189June 2007 Regency Product Specifications Book
Wood Inserts
Wood Inserts
I2400 Wood Insert
Minimum Fireplace Opening
Height 21-1/2” (546mm)
Width 25” (635mm)
Depth 17” (432mm)
Faceplate Dimensions
Standard 40” (wide) x 30” (height)
Oversize 48” (wide) x 33” (height)
Dimension Description I2400
A Adjacent Side Wall (to side) 11” (280mm)
B
Mantle (to top)** 20” (508mm)
Mantle Depth (not shown) Maximum 20” (508mm)
C Top Facing (to top) 12” (305mm)
D Side Facing (to side) 8” (205mm)
E Minimum Hearth Extension* 18” (455mm)
F Minimum Heath Thickness* 1/2” (13mm)
G Minimum Hearth Side Extension 8” (205mm)
Firebox height is 21” at highest point.
Side and Top facing is a maximum of 1-1/2" thick.
Floor protection must be non-combustible, insulating material with an R value of
1.1 or greater.
* Hearth thickness of 1/2" with k value = 0.84", R value = 6 or greater.
** Anon-combustible mantel may be installed at a lower height if the framing
is made of metal studs covered with a non-combustible board.
Thermal floor protection is not required if the unit is raised 3-1/2" minimum
(measured from the bottom of the stove). However, standard ember floor protection
is required. It will need to be a non-combustible material that covers 16" (406
mm) in the US and 18" (450 mm) in Canada to the front of the unit and 8" (200
mm) to the sides.
If the unit is not raised, thermal floor protection required is 18" (450 mm) in the
US and Canada.
All floor protection must be non-combustible (i.e., metals, brick, stone, mineral
fiber boards, etc.) Any organic materials (i.e. plastics, wood paper products, etc.)
are combustible and must not be used. The floor protection specified includes
some form of thermal designation such as R-value (thermal resistance) or k-factor
(thermal conductivity).
I2400 Medium Wood Insert
