Regency Fireplace Products VF18V-NG Instruction Manual

920-676
Copyright 2023, all rights reserved
U.S. and Foreign Patents Pending
Vent Free Gas Log Sets
INSTALLATION &USER’S
MANUAL
Burner Models: VF18V-NG, VF18V-LP, VF24V-NG, VF24V-LP, VF18E-NG,
VF18E-LP, VF24E-NG. VF24E-LP
SIZES: 18 or 24
WARNING
THIS APPLIANCE IS
EQUIPPED FOR EITHER
NATURAL GAS OR
PROPANE GAS. FIELD
CONVERSION IS NOT
PERMITTED
ANS Z21.11.2-2019,
ANS Z21.60-2017 – CSA
2.26-2017
Report # F19-108
WARNING: If the information in this manual is not followed exactly, a fire or
explosion may result, causing property damage, personal injury, or loss of life.
ꟷDo not store or use gasoline or other flammable vapors and liquids in the vicinity of
this or any other appliance.
ꟷWHAT TO DO IF YOU SMELL GAS
•Do not try to light any appliance
•Do not touch any electrical switch; do not use any phone in your building.
•Immediately call your gas supplier from a neighbor’s phone. Follow the gas
supplier’s instructions.
•If you cannot reach your gas supplier, call the fire department.
ꟷInstallation and service must be performed by a qualified installer, service agency or
gas supplier.
This is an UNVENTED gas-fired heater. It uses air (oxygen) from the room in which it is
installed. Provisions for adequate combustion and ventilation air MUST be provided.
Refer to “SAFETY INFORMATION” in Section 2.0 of this manual.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.

2
Contents
Serial Decals........................................................... 3
Introduction ............................................................ 7
General.......................................................... 7
Technology & Specifications ......................... 7
Specifications............................................. 7
1...1 Gas Types....................................7
1...2 Ignition Type.................................7
1...3 Pilot Type .....................................7
1...4 Controllable Features...................7
1...5 Sizing and Gas Pressures............7
Safety Information.................................................. 9
Usage Instructions............................................... 11
Pre-Usage Information ................................ 11
Guidelines................................................ 11
Operating This Appliance Safely ................. 11
Lighting Instructions .................................... 12
Lighting Inst., Millivolt Variable Control.... 13
1...1 Manual Mode .............................14
1...2 Thermostat Mode .......................14
Lighting Instr., Variable Electronic ........... 15
Cleaning and Servicing ............................... 16
Monthly Cleaning ..................................... 16
Pre-Installation Instructions................................ 17
General........................................................ 17
Pre-Installation Precautions & Safety.......... 17
Burner System Requirements ..................... 17
Vented Installation Restrictions ................... 18
Unvented Installation Restrictions ............... 18
Determining a Confined Space................ 18
Installing in a Confined Space ................. 19
Clearances to Combustibles ....................... 20
Clearance IN FRONT .............................. 20
Clearance ABOVE ...................................20
Fitting the Unit.............................................. 21
Location.................................................... 21
Mounting Clearances ...............................21
Optional Chimney Venting .......................21
Product Installation Illustration .................21
Product Dimensions ................................. 21
Mantel Clearances ................................................22
Preparation ..................................................23
Unpacking ................................................23
Gas Connections...................................... 23
Installation.............................................................24
Installation Safety Information......................24
Fireplace Floor Requirements..................24
Installing the Burner Unit..........................25
Installing the Remote Control................... 26
1...1 Installing the Millivolt Variable
Remote ...................................................26
1...2 Installing the Variable Electronic
Ignition Remote ...........27
Setting the Controls..................................27
Checking the Gas Pressure ..................... 28
Placing Decorative Media ........................29
1...1 Placing Glowing Embers............ 29
1...2 Placing Lava Rock ..................... 29
1...3 Making the Media Consistent .... 29
Log Set Placement................................... 29
Gas Maintenance ..................................................30
Troubleshooting ...................................................31
Vent-Free Logs Parts List ....Error! Bookmark not
defined.
Vent Free Burner System Replacement Parts List
............................................................................40
Indoor Gas Limited Lifetime Warranty............ 45

3
Serial Decals
This is a copy of the label that normally accompanies this gas burner. We have printed a copy of the contents here
for your review. The safety label is located near the gas burner. The serial # will be a total of 9 digits. The first 3
digits (as noted below) represent the model of the gas burner.
NOTE: Regency®units are constantly being improved. Check the label on the unit and if there is a difference, the
label on the unit is the correct one.
Serial Decal for Model # VF18V-LP/VF18E-LP

4
This is a copy of the label that normally accompanies this gas burner. We have printed a copy of the contents here
for your review. The safety label is located near the gas burner. The serial # will be a total of 9 digits. The first 3
digits (as noted below) represent the model of the gas burner.
NOTE: Regency®units are constantly being improved. Check the label on the unit and if there is a difference, the
label on the unit is the correct one.
Serial Decal for Model # VF24V-LP/VF24E-LP

5
This is a copy of the label that normally accompanies this gas burner. We have printed a copy of the contents here
for your review. The safety label is located near the gas burner. The serial # will be a total of 9 digits. The first 3
digits (as noted below) represent the model of the gas burner.
NOTE: Regency®units are constantly being improved. Check the label on the unit and if there is a difference, the
label on the unit is the correct one.
Serial Decal for Model # VF18V-NG/VF18E-NG

6
This is a copy of the label that normally accompanies this gas burner. We have printed a copy of the contents here
for your review. The safety label is located near the gas burner. The serial # will be a total of 9 digits. The first 3
digits (as noted below) represent the model of the gas burner.
NOTE: Regency®units are constantly being improved. Check the label on the unit and if there is a difference, the
label on the unit is the correct one.
Serial Decal for Model # VF24V-NG/VF24E-NG

7
Introduction
This document provides user and installation
information for the Regency Vent Free Log Sets. It
is intended to be installed as an unvented
supplemental heating appliance in a new or existing
site.
General
It is important that you read and follow these
instructions carefully if intending to use or install this
appliance. Pay close attention to all safety and
operational instructions contained in this document.
Technology & Specifications
•Lifelike coals and flaming logs are created by
applying a flame source to the appropriate
media.
•Because it uses gas (LP or Natural), the fire
also provides heat that is radiated from the hot
media elements within an enclosure.
•The output is a such a level that a vent is not
required (as long as safety conditions are met).
Specifications
1...1 Gas Types
•Natural
•LP (Propane)
1...2 Ignition Type
•Manual Hand-Held Flame Source can be used
on all models as backup for Piezo lighter
•Manual Piezo (Continuous Pilot Light) used on
the “Millivolt Variable Control” models
•Automatic Piezo (Non-Continuous Pilot Light)
used on the “Variable Electronic” models
1...3 Pilot Type
ODS (Oxygen Depletion Sensing)
1...4 Controllable Features
•Wireless remote control
•Flame On/Off, manual
•Flame On/Off, remote thermostatic setting
•Flame height and intensity, manual setting
•Flexible Media Placement
1...5 Sizing and Gas Pressures
Refer to Tables 1 & 2 for sizing information and gas
pressures/BTU ratings for the various models. Note
that the gas pressure requirements do not change
for the 2 types of valve and control options that are
offered.
Important: For safe operation and proper
performance of this product and to comply with
certification, listings, and building code acceptances,
use ONLY Regency controls, parts & accessories
that have been specifically listed or certified for use
with this burner system. Use of other controls, parts,
or accessories is prohibited and will void all
warranties, certifications, listings and building code
approvals, and may cause property damage,
personal injury, and loss of life.

8
MINIMUM SIZE REQUIREMENTS
Burner Model
Minimum Fireplace Size BTU Ratings
Width
Depth Height
Natural Gas
Propane Gas
Front Rear Low
Setting
High
Setting
Low
Setting
High
Setting
VF18V-NG Vent-Free Burner
Millivolt Variable 18 NG
VF18V-LP Vent-Free Burner
Millivolt Variable 18 LP
VF18E-NG Vent-Free Burner
Electronic 18 NG
VF18E-LP Vent-Free Burner
Electronic 18 LP
22” 20” 13” 18” 26k 35k 24k 32k
VF24V-NG Vent-Free Burner
Millivolt Variable 24 NG
VF24V-LP Vent-Free Burner
Millivolt Variable 24 LP
VF24E-NG Vent-Free Burner
Electronic 24 NG
VF24E-LP Vent-Free Burner
Electronic 24 LP
28” 20” 14” 18” 19k 37k 19k 37k
TABLE 1
GAS PRESSURE SPECIFICATIONS
NATURAL GAS
PROPANE GAS
Outlet pressure reading:
(Flame adjustment on high)
Typical 3.5” w.c
Outlet pressure reading:
(Flame adjustment on
high)
Typical 10.0” w.c
Inlet pressure reading
Max. 10.5” w.c
Min. 5” w.c
Inlet pressure reading
Max 13” w.c
Min. 11” w.c
TABLE 2

9
Safety Information
UNVENTED ROOM HEATER GENERAL SAFETY
INFORMATION:
1. Due to high temperatures, this appliance
should be located out of traffic and away
from furniture/draperies.
2. Children and adults should be alerted to the
hazard of high surface temperatures and
should stay away to avoid burns or clothing
ignition.
3. Young children should be carefully
supervised when in the same room with this
appliance.
4. Do not place clothing or any flammable
material on or near your vent-free gas
appliance. Matches, paper, garbage or any
other material must not be thrown on top of
the logs, burner or into the flame.
5. Any safety screen, guard, or barrier removed
for servicing this appliance must be
replaced prior to operating the heater.
6. Installation and repair should be done by a
qualified service person. The appliance
should be inspected before use and at least
annually by a professional service person.
More frequent cleaning may be required due
to excessive lint from carpeting, bedding
material etc. It is imperative that control
compartments, burners, and circulating air
passageways of the appliance be kept clean.
7.
8.
9. Do not block air intakes any manner and
maintain adequate clearances to enable the
free flow of air.
10. This heater shall not be installed in a room
or space unless the required volume of
indoor combustion air is provided by the
method described in the National Fuel Gas
Code, ANSI Z223.1/NFPA 54, the
International Fuel Gas Code, or applicable
local codes.
11. Provide adequate clearances for servicing
and operation.
12. Do not install this appliance directly on
combustible flooring. Be certain that the top
surface of the combustible flooring material
(i.e. carpet, tile, etc.) is not too close to this
gas appliance. If this appliance is at floor
level or less than 6” above the top surface of
the flooring material, there must be at least
12” of noncombustible material between the
base of the fireplace and any surface of the
combustible flooring.
WARNING: FIRE, EXPLOSION, AND
ASPHYXIATION HAZARD
Improper adjustment, alteration, service,
maintenance, or installation of this heater or
its controls can cause death or serious
Injury.
Read and follow Instructions and
precautions in this User's Information
Manual provided with this heater
This appliance is intended for supplemental
heating.
IMPORTANT - CO Detectors:
Make sure your home has a working CO
detector, especially near any bedrooms. We
recommend having a CO detector in the same
room as the gas burner for additional safety.
Location of both detectors should be chosen
wisely to avoid false alarms.

10
13. At least 10”-12” of noncombustible or
heat-resistant material is required above the
fireplace. A fireplace hood will be required to
act as a heat deflector in protecting
combustible fireplace surrounds (facing
and/or mantel) if certain minimum
clearances cannot be met. See the
“Clearances to Combustibles” section /
Mantel Clearances (figure 14) in this manual.
14. A vent-free room heater having an input
exceeding 10,000 BTU per hour (2,931 Watts)
shall not be installed in a bedroom or
bathroom (ANSI Z21.11.2). This includes ALL
models in this manual.
15. A vent-free room heater having an input
exceeding 6,000 BTU per hour (1,758 Watts)
shall not be installed in a bathroom (ANSI
Z21.11.2). This includes ALL models in this
manual.
16. WARNING: Failure to keep the primary air
opening(s) of the burner(s) clean may result
in sooting and property damage.
17. WHEN INSTALLING AS A DECORATIVE
VENTED APPLIANCE, THE UNIT MUST
CONFORM TO ALL LOCAL CODES OR, IN
THE ABSENCE OF LOCAL CODES, TO THE
NATIONAL FUEL GAS CODE ANSI
Z223.1/NFPA 54.
18. The appliance and its appliance main gas
valve must be disconnected from the gas
supply piping system during any pressure
testing of that system at test pressure in
excess of ½ psi (3.5 kPa). The appliance
must be isolated from the gas supply piping
system by closing its equipment shutoff
valve during any pressure testing of the gas
supply piping system at test pressure equal
to or less than ½ psi (3.5 kPa).
19. Keep the area around your gas appliance
clear of combustible materials, gasoline, and
any other flammable vapors/liquids. Be
especially cautious if the gas appliance is
installed in a basement or converted garage.
20. Do not us this appliance if any part has
been underwater. Immediately call a
qualified professional service technician to
inspect the appliance and to replace a part
of the control system and any gas control
which has been under water.
21. Perform a periodic visual check of the
pilot and burner flame. It should appear as
shown in Figure 1.
22. WARNING: This appliance is for
installation only in a solid-fuel burning
masonry or Ul 127 factory-built fireplace or
in a listed ventless firebox enclosure. It has
been design certified for these installations.
Exception: DO NOT Install this appliance in a
factory-built fireplace that includes
instructions stating it has not been tested or
should not be used with unvented gas logs.
23. WARNING: Before installing in a solid-fuel
burning fireplace, the chimney flue, damper
and firebox must be thoroughly CLEANED of
soot, creosote, ash, and loose paint by a
qualified chimney cleaner.
24. WARNING: DO NOT ALLOW FANS TO
BLOW DIRECTLY INTO THE FIREPLACE.
AVOID ANY DRAFTS THAT ALTER FLAME
PATTERNS.
25. WARNING: DO NOT USE A BLOWER
INSERT, HEATER EXCHANGER INSERT, OR
OTHER ACCESSORY NOT APPROVED FOR
USE WITH THIS HEATER.
26. A fireplace screen must be in place when
this appliance is operating, unless other
provisions for combustion air are provided,
the screen has an opening(s) for
introduction of combustion air.
27. It is important to use the gas logs based
on the minimum size fireplace as indicated
in the “Product Drawing” section showing
the height and width of the front opening
and depth.
28. SOLID-FUEL MUST NOT BE BURNED in
the fireplace where this unvented gas
appliance is installed.
29. GLASS DOORS MUST BE FULLY OPEN
when this vent-free gas appliance is
operating. This appliance MUST NOT BE ON
if glass doors are closed, as it can lead to
sooting, burner outages and possibly
explosion, causing damage or injury.
30. Any outside air ducts and/or ash dumps
located on the floor or walls of the fireplace
must be permanently sealed shut before the
installation. Use heat-resistant sealant. Do
not seal chimney flue damper.

11
31. STATE AND LOCAL CODES MAY ONLY
ALLOW OPERATION OF THIS APPLIANCE
IN A VENTED CONFIGURATION. CHECK
YOUR STATE OR LOCAL CODES.
32. WARNING: CARBON MONOXIDE
POISONING MAY LEAD TO DEATH.
Early signs of carbon monoxide poisoning are
similar to the flu, with headaches, dizziness,
and/or nausea. If you have these signs, the gas
appliance may not be installed correctly, or may
not be working properly.
GET FRESH AIR AT ONCE! STOP USING THE
APPLIANCE IMMEDIATELY!
Some people, including pregnant women;
persons with heart or lung disease, asthma, or
anemia; those under the influence of alcohol;
and persons at high altitudes, are more affected
by carbon monoxide than others. (The
appliance must be serviced by a qualified
professional service technician before use).
33. If any soot appears on the appliance or other
areas of the fireplace in which this appliance is
installed, shut the system off and call a qualified
professional service technician, vent-free gas
burner system technician, or your local gas
company.
34. This appliance may be installed in an
aftermarket, permanently located, manufactured
(mobile) home where not prohibited by local
codes. Installation of appliances designed for
manufactured homes or mobile homes must
conform with Manufactured Home Construction
and Safety Standards, Title 24 CFR, Part 3280
in the U.S.; or with CAN/CSA Z240 MH, Mobile
Housing in Canada; or with ANSI/NCSBCS
A225.1/NFPA 501A, Manufactured Home
Installations Standard when none of the
previously referenced standards are applicable.
35. This appliance has been certified for indoor
use only.
36. This product certified and listed is for use in
the USA only.
WARNING: THIS APPLIANCE IS EQUIPPED FOR
EITHER NATURAL GAS OR PROPANE GAS.
FIELD CONVERSION IS NOT PERMITTED.
Usage Instructions
Pre-Usage Information
Please read the information below before using this
appliance. It is important that you fully understand
how to operate the controls, provide adequate
ventilation, and know how to safely light this product
before using.
Guidelines
It is imperative that you maintain your unvented
gas appliance by having it cleaned and serviced
regularly.
This burner system is equipped with an Oxygen
Depletion Sensor (ODS) safety pilot system. The
ODS senses the amount of oxygen available in the
room and shuts the burner system off before the
oxygen level drops below 18%.
The pilot can only be relit when fresh air is available.
This may require opening a window or a door to
another room or cracking the damper open
slightly.
When using fireplaces, basic precautions should
always be followed to reduce the risk of fire and
injury to persons, including the following:
1. Read all instructions before installing or
using this appliance.
2. Internal components are hot when in use. To
avoid burns, do not let bare skin touch hot
surfaces.
3. May be used indoors only.
4. To disconnect, turn controls to OFF.
5. Do not block exhaust openings and
always allow for adequate flow.
6. Use this appliance only as described in this
manual. Any other use not recommended by
the manufacturer may cause fire, shock or
injury to persons.
7. SAVE THESE INSTRUCTIONS
Operating This Appliance Safely
Please read the information below carefully before
operating your unvented gas appliance. This
appliance must be operated correctly to prevent loss
or damage.

12
1. Make sure there is adequate combustion and
ventilation air when this gas appliance is
operating. You may need to crack damper or
open window slightly.
2. THIS APPPLIANCE MUST BE MAINTAINED
IN A WELL-CLEANED CONDITION AT ALL
TIMES. REGULAR (AT LEAST ONCE PER
YEAR) CLEANING OF THE BURNER AND
ODS PILOT IS REQUIRED BY A QUALIFIED
PROFESSIONAL SERVICE TECHNICIAN.
3. To light this appliance, it may be necessary to
purge the unit for longer than one minute after
long periods of non-use.
4. If you operate this vent-free gas appliance
fueled by LP, operating characteristics may vary
as the fuel in the tank approaches empty (less
than ¼ full). Sooting and other increases in
combustion by-products will occur. If this
happens, turn off the appliance, refill the LP
tank, and have the burner cleaned.
5. During manufacturing, various parts of this unit
are treated with oils or paints. Though not
harmful, they may produce annoying smoke and
smells as they are burned off during initial
operation. This is a normal occurrence. Initial
break-in period should last four to six hours;
maximum ventilation should be provided by
opening windows, doors, or chimney flue.
6. If the gas quality is poor or pressure low, your
ODS pilot may not stay lit, the burners may
produce soot, or the unit may backfire. Contact
your local gas supplier immediately.
7. This appliance is designed for adults to be
present while in operation. Do not leave this
unit burning when unattended or while
anyone is sleeping. This is an attended
appliance.
8. Burning candles, air fresheners and sprays will
cause objectionable odors to be created by the
unvented burner system.
Lighting Instructions
FOR YOUR SAFETY. READ BEFORE LIGHTING
WARNING
If you do not follow these instructions exactly, a fire
or explosion may result, causing property damage,
personal injury or loss of life
Do not use this appliance if any part has been
underwater. Immediately call for a qualified
professional service technician to inspect the
appliance and to replace any part of the control
system and any gas control that has been
underwater
BEFORE LIGHTING, smell around the gas burner
system area for gas. Be sure to smell next to the
floor, as some gas is heavier than air and will settle
on the floor. IF YOU SMELL GAS, FOLLOW
INSTRUCTIONS ON THE COVER PAGE OF THIS
MANUAL.
Use only your hand to push in or turn gas control
knobs. Never use tools. If a knob will not push in or
turn by hand, don’t try to repair it. Call a qualified
professional service technician. Forcing any controls
or attempting repairs may result in fire or explosion.
For each of the lighting options described below,
adjust the gas flow to have the appearance and
flame height as shown in Figure 1. It is important to
have a flame that is balanced with glowing embers
on the bottom and flames that do not extend too
much above the logs. Observe the flames. The main
burner flames should be blue at the base and a
combination of blue/yellow at the body and the tips.
They should be 5” to 8” above the logs, with the
center flame being the tallest. Front flames in the
ember burner should be ¼” above the embers.
NOTE: The Regency burner system uses an Oxygen
Depletion Sensing (ODS) pilot as shown in Figure 2
Figure 1
WARNING!
Do not operate this appliance if damaged or
has malfunctioned. Call a qualified service
technician to inspect it. Replace any part of
the system as necessary before reuse.
!

13
(Millivolt Variable Control & Variable Electronic).
When starting the ODS pilot, follow the instructions
that pertain to your log set model exactly.
The angle of the pilot flame touching the
thermocouple, as set by the factory, is very important
to maintain. The alignment and orientation of the
ODS pilot is slightly different when the burner is
equipped for Natural or Propane gas sources (Figure
3). This should be checked periodically while the
pilot is on.
Lighting Inst., Millivolt Variable Control
In this section, refer to Figure 4 for the gas valve and
Figure 5 for the remote control while doing the
following lighting steps for the Millivolt Variable
Control burner system:
1. Turn the Flame Height Control Knob (bottom
knob) clockwise as far as it will go to reach
the “OFF” position.
2. Verify that no gas is present around the
fireplace or burner area (this could take 5
minutes to clear if present).
3. If you still detect gas STOP! Then follow the
“WHAT TO DO IF YOU SMELL GAS”
instructions found on the cover page of this
manual.
4. Turn the Pilot Ignitor Knob (the top knob)
counterclockwise to the “IGN” (ignition)
position.
5. While in the “IGN” position, push the knob in as
far as it will go. This action releases gas flow to
the ODS pilot.
6. While still holding in the Pilot Ignitor Knob in,
turn it counterclockwise to the “PILOT”
position.
7. This will click, then activate the spark ignitor on
the pilot and cause a spark at the pilot which will
ignite the pilot gas.
8. If the spark does not work after repeating steps
5-7, light the pilot with a match.
9. Note: When lighting the pilot, it may be
necessary to push the Pilot Ignitor Knob in for
as long as 30 seconds to allow gas time to
reach the pilot before it will light.
10. Continue to hold the Pilot Ignitor Knob in all
the way for about 30 seconds after the pilot is lit.
11. Release the knob and it will pop back out.
The pilot should remain lit. If it goes out, repeat
steps 4 thru 7.
12. Note: If the knob does not pop up when
released, STOP! The gas valve needs to be
serviced by a Certified Repair Tech.
13. Note: If the pilot does not stay lit after several
tries, turn the gas control knob “OFF” and
STOP! The gas valve needs to be serviced by
a Certified Repair Tech.
14. Turn the Flame Height Control Knob (bottom
knob) counterclockwise to “ON”. Then turn
the Flame Height Control Knob clockwise
to verify that the correct flame height may be
properly controlled.
15. Turn the Flame Height Control Knob to the
OFF position.
Figure 2
Figure 3
ODS Pilot for Millivolt Variable/Variable Electronic Valves

14
Now that the flame control has been verified, refer to
the next section to use the remote control to control
the burner.With the remote, the flame may either be
adjusted manually using buttons or automatically
using a thermostatic setting.
IMPORTANT: The Flame Height Control Knob has
an interlock device. After shutting off all gas flow, the
pilot burner cannot be relit until the thermocouple
has cooled (Approx.60 sec.). The Flame Height
Control Knob is designed to be operated by hand.
DO NOT use any tools during this operation.
Damaged knobs may result in serious injury.
If you expect to not use the burner for an extended
period of time, turn both knobs to the “OFF” position
to completely extinguish the ODS pilot and main
burner. Then shut off the gas supply line valve to the
fireplace.
1...1 Manual Mode
To operate the system in the “MANUAL MODE” do
the following:
TURNING THE FLAME ON
1. Press and hold the ON/HI key until the flame
comes on and reaches the desired flame height
or is burning at full on.
2. Initially, the display will show “HI”, but after 3
seconds it will default to display the room
temperature and the word “TEMP” will be
shown.
TURNING THE FLAME OFF
1. Press and hold the LO/OFF key until the flame
reaches the desired flame height or completely
shuts off.
2. Initially, the display will show “LO”, but after 3
seconds, the display will default to show the
room temperature and the word “TEMP” will be
shown.
Note: The “Flame” icon will show on the display
when in Manual Mode.
1...2 Thermostat Mode
The remote control can be used to thermostatically
control the flame height to automatically set the room
temperature.
To operate the system in the “THERMOSTAT
MODE”, and set a desired room temperature, do the
following:
SETTING DESIRED ROOM TEMPERATURE
1. Press the MODE key until the display shows the
word “ROOM”; the remote is now in the
Thermostat Mode.
2. Press and hold the SET key until the desired set
temperature is reached. (The display will show
temperature numbers increasing from 45F to
99F, then restarting over at 45F.)
3. When the desired temperature shows on the
display, release the SET key.
4. Initially, the display will show the temperature
that has been set, but after 3 seconds, the
display will flash the set temperature for 3 more
seconds.
5. Then, the display will default to show the room
temperature.
Note: The word “ROOM” will show on the display
when in Thermostat Mode.
TO CHANGE THE SET TEMPERATURE
To make a change to an existing temperature
setting, start at Step 2 in the previous instructions for
“SETTING DESIRED ROOM TEMPERATURE”.
NOTE: The highest SET temperature is 99 degrees
Fahrenheit (32 degrees Celsius) and the lowest
temperature is (45 degrees Fahrenheit (6 degrees
Celsius)
Figure 4

15
Lighting Instr., Variable Electronic
In this section, refer to Figure 6 for the gas valve and
Figure 7 for the remote control while doing the
following lighting steps for the Variable Electronic
burner system:
1. Verify that the Main Valve Knob is in the “OFF”
position.
2. Verify that the Manual Knob is in the is in the
“ON” position.
3. Verify that the On/Off Switch is in the “I” (ON)
position.
4. On the remote control, Hold the “ON/OFF”
button down until you hear two beeps. This will
automatically light the pilot and turn the Main
Gas Knob to the “ON” position.
5. You should hear the spark ignitor attempting to
light the pilot and before gas flows to the burner.
6. If the burner does not light after a maximum of
60 seconds STOP!, TURN OFF GAS SUPPLY
and get assistance from qualified service
personnel.
7. When pilot ignition is confirmed, the burner will
be at maximum flame height.
8. Hold down the “-“ sign (Flame Down Button) to
decrease & the “+” sign (Flame Up Button) to
increase the flame height.
9. Double-clicking “+” sets the flame to max
height.
10. Double-clicking “-“ sets the flame to min
height.
11. Holding the “-“ until the flame goes out leaves
the pilot on and puts the burner in Standby
Mode.
12. Hold the “ON/OFF” button down until you
hear a single beep to turn the valve completely
OFF.
In the event the remote control’s transmitter or valve
control receiver fails to operate, follow these steps to
light the fireplace manually:
1. Make sure the Main Valve Knob (bottom knob)
is fully clockwise to the OFF position.
2. Make sure the Manual Knob if fully clockwise
to the “MAN” position.
3. Make sure the “On/ Off” Switch is in the “O”
(OFF) position.
4. Verify that no gas is present around the
fireplace or burner area (this could take 5
minutes to clear if present).
5. If you still detect gas STOP! Then follow the
“WHAT TO DO IF YOU SMELL GAS”
instructions found on the cover page of this
manual.
6. Place On/Off Switch in the “I” (ON) position.
7. Using a pen or appropriate small tool, push the
Manual Pilot Valve all the way in and hold. This
starts the flow of gas to the pilot.
8. Note: When lighting the pilot, it may take as
much as 30 seconds for gas to reach the pilot.
9. While still pushing the Manual Pilot Valve, push
in the Piezo Ignitor to ignite the pilot.
10. Wait 10 seconds after the pilot is lit, then
release the Manual Pilot Valve.
11. If the pilot does not stay lit when you release
the Manual Pilot Valve, wait five (5) minutes and
repeat the above steps.
12. Turn the Manual Knob counterclockwise
until it is in the “ON” position.
13. Turn the Main Valve Knob all the way
counterclockwise to the “ON” position.
14. If the burner does not light STOP!, TURN
OFF GAS SUPPLY and get assistance from
qualified service personnel.
15. Use the Main Valve Knob to adjust the flame
to the desired height.
Figure 5

16
If you expect to not use the burner for an extended
period of time, turn the Main Valve Knob to the
“OFF” position, turn the Manual Knob to the “MAN”
position, and turn the On/Off Switch to the “O”
position. This will completely extinguish the ODS
pilot and main burner. Then shut off the gas supply
line valve to the fireplace.
Cleaning and Servicing
It is imperative that you maintain your unvented gas
appliance by having it cleaned and serviced
regularly. A qualified professional service technician
shall inspect and service this unit at least annually.
Failure to provide reasonable and necessary
maintenance as outlined in the owner’s manual will
cause your appliance to malfunction and will void
your warranty.
If the flames show any unusual shapes or behavior,
or the burner fails to ignite properly, then the burner
holes may require cleaning.
WARNING: TURN OFF VENT FREE BURNER
SYSTEM AND ALLOW TO COOL BEFORE
CLEANING OR SERVICING.
Monthly Cleaning
1. If removing logs, when reinstalling, refer to
“LOG PARTS LIST” for correct log placement
2. Do not use cleaning fluids to clean logs or any
part of the system.
3. Brush logs with a soft bristle brush or vacuum
with brush attachment.
4. Vacuum loose particles and dust from the front
and rear burners, gas controls, ignition control &
grate.
5. Inspect and clean ODS pilot and accumulation
of lint at burner ports.
6. Verify flame pattern and log placement for
proper operation
7. Verify smooth and responsive ignition of main
burner and rear burner
Figure 6
Figure 7

17
Pre-Installation Instructions
General
IMPORTANT
Be sure you have read and understand all safety
precautions and warnings contained in this
manual.
Read these instructions carefully and completely
before starting installation of the burner system.
Installation and service must be performed by a
qualified professional service technician, service
agency or the gas supplier.
The Regency burner system must be installed by a
qualified professional service technician. Instructions
must be followed carefully to ensure proper
performance and full benefit from the burner system.
Fireplace floor must be level, clean, and smooth.
This appliance may be installed in an aftermarket,
permanently located, manufactured (mobile) home
where not prohibited by local codes.
This appliance is only for use with the type of gas
indicated on the rating plate. This appliance is not
convertible for use with other gasses.
Pre-Installation Precautions & Safety
CAUTION: Installation and repairs must be done
by an NFI certified or another qualified
professional installer.
Installer: Carefully read these instructions before
installing this gas burner system. Be sure you
understand all safety precautions and warnings
contained in this manual.
1. CAUTION: If not installed, serviced, and
used correctly per these instructions, this
product can cause serious personal injury,
property damage, or loss of life.
2. Some fireplaces (especially older ones) may
need repair prior to installing this appliance.
3. This appliance is only for use with the type of
gas indicated on the rating plate. This appliance
is NOT CONVERTIBLE for use with other
gasses.
4. CHECK GAS TYPE (Natural or L.P.): the gas
supply must be the same as stated on your
burner system rating plate. If the gas supply is
different, DO NOT INSTALL. Contact your
dealer for immediate assistance.
5. INSUFFICIENT GAS PRESSURE WILL KEEP
THE ODS (OXYGEN DEPLETION SENSOR)
PILOT FROM OPERATING PROPERLY. DO
NOT USE IF GAS PRESSURE IS LOWER
THAN THE MINIMUM REQUIREMENTS.
6. The minimum inlet gas-supply pressure for the
purpose of input adjustment is 5” water column
(w.c) on natural gas and 11” w.c. LP gas.
7. The maximum inlet gas-supply pressure is
10.5” w.c. on natural gas and 13” w.c. LP gas.
The LP source must be regulated. (Do not
connect this appliance directly to an
unregulated LP gas tank – this can cause an
explosion.) Do not connect this appliance to
a portable LP gas cylinder.
8. The gas piping system must be sized to
provide minimum pressure at the maximum
flow rate (BTU/Hr). Undue pressure loss will
occur if the pipe is too small, or the run is too
long. Gas supply piping must be ½” minimum
interior diameter. If the gas line is longer than
20’, a larger diameter line may be necessary.
Refer to the NFPA 54 guidelines for further
details.
9. Input ratings shown in BTU per hour are for
elevation up to 2,000 ft. For elevations above
2,000 ft., refer to the National Fuel Gas Code or
contact Regency before installing.
Burner System Requirements
Note: Installation in any other fireplace is prohibited
and will void any approvals and warranties.
This burner system is equipped with an Oxygen
Depletion Sensor (ODS) safety pilot system. The
BEFORE PROCEEDING, CAREFULLY READ
ALL OF THE IMPORTANT SAFETY
INFORMATION CONTAINED IN THIS
OWNER’S MANUAL, INCLUDING:
•Pre-Installation and Fireplace
Preparation Safety Guidelines
•Ventilation and Confined Space
Information
•Installation Safety Guidelines

18
ODS senses the amount of oxygen available in the
room and shuts the burner system off before the
oxygen level drops below 18%.
The pilot can only be relit when fresh air is available.
This may require opening a window or a door to
another room or cracking the damper open slightly.
This burner system has been certified to two
standards:
VENTED DECORATIVE APPLIANCE – ANSI Z21.60
UNVENTED ROOM HEATER – ANSI Z21.11.2
Vented Installation Restrictions
This unit may not be installed in a vented fireplace
with a chimney of less than 15 feet in height.
This burner system may be installed as a vented
decorative appliance in compliance with ANSI
Z21.60 and the national Fuel Gas Code, Section 6.6.
The minimum permanent free opening of the
fireplace chimney or chimney damper must be met
per the Chimney Vent Openings shown in Table 3.
To accomplish this, the chimney damper must be
fixed in a manner to maintain permanent free
opening at all times.
The damper clamp (See Figure 8) with bolt is
provided as a means to prevent the full closure of the
damper blade. The clamp is easily attached to most
damper blades with pliers or a wrench, and must be
permanently installed. The clamp is designed to
prevent accidental closure of the damper when
installed as pictured.
Should the clamp not fit, or fail to provide the
required permanent vent opening, do any of the
following:
•Have a permanent stop installed
•Remove the damper blade
•Install a screw or bolt on the edge of the
damper
•Drill holes in the damper
•Cut the damper providing the minimum
permanent opening required
This damper clamp is not required if the burner
system is installed as an unvented room heater.
Unvented Installation Restrictions
Check local or state codes to determine if vent-free
heaters are permitted in your locality before you
install this burner system as a vent-free appliance. If
not permitted, you may install and operate this
burner system as a vented appliance.
When installed as an unvented decorative gas
appliance, your vent-free gas burner system SHALL
NOT BE INSTALLED IN A CONFINED SPACE OR
UNUSUALLY TIGHT CONSTRUCTION unless
provisions are made for adequate combustion and
ventilation air.
Unusually tight construction is defined as:
1. Walls and ceiling exposed to the outside
atmosphere have a continuous water vapor
retarder with a rating of 1 perm or less with
openings that are sealed or use gaskets;
2. Weather stripping has been added on openable
windows and doors; AND
3. Caulking or sealants are applied to areas such
as joints around window and door frames;
between sole plates and floors; between wall-
ceiling joints; between wall panels; at
penetrations for plumbing, electrical and gas
lines; and other openings.
Determining a Confined Space
•In general, the National Fuel Gas Code, ANSI
Z223.1/NFPA 54 defines a confined space as
a space whose volume is less than 50 cu. Ft
Figure 8
Note: To install the unvented gas burner
system, the fireplace must have a gas-supply
line that has been installed by a qualified
professional service technician in
accordance with all local codes.

19
per 1,000 BTU per hour of the aggregate input
of all appliances installed in that space.
•An unconfined space is a space where the
volume is at least 50 cu. Ft. per 1,000 BTU per
hour of the aggregate input rating of all
appliances installed in that space.
•Rooms communicating directly with space in
which the appliances are installed, through
openings not furnished with doors, are
considered a part of the unconfined space.
WARNING: Do not install the unvented burner
system where the room is considered a confined
space.
To determine if the location that this burner system is
to be installed fits the definition of an unconfined
space, multiply in FEET the length of the room by the
width of the room by the height of the room then
multiply by 20. The result is the maximum BTU’s
allowed.
(Per Figure 9, calculate Length x Width x Height x 20
= Maximum BTU’s Allowed)
WARNING
If the area in which the heater may be operated is
smaller than that defined as an unconfined space of
if the building is unusually tight construction, provide
adequate combustion and ventilation air by one of
the methods described in the National Fuel Gas
Code, ANSI Z223.1/NFPA 54, Air Combustion and
Ventilation, or applicable local codes.
REMEMBER
L x W x H x 20 = MAXIMUM BTU’s ALLOWED
BTU/H Rating High Setting
18" Burner Millivolt Variable/Electronic 35,000 Btu/h
NG
18" Burner Millivolt Variable/Electronic 32,000 Btu/h
LP
24" Burner Millivolt Variable/Electronic 37,000 Btu/h
NG
24" Burner Millivolt Variable/Electronic 37,000 Btu/h
LP
Installing in a Confined Space
If the space is smaller than the above formula allows,
and/or smaller than the diagrams, DO NOT install
the vent-free burner system unless provisions for
additional combustion and ventilation air are made.
IT MAY BE NECESSARY TO OPEN A WINDOW
SLIGHTLY (1”-2”) OR OTHERWISE INCREASE
VENTILATION. CONDITIONS REQUIRING THIS
INCLUDE, BUT ARE NOT LIMITED TO:
1. Installation in a CONFINED SPACE
2. Installation in a HOME OF UNUSUALLY TIGHT
CONSTRUCTION
3. Installation at HIGH ALTITUDES
4. Certain MEDICAL or PHYSICAL CONDITIONS
OF THE HOMEOWNER that may be adversely
impacted by combustion products created by
burning natural or propane gas.
Installation in a home with unusually tight
construction and / or installation at high altitudes
may cause your vent-free burner system to produce
excessive heat or excessive moisture. The oxygen
depletion sensor may shut down the burner system.
These conditions may be corrected by opening a
window or otherwise increasing the number of air
changes in the home.
This vent-free burner system has been certified to
function safely and reliably with emission by-
products well within acceptable safety and health
standards.
Your specific medical or physical condition may
render you more sensitive to products created by
burning natural gas or propane gas. If this is the
case, you should open a window or otherwise
increase ventilation.
Figure 9

20
Clearances to Combustibles
If the vent-free burner system is installed in a factory-
built fireplace, follow the manufacturer’s guidelines
for minimum clearances to combustibles.
In the absence of such guidelines, refer to the
illustration of clearances in Figure 10 and follow the
instructions below:
Note: Clearances to combustible construction are
those distances required to ensure that fireplace
mantels, facings, walls, ceilings, and flooring will not
catch fire.
In most cases, these clearances should also be
adequate to prevent discoloration or warping due to
heat. However, every gas burner installation
presents a different and unique set of circumstances
involving many variables beyond the control of the
manufacturer.
These include paint or finish composition, previous
exposures to heat, methods and quality of
construction, air flow patterns, glass doors, fans or
blowers, etc.
Because of these variables, we cannot guarantee
that heat warping or discoloration will never occur.
The potential for heat warping or discoloration may
exist no matter what item(s) you are burning in the
fireplace, including wood.
These dimensions are MINIMUM CLEARANCES to
maintain when you install this burner system. The
fireplace opening MUST BE AT LEAST 6” from any
combustible sidewall. The ceiling MUST BE AT
LEAST 42” from the top of the fireplace opening.
Clearance IN FRONT
Be certain that combustible flooring material (i.e.
carpet, tile, etc.) is not too close to the vent-free unit.
If the vent-free burner system is at floor level or
less than 6” above the floor, there MUST be at
least 12” (1 foot) of noncombustible material
between the front of the fireplace and any
combustible flooring.
Clearance ABOVE
To install the vent-free burner system, there must
ALWAYS be noncombustible or heat resistant
material immediately above the fireplace opening.
Heat resistant material (i.e. marble, or slate) must be
at least 5/8” thick. Sheet metal should not be
installed onto combustible materials.
If you DO NOT install a fireplace hood, there MUST
be at least 12” of noncombustible or heat resistant
material immediately above the fireplace opening.
If you DO install a fireplace hood, there MUST be at
least 10” of noncombustible or heat resistant material
immediately above the fireplace opening.
If there is a wooden mantel, shelf or other
combustible projection above the fireplace, follow the
clearances information in Figure 11 in this manual.
A fireplace hood deflects heat away from the
fireplaces face and mantel, reducing the potential for
heat related warping or discoloration. The use of a
fireplace hood is highly recommended.
DO NOT place any combustible decorations/items
on the mantel or above the fireplace.
Clearances to Combustible Construction:
Sidewalls: 6” from side of fireplace opening.
Ceiling: 42” from top of fireplace opening.
Flooring: See 5.6.1 CLEARANCE IN FRONT.
Mantel:
See 5.6.2 CLEARANCE ABOVE.
Figure 10
IF YOU CANNOT MEET THESE MINIMUM
CLEARANCES, YOU M
UST OPERATE THE
VENT-
FREE BURNER SYSTEM WITH THE
CHIMNEY FLUE DAMPER OPEN.
