PROXY
A CODY WOJCIK & CHRIS JEWETT DESIGN

 
 
      

 

  
   

SAFETY NOTES
m
m
m
m
m
m
IMPORTANT: PRIOR TO ANY ASSEMBLY
Please Note: after removing kit from shipping box, lay each piece flat on a
hard surface, this will allow the airframe to straighten out if lightly bent
from shipping. Do not worry since EPP is very pliable and can be bent back
if out of shape.

 
 
      

 

  
   
B
TWISTED HOBBYS
C D E F G H
D I J J J K
H
J
G
F
H
D
L M N E E O
F
K
P N QR D Q S
G T
I F S
T
D F
U H
J
G
F
H
D
L M N E E O
F
K
P N Q
Thank you for your purchasing a Twisted Hobbys‘ model. Please read through the entire manual before beginning to
build this model. If you have any questions please contact us at the above indicated email address.
WARNING INFORMATION
This R/C Aircraft is not a toy! Read and understand the entire manual before assembly. If misused, it can cause serious bodily harm and
property damage. Fly only in open areas, and AMA (Academy of Model Aeronautics) approved flying sites. Do not over look the warnings
and instructions enclosed or those provided by other manufactures’ products. If you are not an experienced pilot and airplane modeler you
must use the help of an experienced pilot or an authorized flight instructor for the building and flying of this model aircraft.
These instructions are suggestions only on how to assemble this model. There are other ways and methods to do so. Twisted Hobbys has
no control over the final assembly, the materials and accessories used when assembling this kit, or the manner in which the assembled
model, installed radio gear and electronic parts are used and maintained. Thus, no liability is assumed or accepted for any damage
resulting from the use of the assembled model aircraft or from this instruction manual including but not limited to direct, indirect,
incidental, special, and consequential damages. By the act of using this user-assembled product, the user accepts all resulting liability. In
no event shall Twisted Hobbys’ liability exceed the original purchase price of the kit.
SHIPPING DAMAGE
Twisted Hobbys checks each plane before shipping to ensure that each kit is in fine condition. We have no bearing on the condition of any
component parts damaged by use, modification, or assembly of the model. Inspect the components of this kit upon receipt. If you find any
parts damaged or missing, contact Twisted Hobbys immediately. We will not accept the return or replacement of parts on which assembly
work has already begun. Twisted Hobbys reserves the right to change this warranty at anytime without notice.
OUR MISSION
To provide the best products and service to our customers at the lowest prices possible. We take great pride in
our company, our commitment to customer service and in the products we sell. Our online store is designed
to provide you with a safe and secure environment to browse our product catalog.
Thank you for shopping with Twisted Hobbys!

 
 
      

 

  
   
V
kit contents
Fuselage Parts
Wing Parts

 
 
      

 

  
   
W
kit contents
X Y
Z [
\ ] ^
Carbon BundleHardware and Small Carbon

 
 
      

 

  
   
_
TOOL AND ADHESIVES NEEDED
Lighter
Small Drill Bits
Tape Measure and Ruler
Black Sewing Thread
Welders or Foam Tac Glue
Hobby Knife w/new Blade
Needle Nose Pliers
Wire Cutters
Low Temp Hot Glue Gun
Course Sand Paper
Scissors
Small Phillips Screw Driver
Thin and Medium CA
CA Applicator Tips
Activator

 
 
      

 

  
   
`
the build
CONSTRUCTION METHODS:
Building surface should be at least 2ft x 4ft and flat. Weights or some small heavy objects will be handy for holding things in place
during the time glue is setting.
Welders or FoamTac glue is used for FOAM TO FOAM joints. Thin and Medium CA can be used on the PLASTIC TO FOAM and
CARBON TO FOAM joints. When using the Welders or FoamTac glue for a butt joint, apply a thin film to each surface, allow to
sit breifly per mfg instructions, then assemble. Note that this method will create a nearly instant bond, so locate carefully when
bringing the two pieces together. If alignment is necessary or a slip joint, do not allow the glue to tack up, simple apply and join
immediately, you will have several minutes to locate the two parts before the glue sets up. In most cases the parts being glued can be
handled with care in 30 minutes, full cure is approx 24 hours.
¨Locate all the electronics that
will be used on this model
¨Create a model on your
transmitter
¨Following your radio mfg.
instructions, bind your radio to
the power combo components
¨Calibrate the ESC.
¨Confirm all components work
properly.

 
 
      

 

  
   
a
------ GETTING STARTED ------
Control Rod Ends
Push Rod Guides
Landing Gear Components
Radio and FPV Tray
Small Parts Organized for Building
Optional Power Combo
Basic FPV Components supplied
by Customer
Identify all the components and
pieces shown in the pictures. If there
are any items missing contact Twisted
Hobbys right away. If it looks like
some of the small parts are missing,
double check the hardware bags and
kit box. Note that the items shown in
picture G are customer supplied. FPV
Camera and Receiver with Gyro.
A B
D
C
E
F G

 
 
      

 

  
   
b
A B
D
C
E
F G
------ THE WING ------
Gently bend all the control
surfaces back and let them sit like
this for about an hour
Locate the two longest and largest
spars,1x5x950mm, and the
smaller one that is .5x3x200mm
Apply a medium layer of FoamTac
to the mating edges of the wing
halves
Once the glue is tacked up, bring
the two pieces together making
sure the alignment nubs are
locating everything perfectly
Start with the .5x3x200mm spar
Wipe it down with alcohol
Test fit it into the reward slot on
the bottom side of the wing and
secure with thin CA

 
 
      

 

  
   
 
A B
D
C
E
F G
------ THE WING (con’t) ------
Wipe down the two main spars with
alcohol before fitting
Test fit the rear main spar so that
it is flush with the surface
Install the rear main spar,
pushing it flush to the wing
surface for the how length
Repeat the process with the forward
main spar
Secure the wing and spars flush to
the work bench with some weights
Glue all the three of the spars to
the wing with some thin CA, don't
hit with kick yet
Let the whole assembly sit for a
couple minutes to all the CA to
soak in, then hit with kicker
Locate two of the four control
surface horns. All four are the
same, so any two will do

 
 
      

 

  
   
 
A B
D
C
E
F G
------ THE WING (con’t) ------
FoamTac or CA can be used to attach the
control surface horns
Test fit the horn in to the provided
slot
Adjust the length as needed
Retest the fit
Make sure the front of the horn is
flush with the edge of the hinge cut
Apply some glue to the base of the
control horn
Install into the slot, again making
sure that the front edge of the
horn is flush with the hinge cut.
Repeat for the other side, paying
attention to make sure that the
other horn is installed in the same
location relative to the hinge cut

 
 
      

 

  
   
 
------ MAIN FUSELAGE STRUCTURE / Before you Start ------
If you are an experienced builder all the detail may not be necessary, if so skip
ahead a couple pages.
Building the Main Fuselage structure for the proXy will be similar to that of the Crack
Beaver. There are a couple different ways to do this, method and sequence shown here will
ensure that the X cross section of the fuselage will come out nice and square with little
effort. Things that will be critical to the success of this step will be to make sure ahead of
time that all the slits for the spars are deep enough and clear of nubs so that the spars
will lay into the slits nice and flush.
IMPORTANT PART FOR SUCCESS OF THIS STEP TO TEST FIT ALL THE PARTS
TOGETHER FIRST AND UNDERSTAND THE SEQUENCE OF EVENTS BEFORE
GLUING.
------ THE PROCESS / words ------
Start by rounding up the two main fuselage pieces
Remove any scrap from the cut out areas
Locate the fuselage section that has the LONG slits and SHORT tabs as shown
Split the tabs in half at the "V" marks
Locate the landing gear struts. Note that they are keyed unique
Test fit that the nubs match up perfectly and that the slits for the spars align
Attach the two pieces with FoamTac, using the "tackup" method
Hold a little pressure for a minute or two against the joint while the glue sets up
Repeat for the other side
Locate the Ele/Rud that is keyed to fit the large one piece fuselage section
Glue the two together with the "tackup" method, make sure the slits align
Hold a little pressure for a minute or two against the joint while the glue sets up
Take one of the two smaller carbon spars and clean it with alcohol
Fit it into the slit of the Ele/Rud piece that was just attached, make sure it is flush
Constrain it flat and then CA in place
Take the other smaller spar and the loose piece of the Ele/Rud
Clean, test fit, constrain and CA glue the two together
Get two of the larger spars and the one piece fuselage side
Clean the spars with alcohol and test fit, make sure that the spar is all the way to the top of the slit and flush
Also check that the remaining part of the spars at the end of the strut will be approximately the right length to engage the axle hubs
Do not glue the hubs on yet, they will get attached in a later step
Constrain, check for flush and CA
Take top half of fuselage and the remaining two larger carbon spars
Test fit them into the slits, again make sure that they go all the way to the upper end of the slit
Make sure they are flush, the constrain it all flat and apply CA
Test fit the last remaining smaller spar into the slit in the Ele/Rud
Constrain, check for flush and CA

 
 
      

 

  
   
 B
----- THE PROCESS / words (con’t) -----
The next several steps will all be done WITHOUT GLUE it is for test fitting only and to
understand how the assembly will go together, study the pictures and make sure everything
fits together nicely
Take the top half of the fuselage with the spars sticking out and feed those spar ends thru the cut outs in the fuselage
Get it pretty close to the tabs, then focus your attention the the rear Ele/Rud spar and feed it thru its associated hole
Fully engage all the tabs and slots
Make sure that the bevels on the top of the fuselage are LEVEL, if they are not, you have assembled the pieces incorrectly
Grab the lower fuselage half and align the tabs at a slight angle to the slots in the fuselage
Engage the tabs into the slots at the same time as guiding the carbon spars into their respective slits
Push everything together, making sure that it all fits nice, flush and square
If any parts are not flush, fully engaged or not square, make the necessary adjustment to get everything fitting properly
This completes the TEST FIT WITH NO GLUE, keep in mind how it all went together and
disassembly all the pieces
Start the reassembly with the main fuselage piece and the top half of the other side of the fuselage
Apply FoamTac to the larger piece in all the areas where the two items will contact each other including the tab and slot
areas
Keep glue AWAY from the area where the spars cross thru
Fit the upper fuselage half and the strut spars thru the holes in the large fuselage piece like was done in the test fit up
Make sure all the foam tabs and slots are fulling engaged and that the strut spars and Ele/Rud spar are in their slits and
flush
Make sure the two upper fuselage member are nice and square with each other
Apply a little pressure to the assembly for a couple minutes to allow the FoamTac to make a good bond
Next the lower fuselage half will be attached, apply FoamTac to all the mating FOAM surfaces
DO NOT PUT GLUE THE SPARS AT THIS TIME
Move the two pieces into position as was done with the fit up
Make sure the foam tabs and slots are fully engaged
Double check that the spars are (dry fit) flush with the surface of their slits
Make sure all the fuselage pieces are 90 degrees to each other along the entire length
Hold a little pressure on the two pieces for a minute or two so that the FoamTac can make a good bond
NOW the spars will be secured with CA to their slits
Make sure that all the fuselage components are still square and that the spars are flush in the slits
Apply thin CA to all the spars and hit with kicker
This completes the Main Fuselage Structure

 
 
      

 

  
   
 V
A B
D
C
E
F G
------ MAIN FUSELAGE ------
Pictures to follow along with for the
previous two pages
Locate the two fuselage halves
bottom one shown gets split ...
... at the center of the tabs
Split all the way, nose to tail
Locate the gear struts and notice how
they are keyed to their mate fuselage
piece
Use the “tack” up method to
attach the gear strut to the
fuselage
Assemble and hold pressure for a
minute or so
Repeat for the other side

 
 
      

 

  
   
 W
A B
D
C
E
F G
------ MAIN FUSELAGE (con’t) ------
Find the rudder piece shown that
is keyed to fit the fuselage on that
side
Using the “tack” method attache the
two pieces
Locate the shorter spars from the set
pictured above (.5x3x250mm)
Wipe it down with alcohol to remove
any mfg residue
Test Fit and clean up the slot if
needed
Install / Insert
Constrain flat and secure the spar
and control surface together with
some thin CA and kicker

 
 
      

 

  
   
 _
A B
D
C
E
F G
------ MAIN FUSELAGE (con’t) ------
Locate the other short spar, prep it
and ...
... test fit it, as was done with the
other one
Constrain and combined with CA and
kicker
Locate two of the four longer spars
(.5x3x332mm long)
Prep them
Test fit them
Make sure the go all the way up to
the top of the slot near the wing
saddle part of the fuselage

 
 
      

 

  
   
 `
A B
D
C
E
F G
------ MAIN FUSELAGE (con’t) ------
Locate the two little white 3D printed
axle hubs
Compare the slots in the hub to the
exposed spars
The two should match up pretty
close, if not double check to make
sure the spar is up against the other
end of the slot
Constrain Flat and secure with thin
CA and kicker
Grab the remaining two spars
(.5x3x332mm) and the top half of the
other fuselage side
Test fit them, all the way up to the
wing saddle like was done with the
other side
Constrain flat and secure with
thin CA and kicker

 
 
      

 

  
   
 a
A B
D
C
E
F G
------ MAIN FUSELAGE (con’t) ------
Use the “tack” method and attach the
tail piece shown, only apply the glue
on the foam-foam part of the joint
Hold pressure for a minute or so
Secure the carbon-foam part of the
joint with thin CA and kicker
Finished parts
THIS IS WHERE TEST FITTING
STARTS - DO NOT USE GLUE UNTIL
CALLED FOR
Take the fuselage piece with the spars
sticking ut and thread the ends thru
the other fuselage part
All the way thru...
.... and line up the tabs

 
 
      

 

  
   
 b
A B
D
C
E
F G
------ MAIN FUSELAGE (con’t) ------
Also feed the extended tail spars thru
their respective cut outs
Fully engage the tail tabs
Fully engage the forward tabs
Check that the fuselage saddle area
is approximately level/horizontal
Flip the fuselage assembly over so
that the extended spars are facing
upward
Grab the mating lower fuselage
section and start to line up the tabs
into their cutouts and the spars into
their slots
You will have to fit them up to
each other initially at a little bit of
an angle, once the tabs and spars
are nearly in position, you can
square things up

 
 
      

 

  
   
 
A B
D
C
E
F G
------ MAIN FUSELAGE (con’t) ------
Fully seat the spars land gear struts
into their slots, make sure they are
flush
Check to make sure the two fuselage
members are square to each other in
and around the landing gear strut
area
Fully seat the tail spars into their
slots, make sure they are flush
Check to make sure the two fuselage
members are square to each other in
and around the tail section
TEST FIT UP is essentially done, have
a look at the whole thing and make
sure it all looks nice and square
Take is all apart, remember how it
had all been test fit assembled
TEST FIT IS DONE - TIME FOR GLUE
Apply glue as shown to all mating
surfaces
