Regency Ultimate U38-NG1 Quick start guide

FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4
WARNING:
If the information in these instructions are not followed ex-
actly,afireorexplosionmayresultcausingpropertydamage,
personal injury or loss of life.
FOR YOUR SAFETY
Do not store or use gasoline or other flammable vapors and
liquids in the vicinity of this or any other appliance.
Installation and service must be performed by a qualified
installer, service agency or the gas supplier.
FOR YOUR SAFETY
What to do if you smell gas:
Do not try to light any appliance
Do not touch any electrical switch:
donotuseanyphoneinyourbuild-
ing.
Immediately call your gas supplier
from a neighbour's phone. Follow
the gas supplier's instructions.
If you cannot reach your gas sup-
plier, call the fire department.
918-530a
MODELS: U38-NG1 Natural Gas U38-LP1 Propane
04/05/11
ULTIMATE U38 Freestanding Gas Stove
Owners &
Installation Manual
Tested by: Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
www.regency-fire.com

2Regency®U38-1 ULTIMATE Freestanding Gas Stove
To the New Owner:
Congratulations! You are the owner of a state-of-the-art ULTIMATE Gas Stove by FIREPLACE PROD-
UCTS INTERNATIONAL LTD. The Regency®Gas Series of hand crafted appliances has been designed
to provide you with all the warmth and charm of a woodstove, at the flick of a switch. The models U38-
NG1, and U38-LP1 of this series has been approved by Warnock Hersey for both safety and efficiency.
As it also bears our own mark, it promises to provide you with economy, comfort and security for many
trouble free years to follow. Please take a moment now to acquaint yourself with these instructions and
the many features of your Regency®Gas Stove.

Regency®U38-1 ULTIMATE Freestanding Gas Stove 33
TABLE OF CONTENTS
OPERATING INSTRUCTION
Operating Instructions ................................................23
Lighting Instructions.....................................................23
Shutdown Instructions.................................................23
First Fire ......................................................................23
Automatic Convection Fan Operation..........................23
Adjusting Flame Height ...............................................23
Copy of the Lighting Plate Instructions .......................24
Pilot Adjustment...........................................................25
Aeration Adjustment ....................................................25
Normal Operating Sounds of Gas Appliances.............25
MAINTENANCE
Maintenance instructions.............................................26
Log Replacement ........................................................26
Door and Glass Gasket...............................................26
Gold-plated Doors .......................................................26
Glass Replacement.....................................................26
Fan Maintenance.........................................................27
Removing Valve...........................................................28
PARTS LIST
U38-1 Main Assembly..................................................29
U38-1 Burner & Log Assembly....................................30
U38-1 Door Assemblies...............................................31
WARRANTY
Warranty......................................................................35
SAFETY LABEL
Copy of Safety Label.....................................................5
REQUIREMENTS
MA Code - CO Detector.................................................6
INSTALLATION
Before You Start ............................................................7
Important Message ......................................................8
General Safety Information............................................8
Installation Checklist......................................................8
Clearances to Combustibles..........................................9
Optional Outside Air.......................................................9
Draft Hood...................................................................10
High Elevation .............................................................10
Venting.........................................................................10
Gas Connection...........................................................11
Gas Pipe Pressure Testing..........................................11
Conversion from ng to lp .............................................12
Conversion to Lower BTU Rating................................15
Log Set Installation......................................................16
Front Door Installation.................................................19
Louver Installation .......................................................19
Test for Flue Spillage...................................................19
Wall Thermostat ..........................................................20
Remote Control ..........................................................20
Final Check..................................................................20
Wiring Diagrams..........................................................21

4Regency®U38-1 ULTIMATE Freestanding Gas Stove
DIMENSIONS
U38-NG1 & U38-LP1

Regency®U38-1 ULTIMATE Freestanding Gas Stove 5
SAFETY LABEL
This is a copy of the label that accompanies
each ULTIMATE Freestanding Gas Stove. We
haveprintedacopyofthecontentshereforyour
review. The safety label is located on the inside
of the drop down pedestal door.
NOTE: Regency®units are constantly being
improved. Check the label on the unit and if
there is a difference, the label on the unit is the
correct one.
Copy of the Safety Label for the U38-1 Freestanding Gas Stove
Minimum Clearances to Combustibles
Degagement minimum des materiaux combustibles:
314
Serial No./No de serie
DO NOT REMOVE THIS LABEL/NE
PAS ENLEVER CETTE ÉTIQUETTE
918-508a
A 7-1/2" /190mm
B 6" /150mm
E 2" /50mm
Min.Ceiling Height from topof unit / Min.Plafond
Hauteur en haut de l'appareil:
36" / 914 mm
ÉQUIPÉ À L'UISINE POUR GAZ NATUREL:
Pression d’alimentation minimum
Pression tubulure d’échappement élevée
Pression tubulure d’échappement basse
Dimensions de l’orifice
L'altitude
Débit calorifique maximum selon
Débit calorifique minimum selon
Transforme en haute l'altitude Gaz Naturel:
Dimensions de l’orifice
L'altitude
Débit calorifique maximum selon
Débit calorifique minimum selon
Dimensions de l’orifice
Débit calorifique maximum selon
Débit calorifique minimum selon
ÉQUIPÉ À L'UISINE POUR GAZ PROPANE:
Pression d’alimentation minimum
Pression tubulure d’échappement élevée
Pression tubulure d’échappement basse
Dimensions de l’orifice
L’altitude
Débit calorifique maximum selon
Débit calorifique minimum selon
Dimensions de l’orifice
Débit calorifique maximum selon
Débit calorifique minimum selon
Duplicate serial #
Model/Modele: U38-NG1 Model/Modele: U38-LP1
314
MAY BE INSTALLED IN MANUFACTURED (MOBILE) HOMES AFTER FIRST SALE
This appliance must be installed in accordance with local codes, if any; if none, follow the National Fuel Gas Code, ANSI Z223.1, or Natural Gas and Propane Installation Code, CSA B149.1.
This appliance must be installed in accordance with the Standard CAN/CSA Z240 MH, Mobile Housing, in Canada, or with the Manufactured Home Construction and Safety Standard, Title
24 CFR, Part 3280, in the United States, or when such a standard is not applicable, ANSI/NCSBCS A225.1/NFPA 501A, Manufactured Home Installations Standard or ANSI A119.2 ou NFPA
501C Standard for Recreational Vehicles
This appliance is only for use with the type of gas indicated on the rating plate and may be installed in an aftermarket, permanently located, manufactured (mobile) home where not prohibited
by local codes. See owner's manual for details.
Installer l'appareil selon les codes ou règlements locaux, ou, en l'absence de tels règlements, selon les codes d'installation ANSI Z223.1, National Fuel Gas Code ou CSA-B149.1 en vigueur.
Installer l'appareil selon la norme CAN/CSA-Z240, Série MM, Maison mobiles ou CAN/CSA-Z240 VC, Véhicules de camping, ou la norme 24 CFR Part 3280, Manufactured Home Construc-
tion and Safety Standard. Si ces normes ne sont pas pertinentes, utilisez la norme ANSI/NCSBCS A225.1/NFPA 501A, Manufactured Home Installations Standard, ou ANSI A119.2 ou NFPA
501C Standard for Recreational Vehicles.
Cet appareil doit être utilize uniquement avec le type de gaz indiqué sur la plaque signalétique. Cet appareil peut être installé dans une maison préfabriquéo
mobile (É.-U. seulement) installée à demeure si les règlements locaux le permettent. Voir la notice de l'utilisateur pour plus de renseignements. Cet apparene
peut pas être utilisé avec
d'autres gaz sauf si une trousse de conversion certifiée est fournie.
This vented gas fireplace heater is not for use with air filters. Ne pas utiliser de filtre à air avec ce foyer au gaz à évacuation
.
For use with glass doors certified with the appliance only Pour utilisation uniquement avec les portes en verre certifiées avec l'appareil
Listed: VENTED GAS FIREPLACE HEATER / FOYER AU GAZ À ÉVACUATION
Certified for/Certifiée pour: CANADA and U.S.A.
Tested to: CGA-2-17-M91, ANSI Z21.88a-2007 / CSA 2.33a-2007
WN# 16459
FACTORY EQUIPPED FOR NATURAL GAS: Model U38-NG1
Minimum supply pressure 5" WC/C.E. (1.25kPa)
Manifold pressure High 3.8" WC/C.E. (0.94kPa)
Manifold pressure Low 1.1" WC/C.E. (0.27kPa)
Model U38-NG: Factory Equipped for Altitude 0-2000 ft.
Orifice size #31 DMS
Altitude 0-2000 ft/pi (0-610)
Maximum Input 40,000 Btu/h (11.73Kwh)
Minimum Input 21,000 Btu/h (6.15Kwh)
Model U38-NG: Convertible for Altitude 2000-4500 ft.
Orifice size #33 DMS
Altitude 2000-4500ft/pi (610-1370m)
Maximum Input 36,000 Btu/h (10.55Kw)
Minimum Input 19,000 Btu/h (5.57Kwh)
Model U38-NG: Convertible to 30,000 Btu for Altitude 0-4500 ft.
Orifice size #37 DMS
Maximum Input 30,000 Btu/h (8.78Kwh)
Minimum Input 15,000 Btu/h (4.39Kwh)
FACTORY EQUIPPED FOR PROPANE GAS: Model U38-LP1
Minimum supply pressure 12" WC/C.E. (3.00Kpa)
Manifold pressure High 11" WC/C.E. (2.74Kpa)
Manifold pressure Low 2.9" WC/C.E. (0.72Kpa)
Orifice size 50 DMS
Altitude 0-2,000 ft/pi (0-610m)
Maximum Input 38,000 BTU/h (11.14Kw/h)
Minimum Input 20,000 BTU/h (5.86Kw/h)
Model U38-LP: Convertible to 30,000 Btu for Altitude 0-4500 ft.
Orifice size #52 DMS
Maximum Input 30,000 Btu/h (8.78Kwh)
Minimum Input 15,000 Btu/h (4.39Kwh)
VENTED GAS FIREPLACE HEATER - NOT FOR USE WITH SOLID FUELS.
FOYER AU GAZ À ÉVACUATION - NE PAS UTILISER AVEC DU COMBUSTIBLE SOLIDE.
Electrical supply / Électrique 115VAC, 1.13 A, 60Hz
Made in Canada / Fabrique au Canada
For the State of Massachusetts, installation and repair must be done by a plumber or gasfitter licensed in the Commonwealth of
Massachusetts.
For the State of Massachusetts, flexible connectors shall not exceed 36 inches in length.
For the State of Massachusetts, the appliances individual manual shut-off must be a t-handle type valve.
The State of Massachusetts requires the installation of a carbon monoxide alarm in accordance with NFPA 720 and a CO alarm
with battery back up in the same room where the gas appliance is installed.

6Regency®U38-1 ULTIMATE Freestanding Gas Stove
REQUIREMENTS
5.08: Modifications to NFPA-54, Chapter 10
(2) Revise 10.8.3 by adding the following additional requirements:
(a) For all side wall horizontally vented gas fueled equipment installed in every dwelling, building or structure used in whole or in part for
residential purposes, including those owned or operated by the Commonwealth and where the side wall exhaust vent termination is less than
seven (7) feet above finished grade in the area of the venting, including but not limited to decks and porches, the following requirements shall
be satisfied:
1. INSTALLATION OF CARBON MONOXIDE DETECTORS. At the time of installation of the side wall horizontal vented gas fueled
equipment, the installing plumber or gasfitter shall observe that a hard wired carbon monoxide detector with an alarm and battery back-up is
installed on the floor level where the gas equipment is to be installed. In addition, the installing plumber or gasfitter shall observe that a battery
operated or hard wired carbon monoxide detector with an alarm is installed on each additional level of the dwelling, building or structure
served by the side wall horizontal vented gas fueled equipment. It shall be the responsibility of the property owner to secure the services of
qualified licensed professionals for the installation of hard wired carbon monoxide detectors
a. In the event that the side wall horizontally vented gas fueled equipment is installed in a crawl space or an attic, the hard wired carbon
monoxide detector with alarm and battery back-up may be installed on the next adjacent floor level.
b. In the event that the requirements of this subdivision can not be met at the time of completion of installation, the owner shall have a period of
thirty (30) days to comply with the above requirements; provided, however, that during said thirty (30) day period, a battery operated carbon
monoxide detector with an alarm shall be installed.
2. APPROVED CARBON MONOXIDE DETECTORS. Each carbon monoxide detector as required in accordance with the above provisions
shall comply with NFPA 720 and be ANSI/UL 2034 listed and IAS certified.
3. SIGNAGE. A metal or plastic identification plate shall be permanently mounted to the exterior of the building at a minimum height of eight
(8) feet above grade directly in line with the exhaust vent terminal for the horizontally vented gas fueled heating appliance or equipment. The
sign shall read, in print size no less than one-half (1/2) inch in size, "GAS VENT DIRECTLY BELOW. KEEP CLEAR OF ALL
OBSTRUCTIONS".
4. INSPECTION. The state or local gas inspector of the side wall horizontally vented gas fueled equipment shall not approve the installation
unless, upon inspection, the inspector observes carbon monoxide detectors and signage installed in accordance with the provisions of 248 CMR
5.08(2)(a)1 through 4.
(b) EXEMPTIONS: The following equipment is exempt from 248 CMR 5.08(2)(a)1 through 4:
1. The equipment listed in Chapter 10 entitled "Equipment Not Required To Be Vented" in the most current edition of NFPA 54 as adopted by
the Board; and
2. Product Approved side wall horizontally vented gas fueled equipment installed in a room or structure separate from the dwelling, building or
structure used in whole or in part for residential purposes.
(c) MANUFACTURER REQUIREMENTS - GAS EQUIPMENT VENTING SYSTEM PROVIDED. When the manufacturer of Product
Approved side wall horizontally vented gas equipment provides a venting system design or venting system components with the equipment, the
instructions provided by the manufacturer for installation of the equipment and the venting system shall include:
1. Detailed instructions for the installation of the venting system design or the venting system components; and
2. A complete parts list for the venting system design or venting system.
(d) MANUFACTURER REQUIREMENTS - GAS EQUIPMENT VENTING SYSTEM NOT PROVIDED. When the manufacturer of a
Product Approved side wall horizontally vented gas fueled equipment does not provide the parts for venting the flue gases, but identifies
"special venting systems", the following requirements shall be satisfied by the manufacturer:
1. The referenced "special venting system" instructions shall be included with the appliance or equipment installation instructions; and
2. The "special venting systems" shall be Product Approved by the Board, and the instructions for that system shall include a parts list and
detailed installation instructions.
(e) A copy of all installation instructions for all Product Approved side wall horizontally vented gas fueled equipment, all venting instructions,
all parts lists for venting instructions, and/or all venting design instructions shall remain with the appliance or equipment at the completion of
the installation.
MA Code - CO Detector
(for the State of Massachusetts only)

Regency®U38-1 ULTIMATE Freestanding Gas Stove 7
INSTALLATION
BEFORE YOU START
Safe installation and operation of this appliance
requirescommonsense,however,wearerequired
by the Canadian Safety Standards and ANSI
Standards to make you aware of the following:
CLOTHING OR OTHER FLAMMABLE
MATERIAL SHOULD NOT BE PLACED
ON OR NEAR THE APPLIANCE.
CHILDREN AND ADULTS SHOULD BE
ALERTED TO THE HAZARDS OF HIGH
SURFACE TEMPERATURES, ESPE-
CIALLY THE FIREPLACE GLASS, AND
SHOULD STAY AWAYTO AVOID BURNS
OR CLOTHING IGNITION.
INSTALLATION AND REPAIR SHOULD
BE DONE BY AN AUTHORIZED
SERVICE PERSON. THE APPLIANCE
SHOULD BE INSPECTED BEFORE
USE AND AT LEAST ANNUALLY BY A
PROFESSIONAL SERVICE PERSON.
MORE FREQUENT CLEANING MAY
BE REQUIRED DUE TO EXCESSIVE
LINT FROM CARPETING, BEDDING
MATERIAL,ETC. IT IS IMPERATIVETHAT
CONTROL COMPARTMENTS,BURNERS
AND CIRCULATING AIR PASSAGEWAYS
OF THE APPLIANCE BE KEPT CLEAN.
DUE TO HIGH TEMPERATURES, THE
APPLIANCE SHOULD BE LOCATED
OUT OF TRAFFIC AND AWAY FROM
FURNITURE AND DRAPERIES.
WARNING: FAILURE TO INSTALL THIS
APPLIANCE CORRECTLY WILL VOID
YOUR WARRANTY AND MAY CAUSE A
SERIOUS HOUSE FIRE.
YOUNG CHILDREN SHOULD BE CARE-
FULLY SUPERVISED WHEN THEY ARE
IN THE SAME AREA AS THE APPLI-
ANCE. TODDLERS,YOUNG CHILDREN
AND OTHERS MAY BE SUSCEPTIBLE
TO ACCIDENTAL CONTACT BURNS. A
PHYSICAL BARRIERS IS RECOMMEND-
ED IF THERE ARE AT RISK INDIVIDUAL
INTHE HOUSE. TO RESTRICT ACCESS
TO A FIREPLACE OR STOVE, INSTALL
AN ADJUSTABLE SAFETY GATE TO
KEEP TODDLERS, YOUNG CHILDREN
AND OTHER AT RISK INDIVIDUALS OUT
OF THE ROOM AND AWAY FROM HOT
SURFACES.

8Regency®U38-1 ULTIMATE Freestanding Gas Stove
INSTALLATION
IMPORTANT MESSAGE
SAVE THESE
INSTRUCTIONS
The ULTIMATE Freestanding Gas Stove must be
installed in accordance with these instructions.
Carefully read all the instructions in this manual
first. Consult the "authority having jurisdiction" to
determine the need for a permit prior to starting
the installation.
GENERAL SAFETY
INFORMATION
1) The appliance installation must conform with
local codes or, in the absence of local codes,
with the current Canadian or National Gas
Codes,CAN1-B149orANSI-223.1Installation
Codes.
2) The appliance when installed, must be electri-
callygroundedinaccordancewithlocalcodes,
orintheabsenceoflocalcodeswiththecurrent
NationalElectricalCode,ANSI/NFPA70orCSA
C22.1 Canadian Electrical Code.
3) This appliance is Listed for bedroom instal-
lations when used with a Listed Millivolt
Thermostat. Some areas may have further
requirements,check localcodesbefore instal-
lation.
4) ThisapplianceisListedforAlcoveinstallations,
maintain minimum Alcove clearances as fol-
lows,minimumceilingheightof 66", minimum
width of 48" and a maximum depth of 36".
5) This unit is not approved for installation into a
mobile home.
6) Seegeneralconstructionandassemblyinstruc-
tions.
7) This appliance must be connected to a vent
and terminate to the outside of the building
envelope.Neverventtoanotherroomorinside
a building.
8) Inspect the venting system annually for block-
age and any signs of deterioration.
9) Any safety glass removed for servicing must
be replaced prior to operating the appliance.
10) To prevent injury, do not allow anyone who is
unfamiliarwiththeoperationtousethefireplace.
11) Wear gloves and safety glasses for protection
while doing required maintenance.
12) Under no circumstances should this appliance
be modified. Parts that have to be removed for
servicing should be replaced prior to operating
this appliance.
13) Installation and any repairs to this appliance
should be done by a qualified service person.A
professional service person should be called to
inspect this appliance annually. Make it a prac-
tice to have all of your gas appliances checked
annually.
14) Do not strike the glass door.
15) Under no circumstances should any solid fuels
(wood, paper, cardboard, coal, etc.) be used in
this appliance.
16) The appliance area must be kept clear and free
ofcombustiblematerials,(gasesandotherflam-
mable vapours and liquids).
17) Donotconnectthisgasappliancetochimneyflue
serving a separate sold-fuel burning appliance.
18) WARNING:Operationofthisappliancewhennot
connectedtoaproperlyinstalledandmaintained
ventingsystemortamperingwiththeblockedvent
shutoff system can result in carbon monoxide
(CO) poisoning and possible death.
19) Thisapplianceneedsfreshairforsafeoperation
andmustbe installed so there are provisionsfor
adequate combustion and ventilation air.
INSTALLATION
CHECKLIST
1) Locatingyourappliance. Refertothe "Clearance
to Combustibles" section.
2) Ifusingoutsideair. Refertothe "OptionalOutside
Air" section.
3) Install venting. Refer to the "Venting" section.
4) Make gas connections. Refer to the "Gas
Connection" section.
Test the pilot. Must be as per diagram in the
"Pilot Adjustment" section.
5) If necessary, convert Natural Gas to Propane
(Refer to the "Conversion from Natural Gas
to Propane" section), or convert to lower BTU
(Refertothe "Conversion to Lower BTU Rating"
section).
Emissionsfrom burning wood or gas could
contain chemicals known to the State of
California to cause cancer, birth defects
or other reproductive harm.
6) Test Gas Pressure. Refer to the "Gas Pipe
Pressure Testing" section.
7) Install standard and optional features. Refer
to the following sections where applicable.
a. Log Set Installation
b. Front Door Installation
c. Louver Installation
d. Wall Thermostat
e. Remote Control
8) Test for flue spillage (draft test). Refer to the
"Test for Flue Spillage" section.
9) Finalcheck.Refertothe"FinalCheck"section.
Before leaving this unit with the customer, the
installer must ensure that the appliance is firing
correctlyandoperationfullyexplainedtocustomer.
This includes:
1) Clocking the appliance to ensure the correct
firing rate (rate noted on label) after burning
appliance for 15 minutes.
2) If required, adjusting the primary air to ensure
that the flame does not carbon. First allow the
unit to burn for 15-20 min. to stabilize.
CAUTION:Anyalterationtotheproductthatcauses
sooting or carboning or that results in damage is
not the responsibility of the manufacturer.

Regency®U38-1 ULTIMATE Freestanding Gas Stove 9
INSTALLATION
Side View
Rear View
Outside Air Through
Rear of Pedestal
Remove the blanking plate from the rear of the
pedestal cover plate and bend the two tabs
out 90 degrees. Pipe fresh air into the pedestal
area by using duct pipe with a mesh grill at the
outside termination.Attach the pipe to the tabs
with screws.
OPTIONAL
OUTSIDE AIR
Outside air for combustion can be brought in
either through the bottom of the pedestal or
through the rear plate of the pedestal.
Forbothbottomand rear "outside air" the Ped-
estalCoverPlatemustbeinstalled.Loosenthe
4 screws on the rear of the pedestal and slide
thecoverplateoverthem.Slidetheplatetothe
left to center it and tighten down the 4 screws.
Outside Air Through
Pedestal Bottom
Onceyouhaveproperly markedthepositionof
your unit as outlined in "General Information"
and "Clearances to Combustibles", cut a prop-
erly sized hole though the floor directly under
your pedestal base to the outside. Pipe fresh
air into the pedestal area by using appropriate
metallic duct pipe with a mesh grill at the out-
side termination. Do not remove the knockout.
CLEARANCES TO
COMBUSTIBLES
The clearances listed below are MINIMUM dis-
tances. Measure the clearance to both the appli-
ance and the chimney connector. (The farthest
distanceis correct if thetwo clearances donot
coincide.) For example, if the appliance is set as
indicated in one of the figures but the connector is
tooclose,movethestoveuntilthecorrectclearance
to the connector is obtained.
This unit can be installed on a solid combustible
surface like a wood floor. This unit can also be
installed directly on carpeting or vinyl when the
bottom pedestal cover plate (provided with unit)
is installed.
Thisappliancemaybeinstalledonlywiththeclear-
ances as shown in the situations pictured. Do not
combine clearances from one type of installation
withanotherinordertoachievecloserclearances.
Usetheminimumclearancesshowninthediagrams
below for installation with "B" vent.
Minimumceilingheightis36"/914mmfrom
top of unit.
U38-NG1 & U38-LP1 REFERENCE
DIMENSIONS
C Back Wall to Flue Centerline 10-3/4" / 273 mm
D Side Wall to Flue Centerline 20-1/2" / 520 mm
F Side Wall to Flue Centerline 11" / 280 mm
If further reduced clearances are needed, ob-
tainrequirementsforconstructionofaprotected
wallfromyourlocalbuildingauthoritiesandtheir
allowable reductions of the listed clearances.
U38-NG1 & U38-LP1 Clearances
A Side Wall to Unit 7-1/2" / 190 mm
B Back Wall to Unit 6" / 155 mm
E Side Wall to Unit 2" / 50 mm

10 Regency®U38-1 ULTIMATE Freestanding Gas Stove
INSTALLATION
VENTING
This heater is a vented appliance and must be
connected to a chimney/flue in accordance with
the installation codes.
Note: The rear pedestal cover plate is only
required when outside air is being
used.If usingroom airfor combustion,
remove this plate from the back of the
pedestal.
For your safety this heater is equipped with a vent
safety switch designed to sense incorrect venting
and react by shutting down the gas supply. This
thermallyactuated switch is located withinthedraft
hood and will detect either a blocked chimney or
backdraft condition where the chimney flow has
reversed. If this switch shuts the unit down, it in-
dicates a drafting problem that must be identified
andrectifiedwithout delay - the thermally activated
switchmust neverbebypassedordisconnectedas
a hazardous or deadly condition can result.
Venting Requirements
Afourinchdiameter ventisrequired. B-Vent,Class
Aor Masonry with an approved liner are all accept-
able. For cosmetic or aesthetic purposes 6" outer
ventcanbeusedaslongasanapprovedinnervent
is installed. Fasten but do not penetrate the inner
sleeve of the B-Vent when tightening the screw.
Followallventingmanufacturer’srequirementsand
local building codes. In cold climates, we recom-
mendtheuseofinsulatedB-vent,chase,andliners.
For altitudes above 2000 ft. we recommend that a
minimum flue height of 12 ft. is used.
Flue Mounting Bracket
Attach the flue mounting bracket with the enclosed
screw as shown in the diagram.
DRAFT HOOD
This heater has a draft hood built in. It must not
be altered, obstructed, or blocked in any way, and
the unit must be installed so that the draft hood
is in the same atmospheric pressure zone as the
combustionair inlet to the burner.This heater must
be properly connected to a venting system. This
heaterisequippedwithaventsafetyshutoffsystem.
WARNING: Operation of this heater when not
connectedtoaproperlyinstalledandmaintained
ventingsystemortamperingwiththeventsafety
shutoff system can result in carbon monoxide
(CO) poisoning and possible death.
HIGH ELEVATION
The U38-1 (with 40,000 BTU rating) is approved
in Canada for altitude 2000 ft. to 4500 ft. (CAN/
CGA-2.17-M91)withtheorificekit(Part#591-975).
For Natural Gas installations above 4500 ft. follow
current CAN/CGA-B149.1.
In U.S.A., for installations above 2000 ft. refer to
current ANSI Z223.1 Sc8-8.1.2a appendix F, for
resizing orifice.
Vent Terminations
Installation into Existing
Woodstove Flue System
1) Clean existing Chimney system.
2) Run an approved 4" flex liner or "B" vent into
existing chimney.
Note: See the chimney systems manufactur-
er for detailed installation instructions.

Regency®U38-1 ULTIMATE Freestanding Gas Stove 11
INSTALLATION
4) Lightthepilotandturnthevalveto"ON"position.
5) The pressure check should be carried out with
theunitburningandthesettingshouldbewithin
the limits specified on the safety label.
6) When finished reading manometer, turn off the
gas valve, disconnect the hose and tighten the
screw (clockwise) with a 1/8" flat screwdriver.
Screw should be snug, but do not over tighten.
S.I.T. Valve Description
1) Gas on/off knob
2) Manual high/low adjustment
3) Pilot Adjustment
4) Thermocouple Connection
5) Main Operator
6) Outlet Pressure Tap
7) Inlet Pressure Tap
8) Pilot Outlet
9) Main Gas Outlet
10) Flange Securing Screw Holes
11) Alternative TC Connection Point
12) Thermoelectric Unit
13) Additional Valve Mounting Hole
GAS PIPE PRESSURE
TESTING
The appliance must be isolated from the gas
supply piping system by closing its individual
manual shut-off valve during any pressure
testing of the gas supply piping system at test
pressures equal to or less than 1/2 psig. (3.45
kPa). Disconnectpipingfromvalveatpressures
over 1/2 psig (14" w.c.).
Themanifoldpressureiscontrolledbyaregulator
builtintothegascontrol,andshouldbechecked
at the pressure test point.
Note: To properly check gas pressure,
both inlet and manifold pressures
should be checked using the valve
pressure ports on the valve.
1) Make sure the valve is in the "OFF" posi-
tion.
2) Loosen the "IN" (# 7) and/or "OUT" (# 6)
pressure tap(s), turning counterclockwise
with a 1/8" wide flat screwdriver.
3) Attach manometer to "IN" and/or "OUT"
pressure tap(s) using a 5/16" ID hose.
GAS CONNECTION
Thegaslinecanberigidpipe,ortomakeinstal-
lation easier, use a listed flexible connector if
allowed by local codes. Copper may also be
used if approved by local codes.
The gas connection at the valve is 3/8" NPT.
For minimum and maximum supply pressure
see the System Data Table.
U38-NG1: For 0 to 2000 feet altitude
U38-LP1: For 0 to 4500 feet alttitude
Burner Inlet Orifice Sizes:
Natural Gas Propane
Burner #31 #50
Max. Input
Natural Gas 40,000 Btu/h
Propane 38,000 Btu/h
Min. Input
Natural Gas 22,000 Btu/h
Propane 20,000 Btu/h
Supply Pressure
Natural Gas min. 5" w.c.
Propane min. 12" w.c.
Manifold Pressure
Natural Gas 3.8" +/- 0.2" w.c.
Propane 11" +/- 0.2" w.c.
Electrical: 120 V. 1.13A 60Hz.
Circulation: Variable speed fan, 125/75
CFM.
Log Set: Ceramic fiber, 7 per set.
System Data:
HIGH ELEVATION - U38-NG1
For 2,000 - 4,500 feet altitude
Burner Inlet Orifice Sizes:
Natural Gas Burner #33
Max. Input Rating 36,000 Btu/h
Min. Input Rating 19,000 Btu/h
System Data
U38-1 with 40,000 BTU
System Data
U38-1 Converted to 30,000 Btu
For 0 to 4500 feet altitude
Burner Inlet Orifice Sizes:
Natural Gas Propane
Burner #37 #52
Max. Input
Natural Gas 30,000 Btu/h
Propane 30,000 Btu/h
Min. Input
Natural Gas 15,000 Btu/h
Propane 15,000 Btu/h
Supply Pressure
Natural Gas min. 5" w.c.
Propane min. 12" w.c.
Manifold Pressure
Natural Gas 3.8" +/- 0.2" w.c.
Propane 11" +/- 0.2" w.c.
Electrical: 120 V. 1.13A 60Hz.
Circulation: Variable speed fan, 125/75
CFM.
Log Set: Ceramic fiber, 7 per set.

12 Regency®U38-1 ULTIMATE Freestanding Gas Stove
INSTALLATION
CONVERSION KIT# 731-969 FOR NG TO LP
THIS CONVERSION MUST BE DONE BY A QUALIFIED GAS FITTER IF IN DOUBT DO NOT DO THIS CONVERSION !!
1) Shut off the gas supply.
2) Open the front door and carefully
remove the logs and lava rock.
Pilot assembly is now accessible
for steps 4) to 10).
Each Kit contains one LPG
Conversion Kit and one DC
Sparker Kit.
LPG Conversion Kit Contains:
Qty. Part # Description
1 904-529 5/32" Allen Key
1 904-641 Burner Orifice #50
1 918-590 Label "Converted to
LPG"
1 908-528 Red "LPG" label
1 910-037 LPG Injector
(Pilot Orifice)
1 918-485 Instruction Sheet
DC Sparker Kit Contains:
Qty. Part # Description
1 820-475 Bracket DC Sparker
1 820-476 Bracket DC Sparker
1 904-153 Washer #8 External
Star
1 904-330 Nut 8-32 Hex
1 904-438 Plug Nylon 0.750 Hole,
Black
2 904-531 Bushing Split Plastic
0.500 in.
1 904-543 Screw 8-32 x 3/4
Pan Head
2 904-553 Screw #8 x 1/2
Type "B", Black Oxide
1 910-073 Spark Generator
Battery Holder
1 910-074 Spark Generator
Switch C/W Wire
1 910-078 Battery Size AA
Energizer En91
2 910-199 Clip Wire Holder
1 910-903 Wire Fan To Power
Cord, Ground 30 in.
904-781 Velcro Hook, Black
904-782 Velcro Hook, Black
Note: Use a magnetic type screwdriver
if possible.
9) Remove the black
protection cap by hand
from the high-low knob
(Fig.1).
10) Insert a 5/32” or 4mm Allen wrench into
the hexagonal key-way of the screw
(Fig. 2), rotate it counter-clockwise until
it is free and extract it.
11) Check that the screw is clean and if
necessary remove dirt.
12) Flip the screw (Fig. 3).
13) Using the Allen wrench as shown in
Fig.4, rotate the screw clockwise until
snug, do not overtighten.
Fig.4
Installation of LPG
Conversion Kit:
4) Open pedestal door and remove the
gold chain from door which will allow
door to fall.
5) Remove lighting panel by removing the
6 Phillips head screws and put to the
side.
6) Remove hi-low extension knob.
3) Remove burner. See diagram below.
Fig.1
Fig.2
Fig.3
8) Pull off the Hi/Lo gas extension knob to
access the orifice.
7) Turn control knob to the “OFF” position.

Regency®U38-1 ULTIMATE Freestanding Gas Stove 13
INSTALLATION
16) Pull off the pilot cap to expose the pilot
orifice.
17) Unscrew the pilot orifice with the allen
key and replace with the LPG pilot
orifice in the kit.
19) Reinstall new burner orifice LPG
stamped #50 and tighten.
20) Reverse steps 3) to 2).
21) Attach the label "This unit has been
converted to LPG" near or on top of the
Serial # decal.
22) Replace yellow "NG" label with red
"LPG" label.
15) Re-assemble the black protection cap
(Fig. 6).
WARNING!
Also check that the pilot
and main burner injectors are
appropriate for the gas type. Installation of the DC Sparker:
1) Remove the back pedestal cover by
unscrewing the 4 screws.
2) Remove the front control panel by
unscrewing the 6 screws.
4) Plug up the Piezo Ignitor mounting hole
with the plastic plug.
Fig.6
Burner Orifice
18) Remove burner orifice with a 1/2"
wrench while using a 9/16" wrench to
hold onto the elbow behind the orifice,
then discard the orifice.
WARNING!
Do not over tighten the screw.
Recommended to grip the
wrench by the short side.
14) Verify that if the conversion is from
NG to LPG, the screw must be re-
assembled with the red o-ring visible
(Fig. 5).
LPG Configuration
Red o-ring visible
Fig.5
3) Unplug the Piezo Ignitor wire and
remove Piezo Ignitor from the control
panel.
5) Connect the DC spark generator wires
to the SIT Valve with the screw, which is
provided in the kit.
ONLY REQUIRED FOR THE U38

14 Regency®U38-1 ULTIMATE Freestanding Gas Stove
INSTALLATION
7) Reversing step 2 and secure the control
panel back onto the stove pedestal with
the screws.
9) The Ground Wire, DC Sparker Ignition
Wire and Piezo Spark Wire all go
through the hole located on the pedestal
back cover.
10) Put on the plastic split bushing.
11) Attach the Piezo Ignition Wire to the
back of the DC Sparker box.
14) Connect the DC Sparker Ignition Wire to
the DC Sparker.
12) The ground wire and DC Sparker
ignition go through the hole on the heat
shield.
18) We recommend mounting the DC Sparker
box onto the pedestal back cover.
19) Check for gas leaks.
20) Check inlet and outlet pressures.
21) Check operation of flame control.
22) Check for proper flame appearance and glow
on logs.
6) Secure with screw.
8) Attach one end of the green ground wire
to the grounding stud on the inside of
the pedestal. 13) Apply the plastic bushing to the heat
shield hole.
15) Attach the green ground wire.
17) Place the heat shield over the DC Sparker.
green ground wire
16) Install the supplied battery into the DC Sparker
Box by opening the battery compartment.
NOTE: The battery in the DC Sparker Box will
need to be replaced annually.
Battery
Compartment

Regency®U38-1 ULTIMATE Freestanding Gas Stove 15
INSTALLATION
CONVERSION TO LOWER BTU RATING
THIS CONVERSION MUST BE DONE BY A QUALIFIED GAS FITTER IF IN DOUBT DO NOT DO THIS CONVERSION!
Natural Gas Conversion Kit 730-920
Contains:
Qty. Part # Description
1 904-240 Burner Orifice #37 (NG)
1 918-034 Decal "Converted to 30,000 Btu"
1 918-033 Instruction Sheet
Propane Conversion Kit 730-922
Contains:
Qty. Part # Description
1 904-390 Burner Orifice #52 (Propane)
1 918-034 Decal "Converted to 30,000 Btu"
1 918-033 Instruction Sheet
1) Shut off the gas supply.
2) Open the front door. Carefully remove the
logs and lava rock.
3) Remove burner. See diagram below.
Burner Orifice
Note: Use a
magnetic type
screwdriver if possible.
Move Rear Log
Pins forward to
front holes.
Vent Restrictor setting at High 40,000 Btu/h
Vent Restrictor setting at Low 30,000 Btu/h
4) Unscrew the 2 Rear Log Pins and move to
the front hole position.
5) Remove Rear Log Bracket and slide the
Log Bracket Restrictor between the Rear
Log Bracket and the burner, secure with
the 2 screws.
7) Reinstall new burner orifice (NG stamped
#37 or LP stamped #52) and tighten.
8) Reverse steps 3) and 2).
9) AdjustVentrestrictor setting:Tosetthe Vent
restrictionasindicatedinthediagram,simply
loosenthe screwsandpushthe ventrestric-
tor plate to the correct position. Tighten the
screws.
Unit Btu/h Restrictor Opening
U38-1 40,000 A 1-3/8" (35mm)
U38-1 30,000 B 1-1/8" (29mm)
6) Remove burner orifice with a 1/2" wrench
and discard.
10) Attach the label "This unit has been con-
vertedto..."on top of the Serial # decal over
the higher Btu information.
11) Check for gas leaks.
12) Check inlet and outlet pressures.
13) Check operation of flame control. Check
for proper flame appearance and glow on
logs.

16 Regency®U38-1 ULTIMATE Freestanding Gas Stove
INSTALLATION
LOG SET INSTALLATION
Embers Embers
The "02" refer numbers (i.e. 02-65) are
molded into the rear of each log.
Note: Install Optional Brick Panels prior to
installing logs.
1) Carefully remove the logs from the box and unwrap
them. The logs are fragile, handle with care - do
not force into position.
Pins on Rear Log Support
A)02-65
B)02-56
3) Place Rear Log A)02-65 on the two pins on the rear
log support.
4) Place the Middle Left Log B)02-56 on the two pins
as shown.
Read the instructions below carefully and refer to
the diagrams. If logs are broken do not use the unit
until they are replaced. Broken logs can interfere
with the pilot operation.
The gas log kit contains the following:
a) 02-65 Rear Log
b) 02-56 Middle Left Log
c) 02-44 Front Left Log
d) 02-46 Left Top Log
e) 02-45 Front Right Log
f) 02-47 Center Log
g) 02-48 Middle Right Log
h) 902-151 Embers
i) 902-154 Lava
j) 946-669 Platinum Embers
(supplied w/packaged manual)
2) Sprinkle the embers on the left and right sides of the
firebox base.

Regency®U38-1 ULTIMATE Freestanding Gas Stove 17
INSTALLATION
Cutout
Pin
D)02-46
B)02-56
A)02-65
7) Place the Left Top Log D)02-46 on the pin on Log
B)02-56 and on top of the cutout on Log A)02-65.
E)02-45
C)02-44
8) Place Front Right Log E)02-45 on the two pins as
shown.
9) Place the lava rock in the area between the left and
right logs, leaving a space in the middle for
log (F) 02-47.
C)02-44
5) Sprinkle some lava rock just in front of B)
02-56 on the burner holes.
Lava Rock
B)02-56
6) Place Front Left Log C)02-44 onto the 2 front pins
as shown.
10) Separate platinum embers and place around the
lava rock on the burner. Avoid stacking platinum
embers.

18 Regency®U38-1 ULTIMATE Freestanding Gas Stove
INSTALLATION
Cutout
Notch
F)02-47
E)02-45
A)02-65
11) Place the notch in Center Log F)02-47 over
Log E)02-45 and across the cutout on Log A)02-
65.
Notch
E)02-45
Bracket
A)02-65
The bottom right edge of Log G)02-48
must sit snugly against the bracket
Side
View
G)02-48
E)02-45
F)02-47
12) Position notch in Front Right Log G)02-48 on Log
F)02-47 and push the bottom right edge against the
bracket on the burner tray.
G)02-48
13) Test fire to ensure proper light off (make sure flame
flows smoothly from one end of burner to the other.
If there is any flame hesitation, check that area for
any blockage of the burner port.
F)02-47
E)02-45
A)02-65
G)02-48
D)02-46
B)02-56
C)02-44

Regency®U38-1 ULTIMATE Freestanding Gas Stove 19
INSTALLATION
The thermally activated safety switch must
be manually reset before first startup.
Note: If the flue is blocked or has a strong
reverse flow, the thermally actuated safety
switch mounted in the draft hood will auto-
maticallyshutoffthegassupplywithinabout
10 minutes. If the heater turns off because
ofthis during thespillage test, checkfor the
cause of the lack of draft.
TEST FOR FLUE
SPILLAGE
A "spillage" test must be made before the
installed unit is left with the customer. Follow
the procedure below:
1) Start all exhaust fans in the home and any
other gas appliances. Then close all doors
and windows.
2) Light the unit and set controls to maxi-
mum.
3) After five minutes, test that there is a "pull"
on the flue by placing a smoke match,
cigarette or similar device which gives off
smoke, on the edge of the draft hood. See
diagrams.
LOUVER
INSTALLATION
1) Attach the top & bottom louvers to the side
stove panel using 2 screws per side.
Diagram 1
FRONT DOOR
INSTALLATION
(packaged separately)
1) Open the two side panels.
4) Thelatchesshouldalreadybeattheproper
setting. If they are too hard or too easy
to close, you may want to adjust them by
loosening the latch catch. See diagram 3.
Diagram 2
Diagram 3
5) Removetheblueplasticprotectivecoating
from the glass.
6) Test the seal around the door by placing
a piece of paper between the unit and the
door,closethedoorandtrytopullthepaper
out. If it slips out easily, then the door is
not properly sealed. Tighten or loosen the
latch. See diagram 3.
2) Slide the door
ontothetwohinge
pins making sure
the two pieces
areflushtogether.
See diagram 1.
3) Close the door.
The latch plate
must be cen-
tered around the
alignment pin. See
diagram 2. If the latch
plateinterfereswiththe
corner of the stove you
may want to angle the
plateslightlysothedoor
closes easier.
Note: The door latch may require adjust-
ment as the door gasket material
compresses after a few fires and
after glass replacement. Turn the
latch catch inward or outward to
loosen or tighten.
The smoke should be drawn into the draft
hood. If the smoke is not drawn into the draft
hood, turn the unit off and check for the cause
of lack of draft.
.

20 Regency®U38-1 ULTIMATE Freestanding Gas Stove
INSTALLATION
OPTIONAL
REMOTE CONTROL
Use the Regency®Remote Control Kit ap-
proved for this unit. Use of other systems may
void your warranty.
The remote control kit comes with a hand held
transmitter, a receiver and a wall mounting
plate.
Thermostat Wire Table
FINAL CHECK
Before leaving this unit with the customer, the
installer must ensure that the appliance is firing
correctly. This includes:
1) Clocking the appliance to ensure the correct
firing rate (rate noted on label) at 15 minutes.
2) If required, adjusting the primary air to ensure
that the flame does not carbon. First allow the
unit to burn for 15 min. to stabilize.
3) Check for proper draft.
CAUTION
Any alteration to the product that
causes sooting or carboning that
results in damage to the exterior
facia is not the responsibility of the
manufacturer.
1) Choose a convenient location on the wall
to install the receiver and the receptacle
box (protection from extreme heat is very
important). Run wires from the fireplace to
that location, use Thermostat Wire Table.
2) Connectthewiresasperthewiringdiagram
above.
CAUTION
Do not connect the millivolt re-
mote control wires to
the 120V wires.
3) Install3AAAalkalinebatteriesintransmitter
and 4 AA alkaline batteries in the receiver.
Install the receiver and its cover in the wall.
Switch the remote receiver to "remote"
mode. The remote control is now ready for
operation.
OPTIONAL
WALL THERMOSTAT
A wall thermostat may be installed if desired.
Connect the wires as per the wiring diagrams.
Note that the wires are connected to the "TH"
on the gas valve. Use table below to determine
the maximum wire length:
Note:Preferableifthethermostatisinstalled
on an interior wall.
Regency®offers an optional programmable
thermostat but any 250-750 millivolt rated non-
anticipator type thermostat that is CSA, ULC or
UL approved may be used.
CAUTION
Do not connect the millivolt
wall thermostat wires
to the 120V wires.
14 GA.
16 GA.
18 GA.
20 GA.
22 GA.
50 Ft.
32 Ft.
20 Ft.
12 Ft.
9 Ft.
Recommended Maximum Lead Length
(Two-Wire) When Using Wall
Thermostat (CP-2 System)
Wire Size Max. Length
