Regency FireGenie PG121-NG1 Quick start guide

08/04/15
Zero Clearance Room
Sealed Gas Fireplace
FOR YOUR SAFETY
What to do if you smell gas:
Do not try to light any appli-
ance
Do not touch any electri-
cal switch: do not use any
phone in your building.
Immediately call your gas
supplier from a neighbour's
phone. Follow the gas sup-
plier's instructions.
If you cannot reach your
gas supplier, call the re
department.
WARNING:
Improper installation, adjustment, altera-
tion, service or maintenance can cause
injury or property damage. Refer to this
manual. For assistance or additional in-
formation consult an authorized installer,
service agency or the gas supplier.
FOR YOUR SAFETY
Do not store or use gasoline or other am-
mable vapours and liquids in the vicinity of
this or any other appliance.
Installation and service must be performed
by an authorized installer, service agency or
the gas supplier.
PLEASE KEEP THESE INSTRUCTIONS
FOR FUTURE REFERENCE
Owners &
Installation
Manual
LISTINGS AND CODE APPROVALS
These gas appliances have been tested
in accordance with AS4553, NZS 5262
and have been certied by the Australian
Gas Association for installation and op-
eration as described in these Installation
and Operating Instructions.
Your unit should be serviced annu-
ally by an authorised service person.
918-648d
STYLE MODEL
See Thru PG121-NG1 PG121-LPG1
Left Corner PG121LC-NG1 PG121LC-LPG1
Right Corner PG121RC-NG1 PG121RC-LPG1
Pier PG131-NG1 PG131-LPG1

Regency PG121/PG131 Zero Clearance Room Sealed Gas Fireplace
2
To the New Owner:
Congratulations!
You are the owner of a state-of-the-art Gas Fireplace by REGENCY. The PG121-1 / PG121LC-1 /
PG121RC-1 / PG131-1 has been designed to provide you with all the warmth and charm of a wood
replace at the ick of a switch. The model PG121-1 / PG121LC-1 / PG121RC-1 / PG131-1 has
been approved by the Australian Gas Association for both safety and efciency. As it also bears
our own mark, it promises to provide you with economy, comfort and security for many trouble free
years to follow. Please take a moment now to acquaint yourself with these instructions and the
many features of your Regency Fireplace.
IMPORTANT:
If the unit is to be installed into a bathroom, optional Neo ceramic glass Part# 360-946 (Front) or
Part# 360-948 (Side) must be purchased and installed in place of the tempered glass supplied
with the unit.

Regency PG121/PG131 Zero Clearance Room Sealed Gas Fireplace 3
TABLE OF CONTENTS
OPERATING INSTRUCTIONS
Operating Instructions .............................................. 30
Lighting Procedure ................................................... 30
Shutdown Procedure ................................................ 30
First Fire ................................................................... 30
Normal Operating Sounds of
Gas Appliances .................................................. 30
Aeration Adjustment ................................................. 30
Lighting Plate Instructions ........................................ 31
MAINTENANCE
Maintenance Instructions ......................................... 31
General Flue Maintenance ....................................... 31
Log Replacement ..................................................... 32
Thermopile/Thermocouple........................................ 32
Glass Gasket ............................................................ 32
Door Glass................................................................ 32
Gold-Plated Accessories .......................................... 32
Valve Tray Replacement ........................................... 32
Manual Control Replacement ................................... 34
PARTS LIST
Electronic Components List ...................................... 35
Replacement/Spare Parts List .................................. 36
WARRANTY
Warranty ................................................................... 42
DATA BADGE
Data Badge................................................................. 4
INSTALLATION
Important Message ..................................................... 5
Before You Start ......................................................... 5
General Safety Information......................................... 5
Installation Checklist ................................................... 5
Specications ............................................................. 6
Locating Your Fireplace .............................................. 8
Clearances ................................................................. 9
Combustible Mantel Clearances ................................ 9
Framing and Finishing .............................................. 10
Facing and Finishing Requirements ..........................11
Unit Assembly Prior to Installation
Top Standoff Assembly........................................11
Flueing Introduction ...................................................11
Exterior Flue Termination Locations ......................... 12
Flueing: Direct Vent System (Flex) ........................... 13
Flueing: Simpson Dura-Vent Direct Vent GS ........... 14
Flueing: Simpson Dura-Vent Components List......... 14
Flueing Arrangements
Horizontal Terminations ..................................... 15
Vertical Terminations .......................................... 17
Flueing - Dura-Vent Horizontal Installations ............. 19
Flueing - Dura-Vent Vertical Termination .................. 20
Flueing - Installation Procedures for Direct Vent
System (Flex) ..................................................... 21
Conversion from NG to LPG..................................... 22
System Data ............................................................. 23
Gas Line Installation ................................................. 24
Pilot Adjustment ........................................................ 24
Gas Pipe Pressure Test ............................................ 24
SIT Valve Description ............................................... 24
Log Set Installation ................................................... 25
Glass Door Removal ................................................ 27
Finishing Trim ........................................................... 27
Louvers and Grills..................................................... 27
Remote Control (optional) ........................................ 28
Remote Wall Switch (optional) ................................. 28
Wall Thermostat (optional)........................................ 28
Wiring Diagram ......................................................... 28

Regency PG121/PG131 Zero Clearance Room Sealed Gas Fireplace
4
SAFETY LABEL
This is a copy of the label that accompanies each
PG121-1 / PG121LC-1 / PG121RC-1 / PG131-1
Zero Clearance Room Sealed Gas Fireplace.
We have printed a copy of the contents here
for your review. The safety label is located on
the front inside base of the unit, visible when
the bottom louver is open.
NOTE: Regency units are constantly being
improved. Check the label on the unit and if
there is a difference, the label on the unit is
the correct one.

Regency PG121/PG131 Zero Clearance Room Sealed Gas Fireplace 5
INSTALLATION
INSTALLATION
CHECKLIST
1) Locate appliance;
a) Room location
b) Clearances to Combustibles
c) Mantle Clearances
d) Framing & Finishing Requirements
e) Flueing Requirements
2) Assemble Top Standoffs. (NOTE: must be
done before installing unit into replace.)
3) Install ue.
4) Make gas connections. Test the pilot. Must
be as per diagram in "Pilot Adjustment"
section.
5) Install log set.
6) Install Glass Door, Louvers or Grills , and
Finishing Trim.
7) Final check.
Before leaving this unit with the customer,
the installer must ensure that the appliance is
ring correctly and operation fully explained
to customer.
This includes:
1) Clocking the appliance to ensure the correct
ring rate (rate noted on label 40,000 Btu/h
NG, and 39,000 Btu/h LPG) after burning
appliance for 15 minutes.
2) If required, adjusting the primary air to
ensure that the ame does not carbon.
First allow the unit to burn for 15-20 min.
to stabilize.
CAUTION:Any alteration to the product that
causes sooting or carboning that results
in damage is not the responsibility of the
manufacturer.
IMPORTANT:
SAVE THESE
INSTRUCTIONS
The Regency PG121/PG121LC/PG121RC/
PG131-NG1 or PG121/PG121LC/PG121RC/
PG131-LPG1 Room Sealed Gas Fireplace must
be installed in accordanceAG601 and NZS 5261
and with these instructions. Carefully read all
the instructions in this manual rst. Consult the
"authority having jurisdiction" to determine the
need for a permit prior to starting the installation.
It is the responsibility of the installer to ensure this
replace is installed in compliance with manu-
facturer's instructions and all applicable codes.
BEFORE YOU START
Safe installation and operation of this appliance
requires common sense, however, we are
required to make you aware of the following:
GENERAL SAFETY
INFORMATION
1) The appliance shall be installed in accord-
ance with the manufacturer's installation
instructions, local gas tting regulations,
municipal building codes, water supply
regulations, electrical wiring regulations,
with AS5601-2004 (AGA gas installation
code) NZS 5261 (New Zealand)
2) See general construction and assembly
instructions. The appliance and ue should
be enclosed.
3) This appliance must be connected to the
specied ue and termination cap to the
outside of the building envelope. Never ue
to another room or inside a building. Make
sure that the ue is tted as per Flueing
instructions.
4) Inspect the ueing system annually for
blockage and any signs of deterioration.
5) Flueing terminals shall not be recessed into
a wall or siding.
6) Any safety glass removed for servicing must
be replaced prior to operating the appliance.
7) To prevent injury, do not allow anyone who
is unfamiliar with the operation to use the
replace.
8) Wear gloves and safety glasses for protec-
tion while doing required maintenance.
9) Be aware of electrical wiring locations in
walls and ceilings when cutting holes for
termination.
10) Under no circumstances should this ap-
pliance be modied. Parts that have to be
removed for servicing should be replaced
prior to operating this appliance.
11) Installation and any repairs to this appliance
should be done by a authorized service
person. A authorized service person should
be called to inspect this appliance annually.
Make it a practice to have all of your gas
appliances checked annually.
12) Do not slam shut or strike the glass door.
13) Under no circumstances should any solid
fuels (wood, paper, cardboard, coal, etc.)
be used in this appliance.
14) The appliance area must be kept clear and
INSTALLATION AND REPAIR SHOULD
BE DONEBYAAUTHORIZED SERVICE
PERSON. THE APPLIANCE SHOULD
BE INSPECTED BEFORE USEAND AT
LEASTANNUALLY BYAAUTHORIZED
SERVICE PERSON. MORE FREQUENT
CLEANING MAY BE REQUIRED DUE
TO EXCESSIVE LINT FROM CAR-
PETING, BEDDING MATERIAL, ETC.
IT IS IMPERATIVE THAT CONTROL
COMPARTMENTS, BURNERS AND
CIRCULATING AIR PASSAGEWAYS
OF THEAPPLIANCE BE KEPT CLEAN.
DUE TO HIGH TEMPERATURES, THE
APPLIANCE SHOULD BE LOCATED
OUT OF TRAFFIC AND AWAY FROM
FURNITURE AND DRAPERIES.
WARNING: FAILURE TO INSTALL THIS
APPLIANCE CORRECTLY WILL VOID
YOUR WARRANTY AND MAY CAUSE
A SERIOUS HOUSE FIRE.
CLOTHING OR OTHER FLAMMABLE
MATERIAL SHOULD NOT BE PLACED
ON OR NEAR THE APPLIANCE.
CHILDREN AND ADULTS SHOULD
BE ALERTED TO THE HAZARDS OF
HIGHSURFACETEMPERATURES, ES-
PECIALLY THE FIREPLACE GLASS,
AND SHOULD STAY AWAY TO AVOID
BURNS OR CLOTHING IGNITION.
YOUNG CHILDREN SHOULD BE
CAREFULLY SUPERVISED WHEN
THEY ARE IN THE SAME ROOM AS
THE APPLIANCE. Emissions from burning wood or gas could
contain chemicals known to the State of Cali-
fornia to cause cancer, birth defects or other
reproductive harm.
NOTE:
Not intended for
replace insert.
These units are
non-load bearing.
free of combustible materials, (gases and
other ammable vapours and liquids).

Regency PG121/PG131 Zero Clearance Room Sealed Gas Fireplace
6
INSTALLATION
SPECIFICATIONS
PG121-1 - See Thru
PG131-1 - Pier
Note: These units are
non-load bearing.

Regency PG121/PG131 Zero Clearance Room Sealed Gas Fireplace 7
PG121LC-1 - Left Corner Unit
PG121RC-1 - Right Corner Unit
INSTALLATION
Note: These units are
non-load bearing.

Regency PG121/PG131 Zero Clearance Room Sealed Gas Fireplace
8
LOCATING YOUR
GAS FIREPLACE
1) When selecting a location for your stove,
ensure that the clearances are met as
outlined in the "Clearances" section.
2) Provide adequate clearances for servicing.
3) The appliance must be installed on a at,
solid, continuous surface (e.g. wood, metal,
concrete). This may be the oor, or raised up
on a platform to enhance its visual impact.
If the appliance is going to be installed
on carpeting, combustible linoleum tile or
other combustible material other than wood
ooring, the appliance must be installed on
a metal or wood panel extending the full
width and depth of the appliance.
4) The Room Sealed Gas Fireplace can be
installed as follows:
Model # Position
A) PG121-1: See Thru
B) PG131-1: Pier
C) PG121LC-1: Left Corner
D) PG121RC-1: Right Corner
5) This appliance is Listed for bedroom instal-
lations when used with a Listed Millivolt
Thermostat. Some areas may have further
requirements, check local codes before
installation.
6) The PG121-1 / PG121LC-1 / PG121RC-1
/ PG131-1 Room Sealed Gas Fireplace is
approved for alcove installations, which
meet the clearances listed on this page.
7) We recommend that you plan your instal-
lation on paper using exact measurements
for clearances and oor protection before
actually installing this appliance. Have a
authorized inspector, dealer, or installer
review your plans before installation.
Note: For Exterior Flue Termination
Locations see"Exterior Flue Termina-
tion" section.
.
INSTALLATION
A) PG121-1 - See Thru
B) PG131-1 - Pier
C) PG121LC-1 - Left Corner
D) PG121RC-1 - Right Corner

Regency PG121/PG131 Zero Clearance Room Sealed Gas Fireplace 9
INSTALLATION
COMBUSTIBLE MANTELS
CLEARANCES
The clearances listed below are Minimum distances unless otherwise stated (refer to diagrams in "Locating Your Gas Fireplace" section):
WARNING:
Fire hazard is an extreme risk
if these clearances (air space)
to combustible materials are
not adhered to. It is of greatest
importance that this replace
and ue system be installed
only in accordance with these
instructions.
Clearance to Combustibles from:
Back 0" (0mm)
Side 0" (0mm)
Floor 0" (0mm)
CAUTION REQUIREMENTS: The top, back and sides of the replace are dened by
standoffs. The metal ends of the standoffs may NOT be recessed into combustible
construction.
Determine the total thickness of the nished oor (eg. tile, carpet, slate) to allow the
nished surface to be ush with the base of the unit.
Ceiling Height from Floor 72" (1828mm)
Mantel Height from Base of Unit:
39" min. (991mm)
Horizontal Flue Clearances:
Top 2-1/2" (64mm)
Side 1-1/2" (38mm)
Bottom 1-1/2" (38mm)
Vertical Flue Clearances 1-1/4" (32mm)
Due to the extreme heat this replace emits, the mantel clearances
are critical. Combustible mantel clearances from top of unit are shown
in Diagram to the right.
Note: A non-combustible mantel may be installed at a lower
height if the framing is made of metal studs covered with
a non-combustible board.
This drawing is to scale at 1:6 (one inch = 6 inches)
Mantel can be installed anywhere in shaded area or higher using this
scale.
Caution: Ensure the paint that is used on the mantel and the
facing is "heat resistant" or the paint may discolour.
* If the 3" (76mm) metal extension trim is removed it must be replaced
with a 8" (203mm) non-combustible material.
Mantel Clearances

Regency PG121/PG131 Zero Clearance Room Sealed Gas Fireplace
10
FRAMING AND FINISHING
CAUTION: The unit does not have to be completely enclosed in a
chase. The clearance on top of the unit is 0" to the standoffs so
combustible building materials can be laid directly on top of the
standoffs. You must maintain clearance from the ue to combustible
materials for both rigid and ex.
PG121-1 - See Thru
PG131-1 - Pier
Framing Dimensions
PG121 (See Thru) PG131 (Pier) PG121LC / PG121RC
(Corner Unit)
A 25"(635mm) 25"(635mm) 26-13/13"(660mm)
minus two times minus two times minus two times
the nishing the nishing the nishing
material thickness* material thickness* material thickness*
B 42-1/2"(1080mm) 42-1/2"(1080mm) 42-1/2"(1080mm)
C 46-3/4"(1187mm) 45" (1143mm) 45"(1143mm)
minus one time minus one time
the nishing the nishing
material thickness* material thickness*
Note: These units are
non-load bearing.
PG121LC-1 - Corner Unit
* Finish material thickness includes: drywall, ceramic tile, slate, etc.
1) For ease of installation, frame your replace after it is positioned and
the ue system is installed. Remember to install the top standoffs.
Use 2x4's and frame to local building codes.
2) When locating your appliance on an exterior wall or in a chase, apply
a vapour barrier and drywall, as per local building codes. DO NOT
INSULATE THE FIREPLACE ITSELF.
CAUTION: Verify your replace dimensions, framing methods and
nished wall facing details before framing. Determine the total thick-
ness of facing material - drywall plus ceramic tiles, slate, etc. Allow
the nish surface to be ush with the front or side of the unit. Total
facing thickness can vary from 1/2" (13mm) to 1-1/4" (32mm) thick.
PG121RC-1 - Corner Unit
INSTALLATION

Regency PG121/PG131 Zero Clearance Room Sealed Gas Fireplace 11
FLUEING
INTRODUCTION
The PG121-1 / PG121LC-1 / PG121RC-1 /
PG131-1 uses the "balanced ue" technology
Co Axial system. The inner liner ue products of
combustion to the outside while the outer liner
draws outside combustion air into the combus-
tion chamber thereby eliminating the need to
use heated room air for combustion and losing
warm room air up the chimney.
Note: Theseuepipesmustnotbecon-
nectedtoanyotherappliance.
The gas appliance and ue system must be
ueed directly to the outside of the building,
and never be attached to a chimney serving a
separate solid fuel or gas burning appliance.
Each direct ue gas appliance must use it's own
separate ue system. Common ue systems
are prohibited.
INSTALLATION
UNIT ASSEMBLY
PRIOR TO
INSTALLATION
The 4 Top Standoffs must be correctly positioned and attached to the top before unit is slipped
into position.
Top Standoff Assembly
The top standoffs are shipped in a at position and must be folded into shape and attached.
1) Remove the standoffs from the replace
top.
2) Take each standoff and bend into the cor-
rect shape. Bend up at the bend lines until
the screw holes in the standoff and the
pre-punched screw holes on the replace
top line up.
3) Attach the standoff securely to the top with
4 screws per standoff (on opposite corners).
FACING & FINISHING REQUIREMENTS
This replace is supplied with a 3" metal extension trim above the replace. The extension trim may be replaced if the framing is faced with a non-
combustible material placed ush with the front and side face of the unit and extending from the top of the unit. (ie. tile, slate, etc.)

Regency PG121/PG131 Zero Clearance Room Sealed Gas Fireplace
12
INSTALLATION
EXTERIOR FLUE TERMINATION LOCATIONS
Minimum clearances required for balanced ue terminals or
the ue terminals of outdoor appliances
according to AS5601-2004 (AGA gas installation code) or NZS 5261 (New Zealand)
Minimum
Clearance (mm)
a Below eaves, balconies or other projections:
- Appliances up to 50 MJ/h input 300
- Appliances over 50 MJ/h input 500
b From the ground or above a balcony 300
c From a return wall or external corner 500
d From a gas meter (M) 1000
e From an electricity meter or fuse box (P) 500
f From a drain or soil pipe 150
g Horizontal from any building structure (unless appliance is approved
for closer installation) or obstruction facing a terminal 500
h From any other ue terminal, cowl or combustion air intake 500
j Horizontally from an openable window, door, or non-mechanical air inlet, or
any other opening into a building, with the exception of sub-oor ventilation
(see also Note (I)):
- Appliances up to 150 MJ/h input 500
- Appliances over 150 MJ/h input 1500
k Vertically below an openable window, door, or non-mechanical air inlet,
or any other opening into a building, with the exception of sub-oor ventilation
(see also Note (I)): see table below
Clearance 'k' in mm
Space Heaters All Other Appliances
Up to 50 MJ/h Up to 50 MJ/h input Over 50 MJ/h input Over 150 MJ/h input
input to 150 MJ/h input
150 500 1000 1500
NOTES:
(I) For mechanical air inlets, including spa blowers, the clearance 'j' and 'k' shall be 1500 mm in all cases.
(II) All distances shall be measured vertically or horizontally along the wall to a point in line with the nearest par to of the terminal.
(III) Prohibited area below electricity meter or fuse box extends to ground level.
(IV) A ue terminal of this type shall not be located under a roofed area unless the roofed area is fully open on at least two sides and a
free ow of air at the appliance is achieved.

Regency PG121/PG131 Zero Clearance Room Sealed Gas Fireplace 13
23
FLUEING ARRANGEMENT - HORIZONTAL TERMINATIONS
RegencyDirectVentSystem(Flex)HorizontalTerminationsOnly
These ueing systems, in combination with the PG121-1 / PG121LC-1 / PG121RC-1 / PG131-1 Direct Vent Gas Fireplace, have been tested and
listed as a direct ue heater system by Warnock Hersey. The location of the termination cap must conform to the requirements in the Flue Terminal
Locations diagram.
Regency Direct Vent (Flex) System Termination Kit (Part# 946-513) includes all the parts needed to install the PG121-1 / PG121LC-1 /
PG121RC-1 / PG131-1 with a maximum run of 2 feet.
1) 6-7/8" dia. exible liner (2 ft. length)
2) 4" dia. exible liner (2 ft. length)
3) spring spacers (3)
4) thimble (2)
5) AstroCap termination cap (1)
6) screws (12)
7) tube of Mill Pac (1)
8) plated screws (8)
9) screws #8 x 1-1/2" drill point, stainless steel (4)
Notes:
1) Liner sections should be continuous without any joints or seams.
2) Only Flex pipe purchased from Regency may be used for Flex installations.
3) Regency Direct Vent System (Flex) is only approved for horizontal terminations.
INSTALLATION

Regency PG121/PG131 Zero Clearance Room Sealed Gas Fireplace
14
Simpson
Dura-Vent
Direct Vent GS
SIMPSON DURA-VENT FLUEING COMPONENTS LIST
All Simpson Dura-Vent components are available directly from Regency.
SIMPSON DURA-VENT FLUEING
HorizontalorVerticalTerminations
The Simpson Dura-Vent Direct Vent System offers a complete line of component parts for installation of both horizontal and vertical installations.
Many items are offered in decorative black, as well as galvanized nish. We recommend using the galvanized nish for installation with the PG121-1
/ PG121LC-1 / PG121RC-1 / PG131-1.
The minimum components required for a
basic horizontal termination are:
1 Simpson Duravent Adaptor
1 Horizontal Termination Cap
1 45oElbow
1 Flue Adaptor
1 Wall Thimble
1 Length of pipe to suit wall
thickness (see chart)
Wall thickness is measured from the back
standoffs to the inside mounting surface
of termination cap. For siding other than
971 Horiz. Termination Kit includes:
90o black elbow, wall thimble cover, horiz. square
termination cap, 24" black pipe, and 11" -14"
5/8" adjustable black pipe
970 Basic Horiz. Termination. Kit includes:
90o black elbow, wall thimble cover,
horiz. square termination cap
978 Vert. Termination Kit includes 0/12 -
6/12 pitch adjustable ashing, storm
collar, low prole term. cap
908B 6" Pipe Length - Black
907B 9" Pipe Length - Black
906 12" Pipe Length - Galv.
906B 12" Pipe Length - Black
904 24" Pipe Length - Galv.
904B 24" Pipe Length - Black
903 36" Pipe Length - Galv.
903B 36" Pipe Length - Black
902 48" Pipe Length - Galv.
902B 48" Pipe Length - Black
911B 11"-14 5/8" Adjustable Pipe Length -
Black
917B 17"- 24" Adjustable Length - Black
94545O Elbow - Galv.
945B 45O Elbow - Black
945G 45O Elbow - Swivel - Galv.
945BG 45O Elbow - Swivel - Black
99090O Elbow - Galv.
990B 90O Elbow - Black
990G 90O Elbow - Swivel - Galv.
990BG 90O Elbow - Swivel - Black
991 High Wind Termination Cap (Vertical)
980 Vertical Termination Cap
984 Horizontal Square Termination Cap
985 Horiz. Square High Wind Termination Cap
982 Snorkel - 14" Rise Termination Cap
981 Snorkel - 36" Rise Termination Cap
940 Wall Thimble - Support/Box
941 Cathedral/Ceiling - Support/Box
3951 Brass Trim for Wall Thimble/Ceiling Sup.
963 Firestop Spacer
943 Flashing 0/12-6/12
943S Flashing 7/12-12/12
953 Storm Collar
950 Vinyl Siding Standoff
988Wall Strap
942 Wall Thimble
Parts not supplied by Dura-Vent
946-506/P Vent Guard (Optional)
510-994 Dura-Vent Flue Adaptor
640-530/P Riser Vent Terminal
946-205 Vinyl Siding Shield for Riser Vent
Terminal
946-206 AstroCap Standoff
vinyl furring strips may be
used, instead of the vinyl sid-
ing standoff, to create a level
surface to mount the vent ter-
minal. The Terminal must not be
recessed into siding. Measure
the wall thickness including
furring strips.
If a Vinyl Siding Standoff is
required (it must be used with
vinyl siding), measure to outside
surface of wall without siding
and add 2 inches.
Part # Description Part # Description Part # Description
INSTALLATION
Flat Wall Installation
Wall Thickness Vent Length
(mm) Required (mm)
102 - 140 152
178 - 216 229
254 - 292 305
229 - 368 279 - 356 Adj. Pipe
381 - 597 432 - 610 Adj. Pipe
The Regency AstroCapTM is certied for installations using FPI vent-
ing systems as well as Simpson Dura-Vent® and Direct Vent GS.
RegencyTM, and Regency AstroCapTM are the proprietary trade-
marks of FPI Fireplace Products International Ltd.
Dura-Vent® and Direct Vent GS are registered and/or proprietary
trademarks of Simpson Dura-Vent Co. Inc.

Regency PG121/PG131 Zero Clearance Room Sealed Gas Fireplace 15
INSTALLATION
FLUEING ARRANGEMENTS - HORIZONTAL TERMINATIONS
SIMPSONDURA-VENTDIRECTVENTGSSYSTEM
The diagram below shows examples of horizontal termination arrangements using one, two, or three 90o elbows (two 45o elbows equal one 90o elbow).
Note:
1) A maximum of three 90oelbows are permitted.
2) Minimum distance between elbows is 1 ft. (305mm).
• Maintain clearances to combustibles.
• Horizontal ue must be supported every 3 feet.
• Firestops are required at each oor level and whenever passing through a wall.
• Must use optional ue adapter (Part# 510-994) when using Simpson Dura-Vent pipe.
• A vent guard should be used whenever the termination is lower than the specied minimum or as per local codes.
SimpsonDura-Vent
4"innerdiameter
6-5/8"outerdiameter
Straight Out Horizontal Flueing Horizontal Flueing with One (1) 90oElbow
Option VH
A) 1' (305mm) Minimum 3' (914mm) Maximum
B) 2' (610mm) Minimum 6' (1.86m) Maximum
C) 3' (914mm) Minimum 9' (2.7m) Maximum
D) 4' (1.22m) Minimum 12' (3.6m) Maximum
E) 5' (1.5m) Minimum 15' (4.5m) Maximum
F) 6' (1.86m) Minimum 17' (5.1m) Maximum
Diagram 1
Diagram 2
With the above options, maximum total pipe length if 37 feet with
minimum of 6 feet total vertical and maximum 17 feet total horizontal.
Pleasenoteminimum1footbetween90oelbowsisrequired.
Pleasenotetheminimumcenterlinefor
basicinstallshownabove.

Regency PG121/PG131 Zero Clearance Room Sealed Gas Fireplace
16
INSTALLATION
Diagram 3
Horizontal Flueing with Two (2) 90oElbows
Option V H + H1
A) 1' (305mm) Minimum 2' (610mm) Maximum
B) 2' (610mm) Minimum 5' (1.5m) Maximum
C) 3' (914mm) Minimum 8' (2.4m) Maximum
D) 4' (1.22m) Minimum 11' (3.35m) Maximum
E) 5' (1.5m) Minimum 14' (4.27m) Maximum
F) 6' (1.86m) Minimum 15' (4.5m) Maximum
Horizontal Flueing with Two (2) 90oElbows
Option V H H + H1
A) 1' (305mm) Min. 1' (305mm) Max. 3' (914mm) Max.
B) 2' (610mm) Min. 3' (0.91m) Max. 6' (1.86m) Max.
C) 3' (914mm) Min. 5' (1.5m) Max. 9' (2.7m) Max.
D) 5' (1.5m) Min. 8' (2.4m) Max. 12' (3.6m) Max.
Horizontal Flueing with Three (3) 90oElbows
Horizontal Flueing with Three (3) 90oElbows
Diagram 5
Diagram 4 Diagram 6
With the above options, maximum total pipe length if 37 feet with
minimum of 6 feet total vertical and maximum 15 feet total horizontal.
Pleasenoteminimum1footbetween90oelbowsisrequired.
Option V H H + H1 + H2
A) 2' (610mm) Min. 1' (305mm) Max. 3' (914mm) Max.
B) 3' (914mm) Min. 3' (914mm) Max. 6' (1.86m) Max.
C) 4' (1.22mm) Min. 5' (1.5m) Max. 9' (2.7m) Max.
D) 5' (1.5m) Min. 7' (2.13m) Max. 12' (3.6m) Max.
With the above options, maximum total pipe length if 37 feet with
minimum of 5 feet total vertical and maximum 12 feet total horizontal.
Pleasenoteminimum1footbetween90oelbowsisrequired.
With the above options, maximum total pipe length if 37 feet with
minimum of 5 feet total vertical and maximum 12 feet total horizontal.
Pleasenoteminimum1footbetween90oelbowsisrequired.
Option V + V1 H + H1
A) 2' (610mm) Minimum 3' (914mm) Maximum
B) 3' (914mm) Minimum 6' (1.86m) Maximum
C) 4' (1.22m) Minimum 9' (2.7m) Maximum
D) 5' (1.5m) Minimum 12' (3.6m) Maximum
With the above options, maximum total pipe length if 37 feet with
minimum of 5 feet total vertical and maximum 12 feet total horizontal.
Pleasenoteminimum1footbetween90oelbowsisrequired.

Regency PG121/PG131 Zero Clearance Room Sealed Gas Fireplace 17
INSTALLATION
FLUEING ARRANGEMENTS - VERTICAL TERMINATIONS
SIMPSONDURA-VENTDIRECTVENTGSSYSTEM
• Flue must be supported at offsets
• Maintain clearances to combustibles.
• Firestops are required at each oor level and whenever passing through a wall.
• Must use optional ue adapter when using Simpson Dura-Vent pipe (Part# 510-994).
The PG121-1 / PG121LC-1 / PG121RC-1 / PG131-1 is approved for a maximum 35 ft. (10.7m) straight vertical, with Simpson Dura-Vent Direct
Vent GS ue systems for LPG and NG.
Diagram 7
Diagram 8
Straight Up Vertical Flueing Vertical Flueing with One (1) 90oElbow
Option V H
A) 1' (305mm) Minimum 2' (610mm) Maximum
B) 2' (610mm) Minimum 4' (1.22m) Maximum
C) 3' (914mm) Minimum 6' (1.86m) Maximum
D) 4' (1.22m) Minimum 8' (2.4m) Maximum
With the above options, maximum total pipe length if 37 feet with
minimum of 4 feet total vertical and maximum 8 feet total horizontal.
Pleasenoteminimum1footbetween90oelbowsisrequired.

Regency PG121/PG131 Zero Clearance Room Sealed Gas Fireplace
18
INSTALLATION
Vertical Flueing with Two (2) 90oElbows
Option V H
A) 1' (305mm) Minimum 4' (1.22m) Maximum
B) 2' (610mm) Minimum 6' (1.86m) Maximum
C) 3' (914mm) Minimum 9' (2.7m) Maximum
D) 4' (1.22m) Minimum 12' (3.6m) Maximum
E) 5' (1.5m) Minimum 15' (4.5m) Maximum
F) 6' (1.86m) Minimum 17' (5.1m) Maximum
Vertical Flueing with Two (2) 90oElbows
Vertical Flueing with Three (3) 90oElbows
Diagram 9 Diagram 10
Diagram 11
Option V + V1 H H + H1
A) 2' (610mm) Min. 1' (305mm) Max. 2' (610mm) Max.
B) 3' (914mm) Min. 4' (1.22m) Max. 5' (1.5m) Max.
C) 4' (1.22mm) Min. 6' (1.86m) Max. 8' (2.4m) Max.
D) 5' (1.5m) Min. 8' (2.4m) Max. 12' (3.6m) Max.
With the above options, maximum total pipe length if 37 feet with
minimum of 6 feet total vertical and maximum 17 feet total horizontal.
Pleasenoteminimum1footbetween90oelbowsisrequired.
Option V H + H1
A) 1' (305mm) Minimum 2' (610mm) Maximum
B) 2' (610mm) Minimum 4' (1.22m) Maximum
C) 3' (914mm) Minimum 6' (1.86m) Maximum
D) 4' (1.22m) Minimum 8' (2.4m) Maximum
With the above options, maximum total pipe length if 37 feet with
minimum of 4 feet total vertical and maximum 8 feet total horizontal.
Pleasenoteminimum1footbetween90oelbowsisrequired.
With the above options, maximum total pipe length if 37 feet with
minimum of 5 feet total vertical and maximum 12 feet total horizontal.
Pleasenoteminimum1footbetween90oelbowsisrequired.

Regency PG121/PG131 Zero Clearance Room Sealed Gas Fireplace 19
INSTALLATION
HORIZONTAL
INSTALLATIONS
Install the ue system according to the
manufacturer's instructions included with
the components.
1) Set the unit in its desired location. Check to
determine if wall studs or roof rafters are in
the way when the ueing system is attached.
If this is the case, you may want to adjust
the location of the unit. Rough in the gas.
2) Direct Flue pipe and ttings are designed with
special twist-lock connections to connect the
ueing system to the appliance ue outlet. A
twist-lock appliance adaptor is an available
option that must be used in conjunction
with the Simpson Dura-Vent Direct Vent GS
system.
3) Put a bead of silicone inside the outer section
of the adapter and a bead of Mill Pac on the
inner collar. Slip the adapter over the existing
inner and outer ue collar and fasten to the
outer collar only with the 3 supplied screws
(drilling pilot holes will make this easier).
Level the replace and fasten it to the fram-
ing using nails or screws through the nailing
strips.
4) Assemble the desired combination of pipe
and elbows to the appliance adaptor and
twist-lock for a solid connection.
Note:
a) Twist-lock procedure: Four indentations,
located on the female ends of pipes and
ttings, are designed to slide straight
onto the male ends of adjacent pipes
and ttings, by orienting the four pipe
indentations so they match and slide
in to the four entry slots on the male
ends, Diagram 1. Push the pipe sections
completely together, then twist-lock
Diagram 1
ported every three feet. Wall straps are
available for this purpose.
5) Mark the wall for a 10" x 10" square hole.
The center of the square hole should line
up with the centerline of the horizontal
pipe. Cut and frame the 10 inch square
hole in the exterior wall where the ue will
be terminated. If the wall being penetrated
is constructed of non-combustible material,
i.e. masonry block or concrete, a 7"(178mm)
dia. (7-1/2"(191mm) dia. for ex) hole is
acceptable.
Note: With Dura-Vent, the minimum height
is achieved by installing a 45oelbow directly
to the ue adaptor.
Note:
a) The horizontal run of ue must be level,
or have a 1/4 inch rise for every 1 foot
of run towards the termination. Never
allow the ue to run downward. This
Diagram 2
could cause high temperatures and
may present the possibility of a re.
b) The location of the horizontal ue termi-
nation on an exterior wall must meet all
local and national building codes, and
must not be blocked or obstructed. For
External Flue Terminal Locations, see
diagram on page 12.
6) The arrow on the ue cap should be point-
ing up. Insure that the 1-1/2" clearances
to combustible materials are maintained
(Diagram 3 on page 16). Install the termina-
tion cap.
The four wood screws provided should
be replaced with appropriate fasteners for
stucco, brick, concrete, or other types of
sidings.
Note: If installing termination on a siding
covered wall, a vinyl siding standoff
or furring strips must be used to
ensure that the termination is not
recessed into the siding.
7) Before connecting the horizontal run of ue
Note: Apply sealant "Mill-Pac" to inner pipe
and high temperature silicone sealant
to outer pipe on every twist-lock joint.
b) Horizontal runs of ue must be sup-
Diagram 12
Vertical Flueing with Three (3) 90oElbows
Option V + V1 H + H1
A) 2' (610mm) Minimum 3' (914mm) Maximum
B) 3' (914mm) Minimum 6' (1.86m) Maximum
C) 4' (1.22m) Minimum 9' (2.7m) Maximum
D) 5' (1.5m) Minimum 12' (3.6m) Maximum
one section clockwise approximately
one-quarter turn, until the two sections
are fully locked. The female locking lugs
will not be visible from the outside, on
the Black Pipe or ttings. They may be
located by examining the inside of the
female ends.
With the above options, maximum total pipe length if 37 feet with
minimum of 5 feet total vertical and maximum 12 feet total horizontal.
Pleasenoteminimum1footbetween90oelbowsisrequired.

Regency PG121/PG131 Zero Clearance Room Sealed Gas Fireplace
20
Diagram 3
Diagram 5
Diagram 1
Diagram 2
Note: Apply sealant "Mill-Pac" to inner pipe
and high temperature silicone seal-
ant to outer pipe on every twist-lock
joint.
TERMINATION
1) Maintain the 1-1/4" clearances (air spaces)
to combustibles when passing through ceil-
ings, walls, roofs, enclosures, attic
rafter, or other nearby combustible
surfaces. Do not pack air spaces
with insulation. Check pages 17-19
for the maximum vertical rise of the
ueing system and the maximum
horizontal offset limitations.
2) Set the gas appliance in its desired
location. Drop a plumb bob down
from the ceiling to the position of
in the ceiling, and mark the spot where the
ue will penetrate the roof. Determine if ceil-
ing joists, roof rafters or other framing will
obstruct the ueing system. You may wish to
relocate the appliance or to offset, as shown
in Diagram 2 to avoid cutting
load bearing members.
3) A Firestop
spacer must be
installed in the
oor or ceiling
of every level.
To install the
Firestop spacer
in a at ceiling or wall, cut a 10 inch square
hole. Frame the hole as shown in Diagram
3 and install the restop.
4) Assemble the desired lengths of pipe and
elbows. Ensure that all pipes and elbow con-
nections are in the fully twist-locked position
and sealed.
5) Cut a hole in the roof centered on the small
drilled hole placed in the roof in Step 2. The
hole should be of sufcient size to meet
the minimum requirements for clearance
to combustibles of 1-1/4". Slip the ashing
under the shingles (shingles should overlap
half the ashing) as per Diagram 4.
6) Continue to assemble pipe lengths.
Roof Pitch Minimum Vent Height
Feet Meters
at to 7/12 2 0.61
over 7/12 to 8/12 2 0.61
over 8/12 to 9/12 2 0.61
over 9/12 to 10/12 2.5 0.76
over 10/12 to 11/12 3.25 0.99
over 11/12 to 12/12 4 1.22
over 12/12 to 14/12 5 1.52
over 14/12 to 16/12 6 1.83
over 16/12 to 18/12 7 2.13
over 18/12 to 20/12 7.5 2.29
over 20/12 to 21/12 8 2.44
Diagram 4: The upper half of the ashing is
installed under the roong material and not
nailed down until the chimney is installed. This
allows for small adjustments.
Note: If an offset is necessary in the attic
to avoid obstructions, it is important
to support the ue pipe every 3 feet,
to avoid excessive stress on the el-
bows, and possible separation. Wall
straps are available for this purpose
(Diagram 2).
Galvanized pipe is desirable above the roof-
line due to its higher corrosion resistance.
Continue to add pipe sections through the
ashing until the height of the ue cap meets
the minimum height requirements specied
in Diagram 5 or local codes. Note that for
steep roof pitches, the vertical height must
be increased. A poor draft, or down drafting
the appliance ue exit, and
mark the location where
the ue will penetrate the
ceiling. Drill a small hole
at his point. Next, drop a
plumb bob from the roof to
the hole previously drilled
Diagram 3
Diagram 4
Diagram 5
pipe to the ue termination, slide the Wall
Thimble (Part # 942) over the ue pipe.
8) Slide the appliance and ue assembly
towards the wall carefully inserting the ue
pipe into the ue cap assembly. It is important
that the ue pipe extends into the ue cap
sufcient distance so as to result in a mini-
mum pipe overlap of 1-1/4 inches. Secure
the connection between the ue pipe and
the ue cap by attaching the two sheet metal
strips extending from the ue cap assembly
into the outer wall of the ue pipe. Use the
two sheet metal screws provided to connect
the strips to the pipe section. See Diagram
4.
9) Install wall thimble in the center of the 10"
square and attach with wood screws (Dia-
gram 5).
VERTICAL
INSTALLATION
