Thank you for purchasing a REVOX product. To ensure
proper use of the product, please read this Instruction Guide
before use and keep it for your future reference.
The light intensity can be controlled in up to 1024 steps.
Status conrmation and operation settings can be performed on the LCD.
In addition to the manual control from the front panel, external control with
parallel communications (including digital intensity control and analog intensity
control), Ethernet communications, and RS-232C communications are also
possible.
Intensity feedback function is available to suppress fluctuations in the
illumination.
High speed strobe lighting control in accordance with external trigger signals is
available.
Features
Light Emitted by the Product
Items and its details to be observed are classied into the following indication:
Prohibited
Do not
disassemble
No wet
hands
Water wet
prohibited
Instruction
Unplug AC
power cord
The above marks show the items
prohibited.
The above marks show the instruction
which must be observed.
This product has been designed with full consideration of safety. Incorrect usage of the products may result in re, electric shock, or other serious accidents. Observe the
following precautions for prevention of accidents.
This product is Class-1 Laser product compliant to EN60825-1
：
2014. It is a RISK GROUP 3 product and emits high-intensity visible light.
Because light-absorbing materials convert incident light into heat, heat-sensitive or ammable light-absorbing materials may be damaged.
Always observe the following precautions when you use the product. Incorrect usage of the product may jeopardize safety.
・ Never look directly into the opening of the light guide adapter, a
light guide exit or reected light while light is being emitted. There
is a risk of damage to your cornea and retina.
・ Never cover the light guide adapter or light guide exit with your
hand or other part of your body. There is a risk of burn injury.
・ Never cover the light guide adapter or light guide exit. Doing so may
result in re.
・ Direct illumination to human body may cause burn injury. Never
illuminate ammable material, as there is a risk of re.
Items with this mark indicate
that incorrect usage may result
in serious injury or death.
Items with this mark indicate that
incorrect usage may result in
injury or property damage.
Hazards caused by incorrect usage and their levels are classied with the following indication:
Avoid places where the unit might
be exposed to water such as near
humidiers, water faucets or outside.
If water gets into the product, it may
result in re or electric shock.
Avoid places with high temperature,
high humidity or corrosive gas. Such
environments may damage the
product or result in fire or electric
shock.
Be sure to connect to ground using
AC cable with 2-flat-blade and a
round grounding pin for prevention of
electric shock.
Disassembling except for installation
and replacement of lters is strictly
prohibited to prevent re and electric
shock.
Follow the instructions properly
and avoid improper environment or
improper usage such as overvoltage.
Improper use may cause re, electric
shock, or the product malfunction.
DO NOT look at the light beam
directly. It may lead to loss of vision
or blindness.
DO NOT touch the product with wet
hands. It may cause electric shock.
DO NOT use the product if it emits
smoke, re, unusual smells, strange
sounds or becomes unusually
hot. Turn off and unplug the unit
immediately under these conditions.
DO NOT touch the parts inside.
The product has high voltage parts.
Touching these parts may result in
electric shock or burns.
DO NOT touch the product during
operation, because the surface
temperature may be from 40 to 50
degree C, and the temperature of
the light guide adapter may be over
70 degree C. Wait for a while until it
is cool enough to handle in order to
prevent burns.
Be sure to use heat-resistant light
guide so as to prevent melting or
burning of bers.
Ask [e-mail] for more details.
1
When disconnecting the cables, be sure
to hold the plug or connector, not the
cord. Pulling the cord itself may damage
it and cause re or electric shock.
Check the fan and ventilation holes
regularly to make sure they are
not covered with dust or debris.
Inadequate ventilation will keep heat
inside the product and may cause re.
DO NOT drop or give shocks to the
product. It may damage the product and
cause malfunction.
Supply the product with stable voltage
power. Voltage uctuations may cause
unstable performance or malfunction.
Prevent any dust getting into through
the air ventilation holes. Dust may cause
malfunction, damage to the product or
re.
Be sure to turn off the power, before
disconnecting cables. It may cause
malfunction or damage the product.
Be sure to keep the product and attached
cables as far away from any electrical noise
source as possible. Shield the product from
any electrical noise source, such as an
inverter and high voltage cables. A power
cable or communication cables connected
to the product should be 5 m or shorter.
Maintain a constant operating
ambient temperature in accordance
with this document. Sudden change
of temperature may cause variation of
illuminance, malfunction or fire.(e.g.
Near the outlet of air conditioners and
heaters) If you use exhaust air duct,
keep the air exhaust amount over 2.3
m3/min.
Avoid dusty places to prevent any
dust getting into the body through the
ventilation holes. Dust may damage the
product and result in re or malfunction.
Install the product unit on a stable
surface, placing the bottom-side with
rubber feet down. If it falls down, it
may cause injury or malfunction.
Be sure to install the unit in a well-
ventilated room. In order to ensure
enough room for air circulation around
the unit, maintain the clearance 100 mm
or more at the front and the back and 50
mm or more on the top and the side.
Instruction Guide
These light sources are mainly used as ultra-high intensity ber optic
illuminators for image processing and industrial inspections. They are used
with light guides attached. This enables the selection of a lighting pattern
that is suitable for the application.
Note: A light guide adapter is not provided with this product. Order one
separately.
Important Information for Equipment Safety - Read Before Use -
W A R N I N G
Warning
Caution
Warning
Caution
No wet
hands
Prohibited
Prohibited
Prohibited
Instruction
Instruction
Prohibited
Prohibited
Unplug AC
power cord
Instruction
No wet
hands
Instruction
Instruction
Instruction
Instruction
Instruction
Prohibited
Instruction
Unplug AC
power cord
Do not
disassemble
SLG-600V
SLG-600V-FC
SLG-600V-FC
(with filter changer)
Ultra-High Intensity Fiber Optic Illuminator
SLG-600V
RISK GROUP 3
WARNING IR emitted from this product.
Avoid eye exposure.Use appropriate
shielding or eye protection.
CAUTION Possibly hazardous optical
radiation emitted from this product.
Do not stare at operating lamp.
May be harmful to the eyes.
CLASS 1
LASER PRODUCT
RISK GROUP 3
WARNING LABEL
Warning
Caution
IR emitted from this product.
Avoid eye exposure. Use appropriate shielding or eye
protection.
Possibly hazardous optical radiation emitted from
this product. Do not stare at operating lamp.
May be harmful to the eyes.
Prohibited

- 2 -
Contrast Adjustment Screw
Remove the rubber cap and adjust the contrast of the LCD
with a at bladed screwdriver.
Names and Functions of Parts
Connections
2
3
Before connecting the product, make sure that the power is turned OFF.
Making connections while the power supply is ON may result in burn injury, electric shock, re, or damage to the product.
Do not place any objects within 50mm of air
vents on the side panel. Insufcient ventilation
may cause heat to accumulate inside the
product and result in re.
1
2
3
Insert the light guide into the insertion port, then tighten the
screw to secure the light guide.
Mount a light guide adapter(sold separately)to the product.
Remove the protective film from the front panel before you attach the light
guide adapter and secure the adapter with the hexagonal screws.
To control the product from an external device, connect
a suitable cable for the control method.
Controlling Operation with Parallel Communications
・ Controlling Operation with RS-232C Communications
You must provide a cable with a length of 3 m max.
The CBL-D25-3 Cable (sold separately, 3m in length) is available for
connection.
You must provide a cross cable with a length of 3 m max. RS232C-9SU-
9SU-CR1-E-(length in "m") sold by MISUMI Group Inc. is recommended
for connection.
You must provide an Ethernet cable with a length shorter than 30 m.
This product uses auto MDI/MDI-X to automatically recognize either a
cross cable or a straight cable. Cycle the power if you change the cable
type.
・ Controlling Operation with Ethernet Communications
Connect the AC power cord to the AC inlet and a wall socket.
The AC power cable included with the product is for 100 to 120V AC. If you
use the Product with 200 to 240V AC, an appropriate AC cable shown below is
required.
Press the left of the power switch to turn ON the power
supply. Press the right of the power switch to turn OFF the
power supply.
When the power supply is turned ON, the Initialization
Screen will appear on the LCD and it will be followed by
the Operation Screen. Also, the power lamp will light.
The default operating mode of the product is manual
control. Turn the Operating Knob to increase or decrease
the light intensity displayed on the left side of the LCD.
When you press the Operating Knob, the display under the
intensity will change in the following order: x1, x10, and
x100. In this way, you can set the step magnication that is
used to increment/decrement the intensity. Press the ON/
OFF Button to turn ON and OFF the light source.
To change the operating mode to enable using external control, change the setting on the
MODE Setting Screen. Refer to Operations on the LCD on Page 3 for information on the
MODE Setting Screen. You can set one of the following methods of external control in the
product. The default status of the light source is OFF for external control:
Parallel Communications with Digital/Analog Intensity Control:
Refer to Page 5, Control with External I/O Connector
Ethernet Communications: Refer to Page 6, Control with Ethernet Communications
RS-232C Communications: Refer to Page 7, Control with RS-232C Communications
Note: When you turn OFF the power, leave it OFF for at least 10 seconds before you turn it back ON.
For SLG-600V-FC, the lter No.1 is positioned behind the light guide adapter.(Refer to Page 8 for the details.)
POWER
Turning ON the Power
Adjusting the Light Intensity (in manual control)
4
5
6【
Panel 】
【
10BIT
】
0512
【
25℃
】
x1
50%
Ethernet Communication Connector
Power Switch
EXTERNAL I/O Connector
LCD
AC Inlet
Connect an External I/O cable to this connector.
Page 3
Displays the status of the product and the Setting Screen.
Used for Ethernet communications. Connect an Ethernet
cable to this connector.
(RJ-45)
Turns the power ON and OFF.
Supplies power to the product.(EN60320-1 certied C14 type)
RS-232C Communication Connector
Connect an RS-232C communication cable to this connector.
Page 7
Cooling Fan Air Inlet
This product emits high-intensity visible light. Refer
to Light Emitted by the Product on Page 1, and take
suitable safety precautions.
This product generates high temperatures. Do not
touch the area around the light guide adapter while
the product is turned ON or immediately after it is
turned OFF. Burning may result.
The shape of the light guide adapter depends on the details
of the order.
Operating Knob
Page 3
Turn: Selects the item or changes the settings. Increases/
decreases the light intensity during manual control.
Press
：
Sets the selected item.
Selects the step magnication used to increment
/decrement the intensity during manual control.
Press for approx. 3 sec.: Locks the Operating Knob and
ON/OFF Button. They will be released when this button is
pressed for approx. 3 sec.
MENU Button
Page 3
Press
：
Displays Operation Screen on LCD.
ON/OFF Button
Turns the light source ON and OFF.
This button can be used only during manual control.
Power Lamp
Lit while the power is turned ON.
Error Lamp
Lit if an error occurs. Flashes when FB is unavailable.
B
Insulator
To secure the product on the bottom side, remove the
mounting screws and tighten them again from behind
mounting holes prepared in the installation surface.
Press for approx. 4 sec.
：
Displays MENU Screen.
Light Guide Adapter
Page 2
External Input Screw Terminal Block for Filter Changer
Filters can be selected by external input through the
connector.
Filter Select Button
Filters can be selected by pushing this button which is
available only in panel mode.
Page 8
（Only for SLG-600V-FC）
Filter Changer Cover
Remove this cover to exchange lters inside.
Page 8
（The cover only for SLG-600V-FC can be used for replacement）
Inst. surface t Screw
3mm
M4×15
5mm M4×18
Caution
Warning
Warning
Page 8
Use a heat-resistant light guide.
Please inquire ([e-mail]) for the details.
Warning
Recommended
Specications
Wire diameter
1.0mm min.
Line-to line insulation withstand voltage 100MΩ min.
Ratings 250 V min., 10A min.
Withstand voltage 2,000 VAC/minute
Socket standards EN 60320-1 certied C13 type
（Only for SLG-600V-FC）
Page5~6
Page ６ to 7
Light guide
Hexagonal screw
Step magnication
Intensity
Front face
Back face
Light guide lock screw
Mounting holes
（Ø4.5mm）
Light guide adapter
Mounting screws
Insulators
Installation surface
(thickness; 3mm min.)

- 3 -
Operation with LCD
4
When the Power Switch is turned ON, the Initial Screen will appear on the LCD and it will be followed by Operation Screen 1.
To conrm the status or set up the operation of the product, you can change the screen by operating the MENU Button and the Operating Knob.
Screen transitions
Operation Screen 2
【00030:00】
【
OFF
】
0512
【
25℃
】
x1
1)
2)
50%
#Item Description
1Total time
（min.)
The total time of irradiating
period of the light source module
is displayed.
2Strobe settings
OFF ・INT ・EXT
(Refer to STROBE Setting
Screen.）
Use this screen to change the network settings.
Turn the Operating Knob to move the cursor to
the required item and then press the Operating
Knob.
Turn the Operating Knob to change the digits.
When you press the Operating Knob for the
IP*, MASK, or GATE item, the cursor will
move between the digits that are separated by
periods.
To return to the previous status so that you
can move the cursor between items, press the
MENU Button.
* If you change the port number, the step magnication will be displayed. When you
press the Operating Knob, the step magnication will change to x1, x10, x100, or
x1000.
3. NETWORK Setting Screen
【
NETWORK
】
I P 192.168. 0. 2
MASK 255.255.255. 0
PORT
x10
40001 RESET
GATE 192.168. 0. 1
Item Description Default
IP Sets the IP address of the product. 192 .168 .0. 2
MASK Sets the subnet mask of the product. 255.255.255.0
GATE Sets the default gateway of the product. 192 .168 .0.1
PORT Sets the port number to receive the data that is sent from
the external device.*40001
RESET Resets all items on this screen to the default settings. －
* If you have made changes on the NETWORK Setting Screen when you move
to the MENU Screen, a message to confirm whether to save the settings will be
displayed. If you have saved the settings when you move to the Operation Screen,
a message that prompts you to restart the product will be displayed. Follow the
instructions on the screen and turn on the power again.
Power Switch
MENU
Screen
MODE Setting
Screen
UNIT Setting
Screen
NETWORK Setting
Screen
STROBE Setting
Screen
FB/LOGIC Setting
Screen
VER/RST Setting
Screen
Press the MENU Button.
Turn the Operating Knob to select the item
and then press the Operating Knob.
Press the MENU Button.
Press and hold the MENU Button
for approximately 4 seconds.
Press the MENU Button.
Monitor Screen
1
Monitor Screen
2
Initial Screen
Operation Screen 1
Operation Screen 2
Press the
MENU Button.
Press the
MENU Button.
Press the
MENU Button.
#Item Description
1Operating
Mode The operating mode that is set on the MODE Setting Screen is displayed.
2Resolution The total number of steps in the light
intensity is displayed.
3Light Source
Temperature
The temperature of the light source
module (hereinafter referred to as LS)
is displayed.
4Intensity The current setting of the light
intensity is displayed.
5
Intensity
Indicator
The intensity is shown as a
percentage.
If an error is detected*1,icon will
be displayed.
6Magnication The step magnication that is used to increment/decrement the intensity is
displayed.*2
7 Lock Icon
This icon is displayed while operation
on the front panel is locked after
the Operating Knob is pressed for
approximately 3 sec.
8FB Icon
This icon is displayed when feedback
control*3is enable.
9
LS ON Icon
This icon is displayed while the light
source is ON.
10
Filter No.
The number of the selected lter is
displayed.
（Only for SLG-600V-FC）
Operation Screen 1
*1 Refer to Error
Information Screen
on Page 8 for the
details.
* 2: When you press
the Operating Knob,
the magnification
will change in the
following order: x1,
x10, and x100.
* 3: Refer to FB/LOGIC
Setting Screen
on Page 4 for the
details.
Screen for setting intensity steps and the unit
for temperature value to be shown.
(Defaults: 10 bits and °C)
2. UNIT Setting Screen
【
RESOLUTION
】
【
TEMP UNIT
】
°F °C
8BIT 10BIT
Item Description
8BIT Sets the total number of light intensity steps for all operating modes to 8 bits (256
steps).
10BIT Sets the total number of light intensity steps for all operating modes to 10 bits
(1024 steps).
°F Sets the temperature unit for the
Operation Screen to degrees Fahrenheit.
°C Sets the temperature unit for the
Operation Screen to degrees Celsius.
Time for strobe lighting is not accumulated.
Highlighting shows the position of the
cursor. Turn the Operating Knob to move the
cursor. Select the required item and press
the Operating Knob to change to one of the
following setting screens.
You can set up the operation of the product on the following screen.
An arrow (→ ) is displayed to the left of the current setting. Turn the
Operating Knob to move the cursor to the required item and then press the
Operating Knob to set the corresponding item. Press the MENU Button to
go back to the MENU Screen from a Setting Screen. After you move from
the MENU Screen to the Operation Screen, the settings on the Setting
Screen are stored in the product, and operation settings are updated
(except for settings on the NETWORK Setting Screen).
Set the operating mode on this screen. (Default: Panel)
1. MODE Setting Screen
MENU Screen
MENU
1. MODE
2. UNIT
3. NETWORK
4. STROBE
5. FB/LOGIC
6. VER/RST
【
MODE SET
】
RS232C
0-5V
Ethernet
Panel Digital
Item Description
Panel Sets the mode for manual control from the
front panel.
RS232C Sets the mode for external control with
RS-232C communications.
Ethernet Sets the mode for external control with
Ethernet communications.
Digital
Sets the mode for external control with
parallel communications with a digital
intensity control input. You can specify the
intensity with a digital signal input.
0-5V
Sets the mode for external control with
parallel communications with an analog
intensity control input. You can specify the
intensity with an analog signal input from
0 to 5V. The intensity on the Operation
Screen is displayed in 256 or 1024 steps.
【
Panel
】
【
10BIT
】
0512
【
25℃
】
① x 1
1)
4)
7)
8) 9)
5)
6)
2) 3)
50%
10)
Monitor Screen 1
【MON】
①
x100
LS 100
TBL 2007
PDS 1
DAC 0
MOD 1
PDT 23
1)
2)
3)
4)
5)
6)
7)
8)
#Item Description
1LS
(Light source) Light intensity level（10BIT）
（8BIT）
2TBL Brightness obtained in
calibration
3PDS Current brightness obtained
4DAC DAC value
5MOD Feedback Mode
6PDT
Temperature of light source
module
7 Filter No.
No. of lter selected(only for
SLG-600V-FC）
8 FB icon
Indicated when FB control is
available.
FB control is the function which make up for the di󱐯erence between
TBL and PDS. FB operation will stop in case TBL/PDS is within ± 2％ . In
case FB is unavailable, the Error Indicator LED will ash at an interval of 0.5
sec.
Monitor Screen 2
【MON】
①
x100
V IN xxx.xv
V OUT xx.xv
I OUT x.xv
F xxxx
F1 xxxxx
F2 xxxxx
1)
2)
3)
4)
5)
6)
7)
#Item Description
1 V IN Power supply input voltage
2 V OUT Power supply output voltage
3 I OUT Power supply input current
4 F Number of rotation by fan for
power supply（RPM）
5F1 Number of rotation by Fan 1
（RPM）
6F2 Number of rotation by Fan 2
（RPM）
7
Filter No.
The number of the selected lter
is displayed.（Only for SLG-600V-
FC）

- 4 -
Light Intensity Feedback Control
5
To move to FEEDBACK FUNCTION Screen, turn on the Power Switch pushing MENU Button and release MENU Button after the Initial Screen is displayed.
Change the screen by rotating the Operating Knob to select the menu item and pushing the knob. After settings in each setting screen, be sure to push
Menu Button to move to the Shut-down Screen, then turn off the power. By cycling the power, the settings become valid.
MENU Button
2.Select1.Select
Set light intensity
OK
START
FEEDBACK
FUNCTION Screen
STB LIGHT Screen
OPTION Setting
CALIB Screen
Calibration
FEEDBACK
FUNCTION Screen
Shut down Screen
Power OFF
CALIB Complete indicated
Initial Screen
MENU Button
Screen Transitions
[CALIB]
LS 0/1023
PDS 0
PDT 24STOP
2)
3)
1)
START
#Item Description
1LS
`Intensity level/1023
2PDS Illuminance detected
3 PDT Temperature of light
source module
Push Operating Knob to start calibration.
During calibration, lighting is ON and "CALIB
Start..” is indicated on the lowest part of the
LCD. A cursor move to “STOP.”
To stop calibration, push Operating Knob
during calibration.(Set value will not be
revised.) "User interrupt” is indicated on the
lowest part of the LCD, and a cursor move to
“START.” CALIB value will not be revised.
Approx. 10 minutes is required for calibration.
After calibration, the output value is changed
to “0,” and “CALIB Complete” is indicated.
After calibration, be sure to push MENU
Button to return to FEEDBACK FUNCTION
Screen.
Note: Be sure to perform CALIB again in
case the light guide is replaced.
CALIB Screen
Light intensity correction range is determined by correcting intensity
under the actual usage conditions.
80
60
40
20
0
100 10000
100
Light ON Time（H）
Relative Intensity（％）
10 1000
With FB control
Without FB control
Example of FB eff ect (STB LIGHT = 10000H ②)
In case feedback control is unavailable. the Error Lamp continuously  ashes.
FEECBACK FUNCTION Screen
1.STB LIGHT
2.OPTION
FEEDBACK FUNCTION
#Item Description
1STB LIGHT
Sets the period of stabilized
intensity. (Refer to "STB LIGHT
Setting" .)
2OPTION Defines variable figures shown in
“Option Setting Screen” .
Light Intensity Feedback Control
【RESET(RST)】On this screen, you can reset
the total time and the items on the Setting
Screen into their default settings(except for
the items on the NETWORK Setting Screen).
Turn the Operating Knob to move the cursor between the items. Press the Operating
Knob to tick a box next to the required item to select it.
6. VER / RST Setting Screen
【VERSION】
Ver 100
System
Total hour
OK?
γ
【RESET】
Item Description
Total hour Resets the accumulated time shown on the Operation Screen.
System
Initializes the settings in MODE Setting, UNIT Setting, Strobe Setting and FB/
LOGIC Setting.
OK? Cancels the selection of the item above.
【VERSION(VER) 】This screen shows the
version of the control software in the product.
If you inquire about the operation of the
product, inform REVOX of the version number
given on this screen.
Item Description
ON Enables feedback control to suppress  uctuations in the illumination.The
FB icon
（ ↑↓）will be displayed at the top-right of the Operation Screen.
OFF Disables feedback control to suppress  uctuations in the illumination.To
set maximum light intensity, set "OFF" in STB LIGHT Setting Screen.
negative Applies negative logic to pins 2 to 13 on the External I/O Connector and
External Input Screw Terminal Block for Filter Changer.
positive
Applies positive logic to pins 2 to 13 on the External I/O Connector and
External Input Screw Terminal Block for Filter Changer The descriptions
in this document are based on positive logic.
Use this screen to enable/disable feedback
control(FB) and set the logic of pins 2 to 13 on the
External I/O Connector and External Input Screw
Terminal Block for Filter Changer. (Default: OFF and
positive logic) Feedback control should be selected after
STB LIGHT Setting and CALIB setting (described in "5.
Light Intensity Feedback Control")are done. In case strobe
lighting is valid, FB control is invalid.
5. FB/LOGIC Setting Screen
【FB】
【
LOGIC
】
negative positive
ON OFF
Note: If you set negative logic, you will need to interpret the descriptions for when the
photocoupler is ON as for when the photocoupler is OFF. For example, for positive logic, the
light is turned OFF when the photocoupler turns ON for Pin 13 during manual control. For
negative logic, the light is turned OFF when the photocoupler turns OFF.
4. STROBE Setting Screen
【
STROBE
】
TRUP
TRDN
Wait
OFF INT EXT
xxxx
Cycle xxxxx
On xxxx
#Item Description Default Min. Max.
1OFF Disables STROBE
function. OFF - -
2INT Sets Internal Trigger*2-- - -
3EXT Sets External Trigger*3- - -
4 TRUP Sets Trigger Rising. TRUP - -
5
TRDN Sets Trigger Falling. - - -
6Wait Sets the lighting delay
time(Unit:μ sec.）
*1 0 0 9999
7On Sets the lighting time
（Unit:μ sec.）
*1 10 19999
8
Cycle
Sets the internal lighting
cycle time
（Unit:μ sec.）
*1 20 299999
*2 INT （Internal Trigger Operation Timing)
*3EXT(External Trigger Operation Timing）
Internal Trigger
Time set value
Internal lighting cycle set time>Wait time+On time×2Internal lighting cycle set time>Wait time+On time×2
Wait time ON time
Drive current
1μs>Rising time Falling time<1μs
External Trigger Signal
Wait time ON time
Drive current
1μs>Rising time Falling time<1μs
ON
OFF
ON
OFF
External Trigger cycle set time>Wait time+On time×2
Internal Trigger: External trigger input signal is not used, and the light
source is turned ON/OFF in accordance with internal lighting cycle set
value and timing set by ON WAIT time and LS ON time.
External Trigger: Light source is turned ON/OFF in accordance with the
external trigger signal and timing set by ON WAIT time and LS ON time.
Internal Trigger
Time set value
Internal lighting cycle set time>Wait time+On time×2Internal lighting cycle set time>Wait time+On time×2
Wait time ON time
Drive current
1μs>Rising time Falling time<1μs
External Trigger Signal
Wait time ON time
Drive current
1μs>Rising time Falling time<1μs
ON
OFF
ON
OFF
External Trigger cycle set time>Wait time+On time×2
Note: In case WAIT is 0 and intensity level is the highest, the response time to LS ON is within 1µs.
* 1 When you press the ON/OFF Button, the step magni cation will change to x1,
x10, x100, or x1000.
Note: In case WAIT is 0 and intensity level is the highest, the response time to LS ON is within 1µs.

- 5 -
The light intensity is controlled with parallel signal inputs. Use pins 2 to
11 (B0 to B9). Refer to the following logic table for the settings.
SLG-600VExternal circuit
Transistor (NPN)
open collector
24 VDCGND GND
Pin 1
One of the pins
2 to 13
Pin 1
One of the pins
2 to 13
SLG-600VExternal circuit
Transistor (PNP)
open collector
24 VDC
Sinking Sourcing
1
：
Photocoupler ON 0
：
Photocoupler OFF
Note: When "8BIT" is set on the UNIT Setting Screen, only pins B0 to B7 can
be used.
SET
VALUE
B9 B8 B7 B6 B5 B4 B3 B2 B1 B0
Radiant
quantity
00000000000
Min.
10000000001
20000000010
255 0011111111
1022 1111111110
1023 1111111111
Max.
Logic Table
B0 to B9
500 ms min.500 ms min.
Light intensity data 1 Light intensity data 2
Light source
status
Approx. 10 ms Approx. 10 ms
Light intensity data 2Light intensity data 2
2 ms min.2 ms min. 2 ms min.2 ms min.
Light intensity data 1Light intensity data 1
You can set up operation and conrm the status of the product with signals that are input and output on the External I/O Connector.
The following gure shows the arrangement of the connector pins. The
applicable pins depend on the operating mode that is set on the MODE
Setting Screen.
Both sinking (NPN) and sourcing (PNP) inputs are supported.
Control with EXTERNAL I/O Connector
6
EXTERNAL I/O Connector Layout(25-pin D-sub socket)
Pin
No. Signal Description
Applicability
by Control Mode
Panel RS232C/
Ethernet Digital 0-5V
1IN COM Input COMMON ● ●
2B0
Digital intensity control
input
●
3B1 ●
4B2 ●
5B3 ●
6B4 ●
7B5 ●
8B6 ●
9B7 ●
10 B8 ●
11 B9 ●
12 LOCK* Intensity lock input ●
13 LS SW Light ON/OFF input ● ●
14 TRIG_IN+ External trigger input ＋● ● ● ●
15 TRIG_IN- External trigger input －● ● ● ●
16 MONITOR
MONITOR terminal
output: Rising of lighting
can be monitored with
0-3.3V output.
● ● ● ●
17 LS
TEMPALM
Temperature Alarm
：
Light source module
(hereinafter referred
to as LS)temperature
reached to the one to
be alerted to.
● ● ● ●
18 LS ERR LS error output
：
（Refer to Page 8 Error
Information Screen.) ● ● ● ●
19 LS TMP
LS temperature
abnormality output
：
LS
temperature is out of
limitation.
● ● ● ●
20 LS ON LS ON output ● ● ● ●
21
OUT COM Output COMMON_GND ● ● ● ●
22
MONITOR
GND
Monitor Terminal
GND ● ● ● ●
23 NC －
24 AN IN Analog intensity control
input ●
25 AN GND
Analog intensity control
GND
●
Pins 1 to 13 are used for input signals that turn ON the photocouplers
inside the product to set and write data.
Input signal
Digital Intensity Control Inputs
* If "0-5V" is set on the MODE Setting Screen, you can use the intensity lock input (LOCK).
Note:The logic of pins 2 to 13 depends on the setting on the FB/LOGIC Setting Screen.
Legend ● ：
Applicable
SLG-600V External circuit 24V
Transistor (NPN)
open collector
DC
GND Pin 14
Pin 15
Input circuit
example
Pins 14 and 15 are used to input signals of external triggers only for
sinking (NPN).
Input signal specications
Rated input
voltage
Maximum input
voltage ON voltage/ ON current OFF voltage/ OFF current Response time Input
impedance
24 VDC 26.4 VDC 20 VDC min./
6 mA min. 3 VDC max./ 1 mA max. Approx. 10 ms 12 kΩ
(per terminal)
Input signal specications
Rated input
voltage
Maximum
input
voltage ON current OFF current Response time Input impedance
24 VDC 26.4 VDC 12 mA min. 1 mA max. Approx.
100 nsec. 1.8kΩ (per terminal)
25
24
13
12
2
1
15
14
Millimeter
screw threads
(M2.6)
Input circuit example
When "Digital" or "0-5V" is set on the MODE Setting Screen: Input a
signal to Pin 13 (LS SW) to turn ON the photocoupler and turn ON the
light source (Response time: 10ms typ.).
Light ON/OFF input
Input circuit example
Option Setting Screen
OPTION
CONTINUOUS 1
PD SENSE 0
Basically, PD sensitivity variable gure is "0(zero)" in case lters are not
used, and "1" in case lters are used.
After all the settings are completed, be sure to push MENU Button to
return to FEEDBACK FUNCTION Screen.
Shut-down Screen
Feedback mode exit
reboot system now!
After each setting in the above Setting
Screens regarding Light Intensity Feedback
Control, be sure to push MENU Button.
This screen shows that all of the set variable
gures have been recorded.
The recorded variable figures will be
activated by cycling the power.
Variable gures Description
0CONTINUOUS disabled
1Sets continuous CALIB
Set ”CONTINUOUS” variable figure to "1" in
case of continuous calibration for SLG-600V-
FC with plural lters. Default setting of variable
gure is “0 (zero)” which should be applied in
case only one lter is used.
PD sensitivity can be changed by PD
SENSE variable gures, in case higher
sensitivity is required.
Variable gures PD Sensitivity
0200％
1150％
Note: The startup mode after FEEDBACK FUNCTION Screen is Panel Mode.
STB LIGHT
OFF
5000H
10000H
→ 15000H
20000H
OK?
Set the period of stabilized intensity. In case
"OFF" is set, feedback control will not function.
In case 5000H, 10000H, 15000H or 20000H is
set, intensity may be stabilized in accordance
with each set period of intensity stabilization
and the corresponding maximum intensity
shown below. Then, you can move to CALIB
Setting Screen by selecting "OK?."
①In case 5000H is set, 80% of maximum light
intensity may be stabilized by intensity FB control
for 5000 h.
②In case 10000H is set, 70% of maximum light
intensity may be stabilized by intensity FB control
for 10000 h.
③In case 15000H is set, 60% of maximum light
intensity may be stabilized by intensity FB control
for 15000 h.
④In case 20000H is set, 50% of maximum light
intensity may be stabilized by intensity FB control
for 20000 h.
STB LIGHT Setting Screen
Period of
stabilization
Max.
intensity
FB
Availability
OFF 100% Unavailable
5000H ①80%
Available
10000H ②70%
15000H ③60%
20000H ④50%
Note: Set "OFF" to disable the light intensity feedback control for setting
the light intensity to the maximum.

- 6 -
Control with Ethernet Communications
7
Command Formats
You can set up operation and conrm the status of the product with commands input and output through the Ethernet Connector.
When you control operation with Ethernet communications, set "Ethernet" on the MODE Setting Screen. Also, set the network addresses on the Network
Setting Screen to enable connecting the product to the network.
Refer to Operations on the LCD on page 3 for information on the MODE Setting Screen and the Network Setting Screen.
An external device such as a PLC or image processing device sends the send data to the product. The external device can get the receive data as an execution result.
Communication Specications
TCP/IP, UDP/IP protocol, and Ethernet (Baud rate: 10 Mbps or 100 Mbps, automatically detected; Transmission medium: 10BASE-T or 100BASE-TX)
No Keepalive function is equipped with the product. The Number of TCP connection is 8.
* 1 Any changes to the above default settings will be retained after the power supply is turned OFF except for the ON/OFF setting and the lter No. setting.
* 2
Changes to settings made with instructions from E01 to E06 are enabled after the power supply to the product is cycled.
Send Data for Setting Commands
Send Data for Query Commands
* Time for strobe lighting is not accumulated.
The status between Pin 21 and one of the pins 17 to 20 on the External
I/O Connector changes from open to closed to report the status of the
product.
If the temperature of the light source module(hereinafter referred to as
LS)has reached to the one to be alerted, the circuit between Pin 17 (LS
TMP)and Pin 21(OUT COM) is closed.
If an light source error (open or shorted) is detected, the circuit between
Pin 18 (LS ERR) and Pin 21 (OUT COM) is closed.
If an LS temperature is out of limitation, the circuit between Pin 19 (LS
TMP) and Pin 21 (OUT COM) is closed.
While the LS is ON, the circuit between Pin 20 (LS ON) and Pin 21 (OUT
COM) is closed.
SLG-600VExternal circuit
Pin 21
One of the pins
17to 20
Error output Photocoupler
Load current
Output signal specications
Rated input voltage Maximum input voltage Load current Leak current
24VDC DC26.4V 10mA max 50uA max.
Example of Output circuit
Output signals
Status output
If "0-5V" is set, you can input a signal to Pin 12 (LOCK) to turn ON the
photocoupler.
The light intensity control is locked (disabled) while the photocoupler is ON.
During that time, even if the voltage that is applied to Pin 24 on the External I/O
Connector uctuates, the intensity will remain stable.
AN IN
LOCK
Light intensity (voltage) 1
Light intensity (voltage) 2
Photocoupler ON
Photocoupler OFF
Light source
status Light intensity value 1 (locked)Light intensity value 1 (locked)
Light intensity value 2Light intensity value 2
500ms min.500ms min.
100ms±50ms100ms±50ms
50ms±25ms50ms±25ms
Intensity Lock
※
If you cycle the power while the intensity control is locked, the intensity is locked to"
0(ZERO)."
Release the lock to continue operation.
The light intensity is controlled with a voltage from 0 to 5V applied to Pin
24 (AN IN). Pin 25 (AN GND) is the ground. The light intensity is from the
minimum at DC0V to the maximum at DC5V.
Analog Intensity Control Input
Note: When you use the analog intensity control input, you can use the intensity lock input
to suppress intensity uctuations caused by uctuations in the analog voltage.
Note: The light intensity that is set with the analog input is not stored in the product.
Pin 16 is the output terminal for monitoring lighting timing in STROBE
Control with an oscilloscope or other equipment.
SLG-600V
Pin 22
3.3V
Pin 16
Waveform of pulse timing
Oscilloscope
Example of output and input circuit
SLG-600VExternal circuit
Pin 25
Pin 24+5V(Maximum input voltage 5.5V)
Input circuit example
Function Description Header Send command End Code Default*1
Instruction Data
Light Intensity Setting Sets the light intensity of the product.
STX
(0x02)
WDA
When 10BIT Is Set on the UNIT Setting Screen
0000 to 1023.
(0000: Minimum intensity, 1023: Maximum intensity)
ETX
(0x03)
0000
or
000
WD8
When 8BIT Is Set on the UNIT Setting Screen
000 to 255.
(000: Minimum intensity, 255: Maximum intensity)
ON/OFF Setting Turns the light source ON or OFF. WDD 0: OFF, 1: ON 0
Pulse Mode Setting
Selects OFF, INT or EXT.
WPSET 0
：
OF F, 1： INT, 2
：
EXT 0
Pulse Trigger Setting
Sets the rising edge or falling edge.
WPEDG 0
：
Rising, 1
：
Falling 0
OnWait Setting Sets OnWait time.(μ sec)
WWAIT 0000 to 9999 0000
OnTime Setting Sets OnTime .(μ sec)
WONTM 0001 to 9999 0010
Cycle Setting Sets internal pulse cycle time.(μ sec)
WPRD 00002 to 99999 00020
Filter No. Setting Sets the number of lter
（Only for SLG-600V-FC).
WFC 1 to 5 1
Reply IP Address Setting Sets the IP address to which the product sends the execution result. WIP
000.000.000.000 to 255.255.255.255
(Specify all digits,e.g., specify 192.168.000.005
instead of 192.168.0.5)*2
192.168.000.016
Reply Port Setting
Sets the port number to which the product replies the execution
result.
WPT
0000 to 65535
(Specify all digits,e.g., specify 04561 instead of
4561.)*2
30001
Function Description Header Send command End Code
Instruction
Setting Query for Light Intensity Gets the light intensity set with the Ethernet communications.
STX
(0x02)
RDA
ETX
(0x03)
Query for ON/OFF Setting Gets the light ON/OFF setting status. RDD
Version Query Gets the version of the control software in the product. V
Temperature Query Gets values for the light source temperature. RDT
Status Query Gets the error status of the product. REC
Filter No. Query Gets the number of lter.
（Only for SLG-600V-FC）RFP
Total Time Query* Gets total time of irradiation by the light source.
RTM
Commands are exchanged by ASCII code. Commands should begin with a header code and end with an end code as control codes .

- 7 -
Control with RS-232C Communications
8
You can set up operation and conrm the status of the product with command input or output on the RS-232C Communications Connector.
When you control operation with RS-232C communications, set "RS232C" on the MODE Setting Screen.
The following gure shows the arrangement of the connector pins.
Pin No. Signal Pin No. Signal
1NC 4NC
2Rx 5GND
3Tx 6 to 9 NC
Character Code
ASCII
95
1
6
Inch
screw threads
(#4-40 UNC)
RS-232C Communication Connector Layout (9-pin D-sub Male Connector)
Examples of Command Settings
Set Commands
Query Commands
Receive Data for Setting Commands
Receive Data for Query Commands
Function Header Receive command End
Code
Normal send data Send data error Instruction Data
Light Intensity Setting, ON/OFF Setting, Reply IP Address Setting and Reply Port
Setting
ACK
(0x06)
NAK
(0x15)
*1 Sent Command Sent data
ETX
(0x03)
Function
Header Receive command End
Code
Normal send data Send data error Instruction Data
Query for Light Intensity Commands
ACK
(0x06)
NAK
(0x15)
RDA nnnn*1
ETX
(0x03)
Query for ON/OFF Setting RDD 0:OFF 1:ON
Status Query REC nnnnn*2
Temperature Query RDT nnn
Version Query Ver n.n.n.n*3
Filter No. Query(only for SLG-600C-FC) REP n
Total Time Query RTM hhhhh:mm:ss
*1 RDA commands should be in 4 digits in both cases of 10 BIT and 8 BIT is set on the Unit Setting Screen.
*2 Each “n” shows status as shown below.
*3 Version number is set. e.g) 1.0.0.0
REC command reply 1st “n” 2nd “n” 3rd “n” 4th “n” 5th “n”
Data Status Query Total irradiation time Light source
temperature status Light source open Light source short FAN speed
0Normal Normal Normal Normal Normal Normal
1Warning/LIGHT can be
ON Over 30000 hours Not available Not available Not available Not available
2Warning/LIGHT forcibly
OFF Not available Abnormal Abnormal Abnormal Not available
Function Instruction Description Send data Receive data for normal send data Receive data for send data error*
Light Intensity Setting WDA Sets the intensity to 512 in the
product. <STX>WDA0512<ETX> <ACK>WDA0512<ETX> <NAK>WDAnn<ETX>
ON/OFF Setting WDD Turns LIGHT OFF <STX>WDD0<ETX> <ACK>WDD0<ETX> <NAK>WDDnn<ETX>
Reply IP Address
Setting
WIP
Sets 192.168.0.2 as the reply
address.
<STX>WIP192,168.000.002<ETX>
<ACK>WIP192,168.000.002<ETX> <NAK>WIPnn,nn.nn.nn<ETX>
Reply Port Setting WPT Sets 13484 as the reply port.
<STX>WPT13484<ETX> <ACK>WPT13484<ETX> <NAK>WPTnn<ETX>
Pulse Mode Setting WPSET
Disables strobe control. <STX>WPSET0<ETX> <ACK>WPSET0<ETX> <NAK>WPSETnn<ETX>
OnWait Setting WWAIT
Sets 100-μs OnWait.<STX>WWAIT0100<ETX> <ACK>WWAIT0100<ETX> <NAK>WWAITnn<ETX>
OnTime Setting WONTM
Sets 1-ms OnTime. <STX>WONTM1000<ETX> <ACK>WONTM1000<ETX> <NAK>WONTMnn<ETX>
Cycle Time Setting WPRD
Sets the internal Cycle to 1000-
µs. <STX>WPRD01000<ETX> <ACK>WPRD01000<ETX> <NAK>WPRDnn<ETX>
Filter No. Setting WFC
Sets No.5 in the product.
（Only for SLG-600V-FC）
<STX>WFC5<ETX> <ACK>WFC5<ETX> <NAK>WFCnn<ETX>
Function Instruction Description Send data Receive data for normal send
data
Light Intensity Setting RDA Gets light intensity. <STX>RDA<ETX> <ACK>RDA0512<ETX>
ON/OFF Setting RDD Gets ON/OFF setting. <STX>RDD<ETX> <ACK>RDD0<ETX>
Status Query REC
Gets error status. <STX>REC<ETX> <ACK>REC00000<ETX>
Temperature Query RDT Gets light source module temperature. <STX>RDT<ETX> <ACK>RDT023<ETX>
Filter No. Query RFP
Gets Filter No.
（Only for SLG-600V-FC）<STX>RFP<ETX>
<ACK>RFP3<ETX>
Total Time Query RTM Gets total light ON time. <STX>RTM<ETX>
<ACK>RTM00015.58.30<ETX>
Total time is 15 hours, 58 minutes
and 30 seconds.
*Use a cross cable of 3-m length max.
Command Formats
An external device such as a PLC or image processing device sends the send data to the product. The external device can get the receive data as the execution result.
Commands are exchanged by ASCII code. Commands should begin with a header code and end with an end code as control codes .
For the set commands and query commands, refer to page 6, "Controlling Operation with Ethernet Communications."
* "NAK" is replied to Light intensity setting commands and ON/OFF setting commands sent NOT with RS-232C communications.
Communication specications
Communication
protocol Baud rate Data bit length Parity bits Stop bits
EIA-232
compliant
38400 bps 8 bits None 1 bit
*1 In case MODE is other than Ethernet, NAK will be replied to ON/OFF setting command.
*Actual data received by the product is replied.

- 8 -
Error Information Screen 10
#Item Description Restoration Method Error Lamp
1
Light Source Module
Temperature Abnormality
Output
The temperature of the light source module has reached to the one to be
alerted to. The light output will stop.
Turn off the power. After the light source module
temperature decreases, turn on the power again. Lighting
2Light Intensity Feedback
Control Error Status Intensity Feedback Control is unavailable. The light output will not stop. 1. Disable intensity feedback control.
2. Retry STB LIGHT setting. Flashing
3Light Source Module
Status Detection An open or shorted drive circuit has occurred. The light output will stop. Please inquire REVOX ([e-mail]). Lighting
Operation instructions for  lter changer (Only for SLG-600V-FC)
9
3
2
Filter installation
1.Turn off the power. Untighten the two
screws marked with circles and remove
the  lter changer cover.
Turn the  lter changer so that the hole on
which a  lter should be placed is around
the center of the opening.
2.Place a  lter onto a hole as shown
in the right  gure.
Place the product with front panel upright on a working table.
Use a magnetic head screw driver so that no screws are dropped in the
product. After turning off the power, the  lter changer can be turned by hands.
1
2
3
4
Diameter Thickness
Filter size 26.5( ± 0.5) ㎜ 1.0( ± 0.2) ㎜
The  lter of the size shown below could be used.
1
Filter size
4. Repeat the above procedures to
install all  lters required.
5.Reattach the  lter changer cover and
secure it with screws.
3. Put a filter holder on the filter and
secure it with three screws enclosed
with  lter holders in the carton box.
Screw position is marked with three
circles in the right  gure.
The item that corresponds to the error will be highlighted. For example, a shorted drive circuit is indicated in the screen shown below.
Press the MENU Button to switch between the Operation Screen and this screen. If the light output stops, the icon will be displayed at the center of
the intensity indicator on the Operation Screen.
Eliminate the cause of the error and then cycle the power. If the error continues after cycling the power, contact REVOX ([email protected])..
LS 25℃
LS
SHORT
FEEDBACK
【ERROR Report】
OPEN
Press MENU key
1)
3)
2)
FEEDBACK
Control methods
Filter changer can be controlled in the following
three control methods:
When the power is turned on, the  lter No.1 is
positioned behind the light guide adapter.
Filter Model No. Filter color
DFY-520A Yellow
DFM-495A Magenta
DFC-590A Cyan
DFB-500A Blue
DFG-505A Green
DFR-610A Red
1
5
4
3
2
1
5
2
3
4
1
Ethernet/RS-232C communications control
Filter No. can be selected by Filter No. Setting
Commands. Refer to Page 6 to 7.
Panel mode control (with Filter Select Button)
When you push the button once, the
 lters shift to another one by one. The
changer will turn clockwise.
Light guide
adapter position
Filter No. Rectangular
notch
Parallel communication control with external input
(External Input Screw Terminal Block for Filter Changer)
Filter No. Input Terminals (4 pins) are mounted. Through
the External Input Screw Terminal Block, input the Filter No.
in binary as shown below.
Filter No. Pin 4
（BIT 2）
Pin 3
（BIT 1）
Pin 2
（BIT 0）
1OFF OFF OFF
2OFF OFF ON
3OFF ON OFF
4OFF ON ON
5ON OFF OFF
Pin No. Function
1 Input COMMON
2 Filter No.BIT 0
3 Filter No.BIT 1
4 Filter No.BIT 2
SLG-600VExternal circuit
Transistor (NPN)
open collector
24 VDCGND GND
Pin 1
One of the pins
2 to 4
Pin 1
One of the pins
2 to 4
SLG-600VExternal circuit
Transistor (PNP)
open collector
24 VDC
Note: The AWG of the cables connectable to the External Input Screw
Terminal Block should be from 16 to 28.
Note: Filter changer response time is 100m±20ms.
Note: Whether the filter setting is completed can be confirmed by
checking the  lter number indicated on LCD has been changed or not.
The  lter number shown on LCD is selected.
Recommended  lters
Note: The above settings are in case the setting of FB/LOGIC Setting
Screen is POSITIVE. In case NEGATIVE is set, the logic is reversed.
Input signal speci cations
Rated input
voltage
Maximum input
voltage ON voltage/ ON current OFF voltage/ OFF current Response time Input
impedance
24 VDC 26.4 VDC 20 VDC min./
6 mA min. 3 VDC max./ 1 mA max. Approx. 10 ms 12 kΩ
(per terminal)
Both sinking (NPN) and sourcing (PNP) inputs are supported.
Sinking Sourcing

- 9 -
Optional Accessories (Sold Separately) 11
External I/O cable
Wire Color
Marking
Dimensions of recommended lter
Light Guide Adapter
（Applicable to light guide of OFφ8 to 14）
*A light guide adapter is not provided with the product. Please order one separately.
*For light guide adapters other than those shown above, please inquire REVOX.
Pin No. Wire color
Marking
color
Pin No. Wire color
Marking
color
1Black
- 16 Blue Black
2White
- 17 Purple Black
3Red
- 18 Gray Black
4Green
- 19 Pink Black
5Yellow
- 20 Light Green Black
6Brown
- 21 Black White
7Blue
- 22 Red White
8Purple
- 23 Green White
9Gray
- 24 Yellow White
10 Pink
- 25 Brown White
11 White Black NC Blue White
12 Red Black NC Purple White
13 Green Black NC Gray White
14 Yellow Black NC Pink White
15 Brown Black NC
Light Green White
F022
（For Sumita：0000-3794-01）
P.C.D.
120°
120°
22
20
20.2 +0.2
0
45 24
26.9 -0
0.2
M4x0.7
10
Ø
Ø
Ø
Ø
3- Ø 3.2
Thru-hole
Ø 6 3.5
Ø 35
F023
（For Hayashi：0000-3905-01）
F024
（For Moritex：0000-3906-01）
P.C.D.
22
20
15.2
+0.2
0
45 24
26.9
-0
0.2
M4x0.7
5
10
25.2
+0.2
0
120°
120°
Ø 35
3- Ø 3.2
Thru-hole
Ø 6 3.5
Ø
Ø
Ø
Ø
Ø
P.C.D. 35
29
27
15.2
+0.2
0
45 24
26.9
-0
0.2
M4x0.7 27
5
120°
120°
Ø
Ø
Ø
Ø
3- Ø 3.2
Thru-hole
Ø 6 3.5
Ø
F023
Laser marking（F023 HY）
HY
F024
Laser marking（F024 MO）
MO
F022
Laser marking（F022 SU）
SU
U n i t：ｍ ｍ
U n i t：ｍ ｍ
U n i t：ｍ ｍ
Enlarged Cable Diagram
Filter Model No. Filter color
DF Y-520A Yellow
DFM-495A Magenta
DFC-590A Cyan
DFB-500A Blue
DFG-505A Green
DFR-610A Red
Recommended Filters
Installation Instructions
12
CBL-D25-3
(54)
3000+15 0
0
(42)
(Supports digital intensity control and analog intensity control.)
M2.6
25-pin D-sub Plug
Cut off on one end
(Ø
10)
F I LTE R (φ26.5±0.5×1.0±0.2)
U n i t：m m
1.0±0.2
26.5
±0.5
Side
50mm min.
Side
50mm min.
Front
100mm min.
Back
100mm min.
Top
50mm min.
Be sure to install the product in a well-ventilated room. In order to
ensure enough room for air circulation around the unit, maintain the
clearance 100 mm or more at the front and the back and 50 mm or more
on the top and the side.

- 10 -
● Environmental Regulation
Main Specications 13
Top Face
Front Face Side Face Back Face
SLG-600V
Bottom Face
Top Face
Front Face Side Face Back Face
27020 (7)
(15)
225
22.5
145
(22.5)
Bottom Face
SLG-600V-FC
* The shape of the light guide adapter depends on the details of the order.
* The shape of the light guide adapter depends on the details of the order.
(with Filter Changer)
Product name Ultra-High Intensity Fiber Optic Illuminator
Model SLG-600V SLG-600V-FC
(with lter changer)
Applicable ber
bundle diameter Ø8 to 14 mm
Light color White
Correlated color
temperature 5600K
（typ.)
Light distribution angle 30° (Full angle)
Drive method
Constant-current drive
Light control method Variable-current control
Number of channels 1 channel
Input power supply 100 to 240 VAC (±10%), 50/60 Hz
Power consumption (typ.) 350 VA(100VAC), 370VA(240VAC)
Inrush current (typ.)
40A from a cold start
Ground leakage current 0.5 mA max. (240 VAC, 60 Hz, with 100% load)
Insulation withstand voltage
(Input-Output)
(Input-FG)
1,500 VAC for one minute, cutoff current: 10 mA,
500 VDC, 20 MΩ min.
Operating environment
(indoor use only)
Temperature: 0 to 40°C, Humidity: 20% to 80% (with no condensation)
Altitude: 2,000m max. AC Overvoltage: Category II Pollution Degree: 2
Storage environment Temperature: −15 to 60°C, Humidity: 20% to 85% (non-condensing)
Cooling method Forced cooling
CE
Safety standard : conforms to EN61010-1,EN62311-2008
EMC standard : conforms to EN61000-6-2,
EN61000-6-4,EN50581-2012
RoHS Directive Compliant
Material, coating,
and surface processing
Aluminum alloy (Red alumite)
Weight 8kg max. 8.5kg max.
Accessories
One Instruction Guide, One 2-m-long 3-pole AC power cable
with ground terminal, (Only for SLG-600V-FC)ve lter holders
and 18 screws for lter holders
Warranty Information
EXCEPT FOR THE EXPRESS WARRANTIES STATED IN THIS DOCUMENT, REVOX MAKES NO ADDITIONAL WARR ANTIES, EXPRESS,
IMPLIED, OR STATUTORY, AS TO ANY MATTER WHATSOEVER. IN PARTICULAR, ANY AND ALL WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR PARTICULAR PURPOSE ARE EXPRESSLY EXCLUDED. EXCEPT AS EXPRESSLY SET FORTH
HEREIN, REVOX MAKES NO WARR ANTIES WITH RESPECT TO THE PRODUCTS.
WARR ANTY PERIOD: ONE YEAR, STARTING FROM REVOX Inc. SHIPPING DATE.
REVOX Inc. WILL REPAIR OR REPLACE THE PRODUCT FREE OF CHARGE IF IT SHOULD FAIL TO FUNCTION OR IF THE RADIANT
QUANTITY OF THE PRODUCT SHOULD DROP TO 50% OR LESS OF ITS INITIAL RADIANT QUANTITY WITHIN THE SPECIFIED
WARR ANTY PERIOD. IF EITHER OF THESE CONDITIONS OCCURS, PLEASE TAKE THE PRODUCT TO YOUR REVOX SALES
REPRESENTATIVE.
WARR ANTY TERMS
1 REVOX Inc. WILL REPAIR OR REPLACE THE PRODUCT FREE OF CHARGE IF IT SHOULD FAIL TO FUNCTION UNDER
USE ON OUR SPECIFIED CONDITION IN ACCORDANCE WITH THE INSTRUCTION GUIDE AND OTHER WRITTEN CAUTIONS DURING
THE INDICATED WARRANTY PERIOD OF TWO YEARS.
2 REVOX Inc. WILL REPAIR OR REPLACE THE PRODUCT FREE OF CHARGE IF ITS RADIANT QUANTITY SHOULD DROP
TO 50% OR LESS OF ITS INITIAL RADIANT QUANTITY UNDER USE ON OUR SPECIFIED CONDITION IN ACCORDANCE WITH THE
INSTRUCTION GUIDE AND OTHER WRITTEN CAUTIONS DURING THE INDICATED WARR ANTY PERIOD OF ONE YEAR.
3 REVOX Inc. WILL CHARGE A REPAIR FEE UNDER THE FOLLOWING CONDITIONS:
1) IF THE PRODUCT HAS BEEN SUBJECTED TO MISUSE, UNAUTHORIZED REPAIRS, OR MODIFICATION FROM ITS
ORIGINAL DESIGN.
2) IF THE PRODUCT HAS BEEN DAMAGED FROM IMPACTS DUE TO INAPPROPRIATE HANDLING.
3) IF DAMAGE TO THE PRODUCT RESULTS FROM EXTERNAL CAUSES INCLUDING ACCIDENTS, FIRE, POLLUTION,
RIOTS, COMMUNICATION FAILURES, EARTHQUAKES, THUNDERSTORMS, WIND AND FLOOD DAMAGE, OR ANY OTHER
ACT OF PROVIDENCE, OR FROM ANY EXTR AORDINARY CONDITIONS SUCH AS ELECTRICAL SURGES, WATER LEAKAGE,
CONDENSATION, OR THE USE OF CHEMICALS.
4)
IF THE DAMAGE RESULTS FROM CONNECTION TO ANY POWER SUPPLY OR TO ANY EQUIPMENT WHICH REVOX Inc .
DOES NOT MANUFACTURE OR DOES NOT SPECIFY FOR USE.
4 REVOX ASSUMES NO LIABILITY FOR ANY PURCHASER’S SECONDARY DAMAGE (DAMAGE OF EQUIPMENT, LOSS
OF OPPORTUNITIES, LOSS OF PROFITS, ETC.) OR ANY OTHER DAMAGE RESULTING FROM A FAILURE OF OUR PRODUCT.
THIS WARRANTY INFORMATION PROVIDES THE SCOPE OF REVOX'S PRODUCT WARRANTY WITHIN THE SPECIFIED PERIOD, AND
DOES NOT INDICATE OR IMPLY ANY FURTHER GUARANTEE BEYOND THE WARRANTY TERMS.
CONTACT REVOX FOR INQUIRIES OR INFORMATION ON REPAIRS TO THE PRODUCT AFTER THE EXPIR ATION OF THE WARRANTY.
NOTE: THE R ADIANT QUANTIT Y REFERS TO THE WATTAGE OF PHYSICAL ENERGY R ADIATED FROM AN LIGHT SOURCE. IT
REFERS TO THE RADIATION LUMINOSITY OF THE LIGHT SOURCE MEASURED UNDER CONDITIONS SPECIFIED BY REVOX OR
THE RADIATION ILLUMINATION OF THE LIGHT SOURCE UNDER SPECIFIED IRRADIATION CONDITIONS. REVOX SPECIFIES THE
RADIANT QUANTITY FOR EACH LIGHT BECAUSE THE MEASUREMENT AND IRRADIATION CONDITIONS VARY FROM THE FORM,
THE APPLICATION AND THE IRRADIATION WAVELENGTH.
Do not use the product in the following situations.
Under conditions or in an environment not described in this instruction guide.
In nuclear energy control systems, railroad systems, aviation systems, vehicles, combustion equipment, medical
equipment, amusement machines, or safety equipment.
In applications involving serious risk to life or property, particularly applications demanding a high level of safety.
Contents of this Instruction Guide may be changed without prior notice.
Illustrations used in this Instruction Guide may differ from actual products.
REVOX maintains the copyright on this Instruction Guide. Unauthorized transfer or reproduction is strictly
prohibited.
For information on compliance with product standards and environmental regulations, refer to the REVOX website
or to product catalogs.
China RoHS Directive
Usage deadline for environmental protection
The number used in this logo is based on “Management Methods for Restricting Hazardous
Substances Used in Electric and Electronic Products” and related regulations from People’s Republic
of China. It shows the product usage duration in years for environmental protection. After nishing
a product usage, the product needs to be re-used or discarded appropriately following local law and
regulations, complying with safety and usage caution.
Usage
Deadline for
Environmental
Protection
Product name
Names and contents of hazardous substances
Lead
(Pb)
Mercury
(Hg)
Cadmium
(Cd)
Hexavalent
chromium
(Cr(VI))
PBB PBDE
Light,
Control Unit,
or Optional
product
(This table is made in compliance with SJ/T11364 regulations.)
〇: Indicates that this toxic or hazardous substances contained in all the homogeneous materials for this
part, according to GB/T26572 is within the limit requirement.
×: Indicates that this toxic or hazardous substance contained in all the homogeneous materials for this
part, according to GB/T26572, is over the limit requirement.
*Lead and cadmium are excluded in EU RoHS
Names and contents of hazardous substances
China RoHS Directive is formally known as “Management Methods for Restricting Hazardous Substances
Used in Electric and Electronic Products”, which was implemented on July 1, 2016 in China. Same as EU RoHS
Directive, this regulation restricts the usage of six substances such as lead, mercury, cadmium, hexavalent
chromium, polybrominated biphenyl (PBB), and polybrominated diphenyl ether (PBDE). This regulation requires
electronic information products which are manufactured or imported, and sold in China, to clearly disclose
contents of the 6 restricted substances listed below.
环保
使用期限 产品
有害物质的名称及含量
铅
(Pb)
汞
(Hg)
镉
(Cd)
六价铬
(Cr(VI))
多溴联苯
(PBB)
多溴二苯醚
(PBDE)
照明、
电源或
任选付件
( 本表格依据 SJ/T11364 的规定编制。)
○ ： 表示该有毒有害物质在该部件所有均质材料中的含量均在 GB/T26572 标准规定的限量要求以下。
× ： 表示该有毒有害物质至少在该部件的某一均质材料中的含量超出 GB/T26572 标准规定的限量要求。
（注）铅和镉中的“×”，因欧洲 RoHS 没限定，故用“○”表示。
产品中有害物质的名称及含量
环保使用期限
此标志的数字是根据中华人民共和国电器电子产品有害物质限制使用管理办法以及有关标准等，表示该产品
的环保使用期限的年数。遵守产品的安全和使用上的注意，在产品使用后采取适当的方法根据各地法律，
规定，回收再利用或进行废弃处理。
NOTE:Standards for "RoHS Directive-Compliant Products"
Lead Mercury Cadmium Hexavalent chromium PBB PBDE
1000ppm max. 1000ppm max. 100ppm max. 1000ppm max. 1000ppm max. 1000ppm max.
(Items that are exempted in the RoHS Directive are excluded from these standards.)
The RoHS Directive is short for the “restriction of use of certain hazardous substances in electrical and
electronic equipment.” As a directive, it restricts the use of specic hazardous substances for new electrical and
electronic equipment marketed in the EU on or after July 1, 2006, and restricts the use of six substances, which
are (1) lead, (2) mercury, (3) cadmium, (4) hexavalent chromium, (5) polybrominated biphenyl (PBB), and (6)
polybrominated diphenyl ether (PBDE)
EU RoHS Directive
Copyright© 2018 REVOX Inc. All Rights Reserved.
Descriptions in this instruction guide are based on information available as of January 2019 SPC-10493-00E.
Ask any product queries to the following.
Kamimizo1880-2 SIC-3, Chuuou-ku, Sagamihara-shi,Kanagawa 252-0243 Japan
E-mail : [e-mail] : [phone] Fax : [phone]
Headquarters
Use our website for the detail. http://www.revox.jp
REVOX,Inc.
