate steel
cable or chain through the outer band of the unit and fastening a closed loop.
Secondary safety hardware must be rated for a minimum of 110lbs. Secondary safety
cables made from stainless steel aircraft cable are available upon request.
Slide anti-rotation lock onto suspension hook assembly and install hook
assembly into ¾ NPT threaded entry. Tighten to hand tight plus 1 to 2 turns.
Slide anti-rotation lock into place and tighten set screw to lock unit in place.
NOTE: To aid in assembly and provide protection against ingress, use of a
petrolatum or soap thickened mineral oil based thread lubricant/sealant is
necessary.
Un-used conduit opening must be plugged to maintain the integrity of the
enclosure.
Latch hook onto eye-bolt or other xed mounting loop. Mounting point must be
rated for a minimum of 110lbs.
Install remaining loop of secondary safety chain or steel cable to suitable mounting
location and fasten securely.
Resume installation instructions provided with luminaire. (STEP 4 in XR Installation
Instructions from the Surface/Ceiling Mount installation provided with Luminaire).
SPX-BKT-XR-HK QTY PART NAME
1PENDANT HOOK ASSEMBLY
1 ANTI-ROTATION ASSEMBLY
Step 2
Step 3
SPZ-XR

Raytec Americas: [phone] • [email protected]
Raytec Ltd reserve the right to change specifications without prior notification or public announcement.
Version 1
www.raytecled.com
1277-D-0008
Installation Steps
Conduit Mount Installation
Step 1.
Step 2.
Step 3.
Step 4.
This SPX-BKT-R-CC kit is intended for use with UL Listed XR luminaire
as marked on the luminaire nameplate.
Accessory Package Contents
This kit contains Anti-Rotation-Lock
(1004-01-02-201)
Refer to alternate instructions if using Wall, Hook, Pole or Yoke Mount
Inspect shipping package and contents to ensure no damage has occurred during
shipping.
When using the R-CC anti-rotation lock, slide it rst onto suitably mounted hanging
conduit or luminaire hanger loosley tighten set screw.
Fixed Rigid Metal Conduit or luminaire hanger must be suitably mounted to prevent
rotation and system must be rated for 110 lbs. Install luminaire onto ¾” NPT threaded
nipple. Tighten to hand tight contact plus 1 to 2 turns. When using the R-CC losen
set screw and slide R-CC into place with ats aligned to those on luminaire hub and
tighten set screw to lock unit in place.
NOTE: To aid in assembly and provide protection against ingress, use of a petrolatum
or soap thickened mineral oil based thread lubricant/sealant is necessary.
Un-used conduit opening must be plugged to maintain the integrity of the enclosure.
Install Secondary Safety Cable by looping appropriate steel cable or chain through
the outer band of the unit and fastening a closed loop. Secondary safety hardware
must be rated for a minimum of 110lbs.
Install remaining loop of secondary safety chain or steel cable to suitable mounting
location and fasten securely. Secondary safety hardware must be rated for 110lbs.
Resume installation instructions provided with luminaire. (STEP 4 in XR Installation
Instructions from the Surface/Ceiling Mount installation provided with Luminaire).
Step 2
Step 4
SPX-BKT-R-CC QTY PART NAME
1ANTI-ROTATION BRACKET ASSEMBLY
SPZ-XR

Raytec Americas: [phone] • [email protected]
Raytec Ltd reserve the right to change specifications without prior notification or public announcement.
Version 1
www.raytecled.com
1277-D-0008
Installation Steps
Surge Suppressor Kit
Step 1.
Step 2.
Step 5.
Step 3.
Step 4.
This SPX-BKT-XR-SP-AC kit is intended for use with UL Listed XR luminaire as marked on the luminaire nameplate.
Accessory Package Contents
(Requires SPX-BKT-XR-SP-AC Surge Protector Accessory Kit)
Inspect shipping package and contents to ensure no damage has occurred during
shipping.
Open XR Wiring Cover with 7mm hex socket driver. Allow Lens to hang via retention
strap.
NOTE: Screws are captive fasteners and will remain attached to the Lens for ease of
reinstall and prevent loss of fasteners.
Close XR Wiring Cover. Ensure the retention cable is not pinched between XR Head
and the XR Wiring Cover. Tighten lens bolts using a 7mm socket or box wrench to 1.7
N-m (15 in-lbs).
Install provided double-sided tape along side of surge protector and secure
to XR body near AC input. Secure the surge protector and driver lead wires
together as close to the origin of the driver lead wires as possible using the
provided zip tie.
Wire according to wiring instructions on Page 13-14. Refer to NEC/CEC codes and
follow all applicable local standards.
SPX-BKT-XR-SP-AC QTY PART NAME
1BSP3-277-20KA SURGE PROTECTOR
13M VHB TAPE
14" Zip Tie
SURGE PROTECTOR LOCATION
SPZ-XR

Raytec Americas: [phone] • [email protected]
Raytec Ltd reserve the right to change specifications without prior notification or public announcement.
Version 1
www.raytecled.com
1277-D-0008
PS 1
GROUND
(Factory)
BLACK
WHITE
WHITE GREEN BLACK
VIOLET
GREY
SURGE
SUPPRESSOR
GREEN
WHITE
Wiring Diagram
(SPX-BKT-XR-SP-AC)
Black - Line
White - Line 2
Green - Ground
Purple - DIM (+)
Grey - DIM (-)
1. Connect Black lead from surge protector to splice or terminal connected to Input branch
circuit conductor and black (line) lead from LED driver.
2. Connect White lead from surge protector to splice or terminal connected to Neutral
Input branch circuit conductor and White leads from LED Drivers.
3. Connect Green wire from surge protector to splice or terminal connected to Grounding
branch circuit conductor and green lead from luminaire case.
SPZ-XR

Raytec Americas: [phone] • [email protected]
Raytec Ltd reserve the right to change specifications without prior notification or public announcement.
Version 1
www.raytecled.com
1277-D-0008
Installation Steps
Surge Suppressor Kit
Step 1.
Step 2.
Step 5.
Step 3.
Step 4.
This SPX-BKT-XR-SP-HV kit is intended for use with UL Listed XR luminaire as marked on the luminaire nameplate.
Accessory Package Contents
Inspect shipping package and contents to ensure no damage has occurred during
shipping.
Open XR Wiring Cover with 7mm hex socket driver. Allow Lens to hang via retention
strap.
NOTE: Screws are captive fasteners and will remain attached to the Lens for ease of
reinstall and prevent loss of fasteners.
Close XR Wiring Cover. Ensure the retention cable is not pinched between XR Head
and the XR Wiring Cover. Tighten lens bolts using a 7mm socket or box wrench to 1.7
N-m (15 in-lbs).
Install provided double-sided tape along side of surge protector and secure
to XR body near AC input. Secure the surge protector and driver lead wires
together as close to the origin of the driver lead wires as possible using the
provided zip tie.
Wire according to wiring instructions on Page 12-14. Refer to NEC/CEC codes and
follow all applicable local standards.
SPX-BKT-XR-SP-HV QTY PART NAME
1BSP3-480-20KA SURGE PROTECTOR
13M VHB TAPE
14" Zip Tie
SURGE PROTECTOR LOCATION
SPZ-XR

Raytec Americas: [phone] • [email protected]
Raytec Ltd reserve the right to change specifications without prior notification or public announcement.
Version 1
www.raytecled.com
1277-D-0008
PS 1
GROUND
(Factory)
BLACK
WHITE
WHITE GREEN BLACK
VIOLET
GREY
SURGE
SUPPRESSOR
GREEN
WHITE
Wiring Diagram
(SPX-BKT-XR-SP-HV)
Black - Line
White - Line 2
Green - Ground
Purple - DIM (+)
Grey - DIM (-)
1. Connect Black lead from surge protector to splice or terminal connected to Input branch
circuit conductor and black (line) lead from LED driver.
2. Connect White lead from surge protector to splice or terminal connected to Neutral
Input branch circuit conductor and White leads from LED Drivers.
3. Connect Green wire from surge protector to splice or terminal connected to Grounding
branch circuit conductor and green lead from luminaire case.
SPZ-XR
