Red Sea MAX S-650 LED Installation guide

DE
EN
CH
FR
Red Sea MAX®S-650 LED
Complete Coral Reef Systems
Assembly Instructions Manual
Montageanleitungen
Notice de montage
安装指南
All manuals and user guides at all-guides.com
all-guides.com

All manuals and user guides at all-guides.com

MAX®S-650 LED
Assembly Instructions | Montageanleitungen
Notice de montage | 安装指南
Index
Frame | Rahmen
Structure | 框架 ...................................................................................... 5
Cabinet | Unterschrank
Meuble | 底柜 ........................................................................................ 17
Positioning | Ausrichtung
Emplacement | 摆放位置 ...................................................................... 27
Aquarium & Sump | Aquarium & Filtersumpf
Aquarium et decantation | 水族箱和过滤缸 ....................................... 29
Pumps & Skimmer | Pumpen & Abschäumer
Pompes et écumeur | 循环泵和蛋分 ................................................... 49
Lighting & Power | Beleuchtung und Strom
Eclairage et Power Center | 照明设备和电源中心 ............................. 53
All manuals and user guides at all-guides.com

Screw List | Liste der Schrauben | Liste des vis | 螺丝清单
Screw #
Schraube #
Vis #
螺丝 #
Dessin
Description
Beschreibung
Description
介绍
Pack
Paket
Sachet
包装
Quantity
Anzahl mfsdijf
Quantité
数量
S (V) 1
Torx Head
Rundkopf
Tête ronde
ST 5 x 12mm
A
Screw Pack
Schraubenpaket
Sachet de vis
螺丝包
3 X 50
S (V) 2
Countersunk
Senkkopf
Tête fraisée
ST 5 x 14mm
B
Screw Pack
Schraubenpaket
Sachet de vis
螺丝包
28
S (V) 3
Countersunk
Senkkopf
Tête fraisée
ST 4 x 35mm
B
Screw Pack
chraubenpaket
Sachet de vis
螺丝包
6
S (V) 8
Round Head
Rundkopf
Tête ronde
ST 3.5 x 30mm
B
Screw Pack
Schraubenpaket
Sachet de vis
螺丝包
3
S (V) 4
Countersunk
Senkkopf
Tête fraisée
M4 x 25mm
Cabinet Parts Pack
Paket für Unterschrank-Teile
Visserie meuble
木柜板材螺丝包
8
S (V) 6
Countersunk
Senkkopf
Tête fraisée
4 x 16mm
Hinge Set
Scharnier-Set
Charnières
门铰链螺丝包
36
S (V) 3
Countersunk
Senkkopf
Tête fraisée
ST 4 x 35mm
Pipe Clip Pack
Rohrclip-Paket
Fixation tuyaux
管夹螺丝包
3
S (V) 5
Countersunk
Senkkopf
Tête fraisée
ST 6 x 16mm
Pipe Clip Pack
Rohrclip-Paket
Fixation tuyaux
管夹螺丝包
2
S (V) 7
Countersunk
Senkkopf
Tête fraisée
ST 5 x 35mm
Internal Wall pack
Innenwandpaket
Cloison interne
内墙板螺丝包
4
All manuals and user guides at all-guides.com

5
MAX®S-650 LED
#1
Frame | Rahmen
Structure | 框架
All manuals and user guides at all-guides.com

6
MAX®S-650 LED #1 - Frame | Rahmen | Structure | 框架
MR
L
X 1
#2513
#2409-1
#2409-A1
#2409-A2
#2409-A3
#2515 #2514
X 1 X 1
C
E
F
D
X 1
X 1
X 2
X 2
Parts | Teile | Eléments | 部件
All manuals and user guides at all-guides.com
all-guides.com

7
MAX®S-650 LED
K
HJ
N
P
X 1
X 1
X 2
X 2
X 2
X 1
X2
#2410-1
#2410-A2
#2411-A1
#2401-A1
#2410-A1
#2410-A3
#2403-1
QW
All manuals and user guides at all-guides.com

8
MAX®S-650 LED #1 - Frame | Rahmen | Structure | 框架
L
L
M
M
R
R
J
N
N
H
K
K
F
D
F
P
Q
Q
W
W
E
E
C
S1 X 50 (X3) X 26 X 12X 1
All manuals and user guides at all-guides.com

9
MAX®S-650 LED
LL
J
J
N
N
N
N
KK
K
K
S1 X 14
M
2. 3.
M
S1 X 14
1.
N
L
J
N
K
K
N
All manuals and user guides at all-guides.com

10
MAX®S-650 LED #1 - Frame | Rahmen | Structure | 框架
S1 X 4
S1 X 8
4.
6. 7.
5.
Q
Q
Q
Q
Q
Q
Q
P
P
P
F
F
P
E
All manuals and user guides at all-guides.com

11
MAX®S-650 LED
Q
Q
N
N
J
P
F
E
S1 X 16
S1 X 14
L
L
K
K
F
D
M
M
R
8.
9.
All manuals and user guides at all-guides.com
all-guides.com

12
MAX®S-650 LED #1 - Frame | Rahmen | Structure | 框架
10.
S1 X 12
C
H
L
M
R
All manuals and user guides at all-guides.com

13
MAX®S-650 LED
11.
12.
S1 X 9
X 3
S1 X 4
C
H
L
L
M
M
R
R
W
W
All manuals and user guides at all-guides.com

14
MAX®S-650 LED #1 - Frame | Rahmen | Structure | 框架
13.
X 26
All manuals and user guides at all-guides.com

15
MAX®S-650 LED
X 4
X 8
14.
15.
All manuals and user guides at all-guides.com

All manuals and user guides at all-guides.com
all-guides.com

17
MAX®S-650 LED
#2
Cabinet | Unterschrank
Meuble | 底柜
All manuals and user guides at all-guides.com

18
MAX®S-650 LED #2 - Cabinet | Unterschrank | Meuble | 底柜
X 1 X 1
X 10 X 10
X 1
X 1
X 8
Parts | Teile | Eléments | 部件
All manuals and user guides at all-guides.com

19
MAX®S-650 LED
1.
2.
X 10
S1 X 20
10mm
All manuals and user guides at all-guides.com

20
MAX®S-650 LED #2 - Cabinet | Unterschrank | Meuble | 底柜
3.
X 3
S8 X 3
S1 X 3
4.
All manuals and user guides at all-guides.com
