Reflex Storatherm Heat HF /R2 Series User manual

Storatherm
18.02.2021
Storatherm Heat
HF …/R2; H …/R2
GB
Operating manual

Contents
Storatherm Heat — 23.02.2021
English — 3
English
Storat herm
18.02.2021
Contents
1Information concerning the operating manual..................................................... 4
2Safety ....................................................................................................................... 4
2.1 Personnel requirements.............................................................................................................4
2.2 Intended use ..............................................................................................................................4
2.3 Impermissible operating conditions ...........................................................................................4
2.4 Personal protective equipment ..................................................................................................4
3Description .............................................................................................................. 5
3.1 Identification...............................................................................................................................5
3.2 Regulations ................................................................................................................................5
4Technical data ......................................................................................................... 5
5Installation ............................................................................................................... 8
5.1 Transport.................................................................................................................................... 8
5.2 Installation location ....................................................................................................................8
5.3 Tank assembly...........................................................................................................................9
5.3.1 Installation .....................................................................................................................9
5.3.2 Heating system connection...........................................................................................9
6Commissioning ....................................................................................................... 9
6.1 Filling the tank............................................................................................................................9
7Removal from service........................................................................................... 10
8Maintenance .......................................................................................................... 10
8.1 Draining....................................................................................................................................10
8.2 Recommissioning.....................................................................................................................10
9Recycling ............................................................................................................... 10
10 Appendix................................................................................................................ 11
10.1 Reflex Customer Service .........................................................................................................11
10.2 Warranty...................................................................................................................................11

Information concerning the operating manual
4 — English
Storatherm Heat — 23.02.2021
1Information concerning the operating manual
This operating manual is an important aid for ensuring the safe and reliable functioning of the tank. Reflex
Winkelmann GmbH accepts no liability for any damage resulting from failure to observe the information in this
operating manual. In addition national statutory regulations and provisions in the country of installation must also
be complied with (concerning accident prevention, environment protection, safe and professional work practices,
etc.).
2Safety
2.1 Personnel requirements
The assembly of, connection of and structural alteration work to the tank must be carried out by an authorised
specialist company in accordance with all applicable national and local regulations.
2.2 Intended use
The buffer tank must only be used in closed heating and/or chilling systems.
Intended use comprises the following points:
-Only static and fixed installation
-Adherence to the installation, operating and maintenance conditions
-Not to be installed outside
-Filling of the buffer tank must take place using heating water according to VDI Guideline 2035 Sheet 1
and 2.
-The glycol fraction in the water must be between 25 % and 50 %.
The manufacturer’s information in respect of the dosing quantity must be observed when dosing
additives, especially concerning corrosion.
2.3 Impermissible operating conditions
The tank is not suitable for the following conditions:
-Operation below the dew point as the insulation is not diffusion-tight. In this case the tank must be
insulated so that it is diffusion-tight.
-Operation outside the maximum operating conditions.
-Ensure that the connections are made in a zero-volts state.
-Implement suitable measures to prevent frost damage.
2.4 Personal protective equipment
Use the prescribed personal protective equipment as required (e.g. ear protection, eye protection, safety shoes,
helmet, protective clothing, protective gloves) when working on the system in which the tank is installed.
Information on personal protective equipment requirements is set out in the relevant national regulations of the
respective country of operation.

Description
Storatherm Heat — 23.02.2021
English — 5
3Description
The buffer tank acts as an intermediate store for heating water for further transport to the heating circuit.
3.1 Identification
The nameplate provides information on manufacturer, year of manufacture, part number and technical data. The
nameplate is located on the tank or the tank insulation.
3.2 Regulations
All applicable national and local regulations and directives must be adhered to during installation, operation and
maintenance.
4Technical data
Note!
The following values apply for all buffer tanks:
•Manufacturing or serial number
•Year of manufacturing
•Nominal tank volume in litres
•Maximum working pressure
•Height in mm
•Diameter in mm
•Blanking flange in DN
•Max. tank operating temperature
•Number of system connections
•Number of sensors, emptying connections
See nameplate
See nameplate
See nameplate
10 bar
See technical data
See technical data
See technical data
95°C
4
2
HF 500/R2 - HF 1500/R2
• Buffer tank
• Fleece insulation with foil jacket (HF …/R2)
• Energy efficiency according to ErP: C
• Material class DIN 4102-1: B2

Technical data
6 — English
Storatherm Heat — 23.02.2021
Type
Ø D (mm)
Weight (kg)
Heat retention losses W
HF 500/R2
797
128
106
HF 800/R2
990
216
132
HF 1000/R2
990
231
141
HF 1500/R2
1240
240
167
H 500/R2
597
118
---
H 800/R2
790
207
---
H 1000/R2
790
218
---
H 1500/R2
1000
228
---
Type
Contents
(l)
Height H (mm)
Flange size
HF 500/R2; H 500/R2
475
1951
DN180
HF 800/R2; H 800/R2
778
1854
DN180
HF 1000/R2; H 1000/R2
921
2117
DN180
HF 1500/R2; H 1500/R2
1500
2119
DN180

Technical data
Storatherm Heat — 23.02.2021
English — 7
Type
Sensor connection
h2
h3
h4
(mm)
Rp
(mm)
Rp
(mm)
Rp
HF 500/R2; H 500/R2
315
½"
947
½"
1578
½"
HF 800/R2; H 800/R2
325
1 ½"
866
1 ½"
1407
1 ½"
HF 1000/R2; H 1000/R2
325
1 ½"
1011
1 ½"
1697
1 ½"
HF 1500/R2; H 1500/R2
439
1 ½"
1039
1 ½"
1639
1 ½"
Type
Heating source connection
h2
h4
(mm)
DN/PN
(mm)
DN/PN
HF 500/R2; H 500/R2
315
DN80/PN16
1578
DN80/PN16
HF 800/R2; H 800/R2
325
DN80/PN16
1407
DN80/PN16
HF 1000/R2; H 1000/R2
325
DN125/PN16
1697
DN125/PN16
HF 1500/R2; H 1500/R2
439
DN125/PN16
1639
DN125/PN16
Type
Thermometer connection
h1
(mm)
Rp
HF 500/R2; H 500/R2
120
1"
HF 800/R2; H 800/R2
108
1"
HF 1000/R2; H 1000/R2
108
1"
HF 1500/R2; H 1500/R2
220
1"

Installation
8 — English
Storatherm Heat — 23.02.2021
5Installation
WARNING
Risk of injury due to heavy weight
The tanks are heavy. Consequently, there is a risk of physical injury and accidents.
• Use suitable lifting equipment for transportation and installation.
CAUTION
Risk of scalding
Scalding of the skin and eyes caused by escaping hot water.
• Wear personal protective equipment: Protective gloves, protective clothing, safety goggles.
5.1 Transport
The tank insulation can be removed for transport.
5.2 Installation location
Ensure the following conditions are fulfilled for the installation location:
• Connections must be freely accessible.
• Freedom from frost must be ensured.
• The ground must be load bearing and horizontal.

Commissioning
Storatherm Heat — 23.02.2021
English — 9
5.3 Tank assembly
5.3.1 Installation
Remove the outer packaging and undo the screws with which the tank is screwed to the pallet. Position the tank.
WARNING
Risk of injury due to tipping over of the device
Risk of bruising or crushing caused by tipping over of the device
• Ensure sufficient stability of the device.
5.3.2 Heating system connection
ATTENTION
Device damage from overheating
Incorrect positioning of the safety valve will cause damage to the pipe connections.
• Fit the safety valve between tank and non-return valve.
• Do not close the safety valve vent.
6Commissioning
The responsible installer must explain to the operator how the tank functions and how it is to be used. He/She must
draw attention to maintenance work that has to be carried out at regular intervals. The service life and correct
functioning of the tank are dependent on this. The tank must be emptied if there is a risk of frost, or prior to its
being removed from service.
6.1 Filling the tank
Proceed as follows when filling the tank:
1. Connection to the heating system.
2. Filling of the tank and system.
3. Venting of the tank and system.
4. Checking of the leak-tightness.

Removal from service
10 — English
Storatherm Heat — 23.02.2021
7Removal from service
Remove the tank from service, if malfunctions or leaks occur.
8Maintenance
CAUTION
Risk of scalding
Scalding of the skin and eyes caused by escaping hot water.
• Wear personal protective equipment: Protective gloves, protective clothing, safety goggles.
8.1 Draining
Prior to maintenance, repair or removal from service, disconnect the tank from the heat distribution system and
drain.
Proceed as follows:
1. Disconnect the tank from the heat distribution system
2. Depressurise the tank
3. Drain the tank
8.2 Recommissioning
Rinse the tank thoroughly with water after cleaning or after maintenance. Vent the individual water circuits.
9Recycling
The intentional or unintentional reuse of used components can result in a hazard for persons, the environment and
the system.
Therefore, please observe the following points:
• The operating company is responsible for proper disposal.
• Only to be disposed of by specialist personnel.
• Drain operating liquids and consumables into suitable collection containers and dispose of correctly.
• Upon conclusion of the useful life, strip the system down into different separable materials and deliver to a
specialist company for recycling.
Remove the insulation and dispose of the insulation and basic steel tank separately.

Appendix
Storatherm Heat — 23.02.2021
English — 11
10 Appendix
10.1 Reflex Customer Service
Central customer service
Switchboard: Telephone number: [phone] - 0
Customer Service extension: [phone] - 9505
Fax: [phone] - 9523
E-mail: [e-mail]
Technical hotline
For questions about our products
Telephone number: [phone]
Monday to Friday, 8:00 a.m. – 4:30 p.m.
10.2 Warranty
The respective statutory warranty regulations apply.

SI2176en / 02-2021
Reflex Winkelmann GmbH
Gersteinstraße 19
59227 Ahlen, Germany
Telephone: [phone]
Fax: [phone]
www.reflex-winkelmann.com
