Q-See Home Security System User manual

A. OPERATION NOTICES ：
（ 1 ） Keep away from water;
（ 2 ） Don't touch CCD with fingers,if necessary clean
and remove dust with soft cloth dipped in alcohol;
（ 3 ） If you have questions or problems,please contact Q-see tech
support at [e-mail] or 877-998-3440.
P1 P2 P2P2 P3
B. OPERATION PROCEDURES:
（ 1 ） Remove the cap cover from top of camera.
（ 2 ） Remove C converter when using CS lens.
（ 3 ） Screw on the lens.
（ 4 ） Connect the camera to a monitor or recording
device with a 75Ωcoaxial cable.
（ 5 ） Connect the camera to 12V DC power transformer.
（ 6 ） Modify the focus of lens to get an excellent image
when image appears on the screen.
（ 7 ） If object does not focus properly,when modifying focal length, please
try the following ：
a Set the lens focal ring at unfixed.
b Focus on an object which is far
away from the camera.
c Adjust the lens and focal ring to focus the
object until you get a clear image.
d Tighten the lens fix screw.
INSTALLATION PRECAUTIONS ：
（ 1 ） Do not install the camera where it is aimed at a strong light.
（ 2 ） Do not install the camera in a place where temperature
goes above 60℃(140°F),or there is high humidity or rain
（ 3 ） Do not install the camera in a place where it is subjected to vibration
or impact from other devices
（ 4 ） Cover the CCD if the camera will not be in use for a long time.
Digital Color CCD Camera
MANUAL
This camera uses a highly sensitive CCD
and full solid-state circuitry. It offers long life,
high reliablity and excellent image with anti-
burn ability. It is not subject to distortion
caused by magnetic fields. Easy to install, it
is an excellent choice for CCTV.
IR Vandal-proof Dome CCD Camera
CCTV SYSTEM
www.q-see.com
A. OPERATION NOTICES ：
（ 1 ） Keep away from water;
（ 2 ） Don't touch CCD with fingers,if necessary clean
and remove dust with soft cloth dipped in alcohol;
（ 3 ） If you have questions or problems,please contact Q-see tech
support at [e-mail] or 877-998-3440.
（ b ） One monitor system with two or more cameras ：
（ a ） One monitor system with one camera ：
C. CONNECTION ：
CAMERA
DVR
D. DRAFT ：
E. SPECIFICATIONS ：
P1 P2 P2P2 P3
P5 P6P4
扫描系统
同 步系统
视频输出
白平衡
成像系 统
像素
水平解析度
信噪比
珈 玛
电子快门
最低照度
增益控制
Internal
Interlance 2:1
1.0Vp-p 750ΩBNC
ON/OFF
0.45
1.0Vp-p 75ΩBNC
On/Off
B. OPERATION PROCEDURES:
（ 1 ） Remove the cap cover from top of camera.
（ 2 ） Remove C converter when using CS lens.
（ 3 ） Screw on the lens.
（ 4 ） Connect the camera to a monitor or recording
device with a 75Ωcoaxial cable.
（ 5 ） Connect the camera to 12V DC power transformer.
（ 6 ） Modify the focus of lens to get an excellent image
when image appears on the screen.
（ 7 ） If object does not focus properly,when modifying focal length, please
try the following ：
a Set the lens focal ring at unfixed.
b Focus on an object which is far
away from the camera.
c Adjust the lens and focal ring to focus the
object until you get a clear image.
d Tighten the lens fix screw.
INSTALLATION PRECAUTIONS ：
（ 1 ） Do not install the camera where it is aimed at a strong light.
（ 2 ） Do not install the camera in a place where temperature
goes above 60℃(140°F),or there is high humidity or rain
（ 3 ） Do not install the camera in a place where it is subjected to vibration
or impact from other devices
（ 4 ） Cover the CCD if the camera will not be in use for a long time.
Digital Color CCD Camera
MANUAL
This camera uses a highly sensitive CCD
and full solid-state circuitry. It offers long life,
high reliablity and excellent image with anti-
burn ability. It is not subject to distortion
caused by magnetic fields. Easy to install, it
is an excellent choice for CCTV.
Scanning system
Sync System
Elect Shutter time
White Balance
Image Sensor
Picture Elements
Horizontal Resolution
S/N Ratio
Gamma
Video Output
Usable Illumination
Power Supply
Lens
Power Consumption
Operating Temp
AGC
Weight
Video monitor
AC ADAPTOR
CAMERA
Video monitor
AC ADAPTOR
IR Vandal-proof Dome CCD Camera
CCTV SYSTEM
NTSC: 752 582(H)
480TVL
1/3"SONY CCD
Internal
1/50s~1/100000s
ON/OFF
0.45
3mm~9mm
160mA
625g (22oz)
-20
℃
～ +60
℃
(-4°F to +140°F)
DC12V
≥50dB
0.5Lux/F1.2
Design and specification are subject
to change without prior notice.
Printed in Jul.2008
www.q-see.com
