Emerson KF180 User manual

Net Weight:
30.9 Lbs.
Part No. F40BP72840003 Form No. BP7284-3
U.L. Model No.: KF180
READ AND SAVE THESE INSTRUCTIONS
KF180AP01
Antique Pewter with Natural
Cherry/Mahogany Blades
KF180OZ01
Olde Bronze¨with
Teak/Natural Pine Blades
KF180DBK01
Distressed Black with Distressed
Black/Natural Cherry Blades
STURBRIDGE
Ceiling Fan Owner's Manual
Emerson Fans
Designed by
Model Numbers
BP7284, Sturbrige, KF180 7/31/06 10:52 AM Page 1

WARNING: To avoid fire, shock, and serious personal injury, follow these
instructions. Safety Instructions
1. Read your owner’s manual carefully and keep it for future reference.
2. Before servicing or cleaning unit, switch power off at service panel and
lock service panel disconnecting means to prevent power from being
switched on accidentally. When the service disconnecting means cannot
be locked, securely fasten a warning device, such as a tag, to the service
panel.
3. Be careful of the fan and blades when cleaning, painting, or working near
the fan. Always turn off the power to the ceiling fan before servicing.
4. Do not put anything into the fan blades while they are turning.
5. Do not operate reversing switch until fan blades have come to a complete
stop. Additional Safety Instructions for Installation
1. To avoid possible shock, be sure electricity is turned off at the fuse box
before wiring, and do not operate fan without blades.
2. The installation is to be in accordance with the National Electrical Code,
ANSI/NFPA 70-1999 and Local Electrical Codes. Use the National Electrical
Code if Local Codes do not exist. The ceiling fan must be grounded as a
precaution against possible electrical shock. Electrical installation should
be made or approved by a licensed electrician.
3. The outlet box and joist must be securely mounted and capable of reliably
supporting at least 50 pounds. Use only U.L. outlet boxes listed as
“Acceptable for Fan Support”, and use the mounting screws provided with
the outlet box. Most outlet boxes commonly used for support of light
fixtures are not acceptable for fan support and may need to be replaced.
Consult a qualified electrician if in doubt.
4. The downrod furnished with the fan provides the minimum recommended
floor to fan blade clearance for a 8 foot ceiling.
5. The fan must be mounted with the fan blades at least 7 feet from the floor
to prevent accidental contact with the fan blades.
6. Follow the recommended instructions for the proper method of wiring
your ceiling fan. If you do not know enough about electrical wiring, have
your fan installed by a licensed electrician.
NOTE: This fan is suitable for use with solid-state speed controls.
WARNING: To reduce the risk of fire or electric shock, this fan should only
be used with fan speed control Model No. UC7067RC, manufactured by Rhine
Electric Co., Ltd.
WARNING: This product is designed to use only those parts supplied with
this product and/or any accessories designated specifically for use with this
product by Emerson Electric Co. Substitution of parts or accessories not
designated for use with this product by Emerson Electric Co. could result in
personal injury or property damage.
WARNING: To reduce the risk of personal injury, do not bend the blade
flange when installing the blade flanges, balancing the blades or cleaning the
fan. Do not insert foreign objects in between rotating fan blades.
WARNING: To reduce the risk of electrical shock, this fan must be installed
with an isolating wall control/switch.
!WARNING
DATE CODE:
The date code of this fan may be found on the box, stamped in ink on a white label. You should
record this data above and keep it in a safe place for future use.
2
BP7284, Sturbrige, KF180 7/31/06 10:52 AM Page 2

3
Tools Needed for Assembly
One Phillips head screwdriver
One wire stripper
Six wire connectors (supplied)
Three 60-watt (max.) candelabra base bulbs
Materials
Wiring, outlet box and box connectors
must be of type required by the local code.
The minimum wire would be a 3-conductor
(2-wire with ground) of the following sizes:
Installed Wire Length Wire Size A.W.G.
Up to 50 ft. 14
50-100 ft. 12
This Manual Is Designed to Make it as Easy as Possible for You to
Assemble, Install, Operate and Maintain Your Ceiling Fan
Unpacking Instructions
For your convenience, check-off boxes
are provided next to each step. As each
step is completed, place a check mark
in the box. This will insure that all steps
have been completed and will be help-
ful in finding your place should you be
interrupted.
Do not install or use fan if any part is
damaged or missing. Call Toll-Free:
1-800-654-3545
!WARNING
This product is designed to use only
those parts supplied with this product
and/or any accessories designated
specifically for use with this product by
Emerson Electric Co. Substitution of
parts or accessories not designated for
use with this product by Emerson Electric
Co. could result in personal injury or
property damage.
!WARNING
a. Fan motor and housing assembly
b. One ceiling cover
c. One adapter/light fitter assembly
d. Five fan blades
e. Five blade flanges
f. One hanger bracket
g. One hanger ball/downrod assembly
h. One lower ring assembly (with six ring
screws attached)
i. One lower glass
j. One remote control transmitter
k. One remote control receiver
l. One loose parts bag, containing:
1. Two 1-1/4” threaded studs
2. Two knurled knobs
3. Two lockwashers
4. Seven wire connectors
5. One hairpin clip
6. One clevis pin
7. Eleven 1/4-20 x 11mm pan head
screws with lockwashers
8. Sixteen 10-24 x 9mm truss
head screws
9. Sixteen fiber washers
10.Four 8-32 x 12mm pan head screws
NOTE: Place the parts from the loose parts
bags in a small container to keep them from
being lost. If any parts are missing, contact
your local retailer or catalog outlet for
replacement before proceeding.
B
C
EK
A
F
LI
H
HIOFF
LOWMED
J
D
G
1. Open styrofoam unit containing fan.
Remove top half of styrofoam unit.
Remove parts and check to see that
you have received the following parts:
NOTE: If you are uncertain of part
description, refer to exploded view
illustration.
BP7284, Sturbrige, KF180 7/31/06 10:52 AM Page 3

Preset Memory Feature
Your remote control receiver is equipped
with a preset memory feature. The receiv-
er will remember the light intensity and fan
speed when the light and fan are turned off
from the wall switch. When the wall switch
is turned back on, the lights and fan will
resume operation as they were prior to the
switch being turned off.
Installation of Battery
1. Remove the battery cover by pressing
firmly below the arrow and sliding the
cover off the control (Figure 1).
2. Engage the connector in the transmitter
with the terminals of a 9-volt alkaline
battery (not supplied).
2. Remove the fan motor and housing
assembly from the protective plastic
bag. Place the fan assembly into the
lower foam pad with the bottom of the
motor facing up.
The lower foam pad serves as a holder
for the fan during the first stages of
assembly.
General
Your Emerson ceiling fan comes equipped
with a remote control transmitter and a
remote control receiver. This remote con-
trol systems is designed to control your
ceiling fan speed and light intensity.
NOTE: An optional SW101 Wall Control
(not supplied) may also be used with
the remote control receiver supplied
with your ceiling fan.
IMPORTANT
This Owner’s Manual is divided into
two sections. The first section,
REMOTE CONTROL PROCEDURES,
describes how to install the 9-volt alka-
line battery (not supplied) in the remote
control transmitter, and how to set the
operating frequency of the transmitter
and receiver. These instructions must
be performed prior to the installation of
the ceiling fan as described in the
second section, CEILING FAN PROCE-
DURES.
REMOTE CONTROL
PROCEDURES
General
The remote control system is designed to
separately control your ceiling fan and
light intensity. There are four push buttons
on the transmitter (HI, MED, LOW, OFF) to
set the fan speed and turn the fan off. The
light push button turns the light on
and controls the light intensity. The red
indicator light will illuminate while any but-
ton is pressed, indicating that the battery is
good.
4
BATTERY
COVER
BATTERY
Battery
BATTERY
CONNECTOR
REMOTE CONTROL
TRANSMITTER
SWITCH
LEVERS
CODE
SWITCH
1234
ON
RECEIVER
Setting Operating
Frequency of Transmitter
and Receiver
Your remote control transmitter and
receiver have code switches which must
be set on one of 16 possible code combi-
nations. The four levers (numbered 1, 2, 3,
and 4) on the switches are factory-set in
the ON (up) position. Do not use this
setting. Change the switch settings as
follows:
1. On the remote control transmitter,
locate the code switch just above the
battery compartment (Figure 1).
Figure 1
BP7284, Sturbrige, KF180 7/31/06 10:52 AM Page 4

2. Slide the four switch levers on the code
switch to your choice of ON (up) or
down positions. Use a ball-point pen or
small screwdriver and slide the levers
firmly up or down.
3. In the receiver (Figure 1), slide the four
switch levers to the same positions as
set in the transmitter. Make sure the
levers on both switches are in the same
positions, otherwise the fan will not
operate.
4. Position the battery in the transmitter
battery compartment and replace the
battery cover.
CEILING FAN
PROCEDURES
Electrical Requirements
Your new ceiling fan will require a ground-
ed electrical supply line of 120 volts AC,
60 Hz, 15 amp circuit.
The outlet box must be securely anchored
and capable of withstanding a load of at
least 50 pounds.
5
To reduce the risk of fire, electric
shock, or personal injury, mount fan
to outlet box marked “Acceptable for
Fan Support”, and use screws sup-
plied with outlet box. Most outlet
boxes commonly used for support of
light fixtures are not acceptable for
fan support and may need to be
replaced. Consult a qualified electri-
cian if in doubt.
!WARNING
Turning off wall switch is not suffi-
cient. To avoid possible electrical
shock, be sure electricity is turned off
at the main fuse box before wiring. All
wiring must be in accordance with
National and Local codes and the ceil-
ing fan must be properly grounded as
a precaution against possible electri-
cal shock.
!WARNING
How to Assemble Your
Ceiling Fan
1. Remove the hanger ball by loosening
the setscrew in the hanger ball until the
ball falls freely down the downrod
(Figure 2). Remove the pin from the
downrod, then remove the hanger ball.
Retain the pin and hanger ball for rein-
stallation in step 5.
2. Unscrew the two upper setscrews
(Figure 3) until they clear the inside of
the motor coupling. Then separate,
untwist and unkink the three 80” motor
leads. Route the motor lead wires
through the downrod. Align the clevis
pin holes in the downrod with the holes
in the motor coupling. Install the clevis
pin and secure with the hairpin clip
(Figure 3). The clevis pin must go
through the holes in the motor coupling
and the holes in the downrod. Be sure
to push the straight leg of the hairpin
clip through the hole near the end of
the clevis pin until the curved portion of
the hairpin clip snaps around the clevis
pin. The hairpin clip must be properly
installed to prevent the clevis pin from
working loose. Pull up on the downrod
to make sure the clevis pin is properly
installed.
To avoid possible fire or shock, fol-
low all wiring instructions carefully.
Any electrical work not described in
these instructions should be done or
approved by a licensed electrician.
!WARNING
If your fan is to replace an existing ceiling
light fixture, turn electricity off at the main
fuse box at this time and remove the exist-
ing light fixture.
PIN
HANGER
BALL
SETSCREW
DOWNROD
Figure 2
BP7284, Sturbrige, KF180 7/31/06 10:52 AM Page 5

6
It is critical that the clevis pin in the
motor coupling is properly installed
and the setscrews securely tight-
ened. Failure to verify that the pin
and setscrews are properly installed
(as shown in Figure 3) could result in
the fan falling.
!WARNING
HAIRPIN
CLIP DOWNROD
CLEVIS
PIN
MOTOR COUPLIN
G
SETSCREW (2)
Figure 3
3. Tighten the setscrews (Figure 3)
securely while pulling up on the down-
rod.
NOTE: The setscrews must be properly
installed as described above, or fan
wobble could result.
4. Place the ceiling cover over the down-
rod as shown in Figure 4.
HANGER BALL
PIN
CEILING
COVER
DOWNROD SETSCREW
Figure 4
5. Reinstall the hanger ball (Figure 4) on
the downrod as follows. Route the
three 80” motor leads through the
hanger ball and slide the hanger ball
over the downrod. Position the pin
through the two holes in the downrod
and align the hanger ball so the pin is
captured in the groove in the top of the
hanger ball. Pull the hanger ball up tight
against the pin and securely tighten the
setscrew in the hanger ball. A loose
setscrew could create fan wobble.
It is critical that the pin in the hanger
ball is properly installed and the
setscrew securely tightened. Failure
to verify that the pin and setscrew
are properly installed could result in
the fan falling.
!WARNING
6. The fan comes with blue, black, and
white leads that are 80” long. Before
installing the fan, measure up approxi-
mately 6 to 9-inches above top of hang-
er ball/downrod assembly. Cut off
excess leads and strip back insulation
1/2” from end of leads.
7. Mount the fan blades to the blade
flanges using four 10-24 x 9mm truss
head screws and four fiber washers
(supplied) (Figure 5).
To reduce the risk of personal injury,
do not bend the blade flange when
installing the blade flanges, balanc-
ing the blades or cleaning the fan. Do
not insert foreign objects in between
rotating fan blades.
!WARNING
BLADE FLANGE
FAN BLADE
FIBER WASHER (3)
10-24 x 9mm
TRUSS HEAD SCREW (3)
Figure 5
BP7284, Sturbrige, KF180 7/31/06 10:52 AM Page 6

7
8. Turn the fan motor and housing assem-
bly upside down in preparation for
mounting the fan blade assemblies.
Remove and discard the three shipping
retainers securing the motor hub in the
motor housing.
NOTE: Take care not to scratch the fan
housing when installing the blade
assemblies.
9. Insert a 1/4-20 x 11mm pan head screw
with lockwasher (supplied) into each of
the recessed holes in one of the blade
flanges.
10. Align one of the threaded holes in the
motor hub with one of the slots in the
adapter plate (Figure 6). Position the
blade flange on the motor hub so one
of the screws in the blade flange aligns
with this threaded hole. Loosely tight-
en the screw. Rotate the motor hub
until the other flange screw can be
tightened through the slot of the
adapter. Repeat this procedure for the
remaining four blade assemblies, then
securely tighten all the screws.
SLOT FOR FLANGE
SCREW ACCESS
ADAPTER PLATE
1/4-20 x 11mm PAN
HEAD SCREW WITH
LOCKWASHER (2)
BLADE FLANGE
MOTOR HUB
Figure 6
ADAPTER
ASSEMBLY
ADAPTER PLATE
WHITE WIRES
BLACK
WIRES
8-32 x 12mm PAN
HEAD SCREW (2)
Figure 7
ADAPTER/LIGHT
FITTER ASSEMBL
Y
TIGHTEN TWO
SCREWS
INSTALL ONE
8-32 x 12mm
PAN HEAD
SCREW
Figure 8
11. Connect the white wire from the light
fitter to the white wire from the motor
(Figure 7). Connect the black wire
from the light fitter to the black wire
from the motor. Make sure both con-
nectors are securely engaged.
12. Partially install two 8-32 x 12mm pan
head screws (supplied) in two of the
threaded holes in the rim of the
adapter plate (Figure 7).
13. Position the two slots in the
adapter/light fitter assembly over the
two 8-32 x 12mm screws in the rim of
the adapter plate (Figure 8). Turn the
adapter/light fitter assembly counter-
clockwise and tighten the screws.
14. Install another 8-32 x 12mm pan head
screw in the remaining hole to secure
the adapter/light fitter assembly
(Figure 8).
15. You have completed the assembly of
your new ceiling fan. You can now pro-
ceed with hanging and wiring your fan.
BP7284, Sturbrige, KF180 7/31/06 10:52 AM Page 7

2. Carefully lift the fan and seat the hang-
er ball/downrod assembly on the hang-
er bracket that was just attached to the
outlet box (Figure 11). Be sure the
groove in the ball is lined up with the
tab on the hanger bracket (Figure 10).
How to Hang Your Ceiling Fan
The fan must be hung with at least 7'
of clearance from floor to blades
(Figure 9).
!WARNING
The outlet box and joist must be
securely mounted and capable of
supporting at least 50 lbs. Use only a
U.L. outlet box listed as “Acceptable
for Fan Support”.
!WARNING
To reduce the risk of fire, electric
shock, or personal injury, mount fan
to outlet box marked “Acceptable for
Fan Support”, and use screws sup-
plied with outlet box. Most outlet
boxes commonly used for support of
light fixtures are not acceptable for
fan support and may need to be
replaced. Consult a qualified electri-
cian if in doubt.
!WARNING
CEILING
AT LEAST
7'
FLOOR
Figure 9
1. Securely attach the hanger bracket to
the outlet box using the two screws
supplied with the outlet box (Figure 10).
Hanger bracket must seat firmly
against outlet box. If the outlet box is
recessed, remove wall board until
bracket contacts box. If bracket
and/or outlet box are not securely
attached, the fan could wobble or
fall.
!WARNING
Failure to seat tab in groove could
cause damage to electrical wires and
possible shock or fire hazard.
!WARNING
To avoid possible fire or shock, do
not pinch wires between the hanger
ball/downrod assembly and hanger
bracket.
!WARNING
TWO SCREWS
SUPPLIED
WITH
OUTLET BOX HANGER
BRACKET
TAB
OUTLET
BOX
NOTE: CEILING COVER, SUPPLY WIRES AND FAN
WIRES OMITTED FOR CLARITY.
OUTLET
BOX
HANGER
BRACKET
HANGER BALL/
DOWNROD
ASSEMBLY
Figure 10
Figure 11
8
BP7284, Sturbrige, KF180 7/31/06 10:52 AM Page 8

9
1. Position the supply wires to the left side
of the outlet box (Figure 12); position
the fan wires to the right side. Partially
insert the remote control receiver (flat
side up) until one end rests on the
hanger ball as shown in Figure 12.
NOTE: Make all wiring connections
using wire connectors (supplied). Make
sure that all connections are tight,
including ground, and that no bare wire
How to Wire
Your Ceiling Fan
Turning off wall switch is not suffi-
cient. To avoid possible electrical
shock, be sure electricity is turned
off at the main fuse box before
wiring. All wiring must be in accor-
dance with National and Local codes
and the ceiling fan must be properly
grounded as a precaution against
possible electrical shock.
!WARNING
Check to see that all connections are
tight, including ground, and that no
bare wire is visible at the wire con-
nectors, except for the ground wire.
Do not operate fan until blades are in
place. Noise and fan damage could
result.
!WARNING
If you feel that you do not have enough
electrical wiring knowledge or experi-
ence, have your fan installed by a
licensed electrician.
is visible at the wire connectors, except
for the ground wire.
2. Refer to Figure 12 and 13 and connect
the receiver wires to the supply wires
and the fan motor wires as follows:
a. Securely connect the green grounding
wires from the hanger ball and the
hanger bracket to the supply grounding
conductor (this may be a bare wire or a
wire with green insulation).
b. Securely connect the supply white
(neutral) wire to the receiver white (AC
IN N) wire.
c. Securely connect the supply black wire
(hot) wire to the receiver black (AC IN
L) wire.
d. Securely connect the fan motor white
wire to the receiver white (TO MOTOR
N) wire.
e. Securely connect the fan motor black
wire to the receiver red (TO MOTOR L)
wire.
f. Securely connect the fan motor blue
wire to the receiver blue (FOR LIGHT)
wire.
GREEN GROUND
WIRE FROM
HANGER BRACKET
RECEIVER RED WIRE
RECEIVER WHITE WIRE
FAN WHITE WIRE
FAN
BLACK
WIRE
ANTENNA
AC
I
N
N
AC IN L
FOR LIGHT
TO MOTOR N
RECEIVER BLUE
WIRE
RECEIVER
BLACK WIRE
RECEIVER WHITE
WIRE
SUPPLY WHITE WIRE
(NEUTRAL)
SUPPLY BLACK
WIRE (HOT)
GROUND WIRE
GREEN GROUND
WIRE FROM
HANGER BALL
FAN BLUE WIRE
1-1/4" THREADED
STUD (2)
TO MOTOR L
Figure 12
CAUTION: To reduce the risk of electri-
cal shock, disconnect the electrical
supply circuit before installing the fan,
light kit or receiver.
BP7284, Sturbrige, KF180 7/31/06 10:52 AM Page 9

7. Screw three 60-watt (maximum) cande-
labra base flame bulbs into the light
fitter sockets (Figure 15).
8. Unscrew the six ring screws from the
lower ring assembly (Figure 15).
Position the lower glass in the lower
ring assembly so that the six channels
in the glass align with the six arms of
the lower ring assembly.
ARM
LIGHT
FITTER
RING
SCREWS (6)
CHANNEL
LOWER
GLASS LOWER RING
ASSEMBLY
60-WATT
CANDELABRA
BASE BULB (3)
To avoid possible fire or shock, make
sure that the electrical wires are
completely inside the outlet box and
not pinched between the ceiling
cover and the ceiling.
!WARNING
STANDARD ON-OFF WALL
SWITCH OR OPTIONAL SW101
WALL CONTROL BLACK BLACK
WHITE
RED
BLACK
WHITE
HANGER BALL
GREEN WIRE (GROUND)
FROM HANGER BALL AND
HANGER BRACKET
TWO-CONDUCTOR
CABLE (WITH
GROUND)
BLACK
(HOT)
WHITE
GROUND
TO
120-
VOLT
SUPPLY WHITE
BLUE
WHITE
BLUE
Figure 13
3. Push the wires and connectors up into
the outlet box while inserting the receiv-
er fully into the hanger bracket. Position
the antenna wire on top of the receiver.
4. Screw the two 1-1/4” threaded studs
(supplied) into the tapped holes in the
hanger bracket (Figure 12).
5. Lift the ceiling cover up to the threaded
studs and turn until the studs protrude
through the holes in the ceiling cover
(Figure 14).
6. Secure the ceiling cover in place by
sliding lockwashers (supplied) over the
threaded studs and installing the two
knurled knobs (supplied). (Figure 14).
Tighten the knurled knobs securely
until the ceiling cover fits snugly against
the ceiling.
THREADED
STUD (2)
CEILING
COVER
KNURLED
KNOB (2)
LOCKWASHER
(2)
Figure 14
Figure 15
10
BP7284, Sturbrige, KF180 7/31/06 10:52 AM Page 10

button is held down. When the light is
at the desired brightness, release the
button.
5. To turn the light on and off, press and
release the button. The light will turn
on at the light level previously set (see
step 4).
6. If airflow is desired in the opposite
direction, turn the fan off and wait for
the blades to stop turning. Then slide
the reversing switch (Figure 18) to the
opposite position and turn the fan on
again. The blades will turn in the oppo-
site direction and reverse the airflow.
REVERSING
SWITCH
9. Grasp the lower ring assembly and
raise it up and over the ring rods of the
adapter assemlby (Figure 16). Position
the ring assembly of that the ring
assembly arms protrude through the
holes at the end of the ring rods.
Secure the ring asembly in the ring
rods using the six ring screws.
10. Your ceiling fan is now installed and
wired to be controlled by your remote
control system.
11
LOWER RING
ASSEMBLY
RING
SCREWS (6) RING ROD
ARM
Figure 16
Operating Your
Ceiling Fan
IMPORTANT
Fan installation must be completed,
including the installation of the fan
blades, before testing of the remote
control.
Your remote control (Figure 17) has full
control of your fan and light. However, air-
flow direction is controlled by a slide
switch on the switch housing.
1. Restore electrical power to the outlet
box by turning the electricity on at the
service panel.
2. To set the desired fan speed, press the
HI, MED, or LOW buttons to operate
your fan on high, medium, or low speed
(Figure 17).
3. To turn your fan off, press the OFF
button.
4. To set the level of light brightness,
press and hold the light button. The
light brightness will continue to
increase then decrease while the
STORAGE
BRACKET
HIOFF
LOWMED
Figure 17
Figure 18
Installation of
Storage Bracket
A storage bracket is supplied with the
remote control for holding the transmitter
when not in use. If you desire to use the
bracket, use the two screws (supplied)
and install it on a wall that is away from
excess heat or humidity.
BP7284, Sturbrige, KF180 7/31/06 10:52 AM Page 11

12
Do not use water when cleaning your
ceiling fan. It could damage the
motor or the blades and create the
possibility of an electrical shock.
!WARNING
The use of any other control not
specifically approved for this fan
could result in fire, shock and per-
sonal injury.
!WARNING
This product is designed to use only
those parts supplied with this prod-
uct and/or any accessories designat-
ed specifically for use with this
product by Emerson Electric Co.
Substitution of parts or accessories
not designated for use with this
product by Emerson Electric Co.
could result in personal injury or
property damage.
!WARNING
Maintenance
IMPORTANT CARE INSTRUCTIONS
for your Ceiling Fan
Periodic cleaning of your new ceiling fan is
the only maintenance that is needed.
When cleaning, use only a soft brush or
lint free cloth to avoid scratching the finish.
Abrasive cleaning agents are not required
and should be avoided to prevent damage
to finish.
Accessories
1. Downrod Extension Kits (see store or
catalog).
2. Ceiling Fan Controls (see store or cat-
alog).
INSTRUCTION TO THE USER
(if device contains a digital device)
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reason-
able protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and if not installed and used in accor-
dance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
• Consult the dealer or an experienced radio/TV technician for help.
This equipment has been certified to comply with the limits for a Class B computing device,
pursuant to FCC Rules. In order to maintain compliance with FCC regulations, shielded
cables must be used with this equipment. Operation with non-approved equipment or
unshielded cables is likely to result in interference to radio and TV reception. The user is
cautioned that changes and modifications made to the equipment without the approval of
manufacturer could void the user’s authority to operate this equipment.
This Class B digital apparatus meets all requirements of the Canadian Interference-
Causing Equipment Regulations.
BP7284, Sturbrige, KF180 7/31/06 10:52 AM Page 12

13
Trouble Shooting
TROUBLE PROBABLE CAUSE SUGGESTED REMEDY
1.Fan will not 1.Fuse or circuit breaker 1. Check main and branch
start. blown. circuit fuses or circuit breakers.
2.Loose power line 2. Check line power connections
connections to the fan, or to fan and wire.
loose wire connections in
the switch housing.
3.Wall switch is off. 3. Turn on wall switch.
4.Defective battery in remote 4. Check that the battery is good
control transmitter. (red indicator light should
illuminate when any button is
pressed).
5.Code switches in remote 5. Check that both code switches
control receiver and transmitter are set in the same positions.
are not set in the same position. WARNING: Make sure
main power is turned off.
2.Fan sounds 1.Blades not attached to fan. 1. Attach blades to fan before
noisy. operating.
2.Screws securing fan blade 2. Check to make sure the screws
flanges to motor are loose. which attach the blade flanges
to the motor are tight.
3.Wire connectors inside switch 3. Check to make sure wire
housing rattling. connectors in switch housing
are not rattling against each
other or against the interior wall
of the switch housing.
WARNING: Make sure main
power is turned off.
4.Screws holding blades to 4. Tighten screws securely.
flanges are loose.
5.Loose screws in motor housing. 5. Check to make sure all screws
in motor housing are snug
(not over-tight)
3.Fan wobbles 1.Setscrew in motor coupling is 1. Raise coupling cover and tighten
excessively. not tightened securely. setscrew securely.
2.Setscrew in the hanger ball/ 2. Tighten the setscrew in the
downrod assembly is loose. hanger ball/downrod assembly.
3.Screws securing fan blade 3. Check to be sure screws which
flanges to motor are loose. attach the fan blade flanges
to the motor are tight.
4.Fan blade flanges not seated 4. Check to be sure that the
properly. screws securing the fan
blade flanges seat firmly.
5.Hanger bracket and/or ceiling 5. Tighten the hanger bracket
outlet box is not securely screws to the outlet box, and/or
fastened. secure outlet box.
6.Fan blades out of balance. 6. Interchanging an adjacent (side
by-side) blade pair can
redistribute the weight and result
in smoother operation.
Or use supplied balancing kit to
balance blades.
WARNING: FOR YOUR OWN SAFETY TURN OFF POWER AT FUSE BOX
OR CIRCUIT BREAKER BEFORE TROUBLE SHOOTING YOUR FAN.
!
!
!
BP7284, Sturbrige, KF180 7/31/06 10:52 AM Page 13

14
Repair Parts
10
16
12
3
2
1
5
4
76
14
21
19
23
HIOFF
LOWMED
24
11
15
13
9
17
20
25
8
22
18
BP7284, Sturbrige, KF180 7/31/06 10:52 AM Page 14

Part Numbers
Key Model No. Model No. Model No.
No. Description KF180AP01 KF180DBK01 KF180OZ01
* Hanger Pack, Consisting of: 761655-34 761655-36 761655-35
1 Hanger Bracket — — —
2 Hanger Ball — — —
3 Downrod — — —
* Parts Bag, Containing: 762659 762659 762659
4 Wire Connector (7) — — —
5 Threaded Stud, 8-32 x 1-1/4” (2) — — —
6 Knurled Knob (2) — — —
7 Lockwasher (2) — — —
8 Hairpin Pin — — —
9 Clevis Pin — — —
10 Screw, Truss Head, 10-24 x 9mm (16) — — —
11 Washer, Fiber (16) — — —
12 Screw, Pan Head with Lockwasher,
1/4-20 x 11mm (11) — — —
13 Screw, Pan Head, 8-32 x 12mm (4) — — —
14 Cover, Ceiling 762653-AP 762653-DBK 762653-OZ
15 Blade Set (full set for one fan) 762635-8 762635-7 762635-9
16 Flange Set (full set for one fan) 762724-AP 762724-DBK 762724-OZ
17 Harness Assembly, Wiring 762729 762729 762729
18 Adapter, Light Fitter 762730-AP 762730-DBK 762730-OZ
19 Rod, Ring Assembly (6) 762735-AP 762735-DBK 762735-OZ
20 Fitter, Light 763207 763207 763207
21 Glass, Lower 762733 762733 762733
22 Ring Assembly, Lower 762734-AP 762734-DBK 762734-OZ
23 Screw, Ring (6) 762736-AP 762736-DBK 762736-OZ
24 Transmitter, Remote Control 761970-1 761970-1 761970-1
25 Receiver, Remote Control 762670 762670 762670
—Owner's Manual BP7284-3 BP7284-3 BP7284-3
15
Repair Parts Listing
Before discarding packaging material, be certain all parts have been removed.
HOW TO ORDER REPAIR PARTS
WHEN ORDERING REPAIR PARTS, ALWAYS GIVE THE FOLLOWING INFORMATION:
• PART NUMBER
• NAME OF ITEM
• PART DESCRIPTION
• MODEL NUMBER
The model number of your Fan will be found on a label attached to the top housing.
For repair parts, phone [phone].
BP7284, Sturbrige, KF180 7/31/06 10:52 AM Page 15

LIMITED WARRANTY
What The Warranty Covers:
This warranty covers the motor and the other components and accessories of your Emerson ceiling fan against all
defects in workmanship and materials. You must be the original purchaser or user of the product to be covered.
What The Period Of Coverage Is:
As it applies to the motor, this warranty will last for the lifetime of your ceiling fan. All other components and
accessories are covered by this warranty for one year from the date you purchased your ceiling fan. ANY IMPLIED
WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, MADE WITH RESPECT TO
COMPONENTS AND ACCESSORIES IS ALSO LIMITED TO ONE YEAR.
What Will Emerson Electric Co. Do To Correct Problems:
Emerson Electric Co. will replace a defective Emerson Air Comfort Ceiling Fan motor, blade, component or other
accessory at no charge to you. If repair of the motor or blades is not practical or possible within a reasonable time and
no replacement can be provided, Emerson will refund the actual purchase price of your fan. WE WILL SHIP THE
REPAIRED PRODUCT OR REPLACEMENT TO YOU AT NO CHARGE, BUT YOU ARE RESPONSIBLE FOR ALL COSTS OR
REMOVAL, REINSTALLATION AND SHIPPING OF THE PRODUCT TO EMERSON ELECTRIC CO.
How Can You Get Service:
YOU MUST HAVE PROOF OF YOUR PURCHASE OF THE CEILING FAN TO OBTAIN LIMITED WARRANTY SERVICE.
KEEP YOUR RECEIPT OR OTHER PROOF OF PURCHASE. You can return the product to our factory or to your nearest
authorized service center.
• To return the product to the factory, obtain a return authorization and service identification tag by writing to Air
Comfort Products, Division of Emerson Electric Co., 8100 W. Florissant Ave., St. Louis, MO 63136. Include all model
numbers shown on the product with your request.
• To return the product to an authorized service center, call 1-800-654-3545 for the address of the nearest authorized
service center.
You will be responsible for all insurance, freight or other transportation charges to our factory or authorized service
center. Your Emerson Air Comfort Ceiling Fan should be properly packed to avoid damage in transit since we will not
be responsible for any such damage.
What Is Not Covered:
The glass globes and light bulbs of your ceiling fan are not covered by this warranty. This warranty also does not cover
any defects, malfunctions or failures caused by:
• Repairs by persons not authorized by Emerson Electric Co.,
• Use of parts or accessories not authorized by Emerson Electric Co.,
• Mishandling, improper installation, modifications or damage to your ceiling fan while in your possession, or
• Unreasonable use, misuse, abuse, including failing to do reasonable and necessary maintenance, and normal wear
and tear.
Additionally, this warranty and any implied warranty of merchantability or fitness for a particular purpose are voided
when:
• The original purchaser or user ceases to own the product, or
• The fan is moved from its original point of installation.
This warranty is only valid within the 50 states of the United States and the District of Columbia. No other written or
oral warranties apply, and no employee, agent, dealer or other person is authorized to give any warranties on behalf of
Emerson Electric Co.
REPAIR, REPLACEMENT OR A REFUND ARE THE EXCLUSIVE REMEDIES AVAILABLE UNDER THIS WARRANTY AND
EMERSON IS NOT RESPONSIBLE FOR DAMAGES OF ANY KIND, INCLUDING INCIDENTAL AND CONSEQUENTIAL
DAMAGES. Incidental damages include but are not limited to such damages as loss of time and loss of use.
Consequential damages include but are not limited to the cost of repairing or replacing other property which was
damaged if this product does not work properly.
How State Law Relates To The Warranty:
Some states do not allow the exclusion or limitation of incidental or consequential damages so the above exclusion or
limitation may not apply to you. This warranty gives you specific legal rights, and you may also have other rights which
vary from state to state.
Part No. F40BP72840003 Printed in China 08/06 Form No. BP7284-3
Air Comfort Products
DIVISION OF EMERSON ELECTRIC CO.
8100 W. Florissant ¥ St. Louis, MO 63136
BP7284, Sturbrige, KF180 7/31/06 10:52 AM Page 16
