Response Electronics SAP E User manual

These nstruct ons cover bas c set-up. For more
advanced funct ons, please refer to your System
Installat on and Operat ng Manual.
Introduct on
PIR Detectors are designed to detect movement in a
protected area by detecting changes in in ra-red radiation
levels caused, or example, when a person moves within
or across the devices ield o vision. I movement is
detected an alarm signal will be triggered, (i the system
and alarm zone is armed).
Note: PIR Detectors will also detect animals, so ensure that
pets are not in areas itted with PIR Detectors when the
system is armed.
Any number o PIR Detectors can be used with your
system providing they are all coded with the system house
code, and are mounted within e ective radio range.
The PIR Detector is powered by a PP3 alkaline battery.
Under normal operating conditions this will provide an
expected li e in excess o 1 year. When the battery level
becomes low the PIR Detector will lash a red LED behind
the lens. When this occurs the battery should be replaced
as soon as possible.
Choos ng a Pos t on for the
PIR Detector
The recommended position or a PIR Detector is in the
corner o a room mounted at a height o between 2 and
2.5m. At this height, the PIR Detector will have a maximum
range o up to 12m with a ield o view o 110°.
The position o the PCB inside the PIR can be set to 5
di erent positions to adjust the range o the PIR Detector.
Setting the PCB in position 3 will reduce the range to 9m
approximately, with position 1 providing a range o 6m
approximately. The recommended position setting or the
PCB is in position 5.
Note: The range as indicated above re ers to the linear
distance in ront o the PIR Detector.
When deciding upon the mounting position or the PIR
Detector the ollowing points should be considered to
ensure trouble ree operation:
1. Do not position the PIR Detector acing a window or
where it is exposed to or acing direct sunlight. PIR
Detectors are not suitable or use in conservatories or
or external use.
2. Do not position the PIR Detector where it is exposed
to draughts.
3. Do not position the PIR Detector directly above a heat
source, (e.g. ire, radiator, boiler, etc).
4. Where possible, mount the PIR Detector in the corner o
the room so that the logical path o an intruder would
cut across the an detection pattern. PIR Detectors
respond more e ectively to movement across the
device than to movement directly towards it.
5. Do not locate the PIR Detector in a position where it is
subject to excessive vibration.
6. Ensure that the position selected or the PIR Detector
is within e ective range o the System.
Note: When the system is armed, pets should not be
allowed into an area protected by a PIR Detector as their
movement will trigger the PIR and generate an alarm.
Note: DO NOT ix the PIR Detector to metalwork or locate
the unit within 1m o metalwork (i.e. radiators, water pipes,
etc) as this could a ect the radio range o the device.
433MHz Wirefree Passi e Infra-Red
Mo ement Detector (SAP E)
Installation and Operating Instructions
8
7
6
5
4
3
2
12
14
35
ECE
ECEON
ON
SW3SW2
5
4
3
2
1
PCB Positions
Indicator
(positions 1-5)
5
4
3
2
1
Less Sensitive
More Sensitive
110°
12
10
8
6
4
2
0
2
4
6
8
10
12
0
2
4
6
metres
8
10
12
0
2
metres
Side View
Top View

Install ng and Conf gur ng the
PIR Detectors
Ensure that the system s n Test or Serv ce Mode
1. Undo and remove the ixing screw rom the bottom
edge o the PIR Detector. Care ully pull the bottom
edge o the PIR Detector away rom the rear cover and
then slide down to release the top clips.
2. Care ully drill the required mounting holes in the rear
cover using a 3mm drill relevant to whether the
PIR Detector is being mounted in a corner or against
a lat wall.
3. Using the rear cover as a template, mark the positions
o the ixing holes on the wall.
4. Fix the rear cover to the wall using the two 18mm No.4
screws and 25mm wall plugs, (a 5mm hole will be
required or the wall plugs). Do not over-tighten the
ixing screws as this may distort or damage the cover.
Note: The wall plugs supplied with the product are not
suitable or plasterboard walls, i mounting the PIR
Detector onto plasterboard use appropriate wall plugs.
5. Con igure the PIR Detector as described below.
Remember that on initial installation the device needs to
be tested and should there ore be set in Walk Test Mode.
6. Check that the PIR Detector PCB is located and set in
the correct position to give the detection zone pattern
required.
To adjust the PCB position, simply slide it up or down
ensuring that the location legs are aligned with the
required position number marked on the board.
7. To re it the PIR Detector to the rear cover, o er it up to
the rear cover and locate the clips in the top edge into
the rear cover. Push the lower edge o the PIR Detector
into place and re it the ixing screw in the bottom edge
to secure in position. Do not over-tighten the ixing
screws as this may damage the casing.
Sett ng the PIR Detectors
Located on the PCB o the PIR Detector are two blocks
o DIP switches (SW2 and SW3).
When setting Dip Switches to House Code, hold the PIR
Detector ‘upside down’ as shown in the diagram below:
1. DIP switches SW2 (numbered 1-8) are used to set the
House Code or the PIR Detector and must be set to
the same ON/OFF combination as the House Code
DIP switches in all other system devices.
2. Set the alarm zone which the PIR Detector will
operate on, with DIP switches 1-3 o SW3 as ollows:
Sett ng for S ren only Alarm System
For a Siren only Alarm System, DIP switches 1-3 o SW3
must be set as ollows:
Sett ng for an Alarm System w th a Control Panel
I your system has a Control Panel, DIP Switches 1-3 o
SW3 should be set as ollows:
Rear Cover
Fixing Screw
Mounting Hole
Positions
8
7
6
5
4
3
2
12
14
35
ECE
ECEON
ON
SW3SW2
5
4
3
2
1
DIP Switches
(SW2 and SW3)
PCB Board
(slides up and
down to adjust
position)
ON ECE
ON ECE
1 2 3 4 5 6 7 8 1 2 3 4 5
SW3
SW2
Set to House Code
Zone
Settings
Walk Test Sensitivity
DIP 1
ON
DIP 2
ON
DIP 3
OFF
Zone 1
Zone 2
Zone 3
Zone 4
Zone 5
Zone 6
DIP 1
OFF
OFF
OFF
OFF
ON
ON
DIP 2
OFF
OFF
ON
ON
OFF
OFF
DIP 3
OFF
ON
OFF
ON
OFF
ON

3. DIP 4 o SW3 is used to con igure the PIR Detector or
walk test mode, which allows the operation o the
Detector to be checked during installation without
triggering a Full Alarm.
Note: On initial installation the PIR Detector should be
set to Walk-Test mode ready or testing.
4. The PIR Detector incorporates a sensitivity eature
designed to compensate or situations where the
Detector may be a ected by environmental changes,
(e.g. insects, air temperature, etc). This eature is called
“Detection Sensitivity” and may be set to Standard or
High Sensitivity.
Note: The higher the sensitivity the less movement
will be necessary be ore the PIR Detector will trigger
the alarm.
The recommended setting is Standard Sensitivity. I
set to High Sensitivity, in some cases, extreme
environmental problems could cause unattributed
alse alarms. I this is experienced it may be necessary
to reset the PIR Detector to Standard Sensitivity.
Set the required detection sensitivity using DIP 5 o
SW3 as ollows:
5. Connect the PP3 alkaline battery to the battery clip.
Note: When the 9V alkaline battery is connected, the
LED behind the lens will lash or 2-3 minutes until the
PIR has warmed-up and stabilized. The LED will then
stop lashing and turn OFF.
Test ng The PIR Detector
Before test ng the PIR Detector ensure that the
system s n Test mode (for a Control Panel System) or
Serv ce Mode (for a S ren only System).
With the PIR Detector set in Walk Test mode (Switch 4) and
mounted in position on the wall, allow 2-3 minutes or the
PIR Detector to stabilize be ore commencing the Walk Test.
1. Walk into and move slowly around the protected area,
each time the PIR Detector senses your movement
the LED behind the Lens will lash.
I necessary re-adjust the detection pattern by
changing the mounting position o the PCB within the
PIR housing.
2.
Recon igure the PIR Detector or normal operation mode
by setting DIP4 o SW3 to OFF and re it in position.
Note: In normal operation, the LED behind the PIR
Detector lens will not lash on movement detection,
(unless the battery is low).
Note: When the PIR Detector is ully installed i.e.
battery cover is re itted; the unit will not detect
movement or approximately 45 seconds a ter each
activation. (This eature is present to conserve battery
power and maximize the battery li e).
D sposal and Recycl ng
Disposal o this product is covered by
the Waste Electrical or Electronic
Equipment (WEEE) Directive.
It should not be disposed o with other
household or commercial waste.
At the end o its use ul li e the packaging and product
should be disposed o via a suitable recycling centre.
Please contact your local authority or the retailer rom
where the product was purchased or in ormation on
available acilities.
OFF Standard Sensitivity
ON High Sensitivity
DIP 4 Mode Tr gger react on
of SW3 on LED
ON Walk • LED single lash when
Test movement detected:
implies the sensor is
set to high sensitivity
• LED lashes three times
and illuminates once:
implies the sensor is
set to low sensitivity
OFF Normal LED will not light up
Position (unless the battery in the
PIR is low)

Response Electron cs Ltd.
Roman House, Lysons Avenue, Ash Vale, Surrey GU12 5QF
Email: [e-mail]
Web: www.ResponseElectronics.com
Techn cal Support Helpl ne:
0845 373 1353
(Local Call Rate - lines open 09.00 to 17.00 Monday to Friday)
SAP E Ed.1
Guarantee
The product is guaranteed or one year rom the date o purchase against aulty materials and workmanship. No
liability can be accepted or any problems caused by air wear and tear, buyer’s negligence, improper itting or use,
wil ul or accidental damage, or any consequential loss or damage howsoever caused. This guarantee does not a ect
your statutory rights and is valid or UK and EIRE only.
I you believe the product to be aulty or in the unlikely event o the product developing a ault during the warranty
period, then please contact our Technical Support Team (contact details shown below) or product assistance.
Product repair or replacement will be o ered or aulty products only with our prior agreement. Should you need to
return a product then:
1. Contact the Help Line on the number below to obtain a Return Authorisation Number
2. Adequately package your product to prevent damage in transit and include the ollowing:
a. A copy o your original invoice/receipt
b. A covering letter giving your ull contact details, including email address (i applicable)
c. A description o the ault or problem
