Regency Fireplace Products SIT WiFi Guide User manual

920-729 09.25.23
FPI Fireplace Products International Ltd.
6988 Venture St.,
Delta, B.C. Canada, V4G 1H4
SIT WIFI GUIDE
WIFI KIT PART #946-799
PLEASE KEEP THESE INSTRUCTIONS
FOR FUTURE REFERENCE
www.regency-re.com
SIT WiFi Guide Instructions

2SIT WiFi Guide
SIT WiFi Guide Instructions
TABLE OF CONTENTS
WIFI COMPATIBLE HARDWARE ...................... 3
WIFI COMPATIBLE UNITS.............................. 3
PROFLAME CONNECT PLUS APPLICATION ...... 3
INTRODUCTION............................................ 4
SETTING UP YOUR FIREPLACE....................... 5
ADDITIONAL MENUS AND ADVANCED SETTINGS 8
OPERATION .................................................. 9
USING THE APP IN CONJUNCTION WITH THE REMOTE 11
RE-PAIRING THE FIREPLACE WITH THE APP... 12

3
SIT WiFi Guide
SIT WiFi Guide Instructions
WIFI COMPATIBLE HARDWARE
• IFC: 911-311
• Remote: 911-341 (white wall mount), 911-355 (black handheld)
• 946-799 WiFi Kit
Dongle + Cable: 911-323
Velcro to secure WIFI dongle (If required)
• THE DONGLE ONLY CONNECTS TO 2.4 GHz WIFI NETWORKS.
 oCheckyourrouter’smanualorcontactyourlocalInternetServiceProvidertoconrm
your router is set up as a 2.4 GHz network.
o Check your router for the highlighted Wireless Standards for 2.4 GHz compatibility:
IEEE 802.11 b/g/n/ax 2.4GHz
WIFI COMPATIBLE UNITS
• CB40E-12
• CV40E-12
• CC40LE-12
• CC40RE-12
• CB60E-1
• CV60E-1
• CST60E
• CP60E
• CV72E-12
• CB72EPV
• Gi29LE
• Gi33LE
PROFLAME CONNECT PLUS APPLICATION
•ProameConnectPlusappcanbefoundintheGoogle Play Store for Android devices and the
App store for Apple devices.
• Phone with Android 6.0 and up required
• Phone with iOS 11.4 or later required
• HAVE YOUR PERSONAL WIFI PASSWORD READY

4SIT WiFi Guide
SIT WiFi Guide Instructions
INTRODUCTION
FireplacescanberemotelycontrolledbyAndroid/iOSProameConnectapplicationsaslongasthereplacehasaIFCcontrolboardthatisWIFI
capable.ThisWIFIguidewillnotewhichreplacesareapprovedforusewiththisWIFIkit.
TheconnectivitytotheProameIFCisprovidedbyProameWiFiDongle.ThedongleisconnectedtotheIFCthroughX0Aserialportanditconnects
to an existing WiFi network.
ThesetupofProameWiFiDongleisdonecreatingastandaloneWiFinetworkwithadedicatedaccesspoint.
Theappallowstoremotelycontrolthereplaceusingonlythelocalconnection:alldataareexchangedinthelocalWiFiandnopacketsare
exchanged with external servers.
Only with virtual assistants Alexa and Google Assistant, the dongle has a connection outside the local WiFi, connecting to the Amazon Web
Services (AWS). This it is a secure connection.
Android and iOS applications can be found in their respective stores: Play Store and App Store.
Note: Please ensure that the WIFI dongle is synced to the app and functioning before closing the unit when going thru these instructions. The
WIFI dongle should automatically go into AP mode (Red & Green LED's on) upon initial connection to IFC board.
IftheWIFIdongleisnotinAPmodeduringinitialsetup,pleaserefertotherepairingthereplacewiththeAPPsectionoftheseinstructions.

5
SIT WiFi Guide
SIT WiFi Guide Instructions
SETTING UP YOUR FIREPLACE
1. FindtheProameConnectPlusAppinthe
App Store or Google Play Store. Download
and open.
2. Terms and Conditions of Use screen will
pop up. Please read through the document
carefully and tap “I ACCEPT” to proceed.
3. Privacy Policy screen will pop up. Please
read through the document carefully and
tap “I HAVE READ AND UNDERSTOOD” to
proceed.
5. Tap ''Join''.
4. Select"Addanewreplace".
6. Once replace is found, tap “Conrm” to
proceed.

6SIT WiFi Guide
SIT WiFi Guide Instructions
7. Enter the name and password of your
home’s WIFI Network.
8. Nameyourreplace.
9. Tap “Continue” to proceed once replace
is successfully added. If you have multiple
replaces, follow steps 4-9 again to set
them up.
10. Once set up is complete, the app will search
forthereplace.Taponthereplaceyou
want to control.
11.Turn on the replace by pressing the
power symbol on the top right corner of
theblockandthenpressing“Conrm”on
the pop-up screen.

7
SIT WiFi Guide
SIT WiFi Guide Instructions
12.Presstheblocktochangereplacelevels
and modes.
13.Toturnthereplaceo,pressthepower
symbol at the top right of the block
and then press “Conrm”. The app will
rememberthelastmodethereplacewas
set to when turning back on.

8SIT WiFi Guide
SIT WiFi Guide Instructions
ADDITIONAL MENUS AND ADVANCED SETTINGS
1. Tap the hamburger symbol at the top right of the screen to access additional menus, options and features.
2. Tocongurefeaturesintheapp,tapAdvancedsettings.Hereyoucanchoosewhichfeaturesareshowninthehomescreen.
Note:Theappcannotdetectwhatfeaturesyourreplacehas.Youwillhavetotoggletheunusedfeaturesomanuallyifyoudonotwant
to see them on the home screen.
a. Splitow:UnitswithsecondaryburnersavailablecanhavethesecondaryburnerscontrolledbytheSplitowvalve.EnablingSplitow
will allow the app to control the secondary burner.
b. Aux output: Secondary lights or fans on some units are connected and controlled by the auxiliary port on the IFC. Enabling Aux output
will allow the app to control the secondary lights or fans connected.
c. Temperature Unit °C °F: The temperature unit the app displays can be changed depending on your preference. Tap °C or °F.
d. Pilot CPI/IPI: Toggle the pilot to be continuous pilot or intermittent pilot depending on your preference. See the Continuous Pilot/
Intermittent Pilot section in your unit’s manual for more information.
3. Tap List of local replacestoseethereplacesalreadyconnectedtoyourhomenetwork.
4. Tap Add a new replacetoconnectanotherreplaceyourhomenetwork.
5. Tap Edit the replace nametochangethenameofthereplacealreadyconnectedtoyourhomenetwork.
6. Tap Change the app skin to change the color theme of the app.
7. Tap Information for more information about the app.
8. Tap Reset app to reset all the app’s settings.
9. Tap Sign in account to log into your account.
10. Tap Account List Fireplacetolistreplaceslinkedtoyouraccount.

9
SIT WiFi Guide
SIT WiFi Guide Instructions
OPERATION
Thereplacecanbeoperatedusingtheapportheremoteincludedwiththeunit.Theremoteneedstobesyncedtotheunitinordertouse
thermostat (T-stat) and Smart thermostat (Smart) modes from the app. This is because the remote measures the ambient temperature in the
room and transmits it to the app.
Manual Mode:
•Toincreasetheameheight,dragtheslidernexttotheamesymboltowardstheright.
•Todecreasetheameheight,dragtheslidernexttotheamesymboltowardstheleft.
• To increase the fan speed, drag the slider next to the fan symbol towards the right.
• To decrease the fan speed, drag the slider next to the fan symbol towards the left.
• To increase the lamp brightness, drag the slider next to the lamp symbol towards the right.
• To decrease the lamp brightness, drag the slider next to the lamp symbol towards the left.
•Thereplacewillcontinuetorunwhentheappisclosed.Openingtheappwillautomaticallysearchforthereplaceontheconnectednetwork.

10 SIT WiFi Guide
SIT WiFi Guide Instructions
Thermostat Mode (T-stat):
• Set the temperature at which the replace will turn on at by
dragging the slider next to the thermometer symbol left or right.
•Theame,fan,andlamplevelatwhichthereplacewillrunatcan
be adjusted by dragging the slider beside the respective symbols
left or right.
• Note, the ame height, fan speed, and lamp brightness will not
change as room temperature increases or decreases. They will run
at the level you set it at.
Smart Thermostat Mode (Smart):
• Set the temperature at which the replace will turn on at by
dragging the slider next to the thermometer symbol left or right.
• Thefanandlamplevelat which the replace will runat can be
adjusted by dragging the slider beside the respective symbols left
or right.
• Note,theameheightwillvaryasroomtemperatureincreasesor
decreases. Fan speed and lamp brightness will not change as room
temperature increases or decreases and will run at the level you set
it at.

11
SIT WiFi Guide
SIT WiFi Guide Instructions
USING THE APP IN CONJUNCTION
WITH THE REMOTE
• Please ensure your remote contains working batteries. The remote
must still be supplied with power to measure your room temperature
and transmit that measurement to the app.
• If the remote batteries have died, or the remote is lost, or the remote
becomes unpaired, you will only be able to use the app in Manual
mode.
• Use of the remote while the app is controlling the replace will
surrendercontrolofthereplacetotheremote.Theappwillnotbe
abletogaincontrolbackuntiltheunitisturnedousingtheremote.

12 SIT WiFi Guide
SIT WiFi Guide Instructions
RE-PAIRING THE FIREPLACE WITH THE APP
To re-pair your unit to your home network:
1. Locatethedongleinyourreplace.
Note:DependingonwheretheWIFIdongleisplaced,aqualiedservicetechnicianmayberequiredtore-pairthereplacetoyourhome.
2. Press and hold the yellow button on the dongle for 5-10 seconds.
3. The dongle should now be in Access Point (AP) mode as shown by a solid Red and Greed LED on the dongle.
3. Thereplacecannowbesetupbyfollowingtheinstructionsunderthe"SettingUpYourFireplace"section.
5. Alternately blinking Red and Green LEDs on the dongle means it is trying to connect to your home network.
6. Oncethereplaceissetupandconnectedtothehomenetwork,thedongleshouldhaveasolidGreenLEDononly.
SIT Instructions for Reference
https://proame.sitgroup.it/media/96/t-le/Proame-WIFI-Dongle-Use-and-Installation-Instructions.pdf

13
SIT WiFi Guide
SIT WiFi Guide Instructions
notes
