red lion SL-2ES Series Installation instructions

Drawing No. LP0977 Preface
Revision B
Slim Line (SL/SLX) Series 1
Preface
This manual applies to the following products:
SL-2ES-# 2-port unmanaged Ethernet media converter
SLX-3ES-# 3-port unmanaged Ethernet media converter
SLX-3EG-1 3-port unmanaged Gigabit Ethernet converter
SLX-5EG-1 5-port unmanaged Gigabit Ethernet switch
SLX-5EG-2SFP 5-port unmanaged Gigabit Ethernet switch with 2 fiber SFPs
SL/SLX-5ES-# 5-port unmanaged Ethernet switch with 5 10/100 ports
SL/SLX-6ES-# 6-port unmanaged Ethernet switch
SL/SLX-8ES/9ES-# 8/9-port unmanaged Ethernet switch with 8 or 9 10/100 ports
SLX-8MS-# 8-port managed Ethernet switch with 8 10/100 ports
SLX-8MG-1 8-port managed Ethernet switch with 8 Gigabit ports
SLX-10MG-1 10-port managed Gigabit Ethernet switch with 10 ports
SLX-16MS-1 16-port managed Ethernet switch with 16 10/100 ports
SLX-18MG-1 18-port managed Gigabit Ethernet switch with 18 ports
FCC Statement - This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures: Reorient or
relocate the receiving antenna; Increase the separation between the equipment and receiver; Connect
the equipment into an outlet on a circuit different from that to which the receiver is connected; Consult
the dealer or an experienced radio/TV technician for help.

Section 3 Installation Drawing No. LP0977
Revision B
16 Slim Line (SL/SLX) Series
Mechanical Dimensions for SLX-8MS-8/9 with 4 Fiber Ports
Mechanical Dimensions for SLX-8MG with 8 Gigabit Ports
2.60"
[6.60 cm]
2.60"
[6.60 cm]
3.82"
[9.70 cm]
5.05"
[12.83 cm]
for #6
screw
Removable
Screw Block
1.60"
[4.07 cm]
5.20"
[13.21 cm]
0.80"
[2.04 cm]
0.40"
[1.02 cm]
typical
0.15"
[0.38 cm] 1.92"
[4.88 cm]
1.90"
[4.83 cm]
For #12 screw: 5.20" [13.21 cm] For #10 screw: 5.15" [13.08 cm]
For #8 screw: 5.10" [12.95 cm] For #6 screw: 5.05" [12.83 cm]
Panel mounting ears on
newer models accept
up to a #12 screw
Direct to panel
mounting guide
for newer models
#12 screw
#10 screw
#8 screw
#6 screw
SC Fiber
ST Fiber
Snaps to
standard
DIN Rail
EN50022
(35 mm)
Removable DIN clip for
direct panel mounting
Panel mounting ears accept
up to a #6 screw on older
models (see to the right for
newer models)
Console
Port(s) 0.39"
[0.99 cm]
0.15"
[0.38 cm]
5.20"
[13.21 cm]
0.35"
[0.88 cm]
#6 screw
#8 screw
#10 screw
#12 screw
Direct to panel
mounting guide
for newer models
Panel mounting ears on
newer models
accept up to a #12 screw
[12.83 cm]
For #6 screw: 5.05" [12.95 cm] For #8 screw: 5.10" [13.08 cm]
For #10 screw: 5.15" [13.21 cm] For #12 screw: 5.20"
2.60"
[6.60 cm]
2.60"
[6.60 cm]
Typical for SFP Xcvrs
1.92"
[4.88 cm]
0.39"
[0.99 cm]
3.80"
[9.65 cm]
5.05"
[12.83 cm]
SFP Fiber
Ports
Removable DIN clip
for direct panel mounting
Removable
Screw Block
Panel mounting ears
accept up to a #6
screw on earlier models
and up to a #12 screw
on newer models.
Snaps to
standard
DIN Rail
EN50022
(35 mm)
1.88"
[4.78 cm]
Console
Ports
4.70"
[11.94 cm]
0.50"
[1.27 cm] 1.37"
[3.49 cm]
2.75"
[6.98 cm]

Section 6 Technical Specifications Drawing No. LP0977
Revision B
34 Slim Line (SL/SLX) Series
Environmental and Compliances:
Operating temperature
range
SL-2ES models: -10 to +60°C (cold startup at -10°C)
SL-5/6/8/9ES model: -40 to +60°C (cold startup at -40°C)
SLX-3/5EG models: -40 to +85°C (cold startup at -40°C)
SL/SLX-8MG models: -40 to +75°C (cold startup at -40°C)
SLX-5/6/8/9ES-1/2/3/4/5 models: -40 to +85°C (cold startup at -40°C)
SLX-8ES-6/7 models: -40 to 75° C (cold startup at -40°C)
SLX-5/8MS models: -40 to +75°C (cold startup at -40°C)
SLX-10/18MG-1 models: -40 to +75°C (cold startup at -40°C)
SLX-16MS-1 model: -40 to +75°C (cold startup at -40°C)
Contact Red Lion if wider ranges are needed.
Storage temperature range
-40 to +85 °C
PoE Models
Power input with reverse
polarity protection
10-44 VDC with no PoE output
45-52 VDC for PoE output
Switch power consumption
(typical all ports active at 1000
Mbps)
4.3 W (5EG-1, all copper) typical
6.2 W (5EG-2SFP with 2 fiber) typical
66W (5EG-1) with 4 fully loaded PoE ports
53W (5EG-2SFP) with 3 fully loaded PoE ports
PoE power consumption
Up to 15.4 W per port
RJ45 pin assignments for PoE
TX/V- (3, 6); RX/V+ (1, 2)
Power input transient
protection
15,000 watts peak
Power input spike Protection
5,000 watts (10 times for 10 uS)
PoE operation
Auto power management
PoE disconnect mode
DC disconnect
PoE auto-detection
Per IEEE 802.2af
PoE protection
Over-temperature, over-current, over/under-voltage and transient
Mechanical:
Ingress protection
IP30 (SL models) IP40 (SLX models)
Packaging and protection
UL94V0 Lexan plastic for all plastic cased units.
Aluminum w/ protective finish for all metal cased units.
Dimensions (L x W x H)
See mechanical diagrams for details
Weights (typical)
SL-2ES-2/3 and SL-5ES-1/2/3 in Lexan case –4 oz (0.11 kg)
SLX-3EG in metal case –6 oz (0.17 kg)
SLX-5ES-1/2/3 in metal case –6 oz (0.17 kg)
SLX-5EG-1/2SFP in metal case –15.2 oz (0.43 kg)
SLX-5MS-1/4/5 in metal case –8 oz (0.23 kg)
SL-6/8/9ES-1/2/3/4/5 in Lexan case –6 oz (0.17 kg)
SLX-6/8/9ES-1/2/3/4/5 in metal case –8 oz (0.23 kg)
SLX-8MS-1/4/5 in metal case –10 oz (0.28 kg)
SLX-8xS-6/7/8/9 in metal case –11 oz (0.31 kg)
SLX-8MG-1 without fiber transceivers –16 oz (0.45 kg)
SLX-8MG-1 with 4 fiber transceivers –18 oz (0.50 kg)
SLX-10MG-1 in metal case –12 oz (0.34 kg)
SLX-16MS-1 in metal case –16 oz (0.45 kg)
SLX-18MG-1 in metal case –16 oz (0.46 kg)
