RCA L15D20 User manual

rca.com/television
Find Inside:
•Connections ...........page 9
• Remote...................page 19
• Features .................page 20
•Menus ....................page 24
•FAQs.......................page 29
•Troubleshooting .....page 30
LCD User’s Guide
Changing Entertainment. Again.
Changing Entertainment. Again.
16733890.indb 116733890.indb 1 12/6/06 11:27:12 AM12/6/06 11:27:12 AM

CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
Caution: To reduce the risk of electric shock, do not remove cover (or
back). No user serviceable parts inside. Refer servicing to qualified service
personnel.
This symbol indicates important
instructions accompanying the product.
Product Registration
Please fill out the product registration card (packed separately) and return it immediately. For US customers: Your RCA
Consumer Electronics product may also be registered at www.rca.com/television. Registering this product allows us to
contact you if needed.
Product Information
Keep your sales receipt to obtain warranty parts and service and for proof of purchase. Attach it here and record the
serial and model numbers in case you need them. These numbers are located on the product.
Model No. _____________________ Serial No.____________________ Purchase Date __________________
Dealer/Address/Phone _________________________________________________________________________
Important Information
WARNING
To reduce the risk of fire or electric shock, do not
expose this product to rain or moisture. The apparatus
shall not be exposed to dripping or splashing. No ob-
jects filled with liquids, such as vases, shall be placed
on the apparatus.
Refer to the identification/rating label located on the back panel of your product for its proper operating voltage.
FCC Regulations state that unauthorized changes or modifications to this equipment may void the user’s authority to
operate it.
Cable TV Installer: This reminder is provided to call your attention to Article 820-40 of the National Electrical Code
(Section 54 of the Canadian Electrical Code, Part 1) which provides guidelines for proper grounding and, in particular,
specifies that the cable ground shall be connected to the grounding system of the building as close to the point of
cable entry as practical.
Important: This television is a table model and is designed to sit on a firm, flat, surface. Don't place the TV on soft
carpeting or similar surface because the ventilation slots on the bottom of the unit will be blocked resulting in reduced
lifetime from overheating. To assure adequate ventilation for this product, maintain a spacing of 4 inches from the top
and sides of the TV receiver and 2 inches from the rear of the TV receiver and other surfaces.
Also, make sure the stand or base you use is of adequate size and strength to prevent the TV from being accidentally
tipped over, pushed off, or pulled off. This could cause personal injury and/or damage the TV. Refer to the Important
Safety Instructions on the next page.
WARNING
The TV is unstable until it is properly attached to the
base or mounted to the wall. Please follow the base
or wall mounting instructions provided in the User’s
Guide to ensure your safety.
This symbol indicates that this product contains mercury. Special disposal of this product for environmental
reasons may be required under the laws applicable to your jurisdiction. For disposal or recycling
information, please contact your local authorities or the Electronic Industries Alliance: www.eiae.org.
This symbol indicates "dangerous
voltage" inside the product that
presents a risk of electric shock or
personal injury.
"Changing Entertainment. Again." is a trademark of THOMSON used under license to TTE CORPORATION.
16733890.indb 216733890.indb 2 12/6/06 11:27:23 AM12/6/06 11:27:23 AM

Important Information
Important Information i
Important Safety Instructions
Important Safety Instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with
one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or
the third prong is provided for your safety. If the provided plug does not fit into your outlet, consult an electrician
for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the
point where they exit from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the
apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid
injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused for long periods of time.
14. Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain
or moisture, does not operate normally, or has been dropped.
15. If an outside antenna or cable system is connected to the product, be sure the antenna or cable system is grounded
so as to provide some protection against voltage surges and built-up static charges. Section 810 of the National
Electrical Code, ANSI/NFPA No. 70-1984 (Section 54 of Canadian Electrical Code, Part 1) provides information
with respect to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an
antenna-discharge unit, size of grounding conductors, location of antenna-discharge unit, connection to grounding
electrodes, and requirements for the grounding electrode. See following example.
ANTENNA
LEAD IN
WIRE
GROUND CLAMP
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)
ELECTRIC SERVICE
EQUIPMENT
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
16733890.indb 316733890.indb 3 12/6/06 11:27:23 AM12/6/06 11:27:23 AM

This page intentionally left blank
16733890.indb 416733890.indb 4 12/6/06 11:27:24 AM12/6/06 11:27:24 AM

5
Table of Contents
Important Safety Instructions....................................... i
Chapter 1: Connections and Setup
Things to Consider Before You Connect ..................... 6
Protect Against Power Surges................................ 6
Protect Devices from Overheating ........................ 6
Position Cables Properly to Avoid Audio
Interference .......................................................... 6
Use Indirect Light.................................................... 6
Check Supplied Parts .............................................. 6
Attaching Your TV’s Base.............................................. 7
Mounting Your TV to the Wall..................................... 7
Get the Picture .............................................................. 8
Getting Channels .................................................... 8
Choose Your Connection .............................................. 9
Video (Basic) Connection ..................................... 10
Component Video (Advanced) Connection ........ 10
HDMI Connection ................................................. 12
VGA Connection ................................................... 13
Plug in the TV.............................................................. 14
Put Batteries in the Remote ....................................... 14
Turn on the TV............................................................. 14
How to Use the Remote Control to Complete the
Initial Setup ............................................................... 14
Complete the Initial Setup ......................................... 15
Set the Menu Language ...................................... 15
Set the Signal Source............................................ 15
Complete the Channel Search ............................. 15
What To Expect ........................................................... 16
Watching TV ......................................................... 16
Changing Channels............................................... 16
Explanation of Jacks (in alphabetical order)............. 17
Buttons On Your TV .................................................... 18
The Buttons on the Remote Control.......................... 19
Chapter 2: Using the TV's Features
Channel Banner........................................................... 20
Parental Controls and V-Chip ..................................... 20
How V-Chip Works for USA and Canada............. 20
USA V-Chip TV Ratings ......................................... 22
V-Chip Movie Rating Limit ................................... 23
Blocking Canadian V-Chip Ratings ...................... 23
Blocking Unrated/Exempt Programs ................... 23
Future Rating Region ........................................... 23
Chapter 3: Using the TV's Menu System
Using the Menu System ............................................. 24
Setup Menu................................................................. 24
Picture Menu ............................................................... 25
Audio Menu................................................................. 26
Options Menu ............................................................. 27
Chapter 4: Other Information
Frequently Asked Questions (FAQs) .......................... 29
Troubleshooting.......................................................... 30
V-Chip Rating Explanations........................................ 32
US V-Chip Rating System ...................................... 32
Canadian English V-Chip Rating System.............. 32
Canadian French V-Chip Rating System .............. 33
Limited Warranty ........................................................ 34
Care and Cleaning....................................................... 35
16733890.indb 516733890.indb 5 12/6/06 11:27:24 AM12/6/06 11:27:24 AM

Graphics contained within this publication are for representation only.
6 Chapter 1
Chapter 1: Connections and Setup
Things to Consider Before You Connect
Protect Against Power Surges
• Connect all devices before you plug any of their power cords into the wall outlet or power
strip. NEVER plug your TV into an outlet that is controlled by a wall switch.
• Turn off the TV and/or device(s) before you connect or disconnect any cables.
• Make sure all antennas and cables are properly grounded. Refer to the Important Safety
Instructions at the beginning of the User's Guide.
Protect Devices from Overheating
• Don’t block ventilation holes on any of the devices. Arrange the devices so that air can
circulate freely.
• Don’t stack devices.
• If you place devices in a stand, make sure you allow adequate ventilation.
• If you connect an audio receiver or amplifier, place it on the top shelf so the heated air
from it won’t flow around other devices.
Position Cables Properly to Avoid Audio Interference
• Insert each cable firmly into the designated jack.
• If you place devices above the TV, route all cables down the side of the back of the TV
instead of straight down the middle.
• If your antenna uses 300-ohm twin lead cables, do not coil the cables. Also, keep the twin
lead cables away from audio/video cables.
Use Indirect Light
Don’t place the TV where sunlight or room lighting will be directed toward the screen. Use soft
or indirect lighting.
Check Supplied Parts
Check that the following parts were packed with your product.
Remote control
Part # R130D1
2 AA batteries
Power cord
SOUND
ON•OFF
PRESETS
CC
INPUT SUB CH
WATCH TV FORMAT
VOL VOL
MUTE
GO BACK FAV
CLEAR
CH -
CH +
VOL- VOL +
MENU OK INFO
Note: If you need to replace your remote, call 1-800-338-0376. A shipping and handling
fee, and the appropriate sales tax, will be charged upon ordering. Have your Visa,
MasterCard, or Discover Card ready.
Power adapter (only
available for model L15D20)
L15D20 base
L19WD20 base
3 screws to attach base
(only available for
model L19WD20)
16733890.indb 616733890.indb 6 12/6/06 11:27:25 AM12/6/06 11:27:25 AM

Connections and Setup
Chapter 1 7
Mounting Your TV to the Wall
Caution: The wall mount must bear a minimum of five times
the TV’s net weight without causing damage.
To mount your TV to the wall you need to purchase a VESA wall
mount. Purchase a VESA 100 x 100, M4 x 10mm (100 x 100 means
the mounting measurements are 100mm horizontally and 100mm
vertically; M4 x 10mm is the type of screw).
1. If the base is attached, you need to remove it before attaching the
wall mount.
A. Place the TV facedown on a surface that is soft, yet strong
enough to hold the TV.
B. For model L15D20, push in on the tab at the back of the base
and remove the base from the TV.
For model L19WD20, remove the three screws from the bottom
of the base. Then, squeeze the two tabs on the bottom of the
base and remove the base from the TV.
C. Use a screwdriver to remove the screws from the holes as the
picture indicates to the left. Model L15D20 has three screws;
model L19WD20 has four screws.
Remove the screws that attach to the TV's
base attachment.
Wall mount holes
Attaching Your TV’s Base
Your TV comes shipped without the base attached so that you can
choose to mount your TV either to its base or to a wall (wall mount
sold separately). If you want to mount your TV to the wall, don’t
attach the base and instead follow the Mounting Your TV to the Wall
instructions below.
1. Locate the base. For model L19WD20, also locate the three screws.
2. For model L15D20, pick up the TV and align it so that the lock tab
on the base matches with the tab opening on the back of the TV.
For model L19WD20, the screw holes underneath the TV match
with the screw holes inside the base.
Push down on the top of the TV until it clicks into the base.
3. For model L19WD20, attach the three screws to the bottom of the
base as the picture to the left shows.
Model L19WD20 bottom of the base
Model L19WD20
Model L15D20
2. Make sure all cables are already connected to the TV.
3. Attach the wall mount to the TV using the four holes on the TV's
back panel, as indicated in the picture to the left.
4. Follow the directions included with the wall mount to mount the
TV to the wall.
Model L15D20 tab Model L19WD20 tabs
16733890.indb 716733890.indb 7 12/6/06 11:27:28 AM12/6/06 11:27:28 AM

Connections and Setup
8 Chapter 1
Coaxial cable
Outdoor or Indoor
antenna
or
Get the Picture
The first part of connecting your TV is to get the picture, also known
as the signal. The back panel of your TV allows you to receive analog
and/or digital channels by using the ANTENNA/CABLE INPUT.
ANTENNA/
CABLE INPUT
(DIGITAL AND ANALOG)
Getting Channels
What You Need
• Antenna (“rabbit ears”) or outdoor antenna with coaxial cable
OR
• Coaxial cable with cable service
A. Do you have an indoor or outdoor antenna? If you don't, go to
step B. If you do, plug the antenna or coaxial cable from the wall
outlet into the ANTENNA/CABLE INPUT to receive free off-air
local digital and analog channels.
B. Do you have cable? If you don't, go to step C. If you do, plug
the coaxial cable from the wall outlet into the ANTENNA/CABLE
INPUT to receive your cable channels.
C. Do you have a set-top box? If you do, you need to call your cable
company or satellite service provider. They may use special cables
to allow you to view digital channels.
What You Need To Know
• Visit www.antennaweb.org to get help deciding what type of
antenna to use to receive the local digital channels available to
you. By entering where you live, this mapping program tells you
what local analog and digital stations are available using a certain
antenna.
• As you change channels, look at the top right corner of the screen
to see what type of channel you’re viewing. Digital channels
display a D as part of the channel, such as D Ch 29.1, while
analog channels display an Aas part of the channel, such as
A Ch 9. Go to page 16 for more channel information.
16733890.indb 816733890.indb 8 12/6/06 11:27:30 AM12/6/06 11:27:30 AM

Connections and Setup
Chapter 1 9
Jacks Used Cables Needed Go to...
Audio/Video page 10-11
page 12
HDMI™
Video
Audio L and R
HDMI
HDMI, the HDMI logo, and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI
Licensing LLC.
Choose Your Connection
Note for US customers: If you prefer, we can provide you with the name of an Authorized Service Representative
who will visit your home for a fee to install your electronic entertainment system and to instruct you in its
operation. For details about this service, call 1-888-206-3359.
For additional assistance while using your RCA product, please visit www.rca.com/customersupport.
R
AUDIO
VIDEO L
COMPOSITE VIDEO INPUT
AUDIO
INPUT VGA INPUT
PC INPUT
VGA
Audio
page 13
Audio
VGA
There are several ways to connect your TV. Please use the following chart to determine which connection is best
for you. Proceed to the appropriate page and connect your TV.
R
AUDIO
Y
Pb
L
COMPONENT VIDEO INPUT
(1080i/720p/480p/480i)
Pr
Y Pb Pr
Audio L and R
Audio
Component Video page 10-11
16733890.indb 916733890.indb 9 12/6/06 11:27:30 AM12/6/06 11:27:30 AM

Connections and Setup
10 Chapter 1
COMPONENT VIDEO
YPb Pr
VIDEO
INPUT LR
AUDIO
VIDEO
OUTPUT S-VIDEO S-VIDEO
LR
AUDIO
LR
AUDIO
R
AUDIO
VIDEO L
COMPOSITE VIDEO INPUT
Video (Basic) Connection
This is an example of a connection using the Video jack. Go to the top of page 11 for specific
instructions.
1Don't forget: If necessary,
connect antenna or cable to
get a picture. Go to page 8
for instructions.
COMPONENT VIDEO
YPbPr
VIDEO
INPUT LR
AUDIO
VIDEO
OUTPUT
S-VIDEO
S-VIDEO
LR
AUDIO
LR
AUDIO
R
AUDIO
Y
Pb
L
COMPONENT VIDEO INPUT
(1080i/720p/480p/480i)
Pr
Component Video (Advanced) Connection
This is an example of a connection using the Component Video jacks. Go to the middle of
page 11 for specific instructions.
2
3
2
3
1Don't forget: If necessary,
connect antenna or cable to
get a picture. Go to page 8
for instructions.
16733890.indb 1016733890.indb 10 12/6/06 11:27:32 AM12/6/06 11:27:32 AM

Connections and Setup
Chapter 1 11
• If you're done
connecting devices to
your TV, go to page 15
to complete the Initial
Setup.
• To continue
connecting devices, go
to the next page.
Connecting the Device with Component Video (Advanced)
This connection allows you to connect a device that has Y Pb Pr jacks, for example, a DVD
player.
Using the example of a DVD player:
1. If necessary, connect your cable and/or off-air antenna as described on page 8.
2. Connect your Y Pb Pr component video cables.
Connect three video cables or special Y Pb Pr cables to the COMPONENT VIDEO
INPUT Y Pb Pr jacks on the back of the TV and to the Y Pb Pr outputs on the
DVD player.
3. Connect your red and white audio cables.
Connect the audio (red and white) cables to the COMPONENT VIDEO INPUT
AUDIO R and L jacks on the back of the TV and to the Audio Output jacks on the
DVD player.
SOUND
ON•OFF
PRESETS
CC
INPUT SUB CH
WATCH TV FORMAT
VOL VOL
MUTE
GO BACK FAV
CLEAR
CH -
CH +
VOL- VOL +
MENU OK INFO
INPUT
button
ON•OFF button
Use these buttons
to view the picture
of the device you’ve
connected to the TV.
Connecting the Device with Video (Basic)
This connection allows you to connect a device that has a Video Out jack, for example, a
DVD player.
Note: If the device you're connecting also has Component Video jacks and you have
component video cables, we recommend you use the Component Video (Advanced)
Connection instead. See the next set of instructions below.
Using the example of a DVD player:
1. If necessary, connect your cable and/or off-air antenna as described on page 8.
2. Connect your yellow video cable.
Connect a video cable to the VIDEO Input jack on the back of the TV and to the Video
Output jack on the DVD player.
3. Connect your red and white audio cables.
Connect the audio (red and white) cables to the AUDIO R and L jacks on the back of
the TV and to the Audio Output jacks on the DVD player.
Red
Yellow
Composite cables are color
coded- Yellow= video;
Red= right audio; white=
left audio
White
Component Video cables
(Y Pb Pr) are color coded-
Green, Blue and Red
White
Red
Audio cables are color
coded- Red= right audio;
white= left audio
Green
Blue
Red
Viewing the Picture from the Connected Device
1. Plug in the TV (see page 14 for details) and the device, if they aren't already
plugged in.
2. Turn on the TV and the device you want to view, for example a DVD player.
3. Press the INPUT button on the remote control and press the up or down arrow button
to highlight Composite (if connected to the VIDEO jack) or Component (if connected
to the COMPONENT VIDEO jacks). Press OK to tune to the input. To go back to
viewing TV channels, press the WATCH TV button.
Note: If the picture from the DVD player appears black and white and your device
is connected to the VIDEO Input, you might be tuned to the wrong input. Make sure
you press INPUT and select Composite.
16733890.indb 1116733890.indb 11 12/6/06 11:27:33 AM12/6/06 11:27:33 AM

Connections and Setup
12 Chapter 1
SOUND
ON•OFF
PRESETS
CC
INPUT SUB CH
WATCH TV FORMAT
VOL VOL
MUTE
GO BACK FAV
CLEAR
CH -
CH +
VOL- VOL +
MENU OK INFO
HDMI cable
• If you're done
connecting devices to
your TV, go to page 15
to complete the Initial
Setup.
• If you experience HDMI
problems, go to the
HDMI Troubleshooting
section on page 31.
Connecting the Device
High-Definition Multimedia Interface (HDMI) technology is an uncompressed digital connection
that carries both video and audio data by way of an integrated mini-plug cable.
INPUT
button
ON•OFF button
Device with HDMI
Pb
Y
Video Out
Pr
HDMI Out
L
R
Audio Out
HDMI
INPUT
HDMI Connection
This is an example of a connection using the HDMI jack.
*Don't forget: If necessary,
connect antenna or cable to
get a picture. Go to page 8
for instructions.
Use these buttons
to view the picture
of the device you’ve
connected to the TV.
*
Using the example of a set-top box:
• If your set-top box has an HDMI output jack, connect an HDMI cable.
Connect an HDMI cable to the HDMI INPUT on the back of the TV and to the HDMI
Out jack on the back of the device.
Viewing the Picture from the Connected Device
The device in this connection is connected to the HDMI INPUT jack. To view this device:
1. Plug in the TV (see page 14 for details) and the device, if they aren't already
plugged in.
2. Turn on the TV and the device you want to view, for example a set-top box.
3. Press the INPUT button on the remote control and press the up or down arrow
button to highlight HDMI from the input list. Press OK to tune to the input. To go
back to viewing TV channels, press the WATCH TV button.
16733890.indb 1216733890.indb 12 12/6/06 11:27:34 AM12/6/06 11:27:34 AM

Connections and Setup
Chapter 1 13
VGA Connection
This is an example of a connection using the VGA jacks.
AUDIO
INPUT VGA INPUT
PC INPUT
2
Don't forget: If necessary,
connect antenna or cable
to get a picture. Go to
page 8 for instructions.
1
Connecting the Device
This connection allows you to connect to a personal computer.
1. If necessary, connect your cable and/or off-air antenna as described on page 8.
2. Connect your monitor cable.
Connect one end of a 15-pin monitor cable to the VGA INPUT jack on the TV and the
other end to the PC's video output jack. Note, if your PC's video output isn't 15-pin, you'll
need an adapter that can connect to a 15-pin monitor cable.
3. Connect your audio cable.
Connect a 3.5 mm stereo mini pin cable (sometimes referred to as 1/8" stereo mini pin) to
the VGA AUDIO INPUT jack on the back of the TV and the other end to the Audio Output
jack on the PC.
Notes: The maximum panel resolution is 1366 x 768 for your TV. Be sure to set your
PC to the correct monitor output setting.
The TV allows you to listen to the sound from another input while the PC is connected.
Go to page 26 for more information.
Viewing the PC
1. Plug in the TV (see page 14 for details) and the PC, if they aren't already plugged in.
2. Turn on the TV and the PC.
3. Press the INPUT button on the remote control and press the up or down arrow button to
highlight VGA from the input list. Press OK to tune to the input. To go back to viewing TV
channels, press the WATCH TV button.
3
16733890.indb 1316733890.indb 13 12/6/06 11:27:34 AM12/6/06 11:27:34 AM

Connections and Setup
14 Chapter 1
SOUND
ON•OFF
PRESETS
CC
INPUT SUB CH
WATCH TV FORMAT
VOL VOL
MUTE
GO BACK FAV
CLEAR
CH -
CH +
VOL- VOL +
MENU OK INFO
Plug in the TV
Plug the end of the power cord into the back of the TV. For model L15W20, plug the power
cord into the power adapter, then plug the power adapter into the TV. Plug the other end of
the power cord into a grounded wall outlet. Insert the plug completely into the outlet. Do not
plug into an outlet controlled by a light switch.
Put Batteries in the Remote
• Remove the battery compartment cover from the back of the remote by pushing the tab
and lifting off the cover.
• Insert two fresh batteries. Make sure the polarities (+ and -) are aligned correctly.
• Replace the cover.
Turn on the TV
Turn on your TV by pressing the Power button on the top panel of the TV or ON•OFF on the
remote control.
Arrows
OK
button
How to Use the Remote Control to
Complete the Initial Setup
The technical term is “Navigation” – how you move through the on-
screen menus. The theory is the same throughout the menu screens:
highlight your choice and select it.
With the Setup menu displayed, press the right arrow button to access
the Setup menu choices. Press the up or down arrow button to move
up or down within the menu. Items with an arrow (4) means there
are more items to choose from or a sub-menu available. Press the right
arrow or OK to display these.
Note: Highlighted means that the menu item stands out from other
menu items on the list (appears darker, brighter, or a different color).
16733890.indb 1416733890.indb 14 12/6/06 11:27:35 AM12/6/06 11:27:35 AM

Connections and Setup
Chapter 1 15
Auto Channel Search Menu
Analog TV Channel 30: Found
Channels Found: 25
Progress: 30%
Complete the Initial Setup
Customizing items in the Setup menu allows your TV to perform correctly. Make sure you've
connected the TV to cable or an off-air signal before you continue.
Setup
u
u
u
u
u
u
u
To Move
u
Signal Source Cable TV
DTV Signal Strength
Auto Channel Search Start
Manual Channel Setup
Channel Labels
Menu Language English
Screen Format Stretch
Favorite Channel Off
OK To Select MENU To Exit
Setup
u
u
u
u
u
u
u
To Move
u
Signal Source Cable TV
DTV Signal Strength
Auto Channel Search Start
Manual Channel Setup
Channel Labels
Menu Language English
Screen Format Stretch
Favorite Channel Off
OK To Select MENU To Exit
Set the Menu Language
If English is your preferred language, skip this step and go to Set the
Signal Source.
To choose another language, press the MENU button then press the
right arrow button to enter the Setup menu. Press the down arrow
to highlight Menu Language, then press the right arrow to choose a
language. Continue to Set the Signal Source.
Set the Signal Source
From the Setup menu, press the up or down arrow button to highlight
Signal Source. If you connected Cable to your ANTENNA/CABLE
INPUT, the option is chosen for you and you can press the down
arrow button to highlight Auto Channel Search. To choose Air
(Antenna), press the right arrow button and then press the down
arrow button to highlight Auto Channel Search.
If you have ANALOG and DIGITAL channels,
the TV runs 2 separate channel searches.
Complete the Channel Search
Even though the initial channel search can take time, you must
complete it in order for your TV to display channels and programming.
With Auto Channel Search highlighted, press OK to begin the channel
search. The menu shows the TV is running a channel search. The TV
tunes to a program once the search is complete.
Some channels might have been found during the channel search that
are unavailable to view and you might want to get rid of these so they
don't appear as you change channels. To do this, highlight Manual
Channel Setup from the Setup menu. Note that removing channels
from your channel list may be time consuming, so you might want to
do it later. Go to page 24 for details on editing your channel list.
16733890.indb 1516733890.indb 15 12/6/06 11:27:35 AM12/6/06 11:27:35 AM

Connections and Setup
16 Chapter 1
What To Expect
Watching TV
• Your TV allows you to change the format of the picture you're viewing by pressing the
FORMAT button on your remote or accessing the Screen Format option in the Setup menu.
The format changes as you press the FORMAT button and the format type is displayed
at the top of the screen. Depending on the type of signal you're viewing and your TV's
model, a different format might not be available.
• Analog video is sent in a 4/3 format. Most digital video is sent in a 16/9 format, but
sometimes is sent in 4/3. It depends on how the station or device connected to your TV
is formatting the video. If there are bars on-screen, press the FORMAT button to try a
different format that may eliminate the bars.
Changing Channels
• If you have both analog and digital channels, these are put into the same channel list.
As you change channels, look at the top right corner of the screen to see what type of
channel you’re viewing. Digital channels display a D as part of the channel, such as
D Ch 29.1, while analog channels display an Aas part of the channel, such as A Ch 9.
• Digital channels can have both primary channels (like the analog channel number) and
subchannels. If 6 is the primary channel and 1 is the subchannel, for example, the channel
looks like 6.1 on screen. To tune to a digital channel with a subchannel, such as 6.1, enter
the primary channel number (6), then press the SUB CH button. Enter the subchannel
number (1) and press OK.
• Depending upon the type of signal you have connected to your HDTV, you might notice
that the channels change slower than you’re used to. This is perfectly normal. Digital
channels sometimes take longer to tune.
16733890.indb 1616733890.indb 16 12/6/06 11:27:36 AM12/6/06 11:27:36 AM

Connections and Setup
Chapter 1 17
Explanation of Jacks (in alphabetical order)
This section describes the jacks on the back panel of your TV. There are several ways to
connect devices.
R
AUDIO
VIDEO
L
COMPOSITE VIDEO INPUT
HDMI
INPUT HEADPHONE
S-VIDEO
INPUT
R
AUDIO
Y
Pb
L
Pr
DIGITAL AUDIO
OUTPUT (COAXIAL)
AUDIO
INPUT VGA INPUT
PC INPUT
ANTENNA/
CABLE INPUT
(DIGITAL AND ANALOG)
COMPONENT VIDEO INPUT
(1080i/720p/480p/480i)
ANTENNA/CABLE INPUT Lets you connect a coaxial cable to receive the signal from the
antenna, cable, or cable box.
COMPONENT VIDEO INPUT Lets you connect a device that has component video jacks,
such as a DVD player.
• COMPONENT L AUDIO Provides left audio connection when using COMPONENT VIDEO
INPUT. The left audio connector is usually white.
• COMPONENT R AUDIO Provides right audio connection when using the COMPONENT
VIDEO INPUT. The right audio connector is usually red.
• COMPONENT VIDEO Y Pb Pr Provides optimum picture quality because the video is
separated into three signals. Use three video-grade or component video cables for the
connection. When using Y Pb Pr, make sure you connect left and right audio cables to the
COMPONENT L and R AUDIO jacks.
COMPOSITE VIDEO INPUT Lets you connect a device that has composite video jacks, such
as a video game console, VCR, or DVD player.
• AUDIO L and R Receives audio from another device such as a camcorder, video game
console, VCR, or DVD player. Use when connecting to the VIDEO or S-VIDEO Input.
• S-VIDEO Allows you to connect an S-Video cable from another device. Make sure you
also connect audio cables from the device to the TV.
• VIDEO Receives video from another device such as a camcorder, video game console,
VCR, or DVD player.
Note: Do not connect an S-Video and a regular video cable at the same time.
DIGITAL AUDIO OUTPUT (COAXIAL) Use this jack to connect an audio receiver to the TV
for enhanced sound quality. Make sure you set the Audio output correctly in the Advanced
Audio Menu. Go to page 26 for more information.
HDMI INPUT (High-Definition Multimedia Interface) Provides an uncompressed digital
connection that carries both video and audio data by way of an integrated mini-plug cable.
Lets you connect a device, such as a digital cable box, with an HDMI output.
HEADPHONE Allows you to connect headphones to listen to the sound coming from the TV.
The TV speakers turn off when you plug in headphones.
VGA AUDIO INPUT (Stereo mini jack) Use to obtain sound when a device is connected to
the VGA jack. Use a 3.5 mm stereo mini pin cable (sometimes referred to as 1/8” stereo mini
pin) to connect a device to your TV. Go to page 13 for more information.
VGA INPUT Connect your computer, or other device with a VGA output, to this jack using a
15 pin D-sub cable.
16733890.indb 1716733890.indb 17 12/6/06 11:27:36 AM12/6/06 11:27:36 AM

Connections and Setup
18 Chapter 1
Buttons On Your TV
If you cannot locate your remote, you can use the buttons on the top
of your TV to operate many of the TV’s features.
MENU Displays the TV Main menu. If the main menu is displayed,
exits the menu; if a sub menu is displayed, takes you back to the
previous menu.
CH Scans down through the channel list. In the TV menu system,
acts like the down arrow button on the remote control and adjusts
menu controls.
CH Scans up through the channel list. In the TV menu system,
acts like the up arrow button on the remote control and adjusts menu
controls.
POWER Turns the TV on and off.
VOL < Decreases the volume. In the TV menu system, acts like the
left arrow button on the remote control and adjusts menu controls.
VOL > Increases the volume. In the TV menu system, acts like the
right arrow button on the remote control and adjusts menu controls.
INPUT/OK Displays the available video input channels- Watch TV,
Composite, S-Video, Component, VGA, and HDMI. When in the menu
system, displays sub-menus and selects the highlighted item.
>
>
MENU CH INPUT/OKVOL
▲
▲
▲
▲
16733890.indb 1816733890.indb 18 12/6/06 11:27:37 AM12/6/06 11:27:37 AM

Connections and Setup
Chapter 1 19
The Buttons on the Remote Control
Arrows Used to move and highlight different items in the TV menu
and to adjust the menu controls.
(0-9) Number Buttons Enter channel numbers. To enter a digital
channel with a sub-channel, enter the main channel, then press the
SUB CH button to enter the sub-channel and press OK.
CC Toggles through the CC settings: CC Off, CC On, and CC On
When Mute.
CH + or CH - Scan up or down through the current channel list. Press
once to change the channel up or down; press and hold to continue
changing channels.
CLEAR Removes any menu or display from the screen and returns
you to normal viewing.
FAV (Favorite) Press to browse the channels set in your Favorite
Channel list. Go to page 25 for more information.
FORMAT Press to change the size of the picture on-screen.
GO BACK Returns you to the previous channel.
INFO Brings up the channel banner; press again to clear the screen.
INPUT Displays the available video input channels- Watch TV,
Composite, S-Video, Component, VGA, and HDMI.
MENU Displays the TV Main menu. If the main menu is displayed,
exits the menu; if a sub-menu is displayed, takes you back to the
previous menu.
MUTE Reduces the TV’s volume to its minimum level. Press again to
restore the volume.
OK When in the menu system, displays sub-menus and make
selections.
ON•OFF Turns the TV on and off.
PRESETS Toggles through the picture mode settings: Natural,
Vibrant, Gaming, and Personal.
SOUND For an Analog channel, switches the sound mode options.
For a Digital channel, switches the audio language. In VGA mode,
switches to the audio input you selected from the VGA Sound Source
option.
SUB CH When entering a digital channel that has a subchannel, press
this button to enter a subchannel. Once the channel is entered, press
the OK button to tune to the channel.
VOL – or VOL + Decreases or increases the TV’s volume.
WATCH TV Switches back to watching a TV channel if you're tuned
to an input.
SOUND
ON•OFF
PRESETS
CC
INPUT SUB CH
WATCH TV FORMAT
VOL VOL
MUTE
GO BACK FAV
CLEAR
CH -
CH +
VOL- VOL +
MENU OK INFO
Note: If you need to replace your
remote, call 1-800-338-0376. A
shipping and handling fee, and the
appropriate sales tax, will be charged
upon ordering. Have your Visa,
MasterCard, or Discover Card ready.
Remote control part number
R130D1
16733890.indb 1916733890.indb 19 12/6/06 11:27:38 AM12/6/06 11:27:38 AM

Graphics contained within this publication are for representation only.
20 Chapter 2
Chapter 2: Using the TV's Features
Channel Banner
There are several indicators that might appear when you press the INFO button on the remote.
This display is called the Channel Banner. The following list describes the items on the Channel
Banner screen (left to right and top to bottom).
Analog Channel Banner
A Ch 70 LPJ/D Ch 700 BEV The channel and station you're currently viewing are displayed.
An Adisplayed means it's an analog channel; a Ddisplayed
means it's a digital channel. Digital channels may also display an
HD (High Definition), SD (Standard Definition), or DT (Digital
Television) at the end of the station.
12:15 PM Current time that you set under the Set Time option in the
Options menu.
Program name The program name appears, if available.
480i/1080i Current resolution is displayed.
TV-PG The program rating appears, if available.
Stereo Current audio the channel is broadcasting.
A Ch 70 LPJ 12:15 PM
Crafty Lady
480i Stereo
D Ch 700 BEV 12:15 PM
Ides of March
1080i TV-PG
Digital Channel Banner
Parental Controls Menu
u
u
To Move
USA Parental Locks
Canada Parental Locks
Unrated Programs Unlocked
OK To Select MENU To Exit
u
Parental Controls and V-Chip
The choices in the USA Parental Controls and Canada Parental
Controls menus involve software inside your TV (referred to as V-Chip)
which allows you to block TV programs and movies. TV programs can
be blocked by age-based ratings, such as TV-MA, which is explained
on page 22. If available, TV programs can also be blocked by content,
such as adult language (L). This is explained on page 22. Movies can
only be blocked by age-based ratings. This is explained on page 23.
Once you block programs, you can unblock programs by entering a
password.
By default, the software inside your TV is turned off or unlocked. For
instructions to lock V-Chip, go to the next page.
Note: Parental control settings are not available for HDMI or
COMPONENT inputs.
How V-Chip Works for USA and Canada
V-Chip reads the program’s age-based rating (TV-MA, TV-14, etc.) and
content themes [(Violence (V), Adult Language (L), etc.)]. If you have
blocked the rating and/or content themes that the program contains,
you will receive the message This program is blocked. Press MENU
key to enter password. Go to page 32 for the US and Canada ratings
explanations.
Broadcasters are not required to provide content themes, so programs
received with no content themes will only be blocked if you block
their age-based rating. You can also block out programs that have been
given a rating of None for TV Ratings, N/A or N/R for Movies, or E
(Exempt) for Canadian ratings. Go to page 23 for unrated explanation.
Options
To Move
u
u
u
Set Time
Sleep Timer Off
Set Password
Parental Controls
Analog Captions CC1
Digital Captions Text1
Digital Caption Setup
OK To Select MENU To Exit
u
u
u
u
16733890.indb 2016733890.indb 20 12/6/06 11:27:38 AM12/6/06 11:27:38 AM
