RELM GPH Installation manual

Contents
INTRODUCTION................................................................................1
RADIO PROGRAMMING OPTIONS .................................................1
RADIO MODELS ...............................................................................1
ENTERING THE PROGRAMMING MODE........................................2
Portable Radios.........................................................................................2
Mobile Radios............................................................................................3
STANDARD RADIO KEYPAD PROGRAMMING..............................4
GENERAL SETTINGS (CHANNEL 0)...............................................4
Group Password........................................................................................5
Automatic Numeric Identication (ANI)......................................................5
Transmitter Time-Out Timer.......................................................................5
Scan Delay Time .......................................................................................6
Priority 1 Channel......................................................................................6
Priority 2 Channel......................................................................................7
Channel 0 Group One Functions...............................................................7
Channel 0 Group One Functions for Older Models ...................................9
Channel 0 Group Two Functions ...............................................................9
Channel 0 Group Three Functions ..........................................................11
Backlight Duration ...................................................................................12
Group Labels...........................................................................................13
CHANNEL SETTINGS.....................................................................14
Channel Bandwidth .................................................................................14
Receive Frequency..................................................................................14
Receive Mode (Digital Models Only).......................................................14
Receive Analog Code Guard...................................................................15
Receive NAC (Digital Models Only) .......................................................15
Squelch Mode (Digital Models Only) ......................................................16
Transmit Frequency.................................................................................17
Transmit Mode (Digital Models Only)......................................................17
Transmit Analog Code Guard ..................................................................17
Transmit NAC (Digital Models Only).......................................................18
Talk Group ID (Digital Models Only) ......................................................19
Secure Selection (Encrypted Radios Only)............................................. 19

Encryption Key (Encrypted Radios Only)................................................ 19
Key Selection Setting (Encrypted Digital Radios Only)...........................20
Channel Label .........................................................................................20
Review Channel Settings ........................................................................21
Program Another Channel.......................................................................21
Exit Programming Mode..........................................................................21
COMMAND (CMD) RADIO KEYPAD PROGRAMMING .................22
Group Parameters (CH 00) .....................................................................22
Channel Parameters................................................................................22
Global Parameters (GRP 00) ..................................................................22
NAVIGATION ...................................................................................23
Selecting Group Parameters ...................................................................23
Selecting Channel Parameters................................................................23
Selecting Global Parameters...................................................................23
Editing Parameters..................................................................................24
CMD GROUP PARAMETERS (CH 00) ...........................................24
Group Options Group One: 1-12345678 .................................................25
CMD GLOBAL PARAMETER OPTIONS (GRP 00) ........................26
Keypad Editing Password........................................................................26
Global Option Groups 1 and 2.................................................................26
Global Options Group One.................................................................26
Global Options Group Two.................................................................28
Automatic Number Identication ID (ANI)................................................29
Priority 1 Channel....................................................................................30
Priority 1 Group .......................................................................................30
Priority 2 Channel....................................................................................31
Priority 2 Group .......................................................................................31
Transmit on Priority 1 ..............................................................................31
Priority 1 Lock..........................................................................................32
Scan List Lock .........................................................................................32
Transmit Time-out Timer..........................................................................32
Scan Delay .............................................................................................33
Busy Channel Operation .........................................................................33
ANI/DTMF Operation...............................................................................33
Backlight Option ......................................................................................34
Backlight Duration ...................................................................................35
Silent Mode..............................................................................................35
Battery Save............................................................................................35

CHANNEL PARAMETERS..............................................................36
Channel Bandwidth ................................................................................36
Receive Frequency..................................................................................36
Receive Mode (Digital models only) .......................................................36
Receive Code Guard...............................................................................37
Receive NAC (Digital models only) ........................................................37
Squelch Mode (Digital models only) .......................................................38
Transmit Frequency.................................................................................38
Transmit Mode (Digital models only) ......................................................39
Transmit Guard........................................................................................39
Transmit NAC (Digital models only)........................................................39
Talk Group ID (Digital models only)........................................................40
Channel Label .........................................................................................41
CMD SPECIFIC PROGRAMMABLE ITEMS...................................42
Global Priority Channels Considerations.................................................42
User Selectable Code Guard Considerations..........................................42
User Selectable NAC and Talkgroup Considerations .............................42
Programming the Picklists ......................................................................42
CLONING RADIO SETTINGS .........................................................44
What Clones............................................................................................44
Using Standard Model as the Master ......................................................44
Using Command Model as the Master ....................................................46
CLONEABLE INFORMATION TABLES..........................................48
Radio Compatibility .................................................................................48
Older Models......................................................................................48
Standard Radio as Master .................................................................49
Command Radio as Master ...............................................................50
CTCSS CODE GUARD VALUES ....................................................51
CDCSS CODE GUARD VALUES....................................................52
CH00 AND GRP 00 QUICK REFERENCE GUIDE ........................53
NOTES.............................................................................................54

RELM Wireless Corporation 1
Introduction
This manual covers information used to program G-Series and D-Series
BK Radio models, both portables and mobiles, via the radio’s keypad.
Not all functions are available on all models. For instance, G-Series
radios are not capable of digital operation so functions pertaining to
digital operation will not appear when programming the radio.
In addition, the information in this manual can be referenced to program
older L-Series and E-Series radios.
Radio Programming Options
There are three different ways to program BK Radio radios:
KEYPAD - A radio can be programmed with it’s keypad and a
LAA0701 programming plug or cloning cable, LAA0700 or G/ECC.
This manual describes these procedures.
CLONING - You can transfer the programmed settings to another
radio of the same frequency band by using a cloning cable. See the
“Cloning Radio Settings” section of this manual.
PC - With a computer, proper programming software, and LAA 0725
interface cable. That procedure is not described in this manual.
Contact BK Radio for the required programming cable and software.
Radio Models
Instructions for keypad programming of the following models are covered
in this manual.
GPH Standard analog portable
GPH-XP Standard analog portable, extended frequency range
GPH-CMD Command analog portable
DPH Standard digital/analog portable
DPHX Standard digital/analog portable, extended frequency range
DPH-CMD Command digital/analog portable
GMH Standard analog mobile
GMH-XP Standard analog mobile, extended frequency range
DMH Standard digital/analog mobile, extended frequency range

2 BK Radio Programming Manual
Entering the Programming Mode
NOTE: Specic settings may be blocked from keypad programming
when using the Group or Zone password. Using the Master password
overrides these selections and allows for access to all programmable
functions.
Portable Radios
Make sure the battery pack is charged.
Some models are shipped with a door covering the keypad and display.
Before programming, remove the door by removing the battery pack,
engaging the door just below the speaker grill, and sliding the door
downward.
ch 01
Digital
-- -- id
Master Switch
Programming
Plug
Insert the programming plug into the side
connector of the radio. The push-button
master switch will be on the top.
NOTE: The cloning cable can be used
as a substitute for the programming plug
by inserting the end with the push-button
master switch into the side connector of the
radio.
Select a channel group to be programmed
See “Select A Group/Channel” in the
Owner’s Manual.
Press and hold the master switch.
While holding the master switch, press and hold the [FCN] key. After
approximately three seconds the LCD will display ‘- - - ID.’
Release the [FCN] key and the master switch. The radio is now in the
Password Entry Mode.
Enter the six-digit password code for the selected group. Without the
correct password code, you cannot proceed with programming.
NOTE: New radios shipped from the factory are assigned the
password code 000000.
CH 00
PRG
Press the [ENT] key to proceed to
Programming Mode. The display will change
to PRG CH 00.

RELM Wireless Corporation 3
While entering the password code the display will not change, but a
beep will sound for each key pressed. If the password code is entered
incorrectly, the radio will reset to normal operation.
Mobile Radios
SCNPRI SQL
ch 01
PRG PR TX RX SCN ID CG

MON GRP
G
R
P
Press to
Enter
Program
Mode
Select a channel group to be programmed
See “Select a Group/Channel” in the
Owner’s Manual.
Press and hold the [FCN] button on the
microphone and the far right soft switch on
the front of the radio simultaneously.
SCNPRI SQL
---- ID
PRG PR TX RX SCN ID CG

MON GRP
G
R
P
The radio is now in the Password Entry
Mode.
Enter the six-digit password code for the
selected group. Without the correct
password code, you cannot proceed with
programming.
SCNPRI SQL
CH 00
PRG PR TX RX SCN ID CG

MON GRP
G
R
P
Press the [ENT] key to proceed to
Programming Mode. The display will change
to PRG CH 00.
While entering the password code the display will not change, but a
beep will sound for each key pressed. If the password code is entered
incorrectly, the radio will reset to normal operation.

4 BK Radio Programming Manual
Standard Radio Keypad Programming
Portable Models: GPH, GPH Plus, DPH, DPHX
Mobile Models: GMH, GMH Plus, DMH
For CMD models, refer to the “Command Radio Keypad Programming”
section.
General Settings (Channel 0)
Channel 0 settings for each group must be programmed separately.
NOTE: Settings listed as Group One Functions, Group Two Functions,
and Group Three Functions refer to programming function groups, not
channel groups.
Press the [FCN] key repeatedly to view the settings in Channel 0 and
then loop back to the CH 00 entry point.
Group/Channel 0 Settings include:
Group Password
Automatic Numeric Identication
Transmitter Time-Out Timer
Scan Delay Time
Priority 1 Channel
Priority 2 Channel
Group One Functions: 1-12345
Battery Saver Inhibit (Function 1)
Group Scan List (Function 2)
Transmit on Priority 1 (Function 3)
Priority 1 Lock (Function 4)
Scan List Lock (Function 5)
Group Two Functions: 2-12345
User Code Guard (Function 1)
Busy Channel (Functions 2 & 3)
ANI/DTMF Mode (Functions 4 & 5)
Group Three Functions: 3-12345
Reserved (Functions 1 & 2)
Backlight Settings (Functions 3 & 4)
Display Mode (Functions 5)
Group Label

RELM Wireless Corporation 5
Group Password
ch 00
PRG
p 123456
PRG
After entering Programming Mode the
display will show ‘PRG CH 00.’
Press the [FCN] key.
The display will indicate the password for
the selected group.
If no change is needed for the group
password, press the [FCN] key to advance
to the next eld.
To enter a new password, press the [CLR] key, then enter a new six-
digit password. Press the [ENT] key to store the new password and
advance to the next eld.
Automatic Numeric Identication (ANI)
0000000
PRG ID After the group password is set, the display
will indicate the ANI ID number (as many as
seven digits may be used). The ID number
can be used for either radio management or
transmitted as a DTMF tone burst for ANI purposes. The ANI can be
enabled or disabled. See “ANI/DTMF Mode” on page 10 of this
manual.
If no change is needed for the ID number, press the [FCN] key to
advance to the next eld.
To enter a new number, press the [CLR] key and then the number
keys. The digits will appear at the right of display and move to the left.
Press the [ENT] key to store the new ID number and advance to the
next eld.
Transmitter Time-Out Timer
After the ID number is set, the display will indicate ‘PRG TX.’ This
is the duration of the transmitter Time-Out Timer. 0 SEC means the
Time-Out Timer is disabled.
Press the [FCN] key to advance to the next eld if no change is
needed.
225 sec
PRG TX Press the [PRI] key to increase the Time-Out
Timer duration by 15 seconds, with a
maximum of 225 seconds (3 minutes, 45
seconds). Press the [PRI] key again to
change the duration from 225 seconds to 0.

6 BK Radio Programming Manual
Press the [CLR] key to set the Time-Out Timer duration to zero.
Press the [ENT] key to store the changed setting and advance to the
next eld.
Scan Delay Time
After the Time-Out Timer is set, the upper display will indicate ‘PRG
SCN.’ This is the Scan Delay time in seconds.
Press the [FCN] key to advance to the next eld if no change is
needed.
2.0 SEC
PRG SCN Press the [PRI] key to increase the scan
delay time by .5 seconds, up to 7.5 seconds.
Press the [PRI] key again to change the time
from 7.5 seconds to 0.
Pressing the [CLR] key will reset the scan delay time to 0.
Press the [ENT] key to store the changed setting and advance to the
next eld.
Priority 1 Channel
After the Scan Delay is set, the display will indicate ‘PRG PR1.’ The
Priority 1 Channel can be programmed as a xed channel, tied to
the Channel Selector knob, or programmed OFF. If the radio is
programmed to transmit on the Priority 1 Channel, transmissions will
occur on PR1, if PR1 isn’t programmed OFF, when operating in Single
or Dual Priority Scan Mode.
If PR1 is a xed channel, and the [PRI] key on the keypad is not locked
out, during normal radio operation the user can move the channel
selector to a new channel and press the [PRI] key to choose a new
PR1 channel.
PR 1 ON
PRG Press the [PRI] key to cycle through the
priority channel options, or enter a xed
priority channel using the number keys.
Setting the channel to ON ties the PR1
channel to the Channel Selector knob. Pressing [CLR] or the [0] key
turns the PR1 channel OFF.
Press the [ENT] key to store the new priority channel and advance to
the next eld.
