Reid boost User manual

OWNER'S PACK
@REIDBIKES

BUILD ME
Pages 1-10
RIDE ME
MAINTAIN ME
APP INTEGRATION
JOIN THE COMMUNITY
ENVIRONMENTAL PLEDGE
Pages 23-30
Pages 11-22
Pages 31-34
Pages 43-48
Pages 35-42

BUILD ME
1 2

This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or
metal capabilities or lack of experience and knowledge, if they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children without supervision.
1.
2. This manual can also be downloaded from the website: www.tomoloo.com
3. WARNING: For the purposes of recharging the battery, only use the detachable supply unit (model: FY-
0634201500) provided with this appliance.
4. When product is discarded:
(1) the battery must be removed from the appliance before it is scrapped;
(2) the appliance must be disconnected from the supply mains when removing the battery;
(3) the battery is to be disposed safely
5. This appliance contains batteries that are non-replaceable.
You quickly grasp the basic operating procedures and riding methods of your Reid Boost electric
scooter.
You familiarise yourself with safe driving rules for a safe and enjoyable scooter experience.
3. You understand the composition and safety of your Reid Boost electric scooter.
This manual applies to your Reid Boost electric scooter. Please read the manual carefully to ensure that:
1.
2.
If you have any questions or need more information, please visit www.reidbikes.com
Please pay attention to the following signs and relating content:
Dangers!
Could cause serious property damage or
personal injury
Warnings!
Improper operations can lead to the
malfunction of the product
Information tips
Version Number: A01 Original Instruction
About The Manual
3 4
BUILD ME

Components
User manual x1
Screw M5 x 5
Hex wrench M5 x1, M3 x 1
M5 M3
Charger adapter x1
*Please check carefully that the parts in the package are intact.
ComponentsWhat Comes In The Box
Throttle
Front light
Folding mechanism
Front fender
Motor
Dashboard
Folding hook
Brake lever
Silicone pedal
Tail lamp
Disc brake
Charging port
Ambient light
Kickstand
5 6
BUILD ME

Installation GuideControl Panel
Power switch
Bluetooth status Headlight status
Battery
Speed gear
Speed
Maximum mileage
Cruise control
Lock
Long press the power switch button to turn on the eScooter, also turning on the front light, ambient lighting, tail light and rear
brake light. The control panel shows the power and speed.
After turn on, the control panel display shows "1", indicating that the speed is 1st gear. Press the button to display 2nd gear;
the highest is 3rd gear.
Press the button twice to turn on the front light. Press the button twice again to turn it off.
Press the button three times to display the total mileage. Pressing the button three times again will display the speed.
When using the brake, the rear brake light will get brighter.
The battery bar at the top equates to the following: Five Bars = 100%, Four Bars = 80%, Three Bars = 60%, Two Bars = 40%
and One Bar = 20 %.
Use the control panel to control the scooter, the specific features are as follows:
1.
2.
3.
4.
5.
6.
Control Instructions:
Install the brakes to the correct position with the Hex wrench (M5 in the tool bag).1.
7 8
BUILD ME

3. Fasten the scooter standpipe and fold out the kickstand.
6. After the installation is complete, switch the scooter
on and off to check that the scooter is working properly.
2. Hold the scooter upright, to ensure that the lock will not be affected, please keep the folding-spanner
(the blue part of the image) at the bottom. Pull the folding-spanner to the top, then the scooter is completely locked.
4. Install the handlebar to the standpipe.
5. Use the hex wrench in the tool bag to lock the screws
on both sides.
9 10
BUILD ME

RIDE ME
11 12

Installation Guide
Your Reid eScooter is a sporting entertainment tool that is not a vehicle. If you drive it into a public area there
are multiple safety risks not just to yourself but also to others. Strictly follow the instructions in this manual, to
protect yours and others safety and to ensure compliance with national and provincial regulations and traffic
regulations. It is important to understand that if you decide to take your Reid eScooter on a public road or other
public place, you may be exposed to the risk of unauthorised driving / improper operation of your eScooter, even
if you are in full compliance with our safe driving guide. You must strictly follow the safety requirements of this
manual where there are no national standards and regulations for electric scooters. Reid shall not be liable for
any liability, personal injury, accident, legal dispute and all other unfavourable events resulting from the use of
violating the instructions indicated in this manual.
The faster the eScooter is driving, the longer the brakes need and on some smooth surfaces, using the left-hand
brake can cause the wheels to slip and lose balance or even fall. Therefore it is important to be vigilant and
maintain the proper speed during driving, whilst maintaining a reasonable safety distance to others. Please be
vigilant and drive at low speeds before entering unfamiliar terrain.
Do not lend your Reid eScooter to a person who has never ridden it before to avoid injury. If you do lend your
eScooter to someone, be sure to be responsible for the safety of them, you should teach them how to ride and
tell them of how to ride safely, wearing the right safety gear.
Please check your Reid eScooter every time before driving. If you find that parts are loose, the battery life is
minimum, the tyre is punctured of bare tread, or there is abnormal sound or malfunction, then please stop using
it immediately and do not force it to drive.
Charging Instructions
Open the rubber cap.
Insert the charging plug.
After charging is completed, close the rubber cap to prevent water penetration.
Charging takes 5-6 hours.
Safety Instructions
13 14
RIDE ME

How To Ride
*There are risks of falling and injury when riding, so
please wear a helmet and protective gear as shown in the
picture.
Turn on the power and check the power indicatior.1. 2. One foot stands on the deck, the other foot kicks
backward.
3.Once you have the electric scooter moving above
5km, putboth feet on the deck and push the throttle to
start the electric.
4. Releasing the throttle will slow you down gradually,
with an automatic energy recover system coming in.
For hard braking pull the lever on the left side.
5. When turning, you need to lean your body slightly
towards the direction you are turning and turn the
handle slowly.
6. Keep to one speed for approximately 8 seconds
to start the cruise control. When you release the
throttle ,this then means the speed will remain
unchanged. To cancel the cruise control, push the
throttle or operate the brakes.
15 16
RIDE ME

Riding Safely
Please avoid riding in
the rain.
Do not ride quickly over uneven surfaces. Keep
a speed between 5km/h and 10km/h and bend
your knees slightly to ensure maximum safety.
Do not ride throughdoorways. Do not accelerate downhill.
Do not press the throttle whilst
walking with the eScooter.
Avoid obstacles when driving.
Do not hang any heavy items on
the handlebar.
Keep both feet on the deck whilst
driving.
17 18
RIDE ME

Warning Reminder
Do not try to do any dangerous movements.
Forbidden to drive on the road or
in crowded residential areas.
Forbidden to rotate the handle strongly
while driving with high speed.
Forbidden to drive through water
deeper than 2cm.
Forbidden to drive the eScooter with
more than one person and/or holding
a child.
Forbidden to step or tread on the
back mudguard.
Forbidden to press the disc brake.
Forbidden to go up or down stairs or
to jump over barriers when driving.
Forbidden to drive without your hands
holding the handlebar.
19 20
RIDE ME

Fold Open
Put the safety-lock (the red part of the image) up whilst holding the steer tube. Then,
open up the folding spanner (the blue part of the image) and aim it at the bell and fender
hook. Next, buckle the belt with the back-fender.
Folding and Transportation
21 22
Transporting
After the e-scooter has been folded successfully, use one hand or two to hold the folding-level to transit.
RIDE ME

MAINTAIN ME
23 24

1. Do not use alcohol, gasoline, kerosene or other corrosive, volatile solvents to clean, otherwise it will seriously
damage the body and internal structure. It is forbidden to use a pressure fun spray and flush. Make sure that
the charging cable is unplugged and the rubber cap has been tightened when cleaning, otherwise it may cause
an electric shock or accident due to water intake.
2. Store you Reid eScooter in a dry and cool room as much as possible to avoid accelerating of ageing. Failure
to do so will reduce the usage life of the battery over time.
3. When the scooter is fully charged and not in use, it needs to be recharged every 3 months to avoid battery
over-discharge protection.
1. Do not use other brand of batteries, otherwise there may be security risks.
2. Do not touch the battery contacts and do not open the battery compartment. Any tampering of this may
cause a short circuit, potentially damaging the battery and causing personal injury.
3. Only use the original charger for charging, otherwise it may cause damage or a fire.
4. Inappropriate disposal of used batteries may result in serious environmental pollution. Disposal of waste
battery packs must be in accordance with local regulations.
Daily Maintenance
If there is a mark on the body of your Reid eScooter, wipe it with a small amount of water with a soft cloth. If it is
difficult to clean, you can use a toothbrush to brush it repeatedly then use a damp cloth to clean in. If the body
has plastic scratches, you can use sandpaper or other abrasive materials for polishing.
Electric scooter cleaning and storage
Note
Electric scooter battery maintenance
5. Do not place the battery in a high temperature environment higher than 50 °C or lower than -20 °C (for
example do not expose the eScooter or its battery pack to the car in summer)otherwise it may cause a
malfunction, or even a risk of fire. The ideal temperature for maximum mileage and performance is between 20°C
and 25°C and riding below 0°C will severely decrease battery life and performance. In some instance, at -20°C
the mileage may be only half or less than at optimal temperature.
Disc brakes debug
Note:
It is forbidden for non-professionals to remove the battery pack. Failure to do so may result in serious electrical
faults or safety short-circuits.
If you feel the brake is tight when you are riding, you can adjust the disc brake by loosening the screw on the
Rotary knob, with a M5 hex wrench (as shown in the picture below). Turn the Rotary knob slightly to the right and
tighten the screw with a M5 hex wrench. If you feel the brake is loose, you can turn the Rotary knob slightly to the
left, after loosening the screw on the Rotary knob with a M5 hex wrench and then tighten the screw.
M5
Rotary knob
Alternatively, take your electric scooter to the nearest service centre for adjustment.
25 26
MAINTAIN ME

Parameter Table
Data and parameters vary by mode. Subject to change without notice. Note:
Electric scooters are fully charged, load is 100kg, ambient temperature is 25°C without
wind, maximum speed is 25kph. However, the actual cruising range varies with driving
habit, roads, ambient temperature, wind speed and other factors.
Height:
The height of the body to the ground.
Endurance:
27 28
MAINTAIN ME

WARNING
1.To reduce the risk of injury, user must read the instructions manual.
2. Prolonged exposure to UV rays, rain and the elements may damage the enclosed materials.
3. Store indoors when not in use.
4. Risk of fire, no user serviceable parts
5. Use only with specified charger in instructions
Warranty
Your eScooter has a 1-year warranty from the date of purchase.
If you’re having an issue with your eScooter, we want to help resolve it. In the first instance, please contact
the store where you purchased the product. If you experience any difficulty settling a warranty claim with
your retailer, please contact us directly. Likewise, should anything feel loose or not right then please stop
using your product immediately and get in contact with the retailer you purchased it from or us directly.
Register you eScooter with us so we can quickly and easily verify your purchase for you warranty. Should
your eScooter ever be stolen, you can also get in touch with us to retrieve your serial number which is often
wanted by the authorities.
REGISTER YOUR ESCOOTER
Contact Us
@reidbikes
If you have any questions about the Reid Boost eScooter, we would be more than happy to answer
them. Please contact us at:
www.reidbikes.com/contactus/
29 30
MAINTAIN ME

APP INTEGRATON
31 32

APP Download Guide:
The Reid eMobility app is available to download in the App Store and Google Play. You can also scan
the QR code below to download and install the app.
Bluetooth password: 000000
Pairing Your eScooter
To pair your phone to your eScooter, please download the app and follow these instructions: Open the app,
select the model of your scooter, create and account with us and then click the Bluetooth button in the top left
hand corner of the main screen. Chose your device and enter the password: 000000, you are now connected.
33 34
APP INTEGRATON

JOIN THE COMMUNITY
35 36
