Assembly Manual
RT-590

2
WARNING
ONLY
DO NOT STORE OR USE COMBUSTIBLE MATERIALS
IN OR NEAR THIS APPLIANCE.
TO PREVENT INJURY, NEVER ATTEMPT TO MOVE
GRILL WHILE HOT OR WITHOUT ASSISTANCE.
NEVER STORE ANY GRILL IN A SMALL SPACE OR
PLACE IN A VEHICLE UNLESS COMPLETELY COOL
AND FIRE IS VERIFIED AS EXTINGUISHED.
LEAVE A MINIMUM OF 60” CIRCUMFERENCE
BETWEEN GRILL, DECKS, HOUSES OR ANY
COMBUSTIBLE MATERIALS.
USE ON LEVEL GROUND AWAY FROM
OVERHANGING ROOFS OR LEAVES.
FOR OUTDOOR USE

3
IMPORTANT SAFETY INFORMATION
Warning: Read all safety information before operating grill.
For outdoor use only. Do not use in any enclosed area. Use on level surface, away
from overhanging easements.
Keep grill 60” or more from any combustible surface.
Do not put anything flammable on the bottom shelf under the grill.
Never plug in your RT-590 without the service access grate underneath your
controller installed.
Never put your grill in a vehicle without first ensuring that it is completely cool and
that no hot embers, pellets, or ashes remain in the firepot or auger.
Occasionally, your RT-590 should be checked for fire pot obstructions to make
sure proper airflow is maintained. See cleaning instructions in this manual for
proper procedures.
Your RT-590 gets very hot; keep young children and animals away while in use.
Use extreme caution when cooking at high temperatures.
Use heat-resistant barbecue mitts or gloves when operating this unit. Long
handled, non-plastic utensils are also recommended.
Do not touch cooking chamber or attempt to move your RT-590 while operating
or while the grill is hot. Make sure the fire is completely out and that the grill is
completely cool before transporting the grill. Before covering your grill, make sure
that the grill has cooled completely.
Never put your hand in the pellet hopper or attempt to service any part of your
RT-590 while your grill is plugged in.

4
Congratulations on the purchase of your new
RT-590 Wood Pellet Grill. With proper care and maintenance, your grill
will provide you years of trouble-free operation. Please review the following
information carefully for useful tips and information that will help you utilize
your grill’s extensive features and benefits.
To see our favorite recipes and cooking tips, visit recteq.com. As you become
familiar with your recteq, you will find that indoor cooking becomes the
exception and not the rule in your house. With the ability to easily cook foods
to standards that meet or exceed restaurant quality, you will find yourself
not wanting to go to restaurants and pay for food that does not live up to the
recteq standard of flavor. Also, don’t be alarmed when your neighbors call
and ask if you will ‘recteq’ some meat for them...This is a common occurrence
among recteq owners.
We want you to join the vibrant and growing community of recteq owners.
Whether you want to contribute your own tips and recipes, learn from others,
or a bit of both, please jump right in. You now have an incredible tool for
cooking. Let’s see how you use it!
Thank you for choosing recteq.
Ray Carnes & Ron Cundy
Co-Founders, recteq, LLC
RT-590
Assembly Manual and Users Guide

5
RT-590 Contents
1. Grill Body
2. Caster Wheel Legs x2
3. Fixed Wheel Legs x2
4. Bottom Shelf
5. Bull Horn Handles x2
6. Pull Bar Handle
7. Heat Deflector
8. Drip Pan
9. Cooking Grates x2
10. Drip Bucket
11. Temperature Probes x2 (not pictured)
12. Hardware Packet (not pictured)
1
2
34
5
6
7
9
10
8

6
RT-590 Assembly
Start with grill on its backside.
On the left side, attach legs with fixed wheels (3) with wheels facing outward to the front of the grill.
Then on the right side, attach caster wheel legs (2).
Hand tighten all four legs using bolt assembly order pictured below.
Step 1 Unpack and Prepare for Assembly
With assistance, remove all items from inside grill body and lay grill body on its back.
Tip: Flatten the cardboard box out and lay everything on it. This serves as a good working area and it
helps prevent the grill from getting scratched or damaged during installation.
Step 2 Flip Grill and Attach Legs

7
Install Bottom Shelf
Step 3
Align shelf (4) between grill legs and
attach using provided hardware.
Once bottom shelf is installed, fully
tighten all hardware.
Install Pull Bar Handle
Step 4
Attach the pull bar handle (6) using the hardware provided in the handle.
The beauty ring stays attached to the pull bar handle.

8
Step 5 Bull Horn Handle Assembly
Attach bull horn handles (5)using the provided hardware inside handles.
Once handles are installed, stand grill upright. You will need two people as the grill is
VERY HEAVY.

9
Step 6 Heat Deflector, Drip Pan, Cooking Grates, and
Drip Bucket
Open the lid of the RT-590. Install the heat deflector (7) over the Air Box Assembly with the small
notches in the heat deflector over the small tabs located at the inside front and the large cutout to
the rear of the grill body (1). Install the drip pan (8) with the pan sloping down to the right of
the grill making sure to leave equal gaps between the pan and the front and back of the chamber
walls. Install the cooking grates (9) by resting them flat on the front and back ledges. Install the drip
bucket (10) by clipping the handle to the hook on the spout.
Note: See last image for proper placement of drip pan.

10
Initial Setup Procedure
Before cooking for the first time, we recommend that you remove the cooking grate and wash it with
mild soap and water. Fill your hopper at least halfway up and place a small handful of pellets into
the fire pot, enough to cover the igniter. Do not over fill the fire pot. Reinstall the grate, set grill to
400°F and once the grill reaches 400°F, let run with the lid down for 1 hour. This will provide a final
cure and remove any residue that may have accumulated during manufacturing and shipping. After
this initial burn, your auger and fire pot are primed, and your grill is ready for cooking.
Operating Your Grill
Power Button:
Press power button to turn grill on and adjust temperature knob to desired temperature.
• Turning the grill ON activates the automatic startup mode and illuminates the digital readout.
• If your grill fails to light itself within 30 minutes of startup, the Smart Grill Technology™ processor
will turn the grill off and display ER-2 on the screen.
• Pressing the power button again activates the shut down mode of your grill. If grill’s actual
temperature is below 160°F, pressing the power button will simply turn the grill off.
• When the power button is used to shut down your grill, the Smart Grill Technology™ processor
will stop adding pellets to the fire pot and the fan will continue running to completely burn the
pellets remaining in the fire pot. During this cooling process, the display screen will display FAN.
Shortly thereafter, the display screen will change to display AUG - this will push out any embers
left in the auger tube.
WIFI: Download recteq app from Apple App Store for Apple devices or Google Play, and follow
the directions on app.
WIFI Troubleshooting: Go to recteq.com/wifi-setup
Temperature Control Knob: Turn knob to select computer maintained temperature in 5°
increments. (Range: 200°F - 500°F)
Additional Temperature settings: LO and FUL
LO: LO will display as actual temperature when knob is turned counterclockwise beyond 200°F and
Xtreme Smoke will be activated. The grill will feed pellets to the fire at the minimum feed rate (lowest
rate possible to maintain a reliable fire). This will produce the most smoke and achieve the lowest
temperature possible, given environmental conditions/type of pellets used.
FUL: FUL will display as actual temperature when knob is turned clockwise beyond 500°F. Grill will
feed pellets to the fire at 100% of auger capacity. This will produce the highest temperature possible,
given environmental conditions/type of pellets used.

11
1
65
2
0
3
0
4
0
Operating Your Grill
Settings Button: Press and hold the setting button to access the adjustable parameters menu. Short presses
of the settings button will scroll through the adjustable parameters. Pressing and holding the settings button
will exit the adjustable parameters menu.
Test Mode: With grill OFF, press and hold the Settings Button to enter the Adjustable Parameters Menu.
Enter Test Mode from either of the four screens AUG, OFS, PrA, or PrB by pressing the Power Button. Each
additional press of the Power Button will advance you through the 8 Test Mode screens. The last screen is
the BYE screen. While on the BYE screen, press the Settings Button to return to the adjustable parameters
screen then press and hold the Settings Button and your grill’s controller will return to the OFF state.
Adjustable Parameter 1: Min Feed Rate - Min Feed Rate
is the minimum rate that the auger is allowed to feed fuel to
the fire pot, regardless of Set Point. Decreasing the value will
allow the grill to achieve lower temperatures but will increase
the risk of flame-outs. Increasing the value will prevent losing
fire but will limit your ability to maintain low temperatures
on hot, sunny days. Note: Changing this does not change the
auger speed. The auger speed is constant.
Adjustable Parameter 1 controller will display AUG.
Additionally, the current auger minimum feed rate will be
displayed as a number. Turning the Temperature Control
Knob clockwise will increase, and turning counterclockwise
decrease, the value within the range of 5 - 250. (Factory
preset: 30)
Adjustable Parameter 2: Temperature Offset - Your
grill has been precisely calibrated at our facility, but the
Temperature Offset allows you to customize how your
controller will operate. Should you choose to rely on a
secondary temperature probe, you can use the following
process to recalibrate your Smart Grill Technology Controller.
Adjustable Parameter 2 will display OFS.
Additionally, the current temperature offset percentage
value will be displayed. Turning the Temperature Control
Knob clockwise will increase, and turning counterclockwise
decrease, the value within the range of -25.0 to 25.0.
(Factory preset: 0)
Due to varying qualities of pellet brands, we give you the ability to adjust your minimum feed
rate downward in the event that your grill is running hot at lower temperatures. However, if you
experience a sudden loss, followed by an immediate increase in grill temperature, then your grill
has experienced a flame out and will automatically relight. This signifies that your minimum feed rate
was adjusted too low and needs to be increased.
Adjustable Parameter 1
Adjustable Parameter 2
Probe A Calibration
Probe B Calibration
AUG
IGN
PrA
PrB

12
To enter test mode: Press and hold Settings for 3 seconds -
Press Power - until you see IGN
VEr XXX displays current software version.
Screen 5-1 is test mode for your auger motor. You should
be able to look in your grill’s fire pot and see the end of the
auger turning very slowly.
Screen 5-2 is test mode for your grill’s ignition system. You
should be able to look into grill’s fire pot and see your igniter
begin to glow within a few minutes. DO NOT TOUCH THE
IGNITER.
Screen 5-3 is test mode for your grill’s blower fan. You
should be able to hear the fan blowing.
Screen 5-4 is test mode for your grill’s control knob. You can
turn the knob to see the 000 value increase and decrease as
you turn the knob.
Screen 5-5 is test mode for your grill’s temperature sensor
and Probe A and Probe B. You can see the temperature
values for each displayed on the screen (a value of - - -
means the probe is not plugged in or the grill’s sensor is not
connected).
Screen 5-6 is an internal quality control screen that has no
function for the user.
Screen BYE is the final screen of the test mode. Pressing the
power button again will return you to Screen 5-1. Pressing
the settings button will return you to the Settings Menu, at
which time you can hold the Settings Button to exit Settings
Menu and get you back to a blank screen.
Test Mode
VEr XXX
Screen 5-1
Screen 5-2
Screen 5-3
VEr ###
5-1 AUG
5-2
0
IGN
5-3
0
FAN
Screen 5-4
Screen 5-5
Screen 5-6 Screen BYE
5-4
000
NOb
5-5
---
85°F
BYE
Probe A
---
Probe B
Actual
5-6 UF1

13
Operating Temperatures
Smoking
Roasting/Braising
Baking
Grilling
Searing
180°F to 275°F
275°F to 325°F
325°F to 375°F
375°F to 450°F
450°F+
Shutting Off Grill
When you are done cooking, simply press the power button. The blower fan will start to cool
your grill down and will shut off on its own. The auger will feed pellets during the process; this is
completely normal. Keep lid closed during this process. Do not move until fully cooled.
Tips, Tricks, and Temps
Preheating
It is important to allow your grill to preheat to achieve your desired cooking temperature before
cooking. This allows the entire grill to heat up and quickly return to your desired temperature
once your food is introduced. If you do not allow the grill to preheat, you will find that it takes a
longer period of time to bring both the grill and the food to your desired cooking temperature. It is
important to leave the lid closed during preheating.
Pellet Information
Ultimate Blend premium hardwood pellets contain approximately 8,200 BTUs of heat per pound
and leave less than 1% ash residue. Pellets should be stored in a dry area, as wet pellets will swell
and turn back into sawdust. For the best results, always use premium hardwood pellets in your grill.
The use of grades other than premium hardwood pellets may result in temperature variations, uneven
cooking, and poor results. Remember, pellets do not contain preservatives and will deteriorate over
time.
Caution: Some wood pellets produced for heating fuel have a high content of softwood which can
include pitch and should not be used for cooking. Always check with the pellet manufacturer to
ensure that you are cooking with a premium, 100% hardwood pellet.

14
• Clean your grill regularly to maintain beauty and proper function. It is advised to clean before
any long cook.
• Always use grill on a level surface.
• Check and clean fire pot regularly; this will ensure proper ignition and heat output.
• Not all pellets are created equal; always use dry and fresh pellets.
• Always store pellets in a dry area.
• Get to know your grill and keep good cooking notes. This will help with consistency.
•Practice makes perfect.
• Always allow your meat to rest before serving.
• Always keep your cooking area clean.
• Avoid lifting the lid more than necessary.
• Wind can cool your grill temperature.
• Always preheat grill to desired temperature before use.
•Wipe off stainless steel surfaces before preheating; dirt and food stains can cook into surface.
• Always check pellet hopper for debris and remove excess pellet dust as needed.
• Leave at least one inch of clearance between food for even cooks (crowded foods will take
longer to cook).
• Foods cooked in pans or containers will require more time than foods cooked directly on grate.
• Use your platinum-tipped meat probe to determine meat-doneness; never rely on time.
• Know your food’s internal temperature.
• Use long handled tongs and spatulas for turning meats; do not use plastic utensils.
•Injecting, mopping, and spritzing are great ways to keep meat from drying out.
•When going low and slow, plan for your meats to stall; larger pieces of meat tend to take
longer from160°F-180°F. Be patient.
• Never unplug your grill to turn it off.
• When not in use, unplug and cover with recteq Premium Grill Cover.
Temperatures
Remember, you can’t tell whether meat is safely cooked by looking at it. Any cooked, uncured red
meats (including pork) can be pink, even when the meat has reached a safe internal temperature.
After you remove the meat from your grill, allow it to rest for a specified amount of time. During the
rest-time, its temperature remains constant or continues to rise, which destroys harmful bacteria.
• Hot foods should be held at 140°F or warmer.
• Cold foods should be held at 40°F or colder.
• Perishable foods should not be left out for more than 2 hours at room temperature; 1 hour when
the temperature is above 90°F.
• Always follow food safety guidelines provided by the USDA.
Tips, Tricks, and Temps

15
Maintenance & Cleaning
• Clean your fire pot every 3-5 cooks or after every 16 hours of cooking time, to ensure proper
airflow.
• Use a grill brush to clean your cooking grate after every cook to provide years of trouble-free
use.
Note: Make sure that no bristles have shed onto the cooking grate.
• Clean the ash from the interior of your grill after every 2-3 bags of pellets.
WARNING: Always wait at least 12 hours after cooking to remove ash from your grill!
• Use a mild soap and water to clean the exterior of your grill.
AVOID USING CAUSTIC CLEANERS!
• If left in an exposed area, keep your grill covered and unplugged when not in use.
• Never let your pellets get wet; they will swell and jam your auger.
• If grill is not used for 6 weeks or more, it is advised to remove all pellets from hopper.
Never store the grill in a small space or place in a vehicle unless completely cool and fire is verified
as extinguished. Never move the grill while it is still hot. Never move the grill without assistance.
Clean the ash from the interior of your grill, fire pot, and hopper every 5-6 bags of pellets – a shop
vac is an ideal tool for this job. It also helps to leave a thin layer of ash on the bottom of the barrel
for insulation.
If you have completed a low and slow cook that has caused the accumulation of grease on your
foil, you must change the foil before cooking at high temperatures!
Failure to do so will most certainly cause a grease fire in your grill.

16
Troubleshooting
We pride ourselves on our grills, grilling accessories, and on our commitment to serve you. Please
consult the chart below to help resolve issues you may encounter. Also, please don’t hesitate to
contact us with any issues.
[phone]
Issue Potential Cause Solution
Grill will not light/turn on
Power
Make sure power is plugged into
working GFCI outlet, and outlet is
not tripped.
Unplug grill and check for blown
fuse; refer to controller schematic on
page 18.
Fuse
Replace fuse manually and try
again. Call Customer Service or visit
recteq.com if problem persists.
Igniter
Remove cooking grate, heat
deflector, and drip pan; visually
inspect fire pot and if after 10
minutes:
•your pellets are feeding
•your blower fan is running
•your grill is still not lighting
Then your igniter rod may need to be
replaced. Call Customer Service.
Auger Motor
Remove cooking grate, heat
deflector, and drip pan; visually
inspect auger turning in the fire pot.
(Note: the auger turns very slowly)
If auger is not turning, you may have
an obstruction in your hopper. Clean
out pellets and try again. If problem
persists, your auger motor may
need to be replaced. Call Customer
Service.
Control Board
UNPLUG GRILL.
Check to make sure the fuse is intact
and has not blown.
Check for any loose wire
connections. If any wires have
become detached, refer to controller
schematic.

17
Issue Potential Cause Solution
Grill is smoking excessively/
smoke is discolored
Pellet quality/age
Inspect pellets; ensure that pellets are
dry and have not broken down into
sawdust.
If problem persists, remove pellets
from the hopper and clean ash from
your firepot, then replace with fresh
dry pellets.
Excess ash in fire pot
Check the burn pot for ash and clean
as necessary (it’s advised to clean
fire pot every 3-5 uses).
Blower fan
Unplug grill. Remove access panel;
visually inspect blower fan for any
obstructions, loose connections,
bugs, etc.
Remove obstructions. Power grill on.
If problem persists, unplug grill. Spin
fan manually for several revolutions.
Plug grill back in. If problem still
persists, your blower fan may need
to be replaced. Call customer
service.
Grill will not heat up to or
maintain proper temp
Pellet quality/age
Inspect pellets; ensure that pellets are
dry and have not broken down into
sawdust. If problem persists, remove
pellets from the hopper and clean
ash from your firepot, then replace
with clean dry pellets.
Insufficient airflow Check fire pot for any obstructions/
ash accumulation.
Excess ash in fire pot Check fire pot for ash and clear as
necessary.
Fire continues to go out
Pellet quality/age
Inspect pellets; ensure that pellets are
dry and have not broken down into
sawdust. If problem persists, remove
pellets from the hopper and clean
ash from your firepot, then replace
with clean dry pellets.
Hopper obstruction
Unplug grill. Remove pellets from
hopper. Clean hopper of any
obstructions or build up.
Pellet Bridge
Excessively long pellets can catch on
each other and cause pellets not to
fall into the auger.

18
Issue Potential Cause Solution(s)
Pellets are not being delivered
to fire pot
Hopper obstruction
Unplug grill. Remove pellets from
hopper. Clean hopper of any
obstructions or build up.
Auger failure
Remove cooking grate and heat
deflector plate; visually inspect
auger turning in the fire pot.
(Note: the auger turns very slowly)
If auger is not turning, you may have
an obstruction in your hopper. Clean
out pellets and try again. If problem
persists, your auger motor may
need to be replaced. Call Customer
Service.
Flare ups Excessively greasy food while
temperature setting is too high
Cook at 350 degrees or below
when cooking excessively fatty
foods.
Excessive grease/build up Excessively greasy food
Cook at 350 degrees or below
when cooking excessively fatty
foods.
Smoke coming from hopper
Excess ash in firepot Clean grill interior.
Pellet level very low in hopper Add more pellets to hopper
Excess pellet dust lining auger
tube causing burn back
Remove pellets from hopper and
vacuum out hopper, auger tube, and
fire pot.
ER-1 Power Failure
Make sure power is plugged into
working GFCI outlet, and outlet is
not tripped.
Turn grill off, then back on again to
reset controller and clear code.
ER-2 Grill hasn’t ignited in over 30
minutes
Refer to “Grill will not light/turn on”
in Troubleshooting.
ER-3 RTD unplugged/grill over
heated
Check connection and let grill cool.
Turn grill off, then back on again to
reset controller and clear code.

19
Troubleshooting
In case of igniter failure, you can start your RT-700 manually:
1. Remove the stainless steel grates, drip pan, and heat deflector.
2. Clean out fire pot and place no more than 1/2 cup of pellets in the bottom. Add a
small amount of solid fuel fire starter, such as those made from sawdust and wax, or
use wood shavings.
Tip: A paper towel, shredded cardboard, or shredded newspaper can work as a
substitute.
If you have a torch lighter, a fire starter is not needed.
3. Light the fire starter.
4. After the pellets are burning briskly, turn on your grill. If your fire goes out, repeat
steps 1-4.
5. If your fire stays lit, replace the stainless heat deflector, drip pan, and cooking grates
then close the lid.
Be careful not to touch the fire.
CAUTION: Do not use flammable liquids such as gasoline, gasoline-type
lantern fuel, kerosene, charcoal lighter fluid, or similar liquids to start or
freshen-up the fire! Keep all such liquids well away from the grill while it is in
use.

20
Controller Schematic
TYWE1S 1703181
RoHS
P/N:2.01.01.10004 FOC ID: 2AFNLTWYE18
V 1.6 2017. 10. 10
ANTENNAANTENNA
FANAUGERIGNITOR
TEMP
PROBE
HOT RTD
pt1000
FAN
AUG
IGN
COM
