RESTWELL RISE & RECLINE ARMCHAIRS
LARS AND SVEN - OWNER’S HANDBOOK
1. Introduction
2. Model Description
3. Parts Description
4. Personal Safety
5. Installation Instructions
6. Operating Instructions and
Guidelines
7. Care and Maintenance
8. Specification
9. Fair Wear and Tear Policy
10. Warranty
11. Appendix A: Backrest
Assembly Instruction
sheet
12. Appendix B: Wiring
configuration
CONTENTS INTRODUCTION
The Restwell range of lift, rest and recline armchairs are designed to be both
comfortable and stylish whilst also enhancing your mobility.
This armchair is available in a variety of styles and cover material to suit most
décor. There are 6 models available. This manual covers all 6 models of
armchair. All armchairs are made to the highest quality and are CE marked. They
have a weight limit of 27½stone (175kg), except for the manual recline
armchairs which have a weight limit of 120kg (19 stone). They all feature a back
rest recline / legrest elevate function.
Restwell is a brand of Drive Medical. Drive Medical is an ISO 9001:2000
certified company. For more details about our products please see your local
dealer. To find your local dealer please contact:
Drive Medical Ltd,
Ainley’s Industrial Estate,
Elland, United Kingdom HX5 9JP
Tel: +44 (0) 1422 314488
Web: www.drivemedical.co.uk
MODEL DESCRIPTION
Restwell Rise & Recline Armchair
Owner’s Handbook
Part Code: Z50989 (Rev C)
Page 1 of 7
zThe Lars Manual recline armchair. This
armchair is available in genuine Buffalo
leather with PVC back match. It features
easy recline control with side arm mounted
cup trigger release.
zThe Lars Electric recline armchair. This
armchair is available in genuine Buffalo
leather with PVC back match. It features a
basic handset which reclines the backrest
and elevated the legrest electrically.
zThe Lars Electric rise armchair. This
armchair is available in genuine Buffalo
leather with PVC back match.
The single motor features a standard handset
which only requires approximately 6cm / 2”
behind the armchair hence is ideal where
space is a premium.
The dual motor version allows the back rest
and leg rest to operate independently.
zThe Sven Manual recline armchair. This
armchair is available in genuine Buffalo
leather with PVC back match. It features
easy recline control with side arm mounted
cup trigger release.
zThe Sven Electric recline armchair. This
armchair is available in genuine Buffalo
leather with PVC back match. It features a
basic handset which reclines the backrest
and elevated the legrest electrically.
zThe Sven Electric rise armchair. This
armchair is available in genuine Buffalo
leather with PVC back match. It features a
standard handset which only requires
approximately 8cm / 3” behind the armchair
hence is ideal where space is a premium.

Restwell Rise & Recline Armchair
Owner’s Handbook
Part Code: Z50989 (Rev C)
Page 2 of 7
PARTS DESCRIPTION
PERSONAL SAFETY
Please follow the safety guidelines below to ensure that you get the best from your armchair for many years to come.
Failure to follow these guidelines could result in injury or damage:
zJust one at a time. Ensure that only one person uses the armchair at a time.
zFootrests are for feet. Ensure that nobody sits or puts their entire body weight on the elevated footrest as this could
result in injury and/or damage
zWatch for walls. Ensure that the armchair is out of range from walls and furniture when operating to avoid
damage to upholstery and décor.
zStop Child. Ensure that all children and pets are supervised when around the armchair. Do not allow children to
use the handset, and that all visitors are aware of the potential trapping danger from mechanisms.
zTake your key. The handset comes with a key jack. It is recommended that you remove the key when you are not
using the armchair to prevent any body else using the armchair and becoming trapped.
zBe careful of the scissor mechanism. The elevating leg rest uses a scissor mechanism. Please ensure that no body
parts or clothing, blankets, etc are caught in the scissor mechanism when operating.
zPractice makes perfect. In certain circumstances or with some medical conditions the user needs to practice using
the rise recline armchair in the presence of a trained attendant. A trained attendant may be a care professional or a
family member who has been trained in assisting a rise recline armchair user with daily activities.
zWeight Limit. Observe and do not exceed the weight limits on the armchair
zBattery backup. Ensure that the battery back up is replaced very year or when the battery back up is used in the
event of a power cut. See the section on Installation Instructions about inserting backup batteries.
zElectrical systems. Periodically visually inspect the handset and power cord for signs of wear, chafing or cracks.
Also, ensure that no liquid or food is ingressed in to the electrical systems. Failure to do so may affect the
performance of the armchair.
zCall for assistance. It is recommended that some users have a telephone to hand when using the rise recline
armchair. This is in case they experience difficulty and need to call for help. Please note do not use a mobile
telephone whilst operating the armchair. It is recommended that you pull out the handset key before using a mobile
telephone. Failure to do so could cause damage to the electrical systems.
zCarelessness causes fire. Although the foam and fabric used on the armchair are fire retardant to legally specified
levels, caution should be taken to avoid fire. Please ensure that all cigarettes and matches are properly
extinguished. Also, be careful of other fire hazards such as electric and gas fires, etc nearby,
BACK REST
CUSHION
SEA
T
CUSHION
ARM REST
CUSHION
LIFTING
MECHANISM
BACK REST
SCISSOR
MECHANISM
(
NOT SHOWN
)
LEG REST
HANDSET

Operation ( Standard Handset )
zPress the ‘Up’ button to raise the
back rest to the upright position,
lower the leg rest and raise / tilt
the armchair to allow easy access.
zPress the ‘Down’ button to lower
the armchair, elevate the leg rest
and recline the back rest. The leg
rest elevates and the back rest
reclines simultaneously.
Operation ( Basic Handset )
zPress the ‘Recline” button to
lower the armchair, elevate the leg
rest and recline the back rest. The
leg rest elevates and the back rest
reclines simultaneously.
zPress the ‘Return’ button to raise
the back rest and lower the leg
rest to the armchair normal chair
position.
Restwell Rise & Recline Armchair
Owner’s Handbook
Part Code: Z50989 (Rev C)
Page 3 of 7
INSTALLATION INSTRUCTIONS
OPERATING INSTRUCTIONS AND GUIDELINES
zTo assemble your recline armchair, first install the back rest. Slide the back on ensuring the two back rest brackets
go over the two back rest receiver brackets on the armchair. Push down hard on the back rest to lock in position.
Ensure both sides of the back rest are locked in position before use. Your dealer may have done this prior to
delivery. This procedure is described in more detail with photographs on a separate sheet supplied with the
armchair. A copy of this sheet is also included in the back of this handbook.
zThen plug the armchair in to the mains and operate the armchair so it moves. To install the battery backup, first
unplug the armchair. Then press the plastic tab on the battery compartment lid whilst removing. Install two 9V PP3
batteries in to the battery back up place on the main control box underneath the chair. Replace the battery
compartment lid. (See appendix B for a photo showing the compartment’s location).
zYour armchair comes supplied with all peripherals (i.e. handset and actuator) connected. If you need to plug or
unplug any of the peripherals please contact your dealer for information on how to this.
zPlease contact Drive Medical should you require the wiring configuration details for any of the armchairs
General Operation (all electrical
model)
zTo allow the armchair to
operate, the key jack must first
be inserted in to the safety lock.
This is a safety precaution and
the key jack should be removed
when the armchair is not in use
to prevent accidental movement
of the armchair.
zThe power LED will illuminate
when the armchair is operating.
zEnsure that you have read the
section on personal safety before
operating the armchair.
zThe rise armchair is controlled
by the standard handset. The
electric recline armchair is
controlled by the basic
DOWN
BUTTON
UP
BUTTON
KEY JACK
KEY SLOT
KEY JACK
RECLINE
BUTTON
POWER
LED
RETURN
BUTTON
KEY SLOT
POWER
LED
FACE SIDE FACE SIDE

Chair dimensions ( in cm / in ) Seat dimensions ( in cm / in ) Weight
Limit
Chair Model Depth Width Height Depth Width Height
Lars Manual 100 / 39½” 90 / 35½” 104 / 41” 53 / 20¾” 44.5 / 17½” 47.5 / 18¾”120kg
Lars Electric 100 / 39½” 90 / 35½”104 / 41” 53 / 20¾”44.5 / 17½”47.5 / 18¾”175kg
Lars Rise 100 / 39½” 90 / 35½”110 / 43¼” 53 / 20¾”44.5 / 17½”51 / 20” 175kg
Sven Manual 99 / 39” 90 / 35½”101 / 39¾” 54 / 21¼”42 / 16½”49.5 / 19½”120kg
Sven Electric 99 / 39” 90 / 35½”101 / 39¾” 54 / 21¼”42 / 16½”49.5 / 19½”175kg
Sven Rise 99 / 39” 90 / 35½”104 / 41” 54 / 21¼”42 / 16½”51 / 20” 175kg
Restwell Rise & Recline Armchair
Owner’s Handbook
Part Code: Z50989 (Rev C)
Page 4of 7
CARE AND MAINTENANCE
PERSONAL SAFETY
zAll the above dimensions are for the armchairs in their normal chair position.
zAll Restwell rise & recline armchairs are CE marked and meet the relevant British Fire Retardancy Standards
zAll rise & recline armchairs have a serial number label on them, which is located on the armchair frame.
zAll electrical armchairs have a weight limit of 175 kg (27½stone).
zAll manual recline armchairs have a weight limit of 120 kg (19 stone).
zLeather care. Periodically inspect the leather for any signs of wear or damage such as pulls, tears, or gaps. Please
note that leather is a natural product and will not look the same in every location..
zElectrical and control systems. Periodically inspect the cord and hand control for cracks, wear, holes and loose
wires.
zBattery backup. The Restwell range of armchairs has a battery backup system which is designed for emergency
use in the event of a power failure. The battery should be replaced annually or after a power failure. The backup
system has very limited power so should only be used in the event of a power failure or emergency. The backup
system requires two 9V PP3 batteries.
zServicing. Restwell rise recline armchairs are designed to be maintenance free and do not require regular
servicing. However, if a problem does occur with your armchair or you require a spare part please contact your
Drive Medical dealer..
zCleaning the Upholstery – all leather. We recommend cleaning leather with a slightly moist cloth only, and not
using cleaning agents. If you feel you must use a cleaning agent, please use only the agents which have been
especially made for cleaning leather. Please also make sure the cloth or sponge you use to clean the leather (with
warm water or special leather cleaning agents) is appropriate to use for wiping leather.

Restwell Rise & Recline Armchair
Owner’s Handbook
Part Code: Z50989 (Rev C)
Page 5 of 7
FAIR WEAR AND TEAR POLICY
WARRANTY
zDamage from misuse, and use over the specified
weight limited.
zMaterial fading over time of through sunlight.
zDamage from spills or leaks.
zCigarette and match burns.
zCollision damage ( rubbing against wall, etc)
zAccidental tear and damage.
zDamage arising from misuse (e.g. people sitting
on an elevated footrest, etc)
Your new armchair is covered b
y
the warrant
y
below. Please note howeve
r
this Warrant
y
does not include:
Your Restwell lift, rest and recline armchair comes with a comprehensive twelve-month warranty. For warranty
issues and claims please contact your Drive Medical dealer.
Warranty Conditions:
1. Any work or replacement part installation must be carried out by an authorized Drive Medical dealer / service agent.
2. To apply the warranty should your armchair require attention please contact the designated service agent listed below.
3. Should any part of the armchair require repair of full or part replacement as a result of a manufacturing or material defect
within twelve-month of receiving the armchair, parts will be supplied free of charge.
Note: The guarantee is not transferable
4. Any repaired or replaced parts will be covered by this warranty for the balance of the warranty period on the armchair.
5. Parts replaced after the original warranty has expired will be covered by a three-month warranty.
6. Consumable items supplied will not generally be covered during the normal warranty period unless such items require repair
or replacement clearly as a direct result of a manufacturing or material defect.
Such items include (among others): upholstery, batteries
7. The above warranty conditions apply to brand new chairs. If you are unsure whether your chair is covered, check with the
service agent. Products supplied by Drive Medical as ex-demonstration carry a six-month warranty.
8. Under normal circumstances, no responsibility will be accepted where the armchair has required repair as a direct result of:
a) The armchair part not having been maintained in accordance with the manufacturer’s recommendations
b) Failure to use the manufacturer’s specified parts
c) The armchair or part having been damaged due to neglect, accident or improper use
d) The armchair or part having been altered from the manufacturer’s specifications or repairs having been attempted
before the service agent is notified.
In the event of your armchair requiring attention, please contact your service agent / dealer and give all relevant details so they
can act quickly. Please contact Drive Medical for advice if you do not know where the armchair was originally purchased from.
The manufacturer reserves the right to alter without notice any weights, measurements or other technical data shown is this
manual. All figures, measurements and capacities shown in this manual are approximate and do not constitute specification.
DEALER
STAMP

Restwell Rise & Recline Armchair
Owner’s Handbook
Part Code: Z50989 (Rev C)
Page 6 of 7
APPENDIX A: INSTRUCTION SHEET
BACK ASSEMBLY PROCEDURE
BACK REMOVAL PROCEDURE
Pull the spring strips from both sides out and up.
* Note: To remove the back, pull the spring strips out and up simultaneously.
* Note: It takes 2 people to remove the back.
Firstly, operate the armchair so
it is in the reclined position.
Then position the back to line
up with the bayonet slots.
Operate the armchair to its
position. Please remember to
fasten the panel to the Velcro
below.
* Note: Before usin
g
, ensure both sides of the back are securely locked in position
To insert the back into the fixed
slots, then apply pressure
downwards, pushing down on
the back, ensuring both sides
click to lock in position.

Restwell Rise & Recline Armchair
Owner’s Handbook
Part Code: Z50989 (Rev C)
Page 7 of 7
APPENDIX B: WIRING CONFIGURATION
Below shows the wiring diagram for the electric recline armchair & rise armchairs. It also shows the location of the
battery back up compartment.
Z50886-21
2-BUTTON
BASIC HANDSET
Z50831-21
ACTUATOR
Electric Recline
A
rmchair Electric Rise
A
rmchai
r
Z50885-21
2-BUTTON
STANDARD
HANDSET
Z50851-21
CONTROL BOX
Z50831-21
ACTUATOR
TSS PLUG-IN
( BYPASSES
CUTOUT STRIP )
BACKTUP
BATTERY
COMPARTMENT
2No. PP3 BATTERIES
(FOR BACKUP )
2-BUTTON
HANDSET
CONTROL BO
X
ACTUATOR
TSS (COMES WITH
CONTROL BOX)
6-PIN
DIN
PLUG
4-PIN
DIN
PLUG
T
SS
LIFT
RISE RECLINER
ARMCHAIRS
SINGLE MOTOR
WIRING
CONFIGURATION
This manual suits for next models
5
Table of contents
Other Restwell Massager manuals
Popular Massager manuals by other brands

HoMedics
HoMedics MCS-300H Instruction manual and warranty information

komoder
komoder Luxury II user manual

Human Touch
Human Touch Serenity Plus PC 086 Use & care manual

Infinity
Infinity Smart Chair installation guide

WELLSYSTEM
WELLSYSTEM Medical_Plus operating instructions

Sharper Image
Sharper Image SHIATSU 205416 owner's manual
