red roo RH918 User manual

Online Demonstration Available at:
www.redroo.com/products/rotaryhoe
SAFETYPRECAUTIONS
AND OPERATING
INSTRUCTIONS
™
GT622
GARDEN
TILLER
OPERATION
1) Remove the garden tiller
from its trailer/carrier. Use caution.
2) Familiarize yourself with the machine and its
controls.
3) Ensure the safety clutch control lever is in the
disengagedposition. The safety clutch
control lever is located on the left handle bar.
The disengaged position of the lever is down.
4) Remove the shaft locking pin located behind
the wheel axle. Store pin in hole provided on
left hand side of handle bar.
5) The wheel axle will now pivot. Lift up on the
handle to allowwheelaxle to pivot. For
transport, keep the wheel axle forward. When
cultivating, keep the wheel axle rearward for
added stability and control.
DO NOT transport the tillerwith the wheel
axle in the rear position.
6) Adjust depth shoe(ifequipped) by removing
shaft locking collarand slidingdepth shoe to
desired position. Replace shaft locking collar.
7) Open fuel shut-off valve. Set choke
control to Choke or Start position.
Set throttle control to Run or Fast
position. Set engine
stop switch to On or
Run position. Pull
starter cord rapidly.
Repeat (if necessary)
with choke off.
8) Wheninposition to begingarden tilling,
engage the safety clutch controllever. The
tyneswillbeginrotating. Wheel axle must be in
the rearpositionwhile tilling.Release the
safety clutch controllever to stop the tynes
rotating. Tynespeed is governed by engine
throttle setting.
WARNING! –KEEPHANDSAND
FEET CLEAR OF TYNES AT ALL
TIMES!
9) Do not hurry the job. Proceed slowly and allow
the machine time to do the job. When ground
is extremely hard, reduce engine speed.
WARNING! –IN CASE OF DIFFICULTY,
DISENGAGE THE SAFETY CLUTCH
CONTROL LEVER. ALL TILLING ACTION
STOPS.Press the engine"STOP"button
located on the engine.
10) Stop Engine: Release the safety clutch control
lever.Move throttle to Slowposition. Set engine
stop switch to Stop or Offposition.DO NOT move
choke control to Choke
or Start position to stop
engine.Backfire or
enginedamagemay
occur.
AFTER USE
1) Turn fuelshut off valve to the "OFF"
position.
2) Allow machine to cool down.
3) Wash mud and dirt off of the garden tiller.
Ensure no water enters the carburettor.
4) Removeanyweeds,wire,rope or other
material thatmayhavewrappedaround the
tynes and rotor assembly.
5) Returnwheelaxle to forwardposition for
transport. Replace shaft locking collar.
6) Returndepth shoe(ifequipped) to full Up
position.
© Copyright 2001, Red Roo Sales & Service Company Pty. Ltd. 1301-0018
Commercial Environmental Equipment
RH918
ROTARYHOE
1) Remove the rotary hoe from its trailer.
Use caution.
2) Familiarize yourself with the machine and its
controls.
3) Ensure all clutchcontrols are in the
"disengaged" position. The engine safety clutch
lever is located on the left handle bar (from
rear) of the machine. The disengage position of
the engine lever is down. The wheel shift lever
is closest to operator (from rear) and the rotor
shift lever is forward (away from operator) of
the wheel shift lever (from rear). Both levers are
located on the right side of the machine (from
rear). The disengage position of both the wheel
and rotor shift levers is locked in towards the
machine. Both levers are held in place with
locking hooks.
4) DEPTH SHOE ADJUSTMENT
Control the depth of the hoe with the depth
control bar at the rear of the machine. The
higher the bar is set, the deeper the hoe will
dig. It is recommended that the initial setting be
in the centre hole for the first pass. Lower holes
may then be used to achieve full hoe depth.
Where the ground is extremely hard try the
following technique. (a) Soak the ground with
water the day before you intend to do the
designated area. (b) Use the centre hole on the
depth control bar at all times. (c) Pass over the
ground in a clockwise or anticlockwise
direction. (d) Proceed corner tocorner in a
diagonal direction. (e) Repeat step (d) in the
opposite direction.
5) Open fuel shut-off valve, if engine is
equipped. Move choke control to
CHOKE or START position.
Note: Choke must fully close. Move throttle
control to RUN or FAST position.
If engine is equipped
with rocker style stop
switch, push RUN or I
(I = Ignition) before
starting. Rewind
Starter: Grasp rope
handle and pull slowly until resistance is felt to
prevent kickback. Then pull cord rapidly to
overcome compression, and start engine.
Repeat if necessary with choke off and throttle
control in FAST position. Operate engine in
FAST position.
6) Engage the wheel drive. Unlock retaining hook
and pull lever away from machine. Engage
engine clutch by lifting up on handle. The hoe
will begin to move forward. Use engine clutch
to start and stop while Rotary Hoeing.
7) When in position to begin rotary hoeing, disengage
engine clutch lever. The hoe will stop. Engage the
rotor shift lever. Unlock retaining hook and pull
lever away from machine. Lift the engine clutch
lever. The hoe will begin to move forward AND the
blades will turn.
WARNING! –KEEP HANDS AND
FEET CLEAR OF TYNES AT ALL
TIMES!
8) Do not hurry the job. Proceed slowly and give
the machine time to do the job properly. When
ground is extremely hard, reduce engine speed.
Once again we must emphasise the need to
water the area thoroughly and allow sufficient
time for the earth to soften.
9) WARNING!–IN CASE OF DIFFICULTY,
DISENGAGE THE SAFETY CLUTCH
LEVER. ALL HOEING ACTIONSTOPS.
Press the engine "STOP"button located on
the engine. (See illustration)
10) Stop Engine: Do not
move choke control to
CHOKE position tostop
engine. Backfire or engine
damage may occur. Move
throttle control toSLOW position, then push rocker
switchto0(STOP), or turn key toOFF, if equipped.
AFTER USE
1) Turn fuel tap to "OFF" position.
2) Allow machine to cool down.
Wash mud and dirt off of the hoe.
Ensure no water enters the carburettor.
3) Remove any weeds, wire, rope, etc. that may have
wrapped around the knives and rotor assembly.
© Copyright 2012, Red Roo Sales & Service Company Pty. Ltd. 1301-0019-A
You alone know the operational demands and
special conditions affecting the equipment in
your situation and therefore assume the
responsibility for developing, carrying out, and
enforcing the safety concepts which apply to your
own operation to effect the greatest safety for
yourself andthe people around you.
“The Right Way to Rent”
OPERATING INSTRUCTIONS FOR RH918
SAFETYPRECAUTIONS
AND OPERATING
INSTRUCTIONS
™
GT622
GARDEN
TILLER
OPERATION
1) Remove the garden tiller
from its trailer/carrier. Use caution.
2) Familiarize yourself with the machine and its
controls.
3) Ensure the safety clutch control lever is in the
disengagedposition. The safety clutch
control lever is located on the left handle bar.
The disengaged position of the lever is down.
4) Remove the shaft locking pin located behind
the wheel axle. Store pin in hole provided on
left hand side of handle bar.
5) The wheel axle will now pivot. Lift up on the
handle to allowwheelaxle to pivot. For
transport, keep the wheel axle forward. When
cultivating, keep the wheel axle rearward for
added stability and control.
DO NOT transport the tillerwith the wheel
axle in the rear position.
6) Adjust depth shoe(ifequipped) by removing
shaft locking collarand slidingdepth shoe to
desired position. Replace shaft locking collar.
7) Open fuel shut-off valve. Set choke
control to Choke or Start position.
Set throttle control to Run or Fast
position. Set engine
stop switch to On or
Run position. Pull
starter cord rapidly.
Repeat (if necessary)
with choke off.
8) Wheninposition to begingarden tilling,
engage the safety clutch controllever. The
tyneswillbeginrotating. Wheel axle must be in
the rearpositionwhile tilling.Release the
safety clutch controllever to stop the tynes
rotating. Tynespeed is governed by engine
throttle setting.
WARNING! –KEEPHANDSAND
FEET CLEAR OF TYNES AT ALL
TIMES!
9) Do not hurry the job. Proceed slowly and allow
the machine time to do the job. When ground
is extremely hard, reduce engine speed.
WARNING! –IN CASE OF DIFFICULTY,
DISENGAGE THE SAFETY CLUTCH
CONTROL LEVER. ALL TILLING ACTION
STOPS.Press the engine"STOP"button
located on the engine.
10) Stop Engine: Release the safety clutch control
lever.Move throttle to Slowposition. Set engine
stop switch to Stop or Offposition.DO NOT move
choke control to Choke
or Start position to stop
engine.Backfire or
enginedamagemay
occur.
AFTER USE
1) Turn fuelshut off valve to the "OFF"
position.
2) Allow machine to cool down.
3) Wash mud and dirt off of the garden tiller.
Ensure no water enters the carburettor.
4) Removeanyweeds,wire,rope or other
material thatmayhavewrappedaround the
tynes and rotor assembly.
5) Returnwheelaxle to forwardposition for
transport. Replace shaft locking collar.
6) Returndepth shoe(ifequipped) to full Up
position.
© Copyright 2001, Red Roo Sales & Service Company Pty. Ltd. 1301-0018
Commercial Environmental Equipment
SAFETYPRECAUTIONS
AND OPERATING
INSTRUCTIONS
™
GT622
GARDEN
TILLER
OPERATION
1) Remove the garden tiller
from its trailer/carrier. Use caution.
2) Familiarize yourself with the machine and its
controls.
3) Ensure the safety clutch control lever is in the
disengagedposition. The safety clutch
control lever is located on the left handle bar.
The disengaged position of the lever is down.
4) Remove the shaft locking pin located behind
the wheel axle. Store pin in hole provided on
left hand side of handle bar.
5) The wheel axle will now pivot. Lift up on the
handle to allowwheelaxle to pivot. For
transport, keep the wheel axle forward. When
cultivating, keep the wheel axle rearward for
added stability and control.
DO NOT transport the tillerwith the wheel
axle in the rear position.
6) Adjust depth shoe(ifequipped) by removing
shaft locking collarand slidingdepth shoe to
desired position. Replace shaft locking collar.
7) Open fuel shut-off valve. Set choke
control to Choke or Start position.
Set throttle control to Run or Fast
position. Set engine
stop switch to On or
Run position. Pull
starter cord rapidly.
Repeat (if necessary)
with choke off.
8) Wheninposition to begingarden tilling,
engage the safety clutch controllever. The
tyneswillbeginrotating. Wheel axle must be in
the rearpositionwhile tilling.Release the
safety clutch controllever to stop the tynes
rotating. Tynespeed is governed by engine
throttle setting.
WARNING! –KEEPHANDSAND
FEET CLEAR OF TYNES AT ALL
TIMES!
9) Do not hurry the job. Proceed slowly and allow
the machine time to do the job. When ground
is extremely hard, reduce engine speed.
WARNING! –IN CASE OF DIFFICULTY,
DISENGAGE THE SAFETY CLUTCH
CONTROL LEVER. ALL TILLING ACTION
STOPS.Press the engine"STOP"button
located on the engine.
10) Stop Engine: Release the safety clutch control
lever.Move throttle to Slowposition. Set engine
stop switch to Stop or Offposition.DO NOT move
choke control to Choke
or Start position to stop
engine.Backfire or
enginedamagemay
occur.
AFTER USE
1) Turn fuelshut off valve to the "OFF"
position.
2) Allow machine to cool down.
3) Wash mud and dirt off of the garden tiller.
Ensure no water enters the carburettor.
4) Removeanyweeds,wire,rope or other
material thatmayhavewrappedaround the
tynes and rotor assembly.
5) Returnwheelaxle to forwardposition for
transport. Replace shaft locking collar.
6) Returndepth shoe(ifequipped) to full Up
position.
© Copyright 2001, Red Roo Sales & Service Company Pty. Ltd. 1301-0018
Commercial Environmental Equipment
OPERATION RH918
1) Familiarise yourself with the rotary hoe and its controls.
10) Never run the machine in reverse while the tynes are
rotating. Always move the tyne control lever to Neutral
before reversing the wheels.
1) Turn fuel tap to “OFF” position.
3) Remove any weeds, wire, rope, etc that may have
wrapped around the knives and rotorassembly.
Ensure no water enters the carburettor.
2) Allow machine to cool down. Wash mud
and dirt off of the rotary hoe.
11) To prevent injuries from rotating tynes, KEEP
REAR TYNE COVER CLOSED and MACHINE
LEVEL while tynes are operating.
12) WARNING! - OPERATE ROTARY
HOE ON LEVEL GROUND ONLY.
13) WARNING! - DO NOT LEAVE
ROTARY HOE UNATTENDED WITH
ENGINE RUNNING.
14) WARNING! - KEEP HANDS AND FEET
CLEAR OF TYNES AT ALL TIMES!
In most soil conditions, the depth bar can be set
with the pin in the third hole from the top.
A. Begin with the Wheel Speed Control all the
way back (toward the operator)
B. Wheel Drive Control Lever in forward
C. Tyne Drive Control Lever in forward or reverse
D. Squeeze the Safety Clutch Lever
E. Adjust the Speed Control forward until a suitable
speed is obtained based on soil conditions. Under
most conditions, at least two passes must be made.
To increase depth,move the depth bar up one hole
at a time.
3) Remove the rotary hoe from its trailer.
Use caution.
4) Safety Clutch Lever is located on the left handle bar
(from rear) of the machine. The machine will not operate
unless this lever is pressed up against the handle grip. When
the lever is released, both wheels and tynes stop.
5) Wheel Drive Control lever - Select Forward or Reverse to
control the direction (not the speed) of the wheels. When the
control is in Neutral, the wheels are locked. For your safety
the reverse lockout feature prevents the tynes from rotating
when the Wheel Drive is in Reverse.
6) Speed Control lever - The wheel speed is variable when
the Wheel Drive Control Lever is in either Forward or
Reverse. The further forward the speed Control, the faster
the Rotary Hoe will travel. The faster speed is designed only
for transport. Use a slow speed for rotary hoeing and to adjust
for soil conditions.
7)
8)
Tyne Control Lever - The tynes operate at a constant speed.
The tyne drive lever must be moved forward or reverse when
hoeing. If an object becomes lodged in the tynes, put wheel
Drive Control Lever in neutral and change tyne direction to
dislodge it.
2) Free Wheel Hub Feature -Operation:
Pull one free wheeling pin slightly, using the
split ring rotate the pin until the 3mm (1/8”)
diameter roll pin aligns with the slot in the
mounting plate. Allow the pin to slide through the slot.
Repeat for the other wheel. Roll the Rotary Hoe until each
pin drops into a hole in the hub. The wheel hubs are now
locked. Reverse the procedure to unlock the wheels.
AFTER USE
© Copyright 2012, Red Roo Sales & Service Company Pty. Ltd. 1301-0052-A
a.
b.
STARTING THE ENGINE:
c.
d. Turning the engine switch
to the ON position.
To start a cold engine, move the choke
lever or choke rod (applicable types) to
the CLOSED position. To restart a warm
engine,leave the choke lever or choke
rod in the OPEN position.
Move the fuel valve lever to ON position.
Move the throttle lever away from
the MIN position,about 1/3 of the
way toward the MAX position.
RECOIL STARTER
Pull the starter grip lightly until you
feel resistance, then pull briskly.
Return the starter grip gently.
a.
Shut off switch on
console should be
used, not shut off
switch on engine.
b. Turn the engine switch
to the OFF position.
c. Turn the fuel
valve lever to the
OFF position.
15) STOPPING THE ENGINE:
Move the throttle lever
to the MIN position.
Some engine applications use a
remote-mounted throttle control
rather than the engine-
mounted lever shown here
OPERATION RH918
1) Familiarise yourself with the rotary hoe and its controls.
10) Never run the machine in reverse while the tynes are
rotating. Always move the tyne control lever to Neutral
before reversing the wheels.
1) Turn fuel tap to “OFF” position.
3) Remove any weeds, wire, rope, etc that may have
wrapped around the knives and rotorassembly.
Ensure no water enters the carburettor.
2) Allow machine to cool down. Wash mud
and dirt off of the rotary hoe.
11) To prevent injuries from rotating tynes, KEEP
REAR TYNE COVER CLOSED and MACHINE
LEVEL while tynes are operating.
12) WARNING! - OPERATE ROTARY
HOE ON LEVEL GROUND ONLY.
13) WARNING! - DO NOT LEAVE
ROTARY HOE UNATTENDED WITH
ENGINE RUNNING.
14) WARNING! - KEEP HANDS AND FEET
CLEAR OF TYNES AT ALL TIMES!
In most soil conditions, the depth bar can be set
with the pin in the third hole from the top.
A. Begin with the Wheel Speed Control all the
way back (toward the operator)
B. Wheel Drive Control Lever in forward
C. Tyne Drive Control Lever in forward or reverse
D. Squeeze the Safety Clutch Lever
E. Adjust the Speed Control forward until a suitable
speed is obtained based on soil conditions. Under
most conditions, at least two passes must be made.
To increase depth,move the depth bar up one hole
at a time.
3) Remove the rotary hoe from its trailer.
Use caution.
4) Safety Clutch Lever is located on the left handle bar
(from rear) of the machine. The machine will not operate
unless this lever is pressed up against the handle grip. When
the lever is released, both wheels and tynes stop.
5) Wheel Drive Control lever - Select Forward or Reverse to
control the direction (not the speed) of the wheels. When the
control is in Neutral, the wheels are locked. For your safety
the reverse lockout feature prevents the tynes from rotating
when the Wheel Drive is in Reverse.
6) Speed Control lever - The wheel speed is variable when
the Wheel Drive Control Lever is in either Forward or
Reverse. The further forward the speed Control, the faster
the Rotary Hoe will travel. The faster speed is designed only
for transport. Use a slow speed for rotary hoeing and to adjust
for soil conditions.
7)
8)
Tyne Control Lever - The tynes operate at a constant speed.
The tyne drive lever must be moved forward or reverse when
hoeing. If an object becomes lodged in the tynes, put wheel
Drive Control Lever in neutral and change tyne direction to
dislodge it.
2) Free Wheel Hub Feature -Operation:
Pull one free wheeling pin slightly, using the
split ring rotate the pin until the 3mm (1/8”)
diameter roll pin aligns with the slot in the
mounting plate. Allow the pin to slide through the slot.
Repeat for the other wheel. Roll the Rotary Hoe until each
pin drops into a hole in the hub. The wheel hubs are now
locked. Reverse the procedure to unlock the wheels.
AFTER USE
© Copyright 2012, Red Roo Sales & Service Company Pty. Ltd. 1301-0052-A
a.
b.
STARTING THE ENGINE:
c.
d. Turning the engine switch
to the ON position.
To start a cold engine, move the choke
lever or choke rod (applicable types) to
the CLOSED position. To restart a warm
engine,leave the choke lever or choke
rod in the OPEN position.
Move the fuel valve lever to ON position.
Move the throttle lever away from
the MIN position,about 1/3 of the
way toward the MAX position.
RECOIL STARTER
Pull the starter grip lightly until you
feel resistance, then pull briskly.
Return the starter grip gently.
a.
Shut off switch on
console should be
used, not shut off
switch on engine.
b. Turn the engine switch
to the OFF position.
c. Turn the fuel
valve lever to the
OFF position.
15) STOPPING THE ENGINE:
Move the throttle lever
to the MIN position.
Some engine applications use a
remote-mounted throttle control
rather than the engine-
mounted lever shown here
MAXIMUM ANGLE
OF OPERATION
DO NOT EXCEED
15º ANGLE
USE COMMON SENSE
AND PLENTY OF IT
SAFETY INSTRUCTIONS FOR HT912USERS
INSTRUCTIONS
DO NOT allow any person to operate the
hydraulic trencher without first reading and
understanding the safety instructions and
NEVER allow children to operate the hydraulic trencher.
ALWAYS use hydraulic trencher in a well lighted area.
ALWAYS make certain that all control clutches are in
the “disengaged” position prior to starting the engine.
The safety clutch lever/Operator Presence Control on
the left handlebar is for operator protection. DO NOT
tape down or otherwise bypass this Safety Device.
NEVER wear loose fitting clothing or jewellery when
operating the hydraulic trencher. Keep all clothing
away from moving parts. Item could become
caught in the machine, resulting in injury.
ALWAYS wear protective
clothing when operating
the hydraulic trencher.
This includes, but is not limited to, safety glasses, hard hat
loose fitting gloves, steel capped boots and hearing protection.
operating instructions. KNOW THE CONTROLS AND
HOW TO STOP THE HYDRAULIC TRENCHER QUICKLY
IN AN EMERGENCY.
1)
2)
3)
4)
Police the area before trenching. Remove any foreign
objects in the digging area eg bricks, rocks, wire and
sticks. Locate and mark any sprinkler heads, water
pipes, gas lines, electrical and telephone cables or any
other hazard either below or above ground.
5)
DO NOT leave the machine unattended while the engine
is running. DO NOT park on incline or park
perpendicular to slope. DO NOT freewheel down incline.
7)
DO NOT overspeed the engine or alter the governor
settings. Excessive speed is dangerous and will
shorten engine life
8)
NEVER operate the hydraulic trencher when fatigued.
ALWAYS BE ALERT! If you get tired while operating
the hydraulic trencher, take a break. If you have any
type of physical or mental condition that may be
aggravated by strenuous work, consult with your
physician before you operate this equipment. NEVER
operate the hydraulic trencher under the influence of
medication, alcohol or drugs.
9)
NEVER operate the unit without the safety
guards in place and in working order. Keep
the unit well maintained and in good working order
Remove the hydraulic trencher from its
trailer. Use caution.
Police the area. Remove any
foreign objects from the area.
Identify and mark the location of sprinkler heads,
gas pipes, telephone cables, etc.
IGNITION: Must be in “ON” position to start. “OFF”
to stop.
ENGINE: Throttle cable controls engine speed.
Operate at full throttle (all the way forward).
WHEEL DRIVE CONTROL LEVER: Controls wheel
speed forward or reverse after clutch lever is engaged.
DIGGING BOOM CONTROL LEVER: Raises and lowers
the digging boom.
DIGGING CHAIN CONTROL LEVER: must be in “ON”
position BEFORE clutch lever is depressed in order
to start chain in motion. Chain moves in a forward
direction after clutch lever is engaged.
SAFETY CLUTCH LEVER/OPERATOR PRESENCE
CONTROL: (At left handle grip) Activates WHEEL
DRIVE and DIGGING CHAIN controls when depressed.
Stops all motion when released.
FORWARD/REVERSE DIGGING CHAIN CONTROL
LEVER: Allows manual operation of chain in forward
or reverse rotation to dislodge objects or dig difficult
terrain. (This control can be used with the clutch lever
released.) To reverse chain, DIGGING CHAIN control
must be in “OFF” position.
Familiarize yourself with the hydraulic
trencher and its controls.
10)
1)
1)
2)
1)
Free Wheel Hub Feature - Operation:
Pull one free wheeling pin slightly, using the split
ring. Rotate the pin until the 3mm (1/8”) diameter roll
pin aligns with the slot in the mounting plate. Allow
the pin to slide through the slot. Repeat for the other
wheel. Roll the trencher until each pin drops into a
hole in the hub. The wheel hubs are now locked.
Reverse the procedure to unlock the wheels.
2)
DO NOT allow other persons near the hydraulic
trencher. It is up to the operator to keep
bystanders and animals a minimum of 6 metres
(20ft) away from the machine while in operation.
12)
NEVER operate the hydraulic trencher in an
enclosed area. Engine exhaust contains carbon
monoxide, an odourless and tasteless poison.
13)
WARNING: Hydraulic oil is under extreme
pressure and can get under skin and burn
or poison. Check for leaks with cardboard.
14)
STOP the engine and disconnect the spark
plug lead(s) and allow engine to cool before
inspecting or performing maintenance on
the hydraulic trencher.
15)
REFUELLING
* Shut off engine. DO NOT REFUEL AN ENGINE
WHILE OPERATING!
* Allow engine to cool. Minimum 5 minutes
* Do not smoke. *Allow no naked flame
or hot material in refuelling area.
* Use only approved fuel containers and funnels.
Remember, fuel is a potential hazard.
* Do not over-fill fuel tank. Allow space for
fuel expansion.
* USE UNLEADED FUEL ONLY. Use clean,
fresh unleaded fuel.
* Do not mix oil with unleaded fuel.
16)
ALWAYS KEEP YOUR HANDS, FEET AND BODY
AWAY FROM THE DIGGING CHAIN AND OTHER
MOVING PARTS WHILE ENGINE IS RUNNING.
11)
ALWAYS operate
hydraulic trencher
on level ground only.
6) MAXIMUM
ANGLE OF
OPERATION
DO NOT EXCEED 15ºANGLE
BEFORE USE
OPERATION
TRANSPORT
RH918 OPERATING INSTRUCTIONS
9) RotaRy Hoe opeRation

SAFETY INSTRUCTIONS FOR RH918 USERS
OPERATING
INSTRUCTIONS
USE COMMON SENSE
AND PLENTY OF IT
TRANSPORT
BEFORE USE
1) DO NOT allow any person operate the
rotary hoe without first reading and
understanding the safety instructions and
operating instructions.
2) NEVER allow children to operate the rotary hoe.
8) ALWAYS make certain the Tyne Control Lever is
set at neutral while loading and unloading the
rotary hoe, or moving to and away from working area.
9) NEVER run the machine in reverse while the tynes
are rotating. Always move the tyne control lever to
“OFF” before reversing the wheels.
11) DO NOT leave the machine unattended while the
engine is running.
12) DO NOT overspeed the engine or alter the governor
settings. Excessive speed is dangerous and will
shorten engine life.
13) NEVER operate the rotary hoe in an
enclosed area. Engine exhaust contains
carbon monoxide, an odourless and
tasteless poison.
14) STOP the engine and disconnect the
spark plug lead(s) and allow engine to
cool before inspecting or performing
maintenance on the rotary hoe.
15)
1)
REFUELLING
* Shut off the engine. DO NOT REFUEL
AN ENGINE WHILE OPERATING!
* Allow engine to cool. Minimum 5 minutes
* USE UNLEADED FUEL ONLY.
Use clean, fresh unleaded fuel.
* Do not mix oil with unleaded fuel.
* Do not over-fill fuel tank. Allow space
for fuel expansion.
10) NEVER operate the unit without the safety
guards in place and in working order. Keep
the unit well maintained and in good
working order.
4) ALWAYS use the rotary
hoe in a well lighted area.
7) NEVER operate the rotary hoe when fatigued.
ALWAYS BE ALERT! If you get tired while
operating the rotary hoe, take a break. If you have
any type of physical or mental condition that may
be aggravated by strenuous work, consult with
your physician before you operate this equipment.
NEVER operate the rotary hoe under the influence
of medication, alcohol or drugs.
6) DO NOT allow other persons near the
rotary hoe. It is up to the operator to keep
bystanders and animals a minimum of 6
5) ALWAYS operate the rotary
hoe on level ground only.
Police the area before rotary
hoeing. Remove any foreign objects in the digging
area - bricks, rocks, wire and sticks. Locate and mark
any sprinkler heads, water pipes, gas lines,
electrical and telephone cables or any other hazard
either below or above ground.
3) ALWAYS wear protective clothing when operating
the rotary hoe. This includes, but is not limited to;
safety glasses, loose fitting gloves, steel capped
boots and hearing protection. NEVER wear loose
fitting clothing or jewellery when operating the
rotary hoe. Keep all clothing away from moving
parts. Items could become caught in the machine,
resulting in injury.
KNOW THE CONTROLS AND HOW TO STOP
THE ROTARY HOE QUICKLY IN AN EMERGENCY.
metres (20’) away from the machine while in
operation.
ALWAYS KEEP YOUR HANDS,
FEET AND BODY AWAY FROM
THE DIGGING ZONE WHILE
ENGINE IS RUNNING.
* Do not smoke.
* Allow no naked flame or hot material in refuelling area.
* Use only approved fuel containers and funnels.
Remember, fuel is a potential hazard .
Be sure Tyne Control Lever is set to “Neutral”
while loading and unloading the rotary hoe
and when moving to or from jobsite.
Ensure that all grass and weeds have been cut
as low as possible.
2) If the rotary hoe is to be used in clay or hard
ground conditions, it is recommended to water
the area thoroughly and allow sufficient time
for earth to soften.
3) Police the area. Remove any
foreign objects from the area.
4) Identify and mark the location of sprinkler heads,
gas pipes, telephone cables etc.
“The Right Way to Rent”
You alone know the operational demands and
special conditions affecting the equipment in
your situation and therefore assume the
responsibility for developing, carrying out, and
enforcing the safety concepts which apply to your
own operation to effect the greatest safety for
yourself andthe people around you.
USE COMMON SENSE
AND PLENTY OF IT
1) DO NOT allow any person to operate
the rotary hoe without first reading
and understanding the safety
precautions and operating instructions. KNOW
THE CONTROLS AND HOW TO STOP THE
ROTARY HOE QUICKLY IN AN EMERGENCY.
2) NEVERallow children or untrained adults to
operate the rotary hoe.
3) ALWAYS wear
protective clothing
when operating the
rotary hoe. This includes, but is not limited to;
safety glasses, loose fitting gloves, steel
capped boots and hearing protection. NEVER
wear loose fitting clothing or jewellery when
operating the rotary hoe. Keep all clothing
away from moving parts. Items could become
caught in the machine, resulting in injury.
4) ALWAYS operate the rotary hoe in a well
lighted area.
5) ALWAYS make certain that all three control
clutches are in the "disengaged" position prior
to starting the engine.
6) ALWAYS operate rotary hoe on
level ground only. Police the
area before rotary hoeing.
Remove any foreign objects in the digging area
eg bricks, rocks, wire and sticks. Locate and
mark any sprinkler heads, water pipes, gas
lines, electrical and telephone cables or any
other hazard either below or above ground.
7) DO NOT allow other persons near the
rotary hoe. It is up to the operator to
keep bystanders and animals a
minimum of 6 metres (18ft) away from the
machine while in operation.
8) NEVER operate the rotary hoe when fatigued.
ALWAYS BE ALERT! If you get tired while
operating the rotary hoe, take a break. If you have
any type of physical or mental condition that may
be aggravated by strenuous work, consultwith
your physician before you operate this
equipment. NEVERoperate the rotary hoe under
the influence of medication, alcohol or drugs.
9) ALWAYS KEEP YOUR HANDS,
FEET AND BODY AWAY FROM
THE DIGGING AREA WHILE
ENGINE IS RUNNING.
10) NEVER operate the unit without the
safety guards in place and in working
order. Keep the unit well maintained
and in good working order
11) DO NOT leave the machine unattended while
the engine is running.
12) DO NOT overspeed the engine or alter the
governor settings. Excessive speed is
dangerous and will shorten engine life.
13) NEVER operate the rotary hoe in an
enclosed area. Engine exhaust
contains carbon monoxide, an
odourless and tasteless poison.
14) STOP the engine and disconnect the
spark plug lead(s) and allow engine
to cool before inspecting or
performing maintenance on the rotary hoe.
15) REFUELLING
* Shut off engine. DO NOT REFUEL
AN ENGINE WHILE OPERATING!
* Allow engine to cool. Minimum 5
minutes.
*USE UNLEADED FUEL ONLY.
Use clean, fresh unleaded fuel.
*Do not mix oil with unleaded fuel.
* Do not over-fill fuel tank. Allow space for fuel
expansion.
* Do not smoke.
* Allow no naked flame or hot material in
refuelling area.
* Use only approved fuel containers and
funnels. Remember, fuel is a potential
hazard.
SAFETY PRECAUTIONS FOR RH918 USERS
OPERATING
INSTRUCTIONS
TRANSPORT
The depth control bar is to be placed in its
lowest possible position. This will provide
sufficient clearance to prevent damage to the
rotor assembly.
BEFORE USE
1) Ensure that all grass and weeds have been
cut as low as possible.
2) If the rotary hoe is to be used in clay or hard
ground conditions, it is recommended to
water the area thoroughly and allow
sufficient time for the earth to soften.
3) Police the area. Remove any
foreign objects from the area.
4) Identify and mark the location
of sprinkler heads, gas pipes, telephone
cables, etc.
“STAY ALERT – DON’T GET HURT”
SAFETY INSTRUCTIONS FOR RH918 USERS
OPERATING
INSTRUCTIONS
USE COMMON SENSE
AND PLENTY OF IT
TRANSPORT
BEFORE USE
1) DO NOT allow any person operate the
rotary hoe without first reading and
understanding the safety instructions and
operating instructions.
2) NEVER allow children to operate the rotary hoe.
8) ALWAYS make certain the Tyne Control Lever is
set at neutral while loading and unloading the
rotary hoe, or moving to and away from working area.
9) NEVER run the machine in reverse while the tynes
are rotating. Always move the tyne control lever to
“OFF” before reversing the wheels.
11) DO NOT leave the machine unattended while the
engine is running.
12) DO NOT overspeed the engine or alter the governor
settings. Excessive speed is dangerous and will
shorten engine life.
13) NEVER operate the rotary hoe in an
enclosed area. Engine exhaust contains
carbon monoxide, an odourless and
tasteless poison.
14) STOP the engine and disconnect the
spark plug lead(s) and allow engine to
cool before inspecting or performing
maintenance on the rotary hoe.
15)
1)
REFUELLING
* Shut off the engine. DO NOT REFUEL
AN ENGINE WHILE OPERATING!
* Allow engine to cool. Minimum 5 minutes
* USE UNLEADED FUEL ONLY.
Use clean, fresh unleaded fuel.
* Do not mix oil with unleaded fuel.
* Do not over-fill fuel tank. Allow space
for fuel expansion.
10) NEVER operate the unit without the safety
guards in place and in working order. Keep
the unit well maintained and in good
working order.
4) ALWAYS use the rotary
hoe in a well lighted area.
7) NEVER operate the rotary hoe when fatigued.
ALWAYS BE ALERT! If you get tired while
operating the rotary hoe, take a break. If you have
any type of physical or mental condition that may
be aggravated by strenuous work, consult with
your physician before you operate this equipment.
NEVER operate the rotary hoe under the influence
of medication, alcohol or drugs.
6) DO NOT allow other persons near the
rotary hoe. It is up to the operator to keep
bystanders and animals a minimum of 6
5) ALWAYS operate the rotary
hoe on level ground only.
Police the area before rotary
hoeing. Remove any foreign objects in the digging
area - bricks, rocks, wire and sticks. Locate and mark
any sprinkler heads, water pipes, gas lines,
electrical and telephone cables or any other hazard
either below or above ground.
3) ALWAYS wear protective clothing when operating
the rotary hoe. This includes, but is not limited to;
safety glasses, loose fitting gloves, steel capped
boots and hearing protection. NEVER wear loose
fitting clothing or jewellery when operating the
rotary hoe. Keep all clothing away from moving
parts. Items could become caught in the machine,
resulting in injury.
KNOW THE CONTROLS AND HOW TO STOP
THE ROTARY HOE QUICKLY IN AN EMERGENCY.
metres (20’) away from the machine while in
operation.
ALWAYS KEEP YOUR HANDS,
FEET AND BODY AWAY FROM
THE DIGGING ZONE WHILE
ENGINE IS RUNNING.
* Do not smoke.
* Allow no naked flame or hot material in refuelling area.
* Use only approved fuel containers and funnels.
Remember, fuel is a potential hazard .
Be sure Tyne Control Lever is set to “Neutral”
while loading and unloading the rotary hoe
and when moving to or from jobsite.
Ensure that all grass and weeds have been cut
as low as possible.
2) If the rotary hoe is to be used in clay or hard
ground conditions, it is recommended to water
the area thoroughly and allow sufficient time
for earth to soften.
3) Police the area. Remove any
foreign objects from the area.
4) Identify and mark the location of sprinkler heads,
gas pipes, telephone cables etc.
“The Right Way to Rent”
You alone know the operational demands and
special conditions affecting the equipment in
your situation and therefore assume the
responsibility for developing, carrying out, and
enforcing the safety concepts which apply to your
own operation to effect the greatest safety for
yourself andthe people around you.
OPERATOR
ZONE
Tyne Direction
Control Lever
DIGGING ZONE
Safety Clutch
Tyne Control Lever
Engine
Protection Bar
Engine
Free Wheel Hub
Wheel Speed
Control Lever
Depth
Control Bar
Engine
Exhaust
safety
IS EVERYBODY’S BUSINESS
...now
safety
IS EVERYBODY’S BUSINESS
...now
safety
IS EVERYBODY’S BUSINESS
...now
safety
IS EVERYBODY’S BUSINESS
...now
SAFETY INSTRUCTIONS FOR RH918 USERS
OPERATING
INSTRUCTIONS
USE COMMON SENSE
AND PLENTY OF IT
TRANSPORT
BEFORE USE
1) DO NOT allow any person operate the
rotary hoe without first reading and
understanding the safety instructions and
operating instructions.
2) NEVER allow children to operate the rotary hoe.
8) ALWAYS make certain the Tyne Control Lever is
set at neutral while loading and unloading the
rotary hoe, or moving to and away from working area.
9) NEVER run the machine in reverse while the tynes
are rotating. Always move the tyne control lever to
“OFF” before reversing the wheels.
11) DO NOT leave the machine unattended while the
engine is running.
12) DO NOT overspeed the engine or alter the governor
settings. Excessive speed is dangerous and will
shorten engine life.
13) NEVER operate the rotary hoe in an
enclosed area. Engine exhaust contains
carbon monoxide, an odourless and
tasteless poison.
14) STOP the engine and disconnect the
spark plug lead(s) and allow engine to
cool before inspecting or performing
maintenance on the rotary hoe.
15)
1)
REFUELLING
* Shut off the engine. DO NOT REFUEL
AN ENGINE WHILE OPERATING!
* Allow engine to cool. Minimum 5 minutes
* USE UNLEADED FUEL ONLY.
Use clean, fresh unleaded fuel.
* Do not mix oil with unleaded fuel.
* Do not over-fill fuel tank. Allow space
for fuel expansion.
10) NEVER operate the unit without the safety
guards in place and in working order. Keep
the unit well maintained and in good
working order.
4) ALWAYS use the rotary
hoe in a well lighted area.
7) NEVER operate the rotary hoe when fatigued.
ALWAYS BE ALERT! If you get tired while
operating the rotary hoe, take a break. If you have
any type of physical or mental condition that may
be aggravated by strenuous work, consult with
your physician before you operate this equipment.
NEVER operate the rotary hoe under the influence
of medication, alcohol or drugs.
6) DO NOT allow other persons near the
rotary hoe. It is up to the operator to keep
bystanders and animals a minimum of 6
5) ALWAYS operate the rotary
hoe on level ground only.
Police the area before rotary
hoeing. Remove any foreign objects in the digging
area - bricks, rocks, wire and sticks. Locate and mark
any sprinkler heads, water pipes, gas lines,
electrical and telephone cables or any other hazard
either below or above ground.
3) ALWAYS wear protective clothing when operating
the rotary hoe. This includes, but is not limited to;
safety glasses, loose fitting gloves, steel capped
boots and hearing protection. NEVER wear loose
fitting clothing or jewellery when operating the
rotary hoe. Keep all clothing away from moving
parts. Items could become caught in the machine,
resulting in injury.
KNOW THE CONTROLS AND HOW TO STOP
THE ROTARY HOE QUICKLY IN AN EMERGENCY.
metres (20’) away from the machine while in
operation.
ALWAYS KEEP YOUR HANDS,
FEET AND BODY AWAY FROM
THE DIGGING ZONE WHILE
ENGINE IS RUNNING.
* Do not smoke.
* Allow no naked flame or hot material in refuelling area.
* Use only approved fuel containers and funnels.
Remember, fuel is a potential hazard .
Be sure Tyne Control Lever is set to “Neutral”
while loading and unloading the rotary hoe
and when moving to or from jobsite.
Ensure that all grass and weeds have been cut
as low as possible.
2) If the rotary hoe is to be used in clay or hard
ground conditions, it is recommended to water
the area thoroughly and allow sufficient time
for earth to soften.
3) Police the area. Remove any
foreign objects from the area.
4) Identify and mark the location of sprinkler heads,
gas pipes, telephone cables etc.
“The Right Way to Rent”
You alone know the operational demands and
special conditions affecting the equipment in
your situation and therefore assume the
responsibility for developing, carrying out, and
enforcing the safety concepts which apply to your
own operation to effect the greatest safety for
yourself andthe people around you.
SAFETY INSTRUCTIONS FOR RH918 USERS
OPERATING
INSTRUCTIONS
USE COMMON SENSE
AND PLENTY OF IT
TRANSPORT
BEFORE USE
1) DO NOT allow any person operate the
rotary hoe without first reading and
understanding the safety instructions and
operating instructions.
2) NEVER allow children to operate the rotary hoe.
8) ALWAYS make certain the Tyne Control Lever is
set at neutral while loading and unloading the
rotary hoe, or moving to and away from working area.
9) NEVER run the machine in reverse while the tynes
are rotating. Always move the tyne control lever to
“OFF” before reversing the wheels.
11) DO NOT leave the machine unattended while the
engine is running.
12) DO NOT overspeed the engine or alter the governor
settings. Excessive speed is dangerous and will
shorten engine life.
13) NEVER operate the rotary hoe in an
enclosed area. Engine exhaust contains
carbon monoxide, an odourless and
tasteless poison.
14) STOP the engine and disconnect the
spark plug lead(s) and allow engine to
cool before inspecting or performing
maintenance on the rotary hoe.
15)
1)
REFUELLING
* Shut off the engine. DO NOT REFUEL
AN ENGINE WHILE OPERATING!
* Allow engine to cool. Minimum 5 minutes
* USE UNLEADED FUEL ONLY.
Use clean, fresh unleaded fuel.
* Do not mix oil with unleaded fuel.
* Do not over-fill fuel tank. Allow space
for fuel expansion.
10) NEVER operate the unit without the safety
guards in place and in working order. Keep
the unit well maintained and in good
working order.
4) ALWAYS use the rotary
hoe in a well lighted area.
7) NEVER operate the rotary hoe when fatigued.
ALWAYS BE ALERT! If you get tired while
operating the rotary hoe, take a break. If you have
any type of physical or mental condition that may
be aggravated by strenuous work, consult with
your physician before you operate this equipment.
NEVER operate the rotary hoe under the influence
of medication, alcohol or drugs.
6) DO NOT allow other persons near the
rotary hoe. It is up to the operator to keep
bystanders and animals a minimum of 6
5) ALWAYS operate the rotary
hoe on level ground only.
Police the area before rotary
hoeing. Remove any foreign objects in the digging
area - bricks, rocks, wire and sticks. Locate and mark
any sprinkler heads, water pipes, gas lines,
electrical and telephone cables or any other hazard
either below or above ground.
3) ALWAYS wear protective clothing when operating
the rotary hoe. This includes, but is not limited to;
safety glasses, loose fitting gloves, steel capped
boots and hearing protection. NEVER wear loose
fitting clothing or jewellery when operating the
rotary hoe. Keep all clothing away from moving
parts. Items could become caught in the machine,
resulting in injury.
KNOW THE CONTROLS AND HOW TO STOP
THE ROTARY HOE QUICKLY IN AN EMERGENCY.
metres (20’) away from the machine while in
operation.
ALWAYS KEEP YOUR HANDS,
FEET AND BODY AWAY FROM
THE DIGGING ZONE WHILE
ENGINE IS RUNNING.
* Do not smoke.
* Allow no naked flame or hot material in refuelling area.
* Use only approved fuel containers and funnels.
Remember, fuel is a potential hazard .
Be sure Tyne Control Lever is set to “Neutral”
while loading and unloading the rotary hoe
and when moving to or from jobsite.
Ensure that all grass and weeds have been cut
as low as possible.
2) If the rotary hoe is to be used in clay or hard
ground conditions, it is recommended to water
the area thoroughly and allow sufficient time
for earth to soften.
3) Police the area. Remove any
foreign objects from the area.
4) Identify and mark the location of sprinkler heads,
gas pipes, telephone cables etc.
“The Right Way to Rent”
You alone know the operational demands and
special conditions affecting the equipment in
your situation and therefore assume the
responsibility for developing, carrying out, and
enforcing the safety concepts which apply to your
own operation to effect the greatest safety for
yourself andthe people around you.
MAXIMUM ANGLE OF OPERATION
DO NOT EXCEED
15º ANGLE
