GENERAL DESCRIPTION
The NT series is a range of compact IEEE 802.3 layer two network switches
with automatic speed, duplex and cable sensing. The series features ultra-robust
construction, capable of withstanding environmental extremes for use in mission
critical applications.
These affordable, Class I, Division 2 switches feature redundant power
inputs, hardened metal enclosures, and 16 kV port protection. Each switch is
capable of auto negotiating 10/100 Mb and half/full duplex communications.
SAFETY SUMMARY
All safety related regulations, local codes and instructions that appear in the
literature or on equipment must be observed to ensure personal safety and to
prevent damage to either the instrument or equipment connected to it. If
equipment is used in a manner not specified by the manufacturer, the protection
provided by the equipment may be impaired.
For 108TX: Use 60/75°C rated copper wire, (0.22Nm) 2 inch-lbs. tightening
torque for field installed connectors.
For 104TX & 105TX: Use 95°C rated copper wire, (0.22Nm) 2 inch-lbs.
tightening torque for field installed connectors.
SPECIFICATIONS
1. POWER: 10-30 VDC
NT104TX/NT105TX: 215 mA max. @ 24VDC
NT108TX: 250 mA max. @ 24VDC
2. LEDs:
LED COLOR DESCRIPTION
ON Power is Applied.
OFF Power is OFF.
LNK/ACT
ON Link established, no Activity on cable.
BLINKING Link established, Activity on cable
OFF No link activity on cable.
SPD ON Link is 100Mbps.
OFF Link is 10Mbs.
3. ENVIRONMENTAL CONDITIONS:
Operating Temperature Range:
NT104TX/NT105TX: -40 to +80 °C
NT108TX: -40 to +70 °C
Storage Temperature Range: -40 to +85 °C
Operating Humidity: 10-95%, non-condensing
Altitude: Up to 3000 meters.
4. CONSTRUCTION: Brushed aluminum housing
5. CONNECTIONS:
Power: Removable wire clamp screw terminal block.
Wire Gage Capacity: 28 AWG to 16 AWG
Torque: 2 in/lb (0.22 Nm)
Ethernet: RJ-45 UTP ports
6. MOUNTING: Snaps onto standard DIN style top hat (T) profile mounting
rail according to EN50022 -35 x 7.5 and -35 x 15.
7. CERTIFICATIONS AND COMPLIANCES:
UL Listed (N-Tron Incorporated, Part numbers 104TX, 105TX, 108TX. File
#E214222)
Safety: Suitable for use in Class I, Division 2, Groups A, B, C and D
Hazardous locations, or non-hazardous locations only.
Immunity to Industrial Locations:
EMI: EN61000-6-4, EN55011 - Class A
FCC Title 47, Part 15, Subpart B - Class A
ICES-003 – Class A
EMS: EN61000-6-2
EN61000-4-2 (ESD)
EN61000-4-3 (RS)
EN61000-4-4 (EFT)
EN61000-4-5 (Surge)
EN61000-4-6 (Conducted Disturbances)
8. WEIGHT:
NT104TX/NT105TX:0.6 lbs. (0.27 Kg)
NT108TX0: 0.7 lbs. (0.31 Kg)
CAUTION: Risk of Danger.
Read complete instructions prior to
installation and operation of the unit.
UNMANAGED SWITCH REQUIRES NO CONFIGURATION
SUPPORTS 10/100 MBPS NETWORKS
AUTO HALF/FULL DUPLEX NEGOTIATION
REDUNDANT POWER INPUTS
AUTO-CROSSING DETECTION SUPPORTS STANDARD AND
CROSSOVER ETHERNET CABLES
Bulletin No. NT100-X
Drawing No. LP0871
Effective 06/11
MODEL NT100 SERIES – UNMANAGED INDUSTRIAL ETHERNET SWITCHES
WARNING - EXPLOSION HAZARD - DO NOT DISCONNECT
EQUIPMENT WHILE THE CIRCUIT IS LIVE OR UNLESS THE AREA
IS KNOWN TO BE FREE OF IGNITABLE CONCENTRATIONS.
WARNING - EXPLOSION HAZARD - SUBSTITUTION OF
COMPONENTS MAY IMPAIR SUITABILITY FOR CLASS I,
DIVISION 2
WARNING - EXPLOSION HAZARD - DO NOT DISCONNECT EQUIPMENT
UNLESS POWER HAS BEEN SWITCHED OFF OR AREA IS KNOWN TO BE
NON-HAZARDOUS.
CUS
UL
R
LISTED
65SN
FOR USE IN HAZARDOUS LOCATIONS:
Class I, Division 2, Groups A, B, C, and D
or unclassified or non-hazardous locations only.
Phone: [phone] - Fax: [phone] - Web: www.clrwtr.com - Email: [email protected]

POWER
Either V1or V2can be connected to power for minimal operation. For
redundant power operation, V1and V2plugs must be connected to separate DC
Voltage sources. Use wire sizes of 16-28 gauge.
NOTE: Must use an NEC Class 2 or Limited
Power Source (LPS) rated power supply.
MOUNTING
To install the plastic clip units to 35mm industrial DIN rail, place the top edge
of the included mounting bracket on the back of the unit against the DIN rail at
a 15° angle as shown. Rotate the bottom of the unit to the back (away from you)
until it snaps into place.
1 2
3 4
5 6
7 8
PWR
108TX
Powered by
4.22
(107.19)
3.53
(89.62)
3.50
(88.90)
1.49
(37.85)
1.71
(43.43)
3.50
(88.90)
3.80
(96.52)
1 2
3 4
104TX
PWR
Powered by
3.53
(89.62)
1.49
(37.85)
4.22 (107.19)
3.97 (100.95)
3.53 (89.62)
2.87
(72.90)
3.17
(80.52)
1.49
(37.85)
2.87
(72.90)
PWR
Powered by
2 3
4 5
105TX
1
DIMENSIONS In inches (mm)
DIMENSIONS In inches (mm)
Phone: [phone] - Fax: [phone] - Web: www.clrwtr.com - Email: [email protected]

To remove the unit from the DIN rail, place a flat head screwdriver into the
release clip found at the bottom of the unit, and apply downward force on the
clip until it disengages the bottom of the unit from the DIN rail. Rotate the
bottom of the unit towards you and up at an approximate 15° upward angle to
completely remove the unit.
NT series switches are designed to be grounded, but the user has been given
the flexibility to float the unit when required. The best noise immunity and
emissions are obtained when the unit’s chassis is connected to earth ground via
a drain wire.
Users may run a drain wire & lug from the screw provided on the back face
of the enclosure. In the event the provided grounding screw has been lost, care
should be taken to limit the penetration of the outer skin by less than 1/4".
Failure to do so may cause irreversible damage to the internal components of the
switch.
Note: Ensure the power supply is grounded properly before applying power
to the grounded switch. This may be verified by using a voltmeter to determine
that there is no voltage difference between the power supply’s negative output
terminal and the chassis grounding point of the switch.
As an alternative grounding method, both V- legs of the power input
connector are connected to the chassis internally on the PCB. Connecting a
drain wire to earth ground from one of the V- terminal plugs will ground the
switch and the chassis. The power leads from the power source should be
limited to 3 meters or less in length.
If the use of shielded cables is required, it is generally recommended to only
connect the shield at one end to prevent ground loops and interference with low
level signals (i.e. thermocouples, RTD, etc.). Cat5e cables manufactured to
EIA-568A or 568B specifications are required for use with NT series switches.
TROUBLESHOOTING
For further technical assistance, contact technical support at the appropriate company numbers listed.
ORDERING INFORMATION
MODEL NO. DESCRIPTION PART NUMBER
NT100
4-Port Ethernet Switch NT104TX0
5-Port Ethernet Switch NT105TX0
8-Port Ethernet Switch NT108TX0
