Renke RS-FS Series User manual

Wind speed transmitter manual (analog type)
Shandong Renke Control Technology Co., Ltd. www.renkeer.com
1
RS-FS-*
Wind speed transmitter
Instruction Manual
(Analog Type)
Document version：V2.1

Wind speed transmitter manual (analog type)
Shandong Renke Control Technology Co., Ltd. www.renkeer.com
2

Wind speed transmitter manual (analog type)
Shandong Renke Control Technology Co., Ltd. www.renkeer.com
3
Table of Contents
1. product description..................................................................................................................3
2. product model..........................................................................................................................5
3. Equipment installation instructions.........................................................................................5
4. Calculation method................................................................................................................. 7
5. Common problems and solutions............................................................................................8
6. Contact information................................................................................................................ 9
7. Document history.................................................................................................................... 9
8. Dimensions..............................................................................................................................9
Attachment: Description of hole size for site installation........................ 错误！未定义书签。

Wind speed transmitter manual (analog type)
Shandong Renke Control Technology Co., Ltd. www.renkeer.com
4
1. product description
1.1 product description
RS-FS-* wind speed transmitter, compact and light, easy to carry and assemble. The
three-cup design concept can effectively obtain wind speed information. The shell is made of
high-quality aluminum alloy profiles, and the exterior is electroplated and sprayed. It has good
anti-corrosion and anti-corrosion. Corrosion and other characteristics can ensure that the
transmitter is used for a long time without rusting phenomenon. At the same time, it cooperates
with the smooth internal bearing system to ensure the accuracy of information collection. The
traditional analog signal (4-20mA, 0-10V, 0- 5V) for data output. It is widely used in wind speed
measurement in greenhouses, environmental protection, weather stations, ships, docks, and
breeding.
1.2 Features
1. Range: 0-60m/s (default 0-30m/s), resolution 0.1m/s
2. Anti-electromagnetic interference treatment
3. The bottom outlet method is adopted to completely prevent the aging problem of the aviation
plug rubber pad, and it is still waterproof after long-term use
4. Using high-performance imported bearings, low rotation resistance, accurate measurement
5. All aluminum shell, high mechanical strength, high hardness, corrosion resistance, no rust, and
long-term use outdoors
6. The structure and weight of the equipment have been carefully designed and distributed, with
small moment of inertia and sensitive response
7. It can be applied to four-wire and three-wire connection at the same time.
1.3 Main Specifications
DC power supply (default)
10~30V DC
Maximum power
consumption
Current output
0.85W
Voltage output
1.05W
Resolution
0.1m/s
Transmitter circuit operating
temperature
-40℃~+60℃，0%RH~80%RH
Measuring range
0~60m/s（default 0-30m/s）
Dynamic response time
≤0.5s
Precision
±0.3m/s
output signal
Current output
4~20mA

Wind speed transmitter manual (analog type)
Shandong Renke Control Technology Co., Ltd. www.renkeer.com
5
Voltage output
0~5V/0~10V
load capacity
Voltage output
Output resistance≤250Ω
Current output
≤600Ω
2. product model
RS-
Company code
FS-
Wind speed transmitter
I20-
4～20 mA Current output
V05-
0～5V Voltage output
V10-
0～10V Voltage output
3. Equipment installation instructions
3.1 Inspection before equipment installation
1. 1 transmitter equipment
2. 4 mounting screws
3. Certificate of conformity, warranty card, calibration report, etc.
3.2 wiring
3.2.1: Power wiring
Wide voltage 10~30V DC power input. For 0-10V output devices, only 24V power supply can be
used.
3.2.2: Output interface wiring
Adapt to the three-wire system and the four-wire system at the same time.
3.2.3: Electrical wiring
3.3Wiring example
Thread color
Description
power supply
brown
Power is positive
black
Power negative
Output
blue
Wind speed signal is positive
green
Wind speed signal negative

Wind speed transmitter manual (analog type)
Shandong Renke Control Technology Co., Ltd. www.renkeer.com
6
Schematic diagram of four-wire connection
Schematic diagram of three-wire connection
3.4Installation method
Flange installation is adopted. The threaded flange connection makes the lower pipe fitting of
the wind speed sensor firmly fixed on the flange. The chassis is Ø65mm. Four mounting holes of
Ø6mm are opened on the circumference of Ø47.1mm, and the bolts are used to fix it tightly. The
bracket keeps the whole set of instruments at the best level to ensure the accuracy of wind speed
data. The flange connection is easy to use and can withstand greater pressure.

Wind speed transmitter manual (analog type)
Shandong Renke Control Technology Co., Ltd. www.renkeer.com
7
3.5Precautions
1. Users are not allowed to disassemble by themselves, let alone touch the sensor core, so as
not to cause damage to the product.
2. Keep away from high-power interference equipment as much as possible to avoid
inaccurate measurement, such as inverters, motors, etc., when installing or disassembling the
transmitter, you must first disconnect the power supply. Water in the transmitter may cause
irreversible changes.
3. Prevent chemical reagents, oil, dust, etc. from directly invading the sensor, do not use it
for a long time under condensation and extreme temperature environments, and prevent thermal
shock
4. Calculation method
4.1Current output signal conversion calculation
Range 0~30m/s, 4~20mA output, when the output signal is 12mA, calculate the current wind
speed. The span of the wind speed range is 30m/s, expressed by a 16mA current signal,
30m/s/16mA=1.875m/s/mA, that is, the current change is 1mA and the wind speed change is
1.875m/s. Then the measured value can be calculated. The measured value is 12mA-4mA
=8mA.8mA*1.875m/s/mA=15m/s, then the current wind speed=15m/s.
4.2Voltage output signal conversion calculation
The range is 0~30m/s. Take 0-10V output as an example. When the output signal is 5V,
calculate the current wind speed. The span of the wind speed range is 30m/s, expressed by a 10V
voltage signal, 30m/s/10V=3m/s/V, that is, every 1V change in voltage corresponds to a wind

Wind speed transmitter manual (analog type)
Shandong Renke Control Technology Co., Ltd. www.renkeer.com
8
speed change of 3m/s. The measured value is 5V-0V=5V. 5V*3/m/s/V=15m/s. The current wind
speed is 15m/s.
5. Common problems and solutions
Trouble phenomenon: no output or output error
possible reason:
1) The PLC calculation error is caused by the error corresponding to the range. Please refer to the technical
indicators in the first part of the range.
2) The wiring method is wrong or the wiring sequence is wrong.
3) The power supply voltage is wrong (24V power supply for 0-10V type).
4) The distance between the transmitter and the collector is too long, causing signal disturbance.
5) The PLC acquisition port is damaged.
6) The equipment is damaged.

Wind speed transmitter manual (analog type)
Shandong Renke Control Technology Co., Ltd. www.renkeer.com
9
6. Contact information
Shandong Renke Control Technology Co., Ltd.
Address: 2 / F, East Block, Building 8, Shun Tai Plaza, High-tech Zone, Jinan City, Shandong
Province
Post code: 250101
Phone: [phone]
Website: www.renkeer.com
Cloud platform address: en.0531yun.cn Or: eniot.0531yun.cn
Web QR:
7. Document history
V1.0 document creation.
V2.0 document update.
V2.1 Correct the mounting hole size。
8. Dimensions
Attachment: Description of hole size for site installation
