RED-RING Selectronic Mixer Shower TMV3 User manual

form &function
Fits to almost any plumbing
system on virtually any
pressure. Sleek design with
a patented ‘through the
ceiling’ connection -
for one of the quickest
installation times on
the market.
• No fuss
• No problems
• No wasted time
The new TMV3
thermostatic
Redring
Selectronic
Mixer Shower
blurs the
boundaries.
selectronic
mixershower
28844-Complete:Layout 1 21/7/08 07:53 Page 1

Easy and fast installation
• No channel pipe to cut
• Easy two point mounting
• 15mm copper pipes
suitable for all connections
including push-on,
compression and
soldered joints
• Pipes rotate for easy
alignment
Simply connect to water
supplies within roof cavity
Includes pre-assembled
hot and cold feed pipes plus
isolating valves with filters
60 mm
WALL
107 mm
Fixing
point
Fixing
point
190 mm
CEILING
(9 inches)
230 mm
1100 mm
1075mm
(42 inches)
Key Features
Technical
Specifications
Dimensions
Pressure Requirements
• Suitable for rooms with ceiling
heights up to 2.5 metres
• Overall height: 1100mm
The Redring Selectronic Mixer Shower assembly can
be used on systems with pressures from 0.1 bar
(1 metre head) to 7 bar. The maximum hot to cold
pressure differential should NOT exceed 2 bar at higher
pressures or 0.2 bar at very low pressures. For pressures
in excess of 7 bar a pressure regulator should be fitted.
Perfect for retrofit or a brand new
bathroom - minimal disruption
• TMV3 approved thermostatic
shower valve
• Very quick to install
• Hot and cold supplied
down riser rail
• No tile or wall cutting required
• Only two fixings needed
• Compatible with just about any
plumbing system
• Supplied with isolating valves
including integral filters
• Contemporary styling to
enhance bathroom
• Automatic shutdown if cold
or hot water supply fails
• Safety button override for
hotter shower
• Easy clean
• Made from highest quality
components
• Designed for reliability
• Unique UK design and
manufacture
• Chrome plated solid brass
fittings for durability
• All metal construction for strength
Adjustable 3 function
Traditional, Pulsator and
Aerator Showerhead
for pressures 0.2 - 7 bar.
Single function
showerhead
for pressures 0.1 - 7 bar
especially gravity fed sites.
Rub clean.
Discover stunning form and perfect function at
www.redring.co.uk or call 01733 456870
The Product
The Redring Selectronic Mixer
Shower features a unique hot
and cold water connection
design and uses the highest
quality components. This TMV3
approved thermostatic Redring
Selectronic Mixer Shower offers
a superb temperature response,
with automatic shutdown if the
cold or hot water supply fails. In
addition and by utilising the riser
rail to route the hot and cold
supplies through the ceiling this
shower has one of the quickest
installation times on the market.
Product Short Catalogue Description
Reference Code Number
SELECTRONIC TM SLT1 36598201 Redring Selectronic Mixer Shower
including riser rail, hose and high & low pressure shower heads
Product Selector
Aerator
Pulsator
Traditional
RO34 July 2008
28844-Complete:Layout 1 21/7/08 07:53 Page 2
