Red Kite Feed Me Snak Manual

IMPORTANT KEEP FOR FUTURE REFERENCE
Read these instructions carefully before use and keep them for future reference.
Your child’s safety may be affected if you do not follow these instructions.
Instruction Leaet
Feed Me
Snak
Suitable for babies up to a maximum weight of 15 kgs who can sit upright and unaided.
Complies with BS EN 14988 - 1 & 2 + A1 : 2012
Customer Care Line: 01454 326 568

2
Assembly instructions.
1. To connect the base to the back of the seat. Squeeze the seat recline lever on the rear of the
seat back and guide the spring loaded pins on the bottom of the seat back in to the attachment
points on the bottom of the seat base. Fig 1.
With the seat recline lever still squeezed, gently pull the wings of the seat base apart and pull
the seat back until it clicks into place. Fig 1a.
2. Slide the top leg frames in to the seat base making sure the numbers are facing outwards.
Fig 2. Attach the bottom legs frames to the top leg frames ensuring the push pin has come
through the hole and that the rubber feet are facing inwards. Fig 2a + 2b.
3. Thread the ends of the 5 harness straps through the corresponding slots on the seat. Fig 3.
4. Now slide the cover on to the back of the seat back. Fig 4.
5. Push the footrest in to place (g 5) ensuring the clip is in the locked position and secure in place
with 2 screws. Fig 5c. To remove the footrest, remove the 2 screws, push the clip in and pull the
footrest out.
6. Squeeze the triggers on both sides of the tray and slide it on to the arms of the seat frame.
When using the highcair, there are 3 positions available.
Fig 6.
Using the highchair
7. To select a different height, squeeze the buttons on both sides of the height mechanism and
raise or lower to desired position. There are 6 positions to choose from. Fig 7. NOTE. Ensure both
sides of the highchair are in the same position.
8. To adjust the backrest squeeze the handle on the seat back and raise or lower. You can
choose 3 different positions. Fig 8.
9. To fold the highchair pull down the catches on both sides of the rear legs and slide the feet
together. Fig 9.
10. You can remove the tray and store it in between the rear legs. There are 2 small pegs on the
inside of the legs to hold the tray. Fig 10.
To secure and adjust the harness
11. To secure your child in the harness, push the buckle prongs (A) + (B) into the buckle housing (C)
until they snap into position. Adjust sliders to ensure a snug t for your child. Repeat for the other
side and also for the shoulder straps. Fig 11.
IMPORTANT! Always use the harness.
3
1
1. Seat base
2. Seat back
3. Seat cover and harness
4. Top legs
5. Bottom legs
6. Footrest
7. Screws (x2)
8. Tray
Parts List
45
6
7
8

Fig 1a
Fig 1 Fig 6
Fig 7
Fig 8
Fig 9
Fig 10 Fig 11
Fig 2
Fig 3
Fig 4
Fig 5
Fig 2a Fig 2b
slider
a b
c
seat
recline
lever
top legs
bottom
legs
seat base
push pin
harness
slots
harness
seat cover
seat cover
screws
(underneath view)
clip
foot rest
seat base
seat base
seat base
foot rest
foot rest
triggers
buttons
seat
recline
lever
folding
catches
tray storage
pegs
located
behind tray
seat base seat base
seat back
wings
seat back
seat recline
grooves
points for seat
back pins

General care:
•The correct use and maintenance of this
high chair is essential.
•Always ensure the high chair is stored in a dry
place to prevent mould or mildew developing.
• Avoid leaving your high chair in direct sunlight
for prolonged periods of time as this may cause
premature fading of colours.
Cleaning:
•Metal parts may be cleaned with a damp cloth
and wiped dry with a soft cloth.
•Clean the harness with a mild soap and water
solution. Rinse and wipe dry.
•Clean plastic parts with a mild soap and water
solution. Rinse and wipe dry.
•Do not use abrasive cleaners or bleach.
•The tray is not dishwasher safe.
Maintenance:
•Check that nothing is broken, torn or missing and
that no sharp edges have been exposed. Stop
using the highchair immediately if any are found.
•Inspect all studs, nuts and screws for tightness.
Check that all straps and harness attachment
points are in good working order.
•Do not use replacement parts other than those
approved by the manufacturer or distributor.
Failure to do this may invalidate your warranty.
Safety Warnings:
•WARNING: Your child’s safety is your
responsibility.
• WARNING: Do not leave the child unattended.
•WARNING: Do not use the high chair unless all
components are correctly tted and adjusted.
•WARNING: Be aware of the risk of open re and
other sources of strong heat, such as electric bar
res, gas res etc. in the vicinity of the highchair.
Never place the highchair near these items.
•Do not use for a child weighing more than 15 kgs.
•Only suitable for children who can sit unaided.
•Always use the 5 point harness provided. Ensure
that it is correctly tted and adjusted before each
use.
•Adult assembly required. Always ensure that the
high chair has been correctly assembled and that
all locking devices have engaged before placing
your child in the high chair.
•Ensure that all parts of your child’s body are
clear of the high chair when assembling, folding or
making adjustments.
•Do not allow other children to play with this high
chair. It is not a toy. Store safely out of reach when
not in use.
•Never carry the high chair when the child is in it.
•Please lift your child in and out of the highchair. Do
not allow children to stand on the footrest (where
provided) and seat or to climb in and out of the
high chair.
•Only use the high chair on a level oor surface.
•Never add accessories or ttings that have not
been approved by the manufacturer.
This product complies with
Complies with BS EN 14988 - 1 & 2 + A1 : 2012
For all technical queries please call:
01454 326 568
Imported by:
The Red Kite Baby Co Ltd
35 Lavenham Road
Beeches Industrial Estate
Yate
Bristol
BS37 5QX.
