Regency FIREGENIE FG37-LPG Quick start guide

05/26/06
Freestanding Gas Stove
FOR YOUR SAFETY
What to do if you smell gas:
Do not try to light any appli-
an e
Do not tou h any ele tri al
swit h: do not use any
phone in your building.
Immediately all your gas
supplier from a neighbour's
phone. Follow the gas sup-
plier's instru tions.
If you annot rea h your
gas supplier, all the fire
department.
WARNING:
Improper installation, adjustment, altera-
tion, servi e or maintenan e an ause
injury or property damage. Refer to this
manual. For assistan e or additional infor-
mation onsult an authorized installer, serv-
i e agen y or the gas supplier.
FOR YOUR SAFETY
Do not store or use gasoline or other flamma-
ble vapours and liquids in the vi inity of this
or any other applian e.
Installation and servi e must be performed
by an authorized installer, servi e agen y or
the gas supplier.
PLEASE KEEP THESE INSTRUCTIONS
FOR FUTURE REFERENCE
Owners &
Installation
Manual
LISTINGS AND CODE APPROVALS
These gas appliances have een tested
in accordance with AS4553-2000, NZS
5262 and have een certified y the
Australian Gas Association for
installation and operation as descri ed
in these Installation and Operating
Instructions.
Your unit should be serviced
annually by an authorised service
person.
918-318a
Models: FG37-NG
FG37-LPG

2FG37 Regency Rear Flued Room Sealed Freestanding Gas Heater
To the New Owner:
Congratulations! You are the owner of a state-of-the-art Regency Rear Flued Room Sealed Freestanding Gas Stove by FPI
Fire lace Products International. The Regency Gas Series of hand crafted a liances has been designed to rovide you
with all the warmth and charm of a woodstove, at the flick of a switch. The models FG37-NG, and F37-LPG of this series
has been a roved by Warnock Hersey for both safety and efficiency. As it also bears our own mark, it romises to rovide
you with economy, comfort and security for many trouble free years to follow. Please take a moment now to acquaint
yourself with these instructions and the many features of your Regency Rear Flued Room Sealed Freestanding Gas Stove.

FG37 Regency Rear Flued Room Sealed Freestanding Gas Heater 3
TABLE OF CONTENTS
Page Page
Operating Instru tions
O erating Instructions ............................................... 19
Lighting Procedure .................................................... 19
Resetting the Unit ..................................................... 19
Shutdown Procedure ................................................. 19
First Fire ................................................................... 19
Fan O eration ........................................................... 19
Adjusting Flame Heights ........................................... 19
Normal O erating Sounds of Gas A liances ............ 20
Summary of Controls ................................................ 20
Pilot Adjustment ....................................................... 20
Co y of Lighting Plate Instructions ............................ 21
Maintenan e
Maintenance Instructions .......................................... 22
Gold Plated Doors ..................................................... 22
Latch Adjustment ...................................................... 23
Log Re lacement ...................................................... 23
Glass Re lacement ................................................... 23
Fan Maintenance ...................................................... 24
Removing Valve ......................................................... 25
Parts List
Electronic Com onents List ...................................... 26
Re lacement Parts List ............................................. 27
Warranty
Warranty ................................................................... 31
S ecifications diagram ................................................ 2
Data Plate ................................................................... 4
Installation
S ecifications ............................................................. 5
Before You Start ......................................................... 5
General Safety Information .......................................... 5
Installation Checklist ................................................... 6
Clearances to Combustibles ....................................... 6
Locating Your REGENCY Gas Stove .......................... 6
Combustion and Ventilation Air ................................... 6
Exterior Flue Terminal Locations ................................. 7
Fluing Installation Precautions..................................... 8
Safety Precautions for the Installer .............................. 8
Planning Your Fluing Installation ................................. 8
Fluing Arrangements - Vertical Terminations ............... 9
Flue Restrictor Position ............................................... 9
Fluing: Residential and Manufactured
Homes/Mobile Homes Installation ....................... 10
Horizontal Installations .............................................. 10
Vertical Termination with Co-linear Flex System ....... 12
Gas Connection ........................................................ 12
System Data Chart - FG37 ........................................ 12
Conversion from NG to LPG ...................................... 13
Aeration Adjustment.................................................. 15
Log Installation .......................................................... 15
Door Installation ........................................................ 16
Gas Pi e Pressure Testing ....................................... 17
Valve Descri tion ...................................................... 17
Louvre Installation ...................................................... 17
O tional Remote Control Installation ......................... 18
Final Check ............................................................... 18
Wiring Diagram ......................................................... 18

4FG37 Regency Rear Flued Room Sealed Freestanding Gas Heater
This is a copy of the la el that accompanies
each REGENCY Rear Flued Room Sealed Free-
standing Gas Stove. We have printed a copy of
DATA PLATE
the contents here for your review. The data
plate is located on the inside of the drop down
pedestal door.
NOTE: Regency units are constantly eing
improved. Check the la el on the unit and if there
is a difference, the la el on the unit is the correct
one.
(Australia Only)

FG37 Regency Rear Flued Room Sealed Freestanding Gas Heater 5
INSTALLATION AND REPAIRS
SHOULD BE DONE BY AN AUTHOR-
IZED SERVICE PERSON. THIS AP-
PLIANCE SHOULD BE INSTALLED,
REPAIRED, INSPECTED BEFORE
USE AND AT LEAST ANNUALLY
BY AN AUTHORIZED SERVICE PER-
SON. MORE FREQUENT CLEAN-
ING MAY BE REQUIRED DUE TO
EXCESSIVE LINT FROM CARPET-
ING, ETC. IT IS IMPERATIVE THAT
THE CONTROL COMPARTMENT,
BURNERS AND CIRCULATING AIR
PASSAGEWAYS OF THE APPLI-
ANCE BE KEPT CLEAN.
IMPORTANT:
SAVE THESE
INSTRUCTIONS
The REGENCY Rear Flued Room Sealed Free-
standing Gas Stove must e installed in accord-
ance AG601 and NZS 5261 and with these
instructions. Carefully read all the instructions
in this manual first. Consult the uilding authority
having jurisdiction to determine the need for a
permit prior to starting the installation.
Note: Failure to follow the instructions
could cause a malfunction of the
heater which could result in death,
serious bodily injury, and or prop-
erty damage. Failure to follow these
instructions may also void your
fire insurance and or warranty.
SPECIFICATIONS
Fuels: FG37-NG is approved for use with
NG.
FG37-LPG is approved for use with
liquefied petroleum gases (LPG).
Electrical: 240 V A.C. system.
Circulation Fan: Two Speed
Log Sets: Ceramic fi re, 7 per set.
Flue System:
Axial (6-5/8" (168mm) outer / 4"
(102mm) inner liner) rigid flue and
Riser Vent Terminal.
BEFORE YOU START
Safe installation and operation of this appliance
requires common sense, however, please e
aware of the following:
INSTALLATION
4) We recommend that you plan your installa-
tion on paper using exact measurements
for clearances and floor protection efore
actually installing this appliance. Have an
authorized uilding inspector review your
plans efore installation.
GENERAL SAFETY
INFORMATION
1) The appliance shall e installed in accord-
ance with the manufacturer's installation
instructions, local gas fitting regulations,
municipal uilding codes, water supply reg-
ulations, electrical wiring regulations, with
AS5601-2004 (AGA gas installation code)
NZS 5261 (New Zealand)
2) Installation and repair should be done
ONLY by an authorised person.
3) DO NOT CONNECT TO MASONARY FLUE.
4) This appliance must be connected to
the specified flue and termination cap
to the outside of the building enve-
lope. Never flue to another room or
inside a building. Make sure that the
flue is fitted as per Flueing instruc-
tions.
5) Inspect the flueing system annually for
lockage and any signs of deterioration.
6) Flueing terminals shall not e recessed into
a wall or siding.
7) Any safety glass removed for servicing
must e replaced prior to operating the
appliance.
8) To prevent injury, do not allow anyone who
is unfamiliar with the operation to use the
fireplace.
9) Wear gloves and safety glasses for pro-
tection while doing required maintenance.
10) Be aware of electrical wiring locations in
walls and ceilings when cutting holes for
termination.
11) Under no circumstances should this appli-
ance e modified. Parts that have to e
removed for servicing should e replaced
prior to operating this appliance.
12) Installation and any repairs to this appliance
should e done y an authorised service
person. An authorised service person
should e called to inspect this appliance
annually. Make it a practice to have all of
your gas appliances checked annually.
13) Do not slam shut or strike the glass door.
DUE TO HIGH TEMPERATURES,
THE APPLIANCE SHOULD BE LO-
CATED OUT OF TRAFFIC AND
AWAY FROM FURNITURE AND
DRAPERIES.
WARNING: FAILURE TO INSTALL
THIS APPLIANCE CORRECTLY
WILL VOID YOUR WARRANTY AND
MAY CAUSE A SERIOUS HOUSE
FIRE.
CHILDREN AND ADULTS SHOULD
BE ALERTED TO THE HAZARDS OF
HIGH SURFACE TEMPERATURES,
ESPECIALLY THE FIREPLACE
GLASS, AND SHOULD STAY AWAY
TO AVOID BURNS OR CLOTHING
IGNITION.
YOUNG CHILDREN SHOULD BE
CAREFULLY SUPERVISED WHEN
THEY ARE IN THE SAME ROOM AS
THE APPLIANCE.
CLOTHING OR OTHER FLAMMA-
BLE MATERIAL SHOULD NOT BE
PLACED ON OR NEAR THE APPLI-
ANCE.
1) Provide adequate clearances for servic-
ing, proper operation and around the air
openings into the com ustion cham er.
2) The appliance must e installed on a flat,
solid, continuous surface (e.g. wood, met-
al, concrete). This may e the floor, or it can
e raised up on a platform to enhance its
visual impact. The appliance may e in-
stalled on carpeting, tile, wood flooring or
other com usti le material, ecause the
appliance's metal pedestal ase extends
the full width and depth of the appliance.
The REGENCY Rear Flued Room Sealed
Freestanding Gas Stove can e installed in
a wide variety of ways and will fit nearly
any room layout. It may e installed in a
recessed position, framed out into the room,
or across a corner.
3) The REGENCY Rear Flued Room Sealed
Freestanding Gas Stove is approved for
manufactured home installations, see pag-
es 6 to 9 for the required flue arrangements.
If installed into a manufactured home the
unit must e olted down to the floor.

6FG37 Regency Rear Flued Room Sealed Freestanding Gas Heater
14) Under no circumstances should any solid
fuels (wood, paper, card oard, coal, etc.)
e used in this appliance.
15) The appliance area must e kept clear and
free of com usti le materials, (gases and
other flamma le vapours and liquids).
INSTALLATION
CHECKLIST
1) Check Clearances to Com usti les (page
6), location of unit (page 6) and fluing
requirements (pages 6-9).
2) Install fluing: Check all fluing requirements,
pages 8-12.
3) Make gas connections, page 12. Test the
pilot. Must e as per diagram, pages 15 &
22.
4) If necessary, convert from NG to LPG (page
13).
5) Install log set, page 15.
6) Install Front Door Front, page 16.
7) Test Gas Pressure, page 17.
8) Install Louvres, page 17.
9) Install optional Remote Control, page 18.
10) Final check, page 18.
Before leaving this unit with the customer, the
installer must ensure that the appliance is firing
correctly and operation fully explained to
customer.
This includes:
1) Clocking the appliance to ensure the cor-
rect firing rate (rate noted on la el) after
urning appliance for 15 minutes.
2) If required, adjusting the primary air to
ensure that the flame does not car on. First
allow the unit to urn for 15-20 min. to
sta ilize.
CAUTION: Any alteration to the product
that causes sooting or carboning that
results in damage is not the responsibil-
ity of the manufacturer.
LOCATING YOUR
REGENCY GAS STOVE
When selecting a location for your stove, en-
sure that the clearances listed a ove are met as
well as ensuring that there is adequate acces-
si ility for servicing and proper operation.
For Flu Termination requirements, see page 7.
This appliance is Listed for edroom installa-
tions when used with a Listed Millivolt Thermo-
stat. Some areas may have further require-
ments, check local codes efore installation.
This appliance is Listed for Alcove installations,
maintain minimum Alcove clearances as fol-
lows, minimum ceiling height of 1.7m, minimum
width of 1.0m and a maximum depth of 0.9m.
INSTALLATION
Use the minimum clearances shown in the
diagrams elow:
FG37-NG & FG37-LPG Clearances
A Side Wall to Unit 190 mm
B Back Wall to Unit 76 mm
E Side Wall to Unit 114 mm
FG37-NG & FG37-LPG
Reference Dimensions
C Floor to Flue Centerline 635 mm
D Side Wall to Flue Centerline 521 mm
A ) Cross Corner
B) Flush with Wall/Alcove
C) Flat on Wall Corner
D) Flat on Wall
CLEARANCES TO
COMBUSTIBLES
The clearances listed are MINIMUM distances.
Measure the clearance to oth the appliance
and the chimney connector. The farthest
distance is correct if the two clearances
do not coincide. For example, if the appliance
is set as indicated in one of the diagrams ut the
connector is too close, move the stove until the
correct clearance to the connector is o tained.
This appliance may e installed only with the
clearances as shown in the situations pictured.
Do not combine clearances from one type
of installation with another in order to
achieve closer clearances.
This unit can e installed on a solid com usti le
surface like a wood floor. This unit can also e
installed directly on carpeting or vinyl when the
ottom pedestal cover plate (provided with unit)
is installed.
COMBUSTION AND
VENTILATION AIR
The com ustion air from this appliance is drawn
from outside the uilding through the outer flue.
Extra provision for combustion air inside
the room is not required.
Minimum ceiling height
is 914 mm from top of
unit.

FG37 Regency Rear Flued Room Sealed Freestanding Gas Heater 7
INSTALLATION
EXTERIOR FLUE TERMINATION LOCATIONS
Minimum learan es required for balan ed flue terminals or
the flue terminals of outdoor applian es
a ording to AS5601-2004 (AGA gas installation ode) or NZS 5261 (New Zealand)
Minimum
Clearance (mm)
a Below eaves, alconies or other projections:
- Appliances up to 50 MJ/h input 300
- Appliances over 50 MJ/h input 500
From the ground or a ove a alcony 300
c From a return wall or external corner 500
d From a gas meter (M) 1000
e From an electricity meter or fuse ox (P) 500
f From a drain or soil pipe 150
g Horizontal from any uilding structure (unless appliance is approved
for closer installation) or o struction facing a terminal 500
h From any other flue terminal, cowl or com ustion air intake 500
j Horizontally from an opena le window, door, or non-mechanical air inlet, or
any other opening into a uilding, with the exception of su -floor ventilation
(see also Note (I)):
- Appliances up to 150 MJ/h input 500
- Appliances over 150 MJ/h input 1500
k Vertically elow an opena le window, door, or non-mechanical air inlet,
or any other opening into a uilding, with the exception of su -floor ventilation
(see also Note (I)): see ta le elow
Clearan e 'k' in mm
Space Heaters All Other Appliances
Up to 50 MJ/h Up to 50 MJ/h input Over 50 MJ/h input Over 150 MJ/h input
input to 150 MJ/h input
150 500 1000 1500
NOTES:
(I) For mechanical air inlets, including spa lowers, the clearance 'j' and 'k' shall e 1500 mm in all cases.
(II) All distances shall e measured vertically or horizontally along the wall to a point in line with the nearest
par to of the terminal.
(III) Prohi ited area elow electricity meter or fuse ox extends to ground level.
(IV)A flue terminal of this type shall not e located under a roofed area unless the roofed area is fully open on
at least two sides and a free flow of air at the appliance is achieved.

8FG37 Regency Rear Flued Room Sealed Freestanding Gas Heater
PLANNING YOUR FLUING INSTALLATION
INSTALLATION
FLUING
The Regency Room Sealed System (Horizontal
Termination Kit (946-110) and the Vertical Ter-
mination with the Co-linear Flex System in
com ination with the REGENCY Room Sealed-
Rear Freestanding Gas Stoves (FG37-NG and
FG37-LPG) have een approved and listed as
Room Sealed heater systems y Australian
Gas Association.
The Horiz. Termination Kit (946-110) includes
everything required for a straight through the
wall installation, or add a 45o el ow for a corner
installation.
IMPORTANT
Read all instructions carefully efore starting
the installation. Failure to follow these instruc-
tions may create a fire or other safety hazard,
and will void the warranty. Be sure to check the
fluing and clearance to com usti le require-
ments on pages 6 to 9. Consult your local
uilding codes efore eginning installation.
The location of the termination cap must con-
form to the requirements in the Exterior Flue
Terminal Locations diagram on page 7.
FLUING
INSTALLATION
PRECAUTIONS
The Regency Room Sealed System and the
Vertical Termination with the Co-linear Flex
System are engineered products that have
een designed and tested for use with the
FG37-NG, and FG37-LPG. The Regency war-
ranty will e voided and serious fire, health or
other safety hazards may result from any of the
following actions:
1) Installation of any damaged Room Sealed
component
2) Unauthorized modification of the Room
Sealed System
3) Installation of any component part not man-
ufactured or approved y Regency Indus-
tries Ltd.
4) Installation other than as instructed y Re-
gency Industries Ltd.
Warning: Always maintain required
learan es (air spa es) to nearby
ombustibles to prevent a fire haz-
ard. Do not fill air spa es with insu-
lation.
The minimum clearance requirements etween
the outer wall of the flue pipe and near y
com usti le surfaces is 30mm. Be sure to
check the flue termination clearance require-
ments from decks, windows, soffits, gas reg-
ulators, air supply inlets and pu lic walkways
as specified on page 7 and in your local uilding
codes.
The gas applian e and flue system
must be flued dire tly to the outside
of the building, and never be at-
ta hed to a himney serving a sep-
arate solid fuel or gas-burning ap-
plian e.
Each Room Sealed gas appliance must use its
own separate flue system. Common flue sys-
tems are prohi ited.
SAFETY
PRECAUTIONS FOR
THE INSTALLER
1) Wear gloves and safety glasses for pro-
tection.
2) Exercise extreme caution when using lad-
ders or on roof tops.
3) Be aware of electrical wiring locations in
walls and ceilings.
See page 7 for Exterior Flue Termination
requirements.
When planning your installation, it will e nec-
essary to select the proper length of flue pipe
for your particular requirements. Determine the
minimum clearance to com usti les from the
rear of the unit to the wall. It is also important to
note the wall thickness. Before cutting the flue
hole through the wall ensure that ALL flue and
termination clearances (see page 7) will e met.
*If this is an outside corner, the minimum distance etween the flue and the outside corner
is 12" (30cm). See "F" on the diagram on page 7.
NOTE: Ensure compliance with the outside
flue terminal location efore cutting hole as
oth dimensions must e met.
For corner installation, Restrictor must
e set at 1-1/4" (32mm) open.
For straight rear installation, Restric-
tor must e set at 1-1/8" (29mm) open.

FG37 Regency Rear Flued Room Sealed Freestanding Gas Heater 9
INSTALLATION
FLUING ARRANGEMENTS - VERTICAL TERMINATIONS
FOR BOTH RESIDENTIAL & MANUFACTURED HOMES/MOBILE HOMES
Offset to Verti al Terminations
If connecting to a Dura-Vent sys-
tem, the Adapter to Dura-Vent #
640-994 is required.
Verti al Terminations
with Co-linear Flex System
The shaded area in the diagram shows the allowable vertical
terminations installed in a masonry chimney. All vertical flue
installations require the Flue Restrictor to e set to 32mm open. All
Vertical Flue Terminals must e Simpson Dura Vent (A ey Australia)
DV 980 MAS (Australian Modified.)
Verti al Terminations
using Dura-Vent Fluing System
The shaded areas in the two diagrams below show all allowable
combinations of straight vertical and offset to vertical runs with
vertical terminations. Maximum one 90o elbow. All vertical and
offset to vertical flue installations require Flue Restrictor to e set to 32mm
open. If the flue is ENCLOSED in a chase (min. size 229mm x 229mm)
maintain a 32mm clearance to com usti les. All Vertical Flue Terminals
must e Simpson Dura Vent (A ey Australia) DV 980 MAS (Australian
Modified.)
Straight Verti al Terminations
Flue Restri tor Position
Vent Restrictor
Vent
Restrictor
Plate
Vent Restrictor
(fully open)
Vent
Restrictor
Plate
44.5mm 44.5mm 32mm 32mm
To set the Flue restriction
as indicated in the diagram,
simply loosen the screws
and push the flue restrictor
plate to the correct position.
Tighten the screws.
216mm
9.1m Max.
3.2m Min.
1
1
1
2
4
5
6
7
8
2
1
3
9
Horizontal Distance (meters)
Vertical Height (meters)

10 FG37 Regency Rear Flued Room Sealed Freestanding Gas Heater
INSTALLATION
Diagram 2
HORIZONTAL INSTALLATIONS
Diagram 1
*Dia 2: Local codes or regulations may require
different clearances.
RESIDENTIAL AND MANUFACTURED HOMES/
MOBILE HOMES INSTALLATIONS
You will require the following components with your new Regency Rear Flued Room Sealed Freestanding Gas Stove. Please review your product
to make sure you have everything you need. In the event that you are missing any part, contact your dealer.
Note: These are the minimum pieces required.
Other parts may be required for your particular installation.
Minimum components for a Horizontal Installation:
946-110 Horizontal Termination Kit which includes:
1 946-201 6-5/8" dia. x 18" (168mm dia. x 457mm) Black Pipe
1 946-207 4" dia. x 18" (102mm dia. x 457mm) Aluminum Flue
1 946-584 Astro Riser Vent Terminal
1 946-202 Wall Penetration Heat Shield for Heat Sensitive walls
(Wall Thim le) (2 pcs)
1 640-545 Decorative Wall Trim (Black)
1 948-128 Tu e Mill-Pac
Screws
Optional Components:
946-204 45o El ow - 6-5/8" (168mm) Black pipe
and 4" (102mm) Aluminum Flue
946-205 Vinyl Siding Shield for Riser Vent
Terminal
946-208/P Flue Guard
940 Square Wall Thim le Cover*
942 Wall Penetration
Heat Shield*
* Simpson Dura-Vent components
1) Set the unit in its desired location. Check to
determine if wall studs are in the way when
the fluing system is attached. If this is the
case, you may want to adjust the location
of the unit.
2) Assem le the desired com ination of pipe
and el ow to the appliance adapter with
pipe seams oriented down. Offset the pipe
seams as dou le seams in one place will
cause the outer pipe to take an oval shape.
Kit comes complete with 18" (457mm) of
straight flue - 6-5/8" (168mm) dia. lack
outer pipe and 4" (102mm) dia. inner flue.
3) With the pipe attached to the stove, slide the
stove into its correct location, and mark the
wall for a 9-1/2" (241mm) (inside dimen-
sions) round hole. The center of the round
hole should line up with the centerline of the
horizontal pipe, as shown in diagram 1. Cut
and frame the 9-1/2 (241mm) round hole in
the exterior wall where the flue will e
terminated. If the wall eing penetrated is
constructed of non-com usti le material,
i.e. masonry lock or concrete, a 7" (178mm)
diameter hole is accepta le.
Note:
a) The horizontal run of flue should have
a 1/4 inch (6mm) rise for every 1 foot
(305mm) of run towards the termina-
tion. Never allow the flue to run down-
ward. This could cause high tempera-
tures and may present the possi ility of
a fire.
b) The location of the horizontal flue termi-
nation on an exterior wall must meet all
local and national uilding codes, and
must not e locked or o structed. For
External Flue Terminal Locations, see
diagram on page 7.
c) Snorkel Terminations:
For installations requiring a vertical rise
on the exterior of the uilding, Astro
Riser Vent Terminations as shown in
Dia. 2 is availa le. Follow the same
installation procedures as used for
standard Horizontal Termination.
NEVER install the Astro Riser vent up-
side down.

FG37 Regency Rear Flued Room Sealed Freestanding Gas Heater 11
Diagram 5
Diagram 4
Below Grade Snorkel Installation
If the Snorkel Termination must e installed
elow grade, i.e. asement application,
proper drainage must e provided to pre-
vent water from entering the Snorkel Ter-
mination. Refer to Dura-Vent Installation
instructions for details.. Do not attempt to
enclose the Snorkel within the wall, or any
other type of enclosure.
4) Install wall penetration heat shield in the center
of the 9-1/2" (241mm) round hole and attach
with wood screws. The four wood screws
provided should e replaced with appropriate
fasteners for stucco, rick, concrete, or other
types of sidings. Dia. 3.
NOTE: For Snorkel terminations in ABOVE
grade installations, follow national or
local code requirements.
Diagram 3
5) If installing termination on a siding covered
wall, a vinyl siding standoff or furring strips
must e used to ensure that the termination is
not recessed into the siding. Dia. 3.
6) Take the Riser Vent terminal and separate the
Backing Plate from the Riser Vent Front y
removing 8 screws as shown in diagram 4.
7) Install the Backing Plate into the wall
penetration heat shield and attach us-
ing 4 screws. Dia. 4.
8) Connect all pipe sections to unit and
install into wall:
a) Measure pipe length required and
cut to length. Hint: use the cut end
of the 6-5/8" (168mm) dia. outer
pipe at the flue terminal end.
b) Push the pipe sections completely
together, the minimum pipe overlap
is 1-1/4" (32mm). Secure all outer
pipe joints y using at least two
screws. Locate the screws at the
ottom of the pipe so that the screw
heads are hidden on the final instal-
lation. Apply sealant "Mill-Pac" to
inner pipe and high temp silicone
sealant or "Mill-Pac" to outer pipe on
every joint.
Hint: Apply sealant to female end.
c) Before connecting the flue pipe to
the flue termination, slide the lack
decorative wall thim le cover over
the flue pipe, then slide the Wall
Penetration Heat Shield (Part # 946-
202) over the flue pipe. Dia. 3.
d) Slide the appliance and flue assem-
ly towards the wall carefully in-
serting the flue pipe into the riser
vent terminal assem ly. It is impor-
tant that the flue pipe extends into
the Riser Vent Backing Plate a suf-
ficient distance so as to result in a
minimum pipe overlap of
1-1/4 inches (32mm). Secure the
connection etween the flue pipe
and the flue cap y attaching the
two sheet metal strips extending
from the Riser Vent Backing Plate
into the outer wall of the flue pipe.
Use two aluminum screws provid-
ed to connect the strips to the pipe
section. Bend any remaining por-
tion of the sheet metal strip ack
towards the flue cap and cut off
any excess, it will e concealed y
the decorative wall thim le cover.
See diagram 5.
8) Slide the decorative wall thim le up to the
wall surface eing careful not to scratch
the paint. See diagram 5.
9) Back outside: Apply sealant to the 4" (102mm)
inner flue and slide the Riser Vent Front into
the Backing Plate and fasten with 8 screws.
IMPORTANT:
When connecting the pipe to the Riser
Vent, apply Mill-Pac to the inner pipe
on the Riser Vent Terminal, around
the bead. Ensure that the flue pipe is
pushed past the bead for a secure fit.
INSTALLATION
10) Seal around the outer edge of the Riser
Vent Backing Plate.

12 FG37 Regency Rear Flued Room Sealed Freestanding Gas Heater
System Data - FG37
Burner Inlet Orifice Sizes:
NG #37
LPG #52
Max. Input Rating 31.7 mj
Min. Input Rating 16 mj
Supply Pressure
NG min. 1.13 kPa
LPG min. 2.75 kPa
Manifold Pressure
NG .89 kPa
LPG 2.55 kPa
GAS CONNECTION
The gas connection is a 1/2" (13mm) NPT Male
Thread. Copper can e used or other con-
nections approved y AG 604.
When using copper or flex connectors use
only approved fittings. Always provide a union
so that gas lines can e easily disconnected for
urner and/or valve servicing. Flare nuts for
copper lines are usually considered to meet
this requirement.
Important: Always check for gas leaks
with a soap and water solution or gas
leak detector. Do not use open flame for
leak testing.
Note: Prior to any pressure testing of
the gas supply piping system that
exceeds test pressures of 3.45
kPa, this appliance must be dis-
connected from the piping sys-
tem. f test pressures equal to or
less than 3.45 kPa are used then
this appliance must be isolated
from the piping system by clos-
ing its individual manual shut-off
valve during the testing.
VERTICAL TERMINATION WITH
CO-LINEAR FLEX SYSTEM
THE APPLIANCE MUST NOT BE CONNECTED TO A CHIMNEY FLUE SERVING
A SEPARATE SOLID FUEL BURNING APPLIANCE.
This appliance is designed to e attached to two 3" (76mm) co-linear aluminium flex running the
full length of the chimney. See the Fluing Arrangements chart on page 9 for minimum and maximum
flue lengths. See chart elow for minimum distances from roof. Periodically check that the flue
is unrestricted.
Masonry chimneys may take various contours which the flexi le liner will accommodate.
However, keep the flexible liner as straight as possible, avoid unnecessary ending.
The Air Intake pipe must e attached to the inlet air collar of the termination cap.
Required Parts:
Part # Description
946-529 Co-linear DV Vertical Termination Cap
948-305 3" Flex - 35 ft.
640-994 FG37 Dura-Vent Adapter
946-563 Co-Axial to Co-Linear Adapter Kit
which contains the following:
Co-linear Flex Adapter (270-585)
Outer Pipe (946-257)
Inner Pipe Adapter (946-219)
Approved Caps
980 Vertical Termination Cap
923GK 3" (76mm) Co-linear Adapter
with flashing
923GK 3" (76mm) Co-linear Adapter
with flashing
INSTALLATION

FG37 Regency Rear Flued Room Sealed Freestanding Gas Heater 13
INSTALLATION
Conversion Kit for NG to LPG Model #516-969
TH S CONVERS ON MUST BE DONE BY A QUAL F ED GAS F TTER F N DOUBT DO NOT DO TH S CONVERS ON !!
Burner Orifice
Conversion Kit 516-969 Contains:
Qty. Part # Description
1 904-390 Burner Orifice #52
1 908-528 Red "LPG" la el
2 918-590 La el "Converted to LPG"
1 918-334 Instruction Sheet
1 910-920 Pilot Orifice
1) Shut off the gas supply and unplug the
power cord.
2) Open the front door and carefully remove
the logs and lava rock.
3) Remove urner.
4) Remove urner orifice with a 1/2" (13mm)
wrench and discard. Use a wrench to hold
on to the el ow ehind the orifice.
5) Reinstall new urner orifice LPG stamped
#52 and tighten.
18) Stick the conversion la el "This unit has
een converted to LPG" on the control ox
cover.
19) Reverse steps 16, 15 & 12.
Jumper Location
Jumper
8) Remove the NG orifice and replace it with
the LPG orifice.
9) Install the pilot tu e to the pilot assem ly.
10) Place the pilot assem ly over the pilot extru-
sion tu e and secure it with 2 screws.
11) Adjust the urner areation setting to fully
open and install the urner.
12) Remove the pedestal ack cover y remov-
ing the 4 Philips screws.
Pilot Tube
7) Lift the pilot assem ly and remove the pilot
tu e using an 11mm wrench.
6) Remove the 2 screws which hold the pilot.
Pilot
Orifice
Pilot
Assembly
Pilot
xtrusion
Tube
13) Stick the conversion la el "This unit has
een converted to LPG" over top of the
serial num er decal.
14) Replace the yellow "NG" la el with the red
"LPG" la el.
15) Carefully pull out the control ox.
Note: The control ox is held in place y
velcro.
16) Remove the control ox cover y undoing
the 3 screws. Maneuver through antenna.
Control Box
Cover
Antenna
17) Remove the jumper using a plier.
20) Open the ottom door and remove the front
panel y undoing the 6 screws.

14 FG37 Regency Rear Flued Room Sealed Freestanding Gas Heater
Installer Noti e:
These instru tions must be left with
the applian e.
Minimum pressure: Remove one of the
ca les connected to the electric modulator.
Keeping the nut (B) locked, screw in the
screw (C) to increase the pressure and
screw it out to decrease it. Use a screw-
driver 6 x 1 lade.
NOTE: The outlet pressure must e set to
minimum 0.74 kPa.
After carrying out all adjustments, lock
the setting screws with paint, taking care
not to o struct the reather orifice of the
pressure.
Put ack the modulator plastic cap.
WARNING: To ensure the correct opera-
tion of the modulator it is necessary that the
plastic cap (A) is returned to its original
location.
23) At the end of all setting and adjustment
operations, check electrical insulation and
gas leaks.
24) Reverse step 20.
25) Check operation of fan and flame control.
26) Check for proper flame appearance and
glow on logs.
Cable
lectric
Modulator
22) Adjusting the Outlet Pressure
All the adjustments must e carried out
in the following order:
Remove the modulator plastic cap (A) using
needle nose pliers.
Maximum pressure: Turn the unit ON to its
highest input rating. Screw in the nut (B) to
increase the outlet pressure and screw it
out to decrease it. Use a 10 mm wrench.
NOTE: The outlet pressure must e set to
maximum 2.65 kPa.
21) Turn on the gas supply and plug in the
power cord.
C
B
A
INSTALLATION

FG37 Regency Rear Flued Room Sealed Freestanding Gas Heater 15
INSTALLATION
C)02-44
AERATION
ADJUSTMENT
The urner aeration is factory set ut may need
adjusting due to either the local gas supply, air
supply or altitude.
NG: 10mm open
LPG: 10mm open
The aeration adjustment gears are located on
the right side of the urner ox and can e
accessed from the side or from the front when
the louvres are removed.
To adjust the aeration: use the allen key to turn
the turning gear which will adjust the air shut-
ter. Open the air shutter for a lue flame or close
it for a yellower flame. This adjustment is
performed y an authorized installer. The fac-
tory setting should e sufficient for most instal-
lations.
Clockwise to open,
counter-clockwise to close.
Caution: Carbon will be produced if the air
shutter is closed too much.
Note: Any damage due to carboning re-
sulting from improperly setting
the aeration controls is NOT cov-
ered under warranty.
LOG SET
INSTALLATION
Read the instructions below carefully
and refer to the diagrams. If logs are
broken do not use the unit until they are
replaced. Broken logs can interfere with
the pilot operation.
The gas log kit contains the following:
a) 02-65 Rear Log
b) 02-56 Middle Left Log
c) 02-44 Front Left Log
d) 02-46 Left Top Log
e) 02-45 Front Right Log
f) 02-47 Center Log
g) 02-48 Middle Right Log
h) Em ers
i) Lava
Note: Install Optional Brick Panels prior
to installing logs.
mbers mbers
The "02" refer numbers (i.e. 02-65) are
molded into the rear of each log.
1) Carefully remove the logs from the ox and
unwrap them. The logs are fragile, handle
with care - do not force into position.
2) Sprinkle the em ers on the left and right
sides of the fire ox ase.
Pins on Rear Log Support
A)02-65
B)02-56
3) Place Rear Log A)02-65 on the two pins on
the rear log support.
4) Place the Middle Left Log B)02-56 on the
two pins as shown.
5) Sprinkle some lava rock just in front of B)
02-56 on the urner holes.
lava rock
B)02-56
6) Place Front Left Log C)02-44 onto the 2
front pins as shown.

16 FG37 Regency Rear Flued Room Sealed Freestanding Gas Heater
Diagram 2
Diagram 3
4) The latches should already e at the
proper setting. If they are too hard or too
easy to close, you may want to adjust
them y loosening the locking nut and
turning the latch catch. See diagram 3.
5) Remove the lue plastic protective coat-
ing from the glass.
6) Test the seal around the door y placing
a piece of paper etween the unit and the
door, close the door and try to pull the
paper out. If it slips out easily, then the
door is not properly sealed. Tighten or
loosen the latch y turning the latch catch
inward or outward. See diagram 3.
Note: The door latch may require ad-
justment as the door gasket ma-
terial compresses after a few
fires and after glass replace-
ment. Turn the latch catch in-
ward or outward.
Diagram 1
DOOR INSTALLATION
(P ck ged Sep r tely)
1) Open the two side panels.
2) Slide the door
onto the two
hinge pins mak-
ing sure the
two pieces are
flush together.
See diagram
Cutout
Pin Notch
)02-46
B)02-56
A)02-65
E)02-45
Bracket
A)02-65
The bottom right edge of Log G)02-48 must
sit snugly against the bracket
Side View
G)02-48
E)02-45
F)02-47
1.
3) Close the door. The
latch plate must e
centered around the
alignment pin. See dia-
gram 2. If the latch plate
interferes with the cor-
ner of the stove you may
want to angle the plate
slightly so the door clos-
es easier.
7) Place the Left Top Log D)02-46 on the pin
on Log B)02-56 and on top of the cutout on
Log A)02-65.
E)02-45
C)02-44
8) Place Front Right Log E)02-45 on the two
pins as shown.
9) Place the lava rock in the area etween the
left and right logs, leaving a space in the
middle for log (F) 02-47.
CutoutNotch
F)02-47
E)02-45
10) Place the notch in Center Log F)02-47 over
Log E)02-45 and across the cutout on Log
A)02-65.
11) Position notch in Front Right Log G)02-48 on
Log F)02-47 and push the ottom right edge
against the racket on the urner tray.
G)02-48
12) Test fire to ensure proper light off (make sure
flame flows smoothly from one end of urner
to the other. If there is any flame hesitation,
check that area for any lockage of the urner
port.
F)02-47
E)02-45
A)02-65
G)02-48
)02-46
B)02-56
C)02-44
INSTALLATION

FG37 Regency Rear Flued Room Sealed Freestanding Gas Heater 17
INSTALLATION
LOUVRE
INSTALLATION
Attach the top & ottom louvres to the side stove
panel using 2 screws per side.
GAS PIPE PRESSURE
TESTING
The appliance must e isolated from the gas
supply piping system y closing its individual
manual shut-off valve during any pressure
testing of the gas supply piping system at test
pressures equal to or less than 1/2 psig. (3.45
kPa). Disconnect piping from valve at pres-
sures over 3.45 kPa.
The manifold pressure is controlled y a regu-
lator uilt into the gas control, and should e
checked at the pressure test point.
Note: To properly check gas pressure,
both inlet and manifold pressures
should be checked using the valve
pressure ports on the valve.
1) Make sure the valve is in the "OFF" position.
2) Loosen the "IN" and/or "OUT" pressure
tap(s), turning counterclockwise with a 1/
8" wide flat screwdriver.
3) Attach manometer to "IN" and/or "OUT"
pressure tap(s) using a 5/16" (8mm) ID
hose.
4) Light the pilot and turn the valve to "ON"
position. Read manometer.
5) The pressure check should e carried out
with the unit urning and the setting should
e within the limits specified on the safety
la el.
6) When finished reading manometer, turn off
the gas valve, disconnect the hose and
tighten the screw (clockwise) with a 1/8"
flat screwdriver. Note: Screw should be
snug, but do not over tighten
S.I.T. Valve Des ription
1) On-Off Solenoid Valve EV1
2) On-Off Solenoid Valve EV2
3) Inlet Pressure Test Point
4) Outlet Pressure Test Point
5) Connection for Pressure Regulator/Com-
ustion Cham er Compensation
6) Pressure Regulator for Minimum and Max-
imum Outlet Pressure
7) Gas Outlet Pressure Electric Modulator
8) Pilot Outlet
9) Main Gas Outlet
10) Side Outlet

18 FG37 Regency Rear Flued Room Sealed Freestanding Gas Heater
FINAL CHECK
Before leaving this unit with the customer, the
installer must ensure that the appliance is firing
correctly. This includes:
1) Clocking the appliance to ensure the cor-
rect firing rate (rate noted on la el) at 15
minutes.
2) If required, adjusting the primary air to
ensure that the flame does not car on. First
allow the unit to urn for 15 min. to sta ilize.
CAUTION
Any alteration to the product that causes
sooting or carboning that results in dam-
age to the exterior facia is not the respon-
sibility of the manufacturer.
INSTALLATION
WIRING
CAUTION: Label all wires prior to
dis onne tion when servi ing on-
trols. Wiring errors an ause im-
proper and dangerous operation.
WARN NG: Electrical Grounding nstructions
This appliance is equipped with a three pronged (grounding) plug for your protection against shock hazard and should be
plugged directly into a properly grounded three-prong receptacle. Do not cut or remove the grounding prong from this plug.
This heater does not require a 240V A.C. supply
for the gas control to operate. A 240V A.C.
power supply is needed for the fan/ lower
operation.
Caution: Ensure that the wires do
not tou h any hot surfa es and are
away from sharp edges.
OPTIONAL
REMOTE CONTROL
Use the Regency Remote Control Kit approved for
this unit. Use of other systems may void your
warranty.
The remote control kit comes with a hand held
transmitter and a wall mounting plate.
1) Choose a convenient location to mount the
hand held transmitter, protection from extreme
heat is very important.
The remote can also e used as a wall thermostat.

FG37 Regency Rear Flued Room Sealed Freestanding Gas Heater 19
OPERATING INSTRUCTIONS
FIRST FIRE
The FIRST FIRE in your heater is part of the paint
curing process. To ensure that the paint is
properly cured, it is recommended that you
urn your fireplace for at least four (4) hours
the first time you use it with the fan on.
When first operated, the unit will release an
odour caused y the curing of the paint and the
urning off of any oils remaining from manufac-
turing. Smoke detectors in the house may go off
at this time. Open a few windows to ventilate
the room for a couple of hours. The glass may
require cleaning.
NOTE: The main urner will always start on
"HIGH" and resume it's last setting after
20 seconds of operation.
NOTE: When the glass is cold and the appli-
ance is lit, it may cause condensation
and fog the glass. This condensation is
normal and will disappear in a few
minutes as the glass heats up.
DO NOT ATTEMPT TO CLEAN THE GLASS
WH LE T S ST LL
HOT!
DO NOT BURN THE APPL ANCE W TH-
OUT THE GLASS FRONT N PLACE.
OPERATING
INSTRUCTIONS
Before operating this appliance, proceed
through the following check list.
1) Read and understand these Instructions
efore operating this appliance.
2) Check to see that all wiring is correct and
enclosed to prevent possi le shock.
3) Check to ensure there are no gas leaks.
4) Make sure the three pieces of door glass
are properly positioned. Never operate the
appliance with any of the glass removed or
with the door open.
5) Verify that all flueing and the cap is uno -
structed.
6) Verify log placement.
LIGHTING
INSTRUCTIONS
1) Plug the power cord into a power outlet.
2) Press and release the ON/OFF utton once
to start the unit.
3) After approximately 3 seconds the spark
ignition system will spark for 40 seconds to
light the main urner.
4) If the main urner does not light, reset the
unit.
RESETTING
THE UNIT
1) Open the pedestal door on the unit.
2) Press the reset utton for approximately 3
seconds and release. The reset utton is
located on the unit's control panel.
3) Wait for approximately 3 seconds and the
pilot sparks can e heard and seen. It would
take 2 to 3 seconds for the flame to e lit.
SHUTDOWN
INSTRUCTIONS
1) Press the ON/OFF utton once.
2) Turn off all electric power to the appliance
if service is to e performed.
FAN OPERATION
Set the fan speed on the control panel located
in ehind the pedestal door to adjust fan to the
desired speed.
ADJUSTING FLAME
HEIGHT
There are six flame settings that can e adjust-
ed y pressing and releasing the plus (+) and
minus (-) FLAME utton.
The FLAME setting utton is located on the
control panel in ehind the pedestal door.
Pressing and releasing the plus (+) FAN utton
will change the fan speed as follows:
OFF -> LOW -> MEDIUM -> HIGH -> OFF, etc.
Pressing and releasing the minus (-) FAN utton
will e the reverse of the a ove.
Control Panel

20 FG37 Regency Rear Flued Room Sealed Freestanding Gas Heater
NORMAL OPERATING
SOUNDS OF
GAS APPLIANCES
It is possi le that you will hear some sounds
from your gas appliance. This is perfectly nor-
mal due to the fact that there are various gauges
and types of steel used within your appliance.
Listed elow are some examples. All are nor-
mal operating sounds and should not e
considered as defects in your appliance.
Blower:
Regency gas appliances use high tech lowers
to push heated air farther into the room. It is not
unusual for the fan to make a "whirring" sound
when ON. This sound will increase or decrease
in volume depending on the speed setting of
your fan speed control.
Burner Tray:
The urner tray is positioned directly under the
urner tu e(s) and logs and is made of a
different gauge material from the rest of the
fire ox and ody. Therefore, the varying thick-
nesses of steel will expand and contract at
slightly different rates which can cause "tick-
ing" and "cracking" sounds. You should also e
aware that as there are temperature changes
within the unit these sounds will likely re-occur.
Again, this is normal for steel fire oxes.
Gas Control Valve:
As the gas control valve turns ON and OFF, a
dull clicking sound may e audi le, this is normal
operation of a gas regulator or valve.
Unit Body Firebox:
Different types and thicknesses of steel will
expand and contract at different rates resulting
in some "cracking" and "ticking" sounds will e
heard throughout the cycling process.
SUMMARY OF
CONTROLS
On/Off Button:
If the unit is switched off, pressing and releas-
ing this utton once will switch the unit on. The
unit will resume its last settings.
If the unit is switched on, pressing and releas-
ing this utton once will switch the unit off.
Flame:
Increase - If the unit is switched on, pressing
and releasing the flame plus (+) utton once will
increase the flame height to the next availa le
high setting.
Decrease - If the unit is switched on, pressing
and releasing the flame minus (-) utton once
will decrease the flame height to the next
availa le low setting.
Fan:
Increase - If the unit is switched on, pressing
and releasing the fan plus (+) utton once will
increase the fan speed to the next availa le
high setting.
Decrease - If the unit is switched on, pressing
and releasing the fan minus (-) utton once will
decrease the fan speed to the next availa le
low setting.
PILOT ADJUSTMENT
Periodically check the pilot flames. The correct
flame pattern has 3 strong lue flames.
One flowing around the thermocouple, the sec-
ond flowing across the rear of the urner (it
does not have to e touching the urner) and
the third flame flowing tangent to the spark
ignitor.
NOTE: If you have an incorrect flame
pattern, contact your Regency dealer for
further instructions.
Rear of Burner
Front of Burner
An incorrect flame pattern will have small,
probably yellow flames, not coming into
proper contact with the rear of the burner or
thermopile.
Rear of Burner
Front of Burner
OPERATING INSTRUCTIONS
