RCA SystemLink CRCU100 User manual

Thank you for choosing the RCA System Link 5
Universal Remote Control. You have selected a fine
product designed to give you years of performance.
Before attempting to use your new remote control,
please review the set-up instructions that follow.
TABLE OF CONTENTS
Button Functions &
Component Compatibility ....................................2
Battery Installation ................................................
3
Simple Set-Up Instructions.. ................................ .4
Simple Set-Up Instructions.. ................................ .5
Brand Codes
TV.. ...................................................................... .6
VCR.. .................................................................... 7
Cable Box.. .......................................................... .8
Audio Components.. ............................................ .9
Additional Operating Notes
Controlling a Component’s Functions .................10
Controlling Two VCR’s .......................................10
Warranty Information ..........................................
11
SystemLinkTM Remote Control model CRCUlOO
replaces infrared remote controls
manufactured after 1984.

your component(s). owner’s manuals.
BUTTON DESCRIPTION TV VCR CABLE AUDI(
ON/OFF
On or Off 0 0 0 0
VCR1 Operates First VCR 0
VCR2 Operates Second VCR
l
AUDIO Operates one audio
l
component
CABLE Operates cable box 0
TV Operates television 0
REW Rewind 0 0
FF Fast Forward 0 0
STOP Stops Function 0 0
PLAY Starts Function 0 0
REC* Record Function 0 0
TV/VCR Record one channel 0
while watching another
PROG Program Function
n
PAUSE Pauses Function 0 0
DISPLAY Displays on-screen menu
n n
CLEAR Clears on-screen display w
n
ID Identity 0 0 0 0
PC/ENTR Previous Channel/Enter
n
CHAN Channel Up and Down 0 0 0 0
VOL Volume 0 0 0
-and+ Menu
n
VIDEO Display Video Functions
n
AUDIO Display Audio Functions
n
SETUP Display Setup Functions
n
MUTE Blocks Volume 0
PIP Picture-in-Picture
n
SWAP Swaps PIP
n
B&ton Functions & Component Compatibility, ::‘_‘. ‘[‘,
/
The buttons with a 0 beside them in The buttons with a w beside them may
the chart below indicate which func-
tion can work with which component. operate selected models of RCA and
(Ex. The ON/OFF function can work GE components only. They will
with a TV, VCR, Cable Box or Audio probably not control other brands, but
Component). The age, brand, model you should experiment with your
and type of component may prevent it brand component to determine if these :
from responding to all the function buttons have any effect. Complete
c
buttons. Experiment with each button operating details for these buttons can
to determine the exact function for be found in selected RCA and GE
*The REC button is recessed by design to help prevent accidental recordings. Additionally, certam brands of VCR’s may
require you to press both the REC and PLAY buttons simultaneously to start the VCR recording
2

InstalhgReplacing Batter& ‘T:- Operating
YourRemote
Before attempting to operate your
remote control, install the batteries as
shown below.
1. Turn the remote control face down
and press on the ribbed area of the
battery cover to slide it off.
2. Install four new alkaline “AAA”
batteries in the battery compartment
as shown. Match the + end of each
battery to the + marks in the battery
compartment.
l The remote control produces an
invisible (infrared) beam that travels
in a straight line like the beam of a
flashlight. For this reason, when
operating the remote control, you
must point it directly at the remote
sensor on the component you want to
control. Objects between the remote
and the sensor can block the infrared
light beam.
l Never place anything heavy on top of
the remote control or lay it upside-
down. This may accidentally depress
the buttons for a long time and
discharge the batteries.
l Your remote control is designed to be
very rugged and will withstand a
considerable drop. If it receives an
extreme blow, the case is designed to
slightly separate at the seam rather
than fracture. If this happens, simply
squeeze the case where it separated
until it snaps back together. The
operation of the remote will probably
not be affected.
3. Replace the cover.
l Replace the batteries when your
components fail to respond to the
remote control. You may have to
reprogram the code numbers when
you change batteries. Do not press
any buttons while changing batteries.
3
. ..

Simple set-yp Instructlom- \
GETTING STARTED
1. After the batteries are installed,
your next step is to set up the codes
for each component you wish to
operate. (YOUR COMPONENTWILL
NOT OPERATEWITHTHE REMOTE
UNTILITS CODE IS SET UP.)
2. In the space below, write the brands
and codes of each of your remote
controlled components.
ComDonent Brand Code(s)
TV ~ ___
VCR1
VCR2 ~ ~
Cable Box ~ ~
Audio
Component
3. Find the codes for each brand on the
charts following these instructions.
Code Listings
ComDonent m
TV 6
VCR 7
Cable Box 8
Audio Components 9
Since there may be more than one code
listed for your brand of TV, VCR,
Cable Box or Audio Component, note
all the codes listed.
SETTING UP YOUR CODES
Set up each component using steps 4-
8 below. Repeat the steps for each
component you intend to operate with
the remote control.
Press the component button on the
remote that matches the
component you want to set up
(TV, VCRl, VCR2, Cable or
Audio).
Press the ID button (The ID
button is located above the No. 3
key).
Within three seconds of pressing
the ID button, use the O-9 keypad
to enter the two digit code listed
for your brand.
7. Point the remote at the component
you want to operate and press the
ON/OFF button. If it turns on,
you are ready to set up your next
component. For easy reference,
circle the code in the chart on the
left that turned on your
component.
8. If the component does not turn on,
repeat steps 4-7 with the next
code listed for your brand.
Continue repeating until you find
a code that works.
Please Note: If none of the codes
for your device work, try all
codes starting with 00. Since
some of the brands include
products made by a variety of
manufacturers, the code may be
listed under another brand name.
:
:.:;
5;
1 .
......., ‘.. .:.
.
c

MISE EN ROUTE
1. Aprks avoir install6 les piles,
programmez les codes pour chaque
composant que vous dksirez
commander. (LE COMPOSANTNE
FONCTIONNE AVEC LA
tiLJ?COMMANDE QU’UNE FOIS QUE
SON CODE EST PROGRAMMk.)
2. Dans l’espace ci-dessous, inscrivez les
marques et les codes de chacun des
composants command& par la
t&kommande.
ComDosant
TklCviseur Maraue Code(s)
MagnCtoscope 1 ~ ~
Magnttoscope 2 ~ ~
CXblodlecteur
3. Trouvez le code de chaque marque
dans les tableaux a la suite de ces
instructions.
Liste de codes
Comwsant m
TklCviseur 6
Magnktoscope 7
CgblosClecteur 8
Composants audio 9
fitant donnC qu’il peut exister plus d’un
code pour la marque de votre tClCviseur,
magnttoscope, dblostlecteur ou
composant audio, notez tous les codes
Cnum&s.
PROGRAMMATION DES CODES
Programmez chaque code en suivant
les Ctapes 4 k 8 ci-dessous. RCpttez
les Ctapes pour chaque composant que
vous dCsirez commander avec la
tC1Ccommande.
4. Appuyez sur le bouton de
composant de la tClCcommande
correspondant au composant que
vous dksirez programmer (TV, VCR
1, VCR 2, Cable ou Audio).
5. Appuyez sur le bouton ID (au-
dessus de la touche 3).
6. Dans le trois secondes suivant
l’enfoncement du bouton ID, utilisez
les touches 0 g 9 pour entrer le code
&deux chiffres correspondant g la
marque de I’appareil.
7. Pointez la tClCcommande en
direction du composant 5
commander et appuyez sur le bouton
ON/OFF. Si l’appareil s’allume,
vous pouvez programmer le com-
posant suivant. Pour faciliter la ;
rCf&ence encerclez le code dans le 1.
tableau 2 gauche qui a permis d’al- ’
lumer le composant. composant. i
8. Si le composant ne se met pas en
marche, rCpCtez les &apes 4 &7
avec le code suivant pour la marque.
Continuez ainsi jusqu’?i ce que vous
trouviez un code qui fonctionne.
Remarque: Si aucun des codes
convient ?Ivotre appareil, essayez
tous !es codes en commencant par
00. Etant donnC que certaines
marques comprennent des produits
fabriquks par diffkrents fabricants,
le code peut figurer sous un autre
nom de marque.
5

4kai ............................................... 02 NAD .......................................... 18,23
Anam National ................................ 38 NEC ............................ 11,14,19,27,38
AOC ..................................... 11,19,27 Panasonic.. ............................ 12,13,38
Candle.. ................................. 11,27,33 Philco ........................ 06,07,10,(more)
Citizen ............................. 11,27,33,64 ............ 11,13,16,19,27,33,35,37,38,43
Colortyme.. ................................ 11.27 Philips ....................... 06,07,10,(more)
Concerto .................................... 11,27 ...................... 11,13,16,33,35,37,38,43
Contec, Cony ............... 36,37,40,42,64 Pioneer.. ........................... 11,27,45,62
Craig .............................................. 64 Portland ................................ 11,19,27
Curtis Mathes
................... 00,11,15,27 ProScan ..................................... 00,46
CXC.. ............................................. 64 Proton.. ................................. 11,27,37
Daewoo ................................. 11,19,27 Quasar ....................................... 12,38
Daytron.. .................................... 11,27 Radio Shack .______00,21,25,36,37,59,64
Electrohome.. .......... 06,11,14,27,38,61 RCA.. ........ 00,06,11,19,27,34,38,44,46
Emerson.. .......... 11,26,27,28,29,(more) Realistic.. ....................................... 21
...................... 30,31,32,37,42,53,64,65 Sampo.. ...................................... 11,27
Envision .................................... 11,27 Samsung ........ 06,11,14,15,19,27,36,37
Fisher ............................... 17,21,39,41 Sanyo.. .................... 17,21,39,56,57,58
Funai ......................................... 21,64 Scott.. ............................... 11,28,37,64
GE.. ................... .00,08,09,11,12,27,38 Sears.. ............... 00,06,11,14,17,(more)
Goldstar.. ....... 03,04,06,11,19,27,37,50 ...................... 18,21,23,27,39,40,41,51
Hallmark.. .................................. 11,27 Sharp ........ 11,20,25,27,37,52,53,59,60
Hitachi.. .09,11,27,36,37,40,47,63 Sony.. ............................................. 02
........
Infinity.. ......................................... 13 Soundesign ............................ 11,27,33
JBL ................................................ 13 Sylvania.. .................... 06,07,10(more)
Jensen.. ...................................... 11,27 ...................... 11,13,16,27,33,35,43,49
JCPenney ..................... 00,08,11,19,27 Symphonic.. .................................... 64
JVC.. ................. .12,24,36,37,40,48,51 Tatung.. .......................................... 38
Kawasho ............................... 02,11,27 Technics. ........................................ 12
Kenwood .......................... 06,11,14,27 Techwood.. ................................ 11,27
Kloss Novabeam ........................ 35,43 Tecknika ............. 11,19,27,33,36,37,40
Loewe ............................................ 13 TMK .......................................... 11,27
Luxman ...................................... 11,27 Toshiba.. ............................... 18,21,23
LXI. ............................. 13,18,21,23,54 Universal ................................... 08,09
Magnavox .................. 06,07,10,(more) Victor ............................................. 51
......................... .11,13,16,27,33,35,43 Vidtech.. .................................... 19,27
Marantz ................................. 11,13,27 Wards.. ............. 00,05,06,07,08,(more)
MGA.. ...... .06,11,14,19,22,27,41,56,61 ........ 09,10,11,13,19,25,27,28,35,43,59
Mitsubishi .................. 06,11,14,(more) Yamaha.. .......................... 06,14,19,27
.......................... 19,22,27,41,55,56,61 Zenith ............................................. 01
MTC.. ................................... 11,19,27
6

Aiwa.. ............................................ 15
Akai.. ............................... 03,17,22,23
Audio Dynamics ........................ 14,16
Broksonic.. ..................................... 10
Candle.. ............................... ,07,09,13
Canon ........................................... .08
Capehart.. ...................................... .Ol
Citizen.. ................................ 07,09,13
Colortyme ..................................... .14
Craig.. ....................................... 07,12
Curtis Mathes .............. 00,07,08,14,15
Daewoo.. ....................................... ,13
dbx.. .......................................... 14,16
Dimensia.. ...................................... 00
Dynatech.. ...................................... 15
Electrohome .................................. .27
Emerson.. .............. 08,09,10,13,(more)
......................... .15,20,23,27,34,41,42
Fisher .......................... 02,12,18,19,43
Funai.. ........................................... .15
GE.. ................................. 00,07,08,32
Goldstar.. ................................... 09,14
Harmon Kardon.. ............................ 14
Hitachi.. .......................... .05,15,35,36
Instant Replay ................................ 08
JCL.. .............................................. 08
JCPenney.. .... .02,05,07,08,14,16,30,35
JVC.. ............................... .02,14,16,30
Kenwood.. ........................ 02,14,16,30
Lloyd ............................................. 15
Logik.. .......................................... .31
Magnavox.. ................................ OS,29
Marantz ................. .02,08,14,16,29,30
Marta ............................................. 09
MEI ............................................... 08
Memorex.. ....................... .08,09,12,15
MGA.. ....................................... 04,27
Midland.. ....................................... .32
Minolta.. .................................... 05,35
Mitsubishi ................... 04,05,27,35,40
Montgomery Ward.. ....................... .06
MTC .......................................... 07,15
Multitech .......................... 07,15,31,3i
NEC.. ............................... 02,14,16,3C
Panasonic.. ..................................... 08
Pentax ....................................... 05,35
Philco.. ...................................... 08,2S
Philips ....................................... 08,29
Pioneer ...05,16,33(Lase r Disc Player)
ProScan.. ....................................... .OU
Quartz.. .......................................... 02
Quasar ............................................ 08
RCA.. ................. 00,05,07,08,28,35,37
Radio Shack/Realistic.. ...02,06,(more)
......................... .08,09,12,15,19,27,43
Samsung.. .................... 07,13,22,32,42
Sansui.. ......................................... .16
Sanyo ........................................ 02,12
Scott.. ................................... 04,13,41
Sears.. ...... .02,05,09,12,15,18,19,35,43
Sharp ............................... 06,24,27,39
Shintom.. ............................. .17,26,31
Sony.. ................................... 17,26,38
Sylvania.. .............................. 08,15,29
Symphonic ..................................... 15
Tandy.. ...................................... 02,15
Tashiko ......................................... .09
Tatung.. .......................................... 30
Teat .......................................... 15,30
Technics.. ...................................... .08
Teknika.. .......................... 08,09,15,21
Toshiba.. ............................... 05,13,19
Totevision ................................. 07,09
Unitech .......................................... 07
Vector Research.. ...................... .14,16
Victor ............................................ 16
Video Concepts. ......................... 14,16
Videosonic ..................................... 07
Wards ................... 05,06,07,08,(more)
.................... .09,12,13,15,25,27,31,35
Yamaha.. .......................... 02,14,16,30
Zenith.. ................................. 11,17,26
7

[TV Brand Code(s)
ABC .............................................................................................................. 22,46
Anvision ........................................................................................................ 07,08
Cablestar ....................................................................................................... 07,08
Eagle ............................................................................................................. 07,OS
Eastern International .......................................................................................... 02
General Instrument ............................................................ 04,05,15,22,23,24,25,46
G1400 ................................................................................ 04,05,15,23,24,25,30,36
Hamlin ............................................................................................ 03,12,13,34,48
Hitachi ..................................................................................................... 37,43,46
Jerrold ...................................................................................... 04,05,15,23,(more)
...................................................................................... ....... .24,25,30,36,45,46,47
Macom .......................................................................................................... 37,43
Magnavox ................................................................................. 07,08,19,21,(more)
................................................................................... .......... .26,28,29,32,33,40,41
NSC ................................................................................................................... 09
Oak.. ........................................................................................................ 01,16,38
Oak Sigma ......................................................................................................... 16
Panasonic ................................................................................................. 03,27,39
Phillips ................................................................ 07,08,19,21,26,28,29,32,33,40,41
Pioneer.
....................................................................................................
18,20,24
RCA.. ............................................................................................................ 00,27
Randtek ......................................................................................................... 07,08
Regal ........................................................................................................ 03,12,13
Regency ........................................................................................................ 02,33
Samsung ............................................................................................................ 44
Scientific Atlanta ...................................................................................... 03,22,35
Signature ............................................................................................................ 46
Sprucer .............................................................................................................. 27
Starcom .............................................................................................................. 46
Sylvania ............................................................................................................. 11
Teknika. ............................................................................................................. 06
Texscan ......................................................................................................... 10,ll
Tocom .................................................................................................. 17,21,49,50
Unika ....................................................................................................... 31,32,41
Universal ....................................................................................................... 51,52
Viewstar ................................................................................... 07,08,19,21,(more)
.............................................................................................. 26,28,29,32,33,40,41
Warner Amex ..................................................................................................... 44
Zenith ........................................................................................................... 14,42
8

I_
ads
Aiwa
Akai
Denon
Dimensia
Dynamic Bass
Emerson
Fisher
Hitachi
JVC
Kenwood
Kyocera
Lotte (NEC)
Magnavox
Marantz
Mitsubishi
Nakamichi
Panasonic
Philips
Pioneer
RCA
Realistic
Sansui
Scott
Sherwood
Sony
Teat
I’echnics
Yamaha
AMP
01
02,os
23
16,58
17,74
09
6.5
22,76
15,59
20
12
62
14
24
11,13
21
10
l&19
03
29
30,35
74
57
07
25
66
67
63
32
67,70,77
65
76
59
75
61
68
38 36
62 61
42 39
03 07,43,44
63,66
45
66
49
52 46
69
50
CD
TAPE PHON
60
06 05
26,27 28
33,34
71,72
37
40,41
06
55,56
48,53
51
73
05
47
AUX
04
31

c
Additional Operating Notes
Controlling a Component’s
Function:
Press the correct component button to
tell the remote which component you
want to control. Then press the
desired function button. For example,
to turn the TV on: First hit the TV
button, then the ON/OFF button. Or
to operate the fast forward function of
a VCR, first hit the VCR button, then
the fast forward arrow button.
Number Buttons:
Press two numbers to select channel.
Press a “0” before a single-digit
channel number.
For some TV’s there will be a
2-second delay before the channel will
change.
For other brands of TV’s, you will
need to press the PC/ENTER button
after selecting the two number
buttons.
VCR On/Off Switch:
Some older VCR’s do not have an
ON/OFF switch on their remote
controls and cannot be turned on and
off remotely. If you have this type of
VCR, you can test the code number
by pressing the CHAN button instead
of the ON/OFF button. Make sure the
VCR is alreadv turned on when vou
test the code number.
Controlling Two VCR’s
This remote can control two VCR’s
independently as long as each VCR
operates in a different remote
transmitting code.
Some newer RCA VCR’s are capable
of working on either of two remote
codes. These VCR’s have either a
switch labeled VCRIIVCR2 or an
on-screen display titled REMOTE
VCRlIVCR2. You can then set your
new VCR to respond to the remote’s
VCR2 button and your older VCR to
respond to the VCR1 button.
Some older RCA VCR’s have a
NORM/UNIFIED switch that can also
respond to either the VCR1 or VCR2
button on the remote. Place this
switch in the UNIFIED position for
the VCR to respond to the VCR1 but-
ton or in the NORM position for the
VCR2 button. In the NORM position,
you must program the VCR2 button to
respond to code number 05.
If neither of your VCR’s has
switchable code capability, you may
still be able to use the VCRlIVCR2
feature to control two VCR’s of the
same brand since many older VCR’s
use remote codes that are different
than newer VCR’s, You may want to
experiment to see what works with
your particular VCR’s,
10
