Respironics HomeLOX User manual

USER MANUAL

1
HomeLox User Manual
Table of ConTenTs
Symbol Key ....................................................................................................... 2
Introduction .................................................................................... 3
Intended Use.................................................................................................... 3
Warnings and Cautions ................................................................................ 3
Compatibility with Portable Oxygen Devices ..................................... 4
How to Contact Respironics........................................................................ 4
How the System Works.................................................................. 5
Troubleshooting Guide ...............................................................10
Cleaning .........................................................................................11
Circuit Breaker Instructions........................................................12
Specications ................................................................................13
Disposal............................................................................................................13
EMC Information...........................................................................14
Limited Warranty..........................................................................16

2
symbol Key
Follow Instructions For Use Keep Away From Open Flames
Do Not Touch Frosted Areas Keep Away From Electrical Appliances
Keep Well Ventilated Keep Away From Oil Or Grease
No Smoking Keep Unit Upright
AC Power Class II Device
Type BF Applied Part Drip Proof Equipment
CAUTION: US federal law restricts
this device to sale by or on the
order of a physician.
Denitions
e following denitions and acronyms are used in this manual:
• GoLox-93 - the small and wearable device that stores liquid oxygen and controls the flow of oxygen to
the user.
• LED - Light Emitting Diode
• Liquefaction Unit - the HomeLox, which produces liquid oxygen and is used to fill the
GoLox-93.
• LOX - Liquid Oxygen
• LPM - Liters Per Minute
• Transfill - The process of filling the small portable device (GoLox-93) with liquid oxygen from the
liquefaction unit (HomeLox).
© 2011 Koninklijke Philips Electronics N.V. All rights reserved.

3
HomeLox User Manual
Introduction
InTended Use
e Home Liquefaction System (HomeLox) is intended to create and store liquid oxygen in a patient’s home,
so that a patient will be able to ll their liquid portable unit and ambulate. e device is intended only to be a
liquid oxygen reservoir for lling of a portable unit and will not provide any ability for the patient to breathe
oxygen gas directly from the unit. is device is not intended to be life supporting nor life sustaining.
WarnIngs and CaUTIons
CAUTION: US federal law restricts this device to sale by or on the order of a physician.
Warnings
Danger: Explosion Hazard. Do not use this device in the presence of ammable substances.
• If while using the system you experience any discomfort or signs of any unusual physical symptoms,
contact your physician immediately.
• This system refrigerates and stores oxygen in its liquid form. Oxygen in its liquid or gaseous form can
promote rapid burning when exposed to an open flame. Do not allow any smoking objects or open flames
near this unit.
• Do not use any oil, grease, or petroleum-based products on or near this unit.
• Do not smoke while the device is in use.
• Frostbite may occur on contact with liquid oxygen, cold gaseous oxygen, or frosted parts. Do not touch
any frosted parts.
• Protect the device against the spillage of fluids on or around it. Do not place drinks on it. Do not allow
fluids to come in contact with the device.
• Do not set any objects on, or allow to be draped over, the HomeLox System as they might block air flow
into the device. Place the unit in a ventilated location with the sides and rear two feet away from any
object.
• Do not allow minors or children to operate the HomeLox System. Do not allow unsupervised children to
play on or near the device.
• Do not use an extension cord with the HomeLox System.
• Do not connect the HomeLox System to an electrical outlet controlled by a wall switch or ground
fault interruptor. Make sure there is no other high power device such as a TV, stereo, computer, radio
transmitter, space heater, hair dryer, refrigerator, microwave oven, electrical range, or other large appliance
connected to this outlet.

4
• The HomeLox System contains liquid oxygen and is therefore designed to operate on a level surface and in
an upright position. Should the unit be upset or overturned, liquid oxygen could spill. Should this occur,
discontinue its use and immediately contact your home care equipment supplier.
• Electrical shock hazard: Do not remove the cabinet of the HomeLox System. The removal of the cabinet
should only be performed by Respironics, Inc. or a trained representative.
• Disconnect the power cord from the electrical outlet before cleaning the housing of the HomeLox System.
• This equipment complies with IEC 60601-1-2 for electromagnetic compatibility for medical electrical
equipment and/or systems. This standard is designed to provide reasonable protection against harmful
interference in a typical medical installation. However, because of the proliferation of radio-frequency
transmitting equipment and other sources of electrical noise in health care and other environments, it is
possible that high levels of such interference due to close proximity or strength of a source might disrupt
the performance of this device. Medical electrical equipment needs special precautions regarding EMC,
and all equipment must be installed and put into service according to the EMC information specified in
this manual.
• Take precautions to prevent electrostatic discharge (ESD). Precautionary procedures include methods
to prevent buildup of electrostatic discharge (e.g., air conditioning, humidification, conductive floor
coverings, and non-synthetic clothing), discharging one’s body to the frame of the equipment or system or
to earth or a large metal object, and bonding oneself by means of a wrist strap to the equipment or system,
or to earth.
• Do not leave the GoLox-93 unattended while it is filling.
• Extreme caution should be taken when transporting, shipping, or moving the HomeLox System when
partially or completely full of liquid oxygen. If the unit is upset or overturned, liquid oxygen could spill.
Note: Additional warnings, cautions and notes are located throughout this manual.
CompaTIbIlITy WITh porTable oxygen devICes
e HomeLox is compatible only with the Respironics GoLox-93.
hoW To ConTaCT respIronICs
To have your device serviced, contact your home care provider. If you need to contact Respironics directly, call
the Respironics Customer Service department at 1-800-345-6443 (US and Canada only) or 1-724-387-4000.
You can also use the following address:
Respironics, Inc.
1001 Murry Ridge Lane
Murrysville, PA 15668 USA

5
HomeLox User Manual
How the System Works
Your Respironics HomeLox is a device that can generate and store liquid oxygen in your home by converting
the oxygen gas, generated from an integrated oxygen concentrator, to its liquid form. e liquid oxygen stored
in this device can then be transferred to your Respironics GoLox-93 portable liquid oxygen device for your use
as a source of ambulatory oxygen. e HomeLox is only a liquid oxygen reservoir for lling a portable unit and
will not provide any ability for you to breathe oxygen gas directly from it. is device is not intended to be life
supporting nor life sustaining.
Your HomeLox is made up of an oxygen generator, low temperature refrigeration system and an insulated liquid
oxygen storage bottle. e HomeLox operates by taking oxygen gas that it produces from room air and turning
it into liquid oxygen by lowering its temperature to -279 F (-173C) using refrigeration. At this temperature,
gaseous oxygen becomes liquid oxygen. e device then stores this liquid oxygen until you are ready to ll your
GoLox-93.
When your GoLox-93 is properly attached to the HomeLox, the liquid oxygen will be transferred to your
GoLox-93 in approximately 1 to 2 minutes. To be sure you will always have liquid oxygen available for your
use, the HomeLox monitors the amount of liquid oxygen stored inside it. When your available supply has been
reduced to a level set by your equipment provider, the HomeLox will automatically turn on and run until it has
completely relled itself and then will turn o.
To ensure the correct use of this device, please read the information in this manual carefully before trying
to operate this device. After reading this manual, keep it in a safe place where you can refer to it anytime a
question arises.

6
Getting Started
Begin by becoming familiar with your HomeLox and the Control Panel.
6
9
2
3
1
5
4
7
6
8
8
10
8
11
7
Description Function
1 Control Panel HomeLox control switches and indicators
2 Turntable Used to rotate the GoLox-93 to ll it with liquid oxygen
3 Transll Connector Connects the GoLox-93 and valve for transfer of liquid oxygen from the
HomeLox to the GoLox-93
4Equipment Warning Label Displays important equipment information
5 Hour Meter Displays the total operational hours of the unit
6 Hand Holds Gripping points for moving and lifting the unit
7 Fan Inlet Air Vents Air inlets for the cabinet ventilation fans
8 Fan Outlet Air Vent Air outlet for the cabinet ventilation fan
9 Inlet Filter and Cover Filters the ambient air used by the HomeLox
10 Power Cord Connects the HomeLox to an electrical outlet
11 Circuit Breaker Disconnects mains power from the HomeLox

7
HomeLox User Manual
ConTrol panel
1
2
3
4
Description Color Function Indicator Modes
1
SERVICE
Indicator Yellow
When lit, this indicates the
unit has detected a fault
that requires service by the
equipment provider. The
unit has shut itself o and
will not start again until the
problem is corrected.
Steady On – The HomeLox has detected a problem that
prevents it from operating. Contact your home care
equipment provider for repair.
O – No system faults have been detected.
2
PAUSE
Push Button &
Indicator Blue
When this switch is
depressed, the unit stops
operation for a period of 1
hour after which operation is
resumed.
Steady On – The HomeLox is paused; it is in a temporary non-
operating state.
O – The HomeLox is not in PAUSE mode.
3
START
Push Button &
Indicator Green
When this switch is
depressed the unit goes
into its operating state to
produce liquid oxygen.
Steady On – Unit is turned on; mains power is connected.
Flashing – Unit is operating to produce liquid oxygen.
O – The HomeLox is turned o; mains power is not
connected.
4
LIQUID OXYGEN
SEGMENT LEVEL
Indicators
Blue
When each segment is lit, it
indicates that the GoLox-93
can be lled once.
When the rst segment
(next to E) is lit, you can ll
your GoLox-93 once.
When the gauge is at F, with
all six segments lit, you can
ll your GoLox-93 six times.
Segment Steady On – Each lit segment is equivalent to 1 ll
of your GoLox-93 from the HomeLox. The total number of lit
segments is equal to the total number of times your GoLox-93
can be lled.
One Segment Flashing – This segment of the HomeLox
storage bottle is being lled.
Segment O –This segment of the HomeLox storage bottle
has not yet been lled.

8
Filling Your GoLox-93
Warning: Do not leave the GoLox-93 unattended while it is lling.
Warning: Risk of electrical shock if unit is accidentally immersed or if uids are spilled on the HomeLox device.
Do not allow uids to come in contact with the device, as they may create a shock hazard.
If the HomeLox has been installed with liquid oxygen already in the device, you may ll the GoLox-93
immediately. If the HomeLox has been installed without liquid oxygen, wait 24 hours before lling the
GoLox-93. When the rst batch of liquid oxygen is stored in the HomeLox insulated liquid oxygen storage
bottle, the control panel light next to Ewill turn on. In the event of a temporary power loss, you can still ll
your GoLox-93 with oxygen by following the steps below.
1. Wipe the GoLox-93 and HomeLox connectors with a clean, dry,
lint-free cloth to remove any residual dirt or moisture.
Warning: Do not depress the HomeLox ll valve while wiping it clean.
2. Stand in front of the HomeLox facing the control panel.
3. Rotate the turntable on top of the HomeLox counter-clockwise until
it stops. Notice that the indicator line on the turntable is aligned
with the line on the HomeLox.
4. Make sure the Vent Fill Lever on the back of the
GoLox-93 is in the upright, closed position.
5. Make sure the Flow Control Knob is in
the OFF position.
6. Place the GoLox-93 in the recess in the turntable.
7. Rotate the turntable clockwise until it stops. Notice that the
indicator line on the turntable is aligned with the line on the
HomeLox. The portable unit and HomeLox are now connected and
ready for liquid oxygen to be transferred from the HomeLox into the
GoLox-93.

9
HomeLox User Manual
Warning: Make sure the devices are properly connected before lling the GoLox-93.
8. Pull down the Vent Fill Lever on the back of the GoLox-93 so filling
can begin. Liquid oxygen is now flowing from the liquefaction unit
to the GoLox-93. You will hear a hissing sound as gaseous oxygen
escapes. This is normal. You may also see a white vapor near the
connection as the very cold oxygen comes in contact with the warm
air in the room. This is also normal.
Warning: Do not leave the GoLox-93 unattended while lling.
Warning: Do not smoke while the device is in use.
9. Allow filling to continue until the sound of venting stops, about 1-2
minutes. When the sound stops, it means that the
GoLox-93 is full and its internal shutoff valve has stopped receiving
liquid oxygen from the HomeLox.
10. Move the Vent Fill Lever on the back of the GoLox-93 to its closed,
upright position.
11. Rotate the turntable on the top of the HomeLox counter-clockwise
until it stops. Notice that the indicator lines on the turntable align
with the lines on the HomeLox.
12. Gently remove the GoLox-93 from the turntable.
(See the GoLox-93 User Manual for complete instructions.)
Warning: Frostbite may occur on contact with liquid oxygen, cold gaseous oxygen, or frosted parts. Do not
touch any frosted parts. See the Troubleshooting Guide on the next page for more information.
Warning: Always wait at least 15 minutes before attempting the next ll of your GoLox-93 to prevent
excessive frosting of the connections.
