Revolutionary Science SANICLAVE FRONT-LOADER Series User manual

Instrucon Manual
SANICLAVE FRONT-LOADER SERIES

TABLE OF CONTENTS
Introducon 2
Display, Symbols, Control and Parts 3
Installaon Instrucons Intended Use 4
Limitaons of Use 4
Safeguards Cauons 5
Operang the Saniclave 6
Printer 6
Troubleshoong and Error Modes 10-12
Warranty, Registraon and Policy 13
Specicaons 14
Contact Informaon 14
Checklist and Notes of Service Record 15
Care, Storage and Maintenance 16
Sterilizaon Monitoring Guidelines 18
Addional Product Images 20
Instrucon Manual for the Revoluonary Science
SANICLAVE FRONT-LOADING SERIES
1
17319 Lake Blvd. Shafer, MN 55074 | 800-775-7942 | Fax: [phone] | [email protected] | revsci.com
NOTE: Read this manual before use! This manual contains important informaon, safeguards and operang
instrucons for the operaon of the REVOLUTIONARY SCIENCE model Saniclave by Alternave Pioneering
Research & Development, Inc. (APR&D, Inc.)
© Alternave Pioneering Research and Development, Inc.

Saniclave Front-Loading Series
INTRODUCTION
Dear Valued Customer,
Thank you for purchasing the Revoluonary Science Saniclave. We are condent
that the Saniclave will provide years of reliable service. The high quality of
construcon and durable parts deliver a performance equivalent to much costlier
equipment.
You are invited to visit our web site at www.revsci.com. Please know that we
welcome any feedback that might help us enhance and improve future RevSci
products.
Sincerely yours,
REVOLUTIONARY SCIENCE
2
17319 Lake Blvd. Shafer, MN 55074 | 800-775-7942 | Fax: [phone] | [email protected] | revsci.com
Rev. 11-2021

3
17319 Lake Blvd. Shafer, MN 55074 | 800-775-7942 | Fax: [phone] | [email protected] | revsci.com
Saniclave Front-Loading Series

INSTALLATION INSTRUCTIONS
Remove Saniclave from packaging and place it on a dry level surface. Plug it into
an accessible 120 VAC power receptacle. For oponal printer setup, see pg. 6.
The Saniclave is now ready for use. See operang instrucons on pg. 7.
Upon receiving the Saniclave, it is important that you follow these simple steps:
1. Examine carton and contents for possible damage to the product caused
during shipping. If damage is present contact the carrier at once. Failure to do
so immediately may release the carrier from any liability of damage.
2. Fill out the checklist (see pg. 14). If the shipment is incomplete, please
contact us at [e-mail] or [phone] x 2.
3. Carefully read this instrucon manual before operang the Saniclave.
4. 4. Visit the product registraon webpage provided on pg. 12 by scanning
the QR code or entering the URL manually and complete the registraon
online.
INTENDED USE
The Revoluonary Science Saniclave is designed to be used in medical and dental
clinics, hospitals and other facilies where reusable sterile equipment is used. It
is intended to sterilize wrapped and unwrapped heat and moisture stable solid
instruments, mated surfaces, knurled and hinged devices (excluding lumened devices
and dental hand pieces) that are compable with saturated steam sterilizaon at
121 degrees C° for 30 minutes.
SAFEGUARDS & CAUTIONS
WARNING! Do not use this autoclave in an explosive or oxygen rich atmosphere.
Failure to do so may result in serious injury or death.
CAUTION: Chamber contains hot water and steam during and aer operaon.
Hot water may drip from cover during removal and can cause scalding.
Occasionally parts such as the door seal, control panel decal, and ZPD
should be replaced aer heavy usage: These easily replaceable parts are
available through Revoluonary Science. No tools are required.
Saniclave Front-Loading Series
4
17319 Lake Blvd. Shafer, MN 55074 | 800-775-7942 | Fax: [phone] | [email protected] | revsci.com

LIMITATIONS OF USE
Revoluonary Science is not responsible for misuse of the Saniclave.
1.The load should be considered non-sterile unless the display reads ‘CC’
aer the cycle.
2. NEVER aempt to dismantle or modify the Saniclave.
3. NEVER leave an operang Saniclave unaended.
4. NEVER block the drain (located on the inside of the chamber below
heang element).
5. NEVER block the steam trap (located on the inside of the chamber, near
the top, directly above drain).
6. NEVER operate the Saniclave with a damaged cord or plug or aer the unit
malfuncons or has been damaged in any manner.
7. NEVER use accessory aachments not recommended by Revoluonary
Science. Their use may cause re, electrical shock or injury.
8. NEVER use the Saniclave or any purpose other than the intended use.
9. ALWAYS close the door properly before operang.
10. NEVER aempt to force the door open or release pressure while sterilizer
is in operaon.
11. ALWAYS use dislled water. The sensor detects ion content in the water
If dislled water is too pure, the autoclave may not detect the presence
its presence. Salt may be added to the water to increase detectability.
Class III dislled water is recommended.
12. NEVER reuse water le in the exhaust tank. Re-used water may contain
endotoxins. Drain water tank and rell chamber with clean, dislled water
before each cycle.
13. NEVER aempt to modify the plug to t an outlet other than the required
3-slot, grounded outlet. The enclosed 3 prong plug is equipped with a
grounded type 3 conductor wire to further ensure the safe operaon of
the Saniclave.
14. NEVER immerse the autoclave, cord, or plug in water or operate on wet
surfaces.
15. NEVER ll the exhaust tank with water (See pg. 3 for locaon of
exhaust tank and cap). The Saniclave must be lled by pouring water
directly into the chamber.
16. ALWAYS load the Saniclave with instruments compable with steam
sterilizaon at 121 degrees C° for at least 30 minutes. Always contact
the instrument’s manufacturer if you are unsure that this sterilizaon
technique is suitable for instruments being sterilized.
17. ALWAYS inspect the silicone seal before each use for dirt, grime or
cracks.
18. NEVER clean the Saniclave with organic solvents like thinner or benzene
as it will damage the surfaces.
19. ALWAYS test regularly with Geobacillus stearothermophilus. See pg. 17
for sterilizaon monitoring and control for more informaon.
20. This sterilizer has not been validated for double pouching.
5
17319 Lake Blvd. Shafer, MN 55074 | 800-775-7942 | Fax: [phone] | [email protected] | revsci.com
Saniclave Front-Loading Series

OPERATING THE SANICLAVE
PREPARATION FOR STERILIZATION (DEFAULT MODE)
Important:The load should be considered non-sterile unless the display reads
‘CC’ aer the cycle.
1. Preclean instruments according to their manufacturer’s recommendaons.
WARNING! Failure to properly clean instruments before autoclaving, may
result in unsterile equipment. Using unsterile equipment may result in serious
injury or death.
2. It is recommended that all instruments be dismantled, if possible.
CAUTION: Stacking instruments improperly may result in nonsterile
equipment.
3. Use a sterilizaon indicator strip with each set of instruments
being autoclaved.
4. The recommended load is 4.5 lb (not including the tray). Never exceed the
maximum load. Exceeding maximum load may result in nonsterile equipment.
5. Run a biological indicator spore test (Geobacillus stearothermophilus) at
least weekly to conrm proper sterilizaon. For addional informaon on
purchasing biological indicators, see pg. 17.
PRINTER INSTALLATION AND OPERATION
Saniclave: The recommended printer model is the Zebra 2844 with a serial
cable connecon. Printer paper must accommodate printout width of 4
inches. Follow printer manufacturer’s recommendaons for regular repair,
cartridge replacement and service. The printer must be powered and
connected to the Saniclave via a serial cable prior to use.
Saniclave 200P: The printer is axed on the right side of the autoclave.
The Saniclave 200P printer requires 2” wide thermal paper.
Sucient paper must be installed in the printer. At the end of the cycle
(whether it is a complete cycle or a failure), the SET buon, found on the
control panel may be pressed to obtain the
printout. If the Saniclave is reset or powered
down, the printout data cannot be recovered.
Printouts should be made in accordance to
your facility’s standard operang procedures.
A successful printout should look similar to
the following sample printout:
Saniclave Front-Loading Series
6
17319 Lake Blvd. Shafer, MN 55074 | 800-775-7942 | Fax: [phone] | [email protected] | revsci.com

OPERATING INSTRUCTIONS
1. Place the Saniclave on a dry, level surface and rest the drain tube in a sink,
bucket, or other receptacle. Alternavely, the drain tube may be pinched shut and
the water drained every few cycles (see pg. 10).
2. Remove the chamber door by rotang door counterclockwise.
3. Fill the chamber with approximately 500mL of dislled water (unl the heang
element is fully submerged and the metal poron of the temperature sensor is in
contact with the water). ALWAYS use dislled water. The sensor detects ion content
in the water. If dislled water is too pure, the autoclave may not detect the water.
Salt may be added to the water to increase detecon. Class III dislled water is
recommended.
4. Place the tray support in the boom of the chamber, put the tray on the support,
and load the instruments to be sterilized (wrapped or unwrapped) on top of the tray.
5. Inspect the door to assure that the seal is clean and not damaged. Be sure that
the inner poron of the door is also clean and clear, ensuring a secure t.
6. If the seal has been removed re-install seal in the door by evenly tucking seal
under all lugs. Seal may be cleaned with warm, soapy water (discard seal when it
becomes noceably cracked or worn).
7. Place the door on the chamber, aligning the marking on the door with the ‘OPEN’
marking on the autoclave. To close, rotate the door clockwise, ensuring that the
marking on the door is aligned with the ‘CLOSE’ marking on the autoclave. Never
aempt to rotate the door past this CLOSE marking! Improper closing of the door
can cause pressure leaks or damage to the autoclave.
8. Insert the plug of the cord into the wall outlet. NEVER modify the plug to make it
t, as the plug will only t in one way. The autoclave must be grounded when in use.
9. The 4-digit LED indicator will turn on and show ‘0000.’
10. Press ‘START/STOP’ to begin the sterilizaon process for wrapped items. If using
unwrapped items press the ‘ADVANCE’ buon instead.
NOTE: To abort the cycle at any me, press ‘START/STOP’ again. Display will then
read ‘Err 1’ and chamber will instantly depressurize. Allow a few minutes for the
chamber to depressurize before opening the door.
11. The display will briey read ‘C1’ or ‘C2’ for wrapped and unwrapped cycles
respecvely, then change to ‘Ph’ for the preheat mode which takes around 25
minutes to complete.
NOTE: Monitor the display for any errors. If an error warning is displayed, the
cycle will be aborted (see troubleshoong secon on pg. 10).
12. When the preheat mode is nished the display will automacally begin to count
down during the 30-minute sterilizaon cycle. For your convenience, the display will
show the temperature reading. To view the pressure or cycle me le, 12. see pg. 8.
13. Aer the sterilizaon cycle the display will read ‘drn’ and the unit will
automacally depressurize and begin draining. Due to door locking safety feature
of the seal, opening the door is not possible unl the chamber is completely
depressurized. You may hear sound of the chamber depressurizing, which is normal.
7
17319 Lake Blvd. Shafer, MN 55074 | 800-775-7942 | Fax: [phone] | [email protected] | revsci.com
Saniclave Front-Loading Series

17. When the chamber has completed draining the autoclave will make an audible
beep. and the screen will read ‘turn door’ or ‘CC’ aer wrapped or unwrapped
sterilizaon cycles respecvely. If you autoclaved a wrapped load, rotate the door
counterclockwise, remove the door from the chamber, and tuck the boom lip of
the door under the retainer clip so that the door gently rests against the autoclave
providing a small air gap for the drying cycle. Then press the ADVANCE buon to
begin the drying mode. During this mode, the heater warms the chamber for 30
minutes and moist air vents out of the door gap. When drying is completed, the
screen will read ‘CC’. To avoid condensaon let your items cool for an addional
30 minutes before removing. If you autoclaved an unwrapped load, rotate the
door counterclockwise, remove the door from the chamber, and recover your
items. Use cauon as internal chamber contents may be hot to the touch.
18. If the Saniclave is connected to a printer, a cycle report will print when SET
buon is pressed, showing the date/me, preset and achieved parameters.
A RECOMMENDED LOAD CONFIGURATION
Load must not exceed 4.5 lbs. Stand packs upright if possible.
CYCLE PHASES
Fill Display reads “Fill” if the ‘START/STOP’ buon is pressed and the chamber
has not yet been lled with sucient water.
Preheat Mode.
Display will read ‘Ph’ for Preheat. This mode usually lasts about 30 minutes,
depending on the load size.
Sterilizaon Mode Display will show temperature in Celsius:
•Press ADVANCE to view the pressure reading
•in psi
•Press SET to view the cycle me remaining.
Dry Mode
When the sterilizaon cycle is successfully completed, the display will read ‘drn,’
for drain mode. As the water drains, the chamber completely depressurizes and
shortly thereaer (if selected), the Dry Mode may be iniated. During dry mode,
the display will alternate between ‘dry’ and the 30-minute mer.
CC Mode
Aer a successful compleon of the enre cycle, the display will read ‘CC’ for
Cycle Complete. Remove the door and remove the instruments. Instruments
may be warm to the touch.
Print Date/me, preset and achieved parameters are printed.
Saniclave Front-Loading Series
8
17319 Lake Blvd. Shafer, MN 55074 | 800-775-7942 | Fax: [phone] | [email protected] | revsci.com
