Renesas H8S/2138 Series User manual

H8S/2138 Series
TQFP-80C
User System Interface Cable
(HS2138ECN61H)
for E6000 Emulator
User’s Manual
HS2138ECN61HE(C)

Cautions
1. Renesas neither warrants nor grants licenses of any rights of Renesas’s or any third party’s
patent, copyright, trademark, or other intellectual property rights for information contained in
this document. Renesas bears no responsibility for problems that may arise with third party’s
rights, including intellectual propertyrights, in connection with use of the information contained
in this document.
2. Products and product specifications may be subject to change without notice. Confirm that you
have received the latest product standards or specifications before final design, purchase or use.
3. Renesas makes every attempt to ensure that its products are of high quality and reliability.
However, contact Renesas’s sales office before using the product in an application that demands
especially high quality and reliability or where its failure or malfunction may directly threaten
human life or cause risk of bodily injury, such as aerospace, aeronautics, nuclear power,
combustion control, transportation, traffic, safety equipment or medical equipment for life
support.
4. Design your application so that the product is used within the ranges guaranteed by Renesas
particularly for maximum rating, operating supply voltage range, heat radiation characteristics,
installation conditions and other characteristics. Renesas bears no responsibility for failure or
damage when used beyond the guaranteed ranges. Even within the guaranteed ranges, consider
normally foreseeable failure rates or failure modes in semiconductor devices and employ
systemic measures such as fail-safes, so that the equipment incorporating Renesas product does
not cause bodily injury, fire or other consequential damage due to operation of the Renesas
product.
5. This product is not designed to be radiation resistant.
6. No one is permitted to reproduce or duplicate, in any form, the whole or part of this document
without written approval from Renesas.
7. Contact Renesas’s sales office for any questions regarding this document or Renesas
semiconductor products.

i
Preface
Thank you for purchasing this user system interface cable (HS2138ECN61H) for the Renesas’s
original microcomputer H8S/2138 series.
The HS2138ECN61H is a user system interface cable that connects an H8S/2148, H8S/2138,
H8S/2128 series E6000 emulator (HS2148EPI61H; hereinafter referred to as the emulator) to the IC
socket for a TQFP-80C package (package code: TFP-80C) for the H8S/2138 series MCU on the
user system.

ii
Contents
Section 1 Configuration....................................................................................1
Section 2 Connection Procedures......................................................................4
2.1 Connecting User System Interface Cable to Emulator Station .........................................4
2.2 Connecting User System Interface Cable to User System................................................5
2.2.1 Installing IC Socket .............................................................................................5
2.2.2 Soldering IC Socket.............................................................................................5
2.2.3 Inserting Cable Head ...........................................................................................5
2.2.4 Fastening Cable Head..........................................................................................6
2.2.5 Connecting Cable Body to Cable Head ...............................................................8
2.3 Recommended Dimensions for User System Mount Pad.................................................9
2.4 Dimensions for User System Interface Cable Head..........................................................10
2.5 Resulting Dimensions after Connecting User System Interface Cable.............................11
Section 3 Installing the MCU to the User System.............................................12
Section 4 Verifying Operation...........................................................................14
Section 5 Notice ................................................................................................15

1
Section 1 Configuration
CAUTION
Use an IC149-080-058-B51 socket (manufactured by
YAMAICHI ELECTRONICS Co., Ltd.) for the TFP-80C
package IC socket on the user system.
Figure 1 shows the configuration of the HS2138ECN61H user system interface cable for the
TFP-80C package.

2
(for fastening cable head)
User system
IC socket
Cable head
Screws (M2.6 x 12 mm)
with flat washers
Screws (M2.6 x 8 mm)
with flat washers
Socket cover
To emulator station
Cable body
Figure 1 HS2138ECN61H User System Interface Cable

3
Table 1 lists the HS2138ECN61H components. Please make sure you have all of these components
when unpacking.
Table 1 HS2138ECN61H Components
No. Component Quantity Remarks
1 Cable body 1 Includes flat cable
2 Cable head 1
3 IC socket 1 For the TFP-80C package
4 Socket cover 1 For installing an TFP-80C packaged MCU
5 Screws (M2.6 x 12 mm) 4 For fastening cable head (with four flat washers)
6 Screws (M2.6 x 8 mm) 4 For installing an TFP-80C packaged MCU (with
four flat washers)
7 Documentation 1 User’s manual for HS2138ECN61H (this manual)

Section 2 Connection Procedures
2.1 Connecting User System Interface Cable to Emulator Station
WARNING
Always switch OFF the user system and the emulator
product before the USER SYSTEM INTERFACE CABLE
is connected to or removed from any part. Before connecting,
make sure that pin 1 on both sides are correctly aligned. Failure to
do so will damage the user system and the emulator product or will
result in PERSONAL INJURY. The USER PROGRAM will be
LOST.
To connect the cable body to the emulator station, follow the instructions below.
1. Make sure the user system and emulator station are turned off.
2. After making sure the direction of the cable body connector is correct, firmly insert the cable
body connector into the emulator station socket (figure 2).
6000
Emulator station
E
Cable body
User system interface cable
Figure 2 Connecting User System Interface Cable to Emulator Station
4

2.2 Connecting User System Interface Cable to User System
WARNING
Always switch OFF the user system and the emulator
product before the USER SYSTEM INTERFACE CABLE
is connected to or removed from any part. Before connecting,
make sure that pin 1 on both sides are correctly aligned. Failure to
do so will damage the user system and the emulator product or will
result in PERSONAL INJURY. The USER PROGRAM will be
LOST.
To connect the cable head to the user system, follow the instructions below.
2.2.1 Installing IC Socket
After checking the location of pin 1 on the IC socket, apply epoxy resin adhesive to the bottom of
the IC socket for an TFP-80C package, and fasten it to the user system before soldering.
2.2.2 Soldering IC Socket
After fastening, solder the IC socket for an TFP-80C package to the user system. Be sure to
completely solder the leads so that the solder slops gently over the leads and forms solder fillets.
(Use slightly more solder than the MCU.)
2.2.3 Inserting Cable Head
CAUTION
Check the location of pin 1 before inserting.
Align pin 1 on the IC socket for an TFP-80C package on the user system with pin 1 on the user
system interface cable head, and insert the user systeminterface cable head into the IC socket on the
user system, as shown in figure 3.
5

6
2.2.4 Fastening Cable Head
CAUTION
1. Use a Phillips-type screwdriver whose head matches
the screw head.
2. The tightening torque must be 0.294 N•m or less.
If the applied torque cannot be accurately measured,
stop tightening when the force required to turn the screw
becomes significantly greater than that needed when first
tightening. If a screw is tightened too much, the screw
head may break or an IC socket contact error may be caused
by a crack in the IC socket solder.
3. If the emulator does not operate correctly, cracks might
have occurred in the solder. Check conduction with
a tester and re-solder the IC socket if necessary.
Fasten the user system interface cable head to the IC socket for an TFP-80C package on the user
system with the four screws (M2.6 x12 mm; with four flat washers) provided. Each screw should
be tightened a little at a time, alternating between screws on opposing corners. Take special care,
such as manually securing the IC socket soldered area, to prevent the soldered IC socket from being
damaged by overtightening the screws or twisting the components.

Cable head
User system
IC socket
(IC149-080-058-B51 manufactured by
YAMAICHI ELECTRONICS Co. Ltd.)
Screws (M2.6 x 12 mm), flat washer
Pin 1
Figure 3 Connecting User System Interface Cable to User System
7

2.2.5 Connecting Cable Body to Cable Head
Connect the cable body to the cable head.
Cable body
Cable head
Remove jig
Push the remove jig
Removing
User system
Figure 4 Fastening Cable Body
8

2.3 Recommended Dimensions for User System Mount Pad
Figure 5 shows the recommended dimensions for the mount pad (footprint) for the user system with
an IC socket for an TFP-80C package (IC149-080-058-B51: manufactured by YAMAICHI
ELECTRONICS Co., Ltd.). Note that the dimensions in figure 5 are somewhat different from those
of the actual chip's mount pad.
9
Unit: mm
0.50
0.05 0.30
0.05
0.50
19 = 9.50 0.05
0.50
19 = 9.50
0.05
11.80 (max.)
15.10 (min.)
0.50
0.05
Figure 5 Recommended Dimensions for Mount Pad

2.4 Dimensions for User System Interface Cable Head
The dimensions for the user system interface cable head are shown in figure 6.
Unit: mm
Tolerance: –0.5 mm
Figure 6 Dimensions for User System Interface Cable Head
10

2.5 Resulting Dimensions after Connecting User System Interface Cable
The resulting dimensions, after connecting the user system interface cable head to the user system,
are shown in figure 7.
Cable head
User system Unit: mm
Tolerance: –0.5 mm
IC socket
(IC149-080-058-B51
manufactured by
YAMAICHI ELECTRONICS Co. Ltd.)
Figure 7 Resulting Dimensions after Connecting User System Interface Cable
11

12
Section 3 Installing the MCU to the User System
CAUTION
1. Check the location of pin 1 before inserting.
2. Use a Phillips-type screwdriver whose head matches
the screw head.
3. The tightening torque must be 0.294 N•m or less.
If the applied torque cannot be accurately measured,
stop tightening when the force required to turn the screw
becomes significantly greater than that needed when first
tightening. If a screw is tightened too much, the screw
head may break or an IC socket contact error may be caused
by a crack in the IC socket solder.
4. If the MCU does not operate correctly, cracks might have
occurred in the solder. Check conduction with a tester
and re-solder the IC socket if necessary.
Check the location of pin 1 before inserting the MCU into the IC socket on the user system, as
shown in figure 8. After inserting the MCU, fasten the socket cover with the provided four screws
(M2.6 x8 mm; with four flat washers). Take special care, such as manually securing the IC socket
soldered area, to preventthe IC socketfrom being damaged by overtightening the screws or twisting
the components.

MCU
Pin 1
IC socket
(IC149-080-058-B51
manufactured by
YAMAICHI ELECTRONICS Co., Ltd.)
User system
Screws (M2.6 x 8 mm)
with flat washers
Socket cover
Figure 8 Installing MCU to User System
13

Section 4 Verifying Operation
1. When using the E6000 emulator (HS2148EPI61H) for the H8S/2148, H8S/2138, H8S/2128
series, turn on the emulator according to the procedures described in the H8S Series E6000
Emulator User's Manual (HS2000EPI61HE).
2. Verify the user system interface cable connections by accessing the external memory and ports
to check the bus states of the pins with the MEMORY_FILL command (emulator command). If
an error is detected, recheck the soldered IC socket and the location of pin 1.
3. The emulator connected to this user system interface cable supports two kinds of clock sources
as the MCU clock: an emulator internal clock and an external clock on the user system. For
details, refer to the H8S series E6000 Emulator User's Manual (HS2000EPI61HE).
 To use the emulator internal clock
Select the clock in the emulator station as the system clock (φ), by using the CLOCK
command (emulator command).
 To use the external clock on the user system
Supply the external clock from the user system to the emulator. Connect a crystal oscillator
to the EXTAL and XTAL terminals for the system clock (φ). Select the external clock as the
system clock (φ), by using the CLOCK command (emulator command). For details, refer to
section 22, Clock Pulse Generator, in the H8S/2138 Series, H8S/2134 Series Hardware
Manual.
Figure 9 shows the oscillator circuit on the user system interface cable.
R1 1 MΩ
Ω
R2 270
HCU04HCU04
To E6000
emulator
XTALEXTAL
System clock
Figure 9 Oscillator Circuit
14

Section 5 Notice
1. Make sure that pin 1 on the user system IC socket is correctly aligned with pin 1 on the cable
head before inserting the cable head into the user system IC socket.
2. The dimensions of the recommended mount pad for the user system IC socket are different from
those of the MCU.
3. This user system interface cable is specifically designed for the HS2148EPI61H emulator. Do
not use this cable with any other emulator station.
4. To prevent breaking of wires in the cable body, do not place heavy or sharp metal objects on the
user system interface cable.
5. While the emulator station is connected to the user system with the user system interface cable,
force must not be applied to the cable head. Place the emulator station, user system interface
cable, and user system as shown in the example in figure 10.
User system
Cable
Emulator station
Place components so that the cable body and cable head are
parallel to the user system.
Cable head is parallel
to emulator station
Cable head is parallel
to user system
Figure 10 User System Interface Cable Location Example
6. The JP1 short connector is used for testing. Do not remove the short pins that are inserted in the
sides of pin 1 and pin 2.
JP1
Figure 11 JP1 Short Connector
15
