Reliance Controls The Home Protectors 11034 User manual

INSTALLATION
INSTALLATION
INSTALLATION
INSTALLATION
AND
AND
AND
AND
OPERATING
OPERATING
OPERATING
OPERATING
INSTRUCTIONS
INSTRUCTIONS
INSTRUCTIONS
INSTRUCTIONS
WIRELESS
WIRELESS
WIRELESS
WIRELESS
FREEZE
FREEZE
FREEZE
FREEZE
/
/
/
/
FLOOD
FLOOD
FLOOD
FLOOD
WARNING
WARNING
WARNING
WARNING
FLASHER
FLASHER
FLASHER
FLASHER
SYSTEM
SYSTEM
SYSTEM
SYSTEM
Model
Model
Model
Model
11034
11034
11034
11034

INSTALLING
INSTALLING
INSTALLING
INSTALLING
THE
THE
THE
THE
REMOTE
REMOTE
REMOTE
REMOTE
SENSING
SENSING
SENSING
SENSING
MONITOR
MONITOR
MONITOR
MONITOR
TRANSMITTER
TRANSMITTER
TRANSMITTER
TRANSMITTER
Place the ON / OFF switch in the “ off ” position.
Open the battery compartment on the back of the monitor.

Connect a new 9-volt battery to the battery terminals. Replace the
battery compartment cover.

Find the red and white transmitter code selector switch directly
above the battery compartment cover. All units come factory preset
for code 1. To avoid interfering with a neighbor ’ s unit, you may
choose to set your unit to a different transmitter code. Decide which
code you want to use, and select that code by pushing the
numbered switch AWAY from the number (toward the word “ ON ” ).
Note: only one code can be selected. If two or more switches are in
the “ on ” position, the unit will not function prope rly.

Connect the flood sensor probe to the monitor by plugging it into the
jack marked “ flood sensor ” . If the flood sensor feature is not being
used, the sensor need not be connected. Keep the sensor for
testing purposes.

Mount the transmitter in any convenient location. Make sure that
the flood sensor (if used) will reach the place to be monitored. The
transmitter can be mounted to a wall or other structure by hooking
the keyhole slot in the rear of the unit onto a nail or screw.
Position the flood sensor probe end at the place to be monitored.
The flood sensor activates when water touches BOTH of the two
silver contact buttons. The probe end can simply be laid on the
floor, hung in a sump crock, etc. It can also be mounted usi ng the
suction cup supplied with the sensor.
Place the ON / OFF switch in the “ on ” position. The remote sensing
monitor transmitter is now armed and ready.
BATTERY
BATTERY
BATTERY
BATTERY
LIFE
LIFE
LIFE
LIFE

Although batteries will normally last about six months or longer, it is
recommended to install new alkaline batteries every six months or
when leaving for an extended period.
IMPORTANT: As a reminder to the user, the receiver unit will begin
to flash when the batteries in the transmitter are low. It is
recommended to change batteries in both the transmitter and the
receiver alarm when this occurs.

SETTING
SETTING
SETTING
SETTING
UP
UP
UP
UP
THE
THE
THE
THE
FLASHING
FLASHING
FLASHING
FLASHING
STROBE
STROBE
STROBE
STROBE
ALERT
ALERT
ALERT
ALERT
RECEIVER
RECEIVER
RECEIVER
RECEIVER
Remove peel-off decal from flasher lens.
Place the ON / OFF switch in the “ off ” position.
Open the battery compartment on the back of the monitor.
Install three new “ AA ” batteries facing in the direction as shown on
the bottom of the battery compartment. Replace the cover. The
receiver will flash for up to 48 hours with fresh batteries.

Find the red and white transmitter code selector switch directly
above the battery compartment cover. Set this code switch to the
same code to which you set the remote sensing monitor.
Place the unit in a convenient location, no further than 120 feet from
the remote sensing monitor transmitter. Please note that walls,
metallic objects, etc may reduce the range.
oThe unit can be mounted to the inside of a window by
using the suction cup cradle supplied. Be sure the window
is clean and dry. Moisten the suction cups slightly with
water, glycerin, or petroleum jelly. Press the suction cups
to the window. The stro be alert receiver may now be
slipped into the cradle.
o
The cradle may be permanently installed to a window by
moistening the suction cups with cyanoacrylate ( “ super ” )
glue.
oThe unit can also be mounted to a wall or other structure
by hooking the keyhole slot in the rear of the unit onto a
nail or screw. .
Place the ON / OFF switch in the “ on ” position. The receiver is now
armed and ready.
TEST
TEST
TEST
TEST
Your 11034 system should be tested after installation. It is
programmed to check the alarm condition when it is first turned on
and then every 75 seconds thereafter to extend the battery life. To
avoid waiting the 75 seconds, place the flood sensor in water and
t hen turn on the units. If the receiver flashes and the transmitter
beeps, your unit is operating properly.

The transmitter and receiver must be reset by turning both units off
and then back on.
IMPORTANT
IMPORTANT
IMPORTANT
IMPORTANT
NOTE
NOTE
NOTE
NOTE
When the sensing monitor transmitter is triggered by low temperature or
water, it will emit a continuous sharp beeping sound. To reset the unit
and stop the beeping, turn the unit OFF and then ON. The transmitter
will not monitor the alarm condition(s) until this is done. Be sure to also
reset the receiver by turning it OFF and then ON.
OPTIONAL
OPTIONAL
OPTIONAL
OPTIONAL
DC
DC
DC
DC
POWER
POWER
POWER
POWER
SOURCE
SOURCE
SOURCE
SOURCE
You may choose to power your 11034 transmitter by using a 120 volt AC
power adapter instead of the internal 9V battery. This adapter can be
purchased separately from electronics stores, hobby shops, and
department stores.
Remote Sensing Monitor Transmitter Power Adapter
specifications
o120 volt AC input
o9 volt DC output
o200 mA output current (minimum)
o
3.5 mm plug
otip-positive configuration
ALERTING
ALERTING
ALERTING
ALERTING
SPECIFICATIONS
SPECIFICATIONS
SPECIFICATIONS
SPECIFICATIONS
Temperature alert : Activates when the transmitter reaches 40
o
F (4.5 C)
Water alert : Activates when water reaches both of the two silver contact
buttons.
TROUBLESHOOTING
TROUBLESHOOTING
TROUBLESHOOTING
TROUBLESHOOTING
Unit fails test

Make sure flood sensor probe is plugged into proper jack in
transmitter, and is immersed in water

Make sure transmitter is on

Make sure transmitter battery is properly installed
oIf AC adapter is used, make sure adapter is 9 volt DC,
with a minimum output of 200mA
Make sure receiver is on
Make sure receiver batteries are properly installed. Note
battery direction on inside of battery compartment

Make sure transmitter and receiver are set to the same code

Make sure only one code switch on each unit is in the “ on ”
position
Make sure the test was at least 75 seconds long since the unit
checks for the alarm condition every 75 seconds.
Flashing Strobe Alert Receiver flashes when there is no alert condition

Change the receiver and transmitter to a different transmit code .
The receiver may be picking up a signal from a neighbor.
Move the receiver to a different location. The receiver may be
picking up interference from a high powered radio frequency
source.

Battery in transmitter needs to be replaced.
Low battery light flashes
Battery is failing – replace battery
CAUTION
CAUTION
CAUTION
CAUTION
FCC Rules state that changes or modifications to the transmitter or
receiver could void your authority to operate these devices.

Warranty
Warranty
Warranty
Warranty
Reliance Controls Corporation warrants this product to be free from
defects in material and workmanship under normal use for a period of one
year from date of purchase, provided the product has been installed and
used in accordance with Reliance's instruc tions and has not been
subjected to misuse, alteration, modification, accident, or repair not
performed by Reliance. Reliance's obligation under this warranty is
strictly limited to repair or replacement of the product only. The cost of
labor to remove the product or install a replacement is not included in this
warranty. Reliance shall not be liable for any incidental, special, or
consequential damages whatsoever, including damage to person or
property resulting from the product's failure to operate i n the manner in
which it was designed. Use of this product is at the risk of the owner.
Reliance strongly recommends that this product be fully tested after
installation in accordance with these instructions to confirm proper
operation. In the event th at this product does not conform to this warranty
within the warranty period, the product may be returned with dated proof
of purchase to Reliance, at the address below, freight prepaid. Upon
verification of defect, Reliance shall at its sole discretion either repair or
replace the defective product. Batteries are not covered by this or any
warranty. The forgoing warranty is exclusive and in lieu of all other
expressed or implied warranties of merchantability and fitness for a
particular purpose. This warranty gives you specific legal rights, and you
may have other rights, which vary from state to state.

FCC
FCC
FCC
FCC
STATEMENT
STATEMENT
STATEMENT
STATEMENT
1. This device complies with Part 15 of the FCC Rules .
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received,
including interference that may cause undesired
operation.
2. Changes or modifications not expressly approved
by the party responsible for compliance could void the
user's authority to operate the equipment.
NOTE: This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installat ion.
This equipment generates uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there
is no guarantee that interference will not occu r in a
particular installation. If this equipment does cause
harmful interference to radio or television reception,
which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the
interference by one or more of th e following measures :
Reorient or relocate the receiving antenna.
Increase the separation between the equipment
and receiver.

Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV
technician for help.
2001 YOUNG COURT / RACINE, WI 53404 / [phone]
www.home-protectors.com
© Copyright 2004 Reliance Controls Corporation 5/27/10
