Rca Rs22163cp User manual

English (EN)

Español (E)

RS22163CP

User Manual

Manual de usuario

It's important to read this instruction prior to using your new product for the rst time.

Es importante que lea este libro de instrucciones antes de usar su nuevo producto por

primera vez.

EN - 1

This product

contains a low

power laser

device.

CAUTION: TO REDUCE THE RISK OF ELECTRIC

SHOCK, DO NOT REMOVE COVER (OR BACK).

NO USER-SERVICEABLE PARTS INSIDE. REFER

SERVICING TO QUALIFIED SERVICE PERSONNEL.

The lightning ash with arrowhead symbol,

within an equilateral triangle, is intended to

alert the user to the presence of uninsulated

“dangerous voltage” within the product’s

enclosure that may be of sucient magnitude

to constitute a risk of electric shock to persons.

The exclamation point within an equilateral

triangle is intended to alert the user to

the presence of important operating and

maintenance (servicing) instructions in this

owner’s manual.

WARNING:TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSETHIS APPLIANCETO RAIN OR MOISTURE.

The following marks and symbols are located on the back of the unit.

The symbol for Class

(Double lnsulation)

WARNINGS:

• The apparatus shall not be exposed to dripping or

splashingandthatnoobjects lled with liquids,such

as vases, shall be placed on apparatus.

• TheACadapterisusedasdisconnectdeviceand

it should remain readily operable during intended

used. In order to disconnect the apparatus from

the mains completely, the AC adapter should

be disconnected from the mains socket outlet

completely.

• Minimum 10 cm (4 inches) distances around the

apparatus for sucient ventilation.

• Batteriesshallnotbeexposedtoexcessiveheatsuch

as sunshine, re or the like.

• Do not restrict the airow of the unit by placing it in

a place with poor airow, by covering it with a cloth,

or by placing it on carpeting.

• No naked ame sources such as lighted candles

should be placed on the apparatus.

Follow the advice below for safe and appropriate

operations.

ON PLACEMENT

• Donotusetheunitinplaceswhichareextremely

hot, cold ,dusty, or humid.

• Placetheunitonaatandevensurface.

• Donotrestricttheairowoftheunitbyplacingit

in a place with poor air ow, by covering it with a

cloth, or by placing it on a carpet.

ON SAFETY

• Beforeoperating,makesurethattheratedvoltage

oftheACadaptermatchesyourlocalvoltage.

• Whenyouarenotgoingtousetheunitforalong

periodoftime,disconnecttheACadapter.

ON CONDENSATION

• Whenleftinaheatedroomwhereitiswarmand

damp, water droplets or condensation may form

inside the CD player.

• Whenthereiscondensationinsidetheunit,theunit

may not function normally.

• Letitstandfor1to2hoursbeforeturningthepower

on, or gradually heat the room and allow the unit to

dry before use.

SAFETY PRECAUTIONS

EN - 2

IMPORTANT SAFETY INSTRUCTIONS

FCC INFORMATION

This device complies with Part 15 of the FCC rules.

Operation is subject to the following two conditions:

(1) This device may not cause harmful interference,

and

(2) This device must accept any interference received,

including interference that may cause undesired

operation.

Note: This equipment has been tested and found

tocomplywiththelimitsforaClassBdigitaldevice,

pursuant to Part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against

harmful interference in a residential installation. This

equipment generates, uses, and can radiate radio

frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful

interference to radio communications. However, there

is no guarantee that interference will not occur in a

particular installation. If this equipment does cause

harmful interference to radio or television reception,

which can be determined by turning the equipment

o and on, the user is encouraged to try to correct

the interference by one or more of the following

measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment

and receiver.

- ConnecttheequipmentintoanACpoweroutlet

that is on a circuit dierent from the one the

receiver is connected.

- Consult the dealer or an experienced radio/TV

technician for help.

Warnings: Changes or modifications to this unit

not expressly approved by the party responsible for

compliance could void the user’s authority to operate

the equipment.

This Class B digital apparatus complies with

Canadian ICES-003.

Cet appareil numérique de la classe B est conforme

à la norme NMB-003 du Canada.

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Followallinstructions.

5. Do not use this apparatus near water.

6. Clean only with a dry cloth.

7. Do not block any of the ventilation openings.

Install in accordance with the manufacturer’s

instructions.

8. Do not install near any heat sources such as

radiators, heat registers, stoves, or other apparatus

(including ampliers) that produce heat.

9. Do not defeat the safety purpose of the polarized

orgrounding-typeplug.Apolarizedplughastwo

bladeswithonewiderthantheother.Agrounding

type plug has two blades and a third grounding

prong. The wide blade or the third prong are

provided for your safety. If the provided plug

doesnottintoyourACpoweroutlet,consultan

electrician for replacement of the obsolete outlet.

10. Protect theACpowercord frombeing walked

on or pinched particularly at plugs, convenience

receptacles, and the point where they exit from

the apparatus.

11. Only use attachments/accessories specied by the

manufacturer.

12. Use only with a cart, stand, tripod,

bracket, or table specied by the

manufacturer, or sold with the

apparatus.Whenacartisused,

use caution when moving the

cart/apparatus combination to

avoid injury from tip-over.

13. Unplug this apparatus during lightning storms or

when unused for long periods of time.

14. Referallservicingtoqualiedservicepersonnel.

Servicing is required when the apparatus has been

damagedinanyway,suchastheACpowercordor

plug is damaged, liquid has spilled or objects have

fallen into the apparatus, the apparatus has been

exposed to rain or moisture, does not operate

normally, or has been dropped.

Portable Cart

Warning

EN - 3

2. USING THE AC ADAPTER

 Beforeuse,makesurethattheratedvoltageof

yourACadaptermatchesyourlocalvoltage.Make

sure both speakers are connected correctly before

pluggingtheACadaptercordintotheACpower

outlet.

1. CONNECTING THE SPEAKERS

Connect the wires to the speaker terminals.

Note: Connecting speakers other than the speakers supplied with the unit, may damage the unit.

MAINTENANCE

CLEANING THE DISC

If the CD skips or will not play, the

disc may need to be cleaned.

Beforeplaying,wipethediscfrom

the center outward with a cleaning

cloth.Afterplaying,storethedisc

in its case.

CLEANINGTHETAPEHEADS

To maintain optimum sound

quality, clean the playback/

record heads (a), erasure head

(b), pinch roller (c), and capstans

(d)regularly(every10hoursof

use). Use a cotton swab lightly

moistened with cleaning uid or

denatured alcohol.

CLEANING THE UNIT

Do not use volatile chemicals on this unit. Clean by

lightly wiping with a soft cloth.

IMPORTANT NOTE

• Ifanabnormaldisplayindicationoranoperating

problemoccurs,disconnecttheACadapter.Wait

at least 5 seconds, then reconnect it.

• Beforetransportingtheunit,removealldiscsfrom

the disc compartment.

SYSTEM CONNECTIONS

To AC

Power

Outlet

AC adapter

Audio Cable

(not supplied)

To AUDIO OUT or

HEADPHONE jack

Portable Audi o

3. CONNECTING WITH OTHER OPTIONAL EQUIPMENT

Listening to the Audio Signals from the External Equipment

1) ConnecttheACadaptertotheACpoweroutlet.

2) SlidetheFUNCTIONselectortotheLINEINposition.

3) Connecta3.5mm-to-3.5mmaudiocable(notincluded)totheLINEINjackonthefrontofunitandthe

AUDIOOUT/HEADPHONEjackofyourportabledevice.

4) Turnonyouraudioequipmentandplaytheexternalsource.

EN - 4

1. CD Door

2. Remote Sensor

3. POWER ON Indicator

4. VOLUME Control

5. PHONES Jack

6. Function Selector

(TAPE (STANDBY) / AM / FM / CD/LINE-IN)

7. DISC SELECT / PLAY/PAUSE / STOP

Buttons

8. Cassette Compartment

9. Cassette Operation Controls

PLAY Button

REW (Rewind) Button

F.FWD (Fast Forward) Button

STOP/EJECT Button

10. SKIP/SEARCH Buttons

11. CD REPEAT Button

12. LINE IN Jack

13. TUNING Control

14. Dial Scale

15. CD Display

ONLY FOR CD MODE

1. PLAY/PAUSE button

2. SKIP/SEARCH button

3. DISC SKIP button

4. SKIP/SEARCH button

5. REPEAT button

6. STOP button

USING THE REMOTE CONTROL CORRECTLY

• PointtheremotecontrolattheREMOTESENSORlocatedontheunit.

• Whenthereisastrongambientlightsource,theperformanceoftheinfrared

REMOTESENSORmaybedegraded,causingunreliableoperation.

• Therecommendedeectivedistanceforremoteoperationisabout13feet.

LOCATION OF CONTROLS

REMOTE CONTROL

EN - 5

1.SlidetheFUNCTIONselectortoAMorFM.

 ThePOWERONindicatorlightsup.

2. Tune into a station.

3.Adjustthevolumelevel.

NOTE: DO NOT CONNECT TO AN OUTSIDE

ANTENNA.

Fully unwind the wire antenna. Then extend the wire

antenna and place it in the position that sounds best.

(WhentheFMbroadcastsignalisstrong,itcanreceive

FMStereoBroadcast.)

Rotate the unit to get the best receiving position.

AFTER LISTENING

SlidetheFUNCTIONselectortoSTANDBY.

FOR BETTER RECEPTION

Remove the protective

plastic tab before

operating the remote

control.

1. Open the battery door. 2.InsertoneCR2025

(3V) size battery.

NOTE:

If the remote control is not going to be used for a long

time, remove the battery to avoid damage caused by

battery leakage corrosion.

WARNINGS:

• Donotdisposeofbatteryinre.Batterymayex-

plode or leak.

• Batteriesshallnotbeexposedtoexcessiveheat

such as sunshine, re or the like.

TO CHANGE REMOTE BATTERY

CAUTION:

• Dangerofexplosionifbatteryisincorrectly

replaced. Replace only with the same or equivalent

type.

• [Theremotecontrolsuppliedwith]Thisproduct

contains a button cell battery that may be ingested

by children. Do not leave button cell batteries

within reach of children.

BATTERY REPLACEMENT

Whenthebatterybecomesweak,theoperating

distance of the remote control is greatly reduced and

you will need to replace the battery.

REMOTE CONTROL

RADIO OPERATION

EN - 6

4. Close the CD door by gently pushing down until it is

secure. The disc no. and the total number of tracks

will show in the CD display for a few seconds.

1. SlidetheFUNCTIONselectortoCD.ThePOWERON

indicator lights up.

2. Open the disc compartment. Place a disc onto the

disc(s) holder, with the label side up.

3. Press the DISC SKIP button to revolve the tray

clockwise.

Place other disc(s) on the disc holder(s).

5. Press the DISC SKIP button to select the desired disc.

Press either the SKIPorSEARCH button to

select the desired track.

COMPACT DISC PLAYBACK

To Stop Playing:

(a) PressthePLAY/PAUSE button and the track no.

will ash. Press this button again to resume playing.

(b) Press the STOP button.

NOTE:

The SKIPorSEARCH button can only be

used to choose a track on the current disc. To choose

a track of another disc, the DISC SKIP button should

be pressed to get to the desired disc rst.

6. PressthePLAY/PAUSE button to start playback.

REPEAT PLAYBACK - DURING PLAYBACK MODE

To Repeat the Current Track

•Press the CDREPEATbuttonuntilREPEATONE

appears on the CD display. The current track will

be played repeatedly until the STOP button is

pressed.

•Press the or SKIPbuttonswiththeREPEAT

ONEfunctionon,therepeatwillstillskipthrough

dierent tracks on the selected disc.

To Skip to a Dierent Track

•To locate a track of currently selected disc, press

or SKIP/SEARCHbuttonrepeatedly.

• Tolocateatrackofanotherdisc,pressDISCSELECT

button to get to desired disc rst and then press

or SKIP/SEARCHbutton repeatedly.

•To search a track, keep or SKIP/SEARCH

button pressed and release it at desired point.

PRESSITREPEATEDLY

FORWARD

SKIP

REVERSE

SKIP

KEEP IT PRESSED

FORWARD

SKIP

REVERSE

SKIP

EN - 7

To Repeat All Discs

• Pressthe CDREPEATbuttonuntilthethe

REPEATindicatordisappearsfromtheCDdisplay.

•Press the or SKIP buttons will make the

player start playing from the newly selected point

of the current disc.

• PresstheDISCSELECTbuttonwillmaketheplayer

start playing from the rst track of the newly selected

disc. The / SKIP buttons can be used to

choose a particular track on this selected disc, the

player will then start playing from that point.

NOTE: Ensure 3 discs put inside to enjoy repeat all

disc feature.

COMPACT DISC PLAYBACK

To Cancel Repeat Play

• Pressthe CDREPEATbuttonuntilthethe

REPEATindicatordisappearsfromtheCDdisplay.

ATTENTION -

If the CD player does not operate properly

2. Slide the Function se-

lectorfromSTANDBY

to CD.

1. Slide the Function

selector from CD to

STANDBY.

To Repeat the Whole Disc

• Pressthe CDREPEATbuttonuntilREPEATONE

DISC appears on the CD display. The current disc

will be played repeatedly starting from the current

playing point.

•Press the or SKIP buttons with the REPEAT

ONEDISCfunction on. The whole disc can be

searched and the player will start playing from the

selected point.

TAPE PLAYBACK

2. Press the (STOP/EJECT) button.

1.SlidetheFunctionselectortoTAPE.

3. Insert a cassette tape into the cassette door.

4. Press the (PLAY)buttontobeginplayback.

TO STOP PLAYBACK

Press the (STOP / EJECT) button.

TO REWIND AND FASTWIND

Press the (REW)or (F.FWD)button.Pressthe

(STOP / EJECT) button to stop winding at the

desired position.

EN - 8

Need more help?

Please visit online help at http://www.RCAav.com

TROUBLESHOOTING GUIDE

SYMPTOM

Nosound

Nosoundfromonechannelorunbalancedleft

and right volume

Reversed left and right sound

Lackofbasssoundorimprecisephysicallocation

of musical instruments

Severe hum or noise

Disc in place but unit won’t play

Disc skips

RADIO

Poor FM reception

PoorAMreception

CASSETTE

Playback cannot be made or there is a decrease

in sound level.

Excessive wow or utter, or sound dropout.

Insucient erasure.

Increase of noise or erase of high frequencies.

CAUSE (AND REMEDY)

• TurnVOLUMEclockwise.

• Theheadphonesareconnected.

Disconnect them.

• Checkthespeakerconnectionsoftheinoperative

channel.

• Checkthespeakercordconnectionandspeaker

location.

• Checkthespeakerconnectionforproperphasing.

• TheTVorVCRistooclosetothestereosystem.

Separate the stereo system from the TV or VCR.

• MakesuretheACadapterissecureintheACpower

outlet, and the outlet has power.

• MakesureFUNCTIONselectorissettoCD.

• Makesuredisclabelisfacingup.

• Makesurediscisclean.

• Pausemodeisactivated.

• Discmaybedamagedordirty;checkdisc.

• Makesuretheunitisonasecurespot.Vibrationor

jarring can cause the disc to skip.

• MakesureFMantennawireisunwound.

• Electricalinterferenceinyourhomecancause

poor reception. Move the unit away from sources

of interference (especially those with motors and

transformers).

• Repositionorturnthemainunitforbetterreception.

• Dirty head.

•Magneticbuild-upontheplaybackhead.

•Contaminationofthecapstansorpinchrollers.

•Magneticbuild-upontheerasehead.

•Magneticbuild-upontheerasehead.

Specifcations and external appearance are subject to change without notice.

EN - 9

AVC MULTIMEDIA ("AVC") makes the following limited warranty. These limited warranties extend to the original

consumer purchaser and is limited to non-commercial user of the product.

One Year Parts & Labor Warranty

AVC products purchased in the United States are warranted to be free from defects in materials or workmanship

for a period of one year from the date of their original retail purchase. If the unit fails to conform to this warranty,

we will service the product using new or refurbished parts and products, at AVC's sole discretion.

During a period of one year from the eective warranty date, AVC will provide, when needed, service labor to

repair a manufacturing defect at its designated Service Center. To obtain warranty service in the United States, you

must rst call our Customer Support Center at 1-877-252-6873, during the hours listed in the box below. The

deternination of service will be made by AVC customer support.

PLEASE DO NOT RETURN YOUR UNIT TO AVC WITHOUT PRIOR AUTHORIZATION.Neworremanufactured

replacements for defective parts or products will be used for repairs by AVC at its designated Service Center for

one year from the defective warranty date. Such replacement parts or products are warranted for an additional

one year from the date of repair or replacement. The Customer will be required to ship the unit to the Service

Center indicated at the time Customer Support is contacted to make the necessary repairs. The customer is

responsible for all transportation charges to the service facility.

Packaging and Shipping Instruction

Whenyousendtheproducttothe AVC service facility you must use the original carton box and packing material

or an equivalent as designated by AVC.

Your Responsibility

(1) Youmustretainyourbillofsaletoprovideproofofpurchase.

(2) ThesewarrantiesareeectiveonlyiftheproductispurchasedandoperatedintheU.S.A.orCanada.

(3) Warrantiesextendonlytodefectsinmaterialorworkmanship,anddonotextendtoanyproductorparts

which have been lost or discarded, or damage to product or parts caused by misuse, accident, improper

operation or maintenance, or use in violation of instructions provided with the product, or to product which

has been altered or modied without authorization of AVC, or to products or parts thereof which have had the

serial number removed or changed.

Out of Warranty

Allwarrantiesimpliedbystatelaw,includingtheimpliedwarrantiesofmerchantabilityandtnessforaparticular

purpose,areexpresslylimitedtothedurationofthelimitedwarrantiessetforthabove.Withtheexceptionof

any warranties implied by state law as hereby limited, the foregoing warranty is exclusive and in lieu of all other

warranties, guarantees, agreements and similar obligations of manufacturer or seller with respect to the repair or

replacement of any parts. In no event shall AVC be liable for consequential or incidental damages.

Noperson,agent,distributor,dealerorcompanyisauthorizedtochange,modifyorextendthetermsofthese

warranties in any manner whatsoever. The time within action must be commenced to enforce any obligation of

AVC arising under the warranty or under any statute, or law of the United States or any state thereof, is hereby

limited to one year from the date of purchase. This limitation does not apply to implied warranties arising under

state law.

This warranty gives you specic legal rights and you may also have other rights, which may vary from state to state. Some

states do not allow limitation on how long an implied warranty lasts, when an action may be brought, or the exclusion or

limitation of incidental or consequential damages, so the above provisions may not apply to you.

For more information on other products and services, please contact our web site at www.RCAav.com

Important:Alsokeepyour“BillofSale”asproofofpurchase.

Model no. ................................................................................. Product name ................................................................................................

Type of set ...............................................................................................................................................................................................................

Serial no. ................................................................................... Invoice no. .......................................................................................................

Date purchased ..................................................................... Dealer name ...................................................................................................

FORSUPPORT,SERVICEANDREPAIR,PLEASEVISITwww.RCAav.com.
