RenewAire HE ERV Series User manual

HE2XINH
HE2XINV
HE SERIES ERV
Installation, Operation and Maintenance Manual
HE-2XINH Shown
HE-2XINV Shown

1.800.627.4499
2
HE-Series Indoor
ERV
WARNING
ARC FLASH AND ELECTRIC SHOCK HAZARD
Arc flash and electric shock hazard. Disconnect all electric
power supplies, verify with a voltmeter that electric power is
off and wear protective equipment per NFPA 70E before work-
ing within electric control enclosure. Failure to comply
can cause serious injury or death.
Customer must provide earth ground to unit, per NEC, CEC and
local codes, as applicable.
Before proceeding with installation, read all instructions,
verifying that all the parts are included and check the
nameplate to be sure the voltage matches available utility
power.
The line side of the disconnect switch contains live high-
voltage.
The only way to ensure that there is NO voltage inside the unit
is to install and open a remote disconnect switch and verify
that power is off with a volt meter. Refer to unit electrical
schematic. Follow all local codes.
RISK OF ELECTRIC SHOCK OR EQUIPMENT DAMAGE
Whenever electrical wiring is connected, disconnected or
changed, the power supply to the ERV and its controls must
be disconnected. Lock and tag the disconnect switch or circuit
breaker to prevent accidental reconnection of electric power.
RISK OF CONTACT WITH HIGH SPEED MOVING PARTS
Disconnect all local and remote power supplies, verify with
a voltmeter that electric power is off and all fan blades have
stopped rotating before working on the unit.
Do not operate this unit with any cabinet panels removed.
This unit is intended for general ventilating and heating only.
Do not use to exhaust hazardous or explosive materials and
vapors. Do not connect this equipment to range hoods, fume
hoods or collection systems for toxics.
This equipment is to be installed by following Industry Best
Practices and all applicable codes. Any damage to compo-
nents, assemblies, subassemblies or the cabinet which is
caused by improper installation practices will void the
warranty.
Air ducts connecting this ERV to the Occupied Space must be
installed in accordance with the Standards of the National Fire
Protection Agency for the installation of Air-Conditioning and
Ventilating Systems (Pamphlet No. 90A) and Warm-Air Heating
and Air-Conditioning Systems (Pamphlet No. 90B).
This unit is for ventilating finished structures only. It is not to
be used until after all construction has been completed and
construction debris and dust are cleaned from the Occupied
Space.
CAUTION
CAUTION
IMPORTANT
IMPORTANT
IMPORTANT
IMPORTANT

31.800.627.4499
HE-Series Indoor ERV
Serial Number:
SO#:
Unit Option Code:
UNIT LABEL (TYPICAL)
UNIT INFORMATION
H X- IE -J -2 N --
SAVE THIS MANUAL
This manual contains space for maintaining written records of unit maintenance and/
or repairs. See Section 7.7 Maintenance Records. At the time the ERV is commissioned, a
maintenance schedule should be developed by the user to incorporate monthly and seasonal
maintenance and include start-up maintenance tasks as described in this manual.
NOTICE
UNIT INFORMATION
Record information as shown below.
In the unlikely event that factory assistance is ever required, information located on the unit
label will be needed.
Locate the RenewAire unit label found on the outside of the unit.
NOTE: This information is for purposes of identifying the unit-specific option data from the
Option Code.
NOTE: This page
is to be completed
by the installing
contractor. The completed
document is to be turned
over to the owner after
start-up.
OWNER INFORMATION

1.800.627.4499
4
RENEWAIRE.COM 1.800.627.4499
66
SPECIFICATIONS & DIMENSIONS
Specifications may be subject to change without notice.
INDOOR UNIT SPECIFICATIONS
Ventilation Type:
Static plate, heat and humidity transfer
Typical Airflow Range: 500-2,200 CFM
AHRI 1060 Certified Core: Two L125-G5
Standard Features:
TEFC Premium efficiency motors
Motor starters
Non-fused disconnect
24 VAC transformer/relay package
Cross-core differential pressure ports
Filters:
Total qty. 4, MERV 8: 20" x 20" x 2"
Unit Dimensions & Weight:
64 1/2" L x 43" W x 35 1/2" H
406-619 lbs., varies by option(s)
Max. Shipping Dimensions & Weight (on pallet):
70" L x 47" W x 40" H
714 lbs.
Motor(s):
Qty. 2, Belt drive blower/standard motor packages
with adjustable sheaves (see table below)
Options:
Onboard variable frequency drives (VFDs) -
one or both airstreams
Shaft grounding ring on motors with VFDs
Fused disconnect
Integrated programmable controls -
enhanced, premium
Bypass economizer damper
(see bypass DIM drawing) -
dry-bulb temperature controls (standard),
enthalpy controls (option)
Class 1 low leakage motorized isolation dampers -
OA, RA or both airstreams
Qty. 2, Factory mounted filter alarms -
both airstreams
Double wall construction
Exterior paint - white, custom colors
Accessories:
Filters - MERV 13, 2"(shipped loose)
Digital time clock - wall mount (TC7D-W),
in exterior enclosure (TC7D-E)
Carbon dioxide sensor/control -
wall mount (CO2-W), duct mount (CO2-D)
IAQ sensor - wall mount (IAQ-W),
duct mount (IAQ-D)
Motion occupancy sensor/control -
ceiling mount (MC-C), wall mount (MC-W)
Smoke Detector - duct mount (SD-D)
Electric duct heater - EK series (1–175 kW)
Indirect gas-fired duct furnace - GH series
(50-400 MBH), installed downstream of any fans
ELECTRICAL DATA
Standard Electrical Specifications Optional Factory Installed
VFD Electrical Specifications
HP Volts HZ Phase FLA
per motor
Min. Cir.
Amps
Max.
Overcurrent
Protection
Device
FLA
per motor
Min. Cir.
Amps
Max.
Overcurrent
Protection
Device
1.5 120 60 Single 15.2 34.2 45
1.5
208-230
208-230
460
575
60
60
60
60
Single
Three
Three
Three
8.2-7.6
4.6-4.8
2.4
1.8
18.5
10.8
5.4
4.1
25
15
15
15
4.6-4.8
4.6-4.8
2.4
1.8
20.6
11.9
5.9
4.5
25
15
15
15
2.0 120 60 Single 20.0 45.0 60
2.0
208-230
208-230
460
575
60
60
60
60
Single
Three
Three
Three
10.8-10.0
6.6-5.8
2.9
2.4
24.3
14.9
6.5
5.4
35
20
15
15
6.6-5.8
6.6-5.8
2.9
2.4
28.3
16.3
7.2
5.9
30
20
15
15
ThermalPerformanceRatingsG52015.2.xlsx 2Cores(IOM)
HE 2XINH
HE
Download specification at:
renewaire.com/specifications
AIRFLOW PERFORMANCE
Motor
HP
Blower
RPM
Sheave
Adj.
Turns
Open
External Static Pressure (in. w.g.)
0.00 0.25 0.50 0.75 1.00 1.25 1.50
SCFM BHP SCFM BHP SCFM BHP SCFM BHP SCFM BHP SCFM BHP SCFM BHP
1.5
1148 4 1592 0.7 1480 0.7 1320 0.6 1120 0.5 800 0.4
1304 2 1809 1.0 1720 1.0 1600 0.9 1410 0.8 1250 0.7 975 0.6 630 0.4
1460 0 2025 1.5 1950 1.4 1845 1.3 1715 1.2 1540 1.1 1400 1.0 1165 0.8
2.0
1506 2 2130 1.6 2050 1.5 1955 1.4 1840 1.3 1735 1.2 1585 1.0 1360 0.9
1584 1 2170 1.8 2080 1.7 1970 1.5 1870 1.4 1765 1.3 1565 1.1
1661 0 2200 1.9 2100 1.8 2000 1.7 1900 1.5 1765 1.4
Note: Brake Horse Power (BHP) is for one blower motor package only. Operation in this zone will likely exceed FLA limits. Operation in this zone outside of core airflow limits.
Note: Airflow performance includes effect of clean, standard filter supplied with unit.
Energy Recovery Ventilator
Standard & Bypass Economizer Option
Energy Recovery Ventilator
Standard

51.800.627.4499
FOR THE MOST COMPLETE AND CURRENT INFORMATION VISIT RENEWAIRE.COM 67
HE-SERIES















  








 


 









  
   
   
  





 

 
 
  
                 
HE2XINH Energy Recovery Ventilator Standard
AIRFLOW CONFIGURATION Available as shown in dimension drawing.
UNIT MOUNTING & APPLICATION Must be mounted as shown. RA/EA airstream can be switched with OA/FA airstream unless certain options are selected.

1.800.627.4499
6
RENEWAIRE.COM 1.800.627.4499
70
SPECIFICATIONS & DIMENSIONS
Specifications may be subject to change without notice.
INDOOR UNIT SPECIFICATIONS
Options:
Onboard variable frequency drives (VFDs) -
one or both airstreams
Shaft grounding ring on motors with VFDs
Fused disconnect
Integrated programmable controls -
enhanced, premium
Bypass economizer damper
(see bypass DIM drawing) -
dry-bulb temperature controls (standard),
enthalpy controls (option)
Class 1 low leakage motorized isolation dampers -
OA, RA or both airstreams
Qty. 2, Factory mounted filter alarms -
both airstreams
Double wall construction
Exterior paint - white, custom colors
Accessories:
Filters - MERV 13, 2"(shipped loose)
Digital time clock - wall mount (TC7D-W),
in exterior enclosure (TC7D-E)
Carbon dioxide sensor/control -
wall mount (CO2-W), duct mount (CO2-D)
IAQ sensor - wall mount (IAQ-W),
duct mount (IAQ-D)
Motion occupancy sensor/control -
ceiling mount (MC-C), wall mount (MC-W)
Smoke Detector - duct mount (SD-D)
Electric duct heater - EK series (1–175 kW)
Indirect gas-fired duct furnace - GH series
(50-400 MBH), installed downstream of any fans
ELECTRICAL DATA
Standard Electrical Specifications Optional Factory Installed
VFD Electrical Specifications
HP Volts HZ Phase FLA
per motor
Min. Cir.
Amps
Max.
Overcurrent
Protection
Device
FLA
per motor
Min. Cir.
Amps
Max.
Overcurrent
Protection
Device
1.5 120 60 Single 15.2 34.2 45
1.5
208-230
208-230
460
575
60
60
60
60
Single
Three
Three
Three
8.2-7.6
4.6-4.8
2.4
1.8
18.5
10.8
5.4
4.1
25
15
15
15
4.6-4.8
4.6-4.8
2.4
1.8
20.6
11.9
5.9
4.5
25
15
15
15
2.0 120 60 Single 20.0 45.0 60
2.0
208-230
208-230
460
575
60
60
60
60
Single
Three
Three
Three
10.8-10.0
6.6-5.8
2.9
2.4
24.3
14.9
6.5
5.4
35
20
15
15
6.6-5.8
6.6-5.8
2.9
2.4
28.3
16.3
7.2
5.9
30
20
15
15
ThermalPerformanceRatingsG52015.2.xlsx 2Cores(IOM)
AIRFLOW PERFORMANCE
Motor
HP
Blower
RPM
Sheave
Adj.
Turns
Open
External Static Pressure (in. w.g.)
0.00 0.25 0.50 0.75 1.00 1.25 1.50
SCFM BHP SCFM BHP SCFM BHP SCFM BHP SCFM BHP SCFM BHP SCFM BHP
1.5
1146 4 1735 0.8 1670 0.7 1520 0.7 1205 0.5 900 0.4
1302 2 1975 1.1 1925 1.1 1835 1.0 1615 0.9 1340 0.8 1080 0.6 670 0.4
1458 0 2100 1.5 1970 1.4 1755 1.3 1495 1.1 1280 0.9
2.0
1503 2 2175 1.7 2100 1.6 1945 1.4 1700 1.2 1465 1.0
1581 1 2120 1.7 1920 1.5 1685 1.2
1658 0 2125 1.9 1900 1.6
Note: Brake Horse Power (BHP) is for one blower motor package only. Operation in this zone will likely exceed FLA limits. Operation in this zone outside of core airflow limits.
Note: Airflow performance includes effect of clean, standard filter supplied with unit.
Ventilation Type:
Static plate, heat and humidity transfer
Typical Airflow Range: 500-2,200 CFM
AHRI 1060 Certified Core: Two L125-G5
Standard Features:
TEFC Premium efficiency motors
Motor starters
Non-fused disconnect
24 VAC transformer/relay package
Cross-core differential pressure ports
Filters:
Total qty. 4, MERV 8: 20" x 20" x 2"
Unit Dimensions & Weight:
50 1/2" L x 42" W x 52 1/2" H
363-583 lbs., varies by option(s)
Max. Shipping Dimensions & Weight (on pallet):
70" L x 47" W x 57" H
678 lbs.
Motor(s):
Qty. 2, Belt drive blower/standard motor packages
with adjustable sheaves (see table below)
HE 2XINV
HE
Download specification at:
renewaire.com/specifications
Energy Recovery Ventilator
Standard & Bypass Economizer Option
Energy Recovery Ventilator
Standard

71.800.627.4499
FOR THE MOST COMPLETE AND CURRENT INFORMATION VISIT RENEWAIRE.COM 71
HE-SERIES
34 7/8" Case
C
L
5 3/4" Power In
C
L
2 5/8" Control In
4 1/4" Duct
Flange Typ.
5" Damper
Frames Typ.
Pressure Ports (4) Typ.
Disconnect
Switch
E-Box
RA
OA
FA
EA
50 3/8" Overall
41 5/8" Case
42" Overall
33 5/8" Minimum
Service Area
45 1/4" Minimum
Service Area
Door Swing
1 3/4" Typ.
10 3/8" Typ.
3/4" - 1 7/8"
Typ.
16" X 12"
Duct Receiving
Flange Typ.
OA Inlet 24" X 14" Duct Receiving Flange
OA Damper Location (Optional)
51 5/8" Case
52 3/8" Overall
C
L
5 3/8"
Wiring
37" Typ.
9 3/8"
Wiring
8 1/4" Typ.
RA Inlet 24" X 14" Duct Receiving Flange
RA Damper Location (Optional)
RIGHT VIEW
FRONT VIEW
LEFT VIEW
(2)
7/8" Holes
for Wiring in Bottom of E-Box
TOP VIEW
Model: HE2XINV Drawing Type: Unit Dimension Version: MAY18
ABBREVIATIONS EA: Exhaust Air to outside OA: Outside Air intake RA: Room Air to be exhausted FA: Fresh Air to inside INSTALLATION ORIENTATION Unit must be installed in orientation shown. NOTE 1. UNLESS OTHERWISE SPECIFIED, DIMENSIONS ARE ROUNDED TO THE NEAREST EIGHTH OF AN INCH. 2. SPECIFICATIONS MAY BE SUBJECT TO CHANGE WITHOUT NOTICE. 3. MIN. DUCT CLEARANCE FROM DAMPER BLADES WHEN FULLY OPENED TO BE 2". SMACNA RULES APPLY.
HE2XINV Energy Recovery Ventilator Standard
AIRFLOW CONFIGURATION Available as shown in dimension drawing.
UNIT MOUNTING & APPLICATION Must be mounted as shown. RA/EA airstream can be switched with OA/FA airstream unless certain options are selected.

1.800.627.4499
8
HE-Series Indoor
ERV
1.0 OVERVIEW 11
1.1 DESCRIPTION .......................................................11
1.2 AIRFLOW..............................................................11
1.2.1 Airflow in HE2XINH ..........................................................12
1.2.2 Airflow in HE2XINV ..........................................................12
2.0 COMPONENT DESCRIPTIONS 12
2.1 CABINET ..............................................................12
2.2 ENTHALPIC CORES ...............................................12
2.3 FAN/MOTOR ASSEMBLIES.....................................12
2.4 E-BOX ..................................................................13
2.5 FILTERS ...............................................................13
2.6 FACTORY INSTALLED OPTIONS..............................13
3.0 SHIPPING/RECEIVING/HANDLING 13
3.1 UNIT WEIGHTS AND DIMENSIONS .........................14
3.1.1 Unit Dimensions and Weight ..............................................14
3.1.2 Shipping Dimensions and Weight.......................................14
3.2 RIGGING AND CENTER OF GRAVITY .......................14
3.1.1 HE2XINH Hoisting Weights and COG ..................................14
3.1.2 HE2XINV Hoisting Weights and COG ..................................15
3.3 RECEIVING ...........................................................15
3.4 STORAGE .............................................................15
4.0 UNIT PLACEMENT 15
4.1 BEFORE YOU BEGIN ..............................................15
4.2 SERVICE CLEARANCES .........................................16
4.3 SOUND ATTENUATION...........................................16
4.3.1 Outside the Building..........................................................16
4.3.2 Ducts ...............................................................................16
4.3.3 Radiated Noise .................................................................17
4.3.4 Aerodynamic (Velocity) Noise............................................17
5.0 INSTALLATION 17
5.1 DUCTWORK ..........................................................17
5.1.1 Ductwork: All Units............................................................17
5.1.2 Indoor Sound Attenuation ..................................................17
5.2 FLOOR INSTALLATION...........................................17
5.3 SUSPENDED MOUNT ............................................17
5.4 ELECTRICAL REQUIREMENTS................................18
5.4.1 Factory-Recommended Electric Service Entry....................18
5.4.2 Low Voltage Control System .............................................19
5.4.3 How to Reset the 24 VAC Circuit Breaker...........................19
5.4.4 Limits of Power Output .....................................................19
5.5 ELECTRIC WIRING SCHEMATIC ..............................20
5.6 EXTERNAL LOW VOLTAGE CONTROL WIRING
CONNECTIONS .......................................................... 22
5.6.1 Single 2 - Wire Control, Unpowered...................................22
5.6.2 Single 2 - Wire Control, Separate Power............................22
5.6.3 Control Sending 24 VAC “ON” Signal .................................22
5.6.4 External Control Using ERV Power Supply..........................23
5.6.5 Control with 2 Non-Powered Relay Contacts......................23
5.6.6 Control with 2 “ON” Signals, External Power .....................23
5.7 QUICK-START FOR TESTING CORRECT 3PH WIRING
..................................................................................24
6.0 OPERATION 24
6.1 PRINCIPLE OF OPERATION ....................................24
6.2 PRE-STARTUP ......................................................24
6.2.1 Verify Voltages..................................................................24
6.2.2 Verify Transformer Wiring ................................................. 24
6.2.3 Inspect Filters ..................................................................24
6.2.4 Inspect Foam Gasketing....................................................24
6.2.5 Inspect Belts and Verify Sheave Alignment ........................25
6.2.6 Inspect Fans.....................................................................25
6.2.7 Inspect and Clean the Cabinet Interior...............................25
6.2.8 Inspect Ductwork Connections..........................................25
6.3 UNIT STARTUP......................................................25
6.3.1 Fixed-Speed Units.............................................................25
6.4 BALANCING AIRFLOWS .........................................25
6.4.1 All Fixed-Speed Units........................................................26
6.4.2 Filter Pressure Drop..........................................................27
6.4.3 Sheave Adjustment...........................................................28
6.4.Variable-Speed Units ...........................................................28
6.5 NORMAL OPERATION ............................................28
6.6 EXTREME COLD OPERATION .................................28
7.0 MAINTENANCE 29
7.1 MAINTENANCE 24 HRS. AFTER START-UP .............29
7.2 MAINTENANCE 30 DAYS AFTER START-UP.............29
7.3 MAINTENANCE SCHEDULE....................................29
7.4 FILTERS ...............................................................29
7.5 FAN MOTORS .......................................................29
7.5.1 Belt Tension ......................................................................29
7.5.2 Sheave Condition..............................................................30
7.5.3 Motor Cleanliness .............................................................30
7.5.4 Motor Lubrication .............................................................30
7.6 ENTHALPIC CORES ...............................................30
7.6.1 Enthalpic Core Maintenance ..............................................30
7.6.2 Enthalpic Core Removal .................................................... 31
7.6.3 Enthalpic Core Replacement..............................................31
7.7 MAINTENANCE RECORDS .....................................32
TABLE OF CONTENTS

91.800.627.4499
HE-Series Indoor ERV
Figure 1.2.0 HE2XIN Airflow Orientations ................................... 12
Figure 2.4.0 E-Box With Motor Starters...................................... 13
Figure 3.2.0 HE2XINH Weights and COG..................................... 14
Figure 3.2.1 HE2XINH Weights and COG..................................... 15
Figure 4.2.0 HE2XINH Service Clearance ................................... 16
Figure 4.2.1 HE2XINV Service Clearance.................................... 16
Figure 5.4.0 E-Box Wiring Entry Points....................................... 18
Figure 5.5.0 Generic Single-Phase Wiring Schematic.................. 20
Figure 5.5.1 Generic Three-Phase Wiring Schematic .................. 21
Figure 5.6.0 Single 2-Wire Control, Unpowered .......................... 22
Figure 5.6.1 24 VAC From External Source ................................. 22
Figure 5.6.2 External Control Using ERV 24 VAC......................... 23
Figure 5.6.3 Control with 2 Non-Powered Relay Contacts ........... 23
Figure 5.6.4 Control with 2 “ON” Signals, External Power........... 23
Figure 6.4.0 HE2XINH Pressure Port Locations.......................... 26
Figure 6.4.1 HE2XINV Pressure Port Locations .......................... 26
Figure 6.4.2 Initial Pressure Drop of MERV 8 Filters,
Supplied With This Unit.............................................................. 27
Figure 6.4.3 Initial Pressure Drop of MERV 13 Filters,
Available as an Accessory.......................................................... 27
Figure 7.5.0 Fan Belt Tensioning ................................................ 30
Figure 7.8.0 HE2XINH Service Parts .......................................... 33
Figure 7.8.1 HE2XINV Service Parts .......................................... 34
7.8 SERVICE PARTS................................................... 33
7.8.1 HE2XINH Service Parts..................................................... 33
7.8.2 HE2XINV Service Parts .................................................... 34
8.0 TROUBLESHOOTING 35
9.0 FACTORY ASSISTANCE 35
TABLE OF CONTENTS
TABLE OF ILLUSTRATIONS

1.800.627.4499
10
HE-Series Indoor
ERV
CONFIGURATION CODE
MODEL NUMBER
"V", "H"
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25
J - - -
DIGIT NUMBER
Orientation
Digit 9:
Wall Type
Digit 11:
"S" = Single
"D" = Double
Phase
Digit 12:
"1" = Single Phase
"3" = Three Phase
Voltage (see Restrictions 1 & 2)
Digit 13:
"1" = 115V
"4" = 460V
"5" = 208-230V
"8" = 575V
FA Horsepower
Digit 14:
"U" = 1.5HP
"V" = 2HP
Flow Control*
Digit 18:
"-" = No Isolation Dampers (with no Bypass)
"D" = Motorized Damper both Airstreams (with no Bypass)
"E" = Motorized Damper EA or RA Airstream (with no Bypass)
"F" = Motorized Damper FA or OA Airstream (with no Bypass)
"0" = Drybulb Bypass Dampers only (no Isolation Dampers)
"1" = Drybulb Bypass with Motorized Dampers all Airstreams
"4" = Drybulb Bypass with Motorized Damper OA Airstream
"5" = Enthalpy Bypass Dampers only (no Isolation Dampers)
"6" = Enthalpy Bypass with Motorized Dampers all Airstreams
"9" = Enthalpy Bypass witih Motorized Damper OA Airstream
*NOTES:
Digit 6 "J" = G5 Core Type Digits 10, 16 and 17 are not used in these models.
*Digit 18: Flow Control: Codes for Bypass: Face damper also acts as Isolation damper in EA or RA Airstream.
Restrictions:
1: Voltage Codes "1" only available with Phase Code "1" (Single-Phase).
2: Voltage Codes "4" & "8" only available with Phase Code "3" (Three-Phase).
3: Some units with Customization Code "X" are not safety listed.
4: Unit Control Code "V" not available with Voltage Code "1".
Unit Control (see Restriction 4)
Digit 19:
"A" = Standard Unit Control Wiring
"V" = Onboard VFD Both Airstreams
Disconnect
Digit 20:
"N" = Non-Fused (Standard)
"F" = Fused
Unit Control Enhancements
Digit 21:
"T" = Transformer with Isolation Relay (Standard)
"1" = Enhanced Controls
"2" = Premium Controls
"3" = Enhanced Controls with BACNET License
"4" = Premium Controls with BACNET License
Filter Options
Digit 22:
"-" = None
"F" = Filter Monitor Both Airstreams
Other Options
Digit 23:
"-" = None (Reserved)
Paint and Customization
Digit 24:
"-" = None
"W" = White Paint
"C" = Custom Paint
"X" = Custom Unit
Safety Listing (see Restriction 3)
Digit 25:
"L" = Listed
"N" = Non-Listed
-HE - 2X I N
EA Horsepower
Digit 15:
"U" = 1.5HP
"V" = 2HP
HE2XIN MODEL
PRODUCT CODE CHART
CONFIGURATION CODE

111.800.627.4499
HE-Series Indoor ERV
1.0 OVERVIEW
The HE2XIN Energy Recovery Ventilator is a device for recovering both sensible energy (heat) and
latent energy (moisture) from the Exhaust Air from an Occupied Space and injecting those energies
into an incoming Outside Air stream. It accomplishes this task by forcing the two airstreams through
enthalpic cores, where the energy exchange takes place. The two airstreams pass through the
enthalpic cores at right angles and the airstreams never mix together. See Section 2.2 Enthalpic
Cores in this manual.
Each ERV has two electric blowers, one for each airstream. Fan speeds can be either single speed,
using adjustable sheaves to change fan speed, or they can be variable speed, controlled by VFDs,
a RenewAire Commercial Controller or by a BMS. There are a number of different control devices
available to control the operation or speed of the unit fans. For further information on available
control accessories, see the HE RenewAire catalog.
There are two types of HE2X units, one for indoor installations and one for rooftop, or outdoor,
installation. This manual is for the HE2XIN, which is the indoor unit. For information on the outdoor
version of this product, see the HE2XRT manual.
These ERVs are commonly installed as part of an air handling system that provides heating and
cooling of Supply Air. They can also be installed to operate as stand-alone devices when ducted
directly to and from the Occupied Space.
Each HE2XIN unit is available in either a horizontal or a vertical model. The difference between the
two models is in the airflow/ducting configuration. Horizontally ducted units are identified by the
model name HE2XINH and vertically ducted units are identified as model HE2XINV.
Each unit has an integral 24 VAC power supply that is used internally and can also be used as a
power source for other optional control devices.
The HE2XIN units are low-maintenance, requiring periodic replacement of the air filters,
lubrication of the motors and annual vacuuming of the enthalpic cores. See Section 7.0 Unit
Maintenance in this manual.
1.1 DESCRIPTION
IMPORTANT
It is important to understand and use the equipment airstream terminology as it is used in this
manual. The airstreams are defined as:
uOUTSIDE AIR (OA): Air taken from the external atmosphere and, therefore, not previously
circulated through the system.
uFRESH AIR (FA): Air that is downstream of the enthalpic cores and is ready for conditioning or
for return to the Occupied Space.
uRETURN AIR (RA): Air that is returned to the ERV from a conditioned space.
uEXHAUST AIR (EA): Air that is removed from a heating or cooling appliance or from the
Occupied Space and discharged.
OVERVIEW
There are two different airflow options for the HE2XIN. They are:
uHE2XINH
uHE2XINV
The airflow configuration is indicated by digit 9 of the Configuration Code.
1.2 AIRFLOW
NOTE: This unit is
an Energy Recovery
Ventilator, or ERV.
It is commonly referred to
throughout this manual as
an ERV.

1.800.627.4499
12
HE-Series Indoor
ERV
OVERVIEW
FA
OA
RA
EA
HEIN except 6x 8x, LE_IN
INH
FA
OA
EA
RA
HEIN except 6x 8x, LEIN
INV
FIGURE 1.2.0 AIRFLOW ORIENTATIONS
2.0 COMPONENT DESCRIPTIONS
2.2 ENTHALPIC CORES
2.1 CABINET
All HE2XIN ERVs use two static-plate enthalpic cores. The enthalpic cores transfer both latent
and sensible energies between the airstreams. Cores are bi-directional and may be rotated in
their mounting hardware, but care must be taken to install the correct side of the core toward
the unit door. Gasketing is pre-installed on the cores and must be positioned to provide a proper
air seal. For information on annual maintenance of the cores, see Section 7.0 Maintenance in
this manual.
The cabinet for the HE2XIN is made of 20 gauge galvanized steel and has 1" thick high-density,
foil-backed insulation on the inside. Units are available in either single-wall or double-wall
construction. Doors are hinged and are fitted with stainless steel machine screws through the
faces to prevent accidental opening of the doors when the unit is in operation. Doors may be
completely removed by removing the hinge pins. All units are equipped with adjustable-height
leveling legs for purposes of leveling the unit. Duct flanges are provided at all four airstream
openings for connection of field-supplied ductwork.
2.3 FAN/MOTOR ASSEMBLIES
There are two fan and motor assemblies in each ERV. The fans are belt-driven. All fans have
an adjustable sheave on the electric motor for purposes of adjusting the fan speed. The motors
require periodic inspection and lubrication. For information on adjusting sheaves, see Section
7.0 Maintenance.
Low air flow can cause
fouling of the enthalpic
cores. The ERV must never
be operated without clean
filters in place and minimum
airflow must be greater than
250 CFM per full-sized core.
CAUTION
MODEL DESCRIPTION OF DUCT CONNECTION CONFIGURATION
HE2XINH Room Air [RA] and Outside Air [OA] enter on the same side of the unit.
HE2XINV Room Air [RA] and Outside Air [OA] enter on opposite sides of the unit.

131.800.627.4499
HE-Series Indoor ERV
2.4 E-BOX
Every HE2XIN is equipped with what is known as an “E-Box.” High-voltage supply wiring and
low-voltage control wiring is all terminated here. When VFDs are installed in the unit, the VFD
keypads are installed here. If optional integrated programmable controls are installed, an
additional 24 VAC transformer is installed here to power both the controller and its dedicated
sensors.
FIGURE 2.4.0 E-BOX WITH MOTOR STARTERS
COMPONENTS
2.5 FILTERS
All HE2XIN units come equipped with 4 each MERV 8 20" X 20" X 2" thick pleated paper filters.
MERV 13 filters can be ordered as an option and are shipped loose.
2.6 FACTORY INSTALLED OPTIONS
All HE2XIN units can be ordered with factory installed options. See Unit Configuration Code on
page 10.
Options will have supplemental manuals shipped with the unit.
For Isolation Dampers, see Isolation Dampers Supplemental Manual.
For Commercial Controls, see Commercial Controls Supplemental Manual.
For Filter Alarm, see Filter Alarm Supplemental Manual.
For Economizer/Bypass, see Bypass Economizer Supplemental Manual.
For Variable Frequency Drive, see VFD Supplemental Manual.
3.0 SHIPPING/RECEIVING/HANDLING
HE2XIN units are palletized at the factory and then shipped by common carrier. Upon receipt
by the installer, the shipment should be inspected for shipping damage, prior to unloading. Any
discovered shipping damage should be immediately reported to the RenewAire sales rep and the
damage must be recorded on the Bill Of Lading, prior to signing for acceptance of the shipment.
The unit can be handled with a fork lift or a crane. Prior to moving the unit, verify that all
latches and securing bolts on the cabinet doors are tightly fastened.
www.renewaire.com (800) 627- 4499 [email protected]
GROUND BUS
DISCONNECT SWITCH
POWER SUPPLY WIRING
CONNECTED HERE ON TOP
OF DISCONNECT SWITCH
OPTIONAL UNIT FUSING
www.renewaire.com (800) 627- 4499 [email protected]
NOTE: Every ERV
has an attached
electrical connec-
tion box, known as
the E-Box. It is attached to
the outside of the ERV and
all electrical connections
are made there. There is
a high-voltage side and
a low-voltage side. See
Figure 2.4.0.
24 VAC STEP-DOWN TRANSFORMER
(WITH BUILT-IN CIRCUIT BREAKER)
LOW-VOLTAGE TERMINAL STRIP
(ALL CONTROL WIRING IS CONNECTED HERE)

1.800.627.4499
14
HE-Series Indoor
ERV
If a crane is used for moving the HE2XIN unit, unscrew the sheet metal plates that hold the
adjustable legs to the pallet. Use two hoisting slings and a spreader bar to hoist the unit. The
hoisting slings must be positioned around the ends of the unit so they do not touch the unit
doors. Unit hoisting weights and Center of Gravity are detailed in Section 3.1 and 3.2 in this
manual.
Perform a test lift to make sure the unit is being hoisted level and is secure.
Place the HE2XIN unit on a flat surface where it will be protected from the weather and
incidental damage. Do not remove protective coverings from any duct openings and keep the
doors secured and tightly closed.
3.1 UNIT WEIGHTS AND DIMENSIONS
3.1.1 Unit Dimensions and Weight
HE2XINH: 64 1/2" L x 43" W x 35 1/2" H
406–619 lbs., varies by option(s)
HE2XINV: 50 1/2" L x 42" W x 52 1/2" H
363–583 lbs., varies by option(s)
HE2XINH: 70" L x 47" W x 40" H
714 lbs.
HE2XINV: 70" L x 47" W x 57" H
678 lbs.
3.1.2 Shipping Dimensions and Weight
SHIPPING/RECEIVING
3.2.1 HE2XINH Hoisting Weights and COG
4/22/09 MF
SPECIFICATIONS SUBJECT
TO CHANGE WITHOUT NOTICE.
RenewAire LLC
Scale: 1" = 24"
Do not scale drawing
HE2XH_CORNER_WEIGHTS_MAR20.dwg
HE2XH Corner Weights
LR RR
RF
LF
UNIT COG
RANGE
BASIC UNIT WEIGHTS (lbs.)
Motors UNIT LF LR RR RF
1.5 HP 433 123 122 87 101
2 HP 442 126 124 89 103
ADDITIONAL WEIGHTS FOR OPTIONS (lbs.)
Options UNIT LF LR RR RF
Double Wall 103 27 26 25 25
By-Pass 18 5 5 44
VFDs 8
2222
RA or EA Damper 24 1 11 11 1
OA or FA Damper 24 1 1 11 11
Total Selected Weights
Add the additional weights for options to the Basic Module weights
determined by motor size to determine Module and Corner weights for a
specific unit.
Center of gravity: From Left A = 23", From Front B = 20" (+/- 2")
Mounting Leg Pitch
MAY18 MHK
1/2/19 MHZ
B
A
8/26/19 KMC
48.00"
36.00"
Mounting
Leg Pitch
2.00"
.625"
MAR20 KMC
FIGURE 3.2.0 HE2XINH WEIGHTS AND COG
3.2 RIGGING AND CENTER OF GRAVITY

151.800.627.4499
HE-Series Indoor ERV
3.2.2 HE2XINV Hoisting Weights and COG
4/22/09 MF
SPECIFICATIONS SUBJECT
TO CHANGE WITHOUT NOTICE.
RenewAire LLC
Scale: 1" = 24"
Do not scale drawing
HE2XV_CORNER_WEIGHTS_AUG19.dwg
HE2XV Corner Weights
BASIC UNIT WEIGHTS (lbs.)
Motors UNIT LF LR RR RF
1.5 HP 412 108 101 98 105
2 HP 420 110 104 100 106
ADDITIONAL WEIGHTS FOR OPTIONS (lbs.)
Options UNIT LF LR RR RF
Double Wall 91 25 20 20 25
By-Pass 16 11
77
VFDs 8
2 2 22
RA or EA Damper 24 1 11 11 1
OA or FA Damper 24 1 11 11 1
Total Selected Weights
Add the additional weights for options to the Basic Module weights
determined by motor size to determine Module and Corner weights for a
specific unit.
Center of gravity: From Left A = 17", From Front B = 19" (+/- 2")
MAY18 MHK
1/2/19 MHZ 8/26/19 KMC
LR RR
RF
LF
B
A
33.75"
34.50"
Mounting
Leg Pitch
Mounting Leg Pitch
UNIT COG
RANGE
2.00"
.625"
MAR20 KMC
FIGURE 3.2.1 HE2XINV WEIGHTS AND COG
3.3 RECEIVING
Upon receipt of the HE2XIN, inspect the unit for obvious external damage. If damage is
observed, take digital pictures and report the damage to your RenewAire rep. Note the damage
on the carrier’s Bill of Lading. Depending on expected transport and storage conditions, the unit
may have only the duct openings covered, it may be stretch-wrapped or it may be crated. Do
not unwrap the unit at this time. The unit will normally be moved to its final location while still
wrapped and attached to its pallet.
The preferred method of hoisting the HE2XIN from the carrier truck is by using a construction
forklift.
Once the unit is unwrapped, prevent dirt and debris from entering the cabinet by covering any
duct openings that do not have attached dampers. Keep the duct openings covered until it’s
time to connect ductwork.
SHIPPING/RECEIVING
3.4 HANDLING AND STORAGE
Units that must be stored prior to installation should be left on their pallets and protected from
weather and physical damage. Units must be placed on a level surface to prevent wracking of
the pallet and the HE2XIN. All access doors must be secured with all available hardware (door
latches and securing bolts) and all openings into the cabinet must be sealed to prevent entry of
dust, dirt and debris.
4.0 UNIT PLACEMENT
4.1 BEFORE YOU BEGIN
Units that must be stored prior to installation should be left on their pallets and protected from
weather and physical damage. Units must be placed on a level surface to prevent wracking of
the pallet and the HE2XIN. All access doors must be secured with all available hardware (door
latches and securing bolts) and all openings into the cabinet must be sealed to prevent entry of
dust, dirt and debris.
The HE2XIN is designed for installation in a sheltered location, out of the weather. The preferred
mounting location is to place the unit on a concrete floor, although it can also be suspended
from a ceiling or other structural support. See Section 5.3, Suspended Mount, in this manual.

1.800.627.4499
16
HE-Series Indoor
ERV
For all installations, maintain needed service clearances as shown on the dimensioned drawings
located in Section 4.2 of this manual. In addition, if the optional Bypass Economizer is ordered,
additional clearance will be required for the extra bypass duct. See the RenewAire Supplemental
Manual for Bypass or further information and clearance details specific to the HE2XIN units.
For all floor-mount installations, the unit should be set on its factory-provided adjustable legs
and leveled. Select a location that is central to the inside duct runs and close to both the
exhaust duct (to the outside) and also to the fresh air duct (from the outside).
The exhaust outlet and the outside air inlet on the outside of the building should be at least ten
feet apart to avoid cross-contamination. Comply with all local building codes in the positioning
of the duct openings. Do not position the exhaust air outlet in a location where it will dump
exhaust air into any enclosed or occupied space. The duct inlets and outlets should be screened
against insects and vermin and should be shielded from the weather to prevent entry of rain or
snow.
UNIT PLACEMENT
4.2 SERVICE CLEARANCES





 





















































 

 























RA
FA
BP
EA
OA
BYPASS AIRFLOW SCHEMATIC
FRONT VIEW
34 7/8" Case
4 1/4" Duct
Flange Typ.
C
L
2 5/8" Control In
C
L
5 3/4" Power In
5" Damper
Frames Typ.
Pressure Ports
(4) Typ.
Disconnect
Switch
E-Box
RA
OA
FA
EA
BP
51 1/2" Overall
33 5/8" Minimum
Service Area
34 7/8" Minimum
Service Area
41 5/8" Case
42" Overall
Door
Swing
37"
17 5/8"
12 3/8"
3/4" - 1 7/8" Typ.
10 3/8"
1 3/4" Typ.
8 1/4"
16" X 16"
Bypass
Damper
Location
(Optional)
OA Inlet
24" X 14"
Duct Receiving
Flange
OA Damper
Location
(Optional)
37"
51 5/8" Case
52 3/8" Overall
9 3/8" Wiring
C
L
5 3/8"
Wiring
8 1/4"
Bypass
Location
16" X 12"
Duct Receiving
Flange Typ.
RA Inlet
24" X 14"
Duct Receiving
Flange
Isolation Damper
(Optional)
Acts as Face Damper
for Bypass Units
RIGHT VIEW FRONT VIEW LEFT VIEW
(2) 7/8" Holes
for Wiring in
Bottom of E-Box
TOP VIEW
16" X 16" Bypass Duct Connection
(Direct Mount to Damper, By Others)
Face
Damper
Bypass
Damper
Model: HE2XINV [Bypass]
Drawing Type: Unit Dimension
Version: MAY18
ABBREVIATIONS
EA: Exhaust Air to outside
OA: Outside Air intake
RA: Room Air to be exhausted
FA: Fresh Air to inside
BP: Bypass Air Intake
INSTALLATION ORIENTATION
Unit must be installed in orientation
shown.
NOTE
1. UNLESS OTHERWISE SPECIFIED,
DIMENSIONS ARE ROUNDED TO THE
NEAREST EIGHTH OF AN INCH.
2. SPECIFICATIONS MAY BE SUBJECT
TO CHANGE WITHOUT NOTICE.
3. MIN. DUCT CLEARANCE
FROM DAMPER BLADE WHEN FULLY
OPENED TO BE 2". SMACNA RULES
APPLY.
4. UNITS WITH BYPASS WILL REQUIRE
ADDITIONAL SPACE FOR THE
CONNECTION OF THE BYPASS DUCT
(BY OTHERS).
5. FOR INSTALLATION DETAILS, REFER
TO I&O MANUAL SUPPLEMENT FOR
BYPASS.
FIGURE 4.2.0 HE2XINH SERVICE CLEARANCE FIGURE 4.2.1 HE2XINV SERVICE CLEARANCE
4.3 SOUND ATTENUATION
Take these simple steps to attenuate noise from the unit.
4.3.1 Outside the Building
Exhaust velocity noise is the primary cause of unit-related noise outside the building. Size the
exhaust duct and grille for less than 1000 FPM air velocity. When practical, orient the exhaust
air hood to point away from houses or public areas.
4.3.2 Ducts
Make sure the ductwork at the unit outlets is stiff enough to resist the flexure and resulting
booming associated with system start-up and shut-off, as well as the turbulent flow conditions
at the blower outlets.
In general, provide smooth transitions from the ERV’s outlets to the duct. The ducts connecting
to the outlets should be straight for a sufficient distance, with gradual transitions to the final
duct size.
These guidelines are consistent with SMACNA recommended duct layout practices for efficient
and quiet air movement. Follow SMACNA guidelines.

171.800.627.4499
HE-Series Indoor ERV
INSTALLATION
5.0 INSTALLATION
5.2 FLOOR INSTALLATION
Most units are installed in a location specified by others. In general, it’s preferable to install the
unit on a flat, reasonably level surface, such as a concrete floor. The factory-installed leveling
legs are to be used to level the unit before connecting ductwork. When positioning the unit, it is
not to be slid on its adjustable legs because they can be bent.
4.3.3 Radiated Noise
The HE2XIN is insulated with high-density fiberglass. This provides significant attenuation of
radiated sound.
The outlet ducts can be significant sources of radiated sound as well. The FA and EA ducts
(outlet ducts) should be insulated for sound control. This insulation should start at the unit. At a
minimum the first ten feet of duct should be insulated. All parts of the FA and EA ducts located
in the mechanical space should be insulated for sound control, both to minimize sound radiation
out of these ducts and also to control sound radiation into the ducts.
4.3.4 Aerodynamic (Velocity) Noise
When sound attenuation is a design concern, the primary consideration is velocity noise at the
unit’s Fresh Air blower outlet. The average velocity at the blower outlets is 3642 FPM when the
unit is operating at 1500 CFM.
5.1 DUCTWORK
5.1.1 Ducts to the Outside
The exhaust outlet and fresh air inlet on the outside of the building should be at least 10' apart
to avoid cross-contamination. The exhaust outlet should not dump air into an enclosed space or
any other structure. The inlets and outlets should be screened against insects and vermin and
shielded from the weather to prevent the entry of rain or snow.
Ducts connecting the HE2XIN to the outside must be insulated, with sealed vapor barrier
on both inside and outside of the insulation. Insulate both the Outside Air (OA) and Exhaust Air
(EA) ducts.
5.1.2 Inside Ductwork System
Ensure Good Ductwork Design
Ductwork should be designed to allow the unit to provide the required airflow and reduce
pressure drop for efficient, quiet operation. If the inside ducts run through unconditioned spaces
they must be insulated with a sealed vapor barrier on both inside and outside of insulation.
NOTE: Ducts inside
a building that are
connected to the
outside must be
insulated with a sealed
vapor barrier on both the
inside and the outside of the
insulation.
5.3 SUSPENDED MOUNT
HE2XIN units can also be suspended from a ceiling or other structural member. The preferred
method of support is to remove the four adjustable legs and bolt heavy-gauge Unistrut or other
structural channels to the underside of the unit, using the 3/8-16" threaded holes where the
adjustable legs were located.
Install 3/8-16 bolts through the channels, into the bottom of the unit. Support the channels from
threaded rods, located in an appropriate location that maintains required service clearances.
NOTE: It is the
installer’s respon-
sibility to select
appropriate materials
capable of safely support-
ing the weight of the ERV
and all attached hardware,
such as ductwork. It is the
installer’s responsibility to
determine the location of
the ERV and the needed
supporting threaded rods.
All such installations must
be reviewed and approved
by an engineer.

1.800.627.4499
18
HE-Series Indoor
ERV
INSTALLATION
5.4 ELECTRICAL REQUIREMENTS
5.4.1 Factory-Recommended Electric Service Entry
Knockouts are provided in the bottom of the E-box for entry of high-voltage power supply
wiring. Install the wiring in accordance with local codes and provide strain relief at the E-box
opening. Wiring is then terminated on the top of the disconnect switch.
Low-voltage control wiring is to enter the E-box through the knockout in the bottom of the
E-box. Provide strain relief as needed.
High-voltage supply wiring is to be connected on the top side of the disconnect switch. See
Figure 5.4.0 below.
ARC FLASH AND ELECTRIC SHOCK HAZARD
Arc flash and electric shock hazard. Disconnect all electric power supplies, verify with a voltmeter
that electric power is off and wear protective equipment per NFPA 70E before working within
electric control enclosure. Failure to comply can cause serious injury or death.
Customer must provide earth ground to unit, per NEC, CEC and local codes, as applicable.
Before proceeding with installation, read all instructions, verifying that all the parts are included
and check the nameplate to be sure the voltage matches available utility power.
The line side of the disconnect switch contains live high-voltage.
The only way to ensure that there is NO voltage inside the unit is to install and open a remote
disconnect switch and verify that power is off with a volt meter. Refer to unit electrical schematic.
Follow all local codes.
FIGURE 5.4.0 E-BOX WIRING ENTRY POINTS
WARNING
www.renewaire.com (800) 627- 4499 [email protected]
HIGH-VOLTAGE SUPPLY
WIRING ENTRY
HIGH-VOLTAGE SUPPLY
WIRING IS TERMINATED
ON THE TOP OF THE
DISCONNECT SWITCH
LOW-VOLTAGE CONTROL
WIRING ENTRY

191.800.627.4499
HE-Series Indoor ERV
INSTALLATION
If primary-side voltage
is 230 VAC, move black
primary-side lead from
transformer’s “208 V”
terminal to the transform-
er’s terminal marked “240
V” (“230 V” in some units).
Do not move the black
primary-side lead that is
connected to the trans-
former’s “COM” terminal.
NOTICE
5.4.2 Low Voltage Control System
This ERV is provided with a Class II 24 VAC power supply system that operates the unit’s
contactor(s) for HE2XIN. The ERV’s 24 VAC Power Supply can also be used to power the
externally-installed controls system: up to 8VA of power is available.
The unit’s power supply system includes isolation relay(s) so you can use external controls
whose contact ratings are as low as 50 mA (1.2 VA). Also, it is possible to operate the isolation
relays with 24 VAC power from an external source (with proper wiring connections).
A built-in circuit-breaker prevents damage to the transformer and other low-voltage
components in the event of a short-circuit or overload. In extreme cases, the transformer itself
is designed to fail safely.
Specifications:
uNominal Output Voltage under load: 24 VAC
uTypical Output Voltage at no load: 29–31 V
uMinimum contact rating for connected control device: 50 mA (1.2 VA)
uCircuit Breaker Trip Point: 3 A
5.4.3 How to Reset the 24 VAC Circuit Breaker
If the transformer is subjected to an excessive load or a short circuit, the circuit breaker will trip
to prevent the failure of the transformer. When it trips the circuit breaker’s button pops up. Shut
off the primary-side power to the unit, and remove the excessive load or the short. The circuit
breaker can be reset about fifteen seconds after it trips by pressing in the button.
Wire Gauge #22 #20 #18 #16 #14 #12
Circuit Length 100' 150' 250' 400' 700' 1000'
"Circuit Length" is distance from ERV to Control Device.
Observe these limits to wire length and gauge in order to ensure reliable operation of the
control system.
5.4.4 Limits of Power Output
If limits on wire gauge and length are observed, you may connect control devices that draw
up to 8 VA to the blue and red wires. More than one device can be connected as long as total
steady-state load does not exceed 8 VA.
Be careful if the external
control system provides 24
VAC power at its control
output: make sure blue
and red leads are sep-
arately capped and not
connected to any other
wires.
CAUTION
1. Connect only to components intended for use with 24 VAC power.
2. Do not undersize the low-voltage wires connected to this device. Observe the wire length
and gauge limits indicated in this manual.
3. Do not overload this unit’s 24 VAC power supply system. Confirm that the power require-
ments of devices you connect to this power supply system do not exceed 8 VA in total.
4. If an external source of 24 VAC power is used to control the unit, consult the wiring
schematics and connect the external power only to the specified terminals in order to
avoid damaging the unit or external controls. Connect only CLASS II power to the control
terminals of this unit.
5. Unit is not equipped to receive analog signals (such as 1–10 vdc or 4–20 mA).
CAUTION

1.800.627.4499
20
HE-Series Indoor
ERV
5.5 WIRING SCHEMATICS
CHANGESNAMEREV. DATE
Description
Family
Config
No Dampers
RenewAire
1
A B C D E
New0 11/13/2017 austine
15/18/2018 austine Updated wire colors 28/9/2018 austine Added Wire Color Labels
HE-2_HE-4XJxxx-x11,15xx--xAxTx-xx
2 3 4 5 6 7 8 9
10 11 12 13
HE-2_HE-4XJxxx-x11,15xx---AxTx-xx_002
1
2
3
4
5
Contactor Overload
24 VAC
A1 A2 95 96
1L1
3L2
5L3
2T1
4T2
6T3
Exhaust
Contactor Overload
24 VAC
A1 A2 95 96
1L1
3L2
5L3
2T1
4T2
6T3
Supply
M
Supply Fan
Exhaust Fan
GND
L3L2
L1
Input Power
115 VAC, 1 Phase
208-230 VAC, 1 Phase
Transformer
COM 24V
F1
Relay
24 VAC
13 14
812
4
Exhaust
Relay
24 VAC
13 14
812
4
Supply
RD
RD BU
BU
BKBK
RD
RD
RD
RD
RD
RD RD
BU
BU
BU BU
YL
RD RD
YL
YL
FIGURE 5.5.0 GENERIC SINGLE-PHASE WIRING SCHEMATIC
