Renesas US082-ZMOD4450EVZ User manual

Evaluation Board Manual
R36UZ0003EA0100 Rev.1.0 Page 1
Jun 10, 2021 © 2021 Renesas Electronics
The US082-ZMOD4450EVZ board enables quick
prototyping of the ZMOD4450 gas sensor module for
refrigeration air quality (RAQ) in a custom system
design. The board provides a standard Pmod™ Type
6A (Extended I2C) connection for the on-board sensor
to plug into any desired MCU evaluation kit with a
matching connector.
The US082-ZMOD4450EVZ features Pmod
connectors on both sides of the board to allow
additional Type 6/6A boards to be connected in a
daisy-chained solution with multiple sensors on the
same MCU Pmod connector. Because of the standard
connector and software support, the
US082-ZMOD4450EVZ is the best choice to rapidly
create an IoT system with the Renesas
Quick-Connect IoT.
Features
▪Gas sensor module for RAQ ZMOD4450 sensor
sample mounted:
• Measures gases associated with food ripening
and storage: volatile organic compounds
(including ethylene), amines, volatile sulfur
compounds
• Provides configurable methods of operation
based on application and use case
▪Standardized Type 6A Pmod connector supports
I2C Extended interface
▪Dual connectors allow pass-through signals for
daisy-chained solutions
Board Contents
▪US082-ZMOD4450EVZ Board
Figure 1. US082-ZMOD4450EVZ Pmod Board
US082-ZMOD4450EVZ

R36UZ0003EA0100 Rev.1.0 Page 2
Jun 10, 2021
US082-ZMOD4450EVZ Evaluation Board Manual
Contents
1. Functional Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2. Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2.1 Required or Recommended User Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2.2 Software Installation and Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2.3 Kit Hardware Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3. Board Design . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
3.1 Schematic Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3.2 Bill of Materials . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3.3 Board Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
4. Ordering Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
5. Revision History . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

R36UZ0003EA0100 Rev.1.0 Page 3
Jun 10, 2021
US082-ZMOD4450EVZ Evaluation Board Manual
1. Functional Description
The US082-ZMOD4450EVZ functions as a sensor building block to create a custom system solution. It can be
used individually or with a combination of other sensors using the Pmod Type 6A interface. For more information
on creating your full system design, further information on software development, and additional hardware
availability, see Renesas Quick-Connect IoT.
Figure 2. US082-ZMOD4450EVZ Pmod Board with RA2L1 MCU Kit

R36UZ0003EA0100 Rev.1.0 Page 4
Jun 10, 2021
US082-ZMOD4450EVZ Evaluation Board Manual
2. Setup
2.1 Required or Recommended User Equipment
The following additional lab equipment (sold separately) is required for using the board:
▪Any MCU board that supports Type 6A Pmod.
▪US082-INTERPEVZ interposer board if using one of the Renesas MCU kits shown in Table 1.
2.2 Software Installation and Usage
See the Renesas website for the latest version of the e2 studio installer. The minimum FSP version supporting
sensor blocks is FSP 3.1.0. For the latest sensor support, ensure you are using the latest release.
Visit Renesas Quick-Connect IoT for more information about creating your customized system solution.
2.3 Kit Hardware Connections
Follow these procedures to set up the kit as shown on Figure 3.
1. Ensure the MCU evaluation kit has a Pmod connector set to Type 6A (see the kit hardware manual if unsure).
a. If no Type 6A Pmod is available, ensure the MCU evaluation kit can use the US082-INTERPEVZ interposer
board and insert the board into the MCU connector before adding any sensor boards.
2. Plug in the US082-ZMOD4450EVZ to the Type 6A connector, being careful to align Pin 1 on the sensor board
and MCU kit.
3. Connect the J4 and J5 jumpers to place 4.7k pull-up resistors on the I2C bus lines.
a. Only one set of I2C pull-up resistors should be used on the bus. If multiple sensor boards are used, only
one board should have the jumpers present.
b. MCU kits typically do not have pull-up resistors present on the bus lines but double check for them.
4. The INT pin of the ZMOD4450 is a push-pull output signaling if a measurement is being taken. Connect it to
the Busy (GPIO) pin of the Pmod connector by placing Jumper J6 on Pins 1-2. Connect it to the INT pin of the
Pmod connector by placing Jumper J6 on Pins 2-3. Connect Jumper J3 to add an optional 4.7k pull-up resistor
to this line.
Table 1. Renesas MCU Evaluation Kits[1] capable of supporting Type 6A PMODs when used with the
US082-INTERPEVZ
1. This table is not a comprehensive list of supported MCU Kits. See the evaluation kit hardware manual to confirm Pmod pinout.
RA RX Synergy
EK-RA4W1 RX111-Starter-Kit PK-S5D9
EK-RA2A1 RX231-Starter-Kit DK-S3A7
EK-RA4M1 RX23W-Starter-Kit DK-S128
EK-RA6M1 RX23T-Starter-Kit TB-S1JA
EK-RA6M2 RX24T-Starter-Kit TB-S3A6
EK-RA6M3 RX24U-Starter-Kit DK-S7G2
EK-RA6M3G

R36UZ0003EA0100 Rev.1.0 Page 5
Jun 10, 2021
US082-ZMOD4450EVZ Evaluation Board Manual
5. The sensor is now ready to be used in the system. Follow the MCU kit instructions for connecting and powering
up the evaluation kit.
3. Board Design
Figure 3. Evaluation Kit Connections
Figure 4. US082-ZMOD4450EVZ Evaluation Board (Top)
Figure 5. US082-ZMOD4450EVZ Evaluation Board (Bottom)
Jumpers for I2C Pull-Ups
Connector to
MCU board
Jumper for Busy/Int Pull-Up
Jumper for Busy/Int
Connector for additional
sensor Pmod boards
RAQ Gas Sensor Module

R36UZ0003EA0100 Rev.1.0 Page 6
Jun 10, 2021
US082-ZMOD4450EVZ Evaluation Board Manual
3.1 Schematic Diagrams
3.2 Bill of Materials
Figure 6. US082-ZMOD4450EVZ Schematic
Qty Reference Description Value PCB Footprint Part Number
4 C1, C2, C3, C4 Capacitor, 0.1µF, 50V, 0603 0.1µF 0603 C0603C104J5RACTU
1 J1 Male Header 0.1" pitch PMOD 2x6 Right
Angle
PmodTM PMOD-MALE-TOP M20-9950645
1 J2 Female Header 0.1" pitch PMOD 2x6
Right Angle
CON-000050-01 SSW-106-02-F-D-RA
3 J3, J4, J5 CONN HEADER VERT 2POS 1.27 MM HDR-1X2-FTS FTS-102-01-L-S
1 J6 CONN HEADER VERT 3POS 1.27 MM HDR-1X3-FTS FTS-103-01-L-D
3 R1, R2, R3 Resistor, 4.7k, 0603 4.7k 0603 RC0603JR-074K7L
1 U1 Gas Sensor Module ZMOD4450 ZMOD4450
1 U2 Single Inverter Buffer/Driver With
Open-Drain Output
DCK0005A_N SN74LVC1G06DCKT
4 J3, J4, J5, J6 1.27" 1x2 Jumper with Grip, Gold NPB02SVFN-RC
GND
GND
3V3
PMOD Interface System
IIC_SDA
RES_N
IIC_SCL
17
28
39
410
511
612
J2
GND GND
PMOD Interface Slave
IRQ#
4.7k
0603 R1
4.7k
0603 R2
4.7k
0603 R3
3V3
BUSY#
GPIO4GPIO4
C1
0.1uF, 50V C2
0.1uF, 50V
1 2
J3
1 2
J4
1 2
J5
1 7
2 8
3 9
410
511
612
J1
R
LOGO1
GND
3V3
C3
0.1uF, 50V
SCL
1
SDA
2
INT
3
NC
4
VDD
5
VSS
6
VSS 7
NC 8
VSS 9
VDDH 10
RES_N 11
VDDIO 12
U1
ZMOD4450
GND
3V3
BUSY#
BUSY#
2 4
U2A
1
2J6
C4
0.1uF, 50V
ENABLE
POWER_ON
ENABLE
POWER_ON

R36UZ0003EA0100 Rev.1.0 Page 7
Jun 10, 2021
US082-ZMOD4450EVZ Evaluation Board Manual
3.3 Board Layout
Figure 7. Silkscreen Top Layer Figure 8. Top Layer
Figure 9. Layer 1 Figure 10. Layer 2
Figure 11. Bottom Layer Figure 12. Silkscreen Bottom Layer

R36UZ0003EA0100 Rev.1.0 Page 8
Jun 10, 2021
US082-ZMOD4450EVZ Evaluation Board Manual
4. Ordering Information
5. Revision History
Part Number Description
US082-ZMOD4450EVZ ZMOD4450 Pmod Board
US082-INTERPEVZ Pmod interposer board to convert Type 2A and 3A to Type 6A on older Renesas MCU kits.
Revision Date Description
1.0 Jun 10, 2021 Initial release
