RCA MR29410 User manual

Television
User’s Guide
Please read this manual before
using this product for the first time.
TOCOM 15775750
Changing entertainment. Again.
Model: MR29410
15775750 Cover 5/9/01 5:17 PM Page 1

Warning! Important
Safety Instructions
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
This symbol indicates high voltage is present inside. It is
dangerous to make any kind of contact with any inside part of
this product.
This symbol alerts you that important literature concerning
operation and maintenance has been included with this product.
POWER CONSUMPTION: 110-240V~50/60 Hz
120 W (for model MR29410)
Note to CATV system installer: This reminder is provided to call CATV system
installer’s attention to Article 820-40 of the National Electrical Code, that provides
guidelines for proper grounding and, in particular, specifies that the cable ground
shall be connected to the grounding system of the building as close to the point of
cable entry as practical.
Caution: To prevent electric shock, insert the plug fully into the electrical outlet.
To prevent damage which may result in fire or electric shock
hazard, do not expose this appliance to rain or moisture.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
15775750 Inside 5/9/01 5:16 PM Page 1

SAFETY 1
Important Safety Information
Always be careful when using your television. To reduce the risk of fire, electrical shock,
and other injuries, keep these safety precautions in mind when installing, using, and
maintaining your machine.
• Read all safety and operating instructions before operating your TV.
• Keep the safety and operating instructions for future reference.
• Heed all warnings on the TV receiver and in the operating instructions.
• Follow all operating and use instructions.
• Unplug the TV receiver from the wall outlet before cleaning. Use a damp cloth; do not use
liquid or aerosol cleaners.
• Never add any attachments and/or equipment without approval of the manufacturer. Such
additions can increase the risk of fire, electric shock, or other personal injury.
• Do not use the TV receiver where contact with or immersion in water is a possibility, such
as near bath tubs, sinks, washing machines, swimming pools, etc.
• Do not place the TV on an unstable cart, stand, tripod, bracket,
or table where it can fall. A falling TV can cause serious injury
to a child or adult, and serious damage to the appliance. Use
only with a cart, stand, tripod, bracket, or table recommended
by the manufacturer or sold with the TV. Follow the manufac-
turer’s instructions when mounting the unit, and use a mount-
ing accessory recommended by the manufacturer. Move the TV
and cart with care. Quick stops, excessive force, and uneven
surfaces can make the unit and cart unsteady and likely to
overturn.
• Provide ventilation for the TV receiver. The unit is designed with slots in the cabinet for
ventilation to protect it from overheating. Do not block these openings with any object,
and do not place the TV receiver on a bed, sofa, rug, or other similar surface. Do not place
it near a radiator or heat register. If you place the TV receiver on a rack or bookcase,
ensure that there is adequate ventilation and that you’ve followed the manufacturer’s
instructions for mounting.
• Operate your TV receiver only from the type of power source indicated on the marking
label. If you are not sure of the type of power supplied to your home, consult your
appliance dealer or local power company.
• Use only a grounded or polarized outlet.
15775750 Preface 5/9/01 5:19 PM Page 1

•Protect the power cord. Power supply cords should be routed so that they won’t be walked
on or pinched by objects placed on or against them. Pay particular attention to cords at
plugs, convenience receptacles, and the point where they exit from the unit.
•Unplug the TV from the wall outlet and disconnect the antenna or cable system during a
lightning storm or when left unattended and unused for long periods of time. This will pre-
vent damage to the unit due to lightning and power-line surges.
•Avoid overhead power lines. An outside antenna system should not be placed in the vicinity
of overhead power lines or other electric light or power circuits or where it can fall into such
power lines or circuits. When installing an outside antenna system, be extremely careful to
keep from touching the power lines or circuits. Contact with such lines can be fatal.
•Do not overload the wall outlet or extension cords. Overloading can result in fire or electric
shock.
•Do not insert anything through the openings in the unit, where they can touch dangerous
voltage points or damage parts. Never spill liquid of any kind on the TV.
•Ground outdoor antennas. If an outside antenna or
cable system is connected to the TV, be sure the anten-
na or cable system is grounded so as to provide some
protection against voltage surges and built-up static
charges. Section 810 of the National Electrical Code,
ANSI/NFPA No.70-1984, provides information about
proper grounding of the mast and supporting structure,
grounding of the lead-in wire to an antenna discharge
unit, size of grounding conductors, location of antenna
discharge unit, connection to grounding electrodes, and
requirements for the grounding electrode.
•Do not attempt to service the TV yourself. Refer all servicing to qualified service personnel.
Unplug the unit from the wall outlet and refer servicing to qualified service personnel under
the following conditions:
- when the power-supply cord or plug is damaged
- if liquid has been spilled on the unit or if objects have fallen into the unit
- if the TV has been exposed to rain or water
- if the TV does not operate normally by following the operating instructions
- if the TV has been dropped or the cabinet has been damaged
- when the TV exhibits a distinct change in performance
•If you make adjustments yourself, adjust only those controls that are covered by the operat-
ing instructions. Adjusting other controls may result in damage and will often require exten-
sive work by a qualified technician to restore the TV to normal.
•When replacement parts are required, be sure the service technician uses replacement parts
specified by the manufacturer or those that have the same characteristics as the original part.
Unauthorized substitutions may result in additional damage to the unit.
•Upon completion of any service or repairs to this TV, ask the service technician to
perform safety checks to determine that the TV is in a safe operating condition.
ANTENNA
LEAD IN WIRE
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
GROUNDING
CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)
GROUND CLAMP
ELECTRIC
SERVICE
EQUIPMENT
NEC — NATIONAL ELECTRICAL CODE
EXAMPLE OF
ANTENNA GROUNDING
2SAFETY
15775750 Preface 5/9/01 5:19 PM Page 2

CONTENTS
CONTENTS 1
Chapter 1: Your New TV . . . . . . . . . . . . . . .1.1
List of Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.1
Familiarizing Yourself with The TV . . . . . . . . . . . . . . . . . . . . . . . . 1.1
Front Panel Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.1
Side Panel Jacks. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.2
Rear Panel Jacks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.2
Chapter 2: Installation . . . . . . . . . . . . . . . . 2.1
Connecting VHF and UHF Antennas . . . . . . . . . . . . . . . . . . . . . . . 2.1
Antennas with 300-ohm Flat Twin Leads . . . . . . . . . . . . . 2.1
Antennas with 75-ohm Round Leads . . . . . . . . . . . . . . . . 2.2
Separate VHF and UHF Antennas. . . . . . . . . . . . . . . . . . . 2.2
Connecting Cable TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.2
Cable without a Cable Box . . . . . . . . . . . . . . . . . . . . . . . . 2.2
Connecting to a Cable Box that Descrambles
All Channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.2
Connecting to a Cable Box that Descrambles
Some Channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.3
Connecting a VCR. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.4
Connecting a Second VCR to Record from the TV . . . . . . 2.5
Connecting a Camcorder. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.5
Installing Batteries in the Remote Control . . . . . . . . . . . . . . . . . . . 2.6
Chapter 3: Using the Remote . . . . . . . . . . . 3.1
How to Use Your Universal Remote . . . . . . . . . . . . . . . . . . . . . . . . 3.1
Remote Control Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.2
Using the INPUT Button. . . . . . . . . . . . . . . . . . . . . . . . . . 3.3
Programming Your Universal Remote . . . . . . . . . . . . . . . . . . . . . . . 3.4
Testing the Remote . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.4
Programming the Remote to Control a VCR, Laserdisc
Player, Satellite Receiver or Cable Box. . . . . . . . . . . . . . 3.4
Programming the Remote to Control an RCA
Audio Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.5
Using the Remote to Control a Device . . . . . . . . . . . . . . . . . . . . . . 3.5
Modes of Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.5
Remote Control Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.6
15775750 TOC 5/10/01 10:09 AM Page 1

2 CONTENTS
CONTENTS
Chapter 4: Operation. . . . . . . . . . . . . . . . . . 4.1
Turning the TV On and Off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4.1
Plug & Play Feature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4.1
Viewing the Menus and On-Screen Displays. . . . . . . . . . . . . . . . . . 4.2
Viewing the Menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4.2
Viewing the Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4.3
Selecting a Menu Language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4.3
Memorizing the Channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4.4
Selecting the Video Signal-Source . . . . . . . . . . . . . . . . . . . 4.4
Storing Channels in Memory (Automatic Method) . . . . . 4.5
Adding and Erasing Channels (Manual Method) . . . . . . . 4.6
Labeling the Channels. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4.7
Setting the Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4.8
Customizing the Picture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4.9
Using Automatic Picture Settings . . . . . . . . . . . . . . . . . . . . . . . . . . 4.10
Customizing the Sound. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4.11
Using Automatic Sound Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . 4.12
Viewing the Signal from a VCR or Camcorder . . . . . . . . . . . . . . . . 4.13
Chapter 5: Special Features . . . . . . . . . . . . 5.1
Fine Tuning Channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5.1
Digital Noise Reduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5.2
Changing the Screen Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5.3
Setting the On/Off Timer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5.4
Setting the Sleep Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5.5
Sound Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5.6
Choosing a Multi-Channel Sound (MTS) Soundtrack . . . 5.6
Additional sound settings
(Turbo Sound, Surround, or Auto Volume) . . . . . . . . . . 5.7
Viewing Closed Captions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5.8
Viewing the Demonstration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5.9
Chapter 6: Other Information . . . . . . . . . . . 6.1
Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6.1
Cleaning and Maintaining Your TV. . . . . . . . . . . . . . . . . . . . . . . . . 6.2
Using Your TV in Another Country . . . . . . . . . . . . . . . . . . . . . . . . 6.2
Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6.2
15775750 TOC 5/10/01 10:09 AM Page 2

CHAPTER ONE: YOUR NEW TV 1.1
List of Features
Your TV was designed with the latest technology. This TV is a high-performance unit that
includes the following special features:
• Easy-to-use remote control
• Easy-to-use on-screen menu system
• Automatic timer to turn the TV on and off
• Adjustable picture and sound settings that can be stored in the TV’s memory
• Automatic channel tuning for up to 181 channels
• A special filter to reduce or eliminate reception problems
• Fine tuning control for the sharpest picture possible
• Built-in, dual channel speakers
• A special sleep timer
• Headphone jack for private listening
• 16:9 letter-box format available (depending on signal source)
NOTE: Illustrations are for representation only. Your product and on-screen displays might differ.
Chapter 1
YOUR NEW TV
Familiarizing Yourself with the TV
Front Panel Buttons
The buttons on the front panel control your TV’s basic features, including the on-screen menu.
To use the more advanced features, you must use the remote control.
MENU
Press to bring up the main menu.
VOL + and –
Press to increase or decrease the volume. Also used
to select items in the TV’s menu system.
CH ▼and ▲
Press to change channels. Also press to move up or
down in the TV’s menu system.
Remote Control Sensor
Aim the remote control towards this spot on the TV.
POWER & TIMER indicator
This indicator blinks ten times when you turn on the
TV. It also illuminates when the TIMER mode is set to
the “On”position after setting the clock and either the
On timer or Off timer. Even if the power is turned off,
this indicator stays lit. (Clock must be set before using
this function.)
POWER
Press to turn the TV on and off.
15775750.01 5/9/01 5:20 PM Page 1

Side Panel Jacks
Use the side panel jacks to connect an A/V component that is used only occasionally,
such as a camcorder or video game console. (For information on connecting
equipment, see pages 2.1 –2.6.)
HEADPHONE JACK
Connect a set of external headphones to this jack for private
listening.
VIDEO INPUT
Used to connect a video signal from a camcorder or a video
game.
AUDIO INPUTS
Used to connect the audio signals from a camcorder or a
video game.
1.2 CHAPTER ONE: YOUR NEW TV
YOUR NEW TV
Rear Panel Jacks
Use the rear panel jacks to connect an A/V component that will be connected
continuously, such as a VCR or DVD player. Because there are two sets of input jacks,
you can connect two different A/V components (i.e., a VCR and a DVD player, 2
VCRs, etc.).
For more information on connecting equipment, see pages 2.1 –2.6.
VIDEO INPUTS 1 and 2
Used to connect a video signal from an external
component (for example, VCRs, DVD players,
etc.).
AUDIO INPUTS 1 and 2
Used to connect audio signals from an external
component (for example, VCRs, DVD players,
etc.).
MONITOR OUT
Passes the signal being viewed on the television
to another component (for example, to a recoding
VCR.)
VHF/UHF
Connect to an antenna or cable TV system.
15775750.01 5/9/01 5:20 PM Page 2

CHAPTER TWO: INSTALLATION 2.1
Connecting VHF and UHF Antennas
If your antenna has a set of leads that
look like this, see “Antennas with
300-ohm Flat Twin Leads,” below.
If your antenna has one lead that looks
like this, see “Antennas with 75-ohm
Round Leads,” on page 2.2.
If you have two antennas, see “Separate
VHF and UHF Antennas,” on page 2.2.
NOTE: Illustrations are for representation only. Your product and on-screen displays might differ.
Chapter 2
INSTALLATION
Antennas with 300-ohm Flat Twin Leads
If you are using an off-air antenna (such as a roof antenna or “rabbit ears”) that has
300-ohm twin flat leads, follow the directions below.
1
Place the wires from the
twin leads under the
screws on the 300-75
ohm adaptor (not sup-
plied). Use a screwdriv-
er to tighten the screws.
2
Plug the adaptor into the
VHF/UHF terminal on the
bottom of the back
panel.
2
15775750.02 5/9/01 5:22 PM Page 1

2.2 CHAPTER TWO: INSTALLATION
Connecting Cable TV
To connect to a cable TV system, follow the instructions below.
Cable without a Cable Box
▼
1
Plug the incoming cable
into the VHF/UHF
antenna terminal on
back of the TV.
Because this TV is
cable-ready, you do not need a
cable box to view unscrambled cable
channels.
Connecting to a Cable Box that Descrambles All Channels
▼
1
Find the cable that is
connected to the
ANTENNA OUT terminal
on your cable box.
This terminal might be labeled
“ANT OUT,”“VHF OUT,”or simply,
“OUT.”
2
Connect the other end
of this cable to the
VHF/UHF antenna
terminal on the back of
the TV.
INSTALLATION
Separate VHF and UHF Antennas
If you have two separate antennas for your TV (one VHF and one UHF), you must
combine the two antenna signals before connecting the antennas to the TV. This
procedure requires a an optional combiner-adaptor (available at most electronics stores).
Antennas with 75-ohm Round Leads
1
Plug the antenna lead
into the VHF/UHF
terminal on the bottom
of the back panel.
15775750.02 5/9/01 5:22 PM Page 2

CHAPTER TWO: INSTALLATION 2.3
INSTALLATION
Connecting to a Cable Box that Descrambles Some Channels
If your cable box descrambles only some channels (such as premium channels), follow
the instructions below. You will need a two-way splitter, an RF (A/B) switch, and four
lengths of coaxial cable. (These items are available at most electronics stores.)
▼
1
Find and disconnect the
cable that is connected
to the ANTENNA IN
terminal on your
cable box.
This terminal might be labeled
“ANT IN,”“VHF IN,”or simply,
“IN.”
2
Connect this cable to a
two-way splitter.
3
Connect a coaxial cable
between an OUTPUT
terminal on the splitter
and the IN terminal on
the cable box.
4
Connect a coaxial cable
between the ANTENNA
OUT terminal on the cable
box and the B–IN terminal
on the A/B switch.
5
Connect another cable
between the other OUT
terminal on the splitter
and the A–IN terminal
on the RF (A/B) switch.
6
Connect the last coaxial
cable between the OUT
terminal on the RF (A/B)
switch and the VHF/UHF
terminal on the rear of
the TV.
After you’ve made this connection, set the A/B switch to the “A”position for normal viewing. Set the
A/B switch to the “B”position to view scrambled channels. (When you set the A/B switch to “B,”
you will need to tune your TV to the cable box’s output channel, which is usually channel 3 or 4.)
15775750.02 5/9/01 5:22 PM Page 3

Connecting a VCR
These instructions assume that you have already connected your TV to an antenna or a
cable TV system (according to the instructions on pages 2.1-2.3). Skip step 1if you have
not yet connected to an antenna or a cable system.
1
Unplug the cable or
antenna from the back
of the TV.
INSTALLATION
2
Connect the cable or
antenna to the
ANTENNA IN terminal
on the back of the VCR.
3
Connect a coaxial cable
between the ANTENNA
OUT terminal on the
VCR and the antenna
terminal on the TV.
4
Connect a set of audio
cables between the
AUDIO OUT jacks on the
VCR and the AUDIO
jacks on the TV.
5
Connect a video cable
between the VIDEO OUT
jack on the VCR and the
VIDEO jack on the TV.
Follow the instructions in “Viewing a VCR or Camcorder Tape”to view your VCR
tape.
A coaxial cable is usually included with a VCR. (If not, check your local electronics
store).
2.4 CHAPTER TWO: INSTALLATION
15775750.02 5/9/01 5:22 PM Page 4

Connecting a Second VCR to Record from the TV
Your TV can send out signals of its picture and sound to be recorded by a second VCR.
To do this, connect your second VCR as follows:
1
Connect a set of audio
cables between the
AUDIO OUT jacks on the
TV and the AUDIO IN
jacks on the VCR.
2
Connect a video cable
between the VIDEO OUT
jack on the TV and the
VIDEO IN jack on the
VCR.
Refer to your VCR’s instructions for more information about how to record using this
kind of connection.
The VCR input jacks might be either on the front or on back of the VCR.
INSTALLATION
TV Side Panel
Y-Connector
Audio
Cable
Camcorder
Output Jacks
2
Connect an audio cable
between the AUDIO
OUTPUT jack on the
camcorder and the
AUDIO terminals on the
side of the TV.
3
Connect a video cable
between the VIDEO
OUTPUT jack on the
camcorder and the
VIDEO terminal on the
side of the TV.
1
Locate the A/V output
jacks on the camcorder.
They are usually found
on the side or back of
the camcorder.
Connecting a Camcorder
The side panel jacks on your TV make it easy to connect a camcorder to your TV.
The audio-video cables shown here are usually included with a Camcorder. (If not, check your
local electronics store.) If your camcorder is stereo, you need to connect a set of two cables.
TV Side Panel
Video Cable
Camcorder
Output Jacks
CHAPTER TWO: INSTALLATION 2.5
15775750.02 5/9/01 5:22 PM Page 5

2.6 CHAPTER TWO: INSTALLATION
INSTALLATION
3
Replace the cover.
2
Insert fresh batteries.
Make sure that the
polarities (+ and -) are
aligned correctly.
Installing Batteries in the Remote Control
1
Remove the battery
compartment cover
from the back of the
remote.
15775750.02 5/9/01 5:22 PM Page 6

CHAPTER THREE: USING THE REMOTE 3.1
Chapter 3
USING THE REMOTE
How to Use Your Universal Remote
This section defines the buttons of the remote and how to program it to control other
components.
The universal remote can be programmed to control most brands of remote control-
lable VCRs, satellite receivers, Laserdisc players and cable boxes. If you have an RCA,
GE, or PROSCAN component, you probably don’t need to program it at all.
Because this universal remote can control several different components (Laserdisc
player, VCR, Cable Box, etc.), it uses operational modes triggered by the component
buttons. For example if you want the remote to control the TV, you would press the
TV button to put the remote into TV mode before you could control the TV.
NOTE: Illustrations are for representation only. Your product and on-screen
displays might differ.
15775750.03 5/9/01 5:24 PM Page 1

3.2 CHAPTER THREE: USING THE REMOTE
POWER When in TV mode, turns TV on and off. If in another
device mode (VCR, VCR2•LD, Satellite, etc.) and programmed, will
turn the device on and off.
VCR1 Puts the remote in VCR mode.
VCR2•LD Puts the remote in VCR2 mode. VCR2•LD can only be
programmed for one component: either a VCR or Laserdisc player.
SAT•CABLE Puts the remote in SAT•CABLE mode.
AUDIO Puts the remote in Audio mode.
TV Turns on the TV and puts the remote in TV mode. Also displays
channel information.
REW, PLAY, FF, REC, STOP, PAUSE If programmed, provides
transport control for some remote-controllable VCRs, Laserdisc play-
ers, tape decks, and CD players.
DISPLAY Brings up channel information. Also clears menus from
the screen.
SKIP Press twice before changing channels and the TV will wait 30
seconds before returning you to the original channel. Press repeated-
ly to add more time (each press adds another 30 seconds).
CHAN ▲or CHAN ▼Scans up or down through the current
channel list. Press once to change the channel up or down; press and
hold to continue changing channels.
VOL < or VOL > Decreases or increases the TV’s volume.
MUTE Reduces the TV’s volume to its minimum level. Press again
to restore the volume.
PREV CH Returns you to the previous channel.
INPUT ANTENNA
SKIP
PREV CH
REC STOP PAUSE
PLAYREW FF
CLEAR RESET
MOVE
MENU
PROG
•
MUTE
DISPLAY
123
456
789
0
P
O
W
E
R
V
C
R
1
S
A
T
•
C
A
B
L
E
T
V
V
C
R
2
•
L
D
A
U
D
I
O
C
H
A
N
C
H
A
N
V
O
L
V
O
L
USING THE REMOTE
15775750.03 5/9/01 5:24 PM Page 2

CHAPTER THREE : USING THE REMOTE 3.3
USING THE REMOTE
(0-9) Number Buttons Enters channel numbers and time settings
directly though the remote control. To enter a two-digit channel,
press the two digits. To enter a three-digit channel, press and hold
the first digit, then add the second two. Example: to tune to channel
123, press and hold 1, press 2, then press 3.
INPUT In TV mode, press to toggle through the available input
sources (AV1, AV2 and the current channel).
ANTENNA Functions as TV/VCR button in VCR mode and
TV/receiver button in SAT•CABLE mode.
CLEAR Removes any menu or display from the screen and returns
you to TV viewing. With RCA, GE and PROSCAN VCRs, this button
also clears items from the VCR clock and timer programs.
MENU•PROG Brings up the Main menu and selects highlighted
items. When in VCR mode, it functions as a PROGRAM button for
RCA, GE and proscan VCRs.
RESET Resets the settings in a menu.
MOVE (Arrows) Used to point to different items in the menu sys-
tem. Also used to adjust the menu controls.
Using the INPUT Button
Use the INPUT button to toggle through the available input sources
(AV1, AV2 and the current channel) and view the component you
have connected to the TV.
1. Press TV to place the remote in TV mode. Make sure that the
component you want to view is turned on.
2. Press INPUT to tune to the available input source and view the
component.
3. Press INPUT again to tune back to the channel you were previ-
ously watching.
15775750.03 5/9/01 5:24 PM Page 3

3.4 CHAPTER THREE: USING THE REMOTE
USING THE REMOTE
Programming your Universal Remote
The universal remote can be programmed to control most brands of remote controllable
VCRs, satellite receivers, Laserdisc players and cable boxes. If you have an RCA, GE, or
PROSCAN component, you probably don’t need to program it at all.
Testing the Remote
To determine whether the universal remote needs to be programmed, turn a device on, such
as a VCR, point the remote at the VCR, and press the VCR1 button. Then press POWER or
CHAN ▲(channel up) or CHAN ▼(channel down) to see if the VCR responds to the
remote commands. If not, the remote needs to be programmed.
Programming the Remote to Control a VCR, Laserdisc player,
Satellite Receiver or Cable Box
Follow these steps to program your universal remote to control a VCR, Laserdisc player,
Satellite Receiver or Cable Box:
1. Turn on the component to be programmed.
2. Look up the brand and code number(s) for the component on the code list on the last
page of this section, Using the Remote.
3. Press and hold the button on the remote you want to program.
4. Enter the code from the code list.
5. Release button, and then press POWER to see if the component responds to the
remote commands. If it doesn’t, try pressing the component button and then POWER
again.
6. If you get no response, repeat these steps using the next code listed for your brand,
until the component responds to the remote commands.
15775750.03 5/9/01 5:24 PM Page 4

CHAPTER THREE : USING THE REMOTE 3.5
USING THE REMOTE
Programming the Remote to Control an RCA Audio Device:
Your remote controls only RCA audio equipment such as an audio receiver or amplifier—
it does not control other brands of audio equipment. Also, the remote may need to be pro-
grammed for your equipment. This remote may not operate all of the components listed
at the end of this section. Use the codes at the end of this section or on the sheet packed
in with your remote.
1. Turn on the component to be programmed.
2. Look up your brand and its code number(s) on the code list.
3. Press and hold the AUDIO button.
4. Enter the code from the code list.
5. Release the AUDIO button and press POWER or CHAN ▲(channel up) or CHAN ▼
(channel down) to see if the audio device responds to the remote commands.
Using the Remote to Control a Device
Once the remote has been programmed successfully, you are ready to use it to control
your devices.
To operate the device:
1. Press the device button (TV, VCR1, VCR2•LD, SAT•CABLE, or AUDIO) to set the
remote to control the device.
2. Press POWER to turn the device ON or OFF.
3. Use the remote buttons that apply to that device.
Modes of Operation
Because this universal remote can control several different components (Laserdisc player,
VCR, Cable Box, etc.) it uses operational modes triggered by the component buttons. For
example if you want the remote to control the TV, you would press the TV button to put
the remote into TV mode before you could control the TV.
15775750.03 5/9/01 5:24 PM Page 5

3.6 CHAPTER THREE : USING THE REMOTE
REMOTE CONTROL CODES
VCR
Admiral . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2131
Adventura . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2026
Aiko . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2027
Aiwa . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2002, 2026
Akai . . . . . . . . . .2003, 2004, 2005, 2007, 2008, 2111,2112, 2113
American High . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2021
Asha . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2013
Audio Dynamics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2009, 2010
Audiovox . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2014
Bell & Howell . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2011
Beaumark . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2013
Broksonic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2012, 2025
Calix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2014
Candle . . . . . . . . . . . . .2013, 2014, 2015, 2016, 2017, 2018, 2019
Canon . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2021, 2022, 2114
Capehart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2020, 2110
Carver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2062
CCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2027, 2061
Citizen . . . . . . . . .2013, 2014, 2015, 2016, 2017, 2018,2019,2027
Colortyme . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2009
Colt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2061
Craig . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2013, 2014, 2023, 2061
Curtis-Mathes . . . . . . . . . . . . . . . . . . . . . .2000, 2002, 2009, 2013,
2016, 2018, 2021, 2022, 2024, 2115
Cybernex . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2013
Daewoo . . . . . . .2015, 2017, 2019,2025, 2026, 2027, 2028, 2110
Daytron . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2110
Dbx . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2009, 2010
Dimensia . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2000
Dynatech . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2002, 2026
Electrohome . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2014, 2029
Electrophonic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2014
Emerson . . .2002, 2012,2014,2015, 2021, 2024, 2025,2026,2029,
2030, 2032, 2033, 2034, 2035, 2036, 2037, 2038, 2039, 2040,
2041, 2042, 2044, 2045, 2047, 2065, 2105, 2113, 2116, 2117,
2130
Fisher . . . . . . . . .2011, 2023, 2048, 2049, 2050, 2051, 2052,2118
Fuji . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2021, 2119
Funai . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2002, 2026
Garrard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2026
GE . . . . . . . . . . .2000, 2001, 2013, 2021, 2022, 2053, 2115, 2120
Goldstar . . . . . . . . . . . . . . . . . . . . . .2009, 2014, 2018, 2054, 2121
Gradiente . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2026
Harley Davidson . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2026
Harman Kardon . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2009
Harwood . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2061
Headquarter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2011
Hitachi . . . . . . . .2002, 2055, 2056, 2057, 2107, 2111, 2120, 2122
HI-Q . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2023
Instant Replay . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2021
JCL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2021
JC Penney . . . .2009, 2010, 2011, 2013, 2014, 2021, 2022, 2055,
2056, 2058, 2059, 2060, 2107, 2118
Jensen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2055, 2056, 2111
JVC . . . . . . . . . . . . . . .2009, 2010, 2011, 2018, 2058, 2111, 2123
Kenwood . . . . . .2009, 2010, 2011, 2016, 2018, 2058, 2111,2123
KLH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2061
Kodak . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2014, 2021
Lloyd . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2002, 2026
Logik . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2061
LXI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2014
Magnavox . . . . . . . . . .2021, 2022, 2062, 2063, 2104, 2108, 2124
Magnin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2013
Marantz . . .2009, 2010, 2011, 2016, 2018, 2021, 2058, 2062,2064
Marta . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2014
Masushita . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2021
MEI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2021
Memorex .2002, 2011, 2013, 2014, 2021, 2023, 2026, 2104, 2131
MGA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2029, 2065, 2113
MGN Technology . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2013
Midland . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2053
Minolta . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2055, 2056, 2107
Mitsubishi . . . . . . . . . .2029, 2055, 2056, 2065, 2066, 2067, 2069,
2070, 2071, 2072, 2073, 2074, 2106, 2113, 2123
Montgomery Ward . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2075, 2131
Motorola . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2021,2131
MTC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2002, 2013, 2026
Multitech . . . . . . . . . . . . . . . .2002, 2013, 2016, 2026, 2053, 2061
NEC . . . . . . . . . . . . . .2009, 2010, 2011, 2016, 2018, 2058, 2064,
2076, 2078, 2079, 2111, 2123
Nikko . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2014
Noblex . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2013
Olympus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2021
Optimus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2014, 2131
Optonica . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2096
Orion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2035
Panasonic . . . . . . . . . . . . . . .2021, 2022, 2109, 2125, 2126, 2127
Pentax . . . . . . . . . . . . . . . . . . . . . . .2016, 2055, 2056, 2107, 2120
Pentex Research . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2018
Philco . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2021, 2022, 2062, 2063
Philips . . . . . . . . . . . . . . . . . . . . . . . . . . . .2021, 2062, 2096, 2124
Pilot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2014
Pioneer . . . . . . . . . . . . . . . . . . . . . .2010, 2055, 2080, 2081, 2123
Portland . . . . . . . . . . . . . . . . . . . . . . . . . . .2016, 2017, 2019, 2110
PROSCAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2000, 2001
Protec . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2061
Pulsar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2104
Quarter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2011
Quartz . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2011
Quasar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2021, 2022, 2125
RCA . . . . . . . . .2000, 2001, 2003, 2013, 2021, 2055, 2056, 2082,
2083, 2084,2085, 2086,2087,2088, 2089, 2090, 2091,
2107, 2115, 2120, 2125
Radioshack/Realistic . . . . . . . . . . . . . . . . . .2002, 2011, 2013, 2014
2021, 2022, 2023, 2026, 2029, 2049, 2050, 2096, 2131
Radix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2014
Randex . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2014
Ricoh . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2128
Runco . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2104
Samsung . . . . . . . . . . . . . . . .2005, 2013, 2015, 2033, 2053, 2112
Sanky . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2131, 2104
Sansui . . . . . . . . . . . . . . . . . . . . . . . . . . . .2010, 2092, 2111, 2123
Sanyo . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2011, 2013, 2023
Scott . . . .2012, 2015, 2025, 2032, 2035, 2038, 2065, 2093, 2116
Sears . . . . . . . . . . . . . . . . . . . . . . .2011, 2014, 2021, 2023, 2048,
2049, 2050, 2051, 2055, 2056, 2107, 2118
Sharp . . . . . . . . . . . . . .2002, 2017, 2029, 2094, 2095, 2096, 2131
Shintom . . . . . . . . . . . . . . . . . . . . . . . . . . .2004, 2056, 2061, 2098
Shogun . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2013
Signature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2002, 2131
Singer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2021, 2061, 2128
Sony . . . . . . . . . . . . . . . . . . .2002, 2004, 2098, 2099, 2119, 2128
STS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2021, 2107
Sylvania . . . . . . .2002, 2021, 2022, 2026, 2062, 2063, 2065, 2124
Symphonic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2002, 2026
Tandy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2002, 2011
Tashiko . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2014
Tatung . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2058, 2111
TEAC . . . . . . . . . . . . . . . . . . . . . . . .2002, 2026, 2058, 2085, 2111
Technics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2021, 2109
Teknika . . . . . . . . . . . . . . . . . .2002, 2014, 2021, 2026, 2100, 2129
TMK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2013, 2024, 2047
Toshiba . . . . . . . . . . . .2015, 2049, 2051, 2055, 2065, 2093, 2116
ToteVision . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2013, 2014
Unitech . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2013
Vector Research . . . . . . . . . . . . . . . . . . . . .2009, 2010, 2015, 2016
Victor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2010
Video Concepts . . . . . . . . . . . . . . . .2009, 2010, 2015, 2016, 2113
Videosonic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2013
Wards . . . . . . . . . . . ., 2002, 2013, 2014, 2015, 2021, 2023, 2026,
2029, 2055, 2056, 2061, 2096, 2101, 2102, 2103,
2107, 2116, 2131
XR-1000 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2021, 2026, 2061
Yamaha . . . . . . . . . . . . . . . . .2009, 2010, 2011, 2018, 2058, 2111
Zenith . . . . . . . . . . . . . . . . . . . . . . . .2004, 2098, 2104, 2119, 2128
Cable Boxes
ABC . . . . . . . . . . . . . . .5002, 5003, 5004, 5005, 5006, 5007, 5053
Antronix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5008, 5009
Archer . . . . . . . . . . . . . . . . . . . . . . . . . . . .5008, 5009, 5010, 5011
Cabletenna . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5008
Cableview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5008
Century . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5011
Citizen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5011
Colour Voice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5012, 5013
Comtronics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5014, 5015
Contec . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5016
Eastern . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5017
Garrard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5011
GC Electronics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5009
Gemini . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5018, 5019, 5049
General Instrument . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5003, 5053
Hamlin . . . . . . . . . . . . . . . . . . . . . . .5020, 5021, 5022, 5035, 5045
Hitachi . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5003
Hytex . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5002
Jasco . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5011
Jerrold . . . . . . . .5003, 5005, 5007,5018, 5023, 5024, 5046, 5053
Magnavox . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5025
Memorex . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5026
Movie Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5002, 5027, 5028
NSC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5002, 5027, 5028
Oak . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5002,5016, 5029
Panasonic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5048, 5052
Paragon . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5026
Philips . . . . . . . .5011, 5012, 5013, 5019, 5025, 5030, 5031, 5032
Pioneer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5033, 5034
Pulsar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5026
RCA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5047, 5049, 5052
Realistic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5009, 5049
Regal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5022, 5035
Regency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5017
Rembrandt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5003
Runco . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5026
Samsung . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5014, 5034
Scientific Atlanta . . . . . . . . . . . . . . . . . . . . .5006, 5036, 5037, 5038
Signal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5014, 5018
Signature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5003
SL Marx . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5014
Sprucer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5052
Starcom . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5007, 5018, 5053
Stargate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5014, 5018
Starquest . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5018
Tandy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5040
Teleview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5014
Tocom . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5004, 5023, 5041
Toshiba . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5026
Tusa . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5018
TV86 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5027
Unika . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5008, 5009, 5011
United Artists . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5002
United Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5053
Universal . . . . . . . . . . . . . . . . . . . . . . . . . .5008, 5009, 5010, 5011
Videoway . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5044
Viewstar . . . . . . . . . . . . . . . . . . . . . . . . . . .5015, 5025, 5027, 5040
Zenith . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5026, 5050, 5051
Satellite Receivers
Chapparal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5056, 5057
Drake . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5058, 5059
GE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5000, 5001
General Instuments . . . . . . . . . . . . . . . . . . . . . . . .5060, 5061, 5062
Panasonic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5075
Primestar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5076
PROSCAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5000, 5001
RCA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5000, 5001
Realistic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5063
Sony . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5072
STS1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5064
STS2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5065
STS3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5066
STS4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5067
Toshiba . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5068, 5073
Uniden . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5069
Audio
(For RCA and Dimensia brands only)
AM/FM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4003
Aux . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4004
Phono . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4005
CD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4007
Tape . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4006
15775750.03 5/9/01 5:24 PM Page 6
