RH850 Evaluation Platform
RH850/F1x-176pin
User’s Manual: Piggyback Board V4
Y-RH850-F1X-176PIN-PB-T1-V4
Rev. 1.20 August 12, 2021
32
User´s Manual

Table of Contents
CHAPTER 1 INTRODUCTION .............................................................................................................................. 5
1.1 PACKAGE COMPONENTS ........................................................................................................................................6
CHAPTER 2 OVERVIEW ...................................................................................................................................... 7
2.1 OVERVIEW ..........................................................................................................................................................7
2.2 MOUNTING OF THE DEVICE.....................................................................................................................................7
CHAPTER 3 JUMPER CONFIGURATION .............................................................................................................. 9
CHAPTER 4 POWER SUPPLY............................................................................................................................. 11
4.1 BOARD POWER CONNECTION ................................................................................................................................11
4.2 VOLTAGE DISTRIBUTION.......................................................................................................................................12
CHAPTER 5 CLOCK SOURCES............................................................................................................................ 13
5.1 MAINOSC .........................................................................................................................................................13
5.2 SUBOSC...........................................................................................................................................................13
CHAPTER 6 DEBUG AND PROGRAMMING INTERFACE ..................................................................................... 14
CHAPTER 7 CONNECTORS FOR PORTS OF DEVICE............................................................................................ 15
CHAPTER 8 CONNECTORS TO MAINBOARD..................................................................................................... 16
8.1 CONNECTOR CN1 ..............................................................................................................................................16
8.2 CONNECTOR CN2 ..............................................................................................................................................18
8.3 CONNECTOR CN3 ..............................................................................................................................................20
CHAPTER 9 OTHER CIRCUITRY ......................................................................................................................... 22
9.1 PUSH BUTTON FOR RESET ...................................................................................................................................22
9.2 MODE SELECTION...............................................................................................................................................22
9.3 SIGNALLING LEDS...............................................................................................................................................23
CHAPTER 10 DIFFERENCES TO THE -T1-V3 BOARD ........................................................................................ 24
CHAPTER 11 MECHANICAL DIMENSIONS ...................................................................................................... 26
CHAPTER 12 SCHEMATIC .............................................................................................................................. 27
CHAPTER 13 REVISION HISTORY ................................................................................................................... 31

RH850/F1x-176pin Piggyback board V4 Y-RH850-F1X-176PIN-PB-T1-V4
R20UT4148ED0120 Rev. 1.20 5
August 12, 2021
Chapter 1 Introduction
The RH850/F1x Application Board is part of the RH850 Evaluation Platform and
serves as a simple and easy to use platform for evaluating the features and
performance of Renesas Electronics 32-bit RH850/F1x microcontrollers. The
piggyback board (Y-RH850-F1X-176PIN-PB-T1-V4) can be used as a standalone
board, or can be mated with a mainboard (e.g. Y-RH850-X1X-MB-Tx-Vx) for
extended functionality.
Main features:
•Socket for mounting of device
•Standalone operation of the board
•Direct supply of device voltage (typ. 3.3V-5.0V)
•Device programming capability
•Device debugging capability
•Pin headers for direct access to each device pin
•Reset switch
•MainOSC and SubOSC circuitry
•Signal LEDs
•Jumpers for device mode selection
•Connectors to mainboard
This document describes the functionality provided by the piggyback board and
guides the user through its operation.
For details regarding the operation of the microcontroller, refer to the related
User’s Manual and Datasheet.
This manual describes the following board revision:
•Y-RH850-F1X-176PIN-PB-T1-V4
The main difference to the previous board revision (Y-RH850-F1X-176PIN-PB-
T1-V3) are:
•Added support for the RH850/F1KH-D8 device.
(Especially see the Note in chapter 4.2 for the configuration of the
REGnVCC voltage.)
•Modified port assignments on connectors to mainboard (CN1 to CN3)
See the Chapter 10 for further details on the differences to the previous board
version.

RH850/F1x-176pin Piggyback board V4 Y-RH850-F1X-176PIN-PB-T1-V4
R20UT4148ED0120 Rev. 1.20 6
August 12, 2021
1.1 Package Components
The Y-RH850-F1X-176PIN-PB-T1-V4 product package consists of the items
included in below table. After you have unpacked the box, check if your Y-
RH850-F1X-176PIN-PB-T1-V4 package contains all these items.
Item
Description
Quantity
D015801#01
RH850/F1x 176pin
piggyback board
1
D015803
Documentation CD
1
D010816-24
China RoHS document
1
D015800-24
Product contents List
1
Jumpers (2-way, 0.1”)
In the bag
45
Red Hirschmann 4 mm
power lab sockets
In the bag
2
Black Hirschmann 4 mm
power lab sockets
In the bag
1
Crystal, TC38, 32.768 kHz
In the bag
1
Crystal, HC49, 8 MHz
In the bag
1
Crystal, HC49, 20 MHz
In the bag
1
Note: Please keep the Y-RH850-F1X-176PIN-PB-T1-V4 packing box at
hand for later reuse in sending the product for repairs or for other
purposes. Always use the original packing box when transporting the Y-
RH850-F1X-176PIN-PB-T1-V4. If packing of your product is not complete,
it may be damaged during transportation.

RH850/F1x-176pin Piggyback board V4 Y-RH850-F1X-176PIN-PB-T1-V4
R20UT4148ED0120 Rev. 1.20 7
August 12, 2021
Chapter 2 Overview
2.1 Overview
Figures 1 and 2 provide the views of the piggyback board.
Figure 1 –Piggyback board top view
Figure 2 –Piggyback board bottom view
2.2 Mounting of the device
The board is designed for use with the following devices (each in the 176pin
package version):
Device pin #1

RH850/F1x-176pin Piggyback board V4 Y-RH850-F1X-176PIN-PB-T1-V4
R20UT4148ED0120 Rev. 1.20 8
August 12, 2021
•RH850/F1L
•RH850/F1M
•RH850/F1H
•RH850/F1K
•RH850/F1KM-S2
•RH850/F1KM-S4
•RH850/F1KH-D8
The device must be placed inside the socket IC1. To insert the device, press
down the lid, align the #1 pin of the device to the #1pin of the socket, insert the
device inside the socket and release the lid.

RH850/F1x-176pin Piggyback board V4 Y-RH850-F1X-176PIN-PB-T1-V4
R20UT4148ED0120 Rev. 1.20 9
August 12, 2021
Chapter 3 Jumper Configuration
The function of the board can be configured via jumpers. This chapter describes
the standard configuration, i.e. jumper setting for the intended devices. For the
supported function of the used device, please refer to the corresponding HW
user’s manual.
The table has the following meaning:
•x-y: Connect the pins x and y; valid for 3-pin jumpers (e.g. JP17)
The pin #1 can be identified by a small circle in the vicinity of the jumper
Depending on the used device a configuration of several jumpers is required. The
detailed configuration is shown below:
F1L
F1M
F1H
F1K
F1KM-S2
F1KM-S4
F1KH-D8
Function
JP1
closed
open
open
closed
open
open
Selection of Pin 114:
P9_6, VSS, REG0VCC or
REG1VCC
JP2
open
closed
closed
open
open
open
JP3
open
open
open
open
closed
open
JP31
open
open
open
open
open
closed
JP4
closed
open
open
closed
open
open
Selection of Pin 113:
P9_5, REGVCC or VSS
JP5
open
closed
closed
open
open
open
JP6
open
open
open
open
closed
closed
JP7 1-2
closed
closed
closed
closed
open
open
Selection of Pin 73:
P1_6 or ISOVCL
JP7 2-3
open
open
open
open
closed
closed
JP8 1-2
closed
closed
closed
closed
open
open
Selection of Pin 72:
P1_7 or VSS
JP8 2-3
open
open
open
open
closed
closed
JP9 1-2
closed
closed
closed
closed
open
open
Selection of Pin 14:
P11_14 or VSS
JP9 2-3
open
open
open
open
closed
closed
JP10 1-2
closed
closed
closed
closed
open
open
Selection of Pin 13:
P11_13 or ISOVCL
JP10 2-3
open
open
open
open
closed
closed
JP21 1-2
closed
open
open
Either
open
open
Selection of PWGA34:
Either from P9_5 or P0_11
JP21 2-3
open
closed
closed
Or
closed
closed
JP17 1-2
closed
open
open
Either
open
open
Selection of PWGA35:
Either P9_6 or P0_6
JP17 2-3
open
closed
closed
Or
closed
closed
JP24 1-2
open
open
closed
open
open
open
Selection of ETH0RXERR:
Either P11_14 or P11_15
JP24 2-3
open
open
open
open
closed
closed
JP30 1-2
open
open
open
open
closed
closed
Selection of ETH0CRSDV:
Either P11_12 or P11_13
JP30 2-3
open
open
closed
open
open
open
JP36 1-2
Either
Either
Either
Either
Either
Either
Selection of UART0TX:
Either P10_10 or P0_2
JP36 2-3
Or
Or
Or
Or
Or
Or
JP37 1-2
Either
Either
Either
Either
Either
Either
Selection of UART0RX:
Either P10_9 or P0_3
JP37 2-3
Or
Or
Or
Or
Or
Or
JP34 1-2
Either
Either
Either
Either
Either
Either
Selection of LIN0TX:
Either P10_10 or P0_2
JP34 2-3
Or
Or
Or
Or
Or
Or
JP35 1-2
Either
Either
Either
Either
Either
Either
Selection of LIN0RX:
Either P10_9 or P0_3
JP35 2-3
Or
Or
Or
Or
Or
Or
JP32 1-2
Either
Either
Either
Either
Either
Either
Selection of CAN0TX:
Either P10_1 or P0_0
JP32 2-3
Or
Or
Or
Or
Or
Or
JP33 1-2
Either
Either
Either
Either
Either
Either
Selection of CAN0RX:

RH850/F1x-176pin Piggyback board V4 Y-RH850-F1X-176PIN-PB-T1-V4
R20UT4148ED0120 Rev. 1.20 10
August 12, 2021
JP33 2-3
Or
Or
Or
Or
Or
Or
Either P10_0 or P0_1
The jumper setting also are shown in this picture:
Figure 3 –Jumper setting overview
•The green jumper JP25 for FLMDO0 always must be closed for a ‘normal’
(user mode and debug) operation of the device.
•The red jumpers must be set for a single “Voltage 1” (typ +5.0V)
operation of the device.
•The blue jumper must be set for a single “Voltage 2” (typ +3.3V)
operation of the device.
•The orange jumpers must be selected depending on the used device.
See the printing on the board or the table above for the applicable setting.
For jumper settings related to the device operation mode, refer to the
chapter 9.2.

RH850/F1x-176pin Piggyback board V4 Y-RH850-F1X-176PIN-PB-T1-V4
R20UT4148ED0120 Rev. 1.20 11
August 12, 2021
Chapter 4 Power supply
4.1 Board power connection
For operation of the device, a supply voltage must be connected to the board.
Though a single supply voltage is sufficient for the operation of the device, two
(different) voltages can be supplied to the board.
Within this document the following voltages are considered as ‘typical’
connections:
Voltage1 = 5.0V
Voltage2 = 3.3V
The following connectors are available to supply those voltages:
•Three 4mm ‘banana-type’ connectors:
- Two red connectors for voltages Voltage1 (CN54) and Voltage2 (CN17).
- A black connector for VSS connection (CN10).
Note: The three connectors are supplied with the board but not assembled.
•The E1/E2 emulator that is used for debug purposes and flash programming
can also supply a single operating voltage (‘Dbg_Voltage’).
The voltage is programmable via the E1/E2 GUI as 3.3 or 5.0V (typ).
See the documentation of the E1/E2 and chapter 5 ‘Debug and
Programming interface’ for details.
Note: The E1 voltage is connected to Voltage1, what is typically 5V. Still,
3.3V can be provided by the E1.
•In case the piggyback board is mounted on a mainboard, the voltages
Voltage1 and Voltage2 are supplied by the on-board regulators of the
mainboard.
NOTE: Do not supply any voltage directly to the piggyback board in case it is
mounted on the mainboard.
For each of the two voltages, ‘Voltage 1 ‘ and ‘Voltage 2’, a green LED (LED1
and LED2) is available to signal that the related voltage is available on the
piggyback board.

RH850/F1x-176pin Piggyback board V4 Y-RH850-F1X-176PIN-PB-T1-V4
R20UT4148ED0120 Rev. 1.20 12
August 12, 2021
4.2 Voltage distribution
The table shows the required device power supply pins and their function:
Device
supply
pin
Name on
Piggyback
board
Function
REGVCC
REG0VCC
REG0VDD
Supply for the device internal regulators for the digital logic.
REG1VCC
REG1VDD
Supply for the device internal regulators for the digital logic.
EVCC
EVDD
Supply for ports.
BVCC
BVDD
Supply for ports.
A0VREF
Supply for ports and analog functions of ADC0.
A1VREF
Supply for ports and analog functions of ADC1.
VDDIOF
IO supply voltage for components located on a connected
mainboard.
•For each of the above voltages, the voltage source can be selected from
Voltage1 (typ. 5.0V) or Voltage2 (typ. 3.3V) by the jumpers JP12-JP16, JP18,
JP29, respectively the jumpers JP11 and JP20.
Error! Not a valid link.
Note:
•The RH850/F1KH-D8 device requires a supply voltage of 3.3V on its
REG1VCC pin.
•The RH850/F1KM-S2 and RH850/F1KM-S4 device requires the same
supply voltage to be set to REG0VCC and REG1VCC.
See the section ‘Electrical Characteristics’ in the device User’s Manual for further
details.

RH850/F1x-176pin Piggyback board V4 Y-RH850-F1X-176PIN-PB-T1-V4
R20UT4148ED0120 Rev. 1.20 13
August 12, 2021
Chapter 5 Clock sources
Four external crystal oscillators for the device clock supply are provided with the
board.
5.1 MainOsc
A crystal or ceramic resonator can be mounted on socket X1.
The applicable frequency range can be found is the devices electrical
specification.
A 8MHz, 16MHz and a 20MHz oscillator is supplied with the board.
5.2 SubOSC
An oscillator with a frequency of 32.768kHz is supplied with the board and can be
soldered into the connector X2.

RH850/F1x-176pin Piggyback board V4 Y-RH850-F1X-176PIN-PB-T1-V4
R20UT4148ED0120 Rev. 1.20 14
August 12, 2021
Chapter 6 Debug and Programming interface
For connection of the microcontroller debug and flash programming tools, the
connector CN19 is provided.
The signal connection of the connector CN19 is shown in the picture below:
CN19 pin
Device Port
Device signal
1
JP0_2
DCUTCK / LPDCLK
2
GND
GND
3
JP0_4
DCUTRST
4
FLMD0
FLMD0
5
JP0_1
DCUTDO / LPDO
6
P10_8*
FLMD1
7
JP0_0
DCUTDI / LPDI
8
‘Dbg_Voltage’
-
9
JP0_3
DCUTMS
10
JP0_6
EVTO*
11
JP0_5
DCURDY /
LPDCLKOUT
12
GND
-
13
RESET
-
14
GND
-
*In case the EVTOUT signal shall be used by the debug/programming tool, the
pin header JP11 must be closed.
The ‘Dbg_Voltage’ (on CN19 pin 8) is monitored or supplied by the debug and
flash programming tools. Therefore, it is necessary to select either Voltage1 (5V)
or the Voltage2 (3.3V) by pin header JP23:
JP23 pin
Selection for Dbg_Voltage
1-2
5V is selected
2-3
3.3V is selected

RH850/F1x-176pin Piggyback board V4 Y-RH850-F1X-176PIN-PB-T1-V4
R20UT4148ED0120 Rev. 1.20 15
August 12, 2021
Chapter 7 Connectors for ports of device
Connection to each pin of the device is possible via the connectors CN5 to CN8.
Note: The pin headers are directly connected to the pins of the device, therefore
special care must be taken to avoid any electrostatic or other damage to the
device.

RH850/F1x-176pin Piggyback board V4 Y-RH850-F1X-176PIN-PB-T1-V4
R20UT4148ED0120 Rev. 1.20 16
August 12, 2021
Chapter 8 Connectors to Mainboard
Three connectors (CN1 to CN3) are available to connect the piggyback board to
a mainboard.
The function and port assignment of each connector pin is described in this
chapter.
Note:
Not each function may be available on the assigned device port for each of the
supported devices of this piggyback board.
In case a function is not available on the assigned device port but on a different
port of the device, use one of the provided wires (with the mainboard) for a
manual connection of the device pin (via CN5 to CN8) to the related functional
pin header on the mainboard.
8.1 Connector CN1
Pin
Function
Device Port
Pin
Function
Device Port
1
VOLTAGE1
-
2
VOLTAGE1
-
3
VOLTAGE1
-
4
VOLTAGE1
-
5
RESET
_RESET
6
NMI
P9_0
7
WAKE
-
8
-
-
9
INT0
P9_1
10
INT1
P0_6
11
INT2
P9_2
12
INT3
P9_3
13
-
-
14
-
-
15
UART0TX
P10_10 or
P0_2
16
UART1TX
P0_5
17
UART0RX
P10_9 or
P0_3
18
UART1RX
P0_4
19
LIN0TX
P10_10 or
P0_2
20
LIN1TX
P0_8
21
LIN0RX
P10_9 or
P0_3
22
LIN1RX
P0_7
23
IIC0SDL
P10_3
24
IIC1SDL
P9_1
25
IIC0SDA
P10_2
26
IIC1SDA
P9_0
27
CAN0TX
P10_1 or
P0_0
28
CAN1TX
P0_3
29
CAN0RX
P10_0 or
P0_1
30
CAN1RX
P0_2
31
SENTIN0
P8_0
32
SENTIN1
P9_0
33
SENTOUT0
P8_1
34
SENTOUT1
P9_1
35
PSI50Rx
-
36
PSI51Rx
-
37
PSI50Tx
-
38
PSI51Tx
-
39
PSI50Snyc
-
40
PSI51Sync
-
41
FLX0TX
P11_1
42
FLX0EN
P10_11
43
FLX0RX
P10_14
44
FLXSTPWT
P10_12
45
FLX1TX
P10_8
46
FX1EN
P10_13

RH850/F1x-176pin Piggyback board V4 Y-RH850-F1X-176PIN-PB-T1-V4
R20UT4148ED0120 Rev. 1.20 17
August 12, 2021
Pin
Function
Device Port
Pin
Function
Device Port
47
FLX1RX
P10_9
48
FX1CLK
P10_10
49
-
-
50
-
-
51
ETH0MDIO
P12_4
52
ETH0MDC
P12_5
53
ETH0RXD0
P10_1
54
EH0TXD0
P18_1
55
ETH0RXD1
P10_2
56
EH0TXD1
P18_2
57
ETH0RXD2
P10_4
58
EH0TXD2
P18_3
59
ETH0RXD3
P10_5
60
EH0TXD3
P18_4
61
ETH0RXDCLK
P10_0
62
ETH0TXCLK
P18_7
63
ETH0RXER
P11_14 or
P11_15
64
ETH0TXER
P18_6
65
ETH0CRSDV
P11_12 or
P11_13
66
ETH0TXEN
P18_5
67
ETH0RXDV
P11_11
68
ETH0COL
P11_10
69
ETH0RESET
P2_6
70
ETH0LINK
P18_0
71
-
-
72
-
-
73
USB0UDMF
-
74
USB0UDMH
-
75
USB0UDPF
-
76
USB0UDPH
-
77
-
-
78
-
-
79
-
-
80
-
-
81
-
-
82
-
-
83
-
-
84
-
-
85
DIGIO_0
P8_0
86
DIGIO_1
P8_1
87
DIGIO_2
P8_2
88
DIGIO_3
P8_3
89
DIGIO_4
P8_4
90
DIGIO_5
P8_5
91
DIGIO_6
P8_6
92
DIGIO_7
P11_0
93
DIGIO_8
P10_0
94
DIGIO_9
P10_7
95
DIGIO_10
P10_8
96
DIGIO_11
P10_15
97
DIGIO_12
P0_9
98
DIGIO_13
P0_10
99
DIGIO_14
P0_11
100
DIGIO_15
P0_12
101
-
-
102
-
-
103
MUX0
P10_4
104
MUX1
P10_5
105
MUX2
P10_6
106
-
-
107
ADC0
AP0_0
108
ADC1
AP0_1
109
ADC2
AP0_2
110
ADC3
AP0_3
111
ADC4
AP0_4
112
ADC5
AP0_5
113
ADC6
AP0_6
114
ADC7
AP0_7
115
VDDIOF
-
116
VDDIOF
-
117
VOLTAGE2
-
118
VOLTAGE2
-
119
VOLTAGE2
-
120
VOLTAGE2
-

RH850/F1x-176pin Piggyback board V4 Y-RH850-F1X-176PIN-PB-T1-V4
R20UT4148ED0120 Rev. 1.20 18
August 12, 2021
8.2 Connector CN2
Pin
Function
Device Port
Pin
Function
Device Port
1
CAN2Tx
P0_4
2
CAN3Tx
P1_3
3
CAN2Rx
P0_5
4
CAN3Rx
P1_2
5
CAN4Tx
P1_13
6
CAN5Tx
P0_14
7
CAN4Rx
P1_12
8
CAN5Rx
P0_13
9
LIN2Tx
P0_10
10
LIN3Tx
P1_15
11
LIN2Rx
P0_9
12
LIN3Rx
P1_14
13
LIN4Tx
P1_11
14
LIN5Tx
P8_12
15
LIN4Rx
P1_10
16
LIN5Rx
P8_11
17
LIN6Tx
P0_12
18
LIN7Tx
P12_4
19
LIN6Rx
P0_11
20
LIN7Rx
P12_3
21
LIN8Tx
P2_3
22
LIN9Tx
P2_5
23
LIN8Rx
P2_2
24
LIN9Rx
P2_4
25
LIN10Tx
P8_2
26
LIN11Tx
P10_12
27
LIN10Rx
P8_10
28
LIN11Rx
P10_11
29
LIN12Tx
P10_14
30
LIN13Tx
P1_1
31
LIN12Rx
P10_13
32
LIN13Rx
P1_0
33
LIN14Tx
P8_9
34
LIN15Tx
P1_5
35
LIN14Rx
P8_8
36
LIN15Rx
P1_4
37
-
-
38
-
-
39
-
-
40
-
-
41
-
-
42
-
-
43
-
-
44
-
-
45
-
-
46
-
-
47
CAN6Tx
P8_1
48
CAN7Tx
P8_3
49
CAN6Rx
P8_0
50
CAN7Rx
P8_4
51
-
-
52
-
-
53
-
-
54
-
-
55
-
-
56
-
-
57
-
-
58
-
-
59
-
-
60
-
-
61
LIN16Tx
P11_15
62
LIN17Tx
P8_2
63
LIN16Rx
P12_0
64
LIN17Rx
P8_10
65
-
-
66
-
-
67
-
-
68
-
-
69
-
-
70
-
-
71
-
-
72
-
-
73
-
-
74
-
-
75
-
-
76
-
-
77
-
-
78
-
-
79
-
-
80
-
-
81
-
-
82
-
-
83
-
-
84
-
-

RH850/F1x-176pin Piggyback board V4 Y-RH850-F1X-176PIN-PB-T1-V4
R20UT4148ED0120 Rev. 1.20 19
August 12, 2021
Pin
Function
Device Port
Pin
Function
Device Port
85
-
-
86
-
-
87
-
-
88
-
-
89
-
-
90
-
-
91
-
-
92
-
-
93
-
-
94
-
-
95
-
-
96
-
-
97
-
-
98
-
-
99
-
-
100
-
-
101
-
-
102
-
-
103
-
-
104
-
-
105
-
-
106
-
-
107
-
-
108
-
-
109
-
-
110
-
-
111
-
-
112
-
-
113
-
-
114
-
-
115
-
-
116
-
-
117
-
-
118
-
-
119
-
-
120
-
-

RH850/F1x-176pin Piggyback board V4 Y-RH850-F1X-176PIN-PB-T1-V4
R20UT4148ED0120 Rev. 1.20 20
August 12, 2021
8.3 Connector CN3
Pin
Function
Device Port
Pin
Function
Device Port
1
PWM00
P10_0
2
PWM01
P10_1
3
PWM02
P10_2
4
PWM03
P10_3
5
PWM04
P10_7
6
PWM05
P10_8
7
PWM06
P10_9
8
PWM07
P10_10
9
PWM08
P9_0
10
PWM09
P9_1
11
PWM10
P0_4
12
PWM11
P0_1
13
PWM12
P0_2
14
PWM13
P0_3
15
PWM14
P8_0
16
PWM15
P8_1
17
PWM16
P10_11
18
PWM17
P10_12
19
PWM18
P10_13
20
PWM19
P10_14
21
PWM20
P9_2
22
PWM21
P9_3
23
PWM22
P8_2
24
PWM23
P8_3
25
PWM24
P10_15
26
PWM25
P11_0
27
PWM26
P11_1
28
PWM27
P11_2
29
PWM28
P11_3
30
PWM29
P11_4
31
PWM30
P11_5
32
PWM31
P11_6
33
PWM32
P11_7
34
PWM33
P9_4
35
PWM34
P9_5 or
P0_11
36
PWM35
P9_6 or
P0_6
37
PWM36
P8_4
38
PWM37
P8_5
39
PWM38
P8_6
40
PWM39
P8_7
41
PWM40
P8_8
42
PWM41
P8_9
43
PWM42
P8_10
44
PWM43
P8_11
45
PWM44
P8_12
46
PWM45
P0_12
47
PWM46
P0_13
48
PWM47
P0_14
49
PWM48
P11_8
50
PWM49
P11_9
51
PWM50
P11_10
52
PWM51
P11_11
53
PWM52
P11_12
54
PWM53
P11_13
55
PWM54
P11_14
56
PWM55
P11_15
57
PWM56
P12_0
58
PWM57
P12_1
59
PWM58
P12_2
60
PWM59
P20_4
61
PWM60
P20_5
62
PWM61
P18_0
63
PWM62
P18_1
64
PWM63
P18_2
65
PWM64
P20_0
66
PWM65
P20_1
67
PWM66
P20_2
68
PWM67
P20_3
69
PWM68
P12_3
70
PWM69
P12_4
71
PWM70
P12_5
72
PWM71
P18_3
73
PWM72
-
74
PWM73
-
75
PWM74
-
76
PWM75
-
77
PWM76
-
78
PWM77
-
79
PWM78
-
80
PWM79
-
81
PWMADC00
AP0_8
82
PWMADC01
AP0_9
