Reely X-220 Operator's manual

QUICK START V1.0
IN THE BOX
14.8V 4S Li-Po
X2
X2
Aircraft Remote Controller Propeller Pairs
User Manual
Motor Mount Mushroom Antenna
Battery Charger
X4
1. Camera
2. ESC & ESC Cover
3. Motor Cover/Landing gear
4. Clockwise motor
5. Counterclockwise motor
6. Clockwise propeller
7. Counterclockwise propeller
8. 5.8 GHz Video transmitter
9. Receiver
10. Flight controller
11. Power panel
12. 14.8V 1300mAH 60C 4S Li-Po
13. LED lights ( Former Blue, Red after )
The chassis is created using CFP for outstanding crash survivability.
Advanced 5.8G live video, for an unforgeable visual FPV experience.
Modern industrial and modular design, improves the product performance
and permit easy maintainance and upgrades.
The X-220 employs a modern flight control system for acrobac flight
rounes such as roll, flip and race course moves.
ABOUT AIRCRAFT ABOUT REMOTE CONTROLLER
Mode key Buzzer switch Motor lock key
User Manual V1.0

CHARGE THE BATTERY
OPERATION INSTRUCTION
PREPARE THE AIRCRAFT
AC power cord
LED
Aircraft
Front
1file for ACRO Mode
2file for STAB Mode
3file for HOZN Mode
Aircraft Manual is head Remote controller operating instructions
MODE 1 Right hand throttle stick MODE 2 Left hand throttle stick
MODE 2 Left hand throttle stickMODE 1 Right hand throttle stick
Aircraft Up/Down
Tail towards yourself
Aircraft Forward/Backward
Aircraft stick to left/right
The level of the tail
The mode key
Right hand throttle stick
Left hand throttle stick
Tail towards yourself
Tail towards yourself
The aircraft roll forward
The aircraft roll backward
The aircraft roll left
The aircraft roll right
Aircraft Manual is head Remote controller operating instructions
Right/Left hand throttle stick
The mode key
1file for ACRO Mode
2file for STAB Mode
3file for HOZN Mode
2
DREAM Baron
Connect the power socket to an appropriate mains socket via the
supplied power cable. The Power LED lights up green when the
charger is ready for operation.
Connect the rechargeable battery to be charged via its XH
balancer plug with the relevant jack of the charger. At that,
observe the correct polarity of the XH plug. When connecting, do
not use excessive force; always use a socket matching the jack.
Only connect a single battery to the charger at a time.
Always use only one of the XH sockets at a time.
After a few seconds the LEDs 25%/75% and 50%/100% are
flashing alternately. This indicates that no rechargeable battery is
connected and that the charger is ready.
Four LEDs on the charger indicate the charging status (25%,
50%, 75%and 100%). Once the LED “100%” lights up, the
battery is fully charged. Disconnect the battery from
the charger.
Attention:
1) Always select open space without obstacles such as trees, fences or buildings and make sure to
keep a sufficiently safe distance from persons, animals or objects during operation.
2) If you do not have sufficient knowledge as to how to deal with remote-controlled models, please
seek the advice of an experienced model maker or a model making club.
Advance manuvers such as roll and flips are best suited for experienced pilot only.
3) The flight height of a racecopter is affected by the pitch function. Once the control stick is in the
centre position, the propeller speeds should be high enough for the racecopter to hover. If the control
stick is pushed forward further, the racecopter will rise. If the control stick is pulled back, the
racecopter drops.
3) No liability is assumed for damage to property or personal injury caused by improper use or the failure to
observe the safety instructions! In such cases the warranty/guarantee is voided.
Attention:
If the voltage is too low, it will be dangerous to roll, we
strongly recommend to quit HOZN Mode and land the aircraft. When battery voltage drops too low, buzzer alarm will sound regardless of buzzer switch
is on/ off. Please land aircraft as soon as possible to avoid accidents.
Hook and loop tape is already pre-attached on the backside of the battery pack
and airframe. Simply place battery on the airframe while carefully observing and
adjusting aircraft's center of gravity while necessary. Once the aircraft is
balanced, strap down the battery with the enclosed hook and loop belt to hold
the battery in place.
Propeller Spin Direction
Prop Nut Fasten This Direction
Fix the CW propeller onto the CW motor,
tighten the black propeller nuts anticlockwise.
Fix the CCW propeller onto the CCW motor,
tighten the blue propeller nuts clockwise.
CW Propeller
(black nut)
CCW Propeller
(blue nut)
CCW Propeller
(blue nut)
CW Propeller
(black nut)
