Regency GEM54-NG Quick start guide

WARNING:
If the information in these instructions are not followed
exactly, a fire or explosion may result causing property
damage, personal injury or loss of life.
FOR YOUR SAFETY
Do not store or use gasoline or other flammable vapors and
liquids in the vicinity of this or any other appliance.
Installation and service must be performed by a qualified
installer, service agency or the gas supplier.
FOR YOUR SAFETY
What to do if you smell gas:
Do not try to light any appliance
Donottouchanyelectricalswitch:
do not use any phone in your
building.
Immediatelycallyourgassupplier
from a neighbour's phone. Follow
the gas supplier's instructions.
If you cannot reach your gas
supplier, call the fire department.
918-784
Regency Gem54
Gas Fireplace
07/08/09
Owners &
Installation Manual
www.regency-fire.com.au
Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
MODELS: GEM54-NG
GEM54-LPG
GEM54-ULPG
LISTINGS AND CODE APPROVALS
Thesegasapplianceshavebeentestedin
accordancewith AS4558/NZS5262and
have been certified by theAustralian Gas
Association for installation and operation
as described in these Installation and
Operating Instructions.
Your unit should be serviced annually
by an authorised service person.

Regency GemfireTM Gas Fireplace
2
To the New Owner:
Congratulations!
Youaretheownerofastate-of-the-artGasFireplacebyREGENCY®.TheGem54hasbeen
designed to provide you with all the warmth and charm of a wood fireplace at the flick of a
switch. The model Gem54 has been approved by AGA for both safety and efficiency. As
it also bears our own mark, it promises to provide you with economy, comfort and security
for many trouble free years to follow. Please take a moment now to acquaint yourself with
these instructions and the many features of your Regency®Fireplace.

Regency GemfireTM Gas Fireplace 3
TABLE OF CONTENTS
DATA BADGE
Copy of data badge.......................................................4
DIMENSIONS
Unit Dimensions ............................................................5
Faceplate & Door Frame Dimensions ...........................5
INSTALLATION
Important Message ......................................................6
Before You Start ............................................................6
General Safety...............................................................6
Installation Checklist......................................................7
Locating Your Gas Fireplace .........................................7
Clearances ....................................................................8
Non-Combustible Requirements ...................................8
Mantel Clearances.........................................................9
Mantel Leg Clearances..................................................9
Framing & Finishing.....................................................10
Unit Assembly Prior To Installation..............................12
Top Standoff Assembly........................................12
Side Nailing Strips ...............................................12
Venting Introduction.....................................................12
Vent Restrictor Position...............................................13
Exterior Vent Termination Requirements.....................14
Venting Arrangements ................................................15
Horizontal Termination (Flex)...............................15
Rigid Pipe Venting Systems ........................................16
Basic Horizontal & Vertical Terminations.............16
5” x 8” Rigid Pipe Cross Reference Chart...................17
Venting Arrangements ................................................19
Allowable Horizontal Terminations.......................19
Venting Arrangements ................................................20
Venting Arrangements ................................................23
Allowable Vertical Terminations for Gem54-ng....23
Venting Arrangements ................................................24
Allowable Vertical Terminations...........................24
Unit Installation with Horizontal Termination................25
Unit Installation with Vertical Termination....................26
Unit Installation............................................................27
Horizontal Termination.........................................27
with Flex Vent System .........................................27
High Elevation .............................................................28
Gas Line Installation....................................................28
Pilot Adjustment...............................................................
Pilot Adjustment...........................................................28
Gas Pipe Pressure Testing..........................................28
S.I.T. Valve Description................................................28
Conversion from NG to LPg .......................................29
Conversion from NG to ULPG.....................................29
Aeration Adjustment ....................................................32
Wiring Diagram ...........................................................32
Optional Stainless Steel ..............................................33
Reflective Panel Installation ........................................33
Glass Crystals or optional ceramic stones ..................34
Installation On Burner..................................................34
Optional Pebble Installation.........................................34
Screen & Door frame Installation................................35
Faceplate Installation...................................................36
OPERATING INSTRUCTIONS
Operating Instructions .................................................38
First Fire ......................................................................38
Lighting Procedure ......................................................38
Normal Operating .......................................................38
Shutdown Procedure...................................................38
Sounds of Gas Appliances ..........................................38
Copy of Lighting Plate Instructions..............................39
MAINTENANCE
Maintenance Instructions.............................................40
General Vent Maintenance..........................................40
Thermopile / Thermocouple.........................................40
Glass Gasket...............................................................40
Glass Door...................................................................40
Glass Replacement .............................................40
Glass Door Removal ...................................................41
DC Spark Box Battery Replacement...........................42
DC Spark Box Replacement........................................42
Valve Tray Replacement..............................................43
PARTS LIST
Main Assembly ............................................................45
Accessories.................................................................46
WARRANTY
Warranty......................................................................47

Regency GemfireTM Gas Fireplace
4
INSTALLATION
DATA BADGE
ThisisacopyofthebadgethataccompanieseachGem54™-NGDirectVentGasFireplace.Wehaveprintedacopyofthecontentshereforyourreview.
NOTE: Regency®units are constantly being improved. Check the badge on the unit and if there is a difference, the badge on the unit is the correct
one.
COPY OF DATA BADGE
Electrical: Millivolt Only
Serial
Number 345
918-785
N2134
Regency Gas Fireplace
Gas Type NG LPG ULPG
Model Gem54-NG Gem54-LP Gem54-ULPG
Gas Consumption 35.9 mj. 32.2mj. 28.7mj.
Manifold Pressure 0.88 kPa 2.49kPa 2.49 kPa
Injector Size 1 x #32 1 x#51 1 x #52
2.95mm 1.70mm 1.61mm
Model
AGA Approval number to: # 7493
Code AS4558 / NZ5262
Distributed by:
Western Australia:
Eastern Australia:
Air Group Australia
28 Division St
Welshpool WA 6106
To be installed by an authorised person in
accordance with installation instructions provided
with the appliance.
Fireplace Products
Australia Pty. Ltd.
21-23 South Link Blvd.
Dandenong, VIC 3175
(Australia Only)
909-133
“PRIMARILY A DECORATIVE
APPLIANCE NOT CERTIFIED
AS A SPACE HEATER”
WARNING:

Regency GemfireTM Gas Fireplace 5
INSTALLATION
DIMENSIONS
59” (1499mm)
52-5/8” (1337mm)
48-1/2” (1232mm) 20-1/2” (521mm)
19-3/4” (502mm)
10-5/8”
(270mm)
1-1/2”
(38mm)
31-5/8” (803mm)
46-3/8” (1178mm)
35-1/4” (895mm)
21-5/8” (549mm)
17-1/8” (435mm)
5-11/16”
(144mm)
8”(203mm)
Outer Dia.
5” (127mm)
Inner Dia.
FACEPLATE & DOOR FRAME OVERLAY DIMENSIONS
UNIT DIMENSIONS

Regency GemfireTM Gas Fireplace
6
INSTALLATION
13) Do not slam shut or strike the glass door.
14) Under no circumstances should any solid
fuels (wood, paper, cardboard, coal, etc.) be
used in this appliance.
15) The appliance area must be kept clear and
free of combustible materials, (gases and
other flammable vapours and liquids).
INSTALLATION
IMPORTANT MESSAGE
SAVE THESE
INSTRUCTIONS
The Gem54™ Direct Vent Fireplace must be
installed in accordance with these instructions.
Carefullyreadalltheinstructions inthis manual
first. Consult the "authority having jurisdiction"
to determine the need for a permit prior to
startingthe installation.Itis theresponsibilityof
the installer to ensure this fireplace is installed
in compliance with manufacturers instructions
and all applicable codes and complies with a
S5601/AG601clause5.12,13.2and5.12,13.5.
BEFORE YOU START
INSTALLATION AND REPAIR SHOULD
BE DONE BY AN AUTHORIZED
SERVICE PERSON. THE APPLIANCE
CLOTHINGOROTHERFLAMMABLE
MATERIALSHOULDNOTBEPLACED
ON OR NEAR THE APPLIANCE.
GENERAL SAFETY
INFORMATION
SHOULD BE INSPECTED BEFORE
USE AND AT LEAST ANNUALLY BY A
PROFESSIONAL SERVICE PERSON.
MORE FREQUENT CLEANING MAY
BE REQUIRED DUE TO EXCESSIVE
LINT FROM CARPETING, BEDDING
MATERIAL, ETC. IT IS IMPERATIVE
THAT CONTROL COMPARTMENTS,
BURNERS AND CIRCULATING AIR
PASSAGEWAYS OF THE APPLIANCE
BE KEPT CLEAN.
DUE TO HIGH TEMPERATURES, THE
APPLIANCE SHOULD BE LOCATED
OUT OF TRAFFIC AND AWAY FROM
FURNITURE AND DRAPERIES.
WARNING: FAILURE TO INSTALL THIS
APPLIANCE CORRECTLY WILL VOID
YOUR WARRANTY AND MAY CAUSE
A SERIOUS HOUSE FIRE.
CHILDREN AND ADULTS SHOULD BE
ALERTED TO THE HAZARDS OF HIGH
SURFACE TEMPERATURES, ESPE-
CIALLY THE FIREPLACE GLASS, AND
SHOULDSTAYAWAYTOAVOIDBURNS
OR CLOTHING IGNITION.
YOUNGCHILDRENSHOULDBECARE-
FULLY SUPERVISED WHEN THEY
ARE IN THE SAME ROOM AS THE
APPLIANCE.
1) Theapplianceinstallationmustconformwith
localcodesor,intheabsenceoflocalcodes,
with the current Installation and Building
Codes.
2) The appliance when installed, must be
electrically grounded in accordance with
local codes.
3) See general construction and assembly
instructions.Theapplianceandventshould
be enclosed.
4) This appliance must be connected to the
specified vent and termination cap to the
outsideofthebuildingenvelope.Nevervent
to another room or inside a building. Make
sure that the vent is fitted as per Venting
instructions.
5) Inspect the venting system annually for
blockage and any signs of deterioration.
6) Venting terminalsshallnotberecessedinto
a wall or siding.
7) Any safety glass removed for servicing
must be replaced prior to operating the
appliance.
8) To prevent injury, do not allow anyone who
is unfamiliar with the operation to use the
fireplace.
9) Wearglovesandsafetyglassesforprotection
while doing required maintenance.
10) Be aware of electrical wiring locations in
walls and ceilings when cutting holes for
termination.
11) Under no circumstances should this
appliancebemodified.Partsthathavetobe
removed for servicing should be replaced
prior to operating this appliance.
12) Installationandanyrepairstothisappliance
should be done by an authorized service
person.Aprofessionalservicepersonshould
becalledto inspect this appliance annually.
Make it a practice to have all of your gas
appliances checked annually.
"THIS UNIT MUST ALWAYS
TERMINATE / VENT
DIRECTLY TO THE OUTDOORS."

Regency GemfireTM Gas Fireplace 7
INSTALLATION
INSTALLATION
This includes:
1) Clockingthe appliance toensurethe correct
firing rate (rate noted on label 41,500 Btu/h,
after burning appliance for 15 minutes.
2) Ifrequired,adjustingtheprimaryairtoensure
that the flame does not carbon. First allow
the unit to burn for 15-20 min. to stabilize.
CAUTION: Any alteration to the product that
causes sooting or carboning that results
in damage is not the responsibility of the
manufacturer.
LOCATING YOUR
GAS FIREPLACE
A) Flat on Wall
B) Flat on Wall Corner
C) Recessed into Wall/Alcove
D) Corner
Diagram 1
1) When selecting a location for your fireplace,
ensure that the clearances are met.
2) The appliance must be installed on a flat,
solid, continuous surface For example a
wood,metalorconcretefloororinaraised(on
thewall)application. Theappliancemust be
installedonametalorwoodpanelextending
the full width and depth of the appliance.
3) The Gem54 Direct Vent Gas Fireplace can
beinstalled inarecessed positionorframed
out into the room as in A, B, C and D. See
Diagram 1.
7) TestGasPressure(Referto"GasPipePres-
sure Testing" section).
8) Installstandardandoptionalfeatures. Refer
to the following sections:
a) Glass Crystals
b) Optional Firebox Base Pebbles
c) Optional Stainless Steel Reflective
Panels
d) Faceplate / Door Frame Overlay
e) Remote Control or Wall Thermostat
9) Wall Mounted ON/OFF Switch:
Use the toggle wall switch supplied with the
manual package. Use of a “decor” switch
causeshigherresistancewhichisaproblem
on gas fireplaces.
10) Final check.
Before leaving this unit with the customer, the
installer must ensure that the appliance is firing
correctly and operation fully explained to
customer.
INSTALLATION
CHECKLIST
1) Locate appliance
a) Room location (Refer to "Locating Your
Gas fireplace" section)
b) Clearances to Combustibles (Refer to
"Clearances" section)
c) Mantle Clearances (Refer to "Mantel
Clearances" section)
d) Framing&FinishingRequirements(Refer
to "Framing & Finishing" section)
e) VentingRequirements(Referto"Venting"
section)
2) Assemble the standoffs and nailing strips
(Referto"UnitAssemblyPriortoInstallation).
3) Slide unit into place.
4) Installvent(Referto"Venting Arrangement"
sections).
5) Make gas connections (Refer to "Gas Line
Installation section).
6) Test the pilot (Refer to "Pilot Adjustment"
section).
4) This appliance is Listed for bedroom
installations using the standard Remote
(millivolt thermostat system). Some areas
may have further requirements, check local
codes before installation.
5) The Gem54 Direct Vent Gas Fireplace
is approved for alcove installations, see
"Clearances" section for details.
6) We recommendthatyouplanyourinstallation
on paper using exact measurements for
clearances and floor protection before
actually installing this appliance. Have an
authorized inspector, dealer, or installer
review your plans before installation.
Note: For vent terminations refer to
"ExteriorVent TerminationLocations"
section.

Regency GemfireTM Gas Fireplace
8
INSTALLATION
INSTALLATION
Caution Requirements
The top, back and sides of the fireplace are defined by
standoffs. The metal ends of the standoff may NOT be
recessed into combustible construction.
WARNING
Fire hazard is an extreme risk
if these clearances (air space) to combustible materials are not
adhered to. It is of greatest importance that this fireplace and vent
system be installed only in accordance with these instructions.
CLEARANCES
The clearances listed below are Minimum distances unless otherwise stated:
A major cause of chimney related fires is failure to maintain required clearances (air space) to combustible materials. It is of the greatest
importance that this fireplace and vent system be installed only in accordance with these instructions.
F
B
E
D
A
Installed Close
to Floor
G
48" (1219mm)
4"
(102mm) 5-11/16”
(144mm)
28”
(711mm)
20"
(508mm)
21-3/4”
52-5/8”
60-1/2" (1537mm)
Non-combustible
Material
Non-combustible Material
Non-combustible Material
Non-combustible Material
Metal Stud (header)
Wood Stud
Wood Stud
Clearance: Dimension Measured From:
A: Mantel Height (min.) 20" (508mm) Top of Fireplace Opening
B: Sidewall 4" (102mm) Side of Fireplace Opening
C: Ceiling
(room and/or alcove) 40-7/8" (1038mm) Top of Fireplace Opening
D: Mantel Depth (max.) 13" (330mm) 30" Above Fireplace Opening
E: Alcove Width 83" (2108mm) Sidewall to Sidewall (Minimum)
F: Alcove Depth 36" (914mm) Front to Back Wall (Maximum)
Note 0" No hearth required
F
B
C
Installed Close
to Ceiling
NON-COMBUSTIBLE REQUIREMENTS
Flue Clearances
Horizontal - Top 3" (76mm)
Horiztonal - Side 2" (51mm)
Horiztonal - Bottom 2" (51mm)
Vertical 2" (51mm)

Regency GemfireTM Gas Fireplace 9
INSTALLATION
INSTALLATION
MANTEL CLEARANCES
Note: Ensurethepaintthatisusedonthemantel
and the facing is "heat resistant" or the
paint may discolour.
MANTEL LEG CLEARANCES
Combustible mantel leg clearances as per diagram:
4"
Allowable mantel
leg projection
11-1/2” (292mm)
14” (356mm)
15-3/4” (400mm)
1.5" (38mm)
MANTEL LEG
4”(102mm) Non-Combustible
Drywall
2
0
12 64
810
Top o f
Fireplace
Opening
13" (330mm)
3 ½" (89mm)
Standoff
Metal Stud
(On Edge)
0
14
Non-combustible
Facing
To Floor
1" (25mm)
30” (762mm)
20”
21”
28-1/8”
(724mm)
(51mm)
(102mm)
(152mm)
(203mm)
(254mm)
(305mm)
(356mm)
Due to the extreme heat this fireplace emits, the
mantelclearancesarecritical.Combustiblemantel
clearances from top of front facing are shown in the
diagram on the right.
Note: A non-combustible mantel may be
installed at a lower height if the framing
is made of metal studs covered with a
non-combustible board.

Regency GemfireTM Gas Fireplace
10
INSTALLATION
INSTALLATION
Note: When constructing the framed opening, please ensure there
is access to install the gas lines when the unit is installed.
2) For exterior walls, insulate the enclosure to the same degree as the
rest of the house, apply vapour barrier and drywall, as per local instal-
lation codes. (Do not insulate the fireplace itself.)
WARNING:Failuretoinsulateandaddvaporbarrierstotheinside
of the exterior wall will result in operational and performance
problems including, but not limited to: excessive condensation
on glass doors, poor flame package, carbon, blue flames etc.
These are not product related issues.
3) The unit does not have to be completely enclosed in a chase. You
mustmaintainclearancesfromtheventtocombustiblematerials:See
"Clearances" section. Combustible materials can be laid against the
side and back standoffs and the stove base.
4) If material such as brick, stone, etc extends past the faceplate depth,
when finishing around the faceplate, the minimum opening dimen-
sions noted below must be adhered to ensuring for the removal of the
faceplate.
FRAMING & FINISHING
1) Frame in the enclosure for the unit with framing material.
IMPORTANT: Header must be metal stud. Allother framing may be
of combustible type such as 2x4 (0.6m x 1.2m) / 2x6 (0.6m x 1.8m)
framing materials.
58-3/16” (1478mm)
26-5/8” (676mm)
5) When finishing around the faceplate, if material such as brick, stone,
etc. extend past the faceplate depth - the minimum opening
dimensions noted below must be adhered to, this is to assure
removal of the faceplate.
Finished
Material Nailing Strip Position
13mm 25mm
Factory
Setting
25mm 13mm
38mm 0mm (flush)
Unit
Nailing Strip
1” Forward
Unit
Nailing Strip
½” Forward
Unit
Nailing Strip
Flush w/unit
Factory Set
Nailing Strips

Regency GemfireTM Gas Fireplace 11
INSTALLATION
A
B
C
D
E
F
G
H
I
J
KL
Non-Combustible
Facing
Metal Stud (Header)
on edge
Metal Stud
(Header)
on edge
(Located on the right side of the fireplace)
Framing
Dimensions Description Gem54
A Framing Height 46-5/8” (1184mm)
B Framing Width 60” (1524mm)
C*Framing Depth*22” (559mm)
D Minimum Height to Combustibles 51” (1295mm)
E Corner Wall Length 72" (1829mm)
F Corner Facing Wall Width 101-7/8 (2586mm)
G Vent Centerline Height 44” (1118mm)
H Non-combustible facing height 20” (508mm)
I Gas Connection Opening Height 1-1/2” (38mm)
J Gas Connection Height 4” (102mm)
K Gas Connection Inset 7-1/4” (184mm)
L Gas Connection Opening Width 3-1/4” (83mm)
*Framing depth measurement is noted with the side nailing strips set as far forward on the firebox as possible.
The nailing strips can be adjusted back - up to 1” (25mm) to allow for varying thicknesses in non-combustible
material & wall finishes.
INSTALLATION

Regency GemfireTM Gas Fireplace
12
INSTALLATION
INSTALLATION
NAILING STRIPS
The nailing strips come attached to the unit. There is 1 plate on each side,
1 on the top, and one on the bottom that can be folded out as required.
The top and side nailing strips are secured to the framing. The bottom
nailing strip is secured to the unfinished floor - if installing the unit
directly on the floor
UNIT ASSEMBLY
PRIOR TO
INSTALLATION
The top and side nailing strips and the top, rear and side standoffs
must be correctly positioned and attached to the top before unit is
slipped into position.
STANDOFF ASSEMBLY
The top, rear and side standoffs are shipped in a flat position and must
be folded into shape and attached.
1) Remove the standoffs from the fireplace top.
2) Takeeachstandoffandbendinto thecorrectshape.Bendup atthe
bendlinesuntilthescrewholesinthestandoffandthepre-punched
screw holes on the fireplace top line up.
3) Attachthestandoffsecurelywith2screwsperstandoff(onopposite
corners).
Nailing Strips shown folded out.
VENTING INTRODUCTION
The Gem54™ uses the "balanced flue" technology CoAxial system.
The inner liner vents products of combustion to the outside while the
outer liner draws outside combustion air into the combustion chamber
thereby eliminating the need to use heated room air for combustion and
losing warm room air up the chimney.
Note: These flue pipes must not be connected to any other
appliance.
Thegasapplianceandventsystemmustbeventeddirectlytotheoutside
ofthebuilding,andneverbeattachedtoachimneyservingaseparatesolid
fuel or gas burning appliance. Each direct vent gas appliance must use
it's own separate vent system. Common vent systems are prohibited.
IMPORTANT NOTE
Framing depth measurement is noted with the
nailing strips set as far forward on the firebox
(top and sides) as possible. The nailing strips
can be adjusted back - up to 1”(25mm) to
allow for varying thicknesses in
non-combustible material & wall finishes.
Nailing Strips

Regency GemfireTM Gas Fireplace 13
INSTALLATION
INSTALLATION
Vent restriction is required for certain venting installations, see the diagrams in the "Venting
Arrangements" section to determine if they are required for your installation.
The Vent Restrictor plate is located on the inside top of the firebox.
To set the vent restriction as indicated in the venting arrangements diagrams, refer to the following instructions;
1) Remove the glass door.
2) Remove the screws that hold the vent restrictor plate in place.
3) Adjust the vent restrictor plate to the required vent restrictor position as per the diagrams shown.
4) Once the vent restrictor plate is in the required position, secure with screws.
VENT RESTRICTOR POSITION
Vent Restrictor Settings for Gem54-NG Vent Restrictor Settings for Gem54-LP
Gem54-ULPG
108mm
76mm
51mm
Vent Restrictor Set 1
Factory Set Vent Restrictor
(No adjustment required)
Vent Restrictor Set 2
Vent Restrictor Set 3
SET 2
THIS HOLE SETS THE
VENT RESTRICTOR
AT 76mm
SET 1
THIS HOLE SETS THE
VENT RESTRICTOR
(factory setting)
AT 108mm
SET 3
THIS HOLE SETS THE
VENT RESTRICTOR
AT 51mm
SET 3
THIS HOLE SETS THE
VENT RESTRICTOR
AT 51mm
SET 1
THIS HOLE SETS THE
VENT RESTRICTOR
(factory setting)
AT 108mm
SET 4
THIS HOLE SETS THE
VENT RESTRICTOR
AT 25mm

Regency GemfireTM Gas Fireplace
14
INSTALLATION
INSTALLATION
EXTERIOR FLUE TERMINATION LOCATIONS
Minimum clearances required for balanced flue terminals or
the flue terminals of outdoor appliances
according to AS5601-2004 (AGA gas installation code) or NZS 5262 (New Zealand)
and local authorities having jurisdiction.
Minimum Clearance (mm)
a Below eaves, balconies or other projections:
- Appliances up to 50 MJ/h input 300
- Appliances over 50 MJ/h input 500
b From the ground or above a balcony 300
c From a return wall or external corner 500
d From a gas meter (M) 1000
e From an electricity meter or fuse box (P) 500
f From a drain or soil pipe 150
g Horizontal from any building structure (unless appliance is approved
for closer installation) or obstruction facing a terminal 500
h From any other flue terminal, cowl or combustion air intake 500
j Horizontally from an openable window, door, or non-mechanical air inlet, or
any other opening into a building, with the exception of sub-floor ventilation
(see also Note (I)):
- Appliances up to 150 MJ/h input 500
- Appliances over 150 MJ/h input 1500
k Vertically below an openable window, door, or non-mechanical air inlet,
or any other opening into a building, with the exception of sub-floor ventilation
(I) For mechanical air inlets, including spa blowers, the clearance 'j' and 'k' shall be 1500 mm in all cases.
(II) All distances shall be measured vertically or horizontally along the wall to a point in line with the nearest par to of the terminal.
(III)Prohibited area below electricity meter or fuse box extends to ground level.
(IV)A flue terminal of this type shall not be located under a roofed area unless the roofed area is fully open on at least two sides and a free flow of
air at the appliance is achieved.
(see also Note (I)): see table below
Clearance 'k' in mm
Space Heaters All Other Appliances
Up to 50 MJ/h
input
Up to 50 MJ/h Over 50 MJ/h input
to 150 MJ/h input
Over 150 MJ/h
input
150 500 1000 1500

Regency GemfireTM Gas Fireplace 15
INSTALLATION
8” (203mm) dia.
Flue pipe
5” (127mm) dia. flue pipe
spring spacer
Termination Cap
AstroCap XLTM
(Part #946-623/P)
Vent Guard - if required*
(Part #946-506/P)
Wall Thimble
(Mandatory in all
Horizontal Terminations)
Vinyl Siding
Standoff
INSTALLATION
VENTING ARRANGEMENTS
HORIZONTAL TERMINATION (FLEX)
Regency®Direct Vent System
These venting systems, in combination with the Gem54, have been tested and listed as a direct vent system byAGA. The location of the termination
cap must conform to the requirements in the Vent Terminal Locations diagram from the "Exterior Vent Termination Locations" section.
FPI Direct Vent (Flex) System Termination Kits include all the
parts needed to install the Gem54 using a flexible vent.
Notes:
1) Liner sections should be continuous without any joints
or seams.
2) OnlyFlex pipe purchasedfrom FPImay be usedfor Flex
installations.
3) Horizontal vent must be supported every 3 feet (0.9m).
4) Awallthimbleismandatoryforallhorizontalterminations
due to high temperatures.
FPI Kit # Length Contains:
#946-615 4 Feet
(1.2 m) 1) 8” (203mm) flexible liner (Kit length)
2) 5”(127mm) flexible liner (Kit length)
3) spring spacers
4) thimble
5) AstroCap termination cap
6) screws
7) tube of Mill Pac
8) plated screws
9) S.S. screws #8 x 1-1/2” (38mm) drill
point
10) vinyl siding standoff
#946-618 6 Feet
(1.8 m)
#946-616 10 Feet
(3 m )

Regency GemfireTM Gas Fireplace
16
INSTALLATION
RIGID PIPE VENTING SYSTEMS
BASIC HORIZONTAL & VERTICAL TERMINATIONS
Rigid Pipe Vent Systems offer a complete line of
componentpartsforinstallationofbothhorizontal
andverticalinstallations.Manyitemsareofferedin
decorative black, as well as galvanized finish.
Theminimumcomponentsrequiredforabasic
Horizontal Termination are:
1 AstroCap XL Termination Cap
1 90oElbow
1 Rigid Pipe Adaptor
1 Wall Thimble
1 Length of rigid pipe to suit wall thickness
Theminimumcomponentsrequiredforabasic
Vertical Termination are:
1 Vertical Termination Cap
1 Rigid Pipe Adaptor
1 Lengths of pipe to adequately
penetrate roof
1 Ceiling Firestop
1 Flashing
1 Storm Collar
Wall thickness is measured from the back
standoffs to the inside mounting surface of
terminationcap.Forsidingotherthanvinylfurring
strips may be used, instead of the vinyl siding
standoff, to create a level surface to mount the
ventterminal.TheTerminalmustnotberecessed
into siding. Measure the wall thickness including
furring strips.
If a Vinyl Siding Standoff is required (it must be
usedwithvinylsiding),measuretooutsidesurface
of wall without siding and add 2" (51mm).
When using Rigid Vent other than
Simpson Dura-Vent, 3 screws must be
used to secure rigid pipe to adaptor.
WARNING:
Do not combine venting components from
different venting systems.
Exception: However, use of the the AstroCap
XLTM is acceptable with all systems.
INSTALLATION
Rigid Pipe
Adaptor (770-994)
Pipe Length
Vertical Terminal
Flashing
Pipe
Length
Pipe Length
90 Elbow
o
AstroCap XL
Termination Cap
(Part #946-623/P)
Wall Thimble
(Mandatory in all
Horizontal Terminations)
Vent Guard - if required*
(Part #946-506/P)

Regency GemfireTM Gas Fireplace 17
INSTALLATION
INSTALLATION
5” X 8” RIGID PIPE CROSS REFERENCE CHART
Components from different Manufacturers may not be mixed. NotAll Rigid Pipe components are available directly from FPI.
Adjustable Length 3”-10”-Galvanized N/A N/A
Adjustable Length 3”-10”-Black N/A N/A
Adjustable Length 11”-14” -Galvanized Disc. - See 58DV-08A 5DT-AJ
Adjustable Length 11”-14” -Black Disc. - See 58DV-08B 5DT-AJB
Extension Pipe 17”-24” -Galvanized Disc. - See 58DV-16A N/A
Extension Pipe 17”-24” -Black Disc. - See 58DV-16AB N/A
Adjustable Length 8-1/2”-Galvanized 58DVA-08A - N/A from FPI N/A
Adjustable Length 8-1/2”-Black 58DVA-08AB N/A
Extension Pipe 16”-Galvanized 58DVA-16A - N/A from FPI N/A
Extension Pipe 16”-Black 46DVA-16AB N/A
45ºElbow-Galvanized 58DVA-E45 5DT-EL45
45ºElbow-Black 58DVA-E45B 5DT-EL45B
45ºElbow Swivel-Galvanized Disc. - See 58DVA-E45 N/A
45ºElbow Swivel-Black Disc.-See 58DVA-E45B N/A
90ºElbow-Galvanized 58DVA-E90 5DT-EL90S
90ºElbow-Black 58DVA-E90B 5DT-EL90SB
90ºElbow, Swivel-Galvanized Disc. - See 46DVA-E45 N/A
90ºElbow, Swivel-Black Disc. - See 46DVA-E45 N/A
90º Starter Elbow, Swivel-Galvanized N/A N/A
Adaptor* N/A N/A
Ceiling Support 58DVA-DC 5DT-CS
Cathedral Support Box 58DVA-CS 5DT-CSS
Wall Support/Band 58DVA-WS 5DT-WS/B
Offset Support 58DVA-ES - N/A from FPI 5DT-OS
Wall Thimble-Black 58DVA-WT 5DT-WT
Wall Thimble Support/Ceiling Support 58DVA-DC - N/A from FPI N/A
Firestop Spacer 58DVA-FS 5DT-FS
Trim Plate-Black 58DAV-WFS 5DT-TP
Description Simpson
Direct Vent Pro®
Selkirk
Direct Temp™
6” Pipe Length-Galvanized 58DVA-06 5DT-6
6” Pipe Length-Black 58DVA-06B 5DT-6B
9” Pipe Length-Galvanized 58DVA-09 5DT-9
9” Pipe Length-Black 58DVA-09B 5DT-9B
12” Pipe Length-Galvanized 58DVA-12 5DT-12
12” Pipe Length-Black 58DVA-12B 5DT-12B
18” Pipe Length-Galvanized 58DVA-18 5DT-18
18” Pipe Length-Black 58DVA-18B - N/A from FPI 5DT-18B
24” Pipe Length-Galvanized 58DVA-24 5DT-24
24” Pipe Length-Black 58DVA-24B 5DT-24B
36” Pipe Length-Galvanized 58DVA-36 5DT-36
36” Pipe Length-Black 58DVA-36B 5DT-36B
48” Pipe Length-Galvanized 58DVA-48 5DT-48
48” Pipe Length-Black 58DVA-48B 5DT-48B
60” Pipe Length-Galvanized 58DVA-60 N/A
60” Pipe Length-Black 58DVA-60B - N/A from FPI N/A

Regency GemfireTM Gas Fireplace
18
INSTALLATION
INSTALLATION
Description Simpson
Direct Vent Pro®
Selkirk
Direct Temp™
Metal-Fab™
Sure Seal
ICC Excel
Direct
Attic Insulation Shield 12” 58DVA-IS N/A from FPI N/A N/A N/A
High Wind Vertical Cap 58DVA-VCH N/A N/A TM-5VT
High Wind Horizontal Cap N/A N/A N/A TM-5DHT
Horizontal Square Termination Cap N/A 5DT-HHC 5DHT TM-5HT
Vertical Termination Cap N/A 5DT-HVC 5DVT TM-5VT
Storm Collar 58DVA-SC 5DT-SC 5DSC TM-SC
Restrictor Disk 58DVA-RD N/A N/A TM-5DS
Colinear Flex Connectors N/A N/A N/A N/A
Adjustable Flashing 0/12-6/12 58DVA-F6 5DT-AF6 5DF TF-5FA
Adjustable Flashing 6/12-12/12 58DVA-F12 5DT-AF12 5DF1-2 TF-5FB
Vinyl Siding Standoff 58DVA-VSS 5DT-VS 5DVS TM-VSS
Vinyl Siding Shield Plate N/A 5DT-VSP N/A N/A
Snorkel Termination 14” 58DVA-SNK14 N/A N/A TM-5ST14
Snorkel Termination 36” 58DVA-SNK36 (N/A - FPI) N/A N/A TM-5ST36
Basic Horizontal Termination Kit (A) N/A 5DT-HKA N/A N/A
Horizontal Termination Kit (B) 58DVA-KHA 5DT-HKB N/A N/A
Vertical Termination Kit 58DVA-VHA 5DT-VKC N/A N/A
FPI
946-604/P Simpson Direct Vent -Vent Guard (Optional) 946-623/P AstroCap XL Horizontal Cap
770-994 Rigid Pipe Adaptor (Must use with all rigid piping) 946-506/P Vent Guard (Optional)
946-606 Starter collar reducer 5” x 8” to 4” x 6-5/8” 946-625 Vinyl Siding Standoff - AstroCap XL
Note: When using Metal-Fab Sure Seal Rigid Piping - please note that the Adaptor (4DDA) must be used in conjunction with FPI Rigid Pipe Adaptor (510-994).
Offset Pipe Selection: Use this table to determine offset pipe lengths.
Pipe Length
(L)
5” x 8” Venting For specific instructions on venting components - visit the
manufacturers website listed below.
Run (X) Rise (Y)
0” (0mm) 5-11/16” (144mm) 15-5/16” (389mm) Simpson Direct Vent Pro: www.duravent.com
6” (152mm) 8-13/16” (224mm) 18-7/16” (468mm) Selkirk Direct-Temp: www.selkirkcorp.com
9” (229mm) 10-15/16” (278mm) 20-9/16” (522mm) Metal-Fab Sure Seal: www.mtlfab.com
12” (305mm) 13” (330mm) 22-11/16” (576mm) Industrial Chimney Company: www.icc-rsf.com
24” (610mm) 21-7/16” (697mm) 31-1/16” (789mm) Note: Horizontal runs of vent must be level, or have a 1/4”
rise for every 1 foot of run towards the termination.
Never allow the vent to run downward - this could cause high
temperatures and may present a possible fire hazard.
36” (914mm) 29-13/16” (757mm) 39-7/16” (1002mm)
48” (1219mm) 38-1/4” (972mm) 47-7/8” (1216mm)
L676 & L900 DIRECT VENT FIREPLACE
• A Vent Guard is required when the AstroCap is installed above grade at 7 feet or lower.
• The Simpson Dura-Vent and Selkirk Direct Temp horizontal termination caps cannot be used in any applications.
• Only the AstroCap XL and Snorkels are certified for horizontal terminations.
IMPORTANT NOTE

Regency GemfireTM Gas Fireplace 19
INSTALLATION
VENTING ARRANGEMENTS
ALLOWABLE HORIZONTAL TERMINATIONS
The diagram shows all allowable combinations of vertical runs with horizontal terminations, using one 90o(two 45o elbows equal one 90oelbow).
Note: Must use optional rigid pipe adapter (Part# 770-994) when using Simpson Duravent Venting Systems.
• Maintain clearances to combustibles as listed in "Clearances" section
• Horizontal vent must be supported every 3 ft / 91 cm.
• Firestops are required at each floor level and whenever passing through a wall.
• A wall thimble is mandatory for all horizontal terminations due to high temperatures.
VENT RESTRICTOR SETTING:
Vent restrictor factory set, no adjustment required unless otherwise indicated.
Refer to the "Vent Restrictor Position" section for details on how to change the vent restrictor from the factory setting of Set 1 to Set 2 or Set 3
if required.
INSTALLATION
2
2
0
0
12
12 20
6
6 14
4
44” (1118mm)
Minimum Height
Requirement
4
14
8
816
10
10
18
18
Vertical Height (Feet)
Horizontal (Feet)
Vent Restrictor
on Set 2
Vent Restrictor
on Set 3
Vent Restrictor
on Set 1
(factory setting)
16
18
18
"THIS UNIT MUST ALWAYS
TERMINATE / VENT
DIRECTLY TO THE OUTDOORS."

Regency GemfireTM Gas Fireplace
20
INSTALLATION
INSTALLATION
VENTING ARRANGEMENTS
ALLOWABLE HORIZONTAL TERMINATIONS FOR GEM54-LPG/ULPG
The diagram shows all allowable combinations of vertical runs with horizontal terminations, using one 90o(two 45o elbows equal one 90oelbow).
Note: Must use optional rigid pipe adapter (Part# 770-994) when using Rigid Pipe Venting Systems.
• Maintain clearances to combustibles as listed in "Clearances" section
• Horizontal vent must be supported every 3 feet (0.9m).
• Firestops are required at each floor level and whenever passing through a wall.
• A wall thimble is mandatory for all horizontal terminations due to high temperatures.
VENT RESTRICTOR SETTING:
Vent restrictor factory set, no adjustment required unless otherwise indicated.
Refer to the "Vent Restrictor Position" section for details on how to change the vent restrictor from the factory setting of Set 1 to
Set 3 if required.
Note: Regency®Direct Vent System (Flex) is only approved for horizontal terminations.
2
2
0
0
12
12 20
6
6 14
4
44” (1118mm)
Minimum Height
Requirement
4
14
8
816
10
10
18
18
Vertical Height (Feet)
Horizontal (Feet)
Vent Restrictor
on Set 3
Vent Restrictor
on Set 1
(factory setting)
16
18
18
"THIS UNIT MUST ALWAYS
TERMINATE / VENT
DIRECTLY TO THE OUTDOORS."
