Optimizer User’s Guide
RedPort Router - wXa-112

Copyright © Global Marine Networks, LLC

Copyright © Global Marine Networks, LLC
Table of Contents
1.0 About this guide . . . . . . . . 04
2.0 Introduction to RedPort Optimizer . . . . . 05
3.0 Getting Started - Router Administration . . . . 06
4.0 GPS Tracking . . . . . . . . . 08
5.0 GPS/NMEA Repeater . . . . . . . . 10
6.0 Signal Monitor . . . . . . . . 18
7.0 GSM . . . . . . . . . . 20
8.0 Restrict Wireless Network Access . . . . . . 25
9.0 Rename the Wireless Network. . . . . . . 27
10.0 Change Admin Password . . . . . . . 29
11.0 Update Firmware . . . . . . . . 30
12.0 Access System Log . . . . . . . . 31
13.0 Reboot . . . . . . . . . . 32
14.0 System Status for Monitoring Usage . . . . . 33
15.0 Profiles . . . . . . . . . . 34
16.0 Firewall Modification . . . . . . . . 36
Appendix A - Optimizer Quick Start Guide. . . . . . 38

Optimizer User’s Guide Copyright © Global Marine Networks, LLC Page 4of 38
Optimizer User’s Guide Revision History
Date
Revision
Author
December 15, 2014
Initial Release
D. Brickhouse

Optimizer User’s Guide Copyright © Global Marine Networks, LLC Page 5of 38
1.0 About this guide
This guide is intended for onboard/onsite administrators of the RedPort Optimizer wXa-
112 routers. It features only those sections of the user interface that require
configuration for a specific service or may need to be accessed by the average user.
For convenience, the Optimizer Quick Start Guide can be found in the Appendix of this
document. It includes important information regarding the physical connection setup and
initial configuration for email.
The following chapter references will help you in administering the most-used features
of the Optimizer.
Chapter 3.0 Getting Started
Chapter 4.0 GPS Tracking Service
Chapter 5.0 GPS/NMEA Repeater Settings
Chapter 6.0 Signal Monitor (how to change/disable)
Chapter 8.0 Restrict Wireless Network Access with password protection
Chapter 9.0 Rename the Wireless Hotspot Network
Chapter 10.0 Change the Router Admin Password
Chapter 11.0 Update Optimizer Firmware
Chapter 12.0 Access Optimizer System Log
Chapter 13.0 Reboot the Router
Other useful information can be found in the following chapters:
Chapter 7.0 GSM Capability
Chapter 13.0 System Status for Monitoring Usage
Chapter 14.0 Profiles
Chapter 15.0 Firewall Modification
wXa refers to the webXaccelerator by RedPort, a trademark of Global Marine Networks, LLC.

Optimizer User’s Guide Copyright © Global Marine Networks, LLC Page 6of 38
2.0 Introduction to RedPort Optimizer
Global Marine Networks (GMN), the leaders in advancing satellite data speeds and
services, helps Fixed and Mobile Satellite Services providers and their customers by
offering the industry’s fastest, most reliable and easy-to-use email, web, VoIP and other
hardware and software services to maritime, oil and gas, first responder and business
continuity users. The company’s products include XGate high-speed satellite email,
WeatherNet weather and oceanographic data software, and vessel tracking systems.
Ship to shore network management solutions are sold by GMN under the RedPort
Global brand name at www.redportglobal.com and as white-label solutions for the
world’s premier satellite data service service providers.
Optimizer is a satellite firewall and WiFi hotspot router that lets you easily access
accelerated satellite email, weather, web and tracking services, while blocking all
unwanted data traffic.
Email, Web, Weather and Tracking features require compatible service subscriptions.
Key Features
Designed specifically for use with satellite phones and terminals:
•Compatible with any IP-based satellite phone and satellite broadband terminal.
•Powerful firewall stops all unwanted data traffic. Optimizer blocks all traffic except
XGate-compressed email, web and weather data.
•WiFi signal makes setup and use with compatible computers and tablets easy.
•Works with XGate for email, web, weather and social media services.
•GSM support to switch between satellite and GSM when available.
•Track GPS locations from compatible GPS-enabled devices.
Note: The Optimizer ships pre-configured for use with XGate satellite email/data
service. XGate service and Tracking service are not included with the Optimizer and
must be purchased separately. Contact your satellite service provider for details.

Optimizer User’s Guide Copyright © Global Marine Networks, LLC Page 7of 38
3.0 Getting Started – Router Administration
As the onboard/onsite administrator, under normal operating conditions, you will seldom
have a need to interact with the user interface of the router. However, should you find
yourself in a position that requires you to login to the router, this Guide is designed to
help you.
Access the Optimizer User Interface
To access the Optimizer's user interface you must login to the router:
1. With power provided to the Optimizer, connect to the WiFi Hotspot created by the
router using a desktop or laptop computer. Connect to the WiFi Hotspot just like you
would any other WiFi connection:
On a Windows PC, go to: Windows Start > Control Panel > Network Connections
On a MAC, go to: Apple > System Preferences > Network
The Network Name will look something like: ‘wxa-112-XXXX’ where ‘XXXX’ may
represent the last four digits of the Optimizer Mac address. Select this wireless network.
2. Open any web browser on the computer and enter the URL: http://192.168.20.1
3. Login with the username = admin, password = webxaccess
CAUTION: The Optimizer ships pre-configured for use with XGate satellite
email/data service. Tampering with any settings that are not addressed in this Guide
will violate the warranty and may render the Optimizer inoperable.

Optimizer User’s Guide Copyright © Global Marine Networks, LLC Page 8of 38
Once logged in, you will see the Optimizer's Tracking Services screen.
Use the tabs to navigate through the user interface. You will see that the information
represented in the user interface can be quite technical.
This Guide will cover only those sections of the user interface that require configuration
for a specific service or may need to be accessed by the average user.
An alternate method to access the user interface: With power to the Optimizer,
connect the Optimizer to your computer using a standard ethernet cable in the LAN
port and follow the directions above, starting with Step 2, entering the URL
http:192.168.10.1

Optimizer User’s Guide Copyright © Global Marine Networks, LLC Page 9of 38
4.0 GPS Tracking
If you wish to have tracking service using your satellite device, the Optimizer offers GPS
Tracking service powered by GSatTrack or Tracking service via SMS message. There
are two tracking options available in the Optimizer:
4.1 Tracking powered by GSatTrack
Using a GPS-enabled satellite device, the Optimizer can be configured to submit
position reports to a central database for viewing on the tracking website.
To enable this service:
1. From the Optimizer Home page select Services > GPS Tracking > Tracking.
This tracking service must be purchased separately. See your satellite service
provider for details.

Optimizer User’s Guide Copyright © Global Marine Networks, LLC Page 10 of 38
2. In "General Tracking Parameters", select the Tracking Interval in minutes; the
default is set to hourly reporting (60 minutes). This means that every 60 minutes a
position report will be transmitted over your satellite link. Keep in mind that standard
airtime charges will apply to each postition report. Adjust the Tracking Interval to meet
your needs.
3. In "Tracking powered by GSatTrack", select the satellite terminal you are using. Note:
a valid NMEA/GPS feed is required when using some satellite devices.
4. Select <Save & Apply>.
4.2 Tracking via SMS
If using certain satellite devices, GPS information can be sent to an email address using
your satellite provider's SMS service. Standard SMS charges may apply; check with
your satellite airtime provider for details.
1. In General Tracking Parameters, select the Tracking Interval in minutes; the default
is set to hourly reporting (60 minutes). This means that every 60 minutes a position
report will be transmitted via the SMS service provided by your satellite provider
network. Keep in mind that standard SMS charges may apply to each postition report.
Adjust the Tracking Interval to meet your needs.
2. In Tracking via SMS, select which satellite device you are using. At this time, tracking
via SMS is available with the Inmarsat IsatPhone, Iridium handheld 9575 Extreme,
Iridium GO! or an Iridium terminal such as the Pilot. Note: a valid NMEA/GPS feed is
required when using an Iridium terminal.
3. Select <Save & Apply>.

Optimizer User’s Guide Copyright © Global Marine Networks, LLC Page 11 of 38
5.0 GPS/NMEA Repeater
The Optimizer supports USB and RS-232 NMEA devices allowing multiple applications
to share the GPS/NMEA data. If you have a NMEA RS-422 device, adding a RS-422 to
RS-232 converter to your setup may allow the sharing of data.
The Optimizer does not transmit data but can be configured to receive and repeat
GPS/NMEA data from:
•A broadband satellite terminal with integrated GPS when connected to the
Optimizer via a standard ethernet connection. (As of this writing, supported
terminals include: Iridium Pilot, Inmarsat FBB and Inmarsat BGAN).
•A handheld satellite phone with integrated GPS when connected to the Optimizer
with the satphone's USB-Mini/Micro USB cable. (As of this writing, supported
handheld satphones include: Iridium 9575 Extreme and Inmarsat IsatPhonePro.)
•A USB connected GPS or NMEA device.
•A serial port connected GPS or NMEA device
WARNING: IsatPhonePro users! The phone only transmits GPS coordinates
about every 10 minutes. It is NOT recommended for navigation or any
application that requires real time data.
NOTE: If you are using a satellite phone with a serial port (RS-232) that transmits
GPS data (i.e. some fixed phones and fleet phones), it is NOT compatible with the
Optimizer. In order to repeat GPS data, a separate GPS device must be
connected.

Optimizer User’s Guide Copyright © Global Marine Networks, LLC Page 12 of 38
5.1 Equipment Setup
A physical connection is required from the source (satellite terminal or satellite phone
that transmits GPS coordinates, or other GPS/NMEA device) to the Optimizer.
5.1.1 Broadband Satellite Terminal with Integrated GPS
When using a supported broadband satellite terminal with integrated GPS, connect the
terminal to the Optimizer SAT port using a standard ethernet cable.
(OPTIONAL: Use a second ethernet cable to connect the computer with the destination
software, like a navigation program, to the Optimizer LAN port.)
The Optimizer will broadcast the GPS signal both over Ethernet and WiFi, so you can
connect your computer either way in order to establish a successful connection with
your destination software.

Optimizer User’s Guide Copyright © Global Marine Networks, LLC Page 13 of 38
5.1.2 Handheld Satellite Phone with Integrated GPS
When using a supported USB connected satphone with integrated GPS, connect the
satphone to the Optimizer using the Mini-USB (satphone) to USB (Optimizer) cable.
(OPTIONAL: Use an ethernet cable to connect the computer with the destination
software, like a navigation program, to the Optimizer LAN port.)
The Optimizer will broadcast the GPS signal both over Ethernet and WiFi, so you can
connect your computer either way in order to establish a successful connection with
your destination software.

Optimizer User’s Guide Copyright © Global Marine Networks, LLC Page 14 of 38
5.1.3 USB NMEA Device
When using a NMEA device that supports a USB connection, connect the GPS/NMEA
device to the Optimizer with an appropriate USB to NMEA device cable as indicated by
the NMEA device manufacturer.
(OPTIONAL: Use an ethernet cable to connect the computer with the destination
software, like a navigation program, to the Optimizer LAN port.)
The Optimizer will broadcast the GPS signal both over Ethernet and WiFi, so you can
connect your computer either way in order to establish a successful connection with
your destination software.
If your satellite device requires a USB connection to the Optimizer (for example, an Iridium
9555) you can use a 2-port USB hub (either 1.0 or 2.0) plugged into the Optimizer's USB
port to accommodate two USB devices.

Optimizer User’s Guide Copyright © Global Marine Networks, LLC Page 15 of 38
5.1.4 RS-232 NMEA Device
With Serial Port Connector
When using a NMEA device with Serial Port connection, a USB to Serial Adapter
(PL-2303HX) is required to connect the device to the Optimizer.
The Optimizer will broadcast the GPS signal both over Ethernet and WiFi, so you
can connect your computer either way in order to establish a successful
connection with your destination software.
Please Note: The PL-2303HX is the only USB to Serial Adapter that is
compatible with the Optimizer.
If your satellite device requires a USB connection to the Optimizer (for example, an Iridium
9555) you can use a 2-port USB hub (either 1.0 or 2.0) plugged into the Optimizer's USB
port to accommodate two USB devices.

Optimizer User’s Guide Copyright © Global Marine Networks, LLC Page 16 of 38
Without Serial Port Connector
Some NMEA devices do not have a serial port; instead they have a group of
wires extending from the back or bottom of the unit. These devices require
proper wiring to a serial port.
As the Optimizer does not transmit, it only repeats the data, you will only need
two of the wires. The Receive (RD) wire goes to pin 2 and the Ground (SG) wire
goes to pin 5.
A simple solution is to use a terminal block as
shown here. Simply connect the RD wire to pin2 and
the SG wire to pin 5. Then connect the terminal
block to the PL-2302HX USB to serial adapter as
noted above.
5.1.5 Connecting Multiple NMEA Devices
It is possible to connect up to four NMEA devices if you have
the proper hardware. It will require a USB to RS-232 4-port
Hub or a RS-232 4-port terminal block that you would simply
plug into the Optimizer’s USB port.
The Optimizer supports RS232. If you have a NMEA RS-422 device, adding a
properly wired RS-422 to RS-232 converter to your setup may allow the sharing
of data.

Optimizer User’s Guide Copyright © Global Marine Networks, LLC Page 17 of 38
5.2 GPS/NMEA Repeater Parameters Configuration
In order for the destination software to properly route the GPS data you must configure
the GPS/NMEA Repeater Parameters in the Optimizer User Interface.
From the Optimizer Home page select Services > GPS/NMEA Repeater tab.
1. Select the source of the GPS/NMEA information (choose only one):
•GPS from broadband satellite: Select this if you are using a broadband satellite
terminal with integrated GPS.
•GPS/NMEA feed from USB: Select this when connecting a GPS or NMEA
device via USB cable.
2. NMEA Baud Rate - Using the drop down menu, select the baud rate required for the
destination software. By default, most NMEA 183 devices (GPS) and applications use
4800 baud for this setting.
3. UDP Listener Port - Enter the UDP port number that the GPS is connected to. The
default is set to the standard UDP Listener Port for NMEA 183 devices of 10101.
4. UDP Port - Enter the UDP port number to broadcast the GPS data to. The default is
set to the standard UDP Port for NMEA 183 devices of 11101. (Note: configure the
destination software to match this port number; or, change this entry to match the
requirements of the destination software.)

Optimizer User’s Guide Copyright © Global Marine Networks, LLC Page 18 of 38
5. TCP Port - Enter the TCP port number to broadcast the GPS data to. The default is
set to the standard TCP Port for NMEA 183 devices of 11102. (Note: configure the
destination software to match this port number; or, change this entry to match the
requirements of the destination software.)
The data will be broadcast to both the UDP Port and the TCP Port. It is important to
make sure that these two ports are NOT set to the same port number.
To use the GPS Repeater feature, your computer must be connected to the Optimizer
WiFi network or directly connected to the LAN port of the Optimizer.

Optimizer User’s Guide Copyright © Global Marine Networks, LLC Page 19 of 38
6.0 Signal Monitor
Signal monitor queries your satellite device to determine if the signal strength is
sufficient to make a successful data connection. Typically, a minimum of 60% signal is
required; however, 100% is ideal for the fastest possible data transfer rate.
Some of the older satellite phones (for example, the Iridium 9505a) do not support the
signal monitor feature. For these older satellite phones, the signal monitor must be
disabled for a successful data connection.
Changing Signal Monitor
Signal Monitor can be modified in the Optimizer. When logged in to the Optimizer, go to:
Services > USB Phone > Settings > Signal Monitor. From this screen you can
enable/disable signal monitor using the "Enable" checkbox. You can also change the
level of the signal monitor. Keep in mind that 60% is typically the minimum required for
a successful data connection. If you must change the Signal Monitor, we recommend
lowering the Level vs. disabling it. Many IsatPhonePro users have had success by
lowering the level to 40 or 30. NOTE: Reducing the signal strength to less than 60%
may cause lengthy data connections due to poor signal.

Optimizer User’s Guide Copyright © Global Marine Networks, LLC Page 20 of 38
When you are done making changes, click <Save & Apply>.
As an alternative, Signal monitor can also be changed from within the XGate Settings.
See the XGate Help File > User Interface > Settings > Optimizer, wXa, & Sat-Fi for
details.
