Restwell CURVE User manual

®®
Got Questions? Talk to One of Us at: +1 604.576.2339 | [email protected] | restwell.com
CURVE
Adjustable Bed Manual
Restwell's Curve Adjustable bed extends your
resting and sleeping preferences to another level.
With Multiple adjustable configurations, your body will
have endless possibilities of comfort.
Save your preferences and adjust your bed to
dierent positions while you rest in your bed
Control Operated
Conture your mattress to the curves of your
body and prevent straining your neck or
shoulders while you relax.
Multiple Adjustable Positions
Version 1.0
Twin XL: 38” x 80” (96.5 x 203 cm)
Queen: 60” x 80” (152 x 203 cm)
Available Sizes & Specifications:

®®
Got Questions? Talk to One of Us at: +1 604.576.2339 | [email protected] | restwell.com
Version 1.0
Content Index
Safety Precautions.........................................
Included Items & Parts...................................
Assembly Instructions...................................
Remote Control .............................................
Button Functions ...........................................
Memory Setting .............................................
Power Outage ................................................
Troubleshooting ............................................
Warranty .........................................................
3
3
4
5
5
5
6
6
6
Do you have questions about your Adjustable
Base? or have troubles putting it together?
Contact us, we are here to help you with an inquiry you may
have. Talk to one of our support represntatives today.
Hour of Operation: Monday- Friday from 9 am - 5 pm (PST)
2

3
®®
Got Questions? Talk to One of Us at: +1 604.576.2339 | [email protected] | restwell.com
Version 1.0
Included Items & Parts
Bed Platform X1 Mattress Rail X1 Legs X4
Power Supply X1 Power Cable X1 Remote Control X1
Please read all directions before using the bed and retain this guide for reference.
• Input voltage: AC 100-240V. 50/60HZ, output: DC29V 2.0A.
• Unplug the bed before cleaning it.
• Keep the product wire, power supply, and control box away from heat.
• Do not use the bed in a humid environment. The connector part of the wire and the gap between
the motor and the control box cannot be exposed to liquid or high humidity
• Never operate the bed if it has a damaged cord or plug, or is not working properly.
• Unplug the power cord and remove the remote control battery when the bed is not being used
for a prolonged period of time.
• Consult your physician if you have any health questions regarding the use of this product.
• Do not let children play with or operate the bed.
• Do not allow children or pets underneath the bed.
Safety Precautions

®®
Got Questions? Talk to One of Us at: +1 604.576.2339 | [email protected] | restwell.com
Version 1.0
Assembly Instructions
The bed is now ready for use.
1 2 3 4
Lay the carton flat on the floor
and carefully cut it open.
Lift the carton so that the
open side faces down and
slide it up and o the bed.
Place the bed upside-down
flat on the floor
Remove and discard the
plastic bag. Put together the
two pieces of the bed and
align them flat on the floor.
Cut the zip ties, take out all
the part boxes and the
mattress rail, and check
that you have all the
necessary parts according
to the parts list.
5 6
For leg assembly push the
screw through the triangu-
lar brace. Screw in the leg
and tighten.
Connect the 01-connector
from the controller to the
01-plug of the power supply.
Connect the 8-wire plug of the
power cable to the other jack on
the switch’s power supply.
Connect the power cable to your
nearby power outlet.
Insert the mattress rail at
the foot of the bed. The
bed is now ready for use.
7
9
10
8
Insert batteries into the remote
control. Press the first circled
button. If the motor begins to run,
unplug the power supply and turn
the bed over to its right side-up
position. If the motor does not run,
it needs to re-match its code.
Matching code: Press the two
buttons in the circles shown and at
the same time press the little
button on the side of the control
box until you hear the 'didi' sound.
4

®®
Got Questions? Talk to One of Us at: +1 604.576.2339 | [email protected] | restwell.com
Version 1.0
Remote Control Functions
Foot Up
Foot Down
Flat Postion
Remote Flashlight
Programmable
Position Memory
Head Down
Head Up
Button Functions
Press and hold to raise the backrest. Let go
when the desired position is reached.
Press and hold to lower the backrest. Let
go when the desired position is reached.
Press and hold to raise the footrest. Let go
when the desired position is reached.
Click to set a user-defined position.
Click to turn the LED flashlight on top of the
remote on and o.
Click to flatten the bed.
Press and hold to lower the footrest. Let go
when the desired position is reached.
Memory Setting
1. Press the FLAT button to flatten the bed.
2. Adjust the bed to your preferred position.
3. Press and hold button M and let go after
you hear the “didi” chime sound.
4. Chime indicates the setting has been
successfully programmed.
5. Resume back to progrommed position
by pressing the memory button at any time.
5

6
®®
Got Questions? Talk to One of Us at: +1 604.576.2339 | [email protected] | restwell.com
Version 1.0
Power Outage
2. Use the remote to return the bed to a flat
sleeping position until power returns.
2. Check the green power indicator light on the
power supply. If it’s not lit, check the power outlet.
4. Check if the adjustable beds assembled
according to the above steps.
Press and hold to raise the backrest. Let go
when the desired position is reached.
1. Open the power box and install the
appropriate battery.
3. Once power returns replace the battery
if needed.
Troubleshooting
1. Press any button on the remote control to see
whether the blue backlight is bright. If it’s dim or does
not light, check the battery.
Curve warrants faulty workmanship or materials, subject to the limitations that follow:
Year 1: Full parts and labour coverage for the entire unit (control box, remote control, motor and metal frame).
Year 2: Full parts coverage for the motor and control box.
In no instance will this warranty be valid if the bed is misused or damaged by the purchaser or subjected to weight in
excess of 272 kg (600 lbs).
This warranty is limited to the original purchaser.
Proof of purchase must be in the form of a verifiable copy of the original invoice.
Please retain this manual and your original invoice for future reference and documentation.
3. Check for loose wires or connectors.
Warranty
