REED R5010 User manual

Model R5010
TRMS Digital Multimeter
Instruction
Manual
Pantone 534 Blue
Pantone 123 Yellow
Pantone 485 Red
Pantone 123 Yellow
Pantone 534 Blue
Black Rich Black -
20/20/20/100
Blue - 100/80/30/5
Yellow - 0/27/100/0
Red - 10/100/100/5
Yellow - 0/27/100/0
Blue - 100/80/30/5
Only if you REALLY need them:
Pantone 534 Blue - 100/80/30/5
Pantone 485 Red - 10/100/100/5
Pantone 123 Yellow - 0/27/100/
INSTRUMENTS
INSTRUMENTS
Only if you REALLY need them:
Model R5010
TRMS Digital Multimeter
Instruction
Manual
REED Instruments
1-877-849-2127 | [email protected] | www.reedinstruments.com

2
INSTRUMENTS
INSTRUMENTS
2
Table of Contents
Safety ......................................................................................................3-4
IEC1010 Overvoltage Installation Category............................................... 3
Warnings ................................................................................................. 4
Features...................................................................................................... 5
Specications..........................................................................................5-8
Instrument Description............................................................................... 9
Display Description .................................................................................. 10
Operating Instructions.........................................................................11-18
DC Voltage Measurement...................................................................... 11
AC Voltage Measurement...................................................................... 11
DC Current Measurement...................................................................... 12
AC Current Measurement...................................................................... 13
Resistance Measurement ...................................................................... 14
Continuity Check ................................................................................... 14
Diode Test ............................................................................................. 14
Temperature Measurement.................................................................... 15
Capacitance Measurement.................................................................... 15
Frequency Measurement....................................................................... 15
%4-20mA Measurement........................................................................ 16
Autoranging/Manual Range ................................................................... 16
Max/Min ................................................................................................ 16
Relative Mode........................................................................................ 17
Display Backlight ................................................................................... 17
Hold ...................................................................................................... 17
Peak Hold.............................................................................................. 17
Low Battery Indication ........................................................................... 18
Auto Power Off...................................................................................... 18
Maintenance............................................................................................. 18
Battery Replacement................................................................................ 19
Replacing the Fuses................................................................................. 20
REED Instruments
1-877-849-2127 | [email protected] | www.reedinstruments.com

3
INSTRUMENTS
INSTRUMENTS
Safety
This symbol adjacent to another symbol, terminal or
operating device indicates that the operator must refer to an
explanation in the Instruction Manual to avoid personal injury
or damage to the meter.
Indicates a potentially hazardous situation, which if not
avoided, could result in death or serious injury.
Indicates a potentially hazardous situation, which if not
avoided, may result damage to the product.
The terminal(s) so marked must not be connected to a circuit
point for which the voltage with respect to ground exceeds
(in this case) 1000 VAC or VDC.
This symbol adjacent to one or more terminals identies them
as being associated with ranges that may, in normal use, be
subject to particularly hazardous voltages. For maximum
safety, the meter and its test leads should not be handled when
these terminals are energized.
Indicates that a instrument is protected throughout by double
insulation or reinforced insulation.
IEC1010 Overvoltage Installation Category
Overvoltage Category I is equipment for connection to circuits for which
measures are taken. Examples include protected electronic circuits.
Overvoltage Category II is energy-consuming equipment to be supplied
from the xed installation. Examples include household, ofce, and
laboratory appliances.
Overvoltage Category III is equipment in xed installations.
Examples include switches in the xed installation and some equipment
for industrial use with permanent connection to the xed installation.
Overvoltage Category IV is for use at the origin of the installation.
Examples include electricity meters and primary over-current protection
equipment.
WARNING
CAUTION
REED Instruments
1-877-849-2127 | [email protected] | www.reedinstruments.com

4
INSTRUMENTS
INSTRUMENTS
Warnings
This meter has been designed for safe use, but must be operated with
caution. The warnings listed below must be carefully followed for safe
operation.
1. NEVER apply voltage or current to the meter that exceeds the
specied maximum Input Protection Limits:
Function Maximum Input
V DC or V AC 1000VDC/AC RMS
mA AC/DC 500mA 1000V fast acting fuse
A AC/DC 10A 1000V fast acting fuse (20A for 30
seconds max every 15 minutes)
Frequency, Resistance, Capacitance,
Duty Cycle, Diode Test, Continuity 1000VDC/AC RMS
Temperature 1000VDC/AC RMS
Surge Protection: 8kV peak per IEC 61010
2. USE EXTREME CAUTION when working with high voltages.
3. DO NOT measure voltage if the voltage on the "COM" input jack
exceeds 1000V ground.
4. NEVER connect the meter leads across a voltage source while the
function switch is in the current, resistance, or diode mode. Doing
so can damage the meter.
5. ALWAYS discharge lter capacitors in power supplies and
disconnect the power when making resistance or diode tests.
6. ALWAYS turn off the power and disconnect the test leads before
opening the covers to replace the fuse or batteries.
7. NEVER operate the meter unless the back cover and the battery
and fuse covers are in place and fastened securely.
8. If the equipment is used in a manner not specied by the manufacturer,
the protection provided by the equipment may be impaired.
REED Instruments
1-877-849-2127 | [email protected] | www.reedinstruments.com

5
INSTRUMENTS
INSTRUMENTS
Features
• TrueRMSmeasuresfrequency,resistance,capacitanceandtemperature.
• Diodecheckandcontinuityfunctions.
• BacklitLCDreadoutwithanalogbargraph.
• 4-20mAprocessloopmeasurementswith%readout.
• Datahold,Max/MinandPeakcapturemode.
• IP67dustandwaterproof.
• Cat.IV600V,Cat.III1000Vsafetyrating.
• Includes Thermocouple Adapter, thermocouple wire probe (Type K), test
leads, battery, weatherproof plugs, and carrying case.
Specifications
AC/DC Voltage
Range AC: 400mV, 4, 40, 400, 1000V
DC: 400mV, 4, 40, 400, 1000V
Accuracy AC:400mV±(1.0%rdg.+5dgt.)
 4,40,400,1000V±(1.0%rdg.+3dgt.)
 DC:400mV/4,40,400V±(0.06%rdg.+2dgt.)
 1000V±(0.1%rdg.+5dgt.)
Resolution AC: 0.1mV, 0.001, 0.01, 1V
DC: 0.01mV, 0.0001, 0.01, 0.1V
AC/DC Current
Range 400Ω, 4, 40, 400kΩ, 4, 40MΩ
Accuracy 400Ω:±(0.3%rdg.+9dgt.)
 4,40,400kΩ,4MΩ:±(0.3%rdg.+4dgt.)
 40MΩ:±(2.0%rdg.+10dgt.)
Resolution 0.01Ω, 0.0001, 0.001, 0.01kΩ, 0.001MΩ
NOTE: Accuracy is stated at 65oF to 83oF (18oC to 28oC)&lessthan75%RH
continued ...
REED Instruments
1-877-849-2127 | [email protected] | www.reedinstruments.com

6
INSTRUMENTS
INSTRUMENTS
Capacitance
Range 40, 400nF, 4, 40, 400, 4000µF, 40mF
Accuracy 40,400nF:±(3.5%rdg.+40dgt.)
 4,40,400µF:±(3.5%rdg.+10dgt.)
 4000µF,40mF:±(5%rdg.+10dgt.)
Resolution 0.001, 0.01nF, 0.0001, 0.001, 0.01, 0.1µF, 0.001mF
Frequency
Range 40,400Hz,4,40,400kHz,4,40,100MHz
Accuracy ±(0.1%rdg.+1dgt.)
Resolution 0.00,0.01Hz,0.0001,0.001,0.01kHz,0.0001,
 0.001,0.01MHz
Temperature
Range -58 to 1832°F (-50 to 1000°C)
Accuracy ±(1.0%rdg.+4.5°F)
 ±(1.0%rdg.+2.5°C)
Resolution 1°F, 1°C
4-20mA%
Range -25to125%
Accuracy ±(50 dgt.)
Resolution 0.01%
General Specifications
Range Selection Autoranging/Manual
True RMS Yes
Display 40,000 count LCD display
DisplayHold Yes
Max/Min Yes
PeakHold Yes
Relative Mode Yes
Diode Test Yes
continued ...
REED Instruments
1-877-849-2127 | [email protected] | www.reedinstruments.com

7
INSTRUMENTS
INSTRUMENTS
Backlit Display Yes
Digital Analog Bargraph Yes
Continuity Check Audible signal if resistance ≤35Ω
DutyCycle Yes(0.1-99.9%)
Kick Stand Yes
Auto Power Off Yes (after 15 minutes)
Power Supply 9V Battery
Low Battery Indicator Yes
Fuse Protection Yes
Replaceable Test Leads Yes
Overvoltage Category CAT. IV 600V, CAT. III 1000V
Product Certications CE, IP67, Drop Tested (2M)
Operating Temperature 41 to 104°F (5 to 40°C)
Storage Temperature -4 to 140°F (-20 to 60°C)
Dimensions 7.4 x 3.2 x 2.0" (187 x 81 x 50mm)
Weight 12oz (342g)
NOTE: Accuracy specications consist of two elements:
• (% reading) – This is the accuracy of the measurement circuit
• (+ digits) – This is the accuracy of the analog to digital converter
Enclosure Double molded, waterproof
Shock (Drop Test) 6.5 feet (2 meters)
Temperature Sensor Requires type K thermocouple
Input Impedance >10MΩ VDC & >3MΩ VAC
AC True RMS The term stands for "Root-Mean-Square",
which represents the method of calculation of
the voltage or current value.
Average responding multimeters are calibrated
to read correctly only on sine waves and they
will read inaccurately on non-sine wave or
distorted signals. True rms meters read
accurately on either type of signal
(includes holster) continued ...
REED Instruments
1-877-849-2127 | [email protected] | www.reedinstruments.com

8
INSTRUMENTS
INSTRUMENTS
ACVBandwidth 50Hzto1000Hz
Crest Factor ≤3 at full scale up to 500V, decreasing linearly
to ≤1.5 at 1000V
Overrange indication "OL" is displayed
Auto Power Off 15 minutes (approximately) with disable feature
Polarity Automatic (no indication for positive);
Minus (-) sign for negative
Measurement Rate 2 times per second, nominal
Low Battery Indication is displayed if battery voltage drops below
operating voltage
Fuses mA, µA ranges; 0.5A/1000V ceramic fast blow
A range; 10A/1000V ceramic fast blow
OperatingHumidity Max80%upto87ºF(31ºC)decreasinglinearly
 to50%at104ºF(40ºC)
StorageHumidity <80%
Operating Altitude 7000ft. (2000 meters) maximum
Safety This meter is intended for origin of installation
use and protected, against the users, by double
insulation per EN61010-1 and IEC61010-1 2nd
Edition (2001) to Category IV 600V & Category
III 1000V; Pollution Degree 2. The meter also
meets UL 61010-1, 2nd Edition (2004),
CAN/CSA C22.2 No. 61010-1 2nd Edition
(2004), & UL 61010B-2-031, 1st Edition (2003)
Optional Accessories Adapter (AD-1)
Replacement Fuses (F-500mA/1000V, F-10A/1000V)
Thermocouple Probes (R2920, R2930, R2950,
LS-109, TP-01)
Test Leads (FC-300, R1000)
Current Adapter (CP-09)
Carrying Case (CA-05A)
REED Instruments
1-877-849-2127 | [email protected] | www.reedinstruments.com

9
INSTRUMENTS
INSTRUMENTS
Instrument Description
1. 40,000 count LCD display
2. REL button
3. RANGE button
4. MODE button
5. Function switch
6. mA, µA and 10A input jacks
7. COM input jack
8. Positive input jack
9. HOLDand (Backlight) button
10. PEAK button
11. MAX/MIN button
Note: Tilt stand and battery
compartment are on back of unit.
REED Instruments
1-877-849-2127 | [email protected] | www.reedinstruments.com

10
INSTRUMENTS
INSTRUMENTS
Display Description
Continuity Diode test
Battery status nnano (10-9) (capacitance)
µmicro (10-6) (amps, cap) mmilli (10-3) (volts, amps)
AAmps kkilo (103) (ohms)
FFarads (capacitance) Mmega (106) (ohms)
ΩOhms PEAK PeakHold
Hz Hertz(frequency) VVolts
%Percent (duty ratio) REL Relative
AC Alternating current AUTO Autoranging
DC Direct current HOLD Display hold
ºF Degrees Fahrenheit ºC Degrees Centigrade
MAX Maximum MIN Minimum
REED Instruments
1-877-849-2127 | [email protected] | www.reedinstruments.com
