USER’S MANUAL
2.0 MULTIMEDIA
SPEAKER SYSTEM
S-2020

1
ENG
User’s manual S-2020
Technical support: www.real-el.com
Congratulations on your purchase of the REAL-EL speaker system!
COPYRIGHT
© 2019. ENEL GROUP OU.
This Manual and information contained in are copyrighted. All rights reserved.
TRADEMARKS
All trademarks are the property of their legal holders.
1. BUYER RECOMMENDATIONS
•Unpack the device carefully. Make sure there are no accessories left in the box. Check up the
device for damage; if the product was damaged during transportation, address the firm, which
carried out the delivery; if the product functions incorrectly, address the dealer at once.
•Check up the package contents and availability of the warranty card. Make sure the warranty card
has a shop stamp, a legible signature or the seller’s stamp and purchase date, and the goods
number corresponds to that in the warranty card. Remember: in case of warranty card loss or
discrepancy of numbers you forfeit the right for warranty repairs.
•Do not switch on the speaker system immediately after you bring it into a room from environment
with negative temperature! After unpacking, the speaker system should be kept in conditions of
room temperature for at least 4 hours.
•Before installing and using the speaker system, read this Manual carefully and keep it for future
reference.
2. PACKAGE CONTENTS
• Active speaker - 1 pc
• Passive speaker - 1 pc
• Power supply unit - 1 pc
• Remote control (RC) - 1 pc
• FM antenna - 1 pc
• Signal cable - 2 pcs
• Acoustic connection cable - 1 pc
• User manual - 1 pc
• Warranty card - 1 pc

Technical support: www.real-el.com
2
ENG
User’s manual S-2020
3. SAFETY PRECAUTIONS
• Do not open Multimedia Speaker System (MSS) and do not perform repairs by yourself. Service
and repairs should be performed by qualified specialists in an authorized service center only. The list
of authorized service centers is available at www.real-el.com
• Do not put foreign objects inside the holes of the MSS.
• Protect the MSS from high humidity, water and dust.
• Protect the MSS from heating: do not place it closer heat source. Do not expose it to direct sunlight.
• Do not place any open flame sources on or close to MSS.
• Do not use any chemical agents for cleaning. Clean it with dry soft cloth only.
• In case of MSS does not work properly, power cable must be disconnected. Please contact place
of purchase or service center.
4. TECHNICAL DESCRIPTION AND CONNECTION
S-2020 Multimedia Speaker System (MSS) is designed to play music and sound games,
movies, etc. The MSS tnabling to connect to virtual to any audio source (CD/DVD-player, TV,
phone, PC, etc.) without using an additional power amplifier. The MSS has a built-in FM radio,
Bluetooth module and audio files player USB flash.
Special features
•FM radio
•Bluetooth, USB flash
•KARAOKE mode with 2 Mic inputs and Echo adjustment
•Powerful and high-quality sound with deep bass
•AUX for use with PC, TV and other sources
•Full function remote control
Control panel
aVolume contro -
bDisplay
cMode (Bluetooth, USB, FM, AUX)
dIn USB mode play / pause. In FM mode, press briefly to search and save all stations
Long press to delete the current saved station.
eIn USB mode, the previous track. In FM mode, press shortly to move to the previous saved station
Long press - to save the current station to the beginning of the list of stations.
fIn USB mode, the next track. In FM mode, press briefly to move to the next stored station
Long press - to save the current station to the end of the list of stations.
gVolume contro +
hBass level knob
iTreble level knob
jEcho level knob
kMIC VOL -/+
lMic input 1
mUSB port
nMic input 2

Technical support: www.real-el.com
3
ENG
User’s manual S-2020
oPower ON/OFF
pPower cord
qSpeaker output:
satellite connection
rAUX: line input jacks
sFM ANT:
FM radio antenna input
tLine-in: AUX input
op
q
rst
l m n
a
h i j k
cb d e f g

Technical support: www.real-el.com
4
ENG
User’s manual S-2020
a b
c
dh
i
j
k
l
e
f
g
MODE
SEEK
VOLUME
SEEK
EQ
OFF
Remote control:
aON/OFF
bMode (Bluetooth, USB, FM, AUX)
cFM mode, briefly press to change the range and manual setting.
Long press for automatic station search.
dIn USB mode, the previous track. In FM mode, press shortly to
move to the previous saved station. Long press - to save the current
station to the beginning of the list of stations.
eIn FM mode, press briefly to change the range and manual setting.
Long press for automatic station search.
fIn USB and Bluetooth mode selection one of the 6 equalizer
settings.
gVolume level control buttons
hIn USB mode, the next track. In FM mode, press briefly to move to
the next stored station. Long press - to save the current station to
the end of the list of stations.
i In USB mode play / pause. In FM mode, press briefly to search
and save all stations. Long press to delete the current saved station.
jIn USB and Bluetooth mode selection one of the 6 equalizer
settings.
kSwitching offthe equalizer
lSound on/offbutton

Technical support: www.real-el.com
5
ENG
User’s manual S-2020
* You might have to enter “0000” code to connect some models via Bluetooth.
** If an item has been already registered in the device list of sources, then the second search mode activation is
not needed. Choose only the item name and the “connect” command on the source.
5. OPERATION MODES
Bluetooth mode
• Bluetooth mode requires connection of MMS with a signal source. For this purpose select the
Bluetooth mode using MODE button con the front panel of the subwoofer or MODE button b
on the remote control. After 2-3 seconds the speaker system starts the search mode.
• It is necessary to select the search mode of devices with Bluetooth on a signal source (phone,
notebook, smartphone, etc.). “S-2020” device will be displayed on the screen which should be
connected to*.
• After a successful connection, the loudspeaker will sound a signal.**.
FM mode
• Turn the FM mode with the MODE button repeatedly until the frequency of the radio station
appears on the display.
• In the playback mode, briefly press the " " button to automatically search FM stations and save
them automatically. Press the " " or " " buttons to switch between stations.
Playback mode
• Insert USB flash drive into the corresponding slot, the audio track will be played automatically. In
the playback mode, briefly press the " " or " " button to select the desired tracks.
• Press the " " button to play or pause.
KARAOKE Mode
Karaoke is always active with any audio source (AUX, Bluetooth, FM etc.)
To start using Karaoke mode need to connect microphones and set up volume and echo level
LINE IN/AUX mode
• For compatible music devices, use an audio cable with the 3.5 mm mini jack or 2RCA. Connect the
cable to the audio output of any audio source with a 3.5 mm mini jack or 2RCA. Then press the
"MODE" button to switch to mode.
Note: You must turn off the power button "OFF / ON." If the system is not used for a long time.

Technical support: www.real-el.com
6
ENG
User’s manual S-2020
7. SPECIFICATION
Parameter, measurement unit
Output power (RMS), W
Frequency range, Hz
Speaker diameter, mm:
tweeter
middle range
passive radiator
woofer
Connection types
Voltage supply, V/Hz
Bluetooth operation distance, m
Case material
Dimensions of the product, mm
Weight, kg
Value
80 (2 × 40)
20-20000
Ø 25
Ø101
Ø101
Ø 203
USB flash / Aux / Bluetooth
~ 230/50
up to 10
wooden (MDF)
165 x 313 x 822
15
Notes:
• Technical specifications given in this table are supplemental information and cannot give
occasion to claims.
• Technical specifications and package contents are subject to change without notice due to
the improvement of REAL-EL production.
If none of the above methods can solve the problem, please seek professional advice at your
nearest service center. Never attempt to repair the product yourself.
Problem
The MSS does not
turn on.
No sound or the
sound is too quiet.
Distortion of sound.
The remote control
is not working.
Cause
The MSS isn’t connected to a mains
outlet.
The power switch is off.
Volume level is set at minimum value.
Improperly connected audio source.
Large amplitude of the input signal.
The batteries are discharged.
Solution
Check the connection.
Turn on the switch.
Adjust the volume control knob.
Connect the audio sources correctly.
Turn down the source volume
and the MSS volume.
Replace the batteries with new ones.
6. TROUBLESHOOTING

Models: S-2020
Manufacturer: ENEL GROUP OU, Harju maakond, Rae vald, Jüri alevik, Aruküla tee 55a, 75301, Estonia.
® Registered Trademark of ENEL GROUP OU. Estonia.
