MEGANE CABRIOLET NU 640-2 C:\Documentum\Checkout\nu640-2_eng_T1.WIN 24/2/2001 14:25 -page1
the driver's
handbook

QXBIUDB*T[G3DJH
MEGANE CABRIOLET NU 640-2 C:\Documentum\Checkout\nu640-2_eng_T1.WIN 24/2/2001 14:25 -page2
RENAULT
recommends
Forallpetrolengines,
LPG and multi-valve only.
ENGINE
MANUAL GEARBOX
AUTOMATIC GEARBOX
POWER STEERING
BRAKE FLUID
ELF ELITE Premier Plus 5W30
Fuel economy and protecting the environment.
Other types of lubricant approved by RENAULT
may be used in petrol or diesel engines:
ELF ULTIMATE 5W40
ELF ELITE Premier Plus 10W40
ELF ELITE Prestige 15W40
TRANSELF TRJ 75W80
RENAULTMATIC D3 SYN
RENAULTMATIC D2
FRELUB 650
Universal use
Standard use
Flexible driving
All types
All types
All types
All types
ACEA : A3/B3/B4
ACEA : A3/B3
ACEA : A2/B2
API : GL5
DEXRON III
DEXRON II
DOT 4
ACEA : A1/B1
(Performance
A3/B3/B4)
ELF recommends its lubricants as approved by RENAULT. For more information, go to www.elf-lub.com

QXBIUDB*T[G 3DJH 
MEGANE CABRIOLET NU 640-2 C:\Documentum\Checkout\nu640-2_eng_T1.WIN 24/2/2001 14:25 -page4
0.02
Brief overview
•Opening and closing the hood ........................................................... p. 3.02 ¬3.14
• Tyre inflation pressures ..................................................................................... p. 0.04
• Adjusting the seats and driving positions ......................................... p. 1.09 ¬1.13
• Child safety ............................................................................................ p. 1.21 ¬1.27
• Instrument panel lights ........................................................................ p. 1.32 ¬1.44
• Horn and lights ..................................................................................... p. 1.47 ¬1.50
• Demisting/de-icing ............................................................................................. p. 1.51
• Running in, driving .............................................................................. p. 2.02 ¬2.21
• Heating/air conditioning ...................................................................... p. 3.15 ¬3.23
• Opening the bonnet ............................................................................... p. 4.02 - 4.03
• Levels (engine oil, windscreen washer, etc.) ..................................... p. 4.04 ¬4.12
• Emergency spare wheel ........................................................................ p. 5.02 ¬5.05
• Practical advice (changing bulbs, fuses, repairs,
operating incidents) .............................................................................. p. 5.02 ¬5.35

QXBIUDB*T[G 3DJH 
MEGANE CABRIOLET NU 640-2 C:\Documentum\Checkout\nu640-2_eng_T1.WIN 24/2/2001 14:25 -page5
0.03
C O N T E N T S
Sections
1
2
3
4
5
6
7
Getting to know your car .....................................................................
Driving ...............................................................................................................
Your comfort .................................................................................................
Maintenance ..................................................................................................
Practical advice ...........................................................................................
Technical specifications ........................................................................
Alphabetical index ....................................................................................
Opening and closing the hood: pages3.02to3.14

QXBIUDB*T[G 3DJH 
MEGANE CABRIOLET NU 640-2 C:\Documentum\Checkout\nu640-2_eng_T1.WIN 24/2/2001 14:25 -page6
0.04
Tyre inflation pressures when cold (in bar)
Versions 1.4 l 16V 1.6 l 16V
2.0 l 2.0 l IDE
Type
(see vehicle identification plate)
EA10 - EAOD
EA1H - EAOW
EA11 - EA1Y
EAO4 - EAOB
EAOJ
EAOP
EAO3
Normal use
•Front 2.1 2.2 2.2
•Rear 2.0 2.0 2.1
Fully laden (1)
•Front 2.3 2.4 2.4
•Rear 2.2 2.2 2.3
Emergency spare wheel 2.3 2.4 2.4
Tyre
dimensions
175/65 R 14 T - 185/55 R 15 H -185/60 R 15 H
195/50 R 16 V
Wheel sizes 5.5 J 14 - 6.0 J 15 - 6.5 J 16
Tyre safety and use of chains
Refer to the information on tyres in section 5 for advice on tyre maintenance and, depending on the version, the use
of chains.
(1) Special note concerning vehicles used at full load (maximum permissible all-up weight and weight towed) and towing
atrailer
The maximum speed must be limited to 60 mph (100 km/h) and the tyre inflation pressure increased by 0.2 bar.
Refer to the information on “weights” in section 6 for more details.

QXBIUDB*T[G 3DJH 
MEGANE CABRIOLET NU 640-2 C:\Documentum\Checkout\nu640-2_eng_T1.WIN 24/2/2001 14:25 -page7
1.01
Section 1: Getting to know your car
Keys - Plip remote control unit .......................................................................................................... 1.02 ¬1.04
Doors ..................................................................................................................................................... 1.02 ¬1.06
Engine immobiliser system ................................................................................................................... 1.07 - 1.08
Head restraints - Seats ......................................................................................................................... 1.09 ¬1.11
Seat belts/Methods of restraint in addition to the front seat belts ................................................. 1.12 ¬1.20
Child safety ........................................................................................................................................... 1.21 ¬1.27
Driver’s layout ...................................................................................................................................... 1.28 ¬1.31
Instruments ........................................................................................................................................... 1.32 ¬1.42
Driving module (on-board computer) ................................................................................................ 1.40 ¬1.42
Clock and external temperature ........................................................................................................... 1.43 - 1.44
Rear-view mirrors - Steering wheel ..................................................................................................... 1.45 - 1.46
Audible and visible signals ............................................................................................................................. 1.47
Lighting and external signals .............................................................................................................. 1.48 ¬1.50
Headlight beam adjustment ............................................................................................................................. 1.50
De-icing - demisting ......................................................................................................................................... 1.51
Windscreen wipers - Windscreen washers ..................................................................................................... 1.52
Fuel tank (filling with fuel) .................................................................................................................. 1.53 - 1.54

1
QXBIUDB*T[G 3DJH 
MEGANE CABRIOLET NU 640-2 C:\Documentum\Checkout\nu640-2_eng_T1.WIN 24/2/2001 14:25 -page8
1.02
KEYS / REMOTE CONTROL DOOR LOCKS
1Radio frequency remote control
locking unit, ignition key, key for
doors, luggage compartment and
fuel filler flap. If there is a child (or
animal) in the car, never
leave it unattended with
the key in the ignition.
With the key in the ignition it
wouldbepossibletooperatethe
electrical equipment such as the
windows and there is a risk that the
child may be seriously injured (by
trapping his or her neck, arm,
hand, etc.).

1
2
QXBIUDB*T[G 3DJH 
MEGANE CABRIOLET NU 640-2 C:\Documentum\Checkout\nu640-2_eng_T1.WIN 24/2/2001 14:25 -page9
1.03
RADIO FREQUENCY REMOTE CONTROL DOOR LOCKING
Theplipremotecontrol1locks and
unlocks the doors.
It is supplied with power by a
battery which must be replaced
when the battery indicator light 2
no longer illuminates. (Refer to the
information on the plip remote
control batteries in section 5.
Locking/unlocking the doors
Press the plip remote control for
approximately one second to lock or
unlock the doors. (Light 2will
illuminate.)
- The hazard lights and side
repeaters flash twice to indicate
locking.
Note: If an opening (door or boot
lid) is incorrectly closed or
remains open or if a rear light has
remained in the “continuous
lighting” position (see “interior
lights” paragraph in section 3), the
hazard lights will not flash.
- The hazard lights and side
repeaters flash once to indicate
unlocking.
The range within which the
remote control will operate
This varies according to the
environment: therefore take care
when handling the remote control
that you do not inadvertently lock
or unlock the doors.
Note: On certain vehicles, if a door
is not opened within approximately
30 seconds of unlocking the door
using the remote control, the doors
will lock again automatically.

QXBIUDB*T[G 3DJH 
MEGANE CABRIOLET NU 640-2 C:\Documentum\Checkout\nu640-2_eng_T1.WIN 24/2/2001 14:25 -page10
1.04
RADIO FREQUENCY REMOTE CONTROL (continued)
Interference
Interference may be caused to the
operation of the remote control by
factors in the immediate vicinity
(external installations or the use of
equipment operating on the same
frequency as the remote control).
If you lose your keys or need
another set of keys (or a remote
control), contact your Renault
Dealer.
• If a key is replaced, it will be
necessary to take the vehicle to
your Renault Dealer because
both the vehicle and all the keys
are needed to initialise the
system.
•No more than four keys
(including the remote controls)
canbeusedononevehicle.
If the plip remote control will not
operate:
•Make sure that the batteries are
always in good condition - they
last for approximately two years.
• Check that the remote control is
correctly synchronised.
In both cases refer to the
information on the remote control
batteries in section 5.

1
2
31
QXBIUDB*T[G 3DJH 
MEGANE CABRIOLET NU 640-2 C:\Documentum\Checkout\nu640-2_eng_T1.WIN 24/2/2001 14:25 -page11
1.05
OPENING THE DOORS
Opening the doors from the
outside
Use the key to unlock one of the
front door locks 2. (Makesurethat
the key is inserted asfarasitwillgo
into the lock.) Place your hand
behind handle 1and pull it towards
you.
Opening the doors from inside
the car
Move handle 3.
“Lights on” warning buzzer
A warning buzzer will sound when
a door is opened if you have left the
lights switched on after switching
off the ignition (to prevent
discharge of the battery).
Electric central locking
This enables all the doors, the
luggage compartment and fuel flap
to be locked or unlocked
simultaneously.
Press the red spot on switch 1to
lock the doors.
The door cannot be locked if it is
open.
Unlock by pressing on the side
opposite the red spot on switch 1.
If you decide to keep the
doors locked when you
are driving, remember
that it may be more
difficult for those assisting you
to gain access to your vehicle in
the event of an emergency.

1
QXBIUDB*T[G 3DJH 
MEGANE CABRIOLET NU 640-2 C:\Documentum\Checkout\nu640-2_eng_T1.WIN 24/2/2001 14:25 -page12
1.06
AUTOMATIC LOCKING OF DOORS, ETC. WHEN DRIVING
You can decide if you wish to
activate the function.
To activate it
With the ignition on, press the
locking side (red dot) of the door
central locking button 1for
approximately 5 seconds until you
hear a beep.
To deactivate it
With the ignition on, press the
unlocking side (opposite the red
dot) of the door central locking
button 1for approximately 5
seconds until you hear a beep.
If you decide to keep the
doors locked when you
are driving, remember
that it may be more
difficult for those assisting you
to gain access to your vehicle in
the event of an emergency.
Operating principle
When the vehicle moves off, the
system automatically locks the
doors, etc. as soon as a speed of 4
mph (6 km/h) is attained.
Unlocking occurs automatically:
- if a front door is opened.
- by pressing the door unlocking
button 1.

1
QXBIUDB*T[G 3DJH 
MEGANE CABRIOLET NU 640-2 C:\Documentum\Checkout\nu640-2_eng_T1.WIN 24/2/2001 14:25 -page13
1.07
ENGINE IMMOBILISER
This prevents the vehicle being
driven by anyone not in possession
of the vehicle’s coded ignition key.
Any work or
modification to the
engine immobiliser
(computer, wiring, etc.)
may be dangerous. It must be
carried out by trained Renault
network personnel.
Operating principle
The vehicle is automatically
protected a few seconds after taking
the key out of the ignition.
When the ignition is switched on,
tell-tale light 1illuminates steadily
for a few seconds and then
extinguishes.
The vehicle has recognised the code
and the engine can be started.
If the vehicle does not recognise the
code of the ignition key, tell-tale
light 1flashes continuously and the
engine cannot be started.
Tell-tale light relating to the
engine immobiliser
• Vehicle protection tell-tale light
A few seconds after the ignition
has been switched off, tell-tale
light 1will flash continuously.
The vehicle will not be protected
until the key has been taken out of
the ignition.
•Tell-tale light to indicate the
engine immobiliser is operating
When the ignition has been
switched on, tell-tale light 1
illuminates steadily for a few
seconds and then extinguishes.
You can then start the engine.

2
1
QXBIUDB*T[G 3DJH 
MEGANE CABRIOLET NU 640-2 C:\Documentum\Checkout\nu640-2_eng_T1.WIN 24/2/2001 14:25 -page14
1.08
ENGINE IMMOBILISER (continued)
• Warning light to indicate that the
system is not operating correctly
After the ignition has been
switched on, if tell-tale light 1
continues to flash or remains
illuminated steadily, this
indicates that the system is not
operating correctly.
If tell-tale light 2flashes during a
journey when the vehicle is
slowing down or at idling speed,
it indicates that the system is not
operating correctly.
In all cases, it is essential to consult
a Renault Dealer as only he is
qualified to repair the engine
immobiliser.
If your coded ignition key is faulty,
use the second key (given to you
when the vehicle is delivered). If
you do not have access to this, it is
essential to call a Renault Dealer
because it is only dealers in the
Renault network who are qualified
to repair the engine immobiliser.

A
1
1
B
A
QXBIUDB*T[G 3DJH 
MEGANE CABRIOLET NU 640-2 C:\Documentum\Checkout\nu640-2_eng_T1.WIN 24/2/2001 14:25 -page15
1.09
HEAD RESTRAINTS
To raise or lower the head restraint
Pull the head restraint towards you
and slide it up or down at the same
time.
To remove the head restraint
Raise the head restraint until it is at
the highest possible setting. Lift up
tab 1and then pull the head
restraintupwardsuntilitis
released.
To adjust the angle of the head
restraint
On certain vehicles the angle of the
head restraint can be adjusted. To
do this, move the front section Aof
the head restraint forwards or
backwards until it feels
comfortable.
To refit the head restraint
Insert the rods into the sleeves, with
the notches facing the front.
Lower the head restraint until it
locks in position.
The head restraint is
important for safety.
Ensure that it is in place
and in the correct
position. The distance between
your head and the head restraint
should be as small as possible.
The top of the head should be in
line with the top of the head
restraint.

1
2
4
3
QXBIUDB*T[G 3DJH 
MEGANE CABRIOLET NU 640-2 C:\Documentum\Checkout\nu640-2_eng_T1.WIN 24/2/2001 14:25 -page16
1.10
FRONT SEATS
To move forwards or backwards:
Lift lever 2to unlock the seat.
Release the lever in the required
position and ensure that the seat
is locked in place.
To raise or lower the driver's
seat:
Move lever 1.
To incline the seatback:
Move lever 4and tilt the seatback
until it is in the required position.
To adjust the lumbar support of the
driver’s seat
Turn tumblewheel 3.
For safety reasons, only
adjust the seats when the
vehicle is stationary.
So that the effectiveness of
the seat belts is not
reduced, we would advise
you not to recline the
seatbacks excessively.
Make sure the seatback is locked in
place correctly.
No objects should be placed on the
floor (area in front of driver) as
such objects may slide under the
pedal during braking manoeuvres,
thus obstructing its use.

5
6
QXBIUDB*T[G 3DJH 
MEGANE CABRIOLET NU 640-2 C:\Documentum\Checkout\nu640-2_eng_T1.WIN 24/2/2001 14:25 -page17
1.11
FRONT SEATS (continued)
Access to the rear seats
Lift handle 5and tilt the seatback
forwards.
To return the seat to its initial
position, move the seatback into an
upright position until it locks in
place.
Adjust the seat and make sure it is
properly locked in position.
Heated seats
With the ignition on, press switch 6.
An indicator light will illuminate
on the instrument panel.
If the tell-tale light is illuminated,
the system is not necessarily
activated. The system has a
thermostat and only operates
when the passenger compartment
temperature is less than 12°C (with
a tolerance of plus or minus 4°C).

1
2
QXBIUDB*T[G 3DJH 
MEGANE CABRIOLET NU 640-2 C:\Documentum\Checkout\nu640-2_eng_T1.WIN 24/2/2001 14:25 -page18
1.12
SEAT BELTS
Always wear your seat belt when
travelling in your car. You must also
comply with the local legislation in
the particular country you are in.
Before driving off:
- First ensure that your driving
position is correct.
- Then adjust your seat belt to
provide maximum protection.
Incorrectly adjusted seat
belts may cause injuries
in the event of an
accident.
Even pregnant women should
wear a seat belt. In this case,
ensure that the pressure of the
lap belt on the abdomen is not
excessive.
Adjusting your driving position
• Sit with your back firmly against
the seatback. This is essential to
ensure that your lumbar vertebrae
are in the correct position.
•Adjust the distance between the
seat and the pedals. Your seat
should be as far back as possible
for you to be able to press in the
clutch pedal fully. The seatback
should be adjusted so that your
arms are slightly bent when you
hold the steering wheel.
•Adjust the position of your head
restraint. For maximum safety
yourheadshouldbeasnearas
possible to the head restraint.
•Adjusttheheightoftheseat.This
adjustment allows you to select
the seat position which offers you
the best possible vision.
•Adjust the position of the steering
wheel.
Adjusting the seat belts
Sit with your back firmly against the
seatback.
The shoulder strap 1should be as
close to the base of the neck as
possible but not on it.
The lap strap 2should be held
firmly over the thighs and against
the pelvis.
Thebeltshouldbewornsothatitis
as close to the body as possible, i.e.
avoid wearing heavy clothing or
having bulky objects under the
belts.

5
4
5
3
QXBIUDB*T[G 3DJH 
MEGANE CABRIOLET NU 640-2 C:\Documentum\Checkout\nu640-2_eng_T1.WIN 24/2/2001 14:25 -page19
1.13
SEAT BELTS (continued)
To fasten
Unwind the belt slowly and
smoothly and ensure the buckle 3
locks into the catch 5(check it is
locked by pulling on the buckle 3).
If the belt jams, allow it to return
slightly before attempting to
unwind it again.
To fasten (continued)
If your belt becomes completely
jammed:
- Pull the belt slowly but firmly so
that just over an inch (3 cm)
unwinds.
- Then allow the belt to rewind
automatically.
-Unwinditagain.
- If the problem persists, consult
your Renault Dealer.
To release
Press button 4on the catch 5and the
seat belt will be returned by the
inertia reel.
Hold the buckle to help the
operation.

QXBIUDB*T[G 3DJH 
MEGANE CABRIOLET NU 640-2 C:\Documentum\Checkout\nu640-2_eng_T1.WIN 24/2/2001 14:25 -page20
1.14
SEAT BELTS
The following information applies to both the vehicle’s front and rear seat belts.
• No modifications may be made to the component parts of the restraint system (belts and seats and their
mountings) fitted originally.
For special applications (e.g. fitting child seats) consult your Renault Dealer.
• Do not use any devices which give any play in the belts (clothes pegs, clips, for example). A seat belt that is worn too
loosely may cause injuries in the event of an accident.
• Never wear the shoulder strap under your arm or behind your back.
• Do not use the same belt for more than one person and never hold a baby or child on your knees with your seat belt
around them.
• The belt should never be twisted.
• Following a serious accident the seat belts in use at the time must be replaced. Likewise, have your seat belts replaced
as soon as they show any signs of wear.
• When refitting the rear bench seat, take care that the seat belts are correctly positioned so that they can be used
properly.
• If necessary, re-adjust the position and tension of the belt.

1
QXBIUDB*T[G 3DJH 
MEGANE CABRIOLET NU 640-2 C:\Documentum\Checkout\nu640-2_eng_T1.WIN 24/2/2001 14:25 -page21
1.15
METHODS OF RESTRAINT IN ADDITION TO THE FRONT SEAT BELTS
These are:
OFrontseatbeltpretensioners
OForce limiter
OAir bags for driver and front
passenger
Thesesystemsareprovidedtoact
independently or together when the
vehicle is subjected to a frontal
impact.
There are three possibilities,
depending on the force of the
impact:
- protection is provided by the belt
only;
- the pretensioner is triggered to
rectify belt position and play;
- if the air bag and force limiter are
triggered, they provide additional
protection in the event of the most
severe impact.
OSide air bags
are provided to activate in the
event of a severe side impact.
Frontseatbeltpretensioners
This system is only operational
when the ignition is switched on.
If the vehicle is subject to a
severe frontal impact, piston 1
immediately retracts the seat belt
buckle pulling the seat belt tight
against the body and thereby
improving its efficiency.
•Have the entire restraint
system checked following
an accident.
• No work whatsoever may be
performed on the pretensioner
system (computer, wiring, etc.).
• To avoid incorrect triggering of
the system which may cause
injury, only qualified Renault
Network personnel may work on
the pretensioner system.
• Testing of the electric trigger
system may only be carried
out by a specially trained
technician using special
equipment.
• When scrapping your vehicle,
contact your Renault Dealer for
disposal of the gas generator.
