Regency FG38-LPG Quick start guide

03/11/10
Freestanding Gas Stove
FOR YOUR SAFETY
What to do if you smell gas:
Donottrytolightanyappli-
ance
Do not touch any electri-
cal switch: do not use any
phone in your building.
Immediately call your gas
supplierfromaneighbour's
phone. Follow the gas sup-
plier's instructions.
If you cannot reach your
gas supplier, call the fire
department.
WARNING:
Improper installation, adjustment, altera-
tion, service or maintenance can cause
injury or property damage. Refer to this
manual. For assistance or additional in-
formation consult an authorized installer,
service agency or the gas supplier.
FOR YOUR SAFETY
Do not store or use gasoline or other flam-
mable vapours and liquids in the vicinity of
this or any other appliance.
Installation and service must be performed
byanauthorizedinstaller,serviceagencyor
the gas supplier.
PLEASE KEEP THESE INSTRUCTIONS
FOR FUTURE REFERENCE
Owners &
Installation
Manual
LISTINGS AND CODE APPROVALS
These gas appliances have been tested in
accordance with AS4553-2000, NZS 5262
andhavebeencertifiedbytheAustralianGas
Association for installation and operation as
describedintheseInstallationandOperating
Instructions.
Your unit should be serviced annually by
an authorised service person.
918-243c
Models: FG38-NG
FG38-LPG

2Regency FG38 FireGenie Freestanding Gas Stove
To the New Owner:
Congratulations! Youaretheownerofastate-of-the-art GasStovebyFPIFIREPLACEPRODUCTS
INTERNATIONAL LTD. The Regency Gas Series of appliances has been designed to provide you
with all the warmth and charm of a woodstove, at the flick of a switch.
The models FG38-NG, and FG38-LPG of this series has been approved by AGA for both safety
and efficiency. As it also bears our own mark, it promises to provide you with economy, comfort
and security for many trouble free years to follow. Please take a moment now to acquaint yourself
with these instructions and the many features of your Regency Gas Stove.
FG38-NG & FG38-LPG

Regency FG38 FireGenie Freestanding Gas Stove 3
TABLE OF CONTENTS
Safety Label
Specifications ................................................................2
Safety Label...................................................................4
Installation
General Information.......................................................5
Before you start.............................................................5
General Safety Information............................................5
Installation Checklist......................................................6
Clearances to Combustibles..........................................6
Draft diverter..................................................................6
Flueing...........................................................................6
Flueing Requirements ...................................................6
Gas Connection.............................................................7
Gas Pressure Test.........................................................7
S.I.T. Valve Description..................................................7
System Data..................................................................7
Conversion from NG to LPG..........................................8
Aeration Adjustment ......................................................9
Log Installation ..............................................................9
Front Door Installation.................................................11
Test for Flue Spillage...................................................11
Remote Control (optional) ..........................................12
Final Check..................................................................12
Wiring Diagram............................................................12
Operating Instructions
Operating Instructions .................................................13
Lighting Instructions.....................................................13
Resetting the Unit........................................................13
Shutdown Instructions.................................................13
First Fire ......................................................................13
Fan Operation..............................................................13
Flame Height Adjustment ............................................14
Summary of Controls...................................................14
Normal Operating Sounds of Gas Appliances.............14
Copy of Lighting Plate Instructions..............................15
Maintenance
Maintenance Instructions.............................................16
Log Replacement ........................................................16
Door and Glass Gasket...............................................16
Glass Replacement.....................................................16
Fan Maintenance.............................................................
17
Removing Valve...............................................................
18
Parts List
Electronic Components ...............................................19
Main Assembly ...........................................................20
Burner & Log Assembly...............................................21
Door Assembly ............................................................22
Warranty
Warranty......................................................................23

4Regency FG38 FireGenie Freestanding Gas Stove
This is a copy of the label that accompanies
each FreestandingGasStove.Wehaveprinted
acopy ofthe contentshereforyourreview.The
safety label is located on the inside of the drop
down pedestal door.
NOTE: Regency units are constantly being
improved. Check the label on the unit and if
there is a difference, the label on the unit is the
correct one.
SAFETY LABEL
DO NOT
DO NOT
DO NOT
DO NOT
DO NOT
DO NOT
OPERATE THIS APPLIANCE BEFORE READING THE
INSTRUCTIONS BOOKLET.
PLACE ARTICLES ON OR AGAINST THIS APPLIANCE
STORE CHEMICALS OR FLAMMABLE MATERIALS
SPRAY AEROSOLS IN THE VICINITY OF THIS
APPLIANCE WHILE IN OPERATION.
OPERATE WITH PANELS, COVERS OR GUARDS
REMOVED FROM THIS APPLIANCE.
ENCLOSE THIS APPLIANCE.
DO NOT MODIFY THIS APPLIANCE.
NEAR THIS APPLIANCE.
DO NOT
908-602a
(Australia Only)
Gas Type NG LPG
Model
Gas Consumption 38 . 31 .
Manifold Pressure .87 2.65
Injector Size 1x 1x 52
FG38-NG FG38-LPG
mj mj
kPa kPa
##
33
Serial
Number
918-245a
Model
N2134
Regency Gas Fireplace
2.87mm 1.61mm
AGA Approval number to
Code AS4553-2000 6231 6231
257
Distributed by:
Western Australia:
To be installed by an authorised person in
accordance with installation instructions
provided with the appliance.
Air Group Australia
28-30 Division St
Welshpool WA 6106
Fireplace Products
Australia Pty. Ltd.
21-23 South Link Blvd.
Dandenong, VIC 3175
Eastern Australia:

Regency FG38 FireGenie Freestanding Gas Stove 5
INSTALLATION
GENERAL SAFETY
INFORMATION
1) The appliance shall be installed in accord-
ance with the manufacturer's installation
instructions, local gas fitting regulations,
municipal building codes, water supply
regulations, electrical wiring regulations,
with AS5601-2004 (AGA gas installation
code) NZS 5261 (New Zealand)
2) Installation and repair should be done
ONLY by an authorised person.
3) See general construction and assembly
instructions. The appliance should be in-
spectedbefore useand atleast annually
by an authorised service person. More
frequent cleaning may be required due
toexcessivelintfromcarpeting,bedding
material,etc. Itisimperativethatcontrol
compartments, burners and circulating
airpassagewaysoftheappliancebekept
clean and free from excessive lint from
carpeting.
4) This appliance must be connected to a flue
and terminate to the outside of the building
envelope. Never flue to another room.
5) Inspect the flueing system annually for
blockage and any signs of deterioration.
6) Anysafetyglassremovedforservicingmust
bereplacedpriortooperatingtheappliance.
7) To prevent injury, do not allow anyone who
is unfamiliar with the operation to use the
fireplace.
8) Wear gloves and safety glasses for protec-
tion while doing required maintenance.
9) Under no circumstances should this ap-
pliance be modified. Parts that have to be
removed for servicing should be replaced
prior to operating this appliance.
10) Installationandanyrepairstothisappliance
should be done by an authorised service
person.Anauthorisedservicepersonshould
becalled toinspect thisappliance annually.
Make it a practice to have all of your gas
appliances checked annually.
11) Do not strike the glass door.
12) Under no circumstances should any solid
fuels (wood, paper, cardboard, coal, etc.)
be used in this appliance.
13) The appliance area must be kept clear and
free of combustible materials, (gases and
other flammable vapours and liquids).
GENERAL
INFORMATION
This installation must conform with local
codes or, in the absence of local codes,
with AS5601-2004 (Australia) NZS 5261
(New Zealand).
THIS APPLIANCE SHOULD
BEINSTALLED,REPAIRED,
INSPECTED BEFORE USE
AND CLEANED ANNUAL-
LY BY AN AUTHORISED
SERVICE PERSON. MORE FREQUENT
CLEANING MAY BE REQUIRED, DUE TO
EXCESSIVELINTFROMCARPETING,ETC.
IT IS IMPERATIVE THAT CONTROL COM-
PARTMENT,BURNERSANDCIRCULATING
AIR PASSAGEWAYS OFTHEAPPLIANCE
BE KEPT CLEAN.
DUE TO HIGH TEMPERA-
TURES, THE APPLIANCE
SHOULD BE LOCATED OUT
OF TRAFFIC AND AWAY
FROM FURNITURE AND
DRAPERIES.
THISAPPLIANCECANONLY
BEFLUEDINACCORDANCE
WITH AS5601-2004 OR LO-
CAL CODES.
FAILURE TO INSTALL THIS
APPLIANCE CORRECTLY
MAY CAUSE A SERIOUS
HOUSE FIRE.
Provide adequate clearances for servicing,
proper operation and around the air openings
intothecombustionchamber.Adequatecombus-
tion and ventilation air must also be provided.
The appliance must be installed on a flat, solid,
continuoussurface(i.e.wood,metal,concrete).
This may be the floor, or it can be raised up on
a platform to enhance its visual impact.
The Regency Freestanding Gas Heater can be
installed in a wide variety of ways and will fit
nearly any room layout. It may be installed in a
recessed position, framed out into the room, or
across a corner.
Werecommendthatyouplanyourinstallationon
paperusingexactmeasurementsforclearances
andfloorprotectionbeforeactuallyinstallingthis
appliance. If an existing chimney is not utilised,
position the appliance to allow free passage of
factory-built listed chimney through the ceiling
and roof.
IMPORTANT:
The FG38 Freestanding Gas Stove must be
installed in accordance with these instructions.
Carefullyreadalltheinstructionsinthismanual
first.Consultthe"authorityhavingjurisdiction"to
determinethe needfor apermitpriortostarting
the installation.
BEFORE YOU START
INSTALLATION AND REPAIR
SHOULD BE DONE BY AN AU-
THORISED SERVICE PERSON.
THE APPLIANCE SHOULD BE
INSPECTED BEFORE USE AND
CLEANED ANNUALLY BY AN
AUTHORISEDSERVICEPERSON.
MORE FREQUENT CLEANING
MAY BE REQUIRED DUE TO EX-
CESSIVELINTFROMCARPETING,
BEDDING MATERIAL, ETC. IT IS
IMPERATIVE THAT CONTROL
COMPARTMENTS,BURNERSAND
CIRCULATING AIR PASSAGE-
WAYS OF THE APPLIANCE BE
KEPT CLEAN.
DUE TO HIGH TEMPERATURES,
THE APPLIANCE SHOULD BE
LOCATED OUT OF TRAFFIC AND
AWAY FROM FURNITURE AND
DRAPERIES.
WARNING: FAILURE TO INSTALL
THIS APPLIANCE CORRECTLY
MAY CAUSE A SERIOUS HOUSE
FIRE AND WILL VOID YOUR
WARRANTY.
CHILDRENANDADULTSSHOULD
BE ALERTED TO THE HAZARDS
OF HIGH SURFACE TEMPERA-
TURES, ESPECIALLY THE FIRE-
PLACE GLASS, AND SHOULD
STAYAWAYTOAVOIDBURNSOR
CLOTHING IGNITION.
YOUNG CHILDREN SHOULD BE
CAREFULLY SUPERVISEDWHEN
THEYAREINTHESAMEROOMAS
THE APPLIANCE.
CLOTHING OR OTHER FLAM-
MABLE MATERIAL SHOULD NOT
BE PLACED ON OR NEAR THE
APPLIANCE.

6Regency FG38 FireGenie Freestanding Gas Stove
INSTALLATION
CLEARANCES TO
COMBUSTIBLES
The clearances listed below are MINIMUM
distances. Measure the clearance to both the
applianceandthechimneyconnector. (Thefar-
thestdistanceiscorrectifthetwoclearances
donot coincide.)Forexample,if theappliance
is set as indicated in one of the figures but the
connector is too close, move the stove until the
correct clearance to the connector is obtained.
Thisunit canbe installedonasolidcombustible
surface like a wood floor. This unit can also be
installed directly on carpeting or vinyl when
the bottom pedestal cover plate (provided with
unit) is installed.
This appliance may be installed only with the
clearances as shown in the situations pictured.
Do not combine clearances from one type of
installation with another in order to achieve
closer clearances.
Use the minimum clearances shown in the
diagrams below for all installations.
FG38-NG & FG38-LPG
Reference Dimensions
C Back Wall to Flue Centerline 10-3/4" / 273
mm
D Side Wall to Flue Centerline 20-1/2" / 520
mm
F Side Wall to Flue Centerline 11" / 280 mm
Clearances
A Side Wall to Unit 7-1/2"/190mm
B Back Wall to Unit 6" / 155 mm
E Side Wall to Unit 2" / 50 mm
Minimum ceiling
height is 36" / 914
mm from top of unit.
If further reduced clear-
ances are needed, ob-
tain requirements for
construction of a pro-
tected wall from your
local building authori-
ties and their allowable
reductions of the listed
clearances.
DRAFT DIVERTER
This heater has a draft diverter built in. It must
notbealtered,obstructed,orblockedinanyway,
and the unit must be installed so that the draft
diverter is in the same atmospheric pressure
zone as the combustion air inlet to the burner.
This heater must be properly connected to a
flueing system.
WARNING:Operationofthisheaterwhennot
connected to a properly installed and main-
tained flueing system can result in carbon
monoxide(CO)poisoningandpossibledeath.
FLUEING
This heater is a flued appliance and must be
connectedtoa chimney/fluein accordance with
the installation codes.
Note: The rear pedestal cover plate must
alwaysbefittedforsafety.Electrical
connections inside.
Flueing Requirements
A100mmdiameterflueisrequired. Forcosmetic
or aesthetic purposes 6" outer flue can be used
as long as an approved inner flue is installed.
Fasten but do not penetrate the inner sleeve
ofthe flue when tightening the screw.
The minimum flue required is 3.3m from floor
level.
Follow all flueing manufacturer’s requirements
and local building codes or AS5601-2004.
14) This unit can be installed on a solid com-
bustiblesurface likea woodfloor aswell as
on carpeting.
INSTALLATION
CHECKLIST
1) Check Clearances to Combustibles, page
6.
2) Install flueing, page 6.
3) Make gas connections, page 7.
4) If necessary, convert NG to LPG on page
8.
5) Test Gas Pressure, page 7.
6) Install log set where indicated on page 9.
7) Install Front Door, page 11.
8) Test for flue spillage (draft test), page 11.
9) Install Remote Control, page 12.
10) Final check, page 12.
Before leaving this unit with the customer, the
installer must ensure that the appliance is fir-
ing correctly and operation fully explained to
customer.
This includes:
1) Clockingtheappliancetoensurethecorrect
firingrate(ratenotedonlabel)afterburning
appliance for 15 minutes.
2) Ifrequired,adjustingtheprimaryairtoensure
that the flame does not carbon. First allow
the unit to burn for 15-20 min. to stabilize.
CAUTION: Any alteration to the product that
causes sooting or carboning or that results in
damage is not the responsibility of the manu-
facturer.

Regency FG38 FireGenie Freestanding Gas Stove 7
INSTALLATION
GAS CONNECTION
The gas line should be rigid pipe. Copper may
also be used if approved by AS5601-2004.
The gas connection at the valve is 1/2 male.
For minimum and maximum supply pressure
see the System Data Table.
GAS PIPE PRESSURE
TESTING
The appliance must be isolated from the gas
supply piping system by closing its individual
manual shut-off valve during any pressure
testing of the gas supply piping system at test
pressures equal to or less than 1/2 psig. (3.45
kPa). Disconnectpipingfromvalveatpressures
over 3.45 kPa (14" w.c.).
Themanifoldpressureiscontrolledbyaregulator
builtintothegascontrol,andshouldbechecked
at the pressure test point.
Note: To properly check gas pressure,
both inlet and manifold pressures
should be checked using the valve
pressure ports on the valve.
1) Makesurethevalveisinthe"OFF"position.
2) Loosen the "IN" (# 3) and/or "OUT" (# 4)
pressure tap(s), turning counterclockwise
with a 1/8" wide flat screwdriver.
3) Attach manometer to "IN" and/or "OUT"
pressure tap(s) using a 5/16" ID hose.
4) Seal and or check the pilot outlet (# 8)
5) The pressure check should be carried out
with the unit burning and the setting should
be within the limits specified on the safety
label.
6) When finished reading manometer, turn
off the gas valve, disconnect the hose and
tightenthescrew(clockwise) witha1/8"flat
screwdriver. Screw should be snug, but do
not over tighten.
S.I.T. Valve Description
1) On-Off Solenoid Valve EV1
2) On-Off Solenoid Valve EV2
3) Inlet Pressure Test Point
4) Outlet Pressure Test Point
5) Connection for Pressure Regulator /
Combustion Chamber Compensation
6) Pressure Regulator for Minimum and
Maximum Outlet Pressure
7) Gas Outlet Pressure Electric Modulator
8) Pilot Outlet
9) Main Gas Outlet
10)Side Outlet
11) Main Gas Inlet
FG38-NG: For 0 to 610 meters altitude
FG38-LPG: For 0 to 610 meters altitude
Burner Inlet Orifice Sizes:
NG LPG
Burner #33 #52
Max. Input
NG 38 mj
LPG 31 mj
Min. Input
NG 20.8 mj
LPG 16.1 mj
Supply Pressure
NG 1.13 kPa
LPG 2.75 kPa
Manifold Pressure
NG 0.87 kPa
LPG 2.65 kPa
Electrical: 240 V. 50Hz.
Circulation: High/Off/LO speed fan, 150/89
CFM.
Log Set: Ceramic fiber, 7 per set.
Aeration Setting
NG 15 mm
LPG 6.4 mm
Flue Restrictor Setting
NG Full Open
LPG Full Open
System Data
FG38
EV1
EV2
R.Q.
ADJ.
P.OUT
MD
4321
Pin
11
8
9
10
1
2
3
4
6
7
5

8Regency FG38 FireGenie Freestanding Gas Stove
INSTALLATION
Conversion Kit for NG to LPG Model #756-969
THIS CONVERSION MUST BE DONE BY A QUALIFIED GAS FITTER IF IN DOUBT DO NOT DO THIS CONVERSION !!
Burner Orifice
Conversion Kit 756-969 Contains:
Qty. Part # Description
1 904-390 Burner Orifice #52
1 908-528 Red "LPG" label
1 908-255 Label "Converted to LPG"
1 918-270 Instruction Sheet
1) Shut off the gas supply and unplug the
power cord.
2) Open the front door and carefully remove
the logs and lava rock.
3) Remove burner.
4) Remove burner orifice with a 1/2" wrench
and discard. Use a wrench to hold on to
the elbow behind the orifice.
5) Reinstall new burner orifice LPG stamped
#52 and tighten.
6) Adjusttheburneraerationsettingto6.4mm
before installing the burner. Reverse steps
3) and 2).
7) Stick the conversion label "This unit has
been converted to LPG" over top of the
serial number decal.
8) Replace the yellow "NG" label with the red
"LPG" label.
9) Remove the pedestal back cover by
removing the 4 Philips screws.
13) Reverse steps 11 to 9.
14) Turn on gas supply and plug in power cord.
Installer Notice:
These instructions must be left
with the appliance.
Control Box
Cover
Antenna
11) Remove the control box cover by undoing
the 3 screws. Maneuver through antenna.
Jumper Location
Jumper
15) Adjusting the Outlet Pressure
All the adjustments must be carried out
in the following order:
Remove the modulator plastic cap (A)
using needle nose pliers.
Maximum pressure: Turn the unit ON to
its highest input rating. Screw in the nut
(B) to increase the outlet pressure and
screw it out to decrease it. Use a 10 mm
wrench.
NOTE: The outlet pressure must be set
to maximum 2.65 kPa.
Minimum pressure: Remove one of the
cablesconnectedtotheelectricmodulator.
Keeping the nut (B) blocked, screw in the
screw (C) to increase the pressure and
screwitouttodecreaseit.Useascrewdriver
6 x 1 blade.
NOTE: The outlet pressure must be set to
minimum 0.74 kPa.
Aftercarryingoutalladjustments,blockthe
settingscrewswith paint,taking carenotto
obstructthebreatherorificeofthepressure.
Put back the modulator plastic cap.
WARNING:Toensurethecorrectoperation
of the modulator it is necessary that the
plastic cap (A) is returned to its original
location.
16) At the end of all setting and adjustment
operations, check electrical insulation and
gas leaks.
17) Check operation of flame control.
18) Check for proper flame appearance and
glow on logs.
C
BA
Cable
Electric
Modulator
10) Carefully pull out the control box.
NOTE: The control box is held in place with
velcro.
12) Remove the jumper using a plier.

Regency FG38 FireGenie Freestanding Gas Stove 9
INSTALLATION
AERATION
ADJUSTMENT
Theburneraerationisfactorysetbutmayneed
adjusting due to either the local gas supply or
altitude.
FG38 with 38 mj NG
FG38 with 31 mj LPG
FG38-NG 15 mm Fully Open
FG38-LPG 6.4 mm open
Caution: Carbon will be produced if the air
shutter is closed too much.
Note: Any damage due to carboning re-
sulting from improperly setting the
aeration controls is NOT covered
under warranty.
Embers Embers
The "02" refer numbers (i.e. 02-65) are
molded into the rear of each log.
LOG SET
INSTALLATION
Read the instructions below carefully and
refer to the diagrams. If logs are broken
do not use the unit until they are replaced.
The gas log kit contains the following:
a) 02-65 Rear Log
b) 02-56 Middle Left Log
c) 02-44 Front Left Log
d) 02-46 Left Top Log
e) 02-45 Front Right Log
f) 02-47 Center Log
g) 02-48 Middle Right Log
h) Embers 902-151
i) Lava 902-154
1) Carefullyremovethelogsfromtheboxand
unwrap them. The logs are fragile, handle
with care - do not force into position.
2) Sprinkle the embers on the left and right
sides of the firebox base.
C)02-44
Pins on Rear Log Support
A)02-65
B)02-56
3) Place Rear LogA)02-65 on the two pins on
the rear log support.
4) Place the Middle Left Log B)02-56 on the
two pins as shown.
5) Place Front Left Log C)02-44 onto the 2
front pins as shown.

10 Regency FG38 FireGenie Freestanding Gas Stove
Notch
E)02-45
Bracket
A)02-65
The bottom right edge of Log G)02-48 must
sit snugly against the bracket
Side View
G)02-48
E)02-45
F)02-47
10) Position notch in Front Right Log G)02-48
on Log F)02-47 and push the bottom right
edgeagainstthebracketontheburnertray.
G)02-48
11) Test fire to ensure proper light off (make
sure flame flows smoothly from one end
of burner to the other. If there is any flame
hesitation,checkthatareaforanyblockage
of the burner port.
F)02-47
E)02-45
A)02-65
G)02-48
D)02-46
B)02-56
C)02-44
Cutout
Pin
D)02-46
B)02-56
A)02-65
6) Place the Left Top Log D)02-46 on the pin
on Log B)02-56 and on top of the cutout
on Log A)02-65.
E)02-45
C)02-44
7) Place Front Right Log E)02-45 on the two
pins as shown.
8) Place the lava rock in the area between
the left and right logs, leaving a space in
the middle for log (F) 02-47.
CutoutNotch
F)02-47
E)02-45
A)02-65
9) Placethenotch inCenter Log F)02-47over
Log E)02-45 and across the cutout on Log
A)02-65.
INSTALLATION
Ensure that the lava rocks are not placed
directly over the burner ports.

Regency FG38 FireGenie Freestanding Gas Stove 11
TEST FOR FLUE
SPILLAGE
A "spillage" test must be made before the
installed unit is left with the customer. Follow
the procedure below:
1) Start all exhaust fans in the home and any
other gas appliances. Then close all doors
and windows.
2) Lightthe unitand setcontrols tomaximum.
3) After five minutes, test that there is a "pull"
on the flue by placing a smoke match,
cigarette or similar device which gives off
smoke, on the edge of the draft diverter.
See diagrams.
The smoke should be drawn into the draft
diverter. If the smoke is not drawn into the draft
diverter,turntheunitoffandcheckforthecause
of lack of draft.
.
INSTALLATION
Latch plate
Alignment
pin
Adjustable
latch
Door safety
bracket
Diagram 1
FRONT DOOR
INSTALLATION
1) Open the two side panels.
2) Slidethedoorontothetwohingepinsmaking
sure the two pieces are flush together. See
diagram 1.
3) Close the door. The latch plate must be
centered around the alignment pin. See
diagram 2. If the latch plate interferes with
the corner of the stove you may want to
angle the plate slightly so the door closes
easier.
Diagram 2
Diagram 3
4) Thelatchesshouldalreadybeattheproper
setting. If they are too hard or too easy
to close, you may want to adjust them by
loosening the latch catch. See diagram 3.
5) Test the seal around the door by placing
a piece of paper between the unit and the
door,closethedoorandtrytopullthepaper
out. If it slips out easily, then the door is not
properlysealed.Tightenorloosenthelatch.
See diagram 3.
Note: The door latch may require adjust-
ment as the door gasket material
compresses after a few fires and
after glass replacement. Turn the
latch catch inward or outward to
loosen or tighten. Attach safety
bracket with one screw as shown
below.
Note: If the flue is blocked or has a strong
reverse flow, check for the cause of the
lack of draft.

12 Regency FG38 FireGenie Freestanding Gas Stove
WIRING
CAUTION:
Label all wires prior to disconnection
when servicing controls.
Wiring errors can cause improper
and dangerous operation.
WARNING:
Electrical Grounding Instructions
Thisapplianceisequippedwithathree
pronged (grounding) plug for your
protection against shock hazard and
shouldbepluggeddirectlyintoaprop-
erlygroundedthree-prongreceptacle.
Do not cut or remove the grounding
prong from this plug.
REMOTE CONTROL
UsetheRegency RemoteControlKit approved
for this unit. Use of other systems may void
your warranty.
The remote control kit comes with a hand held
transmitter and a wall mounting plate.
1) Choose a convenient location to mount
the hand held transmitter, protection from
extreme heat is very important.
By usiing the wall mounting plate to house the
transmitter, the remote can also be used as a
wall thermostat.
FINAL CHECK
Before leaving this unit with the customer, the
installermustensurethattheapplianceisfiring
correctly. This includes:
1) Clocking the appliance to ensure the cor-
rect firing rate (rate noted on label) at 15
minutes.
2) If required, adjusting the primary air to en-
sure that the flame does not carbon. First
allowtheunittoburnfor15min.tostabilize.
3) Check for proper draft.
CAUTION
Any alteration to the product that
causes sooting or carboning that
results in damage to the exterior
facia is not the responsibility of the
manufacturer.
INSTALLATION
Caution: Ensure that the wires do not
touch any hot surfaces and are away
from sharp edges.

Regency FG38 FireGenie Freestanding Gas Stove 13
OPERATING INSTRUCTIONS
OPERATING
INSTRUCTIONS
Beforeoperatingthisappliance,proceedthrough
the following check list.
1) Read and understand these Instructions
before operating this appliance.
2) Check to see that all wiring is correct and
enclosed to prevent possible shock.
3) Check to ensure there are no gas leaks.
4) Make sure the three pieces of door glass
are properly positioned. Never operate the
appliance with any of the glass removed or
with the door open.
5) Verify that all flueing and the cap is unob-
structed.
6) Verify log placement.
LIGHTING
INSTRUCTIONS
1) Plug the power cord into a power outlet.
2) PressandreleasetheON/OFFswitchonce
to start the unit. The LED will be lit.
3) After approximately 8 seconds the spark
ignition system will spark for 8 seconds to
light the main burner.
4) Ifthemainburnerdoesnotlight,repeatstep
2 to restart unit.
RESETTING
THE UNIT
1) Open the pedestal door on the unit.
2) Press and release the reset button, located
on the unit's control panel once.
3) Wait for approximately 8 seconds and the
pilotsparkscanbeheardandseen.Itwould
take 2 to 3 seconds for the flame to be lit.
NOTE:Aperiodof30secondsmustpassbefore
another reset is attempted.
SHUTDOWN
INSTRUCTIONS
1) Press the ON/OFF switch once.
2) The LED will flash.
3) Turn off all electric power to the appliance
if service is to be performed.
FIRST FIRE
The FIRST FIRE in your heater is part of the
paint curing process. To ensure that the paint
is properly cured, it is recommended that you
burn your fireplace for at least four (4) hours
the first time you use it with the fan on.
When first operated, the unit will release an
odour caused by the curing of the paint and
the burning off of any oils remaining from
manufacturing. Smoke detectors in the house
may go off at this time. Open a few windows
toventilatetheroomfor acouple ofhours.The
glass may require cleaning.
NOTE: The main burner will always start on
"HIGH"andresumeit'slastsettingafter
20 seconds of operation.
NOTE: When the glass is cold and the appli-
ance is lit, it may cause condensation
and fog the glass. This condensation
is normal and will disappear in a few
minutes as the glass heats up.
DO NOT ATTEMPT TO CLEAN THE
GLASS WHILE IT IS STILL HOT!
DONOTBURNTHEAPPLIANCEWITH-
OUT THE GLASS FRONT IN PLACE.
FAN OPERATION
Setthefanspeedonthecontrolpanelatthetop
rear of the unit to adjust to the desired speed.
Pressingandreleasing theplus (+)FANbutton
will change the fan speed as follows:
OFF -> LOW -> MEDIUM -> HIGH -> OFF, etc.
Pressingandreleasingtheminus(-)FANbutton
will be the reverse of the above.

14 Regency FG38 FireGenie Freestanding Gas Stove
NORMAL OPERATING
SOUNDS OF
GAS APPLIANCES
It is possible that you will hear some sounds
fromyourgasappliance.Thisisperfectlynormal
due to the fact that there are various gauges
and types of steel used within your appliance.
Listedbelowaresomeexamples.Allarenormal
operatingsoundsandshouldnotbeconsidered
as defects in your appliance.
Blower:
Regency gas appliances use high tech blowers
to push heated air farther into the room. It is not
unusual for the fan to make a "whirring" sound
when ON. This sound will increase or decrease
in volume depending on the speed setting of
your fan speed control.
Burner Tray:
The burner tray is positioned directly under the
burner tube(s) and logs and is made of a differ-
ent gauge material from the rest of the firebox
andbody. Therefore,the varyingthicknesses of
steelwillexpandandcontractatslightlydifferent
rates which can cause "ticking" and "cracking"
sounds. You should also be aware that as there
are temperature changes within the unit these
sounds will likely re-occur.Again, this is normal
for steel fireboxes.
Gas Control Valve:
As the gas control valve turns ON and OFF, a
dullclickingsoundmaybeaudible,thisisnormal
operation of a gas regulator or valve.
Unit Body/Firebox:
Different types and thicknesses of steel will
expand and contract at different rates resulting
in some "cracking" and "ticking" sounds will be
heard throughout the cycling process.
OPERATING INSTRUCTIONS
WARNING
DO NOT SPRAY AEROSOLS IN
THE VICINITY OF THIS
APPLIANCE WHILE IN
OPERATION
ADJUSTING FLAME
HEIGHT
Therearesixflamesettingsthatcanbeadjusted
bypressingandreleasingtheplus(+)and minus
(-) FLAME button.
The FLAME setting button is located on the
control panel at the top rear of the unit.
SUMMARY OF
CONTROLS
On/Off Button
Iftheunit isswitchedoff,pressingandreleasing
this button once will switch the unit on. The unit
will resume its last settings.
Iftheunitisswitchedon,pressingandreleasing
this button once will switch the unit off.
Flame:
Increase - If the unit is switched on, pressing
andreleasingtheflameplus(+)buttononcewill
increase the flame height to the next available
high setting.
Decrease - If the unit is switched on, pressing
and releasing the flame minus (-) button once
will decrease the flame height to the next avail-
able low setting.
Fan:
Increase - If the unit is switched on, pressing
and releasing the fan plus (+) button once will
increase the fan speed to the next available
high setting.
Decrease - If the unit is switched on, pressing
and releasing the fan minus (-) button once will
decrease the fan speed to the next available
low setting.

Regency FG38 FireGenie Freestanding Gas Stove 15
OPERATING INSTRUCTIONS
COPY OF THE LIGHTING PLATE INSTRUCTIONS
WARNING:
DO NOT SPRAY AEROSOLS IN THE VICINITY OF
THIS APPLIANCE WHILE IN OPERATION.
FOR YOUR SAFETY READ BEFORE LIGHTING
A) BEFORE LIGHTING smell all around the appliance area
for gas. Be sure to smell next to the floor because some
gas is heavier than air and will settle on the floor.
WHAT TO DO IF YOU SMELL GAS
- Do not try to light any appliance
- Do not touch any electric switch, do not use any
phone in your building
- Immediately call your gas supplier from a neighbors
phone. Follow the gas supplier’s instructions.
- If you cannot reach your gas supplier, call the
fire department.
918-247b
WARNING: If you do not follow these instructions exactly, a fire or explosion may result
causing property damage, personal injury or loss of life. Improper installation, adjustment,
alteration, service or maintenance can cause injury or property damage. Refer to the
owner’s information manual provided with this appliance. For assistance or additional
information consult a qualified installer, service agency or gas supplier.
B) Do not use this appliance if any part has been under water.
Immediately call a qualified service technician to inspect
the appliance and to replace any part of the control system
and any gas control which has been under water.
This appliance needs fresh air for safe operation and
must be installed so there are provisions for adequate
combustion and ventilation air.
LIGHTING INSTRUCTIONS
TO TURN OFF GAS APPLIANCE
This appliance must be installed in accordance with local codes, if any; if not,
follow the current CAN1-B149/ANSI Z 223.1 (Australia: AS5601-2004, New Zealand: NZS 5261)
DO NOT REMOVE THIS INSTRUCTION PLATE
1) Press the ON/OFF switch once.
2) The LED will flash.
CAUTION: Hot while in operation. Do not touch. Severe Burns may result. Due to high
surface temperatures keep children, clothing and furniture, gasoline and other liquids
having fammable vapors away. Keep burner and control compartment clean. See installation
and operating instructions accompanying appliance.
STOP! Read the safety information above on this label.
1) Plug the power cord into a power outlet.
2) Press and release the ON/OFF switch once to start
the unit. The LED will be lit.
3) After approximately 8 seconds the spark ignition
system will spark for 8 seconds to light the main
burner.
4) If the main burner does not light, repeat step 2 to
restart.
3) Turn off all electric power to the unit if service is
to be performed.
You may shut off the pilot during prolonged non use periods to conserve fuel.

16 Regency FG38 FireGenie Freestanding Gas Stove
GLASS
REPLACEMENT
YourRegency heaterissupplied withhigh tem-
perature,5mmNeoceramsilicacoatedceramic
glass that will withstand the highest heat that
yourunitwillproduce.Intheeventthatyoubreak
your glass, purchase your replacement from
an authorized Regency dealer only, and follow
the step-by-step instructions for replacement.
Removing Glass:
Note: Wearing gloves will protect your
hands while handling glass.
1) Remove the door from the unit and place
on a soft surface to prevent scratching.
2) Pull out the door gasket.
3) Remove the 24 nuts holding the glass
retainers in place. Do not remove the nuts
underneath the retainers.
4) Remove the door catch plate.
5) Removeglassretainersonsidesfirst(3each
side) then remove two center retainers.
6) Remove glass from door assembly. When
removing glass, leave white insulation in
place.
7) Reverse steps 6 - 2.
MAINTENANCE
MAINTENANCE
INSTRUCTIONS
Any maintenance required accessing the
glass door of the unit must be performed
by an authorized service person.
1) Always unplug the power cord before
cleaning. For relighting, refer to lighting
instructions. Keep the burner and control
compartment clean by brushing and vacu-
uming at least once a year. When cleaning
the logs, use a soft clean brush as the logs
are fragile and easily damaged.
2) Cleanglass(never when unitis hot), appli-
ance, louvres, and door with a damp cloth.
Never use an abrasive cleaner. The gold
louvres (and optional gold door) may be
scratched if abrasives are used to clean
them.
The heater is finished in a heat resistant
paint and should only be refinished with
heat resistant paint (not with wall paint).
Regency uses StoveBright Paint - Metallic
Black #6309.
3) Makea periodic checkofburner forproper
position and condition. Visually check the
flameoftheburnerperiodically,makingsure
theflamesare steady;notliftingorfloating.
If there is a problem, call an authorized
service person.
4) The appliance and flueing system must be
inspected before use, and at least annu-
ally, by an authorized field service person,
to ensure that the flow of combustion and
ventilation air is not obstructed.
During the annual service call, the burners
should be removed from the burner tray
and cleaned. Replace the embers - do not
block the burner ports.
5) Keeptheareaneartheapplianceclearand
free from combustible materials, gasoline
and other flammable vapours and liquids.
WARNING: CHILDREN AND
ADULTS SHOULD BE ALERTED
TO THE HAZARDS OF HIGH
SURFACE TEMPERATURE AND
SHOULD STAY AWAY TO AVOID
BURNS OR CLOTHING IGNITION.
YOUNG CHILDREN SHOULD BE
CAREFULLY SUPERVISED WHEN
THEYAREINTHESAMEROOMAS
THE APPLIANCE.
CAUTION: ANYSAFETYSCREEN
OR GUARD REMOVED FOR
SERVICINGANAPPLIANCEMUST
BE REPLACED PRIOR TO
OPERATING THE APPLIANCE.
CLOTHING OR OTHER FLAM-
MABLE MATERIALSHOULD NOT
BE PLACED ON OR NEAR THE
APPLIANCE.
DO NOT USE THIS APPLIANCE
IF ANY PART HAS BEEN UNDER
WATER. IMMEDIATELY CALL AN
AUTHORIZED SERVICE TECHNI
CIAN TO INSPECT THE APPLI-
ANCE AND TO REPLACE ANY
PARTOFCONTROLSYSTEMAND
ANY GAS CONTROLWHICH HAS
BEEN UNDER WATER.
6) Verify proper operation after servicing.
LOG REPLACEMENT
Theunitshouldneverbeusedwithbrokenlogs.
Unplug the power cord and allow the unit to
cool before opening door to carefully remove
the logs. If for any reason a log should need
replacement,youmustusetheproperreplace-
mentlog.Theposition oftheselogsmustbe as
shown in the diagram under Log Installation.
Note: Improper positioning of logs may
createcarbonbuild-upandwillalter
theunit’sperformancewhichisnot
covered under warranty.
DOOR AND GLASS
GASKET
If the door gasket requires replacement use
7/8"diameterovaldoorgasket(Part#650-920).
The glass requires 5/8" flat glass gasket. See
your Regency dealer.
Safety Screen: Only required in Australia

Regency FG38 FireGenie Freestanding Gas Stove 17
MAINTENANCE
FAN MAINTENANCE
Ifyourfanrequiresmaintenanceorreplacement,
access to the fan is through the access panel
on the rear wall of the firebox.
If the unit is damaged or needs repair, it shall
be repaired by the manufacturer or its service
agent or similiarly qualified person in order to
avoid a hazard.
Note: The unit MUST NOT be operated
withoutthefanaccesspanelsecurely
in place and correctly sealed.
IMPORTANT
Disconnect power supply
before servicing
IMPORTANT: These fans collect a
lot of dust from within your home.
Ensure you maintain these fan mo-
torsonaregularbasisbyvacuuming
out the fan squirrel cages, around
the motor, and around the grills on
the back of the stove.
Diagram 2
4) Lift fan off of the 2 pins, tip back and pull
through firebox opening. Disconnect the
green ground wire from the left side of the
fan as soon as you can reach it.
Diagram 1
WARNING: Electrical Grounding
Instructions This appliance is
equipped with a three pronged
(grounding)plugforyourprotection
against shock hazard and should
be plugged directly into a properly
grounded three-prong receptacle.
Donotcutorremovethegrounding
prong from this plug.
Installing Glass:
1) Install both center and side glass onto
aluminium extrusions as per diagram.
2) Place glass assembly into door frame.
3) Install retainers by placing 1 drop of glue
where previously glued and put in place.
4) Install side retainers.
5) Install door catch plate.
6) Install the 24 nuts loosely, do not tighten
yet.
7) Tightensidepanelsnutsusingthefollowing
procedure:
a. tightentop&bottomoutsidecornernuts
(2)
b. tighten inside nuts (3)
c. tighten top & bottom inside corners (2)
8) Tightenthe10nutsoncenterglassretainer.
9) Repeat step 7 for other side panel.
10) Replace new gasket by gluing it in place.
11) Install door onto stove and check the seal.
Replacing FG38 Fan:
Reverse the above steps (1 to 4). If necessary
install a new gasket before replacing the fan
access panel. Make sure the fan wires and the
ground wire are reattached.
To Remove FG38 Fan:
1) Unplugordisconnectpowersourcetostove.
2) Remove all logs and the rear log support,
then remove the 10 screws holding the ac-
cess panel in place, see Diagram 1. (Fan
is also accessible by opening the right side
door. See Diagram 2).
3) Unclip the black, red and white wires from
the fan motor.

18 Regency FG38 FireGenie Freestanding Gas Stove
4) Remove the two outside frame pieces by
removingtwoscrewsperside. Seediagram
below.
REMOVING VALVE
If your valve requires maintenance or replacement, follow these instructions:
NOTE: Always shut off the gas and
disconnect the power supply before
removing the valve.
1) Open the front door and carefully remove
the logs and lava rock.
2) Remove the burner by removing the two
1/4" hex head screws. See diagram below.
3) Open the front pedestal door and unhook
chain. You may want to put a soft cloth on
thebaseoftheunitsothatwhenthepedestal
doorisopenitdoesn'tscratchthepaint. See
diagram below.
5) Open the side pedestal door by unscrewing
the 2 Philips screws.
6) Disconnect the valve wires from the 9 pin
connector, located on the right side of the
connector.
Valvewiresconsistof2orange,1yellowand
2 purple colored wires.
MAINTENANCE
7) At this point you should disconnect the gas
at the valve.
8) Removethepedestalbackcoverbyremoving
the 4 Philips screws.
9) Disconnect the ground wires.
9 Pin Connector
10) Remove the eight 1/4" hex head screws
holding the burner tray assembly in place.
11) Carefully lift the burner tray assembly out.
Ground
Wires
12) Toreplacetheburnertrayassembly,simply
reverse these instructions.

Regency FG38 FireGenie Freestanding Gas Stove 19
910-936 910-082
910-088
910-089
910-084
910-527 / 910-935
910-080
910-521, 910-522, 910-523
910-912
910-906 910-083
910-922 910-514
PARTS LIST
ELECTRONIC COMPONENTS PARTS LIST
Note: Depending on the model, the diagram below may not be exactly as shown - for reference purposes only.
FG37 FG38 FG39 PG33 PG36 /
PG36D HG35 PG121/ PG131 IG35 IG34
910-909 Fan Resistor    
910-936 Intermittent Pilot N/A    
N/A 
910-082 Direct Spark Ignitor N/A N/A N/A N/A N/A N/A N/A
910-089 Flame Cable N/A N/A N/A N/A N/A N/A N/A
910-088 Spark Cable N/A N/A N/A N/A N/A N/A N/A
910-084 Control Box    
910-527 Manual Control Switch 
N/A N/A N/A N/A 
910-080 Valve    
910-521 Control Box Cable (1)
910-522 Control Box Cable (2)
910-523 Control Box Cable (3)
910-525 Control Box Cable (4)
(2) *N/A (2) (2) (1)
(4) (3) N/A* (2)
910-912 Ignition Module to
Valve Cable N/A N/A N/A  
910-906 Reset Switch N/A    
N/A 
910-083 Ignition Module (1)
910-922 Ignition Module (2) (2) (1)
(2) (2) (2) (2) (2) (2) (1) (2)
910-514 Jumper Wire N/A    
910-527 Manual Control Switch 
N/A N/A N/A N/A 
910-935 Manual Control Switch N/A N/A N/A  
**Note: The Control Box Cable wires for the FG38 come separately: 910-502, 910-505, 910-506, 910-507, 910-509
The Control Box Cable wires for the IG35 come separately: 910-530, 910-504, 910-528

20 Regency FG38 FireGenie Freestanding Gas Stove
PARTS LIST
MAIN ASSEMBLY
1) 560-920 Top / Bottom Gold Louvre (Set)
560-922 Top / Bottom Black Louvre (Set)
2) 750-532 Safety Screen (Australia only)
9) 750-040 Fan Access Door
10) 750-074 Gasket for Fan Access Door
560-519/P Fan Assembly
11) 910-169/P Fan Motor (240 Volt)
12) 910-714 Power Cord (240 Volt)
15) * Pedestal Assembly
16) 730-039 Pedestal Door
17) 904-257 Pedestal Door Magnet
18) 750-084 Pedestal Back
19) 756-518 Side Panel Door Assy (Right Side)
20) 756-520 Side Panel Door Assy (Left Side)
21) 560-031 Hinge for Side Panel
Part # Description Part # Description
23) 904-258 Side Panel Door Magnet
24) 948-255 Door Latch c/w Hook
25) 750-095 Door Hold Down Bracket
30) 750-026 Rear Panel
32) 730-028 Firebox Baffle
33) 560-535 False Top Assembly
34) 590-273 Flue Attachment Bracket
35) 590-930 Ult. 6" Flue Collar (Optional)
38) 820-058F Pedestal Base Cover
46) 750-083 Rear Control Panel
910-087 Switch Manual Control ECS c/w Wire Harness
756-969 Conversion Kit - to LPG
948-216 Logo Plate
918-243 Manual
*Not available as a replacement part.
