Redline RDL-3000 Series User manual

70-00158-03-00 Proprietary Redline Communications © 2015 Page 1of 254 April 17, 2015
RDL-3000 Family
Universal Wireless Transport™
Ellipse Enterprise eLTE-MT Edge
RAS-Elite RAS-Extend Connect-IWS Connect-OW
LV / M / L Connect-OWS
User Manual
Software v3
1Important Notices.................................................................16
2Functional Description.........................................................22
3Web Interface........................................................................40
4CLI Interface........................................................................116
5Diagnostics & Troubleshooting.........................................145
6Security...............................................................................159
7Technical Reference...........................................................165
8Deployment Information.....................................................172
9Connect-OWS / IWS Serial Gateway..................................232

RDL-3000 FAMILY USER MANUAL
70-00158-03-00 Proprietary Redline Communications © 2015 Page 2of 254 April 17, 2015
Copyright Information
All rights reserved April 17, 2015. The information in this document is proprietary to
Redline Communications Inc. This document may not in whole or in part be copied,
reproduced, or reduced to any medium without prior consent, in writing, from Redline
Communications Incorporated.
Contact Information:
Redline Communications Inc.
302 Town Centre Blvd.
Markham, ON
Canada L3R 0E8
Web site:
www.rdlcom.com
Email:Inquiries: [e-mail]
Support: [e-mail]
Training: [e-mail]
Document Control:
70-00158-03-00-RDL-3000_Family_User_Manual_v3.00-20150417a.doc
Disclaimer
The statements, configurations, technical data, and recommendations in this document
are believed to be accurate and reliable, but are presented without express or implied
warranty. Additionally, Redline makes no representations or warranties, either expressed
or implied, regarding the contents of this product. Redline Communications shall not be
liable for any misuse regarding this product. The information in this document is subject
to change without notice. No part of this document shall be deemed to be part of any
warranty or contract unless specifically referenced to be part of such warranty or
contract within this document.
Software Versions
RDL-3000 family products are designed to address a wide base of applications and
operate in extreme environmental requirements. To facilitate ease of use by the
operator, a common user interface is provided across all RDL-3000 family platforms:
Ellipse, Edge, RAS, Enterprise, eLTE-MT, Connect-OW and Connect series.
This manual describes operation using the RDL-3000 software release v3.00 and
Connect serial gateway V1.xx software releases. This manual may include features that
are different or unavailable in previous software releases.
Some RDL-3000 features are controlled by options keys ( ) and are available only on
specific models and where allowed by regional regulations. Refer to the individual
product Release Notes for the latest features, information about the required software
and the availability of features.

RDL-3000 FAMILY USER MANUAL
70-00158-03-00 Proprietary Redline Communications © 2015 Page 3of 254 April 17, 2015
Revision Log
Date
Item
Description of Change(s)
20130707
Many
Passive and active GPS antenna support:
3.5.1: Web control 'GPS Antenna Type'
4.3: CLI control 'gpsantenna active | passive'
Rescan no longer started automatically when saving configuration.
4.3: Added CLI support for forcing rescan (apply rescan).
DHCP discovery behavior modified
3.5.1: DHCP Enable description updated.
20130709
Section 3.5.4
Updated table 19: Polarization of Systems with Integrated Antennas to include 2 GHz
systems.
20130716
3.6.1
3.6.3
4.3
IMPORTANT NOTICE:
Changing Service CIR / PIR for STID Link Templates
Failure to follow proper procedures when changing CIR / PIR settings on services
associated with STID link templates will cause LOSS OF COMMUNICATIONS to all
subscribers on the sector controller.
To modify PIR / CIR settings on services for STID links (templates), use only the
approved methods described in the Section 7.1: Modifying CIR / PIR Settings for Service
on STID Link Templates.
Added new section 7.1 Modifying CIR / PIR Settings for Services on STID Links.
20130730
many
2.3.4 Pass through mode - removed Q-in-Q example
Entire manual - Inserted branding in all illustrations.
20130813
3.5.6
3.4.7
3.5.4
4.2
Clarify that SC MAC address is updated only if new address is entered in the correct format.
Add Long Reset message to system log
Add Target RSSI Enabled and ATPC Level fields to sector controller
Correct syntax of CLI command 'set optionskey'.
Add sector controller CLI commands targetrssilevel and targetrssimode
20130903
3.7.1
Spectrum Sweep: Step size is 2.5 MHz for all 5 GHz systems. Use a maximum of 500
acquisitions for each spectrum sweep.
20130904
3.3
Remove reference to LED blinking when current modulation/coding is too low to meet the
minimum required UBR.
20130924
4.3
Add CLI command 'set atpcss <off|on>' to disable or enable (default) ATPC on individual
subscribers. Includes reference note in field Target RSSI Enabled (Web section 3.5.4
Wireless: Advanced Wireless Configuration).
20131002
All
Change 'RDL-3000 SC' to 'Ellipse' and 'RDL-3000 SU' to 'Edge'.
The Ellipse sector controller and Edge remote terminal are the latest generation systems of
RDL-3000 family.
20131024
2.2
8.1
Table 7: Clarify identification for RDL-3000 SC/SU and Ellipse/Edge
Region 11: Updated maximum power levels
Region 16: Default frequency is 2310 MHz
20131031
2.2
Add Connect-OW
20131111
1.3-4, 8.6-7
Update FCC and IC regulatory notice information
20131118
3.5.3
Add reference to SNMPv3 context name 'contextPMP'
20131216
7
Add regions 25, 26 and 27
20140220
7
3.6.2, 4.3
Add regions 20-24, adjust max power for region 13 to 28 dBm.
Add note: reboot required after changing SS-to-SS mode (hairpinning).
20140306
7
Update region 9 to include 3675-3700 MHz.
20140319
2
Update RDL-3000 SU/Edge S/N prefix, add eLTE-MT Zone 2 units
20140326
2, 3
Add table of Redline products (2.1), Noise Level reading (3.4), Network Topology List (3.5).
20141006
General
Coverage for Update 9 features.
20141126
3.5.1
8.1
LLDP setting in System Configuration screen
Add Region 29: Argentina 3.4-3.7 GHz, Add 5.1 GHz to regions 6 & 7
20141204
9
Add Connect Serial Gateway information. CLI commands: encautomode, webtimeout
20150113
7.6
Update description of auto frequency scanning
20150119
8.7
Add FCC RF power tables for 5.2 GHz
20150204
3.5.4,
Updated Auto Scan information to use center frequency (Update 10)
20150211
3.4.2
Update synchronization references re fixed frame operation
20150217
8.6.7
Update RSS-192 & RSS-197 description and power settings table.
20150311
Many
Updates for v3.00: new channel sizes, ECDSA authentication, Rapid Path, 256QAM, 250
KHz frequency step for all radios, UBR table.

RDL-3000 FAMILY USER MANUAL
70-00158-03-00 Proprietary Redline Communications © 2015 Page 4of 254 April 17, 2015
TABLE OF CONTENTS
1Important Notices.................................................................16
1.1 Service & Safety...............................................................................................16
General Warnings........................................................................................16
Safety Warnings...........................................................................................16
Warning Symbols.........................................................................................17
1.2 Installation Safety............................................................................................17
Professional Installation / Installations Professionnel ...................................17
Safety Precautions.......................................................................................17
Electrocution Hazard / Risque D’électrocution..............................................17
Radio Frequency Safety / Sécurité des Fréquences Radio ..........................18
Personal Safety............................................................................................18
Electrical Safety ...........................................................................................18
Electrical Safety Compliance / Conformité à la Sécurité Electrique ..............18
UL Information .............................................................................................19
Lightning Protection / Protection Contre la Foudre.......................................19
1.3 WEEE Product Return Process.......................................................................20
1.4 Service & Warranty Information......................................................................21
2Functional Description.........................................................22
2.1 Overview...........................................................................................................22
2.2 Unit Type Identification ...................................................................................22
2.3 PMP Mode.........................................................................................................25
Classification................................................................................................25
Links and Services.......................................................................................25
2.3.1 Wireless Links.................................................................................................26
2.3.2 Services and Service Groups..........................................................................27
Overview......................................................................................................27
Services.......................................................................................................27
Service Groups............................................................................................29
2.3.3 Setting Wireless Rates....................................................................................30
2.3.4 Pass through Mode.........................................................................................31
2.3.5 Subscriber-to-Subscriber Traffic......................................................................32
2.3.6 VLAN Tagged Management............................................................................33
2.3.7 PMP Configurations........................................................................................34
VLAN Services.............................................................................................34
Transparent LAN Services (TLS) .................................................................37
2.4 PTP Mode .........................................................................................................39
3Web Interface........................................................................40
3.1 System Menus..................................................................................................40
3.2 Network Connection........................................................................................41
3.3 Dashboard Display ..........................................................................................42

RDL-3000 FAMILY USER MANUAL
70-00158-03-00 Proprietary Redline Communications © 2015 Page 5of 254 April 17, 2015
General Information .....................................................................................42
3.4 Status Screens.................................................................................................44
3.4.1 General Information ........................................................................................44
System.........................................................................................................44
Ethernet.......................................................................................................45
3.4.2 System Status.................................................................................................46
Controls .......................................................................................................46
Wireless System ..........................................................................................46
Wireless Summary.......................................................................................50
Wireless Ethernet Statistics..........................................................................50
Ethernet Port Statistics.................................................................................50
3.4.3 Subscriber Links Summary .............................................................................51
Advanced Link Summary Statistics (RAS-Elite SS only)...............................52
3.4.4 Subscriber Link Status....................................................................................53
General........................................................................................................53
Wireless.......................................................................................................54
Wireless Packets..........................................................................................54
3.4.5 Services Summary (SS only) ..........................................................................55
3.4.6 WSDB Status..................................................................................................56
WSDB Status...............................................................................................57
Channel List.................................................................................................57
3.4.7 System Messages (Log) .................................................................................58
3.5 Configuration Screens.....................................................................................61
3.5.1 System............................................................................................................61
System Identification....................................................................................62
Basic Ethernet Configuration........................................................................62
Advanced Ethernet Configuration.................................................................65
3.5.2 RADIUS..........................................................................................................66
3.5.3 SNMP .............................................................................................................68
SNMP Communities.....................................................................................68
SNMP v2: Trap Destination Settings............................................................69
SNMP v3: Trap Destination Settings............................................................70
SNMP Trap Configuration............................................................................71
3.5.4 Wireless..........................................................................................................72
Basic Wireless Configuration........................................................................73
Advanced Wireless Configuration ................................................................76
Redundancy Configuration: Redundant Base Station (1+1) Option..............79
Frequency Management Screen..................................................................80
3.5.5 WSDB Configuration/Control...........................................................................83
Registration Information...............................................................................84
3.5.6 Security...........................................................................................................85
3.5.7 Network Topology...........................................................................................87
Network Topology File Format .....................................................................88
3.5.8 Network Topology File Formats.......................................................................89
Text Version.................................................................................................89
XML Version ................................................................................................89
3.6 Provisioning Screens ......................................................................................91

RDL-3000 FAMILY USER MANUAL
70-00158-03-00 Proprietary Redline Communications © 2015 Page 6of 254 April 17, 2015
3.6.1 Subscriber Links .............................................................................................91
Subscriber Link Configuration ......................................................................93
3.6.2 Service Groups...............................................................................................98
Service Group Status...................................................................................99
Service Group Configuration......................................................................100
3.6.3 Subscriber Services......................................................................................102
Subscriber Service Status..........................................................................102
Subscriber Service Configuration...............................................................103
3.7 Utilities Screens.............................................................................................105
3.7.1 Spectrum Sweep...........................................................................................105
Spectrum Sweep Configuration..................................................................105
Spectrum Sweep Chart..............................................................................105
Performing a Sweep...................................................................................105
3.7.2 Users Management.......................................................................................107
System Users.............................................................................................107
Manage User Settings................................................................................107
New User...................................................................................................108
Main Menu Access Permissions.................................................................109
3.7.3 Product Options............................................................................................111
3.8 Options Keyed Features................................................................................112
3.8.1 Antenna Alignment Screen............................................................................113
3.8.2 Firmware Management Screen.....................................................................114
Firmware Version.......................................................................................114
Firmware Upgrade .....................................................................................114
4CLI Interface........................................................................116
4.1 Quick Reference.............................................................................................116
4.2 Telnet Access.................................................................................................117
4.3 Command Set.................................................................................................117
apply..........................................................................................................117
arp..............................................................................................................117
chgver........................................................................................................118
clear...........................................................................................................118
del..............................................................................................................118
disable .......................................................................................................119
enable........................................................................................................119
freq.............................................................................................................119
genecckeys................................................................................................120
generate.....................................................................................................120
get..............................................................................................................120
load............................................................................................................124
logout.........................................................................................................125
new............................................................................................................125
ping............................................................................................................126
reboot.........................................................................................................126
reset...........................................................................................................126

RDL-3000 FAMILY USER MANUAL
70-00158-03-00 Proprietary Redline Communications © 2015 Page 7of 254 April 17, 2015
save...........................................................................................................126
script..........................................................................................................127
set..............................................................................................................127
show ..........................................................................................................140
snmpcommunity.........................................................................................141
snmptrap....................................................................................................142
spectrum....................................................................................................143
upgrade......................................................................................................143
user............................................................................................................143
whoami ......................................................................................................144
5Diagnostics & Troubleshooting.........................................145
5.1 Interface Connection Issues .........................................................................145
5.2 Testing Configuration Changes....................................................................145
5.3 Status Code Definitions.................................................................................146
5.4 Working with System Parameters.................................................................147
Parameters Overview.................................................................................147
Restore Factory Configuration....................................................................148
Factory Default Settings.............................................................................149
5.5 Recover from Lost Password or IP...............................................................151
5.5.1 Long Reset ...................................................................................................151
Long Reset Using Telnet............................................................................151
Long Reset - Restore Default Passwords Only ..........................................152
5.5.2 DHCP - Recover Lost IP Address (Link-Local IP)..........................................153
5.6 Classification: Services and Service Groups ..............................................155
Packet Classification at the Sector Controller.............................................155
Packet Classification at the Subscriber ......................................................157
VLAN (802.1Q) Field Definitions ................................................................158
6Security...............................................................................159
6.1 Overview.........................................................................................................159
Authentication............................................................................................159
Management Security................................................................................159
Data Security .............................................................................................159
Physical Security........................................................................................159
Important Security Guidelines: ...................................................................159
6.2 AES Encryption..............................................................................................160
Out of Box Operation .................................................................................160
Enabling AES.............................................................................................160
6.3 Wireless Authentication ................................................................................160
Out-of-Box Operation.................................................................................160
Enabling Authentication..............................................................................160
6.4 SSH for Secure CLI........................................................................................161
Out-of-Box Operation.................................................................................161
Enabling SSH.............................................................................................162

RDL-3000 FAMILY USER MANUAL
70-00158-03-00 Proprietary Redline Communications © 2015 Page 8of 254 April 17, 2015
6.5 HTTPS (SSL) for Secure Web........................................................................163
Out-of-Box Operation.................................................................................163
Enabling HTTPS (SSL) ..............................................................................163
7Technical Reference...........................................................165
7.1 Modify CIR/PIR Settings for Services on STID Links...................................165
7.1.1 Modify STID CIR / PIR Silently (No Reboot)..................................................165
7.1.2 Modify CIR / PIR Settings in a Maintenance Window....................................166
7.2 ID Mapping .....................................................................................................166
7.3 Radio Types ...................................................................................................166
7.4 Uncoded Burst Rates.....................................................................................167
7.5 Frequency Scanning Modes..........................................................................168
7.6 Auto Frequency Scan....................................................................................169
7.7 Scan Threshold Trigger.................................................................................169
7.8 Link Layer Discovery Protocol (LLDP) Support...........................................170
7.9 Typical Link Recovery Times........................................................................171
8Deployment Information.....................................................172
8.1 Regional Codes..............................................................................................172
8.2 Regulatory Notice: Deployment in Mexico...................................................176
8.3 Operation in 480 - 690 MHz Bands................................................................177
8.3.1 Deployment in the United States...................................................................177
FCC Notices...............................................................................................178
Antenna + Power Settings..........................................................................179
8.3.2 Deployment in Canada..................................................................................179
Industry Canada Notices............................................................................180
Antenna + Power Settings..........................................................................182
8.4 Operation in 2305 - 2360 & 2400 - 2483.5 MHz Bands..................................183
8.4.1 Deployment in Canada..................................................................................184
Industry Canada Notices............................................................................184
Antenna + Power Settings..........................................................................186
8.5 Operation in 3450 - 3700 MHz Bands............................................................191
8.6 Deployment in the United States ..................................................................191
8.6.1 Frequency Bands..........................................................................................191
8.6.2 Antenna Use and Transmit Power.................................................................191
8.6.3 Certified Antennas ........................................................................................191
8.6.4 Operation in the 3675-3700 MHz Band.........................................................192
8.6.5 FCC Notices .................................................................................................196
8.6.6 Deployment in Canada..................................................................................197
Industry Canada Notices............................................................................197
8.6.7 Antenna + Power Settings.............................................................................198
8.7 Operation in 4900 - 5800 MHz Bands............................................................199
8.7.1 Deployment in Brazil.....................................................................................199

RDL-3000 FAMILY USER MANUAL
70-00158-03-00 Proprietary Redline Communications © 2015 Page 9of 254 April 17, 2015
8.7.2 Deployment in the United States...................................................................199
FCC Notices...............................................................................................199
Antenna + Power Settings..........................................................................202
8.7.3 Deployment in Canada..................................................................................218
Industry Canada Notices............................................................................218
Antenna + Power Settings..........................................................................219
9Connect-OWS / IWS Serial Gateway..................................232
9.1 System Menus................................................................................................232
9.2 Network Connection......................................................................................233
Ethernet Connection ..................................................................................234
Serial Connection.......................................................................................234
9.3 Dashboard Display ........................................................................................235
General Information ...................................................................................235
9.4 Status Screen.................................................................................................236
9.4.1 General Information ......................................................................................236
System Information....................................................................................236
Network Settings........................................................................................236
9.4.2 Trace Log......................................................................................................237
9.5 Configuration Screens...................................................................................238
9.5.1 System Settings............................................................................................238
System Information....................................................................................238
Network......................................................................................................238
Syslog Settings..........................................................................................238
9.5.2 Trace Settings...............................................................................................239
9.5.3 Radio Management.......................................................................................240
Radio Information.......................................................................................240
Radio Management Settings......................................................................240
9.5.4 Gateway Settings..........................................................................................241
Serial Gateway [1,2] Settings.....................................................................241
Serial Gateway [1,2] Data Packing.............................................................241
Serial Gateway [1,2] TCP Server Settings..................................................242
9.5.5 Serial Port Settings .......................................................................................243
DATA [1,2] Port Settings............................................................................243
9.5.6 Firmware Management.................................................................................244
Firmware Server Configuration...................................................................244
Firmware Images .......................................................................................244
Firmware Upload........................................................................................244
9.5.7 Change Password.........................................................................................246
Change Password......................................................................................246
9.6 Serial Gateway CLI Interface.........................................................................247
9.6.1 Quick Reference...........................................................................................247
9.6.2 Command Set...............................................................................................248
apply..........................................................................................................248
chgver........................................................................................................248

RDL-3000 FAMILY USER MANUAL
70-00158-03-00 Proprietary Redline Communications © 2015 Page 10 of 254 April 17, 2015
get <dnsip1 | dnsip2 | gateway | ipaddr | mac | netmask | radio | sysuptime |
swver>248 LIST OF TABLES
Table 1: Notice - Electrical Safety Specifications...........................................................19
Table 2: Avis - Spécifications de sécurité électrique......................................................19
Table 3: Functional Desc. - Redline RDL-3000 Product Family Applications .................22
Table 4: Functional Desc.- System Identification...........................................................23
Table 5: Web - Operation - Traffic Classification............................................................27
Table 6: Web - Operation - Wireless Rates ...................................................................30
Table 7: Web - Sector Controller and Subscriber Menus...............................................40
Table 8: Web - Wireless LED Indications.......................................................................42
Table 9: Web - Ethernet LED Indications.......................................................................43
Table 10: Web - System Log Messages........................................................................58
Table 11: Web - Required FreeRadius Files..................................................................67
Table 12: Web - Radio Enable - RF Port Settings..........................................................79
Table 13: Web - Configure - Network Topology List Fields............................................88
Table 14: Web - RF Mode - RF Port Settings for Wireless Link .....................................97
Table 15: Web - Screens and User Access.................................................................109
Table 16: Web - RDL-3000 ID Ranges........................................................................112
Table 17: Web - Defaults With No Options Key Installed.............................................112
Table 18: CLI - Command Summary...........................................................................116
Table 19: CLI - Root Mode Commands .......................................................................117
Table 20: Diag. - Web Interface Diagnostics................................................................145
Table 21: Diag. - Status Code Bits (Binary/Hex)..........................................................146
Table 22: Diag. - Status Codes....................................................................................146
Table 23: Diag. - Parameters Overview.......................................................................147
Table 24: Diag. - Factory Default Settings...................................................................149
Table 25: Diag. - Calculating Local Link IP Addresses.................................................153
Table 26: Diag. - Classification: Packet Received on SC Ethernet Port.......................155
Table 27: Diag. - Classification: Packet Received on SC Wireless Interface................156
Table 28: Diag. - Classification: Packet Received on SS Ethernet Port .......................157
Table 29: Diag. - Classification: Packet Received on SS Wireless Interface................157
Table 30: Diag. - 802.1Q Tag Field..............................................................................158
Table 31: Ref. - RDL-3000 ID Ranges.........................................................................166
Table 32: Ref. -RDL-3000 Radio Types.......................................................................166
Table 33: Ref. - Uncoded Burst Rates (UBR) MIMO A CP = 1/4..................................167
Table 34: Ref. - Uncoded Burst Rates (UBR) MIMO B CP = 1/4..................................167
Table 35: Ref. - Uncoded Burst Rates (UBR) MIMO A CP = 1/8..................................167
Table 36: Ref. - Uncoded Burst Rates (UBR) MIMO A CP = 1/8..................................167
Table 37: Ref. - 802.1Q Tag Field ...............................................................................168
Table 38: Ref. –Redline LLDP Data Unit (Frame) TLVs..............................................170
Table 39: Ref. - Redline-Specific LLDP TLV................................................................170
Table 40: Ref. - Regional Identification Codes.............................................................172
Table 41: 470-698 MHz Approved Antennas...............................................................177
Table 42: 470-690 MHz White Space Channel Definitions for USA.............................178
Table 43: 470-690 MHz Transmit Power in the United States......................................179

RDL-3000 FAMILY USER MANUAL
70-00158-03-00 Proprietary Redline Communications © 2015 Page 11 of 254 April 17, 2015
Table 44: 470-690 MHz RRBS Channel Definitions for Canada..................................179
Table 45: 470-698 MHz Recommended Safe Distances in Canada ............................180
Table 46: 470-698 MHz distances de sécurité recommandées dans Canada..............181
Table 47: 470-690 MHz Sector controller Transmit Power for Canada........................182
Table 48: 470-690 MHz Wireless Terminal Transmit Power for Canada......................182
Table 49: 2305-2360 MHz Approved Antennas...........................................................183
Table 50: 2305-2360 MHz Recommended Safe Distances in Canada.........................184
Table 51: 2305-2360 MHz distances de sécurité recommandées dans Canada..........185
Table 52: 2305-2320 MHz: RF Power & EIRP: 5 MHz Chan. & 14.5 dBi ant. for IC.....186
Table 53: 2305-2320 MHz: RF Power & EIRP: 5 MHz Chan. & 15 dBi ant. for IC........186
Table 54: 2305-2320 MHz: RF Power & EIRP: 5 MHz Chan. & 16 dBi ant. for IC........187
Table 55: 2305-2320 MHz: RF Power & EIRP: 5 MHz Chan. & 17 dBi ant. for IC........187
Table 56: 2305-2320 MHz: RF Power & EIRP: 10 MHz Chan. & 14.5 dBi ant. for IC...188
Table 57: 2305-2320 MHz: RF Power & EIRP: 10 MHz Chan. & 15 dBi ant. for IC......188
Table 58: 2305-2320 MHz: RF Power & EIRP: 10 MHz Chan. & 16 dBi ant. for IC......188
Table 59: 2305-2320 MHz: RF Power & EIRP: 10 MHz Chan. & 17 dBi ant. for IC......189
Table 60: 2400-2483.5 MHz: RF Power & EIRP: 5 MHz Chan. & 14.5 dBi ant. for IC..189
Table 61: 2400-2483.5 MHz: RF Power & EIRP: 5 MHz Chan. & 17 dBi ant. for IC.....189
Table 62: 2400-2483.5 MHz: RF Power & EIRP: 10 MHz Chan. & 14.5 dBi ant. for IC189
Table 63: 2400-2483.5 MHz: RF Power & EIRP: 10 MHz Chan. & 17 dBi ant. for IC...189
Table 64: 2400-2483.5 MHz: RF Power & EIRP: 20 MHz Chan. & 14.5 dBi ant. for IC189
Table 65: 2400-2483.5 MHz: RF Power & EIRP: 20 MHz Chan. & 17 dBi ant. for IC...190
Table 66: FCC - Approved Antennas...........................................................................191
Table 67: FCC - RDL-3000 EIRP Measurement Results for 5 MHz.............................192
Table 68: FCC - RDL-3000 EIRP PSD Measurement Results for 5 MHz.....................193
Table 69: FCC - RDL-3000 EIRP Measurement Results for 10 MHz...........................194
Table 70: FCC - RDL-3000 EIRP PSD Measurement Results for 10 MHz...................195
Table 71: FCC - RDL-3000 Recommended Safe Distances........................................196
Table 72: 3450-2675 MHz Recommended Safe Distances in Canada.........................197
Table 73: 3450-2675 MHz distances de sécurité recommandées dans Canada..........198
Table 74: 3650-3675 MHz Power & EIRP Results for Canada ....................................198
Table 75: 4900-5875 MHz Approved Antennas...........................................................199
Table 76: 4900-5875 MHz Recommended Safe Distances for USA............................199
Table 77: 4900-5875 MHz TDWR System Locations in USA.......................................201
Table 78: 4900 MHz: RF Power & EIRP: 5 MHz Chan. & 10 dBi Ant. for FCC.............203
Table 79: 4900 MHz: RF Power & EIRP: 5 MHz Chan. & 19 dBi Ant. for FCC.............203
Table 80: 4900 MHz: RF Power & EIRP: 5 MHz Chan. & 32 dBi Ant. for FCC.............203
Table 81: 4900 MHz: RF Power & EIRP: 10 MHz Chan. & 10 dBi Ant. for FCC...........204
Table 82: 4900 MHz: RF Power & EIRP: 10 MHz Chan. & 19 dBi Ant. for FCC...........204
Table 83: 4900 MHz: RF Power & EIRP: 10 MHz Chan. & 32 dBi Ant. for FCC...........204
Table 84: 4900 MHz: RF Power & EIRP: 20 MHz Chan. & 10 dBi Ant. for FCC...........205
Table 85: 4900 MHz: RF Power & EIRP: 20 MHz Chan. & 19 dBi Ant. for FCC...........205
Table 86: 4900 MHz: RF Power & EIRP: 20 MHz Chan. & 32 dBi Ant. for FCC...........205
Table 87: 5200 MHz: RF Power & EIRP: 5 MHz Channel 10 dBi Antenna for FCC.....206
Table 88: 5200 MHz: RF Power & EIRP: 5 MHz Channel 19 dBi Antenna for FCC.....206
Table 89: 5200 MHz: RF Power & EIRP: 5 MHz Channel 29 dBi Antenna for FCC.....206
Table 90: 5200 MHz: RF Power & EIRP: 10 MHz Channel 10 dBi Antenna for FCC ...207
Table 91: 5200 MHz: RF Power & EIRP: 10 MHz Channel 19 dBi Antenna for FCC ...207

RDL-3000 FAMILY USER MANUAL
70-00158-03-00 Proprietary Redline Communications © 2015 Page 12 of 254 April 17, 2015
Table 92: 5200 MHz: RF Power & EIRP: 10 MHz Channel 29 dBi Antenna for FCC ...207
Table 93: 5200 MHz: RF Power & EIRP: 20 MHz Channel 10 dBi Antenna for FCC ...208
Table 94: 5200 MHz: RF Power & EIRP: 20 MHz Channel 19 dBi Antenna for FCC ...208
Table 95: 5200 MHz: RF Power & EIRP: 20 MHz Channel 29 dBi Antenna for FCC ...208
Table 96: 5300 MHz: RF Power: 5 MHz Chan. & 10 dBi Antenna for FCC..................209
Table 97: 5300 MHz: RF Power: 5 MHz Chan. & 19 dBi Ant. for FCC.........................209
Table 98: 5300 MHz: RF Power: 5 MHz Chan. & 32 dBi Ant. for FCC.........................209
Table 99: 5300 MHz: RF Power: 10 MHz Chan. & 10 dBi Ant. for FCC.......................210
Table 100: 5300 MHz: RF Power: 10 MHz Chan. & 19 dBi Ant. for FCC.....................210
Table 101: 5300 MHz: RF Power: 10 MHz Chan. & 32 dBi Ant. for FCC.....................210
Table 102: 5300 MHz: RF Power: 20 MHz Chan. & 10 dBi Ant. for FCC.....................211
Table 103: 5300 MHz: RF Power: 20 MHz Chan. & 19 dBi Ant. for FCC.....................211
Table 104: 5300 MHz: RF Power: 20 MHz Chan. & 32 dBi Ant. for FCC.....................211
Table 105: 5400 MHz: RF Power: 5 MHz Chan. & 10 dBi Ant. for FCC.......................212
Table 106: 5400 MHz: RF Power: 5 MHz Chan. & 19 dBi Ant. for FCC.......................212
Table 107: 5400 MHz: RF Power: 5 MHz Chan. & 32 dBi Ant. for FCC.......................212
Table 108: 5400 MHz: RF Power: 10 MHz Chan. & 10 dBi Ant. for FCC.....................213
Table 109: 5400 MHz: RF Power: 10 MHz Chan. & 19 dBi Ant. for FCC.....................213
Table 110: 5400 MHz: RF Power: 10 MHz Chan. & 32 dBi Ant. for FCC.....................213
Table 111: 5400 MHz: RF Power: 20 MHz Chan. & 10 dBi Ant. for FCC.....................214
Table 112: 5400 MHz: RF Power: 20 MHz Chan. & 19 dBi Ant. for FCC.....................214
Table 113: 5400 MHz: RF Power: 20 MHz Chan. & 32 dBi Ant. for FCC.....................214
Table 114: 5800 MHz: RF Power & EIRP: 5 MHz Chan. & 10 dBi Ant. for FCC...........215
Table 115: 5800 MHz: RF Power & EIRP: 5 MHz Chan. & 19 dBi Ant. for FCC...........215
Table 116: 5800 MHz: RF Power & EIRP: 5 MHz Chan. & 32 dBi Ant. for FCC...........215
Table 117: 5800 MHz: RF Power & EIRP: 10 MHz Chan. & 10 dBi Ant. for FCC.........216
Table 118: 5800 MHz: RF Power & EIRP: 10 MHz Chan. & 19 dBi Ant. for FCC.........216
Table 119: 5800 MHz: RF Power & EIRP: 10 MHz Chan. & 32 dBi Ant. for FCC.........216
Table 120: 5800 MHz: RF Power & EIRP: 20 MHz Chan. & 10 dBi Ant. for FCC.........217
Table 121: 5800 MHz: RF Power & EIRP: 20 MHz Chan. & 19 dBi Ant. for FCC.........217
Table 122: 5800 MHz: RF Power & EIRP: 20 MHz Chan. & 32 dBi Ant. for FCC.........217
Table 123: 4900-5875 MHz Recommended Safe Distances in Canada.......................218
Table 124: 4900-5875 MHz distances de sécurité recommandées dans Canada........219
Table 125: 4900 MHz: RF Power & EIRP: 5 MHz Chan. & 10 dBi Ant. for IC ..............220
Table 126: 4900 MHz: RF Power & EIRP: 5 MHz Chan. & 19 dBi Ant. for IC ..............220
Table 127: 4900 MHz: RF Power & EIRP: 5 MHz Chan. & 32 dBi Ant. for IC ..............220
Table 128: 4900 MHz: RF Power & EIRP: 10 MHz Chan. & 10 dBi Ant. for IC ............221
Table 129: 4900 MHz: RF Power & EIRP: 10 MHz Chan. & 19 dBi Ant. for IC ............221
Table 130: 4900 MHz: RF Power & EIRP: 10 MHz Chan. & 32 dBi Ant. for IC ............221
Table 131: 4900 MHz: RF Power & EIRP: 20 MHz Chan. & 10 dBi Ant. for IC ............222
Table 132: 4900 MHz: RF Power & EIRP: 20 MHz Chan. & 19 dBi Ant. for IC ............222
Table 133: 4900 MHz: RF Power & EIRP: 20 MHz Chan. & 32 dBi Ant. for IC ............222
Table 134: 5300 MHz: RF Power & EIRP: 5 MHz Chan. & 10 dBi Ant. for IC ..............223
Table 135: 5300 MHz: RF Power & EIRP: 5 MHz Chan. & 19 dBi Ant. for IC ..............223
Table 136: 5300 MHz: RF Power & EIRP: 5 MHz Chan. & 32 dBi Ant. for IC ..............223
Table 137: 5300 MHz: RF Power & EIRP: 10 MHz Chan. & 10 dBi Ant. for IC ............224
Table 138: 5300 MHz: RF Power & EIRP: 10 MHz Chan. & 19 dBi Ant. for IC ............224
Table 139: 5300 MHz: RF Power & EIRP: 10 MHz Chan. & 32 dBi Ant. for IC ............224

RDL-3000 FAMILY USER MANUAL
70-00158-03-00 Proprietary Redline Communications © 2015 Page 13 of 254 April 17, 2015
Table 140: 5300 MHz: RF Power & EIRP: 20 MHz Chan. & 10 dBi Ant. for IC ............225
Table 141: 5300 MHz: RF Power & EIRP: 20 MHz Chan. & 19 dBi Ant. for IC ............225
Table 142: 5300 MHz: RF Power & EIRP: 20 MHz Chan. & 32 dBi Ant. for IC ............225
Table 143: 5400 MHz: RF Power & EIRP: 5 MHz Chan. & 10 dBi Ant. for IC ..............226
Table 144: 5400 MHz: RF Power & EIRP: 5 MHz Chan. & 19 dBi Ant. for IC ..............226
Table 145: 5400 MHz: RF Power & EIRP: 5 MHz Chan. & 32 dBi Ant. for IC ..............226
Table 146: 5400 MHz: RF Power & EIRP: 10 MHz Chan. & 10 dBi Ant. for IC ............227
Table 147: 5400 MHz: RF Power & EIRP: 10 MHz Chan. & 19 dBi Ant. for IC ............227
Table 148: 5400 MHz: RF Power & EIRP: 10 MHz Chan. & 32 dBi Ant. for IC ............227
Table 149: 5400 MHz: RF Power & EIRP: 20 MHz Chan. & 10 dBi Ant. for IC ............228
Table 150: 5400 MHz: RF Power & EIRP: 20 MHz Chan. & 19 dBi Ant. for IC ............228
Table 151: 5400 MHz: RF Power & EIRP: 20 MHz Chan. & 32 dBi Ant. for IC ............228
Table 152: 5800 MHz: RF Power & EIRP: 5 MHz Chan. & 10 dBi Ant. for IC ..............229
Table 153: 5800 MHz: RF Power & EIRP: 5 MHz Chan. & 19 dBi Ant. for IC ..............229
Table 154: 5800 MHz: RF Power & EIRP: 5 MHz Chan. & 32 dBi Ant. for IC ..............229
Table 155: 5800 MHz: RF Power & EIRP: 10 MHz Chan. & 10 dBi Ant. for IC ............230
Table 156: 5800 MHz: RF Power & EIRP: 10 MHz Chan. & 19 dBi Ant. for IC ............230
Table 157: 5800 MHz: RF Power & EIRP: 10 MHz Chan. & 32 dBi Ant. for IC ............230
Table 158: 5800 MHz: RF Power & EIRP: 20 MHz Chan. & 10 dBi Ant. for IC ............231
Table 159: 5800 MHz: RF Power & EIRP: 20 MHz Chan. & 19 dBi Ant. for IC ............231
Table 160: 5800 MHz: RF Power & EIRP: 20 MHz Chan. & 32 dBi Ant. for IC ............231
Table 161: Connect Gateway - Main Menu..................................................................232
Table 162: Serial Gateway CLI - Command Summary ................................................247
Table 163: Serial Gateway CLI - General Commands.................................................247
LIST OF FIGURES
Fig. 1: Notice - WEEE Logo...........................................................................................20
Fig. 2: Functional Desc. - Distributed L2 VLAN-Aware Wireless Switch.........................25
Fig. 3: Functional Desc. - Wireless Subscriber Links.....................................................26
Fig. 4: Functional Desc. - Services and Service Groups................................................27
Fig. 5: Functional Desc. - Services (Subscriber)............................................................28
Fig. 6: Functional Desc. - Service Groups (Sector Controller)........................................29
Fig. 7: Functional Desc. - Wireless Rates......................................................................30
Fig. 8: Functional Desc. - Pass through Mode...............................................................31
Fig. 9: Functional Desc. - Subscriber-to-Subscriber Traffic............................................32
Fig. 10: Functional Desc. - VLAN Tagged Management................................................33
Fig. 11: Functional Desc. - VLAN Services: Default Groups and Services.....................34
Fig. 12: Functional Desc. - VLAN Services: VLAN Mapping ..........................................35
Fig. 13: Functional Desc. - Strict VLAN Tagging............................................................36
Fig. 14: Functional Desc. - TLS - Extended TLS and Double Tagging...........................37
Fig. 15: Functional Desc. - Tagged Traffic - Port-by-Port Tagging.................................38
Fig. 16: Functional Desc. - PTP Mode Configuration.....................................................39
Fig. 17: Web - Connecting the Ethernet Port to a PC.....................................................41
Fig. 18: Web - Dashboard Display.................................................................................42
Fig. 19: Web - General Information Screen ...................................................................44
Fig. 20: Web - Sector Controller System Status Screen ................................................46

RDL-3000 FAMILY USER MANUAL
70-00158-03-00 Proprietary Redline Communications © 2015 Page 14 of 254 April 17, 2015
Fig. 21: Web - Subscriber System Status Screen..........................................................47
Fig. 22: Web - GPS Statistics Screen............................................................................48
Fig. 23: Web - GPS MAP Screen...................................................................................49
Fig. 24: Web - Sector Controller: Subscriber Links Summary Screen............................51
Fig. 25: Web - Sector Controller: Advanced Stat. - Links Summary (RAS-Elite Only)....52
Fig. 26: Web - Subscriber Link Status Screen ...............................................................53
Fig. 27: Web - Services Summary Screen.....................................................................55
Fig. 28: Web - WSDB Status Screen.............................................................................56
Fig. 29: Web - PMP SC/SS System Configuration Screen.............................................61
Fig. 30: Web - Using DHCP to acquire IP, Network Mask, and Gateway.......................62
Fig. 31: Web - VLAN Tagged Management...................................................................64
Fig. 32: Web - VLAN Tagged Management Example ....................................................64
Fig. 33: Web - RADIUS Configuration Screen ...............................................................66
Fig. 34: Web - SNMP v2 Configuration Screen..............................................................68
Fig. 35: Web - SNMP v2: Community Configuration Screen..........................................69
Fig. 36: Web - SNMP v2: Trap Destinations Screen......................................................69
Fig. 37: Web - SNMP v2: Trap Configuration Screen.....................................................70
Fig. 38: Web - SNMP v3: Trap Destinations Screen......................................................70
Fig. 39: Web - SNMP v3: Trap Configuration Screen.....................................................71
Fig. 40: Web - Wireless Configuration Screen -- Sector Controller ................................72
Fig. 41: Web - Subscriber: RAS Advanced Stat. - Auto Scan Status .............................74
Fig. 42: Web - Wireless Configuration Screen -- Subscriber..........................................75
Fig. 43: Web - Redundancy Configuration.....................................................................79
Fig. 44: Web - Frequency Management Screen ............................................................80
Fig. 45: Web - Auto Frequency Scan: Configuration Setting..........................................81
Fig. 46: Web - WSDB Configuration/Control Screen......................................................83
Fig. 47: Web - Wireless Security Screen - Sector Controller..........................................85
Fig. 48: Web - Wireless Security Screen - Subscriber ...................................................85
Fig. 49: Web - Sector controller Identification (SCID).....................................................87
Fig. 50: Web - Sector controller Identification (SCID).....................................................88
Fig. 51: Web - Example Text File...................................................................................89
Fig. 52: Web - Example Text File...................................................................................90
Fig. 53: Web - Subscriber Links Screen.........................................................................91
Fig. 54: Web - Subscriber Link Configuration Screen ....................................................93
Fig. 55: Web - STID Subscriber Template Configuration Screen...................................94
Fig. 56: Web - Scan Threshold: Threshold Timer Example............................................96
Fig. 57: Web - Stickiness Timer Example......................................................................97
Fig. 58: Web - Service Groups Screen..........................................................................98
Fig. 59: Web - Service Group Status Screen.................................................................99
Fig. 60: Web - Service Group Configuration Screen....................................................100
Fig. 61: Web - Subscriber Service Status Screen........................................................102
Fig. 62: Web - Subscriber Service Configuration Screen.............................................103
Fig. 63: Web - Spectrum Sweep Screen......................................................................105
Fig. 64: Web - Users Management Screen..................................................................107
Fig. 65: Web - Product Options Screen.......................................................................111
Fig. 66: Web - Antenna Alignment Tool Screen...........................................................113
Fig. 67: Web - Firmware Management Screen ............................................................114
Fig. 68: Diag: - Saving Parameters in Non Volatile RAM.............................................147

RDL-3000 FAMILY USER MANUAL
70-00158-03-00 Proprietary Redline Communications © 2015 Page 15 of 254 April 17, 2015
Fig. 69: Diag. - Recovering Lost IP Address................................................................151
Fig. 70: Diag. - DHCP Discovery Timing Diagram........................................................153
Fig. 71: Ref: Scan Threshold Configuration Settings ...................................................170
Fig. 72: Connect Gateway - Connect-IWS Configuration Using Ethernet Port .............233
Fig. 73: Connect Gateway - Connect-IWS Configuration Using Console Port..............233
Fig. 74: Connect Gateway - Login Screen...................................................................234
Fig. 75: Connect Gateway - Relogin Screen................................................................234
Fig. 76: Connect Gateway - Dashboard Display..........................................................235
Fig. 77: Connect Gateway - System Information Screen .............................................236
Fig. 78: Connect Gateway - Trace Log Screen............................................................237
Fig. 79: Connect Gateway - System Information Screen .............................................238
Fig. 80: Connect Gateway - Trace Settings Screen.....................................................239
Fig. 81: Connect Gateway - Radio Configuration Screen.............................................240
Fig. 82: Connect Gateway - Serial Gateway [1,2] Settings Screen ..............................241
Fig. 83: Connect Gateway - Serial Port Settings Screen..............................................243
Fig. 84: Connect Gateway - Firmware Management Screen........................................244
Fig. 85: Connect Gateway - Firmware Management Screen........................................246

RDL-3000 FAMILY USER MANUAL
70-00158-03-00 Proprietary Redline Communications © 2015 Page 16 of 254 April 17, 2015
1 Important Notices
1.1 Service & Safety
General Warnings
Redline recommendations for maximum safety include the following:
Do not operate microwave equipment without first having proper training or
knowledge of microwave radio operation.
Do not operate the microwave equipment without an appropriate antenna port
termination, or antenna.
Check to ensure that the area around the antenna is clear of personnel prior to
turning the transmitter on.
Do not look into or stand in front of an antenna.
Do not swing or aim an antenna at nearby persons while the equipment is operating.
Where a structure or rooftop has existing antennas installed, do not proceed with an
installation without first determining the RF/µW exposure risk. Where necessary
have the relevant transmitters turned off or wear a protective suit for the duration of
the installation.
Safety Warnings
Installation of the system must be contracted to a professional installer.
PoE power adapter caution:
Warning to Service Personnel:48 VDC
Customer equipment including personal computers, routers, etc., must be connected
only to the INPUT (DATA) port on the PoE unit.
Only the outdoors Ethernet interface cable connecting to the unit can be safely
connected to the OUTPUT (DATA & POWER) connector. Connecting customer
premises Ethernet equipment directly to the OUTPUT (DATA & POWER) connector
on the Power-over-Ethernet power adapter may damage customer equipment.
Read this manual and follow all operating and safety instructions.
Keep all product information for future reference.
The power requirements are indicated on the product-marking label. Do not exceed
the described limits.
The unit must not be located near power lines or other electrical power circuits.
Disconnect the power before cleaning, or when the unit is not be in-use for an
extended period.
The system must be properly grounded to protect against power surges and
accumulated static electricity. The user is responsible for installing this device in
accordance with the local electrical codes: correct installation procedures for
grounding the unit, mast, lead-in wire and discharge unit, location of discharge unit,
size of grounding conductors and connection requirements for grounding electrodes.
Chapter 1

RDL-3000 FAMILY USER MANUAL
70-00158-03-00 Proprietary Redline Communications © 2015 Page 17 of 254 April 17, 2015
Warning Symbols
These symbols may be encountered during installation or troubleshooting. These
warning symbols mean danger. Bodily injury may result if you are not aware of the safety
hazards involved in working with electrical equipment and radio transmitters. Familiarize
yourself with standard safety practices before continuing.
WARNING
ELECTRO-MAGNETIC
RADIATION
WARNING
HIGH VOLTAGE
WARNING
HOT SURFACE
DO NOT TOUCH
1.2 Installation Safety
Professional Installation / Installations Professionnel
Redline RDL-3000 systems require professional installation. The user is responsible to
ensure all building and safety codes are met and the installation is complete and
secure.
The RDL-3000 system shall be installed according to local Electrical Safety Codes.
For Canadian installations, the entire equipment installation must comply with the
Canadian Electrical Code. For installations in the United States, the entire equipment
installation must be in accordance with Article 810 of the United States National
Electrical Code.
Les appareils RDL-3000 de Redline doivent être installés par un personnel
professionnel. Le personnel responsable doit s’assurer que l’installation est bien
achevée, et qu’elle répond aux exigences de tous les codes de sécurité.
Le RDL-3000 doit être installé conformément aux codes locaux de sécurité électrique.
Pour les installations Canadiennes, l'installation de l'équipement au complet doit se
conformer au Code Canadien de l'électricité. Pour les installations aux États-Unis,
l'installation de l'équipement au complet doit être en conformité avec l'article 810 du
Code des États-Unis National Electrical.
Safety Precautions
Installation and service must be done by personnel having technical training and
experience necessary to be aware of hazards during installation and/or service of
outdoors RF equipment. The installation and/or service must be done using procedures
designed to minimize any danger to technical personnel or any other person.
Use safety devices when working on or around the mast. Be aware of the risk of falling
objects. Use provided safety catches when hoisting antennas and radios.
Do not use any components (screws, nuts, etc.) other than those delivered together with
the Redline microwave radio equipment or those recommended by Redline.
Electrocution Hazard / Risque D’électrocution
Warning to Service Personnel:48 VDC
This product is intended to be connected to a power source as per IEEE 802.3at (42.5
- 57.0 VDC), which must be electrically isolated from any AC sources and reliably
connected to Earth ground. Do not install Redline products near any type of power line.
Should the antenna or related hardware come in contact with power lines, severe bodily
harm or death could result!

RDL-3000 FAMILY USER MANUAL
70-00158-03-00 Proprietary Redline Communications © 2015 Page 18 of 254 April 17, 2015
Attention au personnel du service: 48V CD
Ce produit est destiné à être connecté à une source d'énergie selon la norme IEEE
802.3at (42,5 à 57,0 VDC), qui doit être isolé électriquement de toutes les sources de
courant alternatif et fiable relié à la masse de la Terre. Ne pas installer les produits
Redline près n'importe quel type de ligne électrique. Si votre antenne ou du matériel
connexe entrer en contact avec des lignes électriques, des blessures graves ou la mort
pourraient en résulter!
Radio Frequency Safety / Sécurité des Fréquences Radio
The installer of this radio equipment must ensure that the antenna is located or pointed
such that the antenna does not emit RF fields in excess of the general population limits
as defined by:
FCC CFR 47, Part 2.1091
http://www.gpo.gov/fdsys/pkg/CFR-2009-title47-vol1/pdf/CFR-2009-title47-vol1-sec2-
1091.pdf
FCC OET Bulletin 65, Radio frequency radiation exposure evaluation for fixed
devices
http://transition.fcc.gov/Bureaus/Engineering_Technology/Documents/bulletins/oet65
/oet65c.pdf
Health Canada limits for the general population; consult Safety Code 6, obtainable
from Health Canada’s website:
http://www.hc-sc.gc.ca/ewh-semt/pubs/radiation/radio_guide-lignes_direct-eng.php
Santé Canada limite pour la population générale; consulter le Code de sécurité 6,
disponible sur le site Web de Santé Canada:
http://www.hc-sc.gc.ca/ewh-semt/pubs/radiation/radio_guide-lignes_direct-fra.php .
Personal Safety
WARNING: HOT SURFACE. DO NOT TOUCH.
The radio platform is rated for operation at extreme ambient temperatures. When
operating in high temperature conditions, the chassis surface area can be higher than
the ambient temperature and personal thermal protection should be employed for any
maintenance or inspection activity.
Electrical Safety
The equipment meets the requirements for class I EN 60950-1 (protection against
electric shock).
1. All external circuits are TNV-1 (as defined in EN 60950-1).
2. All equipment must be grounded before the power cable is connected.
3. For electrical safety the DC power supply shall have reinforced insulation to the
mains supply.
Electrical Safety Compliance / Conformité à la Sécurité Electrique
The RDL-3000 system hardware has been tested for compliance to the electrical safety
specifications listed in the following table.

RDL-3000 FAMILY USER MANUAL
70-00158-03-00 Proprietary Redline Communications © 2015 Page 19 of 254 April 17, 2015
Table 1: Notice - Electrical Safety Specifications
Class I
EN 60950-1
All External Circuits
TNV-1 as defined in EN 60950-1
All equipment must be grounded
Le RDL-3000 du matériel a été testé pour la conformité aux normes de sécurité
électriques indiquées dans le tableau suivant:
Table 2: Avis - Spécifications de sécurité électrique
Classe I
EN 60950-1
Tous les circuits externes
TRT-1 tel que défini dans la norme EN
60950-1
Tous les équipements doivent être mis à la terre
UL Information
The suitability of the supplied Ethernet cable is subject to the approval of Authority
Having Jurisdiction and must comply with the local electrical code.
The equipment must be properly grounded according with NEC and other local
safety code and building code requirements.
Reminder to all the BWA system installers: Attention to Section 820-40 of the NEC
which provides guidelines for proper grounding and, in particular, specifies that the
cable ground shall be connected to the grounding system of the building, as close to
the point of cable entry as is practical.
RDL-3000 system must be installed in compliance with relevant articles in National
Electrical Code-NEC (and equivalent Canadian Code-CEC) including referenced
articles 725, 800 and 810 in NEC.
RF coaxial cable connecting an antenna to the RDL-3000 system must comply with
the local electrical code.
To meet the over-voltage safety requirements on the telecommunications cables, a
minimum 26 AWG telecommunication line cord must be used.
Pour être en conformance avec les exigences finies de sûreté de sur-tension sur les
câbles de télécommunications un fil de télécommunication ayant un calibre minimum
de 26 AWG doit être utilisé.
Lightning Protection / Protection Contre la Foudre
When installed, this equipment is to be connected to a Lightning/Surge Protection
Device that meets all applicable national safety requirements. Before Ethernet cables
enter buildings, voltages shall be clamped down to SELV by approved type primary
protectors.
WARNING: The information provide in this user manual consists of general
recommendations for installation the system equipment. The wireless equipment must
be installed by a qualified professional installer who is knowledgeable of the
requirements of installing outdoor radio equipment and follows local and national codes
for electrical grounding and safety. Failure to meet safety requirements and/or use of
non-standard practices and procedures may result in personal injury and/or damage to
equipment.
The system must be properly grounded to protect against power surges and
accumulated static electricity. The user is responsible to install this device in accordance
with the local electrical codes: correct installation procedures for grounding the unit,

RDL-3000 FAMILY USER MANUAL
70-00158-03-00 Proprietary Redline Communications © 2015 Page 20 of 254 April 17, 2015
mast, lead-in wire and discharge unit, location of discharge unit, size of grounding
conductors and connection requirements for grounding electrodes.
All outdoor wireless equipment is susceptible to surge damage from a direct hit or
current induced from a near strike. A direct lightning strike may cause serious damage
even if recommended guidelines are followed. Installing surge protection and following
grounding practices detailed in local and national electrical codes can minimize
equipment damage, service outages, and chance of serious injury.
The major reasons for surge damage can be summarized as:
Poorly grounded antenna sites
Improperly installed surge protection equipment
A lighting protection system provides a means by which the energy may enter earth
without passing through and causing damage to parts of a structure. A good grounding
system disperses most of the surge energy from a lightning strike away from the building
and equipment. Improperly grounded connections are a source of noise that can cause
malfunctions in sensitive equipment. The remaining energy on the Ethernet cable shield
and conductors can be directed safely to ground by installing a surge arrestor in series
with the cable. A surge protection system does not prevent lightning strikes, but protects
equipment by providing a low resistance path for the discharge of energy safely to
ground. If surge protection is required for the system, the following general industry
practices are provided as a guideline only:
The AC wall outlet ground for the indoor POE adapter should be connected to the
building grounding system.
Install a surge arrestor in series with the Ethernet cable at the point of entry to the
building. The grounding wire should be connected to the same termination point
used for the tower or mast.
Provide direct grounding connections from the RDL-3000 system, the mounting
bracket, and the antenna to the common building ground bus. Use the grounding
screws provided for terminating the ground wires.
L’installation exige aussi que l’appareil soit branché à un parafoudre qui répond à
toutes les normes nationales de sécurité.
1.3 WEEE Product Return Process
In accordance with the WEEE (Waste from Electrical and Electronic Equipment)
directive, 2002/96/EC, Redline Communications equipment is marked with the logo
shown below. The WEEE directive seeks to increase recycling and re-use of electrical
and electronic equipment. This symbol indicates that this product should not be disposed
of as part of the local municipal waste program. Contact the local sales representative
for additional information.
Fig. 1: Notice - WEEE Logo
