Safety
Information to the user
The RTS is supplied with two non-rechargeable AA alkaline
batteries. Lithium-thionyl chloride non-rechargeable AA
batteries may also be used in the RTS; refer to the RTS radio
tool setter installation guide (Renishaw part no. H-5646-8504).
Lithium batteries must be approved to (BSEN62133:2013
[IEC62133:2012]). Once the charge in the batteries is depleted,
do not attempt to recharge them.
The use of this symbol on the batteries, packaging or
accompanying documents indicates that used batteries should
not be mixed with general household waste. Please dispose of the
used batteries at a designated collection point. This will prevent
potential negative effects on the environment and human health
which could otherwise arise from inappropriate waste handling.
Please contact your local authority or waste disposal service
concerning the separate collection and disposal of batteries. All
lithium and rechargeable batteries must be fully discharged or
protected from short circuiting prior to disposal.
Ensure replacement batteries are of the correct type and are
tted in accordance with the instructions in the installation guide;
refer to the RTS radio tool setter installation guide (Renishaw
part no. H-5646-8504) for further information. For specic battery
operating, safety and disposal guidelines, refer to the battery
manufacturer’s literature.
• Ensure that all batteries are always inserted with the correct
polarity.
• Do not store batteries in direct sunlight or rain.
• Do not expose to heat or dispose of the batteries in a re.
• Avoid forced discharge of the battery.
• Do not short-circuit or force discharge the batteries.
• Do not disassemble, pierce, deform or apply excessive
pressure to the batteries.
• Do not swallow the batteries.
• Keep the batteries out of the reach of children.
• Do not allow batteries to get wet.
• Do not mix new and used batteries or battery types, as this will
result in reduced life and damage to the batteries.
• If a battery is damaged, exercise caution when handling to
avoid contact with electrolyte.
Ensure that you comply with international and national battery
transport regulations when transporting batteries or the products.
NOTE: Lithium batteries are classied as dangerous goods and
strict controls apply to their shipment by air. To reduce the risk of
shipment delays, if you need to return the RTS to Renishaw for
any reason, do not return any batteries.
In all applications involving the use of machine tools, eye
protection is recommended.
The RTS has a glass window. Handle with care if broken to avoid
injury.

4
Information to the machine supplier/installer
It is the machine supplier’s responsibility to ensure that the user is
made aware of any hazards involved during operation, including
those mentioned in Renishaw product literature, and to ensure that
adequate guards and safety interlocks are provided.
If the probe fails, the probe signal may falsely indicate a probe
seated condition. Do not rely on probe signals to halt the
movement of the machine.
Information to the equipment installer
All Renishaw equipment is designed to comply with the relevant
EU and FCC regulatory requirements. It is the responsibility of
the equipment installer to ensure that the following guidelines are
adhered to, in order for the product to function in accordance with
these regulations:
• any interface MUST be installed in a position away from any
potential sources of electrical noise (for example, power
transformers, servo drives);
• all 0V/ground connections should be connected to the machine
“star point” (the “star point” is a single point return for all
equipment ground and screen cables).This is very important
and failure to adhere to this can cause a potential difference
between grounds;
• all screens must be connected as outlined in the user
instructions;
• cables must not be routed alongside high current sources (for
example, motor power supply cables), or be near high-speed
data lines;
• cable lengths should always be kept to a minimum.
Equipment operation
If this equipment is used in a manner not specied by the
manufacturer, the protection provided by the equipment may be
impaired.

5
Batteries AA alkaline × 2 AA lithium-thionyl chloride × 2
 
Saft
Tadiran
Xeno
LS 14500
SL-760/S
TL-5903/S, TL-2100/S
XL-060F
NOTE: Maximum battery life is achieved when lithium-thionyl chloride batteries are used.

6
Fitting the stylus and captive link
3
1
2
5 mm A/F (thin)
2.5Nm – 2.7Nm
(1.84lbf.ft – 1.99 lbf.ft)
2 mm A/F
1.0Nm – 1.2Nm
(0.74lbf.ft – 0.89lbf.ft)
2 mm A/F
1.0Nm – 1.2Nm
(0.74lbf.ft – 0.89lbf.ft)
3 mm A/F
2.5Nm – 2.7Nm
(1.84lbf.ft – 1.99lbf.ft)

7
Installing the batteries
12 3

8
EN Conguring the probe
The following sections describe the process of reviewing and conguring the probe settings. The
Trigger Logic™ app simplies this process with clear, interactive instructions and informative
videos. The app can also be used with radio probes for probe partnering.

9
1
23
> 5 s
Key to the symbols
LED short ash
LED long ash
LED check
Hibernation mode setting
30 s
or
5 s
or
Off
Enhanced trigger lter
Off
or
On
Reviewing the probe settings
Probe in standby mode (after 5 seconds)
Battery status
Battery good
or
Battery low

10
Placing the probe in conguration mode
Key to the symbols
LED short ash
LED long ash
Deect the stylus for less than 4 seconds
to move to the next menu option.
Deect the stylus for more than 4 seconds
to move to the next menu.
To exit, leave the stylus untouched for
more than 20 seconds.
CAUTION: Do not remove the batteries whilst in conguration mode.
To exit, leave the stylus untouched for more than 20 seconds.
LED check
Battery status
Battery good
or
Battery low
Deect the stylus and hold it
deected until after the battery
status has been displayed at the
end of the review sequence.
1
23
> 5 s
To partner the probe and/or change the
probe settings, go to the next page.

11
New settings
complete
Enhanced trigger lter (on-centre length measurement only)
Off On
Hibernation mode setting
30 s 5 s Off
Return to “Enhanced trigger lter”
Changing the probe settings
Acquisition mode (time out only in acquisition successful)
Acquisition mode
off
Acquisition mode
on
Acquisition
successful

12
 
SYSTEM STATUS LED
RMI-Q in “Aquisition
mode” with empty
probe location
or
SYSTEM STATUS LED
RMI-Q in “Aquisition
mode” with full probe
location
Switch on the RMI-Q
Aquisition mode
Aquisition mode off
RMI-Q
Deflect the stylus to select
“Aquisition mode on”. Ensure
this is done within 60 seconds
of the RMI-Q system status LED
flashing green.
RTS – RMI-Q partnership
< 4 s

13
RMI-Q
The probe is in standby and the
system is ready for use.
NOTE: Refer to the RMI-Q radio machine
interface installation guide (Renishaw part no.
H-5687-8504) when partnering up to four radio
tool setters/radio probes.
SYSTEM STATUS LED
Aquisition pending
Displayed for 5 seconds

SYSTEM STATUS LED
New partner RTS
aquired
SYSTEM STATUS LED
RTS cleared from
location
or
> 20 s
PROBE STATUS
LED
Aquisition
pending

PROBE STATUS
LED
Aquisition mode
completed
successfully
Displayed for 20 seconds

14
Mounting the probe on the
machine table
M10/M12 bolt and
T nut – supplied
by user.
1

15
23
0.7Nm – 0.9Nm
(0.52lbf.ft – 0.66lbf.ft)
2.5 mm A/F
× 4
0.7Nm – 0.9Nm
(0.52lbf.ft –
0.66lbf.ft)
2.5 mm A/F
× 2

16
Stylus on-centre adjustment
1
0.7Nm – 0.9Nm
(0.52lbf.ft – 0.66lbf.ft)
±2.5 µm
2.5 mm A/F
× 2

17
12
Adjust Adjust and lock
12
2
4.6Nm – 5.6Nm
(3.40lbf.ft –
4.13lbf.ft)
±2.5 µm
4 mm A/F
× 2

18
Square stylus only
3
2 mm A/F
1.0Nm – 1.2Nm
(0.74lbf.ft – 0.89lbf.ft)
±100 µm
